A3LEJPX710S PEN

English Copyright © 2020 Samsung Electronics America, Inc. Bluetooth ® is a registered trademark of Bluetooth SIG, Inc. worldwide. Other marks are the property of their respective owners. • Please read this guide before using the device to ensure safe and proper use. • Before using the S Pen, make sure it is compatible with your device. • Your consumer rights are governed by the law of the country in which you purchased the product. Please contact your service provider for more information. Using the S Pen Use the S Pen to perform touch actions or draw on the screen of your mobile device. You can use additional features by pressing the S Pen button ( ). When you attach the S Pen on the rear of your mobile device, charging will start. Refer to the mobile device’s user manual for more information. Safety information Read all safety information before using the device to ensure safe and proper use. To view the full safety information, refer to the Samsung website. Use only charging devices and batteries approved by Samsung. Samsung accessories are designed for your device to maximize battery life. Using other accessories may invalidate your warranty and may cause damage Do not touch the device with wet hands Do not drop or cause an impact to the charger or the device Do not allow children or animals to chew or suck the device Do not disassemble, modify, or repair your device FCC 15.21 Warning against unauthorized change Pursuant to Part 15.21 of the FCC Rules, you are cautioned that changes or modifications not expressly approved by Samsung could void your authority to operate the device. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. • Depending on the region or model, some devices are required to receive approval from the Federal Communications Commission (FCC). If your device is approved by the FCC, you can view the FCC ID of the device. To view the FCC ID, launch the Settings app and tap About phone → Status. Samsung Mobile Products and Recycling Samsung cares for the environment and encourages its customers to properly dispose of Devices and Samsung accessories in accordance with local regulations. In some areas, disposal of these items in household or business trash may be prohibited. Dispose of other unwanted electronics through an approved recycler. To find the nearest recycling location, go to our website: www.samsung.com/recyclingdirect or call 1-877-278-0799. Samsung Electronics America, Inc 85 Challenger Road, Ridgefield Park, New Jersey, 07660 Phone: 1-800-SAMSUNG (726-7864) Printed in Korea A00000 Rev.1.0 USA Type 06/2020 QUICK START GUIDE EJ-PX710 S Pen b a Device layout S Pen buttonS Pen nib English Copyright © 2020 Samsung Electronics Bluetooth ® is a registered trademark of Bluetooth SIG, Inc. worldwide. • Please read this guide before using the device to ensure safe and proper use. • Before using the S Pen, make sure it is compatible with your device. • Your consumer rights are governed by the law of the country in which you purchased the product. Please contact your service provider for more information. Device layout Using the S Pen Use the S Pen to perform touch actions or draw on the screen of your mobile device. You can use additional features by pressing the S Pen button. When you attach the S Pen on the rear of your mobile device, charging will start. Refer to the mobile device’s user manual for more information. Safety information Read all safety information before using the device to ensure safe and proper use. To view the full safety information, refer to the Samsung website. Use manufacturer-approved batteries, chargers, accessories, and supplies Do not touch the device with wet hands Do not drop or cause an impact to the charger or the device Do not allow children or animals to chew or suck the device Do not disassemble, modify, or repair your device FCC 15.21 Warning against unauthorized change Pursuant to Part 15.21 of the FCC Rules, you are cautioned that changes or modifications not expressly approved by Samsung could void your authority to operate the device. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. • Depending on the region or model, some devices are required to receive approval from the Federal Communications Commission (FCC). If your device is approved by the FCC, you can view the FCC ID of the device. To view the FCC ID, launch the Settings app and tap About phone → Status. RSS-Gen, Section 8.4 Statement IC Notice This device complies with Industry Canada licence exempt RSS standard(s). Operation is subject to the following two conditions: 1. This device may not cause interference. 2. This device must accept any interference, including interference that may cause undesired operation of the device. • Depending on the region or model, some devices are required to receive approval from Innovation, Science and Economic Development Canada (ISED)/the Federal Communications Commission (FCC). If your device is approved by the ISED/FCC, you can view the ISED/FCC ID of the device. To view the ISED/FCC ID, launch the Settings app and tap About phone → Status. Printed in Korea A00000 Rev.1.0 CANADA Type 06/2020 QUICK ST ART GUIDE EJ-PX710 b a S Pen buttonS Pen nib FCC and IC RF Radiation Exposure Statement: This equipment complies with FCC and IC RF Radiation exposure limits set forth for an uncontrolled environment. This device and its antenna must not be co- located or operating in conjunction with any other antenna or transmitter. RF du FCC et IC d'exposition aux radiations: Cet équipement est conforme à …

Text truncated - open the document above for the full version.

