A3LEI-GP20Game Pad

Gamepad Type E. AXXXXX 09/2013. Rev. 1.0www.samsung.com This manual’s images and content may differ from the product. Overview Charging the device Use a charger to charge the battery before using the device for the first time. Connect the device and the charger, and then plug the charger into an electric socket. The charger and the charging cable are sold separately. Turning the device on or off Slide the power switch to turn the device on or off, or enter Pairing mode. Checking the indicator light Monitor the device’s condition by checking the indicator light. Device status StatusIndicator light Turned offTurns off. Turned onFlashes blue four times. In Pairing modeTurns blue for 3 minutes. Bluetooth Connected Flashes blue three times. Bluetooth Disconnected Flashes blue times. Battery power is low Flashes red continuously. While chargingTurns red. Battery status Press and hold the select button when the device is turned on. StatusIndicator light Above 80%Flashes blue five times. 20%-80%Flashes yellow five times. Below 20%Flashes red five times. Pairing and connecting the device When using a new smartphone, you need to pair it with the device. Once pairing is complete, the device attempts to reconnect each time you turn it on. Option 1: Manual Pairing 1 Slide the power switch all the way to the right for 3 seconds to enter Pairing mode. • The indicator light turns blue for 3 minutes. 2 Activate the Bluetooth feature on the smartphone, scan for the device, and then select the device name “Samsung Game Pad EI-GP20” from the list of available devices. For more details, refer to the mobile device’s user manual. Option 2: Pairing via NFC 1 Activate the NFC and Bluetooth feature on the smartphone. Make sure to unlock the smartphone before using the NFC feature. 2 Turn the device on, and then the device’s back, the NFC logo, to the smartphone’s NFC antenna until NFC pairing completes. • Some of NFC-enabled devices may not support this feature. • To locate the mobile device’s NFC antenna and activate NFC, refer to the mobile device’s user manual. Reconnecting and disconnecting Reconnecting If the connection is lost while in use, press any button or use the Bluetooth menu on the smartphone. Make sure the device is turned on, and the smartphone’s Bluetooth feature is activated. Disconnecting Turn off the device or use the Bluetooth menu on the smartphone. Attaching a smartphone to the device 1 Pull out the holder from the device. Do not pull out the holder excessively. Doing so may damage the device. 2 Slide the smartphone into the holder until it is fixed firmly as shown in the image below. The device is suitable for 4”-6.3” Samsung smartphones. Off On Pairing mode Power switch Charging jack Indicator light Holder Select button EI-GP20_UM_E_Eng.indd 12013-09-03 오후 5:12:28 Removing the smartphone from the device Push the smartphone to upper side of the device, and lift it as show in the image below. Buttons layout 2 7 3 5 1 4 6 8 Buttonsfeature 1 Trigger button Perform the actions defined by the game. 2 G button Return to the Mobile Console* screen. 3 Analog stick (L) Perform detailed directional control. 4 D-pad Perform four-way directional control. 5 Select buttonSelect in-game menus. 6 Start buttonStart or pause the game. 7 Analog stick (R)Perform aim or gaze control. 8 Action button Perform the actions defined by the game. • * Pressing G button opens Samsung Apps application if Mobile Console is not installed on the device. • The content of this manual is based on Android version 4.3 smartphones. The buttons may work differently depending on the game or Android version. Rejecting a incoming call while playing games Press the G button to reject a incoming call while you are playing games. Specifications ItemSpecifications and description Bluetooth Version 3.0 Support profiles Human Interface Device profile, Device Identification profile Size (mm)137.78 x 86.47 x 31.80 Weight190 g Operating temperatures 5°C -35°C Transmit power 0.25 -2.5 mW Operating range Up to 10 metres Safety information To prevent injury to yourself and others or damage to your device, read the safety information about your device before using the device Do not touch the power cord with wet hands or disconnect the charger by pulling the cord Do not drop or cause an impact to the device Do not insert the device or supplied accessories into the eyes, ears, or mouth Do not store your device near or in heaters, microwaves, hot cooking equipment, or high pressure containers Do not use your device outdoor during a thunderstorm Do not store your device in very hot or very cold areas. It is recommended to use your device at temperatures from 5 °C to 35 °C Do not store your device near magnetic fields Do not use or store your device in areas with high concentrations of dust or airborne materials Keep your device dry. Do not turn on your device if it is wet. If your device is already on, turn it off and remove the battery immediately (if the device will not turn off or you cannot remove the battery, leave it as-is). Then, dry the device with a towel and take it to a service center Do not use the device for anything other than its intended use Any changes or modifications to your device can void your manufacturer’s warranty. If your device needs servicing, take your device to a Samsung Service Center FCC This device complies with par t 15 of the FC C Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Users are not permitted to make changes or modify the device in any way. Changes or modifications not expressly approved by Samsung will void the user’s authority to operate the equipment. FCC RF Radiation Exposure Statement: FCC RF Radiation Exposure Statement: This equipment complies with FCC RF Radiation exposure limits set forth for an uncontrolled environmen…

Text truncated - open the document above for the full version.

