A3LEVNXF1Digital Camera

1 Copyright information •Camera specifications or contents of this manual may be changed without prior notice due to upgrade of camera functions. •You are not allowed to reuse or distribute any part of this manual without prior permission. •We recommend using your camera within the country where you purchase it. •Use this camera responsibly and adhere to all laws and regulations concerning its use. PlanetFirst represents Samsung Electronics' commitment to sustainable development and social responsibility through eco-driven business and management activities. •Microsoft Windows and the Windows logo are registered trademarks of the Microsoft Corporation. •Mac and Apple App Store are registered trademarks of the Apple Corporation. •Google Play Store is a registered trademark of Google, Inc. •Adobe, the Adobe logo, Photoshop and Lightroom are either registered trademarks or trademarks of Adobe Systems Incorporated in the United Stat es and/or other countries. •microSD™, microSDHC™, and microSDXC™ are registered trademarks of the SD Association. •HDMI, the HDMI logo, and the term "High Definition Multimedia I nterface" ar e trademarks or registered trademarks of HDMI Lic ensing LLC. •Wi-Fi®, the Wi-Fi CERTIFIED logo, and the Wi-Fi logo are registered trademarks of the Wi-Fi Alliance. •Trademarks and trade names used in this manual are the property of their respective owners. 2 Health and safety information Prevent damage to subjects’ eyesight. Do not use the flash in close proximity (closer than 1 m/3 ft) to people or animals. If you use the flash too close to your subject’s eyes, this can cause temporary or permanent eyesight damage. Keep your camera away from small children and pets. Keep your camera and all accessories out of the reach of small children and animals. Small parts may cause choking or serious injury if swallowed. Moving parts and accessories may present physical dangers as well. Do not expose the camera to direct sunlight or high temperatures for an extended period of time. Prolonged exposure to sunlight or extreme temperatures can cause permanent damage to your camera’s internal components. Avoid covering the camera or charger with blankets or clothes. The camera may overheat, which may distort the camera or cause a fire. Do not handle the power supply cord or the charger during a thunderstorm. This may result in an electric shock. Always comply with the following precautions and usage tips to avoid dangerous situations and ensure peak performance of your camera. Warning—situations that could cause injury to yourself or others Do not disassemble or attempt to repair your camera. You can damage the camera and expose yourself to the risk of an electric shock. Do not use your camera near flammable or explosive gases and liquids. This may cause a fire or explosion. Do not insert flammable materials into the camera or store these materials near the camera. This may cause a fire or electric shock. Do not handle your camera with wet hands. This may result in an electric shock. 3 Health and safety information If liquid or foreign objects enter your camera, immediately disconnect all power sources, such as the battery or charger, and then contact a Samsung service center. Comply with any regulations that restrict the use of a camera in a certain area. • Avoid interference with other electronic devices. • Turn off the camera when in an aircraft. Your camera can cause interference with aircraft equipment. Follow all airline regulations and turn off your camera when directed by airline personnel. • Turn off the camera near medical equipment. Your camera can interfere with medical equipment in hospitals or health care facilities. Follow all regulations, posted warnings, and directions from medical personnel. Avoid interference with pacemakers. Maintain a safe distance between this camera and all pacemakers to avoid potential interference, as recommended by the manufacturer and research groups. If you have any reason to suspect that your camera is interfering with a pacemaker or other medical device, turn off the camera immediately and contact the manufacturer of the pacemaker or medical device for guidance. Caution—situations that could cause damage to your camera or other equipment Remove the batteries from your camera when storing it for an extended period of time. Installed batteries may leak or corrode over time and cause serious damage to your camera. Use only authentic, manufacturer-recommended, Lithium-ion replacement batteries. Do not damage or heat the battery. Inauthentic, damaged, or heated batteries may cause a fire or personal injury. Use only Samsung-approved batteries, chargers, cables, and accessories. • Using unauthorized batteries, chargers, cables, or accessories can cause batteries to explode, damage your camera, or cause injury. • Samsung is not responsible for damage or injuries caused by unapproved batteries, chargers, cables, or accessories. Use the battery only for its intended purpose. Misusing the battery may cause a fire or electric shock. 4 Health and safety information Do not touch the flash while it fires. The flash is very hot when fired and may burn your skin. When you use the AC charger, turn off the camera before you disconnect the power to the AC charger. Failing to do so may result in fire or electric shock. Disconnect the charger from the wall socket when not in use. Failing to do so may result in fire or electric shock. Do not use a damaged power supply cord, plug, or loose outlet when you charge batteries. This may cause a fire or electric shock. Do not allow the AC charger to come in contact with the +/- terminals on the battery. This may cause a fire or electric shock. Do not drop or subject the camera to strong impacts. Doing so may damage the screen or external or internal components. Exercise caution when you connect cables and install batteries and memory cards. If you force the connectors, improperly connect cables, or improperly install bat…

Text truncated - open the document above for the full version.

