This user manual includes detailed usage instructions for your camera. Please read this manual thoroughly. Click a topic Basic troubleshooting Quick reference Contents Basic functions Extended functions Shooting options Playback/Editing Wireless network Settings Appendixes Index DV180F 1 Prevent damage to subjects’ eyesight. Do not use the flash in close proximity (closer than 1 m/3 ft) to people or animals. If you use the flash too close to your subject’s eyes, this can cause temporary or permanent eyesight damage. Keep your camera away from small children and pets. Keep your camera and all accessories out of the reach of small children and animals. Small parts may cause choking or serious injury if swallowed. Moving parts and accessories may present physical dangers as well. Do not expose the camera to direct sunlight or high temperatures for an extended period of time. Prolonged exposure to sunlight or extreme temperatures can cause permanent damage to your camera’s internal components. Health and safety information Always comply with the following precautions and usage tips to avoid dangerous situations and ensure peak performance of your camera. Warning—situations that could cause injury to yourself or others Do not disassemble or attempt to repair your camera. This may result in electric shock or damage to the camera. Do not use your camera near flammable or explosive gases and liquids. This may cause a fire or explosion. Do not insert flammable materials into the camera or store these materials near the camera. This may cause a fire or electric shock. Do not handle your camera with wet hands. This may result in electric shock. 2 Avoid covering the camera or charger with blankets or clothes. The camera may overheat, which may distort the camera or cause a fire. Do not handle the power supply cord or go near the charger during a thunderstorm. This may result in electric shock. If liquid or foreign objects enter your camera, immediately disconnect all power sources, such as the battery or charger, and then contact a Samsung service center. Comply with any regulations that restrict the use of a camera in a certain area. • Avoid interference with other electronic devices. • Turn off the camera when in an aircraft. Your camera can cause interference with aircraft equipment. Follow all airline regulations and turn off your camera when directed by airline personnel. • Turn off the camera near medical equipment. Your camera can interfere with medical equipment in hospitals or health care facilities. Follow all regulations, posted warnings, and directions from medical personnel. Avoid interference with pacemakers. Maintain a minimum of 15 cm between this camera and all pacemakers to avoid potential interference, as recommended by the manufacturer and the independent research group, Wireless Technology Research. If you have any reason to suspect that your camera is interfering with a pacemaker or other medical device, turn off the camera immediately and contact the manufacturer of the pacemaker or medical device for guidance. Health and safety information 3 Caution—situations that could cause damage to your camera or other equipment Remove the batteries from your camera when storing it for an extended period of time. Installed batteries may leak or corrode over time and cause serious damage to your camera. Use only authentic, manufacturer-recommended, Lithium-ion replacement batteries. Do not damage or heat the battery. Inauthentic, damaged, or heated batteries may cause a fire or personal injury. Use only Samsung-approved batteries, chargers, cables and accessories. • Using unauthorized batteries, chargers, cables or accessories can cause batteries to explode, damage your camera, or cause injury. • Samsung is not responsible for damage or injuries caused by unapproved batteries, chargers, cables or accessories. Use the battery only for its intended purpose. Misusing the battery may cause a fire or electric shock. Do not touch the flash while it fires. The flash is very hot when fired and may burn your skin. When you use the AC charger, turn off the camera before you disconnect the power to the AC charger. Failing to do so may result in fire or electric shock. Disconnect the charger from the wall socket when not in use. Failing to do so may result in fire or electric shock. Do not use a damaged power supply cord, plug, or loose outlet when you charge batteries. This may cause a fire or electric shock. Do not allow the AC charger to come in contact with the +/- terminals on the battery. This may cause a fire or electric shock. Health and safety information 4 Health and safety information Do not force the camera’s parts or apply pressure to the camera. This may cause your camera to malfunction. Exercise caution when you connect cables or adapters and install batteries and memory cards. If you force the connectors, improperly connect cables, or improperly install batteries and memory cards, you can damage ports, connectors, and accessories. Keep cards with magnetic strips away from the camera case. Information stored on the card may be damaged or erased. Never use a damaged charger, battery, or memory card. This may result in electric shock or camera malfunction or cause a fire. Check that the camera is operating properly before use. The manufacturer takes no responsibility for any loss of files or damage that may result from camera malfunction or improper use. You must plug the small end of the USB cable into your camera. If the cable is reversed, it may damage your files. The manufacturer is not responsible for any loss of data. Avoid interference with other electronic devices. Your camera emits radio frequency (RF) signals that may interfere with unshielded or improperly shielded electronic equipment, such as pacemakers, hearing aids, medical devices, and other electronic devices in homes or vehicles. Consult the manufacturers of your electronic devices to solve any interference problems you…

Text truncated - open the document above for the full version.

