A3LEPP6300WIRELESS CHARGER

English 1 2 Copyright © 2020 Samsung Electronics America, Inc. Other marks are the property of their respective owners. • Connect the charger to the wireless charger ( 1 ) and place the mobile device, Buds or the watch on the phone stand ( 2 ) to charge it. • Do not place foreign materials, such as metal objects, magnets, and magnetic stripe cards, between the mobile device, Buds or the watch, and the wireless charger. • Visit www.samsung.com to view the user manual and the safety information. • Your consumer rights are governed by the law of the country in which you purchased the product. Please contact your service provider for more information. FCC Part 15.19 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Part 15.21 Any changes or modifications (including the antennas) to this device that are not expressly approved by the manufacturer may void the user’s authority to operate the equipment. FCC RF Radiation Exposure Statement This equipment complies with FCC RF Radiation exposure limits set forth for an uncontrolled environment. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment should be installed and operated with a minimum distance of 20 cm between the radiator and your body. Samsung Mobile Products and Recycling Samsung cares for the environment and encourages its customers to properly dispose of Devices and Samsung accessories in accordance with local regulations. In some areas, disposal of these items in household or business trash may be prohibited. Dispose of other unwanted electronics through an approved recycler. To find the nearest recycling location, go to our website: www.samsung.com/recycling or call, 1-800-SAMSUNG. Samsung Electronics America, Inc 85 Challenger Road, Ridgefield Park, New Jersey, 07660 Phone: 1-800-SAMSUNG (726-7864) Printed in Korea A00000 Rev.1.0 USA Type 08/2020 QUICK START GUIDE EP-P6300 WIRELESS CHARGER TRIO This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) L’appareil ne doit pas produire de brouillage; (2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Cet équipement est conforme aux limites établies par Industrie Canada en matière d'exposition aux radiofréquences dans un environnement non contrôlé. Cet appareil et son antenne ne doivent pas être colocalisés ou fonctionner en conjonction avec tout autre antenne ou émetteur. Cet équipement doit être installé et utilisé avec une distance minimale de 20cm entre le radiateur et votre corps.

19 Chapin Rd., Building D Pine Brook, New Jersey, 07058, United States Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 LETTER FOR AUTHORIZATION FCC ID: A3LEPP6300 To whom it may concern: I, the undersigned, hereby authorize Lab Manager Hyunchae, You and of SGS Korea Co., Ltd. and hereafter referred to as SGS Korea, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Lab Manager Hyunchae, You of SGS Korea Co., Ltd. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti‐Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing SGS Korea as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; 28 September 2020 19 Chapin Rd., Building D Pine Brook, New Jersey, 07058, United States i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours Jenni Chun/ General Manager Samsung Ele ctronics North America INC. TEL: +1-973-808-6362 E-mail: [email protected]

19 Chapin Rd., Building D Pine Brook, New Jersey, 07058, United States 28 September 2020 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 REQUEST FOR CONFIDENTIALITY FCC ID: A3LEPP6300 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Samsung Electronics Co., Ltd. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short‐Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04‐1705. This provision will give Samsung Electronics Co., Ltd temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: CONFIDENTIAL LIST Permanent 1 Block Diagram 2 Operational Descriptions 3 Schematics Short‐Term 4 External Photos 5 Internal Photos 6 Test‐Setup Photos 7 User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely Yours, Jenni Chun / General Manager Samsung Electronics North America INC. TEL: +1-973-808-6362 E-mail: [email protected]