September, 05, 2013 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 LETTER OF AUTHORIZATION To whom it may concern: I, the undersigned, hereby authorize Lab Manager Feel. Jeong (or Logan. Lee) and of SGS Korea Co., Ltd. and hereafter referred to as SGS Korea, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Lab Manager Feel. Jeong (or Logan. Lee) of SGS Korea Co., Ltd. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti‐Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing SGS Korea as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and reso lution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are ce rtified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; Samsung Electronics Co., Ltd. 19 Chapin Rd., Building D Pine Brook NJ 07058, United States i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours Sang Kyung (Peter) Ra / General Manager Samsung Electronics Co., Ltd. Samsung Electronics Co., Ltd. 19 Chapin Rd., Building D Pine Brook NJ 07058, United States

129, Samsun g‐Ro, Yeongtong‐Gu, Suwon‐City Gyeonggi‐ Do, 443‐742, Korea September 05, 2013 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 REQUEST OF CONFIDENTIALITY for FCC ID: A3LEI-GP20 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Samsung Electronics Co., Ltd. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short‐Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04‐1705. This provision will give Samsung Electronics Co., Ltd temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: CONFIDENTIAL LIST Permanent 1 Block Diagram 2 Operational Descriptions 3 Schematics Short‐Term 4 External Photos 5 Internal Photos 6 Test‐Setup Photos 7 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely Yours, Hayeon Cho, Senior Engineer Samsung Electronics Co., Ltd.

External photos of EUT Front view of EUT Rear view of EUT Top view of EUT Bottom view of EUT Side view of EUT

FCC & IC Label 1. FCC/IC Label Drawing 2. FCC Label Location

Model : EI-GP20 Internal photos of EUT Model : EI-GP20 Over view of EUT Model : EI-GP20 Top view of PCB Bottom view of PCB Ground plate Model : EI-GP20 Bottom view of PCB Model : EI-GP20 Top view of SUB PCB1 Bottom view of SUB PCB1 Model : EI-GP20 Antenna Antenna

Report File No. : F690501/RF-SAR002137-A1 Date of Issue : 2013-12-09 Page : 1 / 86 éééé SAR TEST REPORT Equipment Under Test : Game Pad Model No. : EI-GP20 Applicant : Samsung Electronics Co., Ltd. Address of Applicant : 129, Samsung-Ro, Maetan-Dong, Yeongtong-Gu, Suwon- City, Gyeonggi-Do FCC ID : A3LEI-GP20 IC ID 649E-EIGP20 Device Category : Portable Device Exposure Category : General Population/Uncontrolled Exposure Date of Receipt : 2013-11-26 Date of Test(s) : 2013-12-05 Date of Issue : 2013-12-09 Standards: FCC OET Bulletin 65 supplement C IEEE 1528, 2003 ANSI/IEEE C95.1, C95.3 In the configuration tested, the EUT complied with the standards specified above. Remarks: Tested by : Minhyuk Han 2013-12-09 Approved by : Nicky You 2013-12-09 This report details the results of the testing carried out on one sample, the results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS Korea Co., Ltd. or testing done by SGS Korea Co., Ltd. in connection with distribution or use of the product described in this report must be approved by SGS Korea Co., Ltd. in writing. Report File No. : F690501/RF-SAR002137-A1 Date of Issue : 2013-12-09 Page : 2 / 86 éééé Contents 1. General Information 1.1 Testing Laboratory........................................................................................... 3 1.2 Details of Applicant.......................................................................................... 3 1.3 Version of Report............................................................................................. 3 1.4 Description of EUT(s)....................................................................................... 4 1.5 Nominal and Maximum Output Power Specifications................................................... 5 1.6 Test Environment............................................................................................. 5 1.7 Operation description........................................................................................ 5 1.8 Evaluation procedures....................................................................................... 5 1.9 SAR Measurement Procedures.............................................................................. 6 1.10 The SAR Measurement System............................................................................ 7 1.11 System Components.......................................................................................... 9 1.12 SAR System Verification.................................................................................... 10 1.13 Tissue Simulant Fluid for the Frequency Band.......................................................... 12 1.14 1.15 Test System Validation ................................................................................. Test Standards and Limits................................................................................. 14 14 2. Instruments List.................................................................................... 16 3. Summary of Results................................................................................ 17 3.1 SAR Evaluation Procedures for Game controllers Devices.................................... 17 3.2 FCC Power Measurement Procedures............................................................... 17 3.3 Measured and Reported SAR...........................................................................17 3.4 SAR measurement Conditions for LTE ............................................................ 17 3.4.1 Spectrum Plots for RB Configurations ............................................................17 3.4.2 MPR.........................................................................................................17 3.4.3 A-MPR................................................................................................... 17 3.5 LTE Information.......................................................................................... 18 3.6 RF Conducted Power.................................................................................... 18 3.7 SAR Test Exclusions Applied...........................................................................20 3.8 Galaxy S3 SAR Data Summary........................................................................21 3.9 FCC Multi-TX SAR considerations.................................................................. 23 3.9.1 Introduction............................................................................................. 23 3.9.2 Simultaneous Transmission Procedures......................................................... 23 3.9.3 Body SAR Simultaneous Transmission Analysis................................................ 23 3.10 SPLSR Evaluation Analysis........................................................................... 24 APPENDIX A. DASY4 SAR Report B. Uncertainty Analysis C. Calibration certificate Report File No. : F690501/RF-SAR002137-A1 Date of Issue : 2013-12-09 Page : 3 / 86 éééé 1. General Information 1.1 Testing Laboratory SGS Korea Co., Ltd. (Gunpo Laboratory) 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, 435-040, Korea Telephone : +82 +31 428 5700 FAX : +82 +31 427 2371 Homepage : All SGS services are rendered in accordance with the applicable SGS conditions of service available on request and accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx 1.2 Details of Manufacturer Manufacturer : Samsung Electronics Co., Ltd. Address : 129, Samsung-Ro, Maetan-Dong, Yeongtong-Gu, Suwon-City, Gyeonggi-Do Contact Person : Hayeon Cho Phone No.…