Extended functions 51 Using Magic modes Capture a photo or record a video with various effects. 4 Align your subject in the frame, and then half-press [Shutter] to focus. 5 Press [Shutter] to capture the photo. In Magic Frame mode, the resolution is automatically set to . Using the Magic Frame mode In Magic Frame Shot mode, you can apply various frame effects to your photos. The shape and the feel of the photos will change according to the frame you select. 1 On the Home screen, scroll to <Magic>. 2 Select . 3 Select a desired frame. Mural Panel off Extended functions 52 Using Magic modes Using the Photo Filter mode Apply various filter effects to your photos to create unique images. MiniatureVignetting Fish-eyeSketch 1 On the Home screen, scroll to <Magic>. 2 Select . 3 Select an effect. OptionDescription Miniature Apply a tilt-shift effect to make the subject appear in miniature. Vignetting Apply the retro-looking colors, high contrast, and strong vignette effect of Lomo cameras. Ink Painting Apply a watercolor painting effect. Oil Painting Apply an oil painting effect. Cartoon Apply a cartoon painting effect. Cross Filter Add lines that radiate outward from bright objects to imitate the visual effect of a cross filter. Sketch Apply a pen sketch effect. Soft Focus Hide facial imperfections or apply dreamy effects. Fish-eye Blacken the edges of the frame and distort objects to imitate the visual effect of a fisheye lens. Old Film Apply a vintage film effect. Half Tone Dot Apply a halftone effect. Classic Apply a black and white effect. Retro Apply a sepia tone effect. Zooming Shot Blur the edges of a photo to emphasize the subjects in the center. Extended functions 53 Using Magic modes 4 Align your subject in the frame, and then half-press [Shutter] to focus. 5 Press [Shutter] to capture a photo. Depending on the option you select, the resolution may change to or smaller automatically. Using the Movie Filter mode Apply various filter effects to your videos to create unique images. 1 On the Home screen, scroll to <Magic>. 2 Select . 3 Select an effect. OptionDescription Miniature Apply a tilt-shift effect to make the subject appear in miniature. Vignetting Apply the retro-looking colors, high contrast, and strong vignette effect of Lomo cameras. Half Tone Dot Apply a halftone effect. Sketch Apply a pen sketch effect. OptionDescription Fish-eye Distort close objects to imitate the visual effect of a fisheye lens. Classic Apply a black and white effect. Retro Apply a sepia tone effect. Palette Effect 1 Create a vivid look with sharp contrast and strong color. Palette Effect 2 Make scenes clean and clear. Palette Effect 3 Apply a soft brown tone. Palette Effect 4 Create a cold and monotone effect. 4 Press [Shutter] to start recording. 5 Press [Shutter] again to stop recording. • If you select Miniature, the miniature recording time is also displayed and is shorter than the real recording time. • If you select Miniature, you cannot record the video sound. • Depending on the option you select, the recording speed may change to and the recording resolution may change to or smaller automatically. Extended functions 54 Using Magic modes Using the Split Shot mode In Split Shot mode, you can capture several photos and arrange them with preset layouts. 1 On the Home screen, scroll to <Magic>. 2 Select . 3 Select a split style. • To adjust the sharpness of the dividing line, press [m], and then select Line Blur “ a desired value. • To apply a Smart Filter effect to part of the shot, press [ m], and then select Smart Filter “ a desired option. You can apply different Smart Filter effects to each part of the shot. Panel off 4 Align your subject in the frame, and then half-press [Shutter] to focus. 5 Press [Shutter] to capture a photo. • Repeat steps 4 and 5 to capture the rest of the photos. • To recapture a photo, press [f]. • In Split Shot mode, the resolution is automatically set to or smaller. • In Split Shot mode, the available zoom range may be less than in other shooting modes. Extended functions 55 Using Magic modes 6 Rotate [Zoom] to the left or right to reduce or enlarge the area. CancelSave Frame Size 7 Press [o] to save the photo. • The camera saves an animated GIF and one JPG of the first scene from the GIF file. You cannot view the JPG file on your camera. To view it, connect your camera to a PC. (p. 101) • In Motion Photo mode, the resolution is automatically set to . • Use a tripod to prevent your camera from shaking. • In Motion Photo mode, it may take longer to save files. Using the Motion Photo mode In Motion Photo mode, you can capture and combine a series of photos, and then select an area to be animated to create a GIF animation. This mode is available only when you insert a memory card into the camera. 1 On the Home screen, scroll to <Magic>. 2 Select . 3 Align your subject in the frame, and then half-press [Shutter] to focus. 4 Press [Shutter] to capture the photo. • The camera captures multiple photos while the status lamp is blinking. 5 Press [D/c/F/t] to scroll to an area to be animated. Selecting a resolution and quality ............ 57 Selecting a resolution ........................ 57 Selecting an image quality ..................... 58 Using the timer .................................... 59 Shooting in the dark ........................... 60 Preventing red-eye ........................... 60 Using the flash ................................. 60 Adjusting the ISO sensitivity .................. 62 Changing the camera’s focus ............... 63 Using macro .................................... 63 Using tracking auto focus ..................... 64 Adjusting the focus area ..................... 65 Using Face Detection ........................... 66 Detecting faces ................................. 66 Capturing a smile shot ........................ 67 Detecting eye blinking ........................ 67 Adjusting brightness and color ............... 68 Adjusting the exposure manuall…