Cover Letter-Wireless Charger Approval FCC ID: A3LEPP6300Date: 25 Sep, 2020 Gentlemen: There’s a EP-P6300 that would like to have your authorization as an Inductive wireless power transfer applications approval. The specific product as below, EP-P6300, with its designed features and specified description, considers special requirements for KDB 680106 D01 v03 section 5, b) requirements. Company: Samsung Electronics Co., Ltd. Product Name: WIRELESS CHARGER Model Number: EP-P6300 FCC ID: A3LEPP6300 KDB 680106 D01 v03 Section 5, b) Requirements:Product Technical Specification:Result: (1) Power transfer frequency is less that 1 MHz0.119 ~ 0.122 MHz, 0.126 2 ~ 0.129 2 MHz, 0.136 5 ~ 0.139 5 MHz and 0.144 5 ~ 0.147 5 MHz Complied (2) Output power from each primary coil is less than or equal 15 watts. 2 Watts, 4.5 Watts, 7.5 Watts and 9 Watts Complied (3) The transfer system includes only single primary and secondary coils. This includes charging systems that may have multiple primary coils and clients that are able to detect and allow coupling only between individual pairs of coils The transfer system including a charging system with multiple primary coils are to detect and allow only between individual pairs of coils. Complied (4) Client device is placed directly in contact with the transmitter Client device is placed directly in contact with the transmitter. Complied (5) Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). Mobile conditions onlyComplied (6) The aggregate H-field strengths at 15 cm surrounding the device and 20 cm above the top surface from all simultaneous transmitting coils are demonstrated to be less than 50% of the MPE limit. H-Field: 0.600 A/m (at 15 cm) <0.815 A/m (50% of the limit) Complied

External photos of EUT Top view of EUT Bottom view of EUT Side view of EUT

Internal photos of EUT Internal view of EUT Top view of Main PCB View of Antenna j Loop coil antenna (ANT1) Loop coil antenna (ANT7) Loop coil antenna (ANT2) Loop coil antenna (ANT3) Loop coil antenna (ANT4) Loop coil antenna (ANT5) Loop coil antenna (ANT6)

SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number:F690501-RF-RTL001208 Page:2of13 RTT5041-19(2020.03.02)(2) A4(210 mmx297 mm) INDEX Table of Contents 1. General Information --------------------------------------------------------------------------------------3 2. Test Result -------------------------------------------------------------------------------------------------5 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number:F690501-RF-RTL001208 Page:3of13 RTT5041-19(2020.03.02)(2) A4(210 mmx297 mm) 1. General Information 1.1. Testing Laboratory SGS Korea Co., Ltd. (Gunpo Laboratory) - 10-2, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 - 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 - Designation number: KR0150 All SGS services are rendered in accordance with the applicable SGS conditions of service available on request and accessible athttp://www.sgs.com/en/Terms-and-Conditions.aspx. Phone No.: +82 31 688 0901 Fax No.: +82 31 688 0921 1.2. Details of Applicant Applicant:Samsung Electronics Co., Ltd. Address:19 Chapin Rd., Building D, Pine Brook, New Jersey, United States, 07058 Contact Person:Chun, Jenni Phone No.:+1 973 808 6375 1.3. Details of Manufacturer Company:Samsung Electronics Co., Ltd. Address:Yen Phong 1 Industrial park, Yen Phong District Bac Ninh Province, VIETNAM 1.4. Description of EUT Kind of Product WIRELESS CHARGER Model Name EP-P6300 Power Supply DC 9.0 V Operation Mode 2 W, 4.5 W, 7.5 W, 9W Frequency Range 119㎑~ 122㎑ Ant.1, Ant. 2, Ant. 3, Ant. 4, Ant. 5, Ant. 6 126.2㎑~ 129.2㎑Ant.1, Ant. 2, Ant. 3, Ant. 4, Ant. 5, Ant. 6 136.5㎑~ 139.5㎑ Ant.1, Ant. 2, Ant. 3 144.5㎑~ 147.5㎑Ant. 4, Ant. 5, Ant. 6, Ant. 7 Antenna Type Loop Coil Antenna 1.5. Declaration by the Manufacturer - The EUT has 7 loop coil antennas. - 6 coils for 2 pairs of devices, 1 independent coil for smart watch. - Product is designed to operate only 3 coils at a time and can charge maximum 3 devices simultaneously. SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number:F690501-RF-RTL001208 Page:4of13 RTT5041-19(2020.03.02)(2) A4(210 mmx297 mm) 1.6. Test Equipment List EquipmentManufacturerModelS/NCal. Date Cal. Interval Cal. Due Electric and Magnetic field Probe analyzer NARDAEHP 200AC170WX91017Dec. 05, 2019AnnualDec. 05, 2020 Anechoic Chamber SY Corporation L × W × H (9.6 m × 6.4 m × 6.6 m) N/AN.C.R.N/AN.C.R. ▶Support Equipment DescriptionManufacturerModelFCC ID Samsung Mobile PhoneSamsung Electronics Co., Ltd.SM-G973U1A3LSMG973U Bluetooth HeadsetSamsung Electronics Co., Ltd.SM-R170 A3LSMR170L, A3LSMR170R Smart Wearable DeviceSamsung Electronics Co., Ltd.SM-R500A3LSMR500 C type USB Cable Samsung Electronics Co., Ltd. EP-DA705BBE, EP-DA705BWE - TRAVEL ADAPTER DONGYANG E&PEP-TA800- 1.7. Test Report Revision RevisionReport NumberDate of IssueDescription 0F690501-RF-RTL0012082020.09.25Initial 1.8. Worst Case of Test Configurations In order to check all kinds of possible configurations, EUT was evaluated with appropriate client and under each charging condition as below table. Charging mode with client device ModeDescription Model: SM-G973U1 FCC ID: A3LSMG973U Model: SM-R170 FCC ID: A3LSMR170L, A3LSMR170R Model: SM-R500 FCC ID: A3LSMR500 2 W4.5 W7.5W9W 1 % of battery 50 % of battery 99 % of battery Ant 1 ~ 3Ant 4 ~ 7Ant 1 ~ 3Ant 4 ~ 6Ant 1 ~ 3Ant 4 ~ 6Ant 1 ~ 3Ant 4 ~ 6 136.5㎑~ 139.5㎑ 144.5㎑~ 147.5㎑ 119㎑~ 122㎑ 119㎑~ 122㎑ 126.2㎑~ 129.2㎑ 126.2㎑~ 129.2㎑ 136.5㎑~ 139.5㎑ 144.5㎑~ 147.5㎑ 126.2㎑~ 129.2㎑ 126.2㎑~ 129.2㎑ 136.5㎑~ 139.5㎑ 136.5㎑~ 139.5㎑ 136.5㎑~ 139.5㎑ 144.5㎑~ 147.5㎑ Note; - EUT was investigated with client device under normal charging condition as above then worst value was only reported. SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number:F690501-RF-RTL001208 Page:5of13 RTT5041-19(2020.03.02)(2) A4(210 mmx297 mm) 2. Test Result 2.1. Test Setup 2.2. Measurement procedure a) The RF exposure test was performed in anechoic chamber. b) The measurement probe was placed at test distance (15㎝) which is between the edge of the charger and the geometric center of probe. c) The highest emission level was recorded and compared with limit as soon as measurement of each points (A, B, C, D, E, F) were completed. d) The EUT was measured according to the dictates of KDB 680106 D01 RF Exposure Wireless Charging Apps v03. SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number:F690501-RF-RTL001208 Page:6of13 RTT5041-19(2020.03.02)(2) A4(210 mmx297 mm) 2.3. Equipment Approval Considerations item 5 b) of KDB 680106 D01 v03. (1) Power transfer frequency is less that 1㎒. - The device operates at a frequency 119 ~ 122㎑, 126.2 ~ 129.2㎑, 136.5 ~ 139.5㎑and 144.5 ~ 147.5㎑. (2) Output power from each primary coil is less than or equal to 15 watts. - Output power from primary coil: 9 watts. (3) The transfer system includes only single primary and secondary coils. This includes charging systems that may have multiple primary coils and clients that are able to detect and allow coupling only between individual pairs of coils. - The transfer system including a charging system with one primary coils is to detect and allow only between individual pairs of coils. (4) Client device is placed directly in contact with the transmitter. - Client device is placed directly in contact with the transmitter. (5) Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). - Mobile exposure conditions only. (6) The aggregate H-field strengths at 15㎝surrounding the device and 20㎝a…
