A3LDV50P3WWireless PDP Monitor

ٛ MPEG Encoder MPEG Decoder Back End Video S-Video Component WirelessTransmit Module RF DVI CVBS Component MPEG Decoder CPU WirelessReceive Module Scaler ASI510 DNIe2 SPD31 PDP Module Sound Process A/V Center Wireless Receiver PCDVIWIRELESS DVI RS232C Scaler ASI510 ADC AD9883 RS232C MAX232 DVI SiI169 SDRAM K4S643232 LVDS DS90C385 Rx,Tx SOUND OUT SOUND AMP TAS5112 SOUND PROCESSOR MSP4440 SOUND PRE AMP NSP-6241 TO LOGIC BOARD u-COM OSD SDA6001 EEPROM AT24C16 EPROM M27V160 SDRAM K4S641632 720P DVI SiI169 DNIe2SPD31 SDRAM K4S643232 Option

Test Report No.: NK2ER059 FCC Certification APPENDIX A – LABELLING REQUIREMENTS The sample label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. Labelling Requirements FCC ID: A3LDV50P3W Brand Name: SAMSUNG This device complies with part 15 of the FCC Rules. Operatio n is subject to the following two conditions: (1) This device ma y not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. z FCC ID Location of EUT Samsung Electronics Co., Ltd. FCC ID:A3LDV50P3W Page 49 of 67

Description of Wireless PDP AV system DVD(480i/p) VCR ATSC/NTSC Composite/ Component Composite Optical / Coaxial Home Theater PDP/LCD TV HD Display Signal Audio Signal Remote controller Signal Air5 Solution By Magis DVI PDP is connected to AV center(STB) via DVI jack Remote controller IR Signal Technical Description qWireless transmission is done by Magis Air5 Solution. -uses the same frequency band as IEEE802.11a(5.125 ~ 5.325GHz) qConfiguration -Same wireless module in Set Top Box and PDP (Transmitter/ Receiver) . Synchronization between Tx and Rx during Audio signal transmission. < MAGIS Air5 Solution > STB 365 Model Eagle Plus (MPEG Decoder) MAGIS Air-5 Wireless Module New Port (CPU) + <Tx >

Test Report No.: NK2ER059 FCC Certification TEST DATA MAXIMUM PERMISSIBLE EXPOSURE RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density ( /) Average Time (Minutes) (A) Limits for Occupational / Control Exposure 30 - 300 6.14 0.163 1.0 6 300 - 1500 ... ... F/300 6 1500 - 100000 ... ... 5 6 (B) Limits for General Population / Uncontrolled Exposure 30 - 300 27.5 0.073 0.2 30 300 - 1500 ... ... F/1500 30 1500 - 100000 ... ... 1 30 F = Frequency (MHz) Fries Formula Fries transmission formula : Pd = (Pout * G) / (4 * r = ((Pout * G) / 4 * Where Pd = Power density in / Pout = Output power to antenna in G = Gain of antenna in linear scale r = Distance between observation point center of the radiator in cm Pd is the limit of MPE, 1 /. If we know the Maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Samsung Electronics Co., Ltd. FCC ID:A3LDV50P3W Page 45 of 67 Test Report No.: NK2ER059 FCC Certification TEST DATA Test Result The maximum antenna gain is –3.35dBi or 0.462(Numeric) Output power into antenna and RF Exposure Distance Channel Frequency (MHz) Output power to Antenna (mW) RF Exposure Distance (cm) 1 5180 48.53mW 1.34 4 5240 27.04mW 1.00 5 5260 27.29mW 1.00 8 5320 16.75mW 0.78 MPE Safe Distance = 1.34cm Samsung Electronics Co., Ltd. FCC ID:A3LDV50P3W Page 46 of 67