Date: January 10th, 2014 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Lab Manager Charles. Kim (or Feel. Jeong) and of SGS Korea Co., Ltd and hereafter referred to as SGS Korea, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Lab Manager Charles. Kim (or Feel. Jeong) of SGS Korea Co., Ltd on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing SGS Korea as our agent, we still recognize that we are responsible to: a)comply with the relevant provisions of t he certification program; b)make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, in spection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which cert ification has been granted; d)do not use our product certification in such a manner as to bring the Certification Di vision into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or un authorized; e)upon suspension or cancellation of certification, discontinue use of all advertising m atter that contains any reference thereto and return any certification docume nts as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified st andards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a m isleading ma nner; h)ensure that any reference to our product certification in communication media such as docum ents, brochures or advertising, complies with the requirements of th e Certification Division ; i)kee p a record of all complaints made known to the us relating to the pro duct’s com pliance with requirements of the relevant standard and to make these record s avai lable to the Certification Division wh en requested; j)take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certific ation; k)do cument the acti ons taken. Th is authorization is valid until further written notice from the applicant. Sincerely Yours, Sang Kyu ng (Peter) Ra / General Manager Samsung Electronics Co., Ltd.

Date: January 10th, 2014 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 2 1046 RE: Request of Confidentiality for FCC ID: A3LEVNXF1 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Samsung Electronics Co., Ltd. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give Samsung Electronics Co., Ltd temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: CONFIDENTIALLIST 1Block Diagram 2Operational Descriptions Permanent 3Schematics 4External Photos 5Internal Photos 6Test-Setup Photos Short-Term 7User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely Yours, Sang Ky ung (Peter) Ra / General Manager Samsung Electronics Co., Ltd.

External photos of EUT Front view of EUT Rear view of EUT Side view of EUT

FCC/IC Label 1.(1) FCC Label Drawing (2) FCC Label Location WB350F 2.(1) IC Label Drawing (2) IC Label Location Model: EV-NXF1

Model :EV-NXF1 External photos of EUT Model :EV-NXF1 Top view of EUT Model :EV-NXF1 Top view of PCB Bottom view of PCB Model :EV-NXF1 Antenna NFC Tag

Report File No. : F690501/RF-SAR002045-A1 Date of Issue : 2014-01-13 Page : 1 / 53 éééé SAR TEST REPORT Equipment Under Test : Digital Camera Model No. : EV-NXF1 Applicant : Samsung Electronics Co., Ltd. Address of Applicant : 129, Samsung-ro, Yeongtong-gu Suwon-si, Gyeonggi-do, 443-742 Korea, Republic of FCC ID : A3LEVNXF1 IC ID 649E-EVNXF1 Device Category : Portable Device Exposure Category : General Population /Uncontrolled Exposure Date of Receipt : 2013-12-28 Date of Test(s) : 2014-01-09 Date of Issue : 2014-01-13 Standards: FCC 47 CFR Part 2 (2.1093) IEEE 1528, 2003 ANSI/IEEE C95.1, C95.3 In the configuration tested, the EUT complied with the standards specified above. Remarks: Te s t e d b y : Jongwon Ma 2014-01-13 Approved by : Nicky You 2014-01-13 This report details the results of the testing carried out on one sample, the results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS Testing Korea Co., Ltd. or testing done by SGS Testing Korea Co., Ltd. in connection with distribution or use of the product described in this report must be approved by SGS Testing Korea Co., Ltd. in writing. Report File No. : F690501/RF-SAR002045-A1 Date of Issue : 2014-01-13 Page : 2 / 53 éééé Contents 1. General Information 1.1 Testing Laboratory........................................................................................... 3 1.2 Details of Applicant.......................................................................................... 3 1.3 Version of Report............................................................................................. 3 1.4 Description of EUT(s)....................................................................................... 3 1.5 Nominal and Maximum Output Power Specifications................................................... 4 1.6 Test Environment............................................................................................. 4 1.7 Operation description........................................................................................ 4 1.8 SAR Measurement Procedures.............................................................................. 6 1.9 The SAR Measurement System............................................................................ 6 1.10 System Components.......................................................................................... 8 1.11 SAR System Verification.................................................................................... 9 1.12 Tissue Simulant Fluid for the Frequency Band.......................................................... 11 1.13 Test System Validation...................................................................................... 12 1.14 Test Standards and Limits................................................................................. 12 2. Instruments List.................................................................................... 14 3. Summary of Results................................................................................ 15 3.1 FCC Power Measurement Procedures............................................................... 15 3.2 Measured and Reported SAR...........................................................................15 3.3 RF Conducted Power.................................................................................... 15 3.4 Test Configuration.........................................................................................17 3.5 SAR Data Summary.......................................................................................18 APPENDIX A. DASY5 SAR Report B. Uncertainty Analysis C. Calibration certificate Report File No. : F690501/RF-SAR002045-A1 Date of Issue : 2014-01-13 Page : 3 / 53 éééé 1. General Information 1.1 Testing Laboratory SGS Korea Co., Ltd. Wireless Div. 2FL, 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, 435-040 Republic of Korea Telephone : +82 +31 428 5700 FAX : +82 +31 427 2371 Homepage : All SGS services are rendered in accordance with the applicable SGS conditions of service available on request and accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx 1.2 Details of Applicant Manufacturer : Samsung Electronics Co., Ltd. Address : 129, Samsung-ro, Yeongtong-gu, Suwon-city, Gyeonggi-do, 443-742 Korea, Republic of Contact Person : Samsung Electronics Co., Ltd. Phone No. : +82 +31 277 6797 E-mail : [email protected] 1.3 Version of Report Version Number Date Revision 00 2014-01-09 Initial issue 01 2014-01-13 Revision 01 1.4 Description of EUT(s) EUT Type : Digital Camera Model : EV-NXF1 Serial Number : NXF1PV1-220R H/W Version : PV1 2013.12.03 S/W Version : 1226 Mode of Operation : WLAN Body worn Accessory : None Tx Frequency Range : 2412 ~ 2462 (WLAN) Max. Conducted RF Power : 13.41 m (WLAN) Battery Type : DC 3.8 V (Li-ion Battery) Equipment Class Band & Mode Measured Conducted Power [dBm] Reported SAR 1g Body-Worn (W/kg) DTS WLAN 13.41 0.575 Simultaneous SAR per KDB 690783 D01v01r02 N/A Report File No. : F690501/RF-SAR002045-A1 Date of Issue : 2014-01-13 Page : 4 / 53 éééé 1.5 Nominal and Maximum Output Power Specifications This device operates using the following maximum and nominal output power specifications. SAR values were scaled to the maximum allowed power to determine compliance per KDB Publication 44798 D01v05. Average power for Production Mode Nominal & Maximum a b g n WLAN Maximum 14.0 11.0 11.0 Nominal 12.5 10.5 10.5 1.6 Test Environment Ambient temperature : (22 2) ° C Tissue Simulating Liquid : (22 2) ° C Relative Humidity : (55 5) …

