CY-WDCB7UT 1 of 12 User’s manual CY-WDCB7UT V1.0 CY-WDCB7UT 2 of 12 CY-WDCB7UT 3 of 12 CY-WDCB7UT 4 of 12 Contents 1. Package Components .............................................................................................................................................................. 5 2. Computer requirements ......................................................................................................................................................... 5 3. S/W installation .......................................................................................................................................................................... 6 4. Connecting Wireless USB dongle to USB port ............................................................................................................ 8 5. Cautions ...................................................................................................................................................................................... 11 6. CY-WDCB7UT specification ................................................................................................................................................ 12 CY-WDCB7UT 5 of 12 1. Package Components 2. Computer requirements ™ 1.2 GHz or higher processor (Intel® Pentium®/Celeron® family, or AMD K6®/AMD Athlon™/AMD Duron™ family, or compatible processor recommended. Intel® Core™ 2 Duo 2.0 GB or higher processor recommended for optimal video performance.) ™ 512 MB memory or higher (1 GB memory or higher recommended) ™ USB 2.0 port ™ 50 MB of available disk space ™ Microsoft® Windows® XP (32-bit edition) with SP2/SP3, or Microsoft® Windows Vista® (32-bit or 64-bit editions) with SP1 or Microsoft® Windows 7® (32-bit or 64-bit editions). CY-WDCB7UT 6 of 12 3. S/W installation z Put the CD to computer CD driver which is provided. z Click the installation program in the CD z Install Wireless USB driver. Click Next CY-WDCB7UT 7 of 12 z If you agree the agreement, click the “I Accept”. z Click the Next after addressing the installation path. CY-WDCB7UT 8 of 12 z Click the finish and complete the wireless manager program. z Reboot the computer after finishing the installation. 4. Connecting Wireless USB dongle to USB port ● Plug the USB dongle to the USB port in computer. NOTE: you can use USB extension cable if your computer is desktop PC. Be careful there is no object between USB dongle and receiver. z New hardware device installation message is showed in the tray. Please wait until completing of the installation. CY-WDCB7UT 9 of 12 z If new device installation is completed, click the “wireless Connection Manager” for running the program. Then you can see the connectable monitors. ( Wireless Connection Manager icon) CY-WDCB7UT 10 of 12 z If you select and click the monitor device and it becomes Connected Monitor. If you want automatic connection, click the right button of mouse and select ”Set as default”. CY-WDCB7UT 11 of 12 5. Cautions This device uses ultra high frequency radio. Therefore if there’s an object like concrete wall or furniture etc, between USB dongle and receiver device, the radio performance will be decreased much. Any obstacle objects should not be between USB dongle and receiver. The operating range is 5~10m and it can be varied according the environment. CY-WDCB7UT 12 of 12 6. CY-WDCB7UT specification CY-WDCB7UT Model Name CY-WDCB7UT Wireless Technology UWB(Ultra Wide Band)/IEEE 802.15.3a Data rate 53.3~480Mbps Band Group(BG) 1,3,6(3.1GHz~8.9GHz) (some of BGs are available based on country regulation) PC interface USB 2.0 Power USB self powered Operating System Support Microsoft Windows XP with SP2 Microsoft Vista 32/64 Microsoft Windows 7 Operating condition 5 to 35°C(41 to 95 °F) / 20 to 80 % relative humidity Non-operating condition -20 to 65°C(-4 to 149 °F)/10 to 90% relative humidity Warranty One-year limited warranty

