A3LGTC3350Cellular/PCS GSM Phone with Bluetooth

User manual GT-C3350 Draft 1 2011-09-19 Only for Marketing using this manual This user manual has been specially designed to guide you through the functions and features of your mobile phone. Instructional icons Before you start, familiarise yourself with the icons you will see in this manual: Warning—situations that could cause injury to yourself or others Caution—situations that could cause damage to your phone or other equipment Note—notes, usage tips, or additional information Refer to—pages with related information; for example: p. 12 (represents “see page 12”) Õ Followed by—the order of options or menus you must select to perform a step; for example: In Menu mode, select Messages Õ Create new message (represents Messages, followed by Create new message) [ ] Square brackets—phone keys; for example: [ ](represents the Power/ Menu exit key) < > Angled brackets—softkeys that control different functions at each screen; for example: <OK> (represents the OK softkey) Copyright information Rights to all technologies and products that comprise this device are the property of their respective owners:  Bluetooth ® is a registered trademark of the Bluetooth SIG, Inc. worldwide  Java™ is a trademark of Sun Microsystems, Inc.  Windows Media Player ® is a registered trademark of Microsoft Corporation. contents safety and usage information Safety warnings Safety precautions Important usage information introducing your mobile phone Unpack .. Phone layout Keys Display Icons assembling and preparing your mobile phone Install the SIM card and battery Charge the battery using basic functions Turn your phone on and off Access menus Customise your phone Use basic call functions Send and view messages Add and find contacts troubleshooting safety and usage information Comply with the following precautions to avoid dangerous or illegal situations and ensure peak performance of your mobile phone. Safety warnings Keep your phone away from small children and pets Keep your phone and all accessories out of the reach of small children or animals. Small parts may cause choking or serious injury if swallowed. Protect your hearing Excessive exposure to sound at high volumes can cause hearing damage. Always turn the volume down before plugging the earphones into an audio source and use only the minimum volume setting necessary to hear your conversation or music. Install mobile phones and equipment with caution Ensure that any mobile phones or related equipment installed in your vehicle are securely mounted. Avoid placing your phone and accessories near or in an air bag deployment area. Improperly installed wireless equipment can cause serious injury when air bags inflate rapidly. Handle and dispose of batteries and chargers with care  Use only Samsung-approved batteries and chargers specifically designed for your phone. Incompatible batteries and chargers can cause serious injuries or damage to your phone.  Never dispose of batteries or phones in a fire. Follow all local regulations when disposing used batteries or phones.  Never place batteries or phones on or in heating devices, such as microwave ovens, stoves, or radiators. Batteries may explode when overheated.  Never crush or puncture the battery. Avoid exposing the battery to high external pressure, which can lead to an internal short circuit and overheating. Avoid interference with pacemakers Maintain a minimum of 15 cm (6 inches) between mobile phones and pacemakers to avoid potential interference, as recommended by manufacturers and the independent research group, Wireless Technology Research. If you have any reason to suspect that your phone is interfering with a pacemaker or other medical device, turn off the phone immediately and contact the manufacturer of the pacemaker or medical device for guidance. Turn off the phone in potentially explosive environments Do not use your phone at refuelling points (service stations) or near fuels or chemicals. Turn off your phone whenever directed by warning signs or instructions. Your phone could cause explosions or fire in and around fuel or chemical storage and transfer areas or blasting areas. Do not store or carry flammable liquids, gases, or explosive materials in the same compartment as the phone, its parts, or accessories. Reduce the risk of repetitive motion injuries When sending text messages or playing games on your phone, hold the phone with a relaxed grip, press the keys lightly, use special features that reduce the number of keys you have to press (such as templates and predictive text), and take frequent breaks. Safety precautions Drive safely at all times Avoid using your phone while driving and obey all regulations that restrict the use of mobile phones while driving. Use hands-free accessories to increase your safety when possible. Follow all safety warnings and regulations Comply with any regulations that restrict the use of a mobile phone in a certain area. Use only Samsung-approved accessories Using incompatible accessories may damage your phone or cause injury. Turn off the phone near medical equipment Your phone can interfere with medical equipment in hospitals or health care facilities. Follow all regulations, posted warnings, and directions from medical personnel. Turn off the phone or disable the wireless functions when in an aircraft Your phone can cause interference with aircraft equipment. Follow all airline regulations and turn off your phone or switch to a mode that disables the wireless functions when directed by airline personnel. Protect batteries and chargers from damage Avoid exposing batteries to very cold or very hot temperatures (below 0° C/32° F or above 45° C/ 113° F). Extreme temperatures can reduce the charging capacity and life of your batteries. Prevent batteries from contacting metal objects, as this can create a connection between the + and - terminals of your batteries and lead to temporary or permanent battery damage. Never use a damaged charger or battery. Handle…

Text truncated - open the document above for the full version.