Text truncated - open the document above for the full version.

Report Number:F690501/RF-RTL007295 Page:2of64 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGSKoreaCo.,Ltd.(GunpoLaboratory) 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-040www.ee.sgs.com/korea RTT5041-20(2013.07.27)(1) Tel. +82 31 428 5700 / Fax. +82 31 427 2371 A4(210mmx297mm) INDEX Table of contents 1. General information --------------------------------------------------------------------------------------3 2. Transmitter radiated spurious emissions and conducted spurious emission --------------6 3. 6㏈bandwidth and 99% bandwidth ----------------------------------------------------------------32 4. Maximum peak output power --------------------------------------------------------------------------46 5. Power Spectral Density ---------------------------------------------------------------------------------51 6. Transmitter AC Power Line Conducted Emission-------------------------------------------------59 7. Antenna Requirement -----------------------------------------------------------------------------------64 Report Number:F690501/RF-RTL007295 Page:3of64 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGSKoreaCo.,Ltd.(GunpoLaboratory) 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-040www.ee.sgs.com/korea RTT5041-20(2013.07.27)(1) Tel. +82 31 428 5700 / Fax. +82 31 427 2371 A4(210mmx297mm) 1. General Information 1.1. Testing Laboratory SGS Korea Co., Ltd. (Gunpo Laboratory). - Wireless Div. 3FL, 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea 435-040 (Lab) - Wireless Div. 1FL, 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea 435-040 (Chamber) All SGS services are rendered in accordance with the applicable SGS conditions of service available on request and accessible athttp://www.sgs.com/en/Terms-and-Conditions.aspx. Phone No.:+82 31 428 5700 Fax No.:+82 31 427 2371 1.2. Details of Applicant Applicant:SAMSUNG ELECTRONICS Co., Ltd. Address:129, Samsung-ro, Yeongtong-gu Suwon-si, Gyeonggi-do, 443-742 Korea, Republic of Contact Person:Park, Ta-ri Phone No.:+82 31 277 6797 1.3. Description of EUT Kind of Product Digital Camera Model Name EV-NXF1 Power Supply DC 3.8 V Frequency Range 2 412㎒~ 2 462㎒(11b/g/n_HT20) Modulation Technique DSSS, OFDM Number of Channels 11 channel (11b/g/n_HT20) Antenna Type Internal type (SISO) Antenna Gain 2 412㎒~ 2 462㎒: 0.4㏈i H/W version PV1 2013.12.03 S/W version 1226 1.4. Declaration by the manufacturer - Duty Cycle ≥ 98 percent. Report Number:F690501/RF-RTL007295 Page:4of64 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGSKoreaCo.,Ltd.(GunpoLaboratory) 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-040www.ee.sgs.com/korea RTT5041-20(2013.07.27)(1) Tel. +82 31 428 5700 / Fax. +82 31 427 2371 A4(210mmx297mm) 1.5. Test Equipment List EquipmentManufacturerModelS/NCal Date Cal Interval Cal Due. Signal GeneratorR&S SMR40100272 Aug. 10, 2013AnnualAug. 