UNITED STATES DESIGNATED AGENT LETTER Date: 28-MAR-2023 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Applicant U.S. designated agent Company Name: Samsung Electronics Co., Ltd. Company Name: Samsung Electronics Co., Ltd. Grantee Code: A3L FRN: 0005810205 Contact Name: Jenni Chun Contact Name: Jenni Chun Address: 19 Chapin Rd., Building D Address: 19 Chapin Rd., Building D City/Province/Zip: Pine Brook/New Jersey/07058 City/Province/Zip: Pine Brook/New Jersey/07058 Telephone: 973-808-6375 Telephone: 973-808-6375 Fax: 973-808-6361 Fax: 973-808-6361 Email: [email protected] Email: [email protected] Applicable Equipment: FCC ID: A3LFEJPX710 ATTN: Director of Certification: We, Samsung Electronics Co., Ltd., understand and acknowledge the applicants consent and the designated agent’s obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and e-mail of the designated agent listed above. We, Samsung Electronics Co., Ltd., acknowledge the applicant’s acceptance of its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Applicant U.S. designated agent Name (Printed): Jenni Chun Name (Printed): Jenni Chun Title: General Manager Title: General Manager Signature: Signature:

Applicant Declaration QSF27-14-04 Rev 1.0 Rev. Feb 6, 2023 Page 1 of 1 Original Issue: Jan. 4, 2021 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name Samsung Electronics Co., Ltd. Address 19 Chapin Rd., Building D, Pine Brook, New Jersey, 07058 Grantee Code A3L FCC ID A3LEJPX710 Authorized Contact Name Jenni Chun Contact Email [email protected] Contact Phone 973-808-6375 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a)in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b)in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c)if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d)in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e)in accordance with ISO 17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f)neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g)the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Link to the Covered List: Covered List Samsung Electronics Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Samsung Electronics Co., Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered list, established pursuant to §1.50002, as an entity producing “covered” equipment. Applicant Signature: Date: 03 April 2023 Print Name: Jenni Chun Title: General Manager *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

Item Contents Antenna Type PCB Embedded Antenna Antenna peak gain -6.02 ㏈i Manufacturer / Model name Samsung Electronics Co Ltd / - Address of manufacturer 19 Chapin Rd., Building D, Pine Brook, New Jersey, United States, 07058 Antenna Length 0.4 cm Antenna Width 0.2 cm Antenna Information PCB Embedded Antenna Length Width TopBottom EJ-PX711 S-Pen BLE Antenna Specification EJ-PX711 S-Pen BLE PCB Embedded Antenna Frequency [MHz]240024402480 PeakGain [dBi]-8.96-7.73-6.02 Avg.Gain [dB]-13.32-11.98-10.51 VSWR Antenna Gain Freqency[MHz]240024402480 VSWR1.701.281.33 Antenna Antenna T I S Measurement ReportAirlink 3D Model NameEJ-PX710 Channel0 Ch.19 Ch.39 Ch. T I S79.4481.7981.89 Max.84.7987.2987.47 NHPIS 60`78.2480.4580.48 UHIS78.9881.3881.52 UHIS Ratio64.65%65.42%66.13% T R P Measurement ReportAirlink 3D Model NameEJ-PX710 Channel0 Ch.19 Ch.39 Ch. T R P-13.93-11.05-9.92 Max.-8.36-5.71-4.21 NHPRP 60`-15.08-12.36-11.33 UHRP-14.38-11.40-10.23 UHRP Ratio64.83%66.14%67.23%