ASI510 3EH NSP6241 74HCT573 74HCT573 92 D0 20 VCC 3 D1D2 4 D3 5 D4 67 D5D6 8 D7 12 Q7Q6 1314 Q5 15 Q4Q3 1617 Q2Q1 18 Q0 19 SN74HCT573DWR IC612 /OE 1 10 GND LE 11 VCC 3 D1D2 4 D3 5 D4 67 D5D6 8 D7 9 1314 Q5 15 Q4Q3 1617 Q2Q1 18 Q0 19 2 D0 20 /OE 1 10 GND LE 1112 Q7Q6 SN74HCT573DWR IC605 100uFC626 12 CN701 slcon2p 12 slcon2p CN702 I 1 G 2 O 3 C62525V100uF +12V_O +12V_O I 1 G 2 O 3 BD201 1 2 FAN1117AD-1.8 FT609 ADJ 1 2 O I 3 IC306 LF33CDT IN 1 GND 2 OUT 3

Test Report No.: NK2ER059 FCC Certification Nemko Korea CO., Ltd. 300-2, Osan-Ri, Mohyun-Myun, Yongin-City, Kyungki-Do, KOREA TEL:+82 31 322 2333 FAX:+82 31 322 2332 FCC EVALUATION REPORT FOR CERTIFICATION Applicant : Samsung Electronics Co., Ltd. Visual Display Division,R&D Dept, 416,Maetan3-dong, Dates of Issue : April 12, 2004 YeongTong-gu Suwon-City,Kyungki-Do, Korea, Test Report No. : NK2ER059 (Post code : 442-742) Test Site : Nemko Korea Co., Ltd. Attn. : Mr.ChangSeub Eum EMC site, Korea A3LDV50P3W SAMSUNG Samsung Electronics Co., Ltd. Visual Display Division,R&D Dept,#416 Maetan3-dong, YeongTong-gu,Suwon-City,Kyunggi-do, Korea , 442-742. Mr. ChangSeub Eum Telephone No. : +82 31 200 7611 FCC ID Brand Name Contact Person Applied Standard: FCC 47 CFR Part 15, Subpart E : 2000 Classification : FCC Class B Device EUT Type: Wireless PDP Monitor The device bearing the brand name and FCC ID specified above has been shown to comply with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.4-1992. I attest to the accuracy of data and all measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Tested By : C.S.Choi Reviewed By : H.H.Kim Senior Engineer Manager & Chief Engineer Samsung Electronics Co., Ltd. FCC ID:A3LDV50P3W Page 1 of 67 Test Report No.: NK2ER059 FCC Certification TABLE OF CONTENTS SCOPE INTRODUCTION (Site Description) TEST CONDITIONS & EUT INFORMATION SUMMARY OF TEST RESULTS RECOMMANDATION / CONCLUSION SAMPLE CALCULATION DESCRIPTION OF TEST TEST DATA (Conducted Emissions) PLOT OF EMISSION TEST DATA (Radiated Emissions) TEST DATA (Emission Bandwidth) PLOT OF TEST DATA TEST DATA ( Peak Conducted Transmit Output Power) PLOT OF TEST DATA TEST DATA (Peak Excursion measurement) PLOT OF TEST DATA TEST DATA (Peak Power Spectral Density) PLOT OF TEST DATA TEST DATA (Band Edge) PLOT OF TEST DATA TEST DATA (Conducted & Radiated Spurious Emission) PLOT OF TEST DATA TEST DATA (Frequency Stability) TEST DATA (Maximum Permissible Exposure) ACCURACY OF MEASUREMENT TEST EQUIPMENT APPENDIX A - LABELLING REQUIREMENTS APPENDIX B - BLOCK DIAGRAM APPENDIX C - CLOCK DIAGRAM APPENDIX D - PHOTOGRAPHS OF TEST SET-UP APPENDIX E - EUT PHOTOGRAPHS APPENDIX F - USER’S MANUAL APPENDIX G - SCHEMATIC DIAGRAM APPENDIX H - OPERATING DESCRIPTION 3 4 5 7 7 7 8 13 14 16 18 19 21 22 24 25 27 28 30 31 35 36 44 45 47 48 49 50 53 54 56 65 66 67 Samsung Electronics Co., Ltd. FCC ID:A3LDV50P3W Page 2 of 67 Test Report No.: NK2ER059 FCC Certification SCOPE Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission under FCC part 15. Responsible Party* : Contact Person : Manufacturer : Samsung Electronics Co., Ltd. Mr. ChangSeub Eum Samsung Electronics Co., Ltd. Visual Display Division,R&D Dept, #416 Maetan3-dong, YeongTong-gu, Suwon-City,Kyunggi-do, Korea , 442-742 z