10, 2014 Signal GeneratorR&SSMBV100A255834Jun. 26, 2013AnnualJun. 26, 2014 Spectrum AnalyzerAgilentN9030AUS51350132Oct. 08, 2013AnnualOct. 08, 2014 AttenuatorAEROFLEX / INMET18N-20dB 2 Apr. 01, 2013AnnualApr. 01, 2014 High Pass FilterWainwrightWHK3.0/18G-10SS 344Jun. 08, 2013 Annual Jun. 08, 2014 High Pass FilterWainwrightWHK7.5/26.5G-6SS11 Jun. 08, 2013 Annual Jun. 08, 2014 Low Pass FilterMini circuitsNLP-1200+V8979400903-2 Mar. 30, 2013 Annual Mar. 30, 2014 Power MeterAnritsu ML2495A1223004 Jun. 13, 2013 Annual Jun. 13, 2014 Power SensorAnritsu MA2411B1207272 Jun. 13, 2013 Annual Jun. 13, 2014 DC Power SupplyAgilentU8002AMY49030063Dec. 12, 2013AnnualDec. 12, 2014 Preamplifier H.P. 8447F2944A03909Jun. 28, 2013AnnualJun. 28, 2014 PreamplifierR&SSCU 1810117Jan. 14, 2013 Annual Jan. 14, 2014 PreamplifierMITEQ Inc.JS44-18004000-35-8P1546891Jun. 13, 2013 Annual Jun. 13, 2014 Test ReceiverR&SESU26100109Feb. 28, 2013 Annual Feb. 28, 2014 Bilog Antenna SCHWARZBECK MESSELEKTRONIK VULB9163396Jun. 07, 2013BiennialJun. 07, 2015 Loop AntennaR&SHFH2-Z2100118Jul. 12, 2013BiennialJul. 12, 2015 Horn AntennaR&SHF906 100326Nov. 01, 2013BiennialNov. 01, 2015 Horn Antenna SCHWARZBECK MESSELEKTRONIK BBHA9170BBHA9170431May 15, 2012BiennialMay 15, 2014 Antenna MasterINNCOMM4000 N/AN.C.R.N/AN.C.R. Turn TableINNCODS 1200S N/AN.C.R.N/AN.C.R. Anechoic ChamberSY Corporation L × W × H (6.5 m × 3.5 m × 3.5 m) N/AN.C.R.N/AN.C.R. EMI Test ReceiverR&SESHSI0863365/018Jun. 27, 2013AnnualJun. 27, 2014 Two-Line V-NetworkR&SENV216100190Jan. 02, 2014AnnualJan. 02, 2015 Anechoic ChamberSY Corporation L × W × H (9.6 m × 6.4 m × 6.4 m) N/AN.C.R.N/AN.C.R. ▶Support equipment DescriptionManufacturerModelSerial Number N/A--- Report Number:F690501/RF-RTL007295 Page:5of64 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGSKoreaCo.,Ltd.(GunpoLaboratory) 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-040www.ee.sgs.com/korea RTT5041-20(2013.07.27)(1) Tel. +82 31 428 5700 / Fax. +82 31 427 2371 A4(210mmx297mm) 1.6. Summary of Test Results The EUT has been tested according to the following specifications: APPLIED STANDARD:FCC Part15 subpart C, RSS-210, RSS-Gen Standard sectionTest ItemResult 15.205(a) 15.209 15.247(d) RSS-210 A8.5 Transmitter Radiated Spurious Emissions Conducted Spurious Emission Complied 15.247(a)(2)RSS-210 A8.2(a)6 dB Bandwidth and 99% BandwidthComplied 15.247(b)(3)RSS-210 A8.4(4)Maximum Peak Output PowerComplied 15.247(e)RSS-210 A8.3(2)Power Spectral DensityComplied 15.207 RSS-Gen 7.2.4 Transmitter AC Power L…

Text truncated - open the document above for the full version.

Test setup photos of EUT A. The photo of Radiated Emission(WLAN) B. Transmitter AC Power Line Conducted Emission(WLAN)

Test Setup Photographs Front Rear Right Edge Left Edge To p Bottom EUT Photo Front Back Right Edge Left Edge To p Bottom Battery