CY-WDCB7UT 1 of 12 User’s manual CY-WDCB7UT V1.0 CY-WDCB7UT 2 of 12 CY-WDCB7UT 3 of 12 FCC information FCC notice "Declaration of Conformity Information" This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 1. Reorient or relocate the receiving antenna. 2. Increase the separation between the equipment and receiver. 3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. 4. Consult the dealer or an experienced radio/TV technician for help. FCC Conditions This equipment has been tested and found to comply with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference (2) This device must accept any interference received, including interference that may cause undesired operation. FCC Notice "Equipment Authorization" Information This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device is authorized under Title 47 CFR 15.519 (the FCC Rules and Regulations). The operation of this device is subject to the following restriction: This UWB device shall transmit only when it is sending information to an associated receiver. This UWB device shall cease transmission within 10 seconds unless it receives an acknowledgement from the associated receiver that its transmission is being received. An acknowledgement of reception must continue to be received by the transmitting device at least every 10 seconds of operation or the UWB device must cease transmitting. Changes or modifications made to this equipment not expressly approved by SAMSUNG or parties authorized by SAMSUNG could void the user's authority to operate the device under the FCC Equipment Authorization. This includes changes or substitutions of the antennas which are furnished with the device. UWB devices may not be employed for the operation of toys. Operation onboard an aircraft, a ship or satellite is prohibited. CY-WDCB7UT 4 of 12 Contents 1. Package Components .............................................................................................................................................................. 5 2. Computer requirements ......................................................................................................................................................... 5 3. S/W installation .......................................................................................................................................................................... 6 4. Connecting Wireless USB dongle to USB port ............................................................................................................ 8 5. Cautions ...................................................................................................................................................................................... 11 6. CY-WDCB7UT specification ................................................................................................................................................ 12 CY-WDCB7UT 5 of 12 1. Package Components 2. Computer requirements ™ 1.2 GHz or higher processor (Intel® Pentium®/Celeron® family, or AMD K6®/AMD Athlon™/AMD Duron™ family, or compatible processor recommended. Intel® Core™ 2 Duo 2.0 GB or higher processor recommended for optimal video performance.) ™ 512 MB memory or higher (1 GB memory or higher recommended) ™ USB 2.0 port ™ 50 MB of available disk space ™ Microsoft® Windows® XP (32-bit edition) with SP2/SP3, or Microsoft® Windows Vista® (32-bit or 64-bit editions) with SP1 or Microsoft® Windows 7® (32-bit or 64-bit editions). CY-WDCB7UT 6 of 12 3. S/W installation z Put the CD to computer CD driver which is provided. z Click the installation program in the CD z Install Wireless USB driver. Click Next CY-WDCB7UT 7 of 12 z If you agree the agreement, click the “I Accept”. z Click the Next after addressing the installation path. CY-WDCB7UT 8 of 12 z Click the finish and complete the wireless manager program. z Reboot the computer after finishing the installation. 4. Connecting Wireless USB dongle to USB port ● Plug the USB dongle to the USB port in computer. NOTE: you can use USB extension cable if your computer is desktop PC. Be careful there is no object between USB dongle and receiver. z New hardware device installation message is showed in the tray. Please wait until completing of the installation. CY-WDCB7UT 9 of 12 z If new device installation is completed, click the “wireless Connection Manager” for running the program. Then you can see the connectable monitors. ( Wireless Connection Manager icon) CY-WDCB7UT 10 of 12 z If you select and click the monitor device and it becomes Connected Monitor. If you want automatic connection, click the right button of mouse and select ”Set as default”. CY-WDCB7UT 11 of 12 5. Cautions This device uses ultra high frequency radio. Therefore if there’s an object like concrete wall or furniture etc, between USB dongle and receiver device, the radio performance will be decreased much…

Text truncated - open the document above for the full version.