SAMSUNG ELECTRONICS CO., LTD 129, Samsung-ro,Yeongtong-gu Suwon-si,Gyeonggi-do, 16677, Korea April 4 th , 2023 Federal Communications Commission SUBJECT : Label Statement FCC ID : A3LEJPX710 To Whom It May Concern: We hereby provide the following attestations according to 47 CFR 2.935 and FCC KDB 784748 D02: This device operates in conjunction with a device that has an electric display and therefore qualifies for e-labling per 47 CFR 2.935 and FCC KDB 784748 D02. The product and associated device are capable of functioning locally and under control of the end-user, per FCC KDB 784748 D02. At the time of purchase, the FCC ID is readily and physically visible to the purchaser on the exterior package per 2.935(d). The FCC ID will be readily legible without the aid of magnification according to 2.935(a). The literature in the package describes how to access the electronic display to find the FCC ID per 2.935(e) and FCC KDB 784748. The user will be able to ac cess this information within a maximum of 3 steps. We, Samsung have programmed the e-label and it is not able to be modified by any third party.The user will be able to access this information without a SIM card, special ac cessories or supplemental plug- ins. The FCC ID will be able to survive normal shipping and handling so it is visible for inspection at the time of import. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely Yours, JENNI, CHUN General Manager Samsung Electronics CO. LTD TEL: +1-973-808-6375 FAX: +1-973-808-6361 E-mail: [email protected]

19 Chapin Rd., Building D Pine Brook, New Jersey, 07058, United States Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 LETTER FOR AUTHORIZATION FCC ID: A3LEJPX710 To whom it may concern: I, the undersigned, hereby authorize SGS Korea Co., Ltd. and hereafter referred to as SGS Korea, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by SGS Korea Co., Ltd. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti‐Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing SGS Korea Co., Ltd. as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; 03 April 2023 19 Chapin Rd., Building D Pine Brook, New Jersey, 07058, United States i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours Jenni Chun/ General Manager Samsung Ele ctronics North America INC. TEL: +1-973-808-6362 E-mail: [email protected]

19 Chapin Rd., Building D Pine Brook, New Jersey, 07058, United States 03 April 2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 REQUEST FOR CONFIDENTIALITY FCC ID: A3LEJPX710 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Samsung Electronics Co., Ltd. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets a nd proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short‐Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04‐1705. This provision will give Samsung Electronics Co., Ltd temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: CONFIDENTIAL LIST Permanent 1 Block Diagram 2 Operational Descriptions 3 Schematics Short‐Term 4 External Photos 5 Internal Photos 6 Test‐Setup Photos 7 User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely Yours, Jenni Chun / General Manager Samsung Electronics North America INC. TEL: +1-973-808-6362 E-mail: [email protected]

Model name: EJ-PX710 External photos of EUT Model name: EJ-PX710 Top view of EUT Bottom view of EUT Model name: EJ-PX710 Side view of EUT Model name: EJ-PX710

Description of E-label on the A3LEJPX710 April 4 th , 2023 IC: 649E-EJPX710 HVIN: EJ-PX710 FCC ID: A3LEJPX710 This model is applied E-label, please find description of E-label below. 1.ISED( E-label) - English: Settings > About phone> Status ISED( E-label) - French: Paramètres > À propos du téléphone> État S Pen FCC and ISED certification FCC ID: A3LEJPX710 IC: 649E-EJPX710 (EJ-PX710) 2.Instruction of E-label on the User manual (online manual) •Depending on the region or model, some devices are required to receive approval from Innovation, Science and Economic Development Canada (ISED)/the Federal Communications Commission (FCC). If your device is approved by the ISED/FCC, you can view the ISED/FCC ID of the device. To view the ISED/FCC ID, launch the Settings app and tap About phone → Status. •Selon la région ou le modèle, certains appareils doivent recevoir une certification de Innovation, Sciences et Développement économique Canada (ISDE) et de la Commission fédérale des communications (FCC). Si votre appareil est approuvé par ISDE/FCC, vous pouvez trouver l’ID ISDE/FCC de l’appareil. Pour ce faire, ouvrez l’appli Paramètres et touchez À propos du téléphone → État. <Display Screen>

Model name: EJ-PX710 Internal photos of EUT Model name: EJ-PX710 Internal view of EUT Model name: EJ-PX710 Top view of Main PCB Bottom view of Main PCB Model name: EJ-PX710 View of Antenna & Module PCB Embedded Antenna Bluetooth Low Energy Module

