Cover Letter-Wireless Charger Approval FCC ID: A3LEPP1300 Date: 16 Dec, 2020 Gentlemen: There’s a EP-P1300 that would like to have your authorization as an Inductive wireless power transfer applications approval. The specific product as below, EP-P1300, with its designed features and specified description, considers special requirements for KDB 680106 D01 v03 section 5, b) requirements. Company: Samsung Electronics Co., Ltd. Product Name: WIRELESS CHARGER Model Number: EP-P1300 FCC ID: A3LEPP1300 KDB 680106 D01 v03 Section 5, b) Requirements: Product Technical Specification: Result: (1) Power transfer frequency is less that 1 MHz 0.126 2 ~ 0.129 2 MHz Complied (2) Output power from each primary coil is less than or equal 15 watts. 2 Watts, 4.5 Watts, 7.5 Watts and 9 Watts Complied (3) The transfer system includes only single primary and secondary coils. This includes charging systems that may have multiple primary coils and clients that are able to detect and allow coupling only between individual pairs of coils The transfer system includes only single primary coil. Complied (4) Client device is placed directly in contact with the transmitter Client device is placed directly in contact with the transmitter. Complied (5) Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). Mobile conditions only Complied (6) The aggregate H-field strengths at 15 cm surrounding the device and 20 cm above the top surface from all simultaneous transmitting coils are demonstrated to be less than 50% of the MPE limit. H-Field: 0.643 A/m (at 15 cm) < 0.815 A/m (50% of the limit) Complied

External photos of EUT Top view of EUT Bottom view of EUT Side view of EUT

< 1:1 Artwork > 5.3 5.3 7.42 6.5 3.1 S/N:제조시 14자리 인쇄 표기 < 1:1 Artwork > 3-R1.0 36.0 24.0 C2 WIRELESS CHARGER This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. MODEL : EP-P1300 INPUT : 9.0 V 1.67 A FCC ID : A3LEPP1300 IC : 649E-EPP1300 S/N : MADE IN VIETNAM / FABRIQUÉ AU VIETNAM Label information

Internal photos of EUT Internal view of EUT Top view of Main PCB Bottom view of Main PCB View of Antenna j Loop coil antenna

SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001436-2 Page: 2 of 9 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) INDEX Table of Contents 1. General Information -------------------------------------------------------------------------------------- 3 2. Test Result -------------------------------------------------------------------------------------------------- 6 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001436-2 Page: 3 of 9 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 1. General Information 1.1. Testing Laboratory SGS Korea Co., Ltd. (Gunpo Laboratory) - 10-2, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 - 4, LS-ro 182beon-gil , Gunpo-si, Gyeonggi-do, Korea, 15807 All SGS services are rendered in accordance with the applicable SGS conditions of service available on request and accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx. Phone No. : +82 31 688 0901 Fax No. : +82 31 688 0921 1.2. Details of Applicant Applicant : Samsung Electronics Co., Ltd. Address : 19 Chapin Rd., Building D, Pine Brook, New Jersey, United States, 07058 Contact Person : Chun, Jenni Phone No. : +1 973 808 6375 1.3. Details of Manufacturer Company : Samsung Electronics Co., Ltd. Address : Yen Phong 1 Industrial park, Yen Phong District Bac Ninh Province, VIETNAM 1.4. Description of EUT Kind of Product WIRELESS CHARGER Model Name EP-P1300 Power Supply DC 9.0 V Operation Mode 2 W, 4.5 W, 7.5 W, 9W Frequency Range 126.2 ㎑ ~ 129.2 ㎑ Antenna Type Loop Coil Antenna H/W Version rev.03 S/W Version_MCU EP-P1300_20201111_8F5C S/W Version_Tx IC P13_PRA_OFFI_1208 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001436-2 Page: 4 of 9 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 1.5. Test Equipment List Equipment Manufacturer Model S/N Cal. Date Cal. Interval Cal. Due Electric and Magnetic field Probe analyzer NARDA EHP 200AC 170WX91017 Nov. 16, 2020 Annual Nov. 16, 2021 Anechoic Chamber SY Corporation L × W × H (9.6 m × 6.4 m × 6.6 m) N/A N.C.R. N/A N.C.R. ▶ Support Equipment Description Manufacturer Model FCC ID Samsung Mobile Phone Samsung Electronics Co., Ltd. SM-G970 A3LSMG970U SM-G973U A3LSMG973U Bluetooth Headset Samsung Electronics Co., Ltd. SM-R170 A3LSMR170L, A3LSMR170R C type USB Cable Samsung Electronics Co., Ltd. EP-DW720 - TRAVEL ADAPTER DONGYANG E&P EP-TA200 - 1.6. Test Report Revision Revision Report Number Date of Issue Description 0 F690501-RF-RTL001436 2020.12.09 Initial 1 F690501-RF-RTL001436-1 2020.12.14 Added the information of H/W Version and S/W Version. 2 F690501-RF-RTL001436-2 2020.12.16 Added the test mode to indicate what kind of client device is used. 1.7. Measurement Uncertainty Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the apparatus: Parameter Uncertainty Electric Field ± 19.78 % Magnetic Field ± 13.66 % Uncertainty figures are valid to a confidence level of 95 %. SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001436-2 Page: 5 of 9 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 1.8. Worst Case of Test Configurations In order to check all kinds of possible configurations, EUT was evaluated with appropriate client and under each charging condition as below table. Charging mode with client device Mode Description Model: SM-G970U FCC ID: A3LSMG970U Model: SM-G973U FCC ID: A3LSMG973U Model: SM-R170 FCC ID: A3LSM R170L, A3LSMR170R 2 W 4.5 W 7.5 W 9 W 1 % of battery 50 % of battery 99 % of battery 126.2 ㎑ ~ 129.2 ㎑ 126.2 ㎑ ~ 129.2 ㎑ 126.2 ㎑ ~ 129.2 ㎑ 126.2 ㎑ ~ 129.2 ㎑ SM-R170 SM-G970U (Normal) SM-G970U (Fast) SM-G973U Note; The 4.5 W and 7.5 W modes are controlled by the software on the client device. EUT was investigated with client device under normal charging condition as above then worst value was only reported. SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001436-2 Page: 6 of 9 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 2. Test Result 2.1. Test Setup 2.2. Measurement procedure a) The RF exposure test was performed in anechoic chamber. b) The measurement probe was placed at test distance (15 ㎝) which is between the edge of the charger and the geometric center of probe. c) The highest emission level was recorded and compared with limit as soon as measurement of each points (A, B, C, D, E, F) were completed. d) The EUT was measured according to the dictates of KDB 680106 D01 RF Exposure Wireless Charging Apps v03. SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001436-2 Page: 7 of 9 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 2.3. Environmental evaluation and exposure limit according to FCC CFR 47 part 1, 1.1307(b), 1.1310. §1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in §1.1307(b), except in the case of portable devices which shall be evaluated according to the provisions of FCC part 2.1093 of this chapter. TABLE 1 - LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) f = frequency in ㎒ * = Plane wave equivalent power density Frequency Range (㎒) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (㎽/㎠) Average Time (minutes) (A) Limits for Occupational /Control Exposures 0.3-3.0 614 1.63 *(100) 6 3.0-30 1842/f 4.89/f *(900/f 2 …

Text truncated - open the document above for the full version.

SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001435-2 Page: 2 of 39 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) INDEX Table of Contents 1. General Information -------------------------------------------------------------------------------------- 3 2. Field Strength of Fundamental and Spurious Emission ----------------------------------------- 7 3. 20 ㏈ Bandwidth ----------------------------------------------------------------------------------------- 27 4. AC Power Line Conducted Emission ---------------------------------------------------------------- 30 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001435-2 Page: 3 of 39 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 1. General Information 1.1. Testing Laboratory SGS Korea Co., Ltd. (Gunpo Laboratory) - 10-2, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 - 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 All SGS services are rendered in accordance with the applicable SGS conditions of service available on request and accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx. Phone No. : +82 31 688 0901 Fax No. : +82 31 688 0921 1.2. Details of Applicant Applicant : Samsung Electronics Co., Ltd. Address : 19 Chapin Rd., Building D, Pine Brook, New Jersey, United States, 07058 Contact Person : Chun, Jenni Phone No. : +1 973 808 6362 1.3. Details of Manufacturer Company : Samsung Electronics Co., Ltd. Address : Yen Phong 1 Industrial park, Yen Phong District Bac Ninh Province, VIETNAM 1.4. Description of EUT Kind of Product WIRELESS CHARGER Model Name EP-P1300 Power Supply DC 9.0 V Operation Mode 2 W, 4.5 W, 7.5 W, 9W Frequency Range 126.2 ㎑ ~ 129.2 ㎑ Antenna Type Loop Coil Antenna H/W Version rev.03 S/W Version_MCU EP-P1300_20201111_8F5C S/W Version_Tx IC P13_PRA_OFFI_1208 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001435-2 Page: 4 of 39 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 1.5. Test Equipment List Equipment Manufacturer Model S/N Cal. Date Cal. Interval Cal. Due Spectrum Analyzer R&S FSV30 103210 Dec. 07, 2020 Annual Dec. 07, 2021 Signal Generator R&S SMBV100A 255834 Ju n. 03, 2020 Annual Ju n. 03, 2021 Amplifier H.P. 8447F 2944A03909 Aug. 06, 2020 Annual Aug. 06, 2021 Loop Antenna Schwarzbeck Mess-Elektronik FMZB 1519 1519-039 Aug. 22, 2019 Biennial Aug. 22, 2021 Bilog Antenna Schwarzbeck Mess-Elektronik VULB9163 396 Mar. 21, 2019 Biennial Mar. 21, 2021 Test Receiver R&S ESU26 100109 Feb. 18, 2020 Annual Feb. 18, 2021 Turn Table Innco systems GmbH DS 1200 S N/A N.C.R. N/A N.C.R. Controller Innco systems GmbH CONTROLLER CO3000-4P CO3000/963/38 330516/L N.C.R. N/A N.C.R. Anechoic Chamber SY Corporation L × W × H (9.6 m × 6.4 m × 6.6 m) N/A N.C.R. N/A N.C.R. Coaxial Cable RFONE MWX221-NMSNMS (4 m) J1023142 Dec. 01, 2020 Semi- annual Jun. 01, 2021 Coaxial Cable RFONE PL520-NMNM-10M (10 m) 20200324001 Aug. 10, 2020 Semi- Annual Feb. 10, 2021 Test Receiver R&S ESCI 7 100911 Feb. 19, 2020 Annual Feb. 19, 2021 Two-Line V-Network R&S ENV216 100190 May 08, 2020 Annual May 08, 2021 Shield Room SY Corporation L × W × H (6.5 m × 3.5 m × 3.5 m) N/A N.C.R. N/A N.C.R. ▶ Support Equipment Description Manufacturer Model FCC ID Samsung Mobile Phone Samsung Electronics Co., Ltd. SM-G970 A3LSMG970U SM-G973U A3LSMG973U Bluetooth Headset Samsung Electronics Co., Ltd. SM-R170 A3LSMR170L, A3LSMR170R C type USB Cable Samsung Electronics Co., Ltd. EP-DW720 - TRAVEL ADAPTER DONGYANG E&P EP-TA200 - 1.6. Sample Calculation Where relevant, the following sample calculation is provided: Field strength level (㏈㎶/m) = Measured level (㏈㎶) + Antenna factor (㏈) + Cable loss (㏈) + (AMP (㏈)) SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001435-2 Page: 5 of 39 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 1.7. Worst Case of Test Configurations Charging mode with client device Mode Description Model: SM-G970U FCC ID: A3LSMG970U Model: SM-G973U FCC ID: A3LSMG973U Model: SM-R170 FCC ID: A3LSMR170L, A3LSMR170R 2 W 4.5 W 7.5 W 9 W 1 % of battery 50 % of battery 99 % of battery 126.2 ㎑ ~ 129.2 ㎑ 126.2 ㎑ ~ 129.2 ㎑ 126.2 ㎑ ~ 129.2 ㎑ 126.2 ㎑ ~ 129.2 ㎑ SM-R170 SM-G970U (Normal) SM-G970U (Fast) SM-G973U Note; The 4.5 W and 7.5 W modes are controlled by the software on the client device. EUT was investigated with client device under normal charging condition as above then worst value was only reported. SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001435-2 Page: 6 of 39 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 1.8. Summary of Test Results The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15 Subpart C Section Test Item(s) Result 15.209 Radiated Emission, Spurious Emission and Field Strength of Fundamental Complied 2.1049 20 ㏈ Bandwidth Complied 15.207 AC Power Line Conducted Emission Complied Note; Due to the frequency range of the device is less than 1㎒, so we perform Middle frequency according to 15.31 requirement. 1.9. Measurement Uncertainty Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the apparatus: Parameter Uncertainty 20 ㏈ Bandwidth ± 9.66 ㎑ AC Conducted Emission ± 3.45 ㏈ Radiated Disturbance, 9㎑ to 30㎒ ± 3.59 ㏈ Radiated Disturbance, below 1 ㎓ ± 5.88 ㏈ Uncertainty figures are valid to a confidence level of 95 %. 1.10. Test Report Revision Revision Report Number Date of Issue Description 0 F690501-RF-RTL001435 20…

Text truncated - open the document above for the full version.

Test setup photo of EUT 1. Photos of Operating Mode 2. Photo of Radiated Spurious Emission Test (9 ㎑ ~ 30 ㎒) 3. Photo of Radiated Spurious Emission Test (30 ㎒ ~ 1 000 ㎒) 4. Photos of AC Power line emission Test 5. Photos of MPE Test T R AV E L ADAPTER Test PC SM-R170 Probe EUT
