A3LGTI8258Portable Handset

User manual GT-I8258 Draft 6.1 2012-10-30 Only for Approval using this manual This user manual has been specially designed to guide you through the functions and features of your mobile phone. To get started quickly, refer to “introducing your mobile phone, Instructional icons Before you start, familiarise yourself with the icons you will see in this manual: Warning—situations that could cause injury to yourself or others Caution—situations that could cause damage to your phone or other equipment Note—notes, usage tips, or additional information Refer to—pages with related information; for example: p. 12 (represents “see page 12”) Õ Followed by—the order of options or menus you must select to perform a step; for example: In Menu mode, select Messages Õ Create new message (represents Messages, followed by Create new message) [ ] Square brackets—phone keys; for example: [ ](represents the Power/ Menu exit key) < > Angled brackets—softkeys that control different functions at each screen; for example: <OK> (represents the OK softkey) Copyright information Rights to all technologies and products that comprise this device are the property of their respective owners:  Bluetooth ® is a registered trademark of the Bluetooth SIG, Inc. worldwide  Java™ is a trademark of Sun Microsystems, Inc.  Windows Media Player ® is a registered trademark of Microsoft Corporation. contents safety and usage information Safety warnings Safety precautions Important usage information introducing your mobile phone Unpack .. Phone layout Keys Display Icons assembling and preparing your mobile phone Install the SIM card and battery Charge the battery using basic functions Turn your phone on and off Access menus Customise your phone Use basic call functions Send and view messages Add and find contacts troubleshooting safety and usage information Comply with the following precautions to avoid dangerous or illegal situations and ensure peak performance of your mobile phone. Safety warnings Keep your phone away from small children and pets Keep your phone and all accessories out of the reach of small children or animals. Small parts may cause choking or serious injury if swallowed. Protect your hearing Excessive exposure to sound at high volumes can cause hearing damage. Always turn the volume down before plugging the earphones into an audio source and use only the minimum volume setting necessary to hear your conversation or music. Install mobile phones and equipment with caution Ensure that any mobile phones or related equipment installed in your vehicle are securely mounted. Avoid placing your phone and accessories near or in an air bag deployment area. Improperly installed wireless equipment can cause serious injury when air bags inflate rapidly. Handle and dispose of batteries and chargers with care  Use only Samsung-approved batteries and chargers specifically designed for your phone. Incompatible batteries and chargers can cause serious injuries or damage to your phone.  Never dispose of batteries or phones in a fire. Follow all local regulations when disposing used batteries or phones.  Never place batteries or phones on or in heating devices, such as microwave ovens, stoves, or radiators. Batteries may explode when overheated.  Never crush or puncture the battery. Avoid exposing the battery to high external pressure, which can lead to an internal short circuit and overheating. Avoid interference with pacemakers Maintain a minimum of 15 cm (6 inches) between mobile phones and pacemakers to avoid potential interference, as recommended by manufacturers and the independent research group, Wireless Technology Research. If you have any reason to suspect that your phone is interfering with a pacemaker or other medical device, turn off the phone immediately and contact the manufacturer of the pacemaker or medical device for guidance. Turn off the phone in potentially explosive environments Do not use your phone at refuelling points (service stations) or near fuels or chemicals. Turn off your phone whenever directed by warning signs or instructions. Your phone could cause explosions or fire in and around fuel or chemical storage and transfer areas or blasting areas. Do not store or carry flammable liquids, gases, or explosive materials in the same compartment as the phone, its parts, or accessories. Reduce the risk of repetitive motion injuries When sending text messages or playing games on your phone, hold the phone with a relaxed grip, press the keys lightly, use special features that reduce the number of keys you have to press (such as templates and predictive text), and take frequent breaks. Safety precautions Drive safely at all times Avoid using your phone while driving and obey all regulations that restrict the use of mobile phones while driving. Use hands-free accessories to increase your safety when possible. Follow all safety warnings and regulations Comply with any regulations that restrict the use of a mobile phone in a certain area. Use only Samsung-approved accessories Using incompatible accessories may damage your phone or cause injury. Turn off the phone near medical equipment Your phone can interfere with medical equipment in hospitals or health care facilities. Follow all regulations, posted warnings, and directions from medical personnel. Turn off the phone or disable the wireless functions when in an aircraft Your phone can cause interference with aircraft equipment. Follow all airline regulations and turn off your phone or switch to a mode that disables the wireless functions when directed by airline personnel. Protect batteries and chargers from damage Avoid exposing batteries to very cold or very hot temperatures (below 0° C/32° F or above 45° C/ 113° F). Extreme temperatures can reduce the charging capacity and life of your batteries. Prevent batteries from contacting metal objects, as this can create a connection between the + and - terminals of your batteries and lead to temporary or perman…

