QUICK START GUIDE EB-U3300 WIRELESS BATTERY PACK Printed in Korea A00800 Rev.1.0 EU/ASIA Type 12/2019 2 1 2 Copyright © 2019 Samsung Electronics • () Connect one end of the USB cable to the battery pack’s USB charger port. Then, plug the other end of the USB cable into the mobile device’s multipurpose jack. Or, ( ) place a mobile device on the wireless battery pack. Charging will begin when the charging coil comes into contact with the wireless charging coil of the mobile device. • Do not place foreign materials, such as metal objects, magnets, and magnetic stripe cards, between the mobile device and the wireless charger. • If the charger is not connected, you must press the Battery level / Wireless charging button to charge the mobile device. • Visit www.samsung.com to view the user manual and the safety information. 3 • Your consumer rights are governed by the law of the country in which you purchased the product. Please contact your service provider for more information. Correct disposal This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste. This product is RoHS compliant. For information on Samsung’s environmental commitments and product regulatory obligations, e.g. REACH, WEEE or Batteries, visit our sustainability page available via www.samsung.com. Declaration of Conformity Samsung Electronics declares that this device complies with the essential requirements and relevant provisions of Directive 2014/53/EU. Go to www.samsung.com/mobile_doc to view the Declaration of Conformity. Band and mode Band and modeOutput power Wireless Charging 125.7 kHz–129.7 kHz 146 kHz-146 kHz 16.57 dBμA/m at 10 m Samsung Electronics America, Inc. 85 Challenger Road, Ridgefield Park, New Jersey 07660 Phone: 1-800-SAMSUNG (726-7864) FCC Part 15.19 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Part 15.21 Any changes or modifications (including the antennas) to this device that are not expressly approved by the manufacturer may void the user’s authority to operate the equipment. FCC 15.105 Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence- exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) L’appareil ne doit pas produire de brouillage; (2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. FCC and IC RF Radiation Exposure Statement: This equipment complies with FCC and IC RF Radiation exposure limits set forth for an uncontrolled environment. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment should be installed and operated with a minimum distance of 20 cm between the radiator and your body. RF du FCC et IC d'exposition aux radiations: Cet équipement est conforme à l'exposition de FCC et IC rayonnements RF limites é-tablies pour un environnement non contrôlé. L’antenne pour ce transmetteur ne doit pas être même endroit avec d’autres émetteur sauf conformément à FCC et IC procédures de produits Multi-émetteur. Cet équipement doit être installé et utilisé avec une distance minimale de 20 cm entre le radiateur et votre corps.

19 Chapin Rd., Building D Pine Brook, New Jersey, 07058, United States Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 LETTER FOR AUTHORIZATION FCC ID: A3LEBU3300 To whom it may concern: I, t he undersigned, hereby authorize Lab Manager (Hyunchae, You) and of SGS Korea Co., Ltd. and hereafter referred to as SGS Korea, to a ct on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Lab Manager (Hyunchae, You) of SGS Korea Co., Ltd. on our behalf shall have t he same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti‐Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing SGS Korea as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; 10 February 2020 19 Chapin Rd., Building D Pine Brook, New Jersey, 07058, United States i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours Jenni Chun/ General Manager Samsung Ele ctronics North America INC. TEL: +1-973-808-6362 E-mail: [email protected]

19 Chapin Rd., Building D Pine Brook, New Jersey, 07058, United States 10 February 2020 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 REQUEST FOR CONFIDENTIALITY FCC ID: A3LEBU3300 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Samsung Electronics Co., Ltd. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short‐Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04‐1705. This provision will give Samsung Electronics Co., Ltd temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: CONFIDENTIAL LIST Permanent 1 Block Diagram 2 Operational Descriptions 3 Schematics Short‐Term 4 External Photos 5 Internal Photos 6 Test‐Setup Photos 7 User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely Yours, Jenni Chun / General Manager Samsung Electronics North America INC. TEL: +1-973-808-6362 E-mail: [email protected]

External photos of EUT Top view of EUT Bottom view of EUT Side view of EUT

Internal photos of EUT Internal view of EUT Top view of Main PCB Bottom view of Main PCB X1 (8MHz X’tal) U7 (WPC-IC) View of Antenna Loop coil antenna (ANT1) Loop coil antenna (ANT2)