FCC ID: A3LEJPX710 According to KDB 447498 D04 Interim General RF Exposure Guidance v01 1. SAR-based Exemption A more comprehensive exemption, considering a variable power threshold that depends on both the separation distance and power, is provided in § 1.1307(b)(3)(i)(B). This exemption is applicable to the frequency range between 300 ㎒ and 6 ㎓, with test separation distances between 0.5 ㎝ and 40 ㎝, and for all RF sources in fixed, mobile, and portable device exposure conditions. Accordingly, a RF source is considered an RF exempt device if its available maximum time-averaged (matched conducted) power or its effective radiated power (ERP), whichever is greater, are below a specified threshold. This exemption threshold was derived based on general population 1-g SAR requirements and is detailed in Appendix C. 2. RF Exposure Test Exemptions for Single Source Mode Frequency Range (㎒) Minimum Separation Distance (㎝) Maximum Average Target Power 1) (㏈m) Maximum Tune up (㏈) Maximum Average Output Power 2) (㏈m) Antenna Gain (㏈i) ERP 3) P th (㎽) Ratio Result (㏈m) (㎽) Bluetooth Low Energy 2 402 ~ 2 480 0 -1.00 1.50 0.50 -6.02 0.50 1.12 2.72 0.41 Pass Note ; 1) Maximum average target power is the manufacturer’s declared rated power. 2) Maximum average output power = Maximum average target power ( ㏈m) + Maximum tune up (㏈). 3) The larger value of Maximum Average Output Power or E.R.P. was applied. 3. Conclusion: No SAR is required.

SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003927 Page: 2 of 36 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) INDEX Table of contents 1. General Information -------------------------------------------------------------------------------------- 3 2. Transmitter Radiated Spurious Emissions and Conducted Spurious Emission ----------- 9 3. 6 ㏈ Bandwidth & 99 % Bandwidth ----------------------------------------------------------------- 25 4. Maximum Peak Conducted Output Power --------------------------------------------------------- 30 5. Power Spectral Density --------------------------------------------------------------------------------- 33 6. Antenna Requirement ----------------------------------------------------------------------------------- 36 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003927 Page: 3 of 36 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 1. General Information 1.1. Testing Laboratory SGS Korea Co., Ltd. (Gunpo Laboratory) - 10-2, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 - 4, LS-ro 182beon-gil , Gunpo-si, Gyeonggi-do, Korea, 15807 - Designation number: KR0150 All SGS services are rendered in accordance with the applicable SGS conditions of service available on request and accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx. Phone No. : +82 31 688 0901 Fax No. : +82 31 688 0921 1.2. Details of Applicant FCC Applicant : Samsung Electronics Co Ltd FCC Address : 19 Chapin Rd., Building D, Pine Brook, New Jersey, United States, 07058 IC Applicant : SAMSUNG ELECTRONICS CO. LTD. IC Address : 129 Samsung-ro, Yeongtong-gu, Suwon-Si, Gyeonggi-do, 16677, Korea (Republic Of) Contact Person : Jenni, Chun Phone No. : +1 973 808 6375 1.3. Details of Manufacturer Company : Samsung Electronics Co., Ltd. Address : 129, Samsung-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Republic of Korea 1.4. Description of EUT Kind of Product S PEN Model Name EJ-PX710 Variant Model Names - Serial Number Conducted Sample: PX710_1 Radiated Sample: PX710_2 Power Supply DC 2.40 V Frequency Range 2 402 ㎒ ~ 2 480 ㎒ (Bluetooth Low Energy) Modulation Technique GFSK Number of Channels 40 channels (Bluetooth Low Energy) Antenna Type PCB Embedded Antenna Antenna Gain ※ -6.02 ㏈i H/W Version rev0.4 S/W Version 0X82 FVIN N/A SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003927 Page: 4 of 36 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 1.5. Test Equipment List Equipment Manufacturer Model S/N Cal. Date Cal. Interval Cal. Due Signal Generator R&S SMA100B 106887 Oct. 13, 2022 Annual Oct. 13, 2023 Signal Generator R&S SMBV100A 255834 May 25, 2022 Annual May 25, 2023 Spectrum Analyzer R&S FSV30 103210 Dec. 07, 2022 Annual Dec. 07, 2023 Spectrum Analyzer Agilent N9020A MY53421758 Aug. 26, 2022 Annual Aug. 26, 2023 Attenuator AEROFLEX / INMET 40AH2W-10 40G-1 Jun. 08, 2022 Annual Jun. 08, 2023 High Pass Filter Wainwright Instrument GmbH WHKX3.0/18G-6SS 21 Jun. 09, 2022 Annual Jun. 09, 2023 Low Pass Filter Mini-Circuits NLP-1200+ V 8979400903-2 Feb. 09, 2023 Annual Feb. 09, 2024 Power Sensor R&S NRP-Z81 100669 May 06, 2022 Annual May 06, 2023 DC Power Supply Agilent U8002A MY49030063 Jan. 20, 2023 Annual Jan. 20, 2024 Preamplifier H.P. 8447F 2944A03909 Aug. 04, 2022 Annual Aug. 04, 2023 Signal Conditioning Unit R&S SCU-18 10117 Jun. 13, 2022 Annual Jun. 13, 2023 Pre Amplifier TESTEK TK-PA1840H 130016 Jan. 11, 2023 Annual Jan. 11, 2024 Loop Antenna Schwarzbeck Mess-Elektronik FMZB 1519 1519-039 Aug. 23, 2021 Biennial Aug. 23, 2023 Bilog Antenna Schwarzbeck Mess-Elektronik VULB 9163 01126 Feb. 09, 2023 Annual Feb. 09, 2024 Horn Antenna R&S HF906 100326 Feb. 28, 2023 Annual Feb. 28, 2024 Horn Antenna Schwarzbeck Mess-Elektronik BBHA 9170 9170-540 Nov. 30, 2022 Annual Nov. 30, 2023 EMI Test Receiver R&S ESU26 100109 Jan. 18, 2023 Annual Jan. 18, 2024 Turn Table Innco systems GmbH DS 1200 S N/A N.C.R. N/A N.C.R. Controller Innco systems GmbH CONTROLLER CO3000-4P CO3000/963/383 30516/L N.C.R. N/A N.C.R. Antenna Mast Innco systems GmbH MA4640-XP-ET MA4640/536/383 30516/L N.C.R. N/A N.C.R. Anechoic Chamber SY Corporation L × W × H (9.6 m × 6.4 m × 6.6 m) N/A N.C.R. N/A N.C.R. Coaxial Cable RFONE MWX221-NMSNMS (4 m) J1023142 Oct. 04, 2022 Semi- Annual Apr. 04, 2023 Coaxial Cable Qualwave Inc. QA500-18-NN-10 (10 m) 22200114 Oct. 04, 2022 Semi- Annual Apr. 04, 2023 Coaxial Cable RFONE PL360P-292M292M-1.5M- A 20200324002 Feb. 18, 2023 Semi- Annual Aug. 18, 2023 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL003927 Page: 5 of 36 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 1.6. Summary of Test Results The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15 Subpart C, RSS-247 Issue 2, RSS-Gen Issue 5 Section in FCC Section in IC Test Item(s) Result 15.205(a) 15.209 15.247(d) RSS-247 Issue 2 5.5 RSS-Gen Issue 5 8.9 Transmitter Radiated Spurious Emissions and Conducted Spurious Emission Complied 15.247(a)(2) RSS-247 Issue 2 5.2(a) RSS-Gen Issue 5 6.7 6 ㏈ Bandwidth & 99 % Bandwidth Complied 15.247(b)(3) RSS-247 Issue 2 5.4(d) Maximum Peak Conducted Output Power Complied 15.247(e) RSS-247 Issue 2 5.2(b) Power Spectral Density Complied 15.207 RSS-Gen Issue 5 8.8 AC Power Line Conducted Emission N/A 1) Note; 1) The AC power line test was not performed because the EUT use battery power for operation and which do not operate from the AC power lines. 1.7. Test Procedure(s) The measurement procedures described in the American National Standard of Procedure for Compliance T…

Text truncated - open the document above for the full version.

Model name: EJ-PX710 Test setup photos of EUT Model name: EJ-PX710 1. Orthogonal plane of EUT - The testing was set in the three orthogonal planes and measured for each position (X, Y, Z). X-axis Y-axis Model name: EJ-PX710 Z-axis Model name: EJ-PX710 2. Photos of Radiated Spurious Emission Test (Below 1㎓) Model name: EJ-PX710 3. Photo of Radiated Spurious Emission Test (Above 1㎓) Model name: EJ-PX710 4. Photo of Conducted Test