SAMSUNG ELECTRONICS AMERICA, INC. American QA Lab 18600 Broadwick St. Rancho Dominguez, CA 90220 Date: September 28, 2011 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: A3LGTC3350 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, SAMSUNG ELECTRONICS CO.,LTD. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give SAMSUNG ELECTRONICS CO.,LTD. temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram PERMANENT 2 Operational Description 3 External Photos 4 Internal Photos 5 Test-Setup Photos SHORT-TERM 6 Users Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Peter Ra General Manager American QA Lab SAMSUNG Electronics America INC.

SAMSUNG ELECTRONICS CO., LTD 416,Maetan-3dong,Yeongtong-gu Suwon-si,Gyeonggi-do, 443-742 Korea Federal Communicat ions Commission 7435 Oakland Mills Road Colum bia, MD 21046 SUBJECT : Label Statement FCC ID : A3L Gentlemen: We hereby provide the label statement letter for the above-mentioned phone by a new label statement policy instituted at the September 12, 2006, TCB-FCC Teleconference. The label statement is as follows: The FCC ID shown in the FCC ID label page will be readily visible at the time of purchase because the phone will be marketed without the battery installed. This statement could not be included in the label. So we inform you of it through this letter. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely Yours, Seoung Ho Park Senior Manager SAMSUNG ELECTRONICS CO.,LTD Telecommunication Network Business Mobile Communication Division Regulatory Compliance Group.

110905 Changing size of label cutter guide September 5 110905 110905 LABEL-MAIN GT-C3350 (Europe common) GH68-00000A WHITE POLYPROPYLENE 80 Lee Jae JinJo Kyeong HwanKim June Sop Technical Description 1. Use ‘AI / PDF’ provided by ‘SAMSUNG’ for letter and contents 2. Background color is ‘WHITE’, letter color is ‘BLACK’ (reverse for SAMSUNG LOGO) 3. Back side should be attached to release paper once adhesive is applied. 4. No letter should be blur/smeared 5. The production must be proceed after the approval of R&D Group 6. The product must be within approved sample's specification tolerance. 7. The product must be finished in a ROLL 8. Release paper must be unifiedn for material and color(blue) 9. Do not contain any substances which are specified in (OQA-2049). Vendor HSINS MODEL : GT-C3350 RATED : 3.7 V 1300 mA SSN : -C3350GSMH FCC ID : A3LGTC3350 MADE IN KOREA BY SAMSUNG ; The label is placed inside the battery compartment MODEL : GT-C3350 RATED : 3.7 V 1300 mA SSN : -C3350GSMH FCC ID : A3LGTC3350 MADE IN KOREA BY SAMSUNG ;