CY-WDCB7UT 1 of 13 User’s manual CY-WDCB7UT V1.0 CY-WDCB7UT 2 of 13 CY-WDCB7UT 3 of 13 FCC information FCC notice "Declaration of Conformity Information" This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 1. Reorient or relocate the receiving antenna. 2. Increase the separation between the equipment and receiver. 3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. 4. Consult the dealer or an experienced radio/TV technician for help. FCC Conditions This equipment has been tested and found to comply with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference (2) This device must accept any interference received, including interference that may cause undesired operation. FCC Notice "Equipment Authorization" Information This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device is authorized under Title 47 CFR 15.519 (the FCC Rules and Regulations). The operation of this device is subject to the following restriction: Changes or modifications made to this equipment not expressly approved by SAMSUNG or parties authorized by SAMSUNG could void the user's authority to operate the device under the FCC Equipment Authorization. This includes changes or substitutions of the antennas which are furnished with the device. UWB devices may not be employed for the operation of toys. Operation onboard an aircraft, a ship or satellite is prohibited. CY-WDCB7UT 4 of 13 IC Statement This UWB RF module apparatus complies with Canadian ICES-003 and RSS-GEN. This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. RF exposure This device and its antenna(s) must not be co-located or operation in conjunction with any other antenna or transmitter. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. CY-WDCB7UT 5 of 13 Contents 1. Package Components .............................................................................................................................................................. 6 2. Computer requirements ......................................................................................................................................................... 6 3. S/W installation .......................................................................................................................................................................... 7 4. Connecting Wireless USB dongle to USB port ............................................................................................................ 9 5. Cautions ...................................................................................................................................................................................... 12 6. CY-WDCB7UT specification ................................................................................................................................................ 13 CY-WDCB7UT 6 of 13 1. Package Components 2. Computer requirements  1.2 GHz or higher processor (Intel® Pentium®/Celeron® family, or AMD K6®/AMD Athlon™/AMD Duron™ family, or compatible processor recommended. Intel® Core™ 2 Duo 2.0 GB or higher processor recommended for optimal video performance.)  512 MB memory or higher (1 GB memory or higher recommended)  USB 2.0 port  50 MB of available disk space  Microsoft® Windows® XP (32-bit edition) with SP2/SP3, or Microsoft® Windows Vista® (32-bit or 64-bit editions) with SP1 or Microsoft® Windows 7® (32-bit or 64-bit editions). CY-WDCB7UT 7 of 13 3. S/W installation  Put the CD to computer CD driver which is provided.  Click the installation program in the CD  Install Wireless USB driver. Click Next CY-WDCB7UT 8 of 13  If you agree the agreement, click the “I Accept”.  Click the Next after addressing the installation path. CY-WDCB7UT 9 of 13  Click the finish and complete the wireless manager program.  Reboot the computer after finishing the installation. 4. Connecting Wireless USB dongle to USB port ● Plug the USB dongle to the USB port in computer. NOTE: you can use USB extension cable if your computer is desktop PC. Be careful there is no object between USB dongle and receiver.  New hardware device installation message is showed in the tray. Please wait until completing of the installa…

Text truncated - open the document above for the full version.

1 From: Claire Hoque, [email protected] To: Jyun‐Cheng Chen, [email protected] Re: FCC ID: A3LCYWDCB7UT Applicant: Samsung Electronics Co Ltd Correspondence Reference Number: 42088 Form 731 Confirmation Number: EA198143 Date of Original E‐mail: 06/18/2012 1. The new operational description's explanations on the country code, band group selection, channel spacing, emission at 1593/18896 MHz and the 10‐second stop transmission time are acceptable. However, the document was not issued by the responsible party. Please ask the applicant to attest that the operational description submitted by the chipset vendor is truthful and fully representative of the final product. This attestation is highly desirable because we are still concerned with the practice of fixing country code at time of production. Such approach would not only create multiple SKUs (thus a production and inventory inconvenience unless for a high volume product) but also potential customer complaints when the laptop travels to another regulatory domain with the same USB dongle. <answer> pls see Samsung Attestation Letter. 2. Unlicensed intentional radiators are restricted to transmit within the authorized frequency range. FCC did not explicitly agree for U9YAL5625 to omit frequency stability test. In fact, the general rule in 15.31(e) specifies frequency stability test against voltage fluctuation. Furthermore, 15.215(c) also states that "The requirement to contain the designated bandwidth of the emission within the specified frequency band includes the effects from ...the frequency stability of the transmitter over expected variations in temperature and supply voltage." With the lower edge of the lowest channel only 68 MHz away from the lowest frequency allowed under the provision of 15.519, frequency stability tests should be conducted. We may also review U9YAL5625 grant if resource permits. <answer> pls see revised Test Report. Thanks, UL CCS