Text truncated - open the document above for the full version.

129, Samsung‐Ro, Yeongtong‐Gu, Suwon‐City Gyeonggi‐Do, 443‐742, Korea December 4, 2013 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 ATTESTATION STATEMENT for FCC ID: A3LEI‐GP20 To Whom It May Concern: For the certification of product mentioned above, Simultaneous SAR per KDB 690783 D01v01r02 was conducted under following basis. 1. Attached mobile phone Simultaneous SAR was needed to make sure SAR value, while both gamepad and attached phone are operating, is under limit. The gamepad is designed for several major mobile phones of Samsung and Galaxy S3 (FCC ID: A3LSCHI535) has the closest antenna to its enclosure. Since the output power of gamepad is weak enough not to practically affect simultaneous SAR result, distance between antennas of gamepad and mobile phone was critical factor. Thus, Galaxy S3 has been selected as a sample for the simultaneous SAR test. 2. Antenna There are three antennas in Galaxy S3. According to FCC SAR report of the device, the CDMA/EVDO antenna has the highest SAR value and GSM/GPRS/EDGE is the second high antenna. However, the closest antenna to the game pad was the GSM/GPRS/EDGE antenna (29.78mm). All the other antennas, even CDMA/EVDO antenna, have enough separation distance to get SPLS ratio lower than 0.04 with maximum SAR value (1.60W/kg). Under the consideration, the GSM/GPRS/EDGE850/1900 antenna was only tested. Sincerely Yours, Hayeon Cho, Senior Engineer Samsung Electronics Co., Ltd.