Text truncated - open the document above for the full version.

December 4, 2012 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: A3L GTI8258 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematics Block Diagram Operational Description Antenna Specification Parts List Tune-Up Procedure Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondence during certification review process cannot be granted as confidential documents and such information will be available for public review once the grant of equipment authorization is issued. Best Regards Sang Kyung (Peter), Ra/ General Manager Samsung Electronics CO. LTD TEL: 310-900-5250 FAX: 310-537-5500 E-mail: [email protected]

416, Maetan-3 Dong , Yeongtong-Gu, Suwon-City, Gyeonggi-Do 443-742 South Korea Date: 04/09/2012 Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Ms. Claire Hoque/Application Examiner of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Ms. Claire Hoque of CCS on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing CCS as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, NAME: Sang Kyung(Peter), Ra TITLE: Head of QA Lab (General Manager) Applicant: Samsung Electronics America, Inc Address: 19 Chapin Rd, Building D. Pine Brook, NJ 07058

SAMSUNG ELECTRONICS CO., LTD 416,Maetan-3dong,Yeongtong-gu Suwon-si,Gyeonggi-do, 443-742 Korea December 4, 2012 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT : Label Statement FCC ID : A3L GTI8258 Gentlemen: We hereby provide the label statement letter for the above-mentioned device by a new label statement policy instituted at the September 12, 2006, TCB-FCC Teleconference. The label statement is as follows: The FCC ID shown in the FCC ID label page will be readily visible at the time of purchase because the device will be marketed without the battery installed. The label is permanently attached by acrylic glue and not easily removed from the device. This statement could not be included in the label. So we inform you of it through this letter. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely Yours, Seoung Ho Park Senior Manager SAMSUNG ELECTRONICS CO.,LTD Telecommunication Network Business Mobile Communication Division Regulatory Compliance Group.

Label and Location Samsung Phone Model: GT-I8258 FCC ID: A3LGTI8258 Label: Location: Top Back plate of device Bottom Phone: Label is placed inside of the battery compartment.