Text truncated - open the document above for the full version.

Wireless network 100 Connecting to a WLAN and configuring network settings Using the login browser You can enter your login information via the login browser when connecting to some APs, sharing sites, or cloud servers. ButtonDescription [D/c/F/t] Move to an item or scroll the page. [o] Select an item. [m] Access the following options: • Previous Page: Move to the previous page. • Next Page: Move to the next page. • Reload: Reload the page. • Stop: Stop loading the page. • Exit: Close the login browser. [f] Close the login browser. • You cannot select some items depending on the page you connected to. This does not indicate a malfunction. • The login browser may not close automatically after you log into some pages. If this occurs, close the login browser by pressing [f], and then proceed with the desired operation. • It may take longer to load the login page due to the page size or network speed. If this occurs, wait until the login information input window appears. Setting network options 1 In the Wi-Fi Setting screen, move to an AP, and then press [t]. 2 Select each option, and then enter the required information. OptionDescription Authentication Select a network authentication type. Data Encryption Select an encryption type. Network Password Enter the network password. IP Setting Set the IP address manually. Manually setting the IP address 1 In the Wi-Fi Setting screen, move to an AP, and then press [ t]. 2 Select IP Setting “ Manual. 3 Select each option, and then enter the required information. OptionDescription IP Enter the static IP address. Subnet Mask Enter the subnet mask. Gateway Enter the gateway. DNS Server Enter the DNS address. Wireless network 101 Connecting to a WLAN and configuring network settings • If you cannot connect to a WLAN, try another AP from the available AP list. • You can also connect to free WLANs in some foreign countries. • A login page may appear when you select free WLANs provided by some network service providers. Enter your ID and password to connect to the WLAN. For information about registering or the service, contact the network service providers. • Be cautious when you enter personal information for an AP connection. Do not enter any payment or credit card information on your camera. The manufacturer is not liable for any problem caused by entering such information. • Available network connections may differ by country. • The WLAN feature of your camera must comply with radio transmission laws in your region. To ensure compliance, use the WLAN feature only in the country where you purchased the camera. • The process for adjusting network settings may differ, depending on network conditions. • Do not access a network that you are not authorized to use. • Before you connect to a network, ensure your battery is fully charged. • When a DHCP server is not available you must make an autoip. txt file and copy it to the inserted memory card to connect to the network using Auto IP. Network connection tips • The quality of the network connection will be determined by the AP. • The further the distance between your camera and the AP, the longer it will take to connect to the network. • If a nearby device is using the same radio frequency signal as your camera, it may interrupt your connection. • If your AP name is not in English, the camera may not be able to locate the device or the name may appear incorrectly. • For network settings or a password, contact your network administrator or network service provider. • If a WLAN requires authentication from the service provider, you may not be able to connect to it. To connect the WLAN, contact your network service provider. • Depending on the encryption type, the number of digits in the password may differ. • A WLAN connection may not be possible in all surroundings. • The camera may display a WLAN enabled printer on the AP List. You cannot connect to a network via a printer. • You cannot connect your camera to a network and a TV simultaneously. Also, you cannot view photos or videos on a TV while connected to a network. • Connecting to a network may incur additional charges. Costs will vary based on the conditions of your contract. Wireless network 102 Connecting to a WLAN and configuring network settings Entering text Learn how to enter text. The icons in the table below let you move the cursor, change the case, etc. Press [D/c/F/t] to move to a desired key, and then press [o] to enter the key. BackBackspace Done IconDescription Delete the last letter. Move the cursor. In ABC mode, change the case. Enter ".com". IconDescription Switch between Symbol mode and ABC mode. Enter a space. DoneSave the displayed text. View the entering text guide. • You can use only the English alphabet, regardless of the display language. • To move to Done directly, press [P]. • You can enter up to 64 characters. Wireless network 103 Sending photos or videos to a smart phone The camera connects to a smart phone that supports the MobileLink feature via a WLAN. You can easily send photos or videos to your smart phone. • The MobileLink feature is supported by Galaxy S smart phones with the Android 2.2 OS or higher. If your smart phone uses the Android 2.1 OS, upgrade your smart phone to Android 2.2 or higher. This feature is also supported by the 7 and 10.1 inch Galaxy Tab. This feature may be supported by other devices with Android 2.2 or higher, but Samsung makes no guarantee of its functionality. • You should install the Samsung MobileLink application on your phone or device before using this feature. You can download the application from Samsung Apps or Android market. • When there are no files in the camera memory, you cannot use this feature. • You can view up to 1,000 files and send up to 100 files at a time. 5 On the smart phone, select files to send from the camera to the smart phone. 6 On the smart phone, select Copy. • The camera will send the files. 1 On the camera's Home screen, scroll to <Wi-Fi>. 2 On the camera, select…