Report Number: F690501/RF-RTL006930-2 Page: 2 of 48 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Korea Co., Ltd. (Gunpo Laboratory) 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-040 www.ee.sgs.com/korea RTT5041-20(2013.07.27)(1) Tel. +82 31 428 5700 / Fax. +82 31 427 2371 A4(210mmx297mm) INDEX Table of Contents Page 1. General Information -------------------------------------------------------------------------------- 3 2. Transmitter Radiated Spurious Emissions and Conducted Spurious Emission ----- 7 3. 20㏈ Bandwidth & 99 % bandwidth----------------------------------------------- 22 4. Maximum Peak Output Power ------------------------------------------------------------------- 28 5. Hopping Channel Separation --------------------------------------------------------------------- 30 6. Number of Hopping Frequency ------------------------------------------------------------------ 32 7. Time of Occupancy(Dwell Time) ----------------------------------------------------------------- 35 8. Transmitter AC Power Line Conducted Emission ------------------------------------------- 43 9. Antenna Requirement ------------------------------------------------------------------------------ 48 Report Number: F690501/RF-RTL006930-2 Page: 3 of 48 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Korea Co., Ltd. (Gunpo Laboratory) 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-040 www.ee.sgs.com/korea RTT5041-20(2013.07.27)(1) Tel. +82 31 428 5700 / Fax. +82 31 427 2371 A4(210mmx297mm) 1. General Information 1.1 Testing Laboratory SGS Korea Co., Ltd. (Giheung Laboratory) - 400-2, Gomae-dong, Giheung-gu, Yongin-si, Gyeonggi-do, Korea, 446-901 All SGS services are rendered in accordance with the applicable SGS conditions of service available on request and accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx. Telephone : +82 31 428 5700 FAX : +82 31 427 2371 1.2. Details of Applicant Applicant : Samsung Electronics Co., Ltd. Address : 129, Samsung-ro, Maetan-Dong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Republic of Korea Contact Person : Hayeon Cho Phone No. : +82 10 3186 8379 1.3. Description of EUT Kind of Product Game Pad Model Name EI-GP20 Serial Number N/A Power Supply DC 3.7 V Frequency Range 2 402 ㎒ ~ 2 480 ㎒ Modulation Technique GFSK Number of Channels 79 Antenna Type Internal type Antenna Gain 1.87 ㏈i 1.4. Declaration by the manufacturer - Adaptive Frequency Hopping is supported and use at least 20 channels - Operation temperature: -10 °C ~ 50 °C - Operation voltage: DC 3.37 V ~ DC 4.15 V - Power class: 2 - The modulation type of this Bluetooth device is only GFSK Report Number: F690501/RF-RTL006930-2 Page: 4 of 48 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Korea Co., Ltd. (Gunpo Laboratory) 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-040 www.ee.sgs.com/korea RTT5041-20(2013.07.27)(1) Tel. +82 31 428 5700 / Fax. +82 31 427 2371 A4(210mmx297mm) 1.5. Information about the FHSS characteristics: 1.5.1. Pseudorandom Frequency Hopping Sequence The channel is represented by a pseudo-random hopping sequence hopping through the 79 RF channels. The hopping sequence is unique for the piconet and is determined by the Bluetooth device address of the master; the phase in the hopping sequence is determined by the Bluetooth clock of the master. The channel is divided into time slots where each slot corresponds to an RF hop frequency. Consecutive hops correspond to different RF hop frequencies. The nominal hop rate is 1 600 hops/s. 1.5.2. Equal Hopping Frequency Use All Bluetooth units participating in the piconet are time and hop-synchronized to the channel. 1.5.3. System Receiver Input Bandwidth Each channel bandwidth is 1㎒ 1.5.4. Equipment Description 15.247(a)(1) that the rx input bandwidths shift frequencies in synchronization with the transmitted 15.247(g): In accordance with the Bluetooth Industry Standard, the system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information) system. 15.247(h): In accordance with the Bluetooth Industry Standard, the system does not coordinate it channels selection/ hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters. Report Number: F690501/RF-RTL006930-2 Page: 5 of 48 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Korea Co., Ltd. (Gunpo Laboratory) 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-040 www.ee.sgs.com/korea RTT5041-20(2013.07.27)(1) Tel. +82 31 428 5700 / Fax. +82 31 427 2371 A4(210mmx297mm) 1.6. Test Equipment List Equipment Manufacturer Model S/N Cal Date Cal Interval Cal Due. Signal Generator R&S SMR40 100540 Jan. 08, 2013 Annual Jan. 08, 2014 Spectrum Analyzer R&S FSV30 101004 Jul. 20, 2013 Annual Jul. 20, 2014 Spectrum Analyzer Agilent N9030A MY53120526 Jul. 30, 2013 Annual Jul. 30, 2014 Band Rejection Filter Wainwright WRCT2402/2480- 2400/2483.5-30/20SS 22 Jul. 02, 2013 Annual Jul. 02, 2014 High Pass Filter Wainwright WHK3.0/18G-6SS 4 Jul. 02, 2013 Annual Jul. 02, 2014 Bluetooth Tester TESCOM TC-3000C 3000C000296 Jul. 02, 2013 Annual Jul. 02, 2014 Directional Coupler KRYSTAR 152613 127445 Jul. 02, 2013 Annual Jul. 02, 2014 Low Pass Filter Mini circuits NLP-1200+ V9500401023-1 Jul. 02, 2013 A…

Text truncated - open the document above for the full version.

Test Setup Photographs a) Rear EUT Photo a) Front b) Rear

Test setup photos of EUT Photo of Field Strength & Spurious Emission Test(Below 1㎓) Photo of Field Strength & Spurious Emission Test(Above 1㎓) Photos of AC power line Conducted Emission Test