Report Number:F690501-RF-RTL000239-1 Page:2of9 The results of this test report are effective only to the items tested. The SGS Korea is not responsible for the sampling, the results of this test report apply to the sample as received. This test report cannot be reproduced, except in full, without prior written permission of the Company. This test report does not assure KOLAS accreditation. SGS Korea Co., Ltd. (Gunpo Laboratory)4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 http://www.sgsgroup.kr RTT5041-19(2019.04.24)(1)Tel. +82 31 428 5700 / Fax. +82 31 427 2370 A4(210 mmx297 mm) Table of contents 1. General Information -----------------------------------------------------------------------3 2. Test Result -----------------------------------------------------------------------------------5 Report Number:F690501-RF-RTL000239-1 Page:3of9 The results of this test report are effective only to the items tested. The SGS Korea is not responsible for the sampling, the results of this test report apply to the sample as received. This test report cannot be reproduced, except in full, without prior written permission of the Company. This test report does not assure KOLAS accreditation. SGS Korea Co., Ltd. (Gunpo Laboratory)4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 http://www.sgsgroup.kr RTT5041-19(2019.04.24)(1)Tel. +82 31 428 5700 / Fax. +82 31 427 2370 A4(210 mmx297 mm) 1. General Information 1.1. Testing Laboratory SGS Korea Co., Ltd. (Gunpo Laboratory) - 10-2, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 - 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 - Designation number: KR0150 All SGS services are rendered in accordance with the applicable SGS conditions of service available on request and accessible athttp://www.sgs.com/en/Terms-and-Conditions.aspx. Phone No.: +82 31 688 0901 Fax No.: +82 31 688 0921 1.2. Details of Applicant Applicant:Samsung Electronics Co., Ltd. Address:19 Chapin Rd., Building D, Pine Brook, New Jersey, United States, 07058 Contact Person:Chun, Jenni Phone No.:+1 973 808 6375 1.3. Details of Manufacturer Company:Samsung Electronics Co., Ltd. Address:No.98, Jiangbin East Avenue, Mawei District, Fuzhou, Fujian, P.R china 1.4. Description of EUT Kind of Product WIRELESS battery pack Model Name EB-U3300 Power Supply DC 12.0 V Operation Mode 5 W, 7.5 W Frequency Range 5 W Ant. 1: 125.7㎑~ 129.7㎑ Ant. 2: 146㎑ 7.5 W Ant. 1: 125.7㎑~ 129.7㎑ Antenna Type Loop Coil Antenna 1.5. Declaration by the Manufacturer - The EUT has 2 loop coil antennas, and only one antenna can transmit at once. Report Number:F690501-RF-RTL000239-1 Page:4of9 The results of this test report are effective only to the items tested. The SGS Korea is not responsible for the sampling, the results of this test report apply to the sample as received. This test report cannot be reproduced, except in full, without prior written permission of the Company. This test report does not assure KOLAS accreditation. SGS Korea Co., Ltd. (Gunpo Laboratory)4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 http://www.sgsgroup.kr RTT5041-19(2019.04.24)(1)Tel. +82 31 428 5700 / Fax. +82 31 427 2370 A4(210 mmx297 mm) 1.6. Test Equipment List EquipmentManufacturerModelS/NCal. Date Cal. Interval Cal. Due E-Field Probe D.A.R.E!! Instruments RadiSense 413I00444SNO04Jun. 24, 2019AnnualJun. 24, 2020 Magnetic Field Sensor HIOKI34710850-B1Aug. 02, 2019AnnualAug. 02, 2020 Magnetic Field Hitester HIOKIFT3470-50140430999Aug. 02, 2019AnnualAug. 02, 2020 Anechoic Chamber SY Corporation L × W × H (9.6 m × 6.4 m × 6.6 m) N/AN.C.R.N/AN.C.R. ▶Support Equipment DescriptionManufacturerModelFCC ID Samsung Mobile PhoneSamsung Electronics Co., Ltd.SM-G973UA3LSMG973U SMART WATCHSamsung Electronics Co., Ltd.SM-R775UA3LSMR775U C type USB CableSamsung Electronics Co., Ltd.EP-DG170BBE- TRAVEL ADAPTER Dongguan Yingju Power Co., LtdEP-TA300- 1.7. Test Report Revision RevisionReport NumberDate of IssueDescription 0F690501-RF-RTL0002392020.02.07Initial 1F690501-RF-RTL000239-12020.02.12Revised item 5 b) of KDB 680106 1.8. Worst Case of Test Configurations In order to check all kinds of possible configurations, EUT was evaluated with appropriate client and under each charging condition as below table. Charging mode with client device ModeDescription Model: SM-G973U FCC ID: A3LSMG973U Model: SM-R775U FCC ID: A3LSMR775U 5 W7.5 W 1 % of battery 50 % of battery 99 % of battery Ant. 1 Ant. 2 Ant. 1 Note; - EUT was investigated with client device under normal charging condition as above then worst value was only reported. Report Number:F690501-RF-RTL000239-1 Page:5of9 The results of this test report are effective only to the items tested. The SGS Korea is not responsible for the sampling, the results of this test report apply to the sample as received. This test report cannot be reproduced, except in full, without prior written permission of the Company. This test report does not assure KOLAS accreditation. SGS Korea Co., Ltd. (Gunpo Laboratory)4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 http://www.sgsgroup.kr RTT5041-19(2019.04.24)(1)Tel. +82 31 428 5700 / Fax. +82 31 427 2370 A4(210 mmx297 mm) 2. Test Result 2.1. Test Setup 2.2. Measurement procedure a) The RF exposure test was performed in anechoic chamber. b) The measurement probe was placed at test distance (15㎝) which is between the edge of the charger and the geometric center of probe. c) The highest emission level was recorded and compared with limit as soon as measurement of each points (A, B, C, D, E, F) were completed. d) The EUT was measured according to the dictates of KDB 680106 D01 v03. Report Number:F690501-RF-RTL000239-1 Page:6of9 The results of this test report are effective only to the items tested. The SGS Korea is not responsible for the sampling, the results of this test report apply to the sample as received. This test report cannot be reproduced, except in full, without prior written permission of the Company. This test report …
