A3LGTE3210LCellular/PCS WCDMA/GSM Phone with Bluetooth

User manual GT-E3210L using this manual This user manual has been specially designed to guide you through the functions and features of your mobile phone. To get started quickly, refer to “introducing your mobile phone,” “assembling and preparing your mobile phone,” and “using basic functions.” Instructional icons Before you start, familiarise yourself with the icons you will see in this manual: Warning—situations that could cause injury to yourself or others Caution—situations that could cause damage to your phone or other equipment Note—notes, usage tips, or additional information  Refer to—pages with related information; for example:  p. 12 (represents “see page 12”) Õ Followed by—the order of options or menus you must select to perform a step; for example: In Menu mode, select Messages Õ Create new message (represents Messages, followed by Create new message) [ ] Square brackets—phone keys; for example: [] (represents the Power/ Menu exit key) Copyright information Rights to all technologies and products that comprise this device are the property of their respective owners:  Bluetooth ® is a registered trademark of the Bluetooth SIG, Inc. worldwide  Java™ is a trademark of Sun Microsystems, Inc.  Windows Media Player ® is a registered trademark of Microsoft Corporation. contents safety and usage information Safety warnings Safety precautions Important usage information introducing your mobile phone Unpack .. Phone layout Keys Display Icons assembling and preparing your mobile phone Install the SIM card and battery Charge the battery using basic functions Turn your phone on and off Access menus Customize your phone Use basic call functions Send and view messages Add and find contacts troubleshooting safety and usage information Comply with the following precautions to avoid dangerous or illegal situations and ensure peak performance of your mobile phone. Safety warnings Keep your phone away from small children and pets Keep your phone and all accessories out of the reach of small children or animals. Small parts may cause choking or serious injury if swallowed. Protect your hearing Excessive exposure to sound at high volumes can cause hearing damage. Always turn the volume down before plugging the earphones into an audio source and use only the minimum volume setting necessary to hear your conversation or music. Install mobile phones and equipment with caution Ensure that any mobile phones or related equipment installed in your vehicle are securely mounted. Avoid placing your phone and accessories near or in an air bag deployment area. Improperly installed wireless equipment can cause serious injury when air bags inflate rapidly. Handle and dispose of batteries and chargers with care  Use only Samsung-approved batteries and chargers specifically designed for your phone. Incompatible batteries and chargers can cause serious injuries or damage to your phone.  Never dispose of batteries or phones in a fire. Follow all local regulations when disposing used batteries or phones.  Never place batteries or phones on or in heating devices, such as microwave ovens, stoves, or radiators. Batteries may explode when overheated.  Never crush or puncture the battery. Avoid exposing the battery to high external pressure, which can lead to an internal short circuit and overheating. Avoid interference with pacemakers Maintain a minimum of 15 cm (6 inches) between mobile phones and pacemakers to avoid potential interference, as recommended by manufacturers and the independent research group, Wireless Technology Research. If you have any reason to suspect that your phone is interfering with a pacemaker or other medical device, turn off the phone immediately and contact the manufacturer of the pacemaker or medical device for guidance. Turn off the phone in potentially explosive environments Do not use your phone at refuelling points (service stations) or near fuels or chemicals. Turn off your phone whenever directed by warning signs or instructions. Your phone could cause explosions or fire in and around fuel or chemical storage and transfer areas or blasting areas. Do not store or carry flammable liquids, gases, or explosive materials in the same compartment as the phone, its parts, or accessories. Reduce the risk of repetitive motion injuries When sending text messages or playing games on your phone, hold the phone with a relaxed grip, press the keys lightly, use special features that reduce the number of keys you have to press (such as templates and predictive text), and take frequent breaks. Safety precautions Drive safely at all times Avoid using your phone while driving and obey all regulations that restrict the use of mobile phones while driving. Use hands-free accessories to increase your safety when possible. Follow all safety warnings and regulations Comply with any regulations that restrict the use of a mobile phone in a certain area. Use only Samsung-approved accessories Using incompatible accessories may damage your phone or cause injury. Turn off the phone near medical equipment Your phone can interfere with medical equipment in hospitals or health care facilities. Follow all regulations, posted warnings, and directions from medical personnel. Turn off the phone or disable the wireless functions when in an aircraft Your phone can cause interference with aircraft equipment. Follow all airline regulations and turn off your phone or switch to a mode that disables the wireless functions when directed by airline personnel. Protect batteries and chargers from damage Avoid exposing batteries to very cold or very hot temperatures (below 0° C/32° F or above 45° C/ 113° F). Extreme temperatures can reduce the charging capacity and life of your batteries. Prevent batteries from contacting metal objects, as this can create a connection between the + and - terminals of your batteries and lead to temporary or permanent battery damage. Never use a damaged charger or battery. Handle your phone care…

Text truncated - open the document above for the full version.

SAMSUNG ELECTRONICS AMERICA, INC. American QA Lab 18600 Broadwick St. Rancho Dominguez, CA 90220 Date: January 7, 2011 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, http Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: A3LGTE3210L To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, SAMSUNG ELECTRONICS CO.,LTD. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give SAMSUNG ELECTRONICS CO.,LTD. temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Operational Description 3 Schematics PERMANENT 4 Parts List & Tune-Up Procedure 5 External Photos 6 Internal Photos 7 Test-Setup Photos SHORT-TERM 8 Users Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Peter Ra General Manager American QA Lab SAMSUNG Electronics America INC.

From: DuckSu Kim Sent: Monday, January 10, 2011 2:36 AM To: PCTEST TCB/CB; 함재준; 전자메일 Cc: 장우태; 장왈운; 이준환; 권기중; PCTEST - Channy Park; PCTEST - Greg Czumak; PCTEST - Mia Park; PCTEST - Randy Ortanez; PCTEST - Steve Liu Subject: Re: Questions Regarding FCC ID: A3LGTE3210L Page 1 of 3 1/10/2011 Dear PCTEST TCB, Please find revised EMC and SAR reports. We'd appreciate it if you would FCC grants today. Best Regards, Ducksu Kim. ------- Original Message ------- Sender : PCTEST TCB/CB<[email protected]> [email protected] Date : 2011-01-08 11:45 (GMT+09:00) Title : Questions Regarding FCC ID: A3LGTE3210L To: Mr. Geoffrey Ham / Samsung Electronics Co., Ltd. From: Mr. Gregory Czumak / PCTEST TCB RE: FCC ID: A3LGTE3210L Applicant: Samsung Electronics Co., Ltd. Correspondence Reference Number: A3L101482 Confirmation Number: 1Y1012231482-84 Date of Original Email: January 7, 2011 Subject: Request for additional information In regards to your recent TCB application referenced above, we kindly request that you provide the following additional information. 1. Please confirm that, during radiated testing, the EUT was placed in 3 orthogonal planes in an effort to maximize emissions. If this is the case, both the GSM EMC and the WCDMA EMC reports should be revised to include this attestation. 2. Both the GSM EMC and WCDMA EMC reports describe the EUT as containing a WLAN (pp. 3, 14 and 27 in the GSM report and pp. 3, 15 and 29 in the WCDMA report). Nothing else in the application indicates this, and a DTS was not tested. Please revise the reports, removing the reference to the WLAN. 3. In the WCDMA EMC report, Section 5.4 states that a spectrum analyzer was used to measure PAR, but p. 53 shows that the CCDF was (correctly) used. Please revise Section 5.4 to describe the actual test procedure used. 4. SAR Table 7.2 lists the Normalized SAR levels as the “Measured” SAR levels. Please revise the column heading to “Normalized SAR”, and add a separate column for the actual measured SAR levels. 5. SAR data Table 8.2 (p. 26) lists power levels for 3TX and 4TX operation that are several dB higher than the levels listed in Power data Table 8.2 (p. 22)- please address. 6. Please modify the Notes on pp. 29-32 of the SAR report to specify the WCDMA mode used to generate the test data. 7. SAR data Table 8.7 lists the max SAR level as 0.953, but the corresponding SAR plot lists 0.935. Please address. The items indicated above must be submitted before processing can continue on the above referenced application. Sincerely, Gregory Czumak Senior Certification Engineer Quality Manager PCTEST Engineering Laboratory, Inc. Page 2 of 3 1/10/2011 6660-B Dobbin Road Columbia, MD 21045 410-290-6652 410-290-6654 (Fax) [email protected] This communication and its attachments contain information from PCTEST Engineering Laboratory, Inc., and is intended for the exclusive use of the recipient (s) named above. It may contain information that is confidential and/or legally privileged. Any unauthorized use that may compromise that confidentiality via distribution or disclosure is prohibited. Please notify the sender immediately if you receive this communication in error, and delete it from your computer system. Usage of PCTEST email addresses for non-business related activities is strictly prohibited. No warranty is made that the e-mail or attachment(s) are free from computer virus or other defect. Thank you. Page 3 of 3 1/10/2011

LABEL-MAIN Jo Kyeong HwanKim June Sop Technical Description 1. Use ‘AI / PDF’ provided by ‘SAMSUNG’ for letter and contents 2. Background color is ‘WHITE’, letter color is ‘BLACK’ (reverse for SAMSUNG LOGO) 3. Back side should be attached to release paper once adhesive is applied. 4. No letter should be blur/smeared 5. The production must be proceed after the approval of SAMSUNG R&D Group 6. The product must be within approved sample's specification tolerance. 7. The product must be finished in a ROLL 8. Release paper must be unifiedn for material and color(blue) 9. Do not contain any substances which are specified in (OQA-2049). Vendor < 1:1 Artwork > 101025101025101025 GT-E3210L(LATIN) Park Tae San HANSUNG OPP Laminating 16 Adhesive 8 WHITE POLYPROPYLENE 80 Adhesive 25 Semi transparency OPP laminating + UVP Coating (0.13T±0.01) MODELO:GT-E3210L FCC ID:A3LGTE3210L SSN:-E3210LGSMH ALIMENTACION:3,7 V ;800 mA PRODUCTO COREANO /KOREAN PRODUCT 5.0 30.0 6-R1.0 24.0 13.0 7.0 13.0 * 라벨 형상 및 사이즈 수정(101122) TELEFONO CELULAR /CELLULAR PHONE The label is placed inside the battery compartment MODELO:GT-E3210L FCC ID:A3LGTE3210L SSN:-E3210LGSMH ALIMENTACION:3,7 V ;800 mA PRODUCTO COREANO /KOREAN PRODUCT 5.0 TELEFONO CELULAR /CELLULAR PHONE

FCC ID: A3LGTE3210LReport Number: FH-280-S1 Page : 1 of 35 SAMSUNG Electronics C0. LTD EUT Type: Dual-Band GSM850/1900, GPRS850/1900 and Dual-Band WCDMA850/1900 Phone with Bluetooth Issue Date : Jan.05, 2011 SAMSUNG ELECTRONICS Co., Ltd., Regulatory Compliance Group IT R&D Center 416, Maetan-3dong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea 443-742 TEST REPORT ON SAR Model Tested: GT-E3210L FCC ID (Requested): A3LGTE3210L Job No: FH-280 Report No: FH-280-S1 - Abstract – This document reports on SAR Tests carried out in accordance with FCC/OET Bulletin 65, Supplement C(July 2001). Prepared By JR LEE - Test Engineer Authorized By JD JANG – Technical Manager FCC ID: A3LGTE3210LReport Number: FH-280-S1 Page : 2 of 35 SAMSUNG Electronics C0. LTD EUT Type: Dual-Band GSM850/1900, GPRS850/1900 and Dual-Band WCDMA850/1900 Phone with Bluetooth Issue Date : Jan.05, 2011 Contents 1. GENERAL INFORMATION .............................................................................. 3 2. DESCRIPTION OF DEVICE ............................................................................ 3 3. DESCRIPTION OF TEST EQUIPMENT .......................................................... 4 3.1 SAR Measurement Setup ............................................................................................................... 4 3.2 E-field Probe ................................................................................................................................... 5 3.3 Phantom .......................................................................................................................................... 7 3.4 Brain Simulating Mixture Characterization .................................................................................... 9 3.5 Device Holder for Transmitters ........................................................................................................ 9 3.6 Validation Dipole ........................................................................................................................... 10 3.7 Equipment Calibration ................................................................................................................... 11 4. SAR MEASUREMENT PROCEDURE ........................................................... 12 5. DESCRIPTION OF TEST POSITION ............................................................ 13 5.1 SAM Phantom Shape.................................................................................................................... 13 5.2 “cheek” Position ............................................................................................................................ 13 5.3 “tilted” Position .............................................................................................................................. 15 5.4 Body Holster/Belt Clip Configurations ........................................................................................... 16 6. MEASUREMENT UNCERTAINTY ................................................................. 18 7. SYSTEM VERIFICATION ............................................................................... 20 7.1 Tissue Verification ......................................................................................................................... 20 7.2 Test System Validation .................................................................................................................. 20 8. SAR MEASUREMENT RESULTS .................................................................. 21 8.1 GSM850 Head SAR Results ......................................................................................................... 25 8.2 GPRS850 Body SAR Results(Without Holster) ............................................................................. 26 8.3 GSM1900 Head SAR Results ....................................................................................................... 27 8.4 GPRS1900 Body SAR Results(Without Holster) ........................................................................... 28 8.5 WCDMA850 Head SAR Results ................................................................................................... 29 8.6 WCDMA850 Body SAR Results(Without Holster) ......................................................................... 30 8.7 WCDMA1900 Head SAR Results ................................................................................................. 31 8.8 WCDMA1900 Body SAR Results(Without Holster) ....................................................................... 32 9. CONCLUSION ............................................................................................... 33 10. REFERENCES ............................................................................................. 34 APPENDIX A SAR Definition ........................................................................... 36 APPENDIX B Probe Calibration Process ........................................................ 37 APPENDIX C ANSI/IEEE C95.1 – 1992 RF EXPOSURE LIMITS .................. 38 APPENDIX D The Validation Measurements .................................................. 39 APPENDIX E Plots of The SAR Measurements .............................................. 42 APPENDIX F Probe Calibration ...................................................................... 71 APPENDIX G Calibration of The Validation Dipole ......................................... 83 FCC ID: A3LGTE3210LReport Number: FH-280-S1 Page : 3 of 35 SAMSUNG Electronics C0. LTD EUT Type: Dual-Band GSM850/1900, GPRS850/1900 and Dual-Band WCDMA850/1900 Phone with Bluetooth Issue Date : Jan.05, 2011 1. GENERAL INFORMATION Test Dates : Dec.20, 2010 ~ Dec.22, 2010 Manufacturer : SAMSUNG ELECTRONICS Co., Ltd. Address : 416 Maetan3-Dong, Suwon City, Korea Test Standard : §2.1093; FCC/OET Bulletin 65, Supplement C(July 2001) FCC Classification : Licensed Portable Transmitter Held to Ear (PCE) Tested for : FCC/TCB …

Text truncated - open the document above for the full version.

SAMSUNG ELECTRONICS Co., Ltd., Regulatory Compliance Group IT R&D Center 416 Maetan3-Dong, Yeongtong-gu, Suwon city, Gyeonggi-Do, Korea 443-742 FCC CFR47 PART 22 & 24 SUBPART CERTIFICATION REPORT Model Tested : GT-E3210L FCC ID(Requested) : A3LGTE3210L Report No : FH-280-R1 Job No : FH-280 Date issued : December 27, 2010 - Abstract - All measurement reported herein accordance with FCC Rules, 47CFR Part2, Part22, Part24. Prepared By KJ KWON – Test Engineer Authorized By WT JANG – Technical Manager Report Number : FH-280-R1 2 of 58 TABLE OF CONTENT MEASUREMENT REPORT Page 1. FCC CERTIFICATION INFORMATION .....................................................................3 1.1. §2.1033 General Information .........................................................................3 2. INTRODUCTION .......................................................................................................4 2.1. General..........................................................................................................4 3. MEASURING INSTRUMENT CALIBRATION ...........................................................5 4. TEST EQUIPMENT LIST...........................................................................................6 5. DESCRIPTION OF TESTS ........................................................................................7 5.1. Effective Radiated Power / Equivalent Isotropic Radiated Power ..................7 5.2. Radiated Spurious & Harmonic Emission ......................................................8 5.3. Peak-Average Ratio .......................................................................................9 5.4. Occupied Bandwidth ....................................................................................10 5.5. Spurious and Harmonic Emission at Antenna Terminal................................10 5.5.1. Occupied Bandwidth Emission Limits ..............................................10 5.5.2. Conducted Spurious Emission .........................................................12 5.6. Frequency Stability / Temperature Variation .................................................13 6. TEST DATA .............................................................................................................14 6.1. Conducted Output Power.............................................................................14 6.2. Effective Radiated Power (E.R.P.)................................................................15 6.3. Equivalent Isotropic Radiated Power (E.I.R.P.) ............................................16 6.4. GSM850 Radiated Spurious & Harmonic measurement ..............................17 6.5. GSM1900 Radiated Spurious & Harmonic measurement ............................18 6.6. GSM850 Radiated Spurious & Harmonic Conversion Table ........................19 6.7. GSM1900 Radiated Spurious & Harmonic Conversion Table ......................20 6.8. Frequency Stability.......................................................................................21 6.8.1. GSM850 Frequency Stability Table ..................................................21 6.8.2. GSM850 Frequency Stability Graph.................................................22 6.8.3. GSM1900 Frequency Stability Table ................................................24 6.8.4. GSM1900 Frequency Stability Graph...............................................25 7. CONCLUSION.........................................................................................................27 8. TEST PLOTS...........................................................................................................28 Report Number : FH-280-R1 3 of 58 MEASUREMENT REPORT 1. FCC Certification Information The following information is in accordance with FCC Rules, 47CFR Part2, Subpart J, Sections 2.1033 – 2.1055. 1.1. §2.1033 General Information • Applicant Name : SAMSUNG ELECTRONICS CO., LTD. • Address : 416 Maetan3-Dong, Yeongtong-gu, Suwon City Gyeonggi-Do, Korea 443-742 • FCC ID : A3LGTE3210L • Model : GT-E3210L • Quantity : Quantity production is planned • Emission Designators : 254KGXW(GSM850) 249KGXW(GSM1900) • Tx Freq. Range : 824.2 - 848.8MHz (GSM850) 1850.2MHz - 1909.8MHz (GSM1900) • Rx Freq. Range : 869.2 - 893.8 MHz (GSM850) 1930.2MHz - 1989.8MHz (GSM1900) • Max. Power Rating : 0.678 W ERP GSM850 (28.31 dBm) 0.687 W EIRP GSM1900 (28.37 dBm) • FCC Classification(s) : PCS Licensed Portable Tx Held to Ear (PCE) • Equipment (EUT) Type : 850/1900 GSM/GPRS/WCDMA Phone with Bluetooth and EDGE Rx Only • Frequency Tolerance : ±0.00025% (2.5ppm) • FCC Rule Part(s) : §24(E), §22(H), §2. • Dates of Test : December 15-16, 2010 • Place of Test : SAMSUNG Lab, • Test Report S/N : FH-280-R1 Report Number : FH-280-R1 4 of 58 2. INTRODUCTION 2.1. General These measurement test were conducted at SAMSUNG ELECTRONICS CO., LTD(SUWON). The site address is 416 Maetan3-Dong, Yeongtong-gu, Suwon City, Gyeonggi-Do, Korea 443-742 The site have 1 Fully-anechoic chamber and measurement facility. Measurement Procedure The radiated and spurious measurements were made Fully-anechoic chamber at a 3-meter test range (see Figure2). The equipment under testing was placed on a Non-conducted turntable 3- meters from the receive antenna. The receive antenna height and turntable rotations were adjusted for the highest reading on the receive spectrum analyzer. The substitution antenna will replace the EUT antenna it the same position and in vertical polarization. The frequency of the signal generator shall be set to the frequencies that were measured on the EUT. The test antenna shall be raised and lowered, if necessary, to ensure that the maximum signal is still being received. The signal generator, output level, shall be adjusted until an equal or a known related level to what was measured from the EUT is obtained in the spectrum analyzer. This level was recorded. For readings above 1 GHz, the above procedure is repeated using horn antennas and the difference b…

Text truncated - open the document above for the full version.

Report Number : FH-280-R2 1 of 53 SAMSUNG ELECTRONICS Co., Ltd., Regulatory Compliance Group IT R&D Center 416 Maetan3-Dong, Yeongtong-gu, Suwon city, Gyeonggi-Do, Korea 443-742 FCC CFR47 PART 22 & 24 SUBPART CERTIFICATION REPORT Model Tested: GT-E3210L FCC ID (Requested): A3LGTE3210L Report No: FH-280-R2 Job No: FH-280 Date issued: December 27, 2010 - Abstract – All measurement reported here in accordance with FCC Rules, 47CFR Part2, Part22, Part24 Prepared By KJ KWON – Test Engineer Authorized By WT JANG – Technical Manager © Copyright SAMSUNG Electronics 2010 Report Number : FH-280-R2 2 of 53 TABLE OF CONTENT MEASUREMENT REPORT Page 1. FCC Certification Information .......................................................................................3 1.1 §2.1033 General Information ...................................................................................3 2. INTRODUCTION .............................................................................................................4 2.1 General ....................................................................................................................4 3. MEASURING INSTRUMENT CALIBRATION .................................................................5 4. TEST EQUIPMENT LIST.................................................................................................6 5. FCC 3G MEASUREMENT PROCEDURES ....................................................................7 5.1 Effective Radiated Power / Equivalent Isotropic Radiated Power ............................8 5.2 Radiated Spurious & Harmonic Emission ................................................................9 5.3 Occupied Bandwidth .............................................................................................. 11 5.4Peak-Average Radio ............................................................................................... 11 5.5 Spurious and Harmonic Emissions at Antenna Terminal ........................................ 11 5.5.1 Occupied Bandwidth Emission Limits ........................................................... 11 5.5.2 Conducted Spurious Emission ......................................................................13 5.6 Frequency Stability / Temperature Variation...........................................................14 6. TEST DATA ...................................................................................................................15 6.1 Conducted Output Power.......................................................................................15 6.2 Effective Radiated Power(E.R.P.) ..........................................................................16 6.3 Equivalent Isotropic Radiated Power(E.I.R.P.) .......................................................17 6.4 Cellular WCDMA Radiated Spurious & Harmonic measurement ...........................18 6.5 PCS WCDMA Radiated Spurious & Harmonic measurement ................................19 6.6 Cellular WCDMA Radiated Spurious & Harmonic Conversion Table......................20 6.7 PCS WCDMA Radiated Spurious & Harmonic Conversion Table ..........................21 6.8 Frequency Stability.................................................................................................22 6.8.1 Cellular WCDMA Frequency Stability Table ..................................................22 6.8.2 PCS WCDMA Frequency Stability Table .......................................................23 6.8.3 Cellular WCDMA Frequency Stability Graph .................................................24 6.8.4 PCS WCDMA Frequency Stability Graph......................................................26 7. SAMPLE CALCULATION .............................................................................................28 7.1 Emission Designator ..............................................................................................28 8. CONCLUSION...............................................................................................................29 9. TEST PLOT ...................................................................................................................30 Report Number : FH-280-R2 3 of 53 MEASUREMENT REPORT 1. FCC Certification Information The following information is in accordance with FCC Rules, 47CFR Part2, Subpart J, Sections 2.1033 – 2.1055. 1.1 §2.1033 General Information • Applicant Name: SAMSUNG ELECTRONICS CO., LTD. • Address: 416 Maetan3-Dong, Yeongtong-gu, Suwon City Gyeonggi-Do, Korea 443-742 • FCC ID: • Model: A3LGTE3210L GT-E3210L • Quantity: Quantity production is planned • Emission Designators: 4M17F9W(Cellular WCDMA),4M19F9W(PCS WCDMA) • Tx Freq. Range: 826.4 - 846.6 MHz (Cellular WCDMA) 1852.4 - 1907.6 MHz (PCS WCDMA) • Rx Freq. Range: 871.4 - 891.6 MHz (Cellular WCDMA) 1932.4 - 1987.6 MHz (PCS WCDMA) • Max. Power Rating: 0.055 W Cellular WCDMA (17.43 dBm) 0.100 W PCS WCDMA(20.0 dBm) • FCC Classification(s): PCS Licensed Portable Tx Held to Ear (PCE) • Equipment (EUT) Type: 850/1900 GSM/GPRS/WCDMA Phone with Bluetooth and EDGE Rx Only • Modulation(s): WCDMA • Frequency Tolerance: ±0.00025% (2.5ppm) • FCC Rule Part(s): §24(E), §22(H), §2. • Dates of Test: December 15-16, 2010 • Place of Test: SAMSUNG Lab, • Test Report S/N: FH-280-R2 Report Number : FH-280-R2 4 of 53 2. INTRODUCTION 2.1 General These measurement test were conducted at SAMSUNG ELECTRONICS CO., LTD(SUWON). The site address is 416 Maetan3-Dong, Yeongtong-gu, Suwon City, Gyeonggi-Do, Korea 443-742 The site have 1 Fully-anechoic chamber and measurement facility. Mea…