Text truncated - open the document above for the full version.

129, Samsung‐Ro, Yeongtong‐Gu, Suwon‐City Gyeonggi‐ Do, 443‐742, Korea December 2nd , 2014 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 LETTER OF AUTHORIZATION To whom it may concern: I, the undersigned, hereby authorize Lab Manager Feel. Jeong (or Logan. Lee) and of SGS Korea Co., Ltd. and hereafter referred to as SGS Korea, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Lab Manager Feel. Jeong (or Logan. Lee) of SGS Korea Co., Ltd. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti‐Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing SGS Korea as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary ar rangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scop e for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon su spension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; 129, Samsung‐Ro, Yeongtong‐Gu, Suw on‐City Gyeonggi‐Do, 443‐742, Korea i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours Chan Ho, Youn / General Manager Samsung Electronics North America INC. TEL: +1-973-808-6362 E-mail: [email protected]

129, Samsun g‐Ro, Yeongtong‐Gu, Suwon‐City Gyeonggi‐Do, 443‐742, Korea December 2nd, 2014 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 REQUEST OF CONFIDENTIALITY for FCC ID: A3LDV180F To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Samsung Electronics Co., Ltd. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short‐Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04‐1705. This provision will give Samsung Electronics Co., Ltd temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: CONFIDENTIAL LIST Permanent 1 Block Diagram 2 Operational Descriptions 3 Schematics Short‐Term 4 External Photos 5 Internal Photos 6 Test‐Setup Photos 7 User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely Yours, Chan Ho, Youn / General Manager Samsung Electronics North America INC. TEL: +1-973-808-6362 E-mail: [email protected]

Model : DV180F External photos of EUT Model : DV180F Front view of EUT Rear view of EUT Model : DV180F Top view of EUT Bottom view of EUT Model : DV180F Side view of EUT