416, Maetan-3 Dong , Yeongtong-Gu, Suwon-City, Gyeonggi-Do 443-742 South Korea Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 Date: June 25, 2012 FCC ID: A3LCYWDCB7UT To Whom It May Concern: As per FCC’s request, Samsung Electronics Co., Ltd., hereby attests that the operational description submitted by Alereon, Inc for FCC evaluation is truthful and fully representative of the final product. Sincerely, ---------------------------------------------------- NAME : Jaywoo Lee TITLE : Engineer COMPANY : Samsung Electronics Co., Ltd. 416, Maetan-3 Dong , Yeongtong-Gu, Suwon-City, Gyeonggi-Do, 443-742, South Korea

1 From: Claire Hoque, [email protected] To: Jyun‐Cheng Chen [email protected] Re: FCC ID: A3LCYWDCB7UT Applicant: Samsung Electronics Co Ltd Correspondence Reference Number: 42117 Form 731 Confirmation Number: EA198143 Date of Original E‐mail: 06/26/2012 Please review/correct the power number (0 Watts) entered on Form 731. The power listed on the grant should be the total transmit power, instead of the level within 50 MHz (or 8 MHz or 1 MHz) in compliance tests. <answer> The total power is 0.0000035 watts (3.5 uw). However, FCC 731 form does not allow us to list 0.0000035 watts, so only 0 Watt showed in 731 form. Please also enter comments, which become the grant notes/conditions; or you can leave it to the FCC. <answer> we would like FCC to create the grant notes/conditions. Thanks, UL CCS

1 From: Claire Hoque, [email protected] To: Jyun-Cheng Chen [email protected] Re: FCC ID: A3LCYWDCB7UT Applicant: Samsung Electronics Co Ltd Correspondence Reference Number: 42127 Form 731 Confirmation Number: EA198143 Date of Original E-mail: 06/26/2012 Please review the total power number on Form 731. <answer> Sorry, I could not revise any data in completed 731 form, could you please revise power data for us? Here is our response for the power data issue: The total worst-case average power is 0.0000062 watts (6.2 uw). Thanks, UL CCS

7. PACKAGE DIMENSION 7.1 LABEL Requirement Label, pasted on the bottom of cover Material: PP MATIC/S692N/GB Label Image 7.2 LABEL location