FCC ID : A3LDV50P3W z Model: DV50P3W z Brand Name: SAMSUNG z EUT Type: Wireless PDP Monitor z Classification: z Applied Standard: z Test Procedure(s): z Dates of Test: z Place of Tests: z Test Report No.: FCC Class B FCC 47 CFR Part 15 , Subpart E ANSI C63.4 (2001), DA 02-2138(2002) March 31, 2004 to April 10, 2004 Nemko Korea Co., Ltd. EMC Site NK2ER059 Samsung Electronics Co., Ltd. FCC ID:A3LDV50P3W Page 3 of 67 Test Report No.: NK2ER059 FCC Certification INTRODUCTION The measurement procedure described in American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz (ANSI C63.4-1992) was used in determining radiated and conducted emissions emanating from Samsung Electronics Co., Ltd. FCC ID : A3LDV50P3W These measurement tests were conducted at Nemko Korea Co., Ltd. EMC Laboratory . The site address is 300-2, Osan-Ri, Mohyun-Myun, Yongin-City, Kyungki-Do, KOREA The area of Nemko Korea Corporation LTD. EMC Test Site is located in a mountain area at 80 kilometers (48 miles) southeast and Incheon International Airport (Incheon Airport), 30 kilometers (18miles) south-southeast from central Seoul. It is located in the valley surrounded by mountains in all directions where ambient radio signal conditions are quiet and a favorable area to measure the radio frequency interference on open field test site for the computing and ISM devices manufactures. The detailed description of the measurement facility was found to be in compliance with the requirements of 2.948 according to ANSI C63.4 on October 19, 1992. Nemko Korea Co., Ltd. EMC Lab. 300-2, Osan-Ri, Mohyun-Myun, Yongin- City Kyungki-Do,KOREA 449-852 Tel)+82-31-322-2333 Fax)+82-31-322-2332 Fig. 1. The map above shows the Seoul in Korea vicinity area. The map also shows Nemko Korea Corporation Ltd. EMC Lab. and Incheon Airport. Samsung Electronics Co., Ltd. FCC ID:A3LDV50P3W Page 4 of 67 Test Report No.: NK2ER059 FCC Certification TEST CONDITIONS & EUT INFORMATION Operating During Test EUT Wireless Digital Set top Box Laptop PC For Part 15 subpart E testing of this EUT, Tx power and channels are changed through RS-232 cable of laptop pc. Laptop and RS-232 cable are removed, FCC part 15.207,15.209 testing has been performed while EUT is communicating with “Wireless Digital Set top Box”. The test results related to PDP Monitor.(i.e. Part 15 subpart B) were not included in this report. Therefore, Is refered in other report Support Equipment No. PRODUCT BRAND MODEL SERIAL No. 1 Laptop PC SAMSUNG Electronics Co.,Ltd S830 571191AR100141 2 Wireless Digital Set top Box SAMSUNG Electronics Co.,Ltd FC20 - Samsung Electronics Co.…

Text truncated - open the document above for the full version.

Test Report No.: NK2ER059 FCC Certification APPENDIX D – PHOTOGRAPHS OF TEST SET-UP The Conducted Test Picture and Radiated Test Picture and show the worst-case configuration and cable placement. z Conducted Test Picture(Front) z Conducted Test Picture(Rear) Samsung Electronics Co., Ltd. FCC ID:A3LDV50P3W Page 54 of 67 Test Report No.: NK2ER059 FCC Certification The Radiated Test Picture show the worst-case configuration from the X-azimuth. z Radiated Test Picture(Front) z Radiated Test Picture(Rear) Samsung Electronics Co., Ltd. FCC ID:A3LDV50P3W Page 55 of 67