FCC ID: A3LGTI8258 Report Number: FJ-279-S1 Page : 1 of 35 SAMSUNG Electronics C0. LTD EUT Type: 1900 GSM/GPRS/EDGE Mobile Phone with WLAN and Bluetooth Issue Date : Nov.21, 2012 SAMSUNG ELECTRONICS Co., Ltd., Regulatory Compliance Group IT R&D Center 416, Maetan-3dong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea 443-742 TEST REPORT ON SAR Model Tested: GT-I8258 FCC ID (Requested): A3LGTI8258 Job No: FJ-279 Report No: FJ-279-S1 - Abstract – This document reports on SAR Tests carried out in accordance with FCC/OET Bulletin 65, Supplement C(June 2001). Prepared By BH JEON - Test Engineer Authorized By JD JANG - Technical Manager FCC ID: A3LGTI8258 Report Number: FJ-279-S1 Page : 2 of 35 SAMSUNG Electronics C0. LTD EUT Type: 1900 GSM/GPRS/EDGE Mobile Phone with WLAN and Bluetooth Issue Date : Nov.21, 2012 Contents 1. GENERAL INFORMATION ........................................................................................................ 3 2. DESCRIPTION OF DEVICE ...................................................................................................... 3 3. DESCRIPTION OF TEST EQUIPMENT .................................................................................... 4 3.1 SAR Measurement Setup ................................................................................................................................................. 4 3.2 E-field Probe ..................................................................................................................................................................... 5 3.3 Phantom ........................................................................................................................................................................... 7 3.4 Brain Simulating Mixture Characterization ........................................................................................................................ 8 3.5 Device Holder for Transmitters.......................................................................................................................................... 9 3.6 Validation Dipole ............................................................................................................................................................... 9 3.7 Equipment Calibration ..................................................................................................................................................... 10 4. SAR MEASUREMENT PROCEDURE ..................................................................................... 11 5. DESCRIPTION OF TEST POSITION ...................................................................................... 12 5.1 SAM Phantom Shape ..................................................................................................................................................... 12 5.2 “cheek” Position .............................................................................................................................................................. 12 5.3 “tilted” Position ................................................................................................................................................................ 14 5.4 Body Holster/Belt Clip Configurations ............................................................................................................................. 15 5.5 FCC Personal Wireless Router Configurations ............................................................................................................... 16 6. MEASUREMENT UNCERTAINTY ........................................................................................... 18 7. SYSTEM VERIFICATION ........................................................................................................ 20 7.1 Tissue Verification ........................................................................................................................................................... 20 7.2 Test System Validation .................................................................................................................................................... 20 8. SAR MEASUREMENT RESULTS ........................................................................................... 21 8.1 GSM1900 Head SAR Results ......................................................................................................................................... 29 8.2 GSM1900 Body SAR Results ......................................................................................................................................... 30 8.3 802.11b WLAN Head SAR Results ................................................................................................................................. 31 8.4 802.11b WLAN Body SAR Results ................................................................................................................................. 32 9. CONCLUSION ......................................................................................................................... 33 10. REFERENCES ....................................................................................................................... 34 FCC ID: A3LGTI8258 Report Number: FJ-279-S1 Page : 3 of 35 SAMSUNG Electronics C0. LTD EUT Type: 1900 GSM/GPRS/EDGE Mobile Phone with WLAN and Bluetooth Issue Date : Nov.21, 2012 1. GENERAL INFORMATION Test Dates : Oct.12, 2012 ~ Oct.15,2012 Manufacturer : SAMSUNG ELECTRONICS Co., Ltd. Address : 416 Maetan3-Dong, Suwon City, Korea Test Standard : §2.1093; FCC/OET Bulletin 65, Supplement C(June 2001) FCC Classification : Licensed Portable Transmitter Held to Ear (PCE) Digital Transmitter System (DTS) Tested for : FCC/TCB Certification 2. DESCRIPTION OF DEVICE Test Sample : 1900 GSM/GPRS/EDGE Mobile Phone with WLAN and Bluetooth Model Number : GT-I8258 Serial Number : Identical prototype (S/N : # FJ-279-C) Tx Freq. Range : 1850.20 …

Text truncated - open the document above for the full version.