-1/12- E E E M M M C C C T T T E E E S S S T T T R R R E E E P P P O O O R R R T T T Project No. LBE20114706 Issue No. 1 Applicant Name of organization Samsung Electronics Co., Ltd. Address 416, Maetan 3-dong, Yeongtong-gu, Suwon-si, Gyeonggi-do, 443-742, Republic of Korea Date of application September 20, 2011 EUT Type of device Class B personal computers and peripherals Equipment authorization Declaration of Conformity Certification Verification FCC ID A3LGTC3350 Kind of product Mobile Phone Model No. GT-C3350 Variant Model No. Refer to clause 3.5 Manufacturer SAMSUNG ELECTRONICS CO., LTD. 94-1, Imsu-dong, Gumi-si, Gyengsangbuk-do, 730-722, Republic of Korea TIANJIN SAMSUNG TELECOM TECHNOLOGY CO., LTD. 300385 China Tianjin No.9, WeiWu Rd., Micro Electronic Industrial Park, Xiqing Dist, Tianjin, China Applied Standards FCC Part 15, Subpart B, Class B / ANSI C63.4-2003 Test Period September 22, 2011 ~ September 23, 2011 Issue date September 26, 2011 Test result : Complied The equipment under test has found to be compliant with the applied standards. (Refer to the attached test result for more detail.) Tested by : Jong-Sup Jeong Reviewed by : Tae-Young Jang The test results in this report only apply to the tested sample. This report must not be reproduced, except in full, without written permission from CS & Environment center. 416, Maetan 3-dong, Yeongtong-gu, Suwon-si, Gyeonggi-so, 443-742, Republic of Korea Tel: 82 31 279 1750, Fax: 82 31 279 1745 Project No. : LBE20114706 Mobile Phone : GT-C3350 -2/12- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-20/0 Table of contents 1. Summary of test results 1.1 Emission 2. General Information 2.1 Test facility 3. Test configuration 3.1 Test Peripherals 3.2 EUT operating mode 3.3 Details of Sampling 3.4 Used cable description 3.5 EUT Description 3.6 Clock Frequencies 3.7 Test configuration and condition 3.8 Measurement uncertainty 4. Result of individual tests 4.1 Conducted disturbance 4.2 Radiated disturbance Project No. : LBE20114706 Mobile Phone : GT-C3350 -3/12- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-20/0 1. Summary of test results 1.1 Emission The EUT has been tested according to the following specifications: Applied Test type Applied standard Result Remarks Conducted Disturbance (Mains port) FCC Part 15 Subpart B / ANSI C63.4-2003 Complied Meets Class B Limit Radiated Disturbance Complied Meets Class B Limit 2. General Information 2.1 Test facility The CS & Environment center is located on Samsung Electronics Co., Ltd. at 416, Maetan 3-dong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Republic of Korea. All testing are performed in Semi-anechoic chambers conforming to the site attenuation Characteristics defined by ANSI C63.4, CISPR 22, 16-1 and 16-2. and Shielded rooms. The CS & Environment center is operated as testing laboratory in accordance with the requirements of ISO/IEC 17025:2005. 3. Test Setup configuration 3.1 Test Peripherals The cables used for these peripherals are either permanently attached by the peripheral manufacturer or coupled with an assigned cable as defined below. The following is a listing of the EUT and peripherals utilized during the performance of EMC test: Description Model No. Serial No. Manufacturer/ Trademark FCC ID / DoC Mobile Phone GT-C3350 R2FB854601L SAMSUNG A3LGTC3350 Battery AB803443BU THaB891AS/4-B SAMSUNG - Headset EHS41UMAME - SAMSUNG - Data Cable ECC1DU0BBK - SAMSUNG - microSD Card 2GB - SANDISK - Note PC NT-P530 - SAMSUNG DoC AC Adapter AD-6019 CNBA4400162ABJ6F65 51560 SAMSUNG - USB mouse MOARUO MS-S5-AR03-01 SAMSUNG DoC USB Keyboard GP-K5000U 15000099 SAMSUNG DoC Project No. : LBE20114706 Mobile Phone : GT-C3350 -4/12- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-20/0 3.2 EUT operating mode To achieve compliance applied standard specification, the following mode(s) were made during compliance testing: Operating Mode 1 USB Mode (Data Communication) 3.3 Details of Sampling Customer selected, single unit. 3.4 Used cable description The EUT is configured, installed, arranged and operated in a manner consistent with typical applications. Interface cables/loads/devices are connected to at least one of each type of interface port of the EUT, and where practical, each cable shall be terminated in a device typical of actual usage. The type(s) of interconnecting cables to be used and the interface port (of the EUT) to which these were connected; Connected cable Length [m] Shielded [Y/N] Note Data Cable 0.8 Yes From EUT to Note PC Headset 1.6 No For Headset Power 1.8 No For AC Adapter USB 1.8 Yes From Note PC to Mouse USB 1.5 Yes From Note PC to Keyboard Project No. : LBE20114706 Mobile Phone : GT-C3350 -5/12- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-20/0 3.5 EUT Description 1. The following features describe EUT represented by this report: Item Specification Frequency Range GSM850 TX : 824.2 ~ 848.8 MHz RX : 869.2 ~ 893.8 MHz GSM900 TX : 880.2 ~ 914.8 MHz RX : 925.2 ~ 959.8 MHz GSM1800 TX : 1 710.2 ~ 1 784.8 MHz RX : 1 805.2 ~ 1 879.8 MHz GSM1900 TX : 1 850.2 ~ 1 909.8 MHz RX : 1 930.2 ~ 1 989.8 MHz Size (Standard Battery) 122.3 (L) * 52.9 (W) * 17.9 (H) (mm) Weight (Standard Battery) 110 g (±1 g) LCD Specification Main 2.2 Inch, TFT (320 X 240) Operating Temperature (°C) -20 ~ +50 Operating Humidity (%) 0 ~ 95 Bluetooth TX/RX Frequency : 2 402 ~ 2 480 MHz Version : 3.0 Memory Internal Memory : 512 MB External Memory : microSD (Max. 16 GB) 2. The variant models - None 3.6 Clock Frequencies Kind of Clocks Frequency [ MHz ] CPU 208 USB 2.0 48 Project No. : LBE20114706 Mobile Phone : GT-C3350 -6/12- This report must not be reproduced, except in full, without written permission from CS …

Text truncated - open the document above for the full version.

Project No. : LBE20114706 Mobile Phone : GT-C3350 -1/7- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-20/0 APPENDIX – Test Setup and EUT photography – Project No. : LBE20114706 Mobile Phone : GT-C3350 -2/7- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-20/0 1. Photograph of Test Setup [ Conducted Disturbance – Front ] [ Conducted Disturbance – Rear ] Project No. : LBE20114706 Mobile Phone : GT-C3350 -3/7- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-20/0 [ Radiated Disturbance for Below 1 GHz – Front ] [ Radiated Disturbance for Below 1 GHz – Rear ] Project No. : LBE20114706 Mobile Phone : GT-C3350 -4/7- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-20/0 [ Radiated Disturbance for Above 1 GHz – Front ] [ Radiated Disturbance for Above 1 GHz – Rear ] Project No. : LBE20114706 Mobile Phone : GT-C3350 -5/7- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-20/0 2. EUT photography [ Front View ] [ Rear View ] Project No. : LBE20114706 Mobile Phone : GT-C3350 -6/7- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-20/0 [ Travel Adapter ] [ Headset ] Project No. : LBE20114706 Mobile Phone : GT-C3350 -7/7- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-20/0 [ Data Cable ] [ Label ]