FCC CFR47 PART 15 SUBPART F CERTIFICATION TEST REPORT FOR UWB RADIO DEVICE WITH USB 2.0 INTERFACE MODEL NUMBER: CY-WDCB7UT FCC ID: A3LCYWDCB7UT REPORT NUMBER: 12U14355-1 ISSUE DATE: APRIL 19, 2012 Prepared for SAMSUNG ELECTRONICS CO., LTD. 416, MAETAN 3-DONG, YEONGTONG-GU, SUWON-CITY, GYEONGGI-DO KOREA Prepared by COMPLIANCE CERTIFICATION SERVICES (UL CCS) 47173 BENICIA STREET FREMONT, CA 94538, U.S.A. TEL: (510) 771-1000 FAX: (510) 661-0888 REPORT NO: 12U14355-1 DATE: APRIL 19, 2012 FCC ID: A3LCYWDCB7UT Page 2 of 72 COMPLIANCE CERTIFICATION SERVICES (UL CCS) FORM NO: CCSUP4701E 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL CCS. Revision History Rev. Issue Date Revisions Revised By -- 4/19/2012 Initial Issue M. Heckrotte REPORT NO: 12U14355-1 DATE: APRIL 19, 2012 FCC ID: A3LCYWDCB7UT Page 3 of 72 COMPLIANCE CERTIFICATION SERVICES (UL CCS) FORM NO: CCSUP4701E 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL CCS. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS .................................................................................... 4 2. TEST METHODOLOGY ........................................................................................................ 5 3. FACILITIES AND ACCREDITATION .................................................................................... 5 4. CALIBRATION AND UNCERTAINTY .................................................................................. 5 4.1. MEASURING INSTRUMENT CALIBRATION ................................................................ 5 4.2. SAMPLE CALCULATION ............................................................................................... 5 4.3. MEASUREMENT UNCERTAINTY ................................................................................. 5 5. EQUIPMENT UNDER TEST ................................................................................................. 6 5.1. DESCRIPTION OF EUT ................................................................................................. 6 5.2. OPERATING FREQUENCY RANGE ............................................................................. 6 5.3. MAXIMUM OUTPUT POWER ........................................................................................ 6 5.4. DESCRIPTION OF AVAILABLE ANTENNAS ................................................................ 6 5.5. SOFTWARE AND FIRMWARE ...................................................................................... 6 5.6. WORST-CASE CONFIGURATION ................................................................................ 6 5.7. OPERATING MODE ....................................................................................................... 6 5.8. DESCRIPTION OF TEST SETUP .................................................................................. 7 6. TEST AND MEASUREMENT EQUIPMENT ......................................................................... 9 7. UWB TEST PROCEDURES ................................................................................................ 10 8. LIMITS AND RESULTS ...................................................................................................... 11 8.1. UWB BANDWIDTH, CENTER FREQUENCY, AND FRACTIONAL BW ...................... 11 8.1.1. UWB BANDWIDTH FOR BG1 .............................................................................. 12 8.1.2. UWB BANDWIDTH FOR BG3 .............................................................................. 18 8.1.3. UWB BANDWIDTH FOR BG6 .............................................................................. 24 8.2. PEAK POWER ............................................................................................................. 30 8.3. RADIATED EMISSIONS ABOVE 960 MHz .................................................................. 32 8.3.1. RADIATED EMISSIONS ABOVE 960 MHz FOR BG1 .......................................... 34 8.3.2. RADIATED EMISSIONS ABOVE 960 MHz FOR BG3 .......................................... 43 8.3.3. RADIATED EMISSIONS ABOVE 960 MHz FOR BG6 .......................................... 52 8.4. RADIATED EMISSIONS AT OR BELOW 960 MHz ..................................................... 61 9. AC POWER LINE CONDUCTED EMISSIONS ................................................................... 65 10. SETUP PHOTOS ............................................................................................................. 69 REPORT NO: 12U14355-1 DATE: APRIL 19, 2012 FCC ID: A3LCYWDCB7UT Page 4 of 72 COMPLIANCE CERTIFICATION SERVICES (UL CCS) FORM NO: CCSUP4701E 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL CCS. 1. ATTESTATION OF TEST RESULTS COMPANY NAME: SAMSUNG ELECTRONICS CO., LTD. 416, MAETAN 3-DONG, YEONGTONG-GU, SUWON-CITY, GYEONGGI-DO KOREA EUT DESCRIPTION: UWB RADIO DEVICE WITH USB 2.0 INTERFACE MODEL: CY-WDCB7UT SERIAL NUMBER: Prototype DATE TESTED: APRIL 3 TO 9, 2012 APPLICABLE STANDARDS STANDARD TEST RESULTS CFR 47 Part 15 Subpart F Pass Compliance Certification Services (UL CCS) tested the above equipment in accordance with the requirements set forth in the above standards. All indications of Pass/Fail in this report are opinions expressed by UL CCS based on interpretations and/or observations of test results. Measurement Uncertainties were not taken into account and are published for informational purposes only. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Note: The results documented in this report apply only to the tested sample, under the conditions and modes of operat…