APPENDIX D The Validation Measurements DUT: Dipole 1900 MHz; Serial: 5d023 Program Name: 1900MHz Dipole Validation 2012.10.12 Procedure Name: 1900MHz @ 100mW Meas. Ambient Temp(celsius)-22.6,Tissue Temp(celsius)-22.4;Test Date-12/Oct/2012 j–””œ•Šˆ›–•Gz š›Œ”aGj~bGm™Œ˜œŒ•Š aGX`WWGto¡bkœ› Gj Š“ŒaGXaXG tŒ‹œ”G—ˆ™ˆ”Œ›Œ™šGœšŒ‹aGGdGX`WWGto¡bGɍ GdGXU[G”–V”bGȿ ™ GdGZ`UZbGɋGdGXWWWG’ŽV” Z GG wˆ•›–”GšŒŠ›–•aGm“ˆ›GzŒŠ›–•GG khz€\Gj–•Žœ™ˆ›–•aG TGw™–‰ŒaGlZk}[GTGzuZ\YWbGj–•mO_U\[SG_U\[SG_U\ [PbGjˆ“‰™ˆ›Œ‹aGYWXYTWYTYXG TGzŒ•š–™Tzœ™ˆŠŒaG[””GOtŒŠˆ•Šˆ“Gzœ™ˆŠŒGkŒ›ŒŠ›–•PG TGl“ŒŠ›™–•ŠšaGkhl[Gz •]_]bGjˆ“‰™ˆ›Œ‹aGYWXYTWZTX`G TGwˆ•›–”aGwohu{vtGJYbG{ —ŒaGzhtbGzŒ™ˆ“aG{wTX]W[G TGtŒˆšœ™Œ”Œ•›Gz~aGkhz€ [SG}[U^Giœ“‹G_WbGw–š›—™–ŠŒšš•ŽGz~aGzltjhkSG}XU_Giœ“‹GX_]G G X`WWto¡GgGXWW”~Vh™ŒˆGzŠˆ•GO\XŸ\XŸXPaGtŒˆšœ™Œ”Œ•›GŽ™‹aG‹ŸdYW””SG‹ dYW””G tˆŸ”œ”Gˆ“œŒG–GzhyGO•›Œ™—–“ˆ›Œ‹PGdG\UZZG”~VŽG G X`WWto¡GgGXWW”~V––”GzŠˆ•GO\Ÿ\Ÿ^PVjœ‰ŒGWaGtŒˆšœ™Œ”Œ•›GŽ™‹aG‹Ÿd_””SG‹ d_””SG ‹¡d\””G yŒŒ™Œ•ŠŒG}ˆ“œŒGdG[\U]G}V”bGw–žŒ™Gk™›GdGTWUWY]G‹iG wŒˆ’GzhyGOŒŸ›™ˆ—–“ˆ›Œ‹PGdG^U[]G~V’ŽG zhyOXGŽPGdG[UW_G”~VŽbGzhyOXWGŽPGdGYUX[G”~VŽG tˆŸ”œ”Gˆ“œŒG–GzhyGO”Œˆšœ™Œ‹PGdG[U\^G”~VŽG 0 dB = 4.57mW/g DUT: Dipole 1900 MHz; Serial: 5d023 Program Name: 1900MHz Dipole Validation 2012.10.12 Procedure Name: 1900MHz @ 100mW Meas. Ambient Temp(celsius)-22.6,Tissue Temp(celsius)-22.4;Test Date-12/Oct/2012 j–””œ•Šˆ›–•Gz š›Œ”aGj~bGm™Œ˜œŒ•Š aGX`WWGto¡bkœ› Gj Š“ŒaGXaXG tŒ‹œ”G—ˆ™ˆ”Œ›Œ™šGœšŒ‹aGGdGX`WWGto¡bGɍ GdGXU\G”–V”bGȿ ™ GdG\ZUXbGɋGdGXWWWG’ŽV” Z GG wˆ•›–”GšŒŠ›–•aGsŒ›GzŒŠ›–•GG khz€\Gj–•Žœ™ˆ›–•aG TGw™–‰ŒaGlZk}[GTGzuZ\YWbGj–•mO_UX`SG_UX`SG_UX `PbGjˆ“‰™ˆ›Œ‹aGYWXYTWYTYXG TGzŒ•š–™Tzœ™ˆŠŒaG[””GOtŒŠˆ•Šˆ“Gzœ™ˆŠŒGkŒ›ŒŠ›–•PG TGl“ŒŠ›™–•ŠšaGkhl[Gz •]_]bGjˆ“‰™ˆ›Œ‹aGYWXYTWZTX`G TGwˆ•›–”aG{™—“ŒGm“ˆ›Gwˆ•›–”G\UXbG{ —ŒaG{™—“ŒGm“ˆ›Gwˆ•›–”G\UXbGzŒ™ˆ “aGtwTXWXWG TGtŒˆšœ™Œ”Œ•›Gz~aGkhz€[SG}[U^Giœ“‹G_WbGw–š›—™–ŠŒšš•ŽGz~aGzltjhkSG}XU_Giœ“‹GX_]G G X`WWto¡GgGXWW”~Vh™ŒˆGzŠˆ•GO\XŸ\XŸXPaGtŒˆšœ™Œ”Œ•›GŽ™‹aG‹ŸdYW””SG‹ dYW””G tˆŸ”œ”Gˆ“œŒG–GzhyGO•›Œ™—–“ˆ›Œ‹PGdG\U[_G”~VŽG G X`WWto¡GgGXWW”~V––”GzŠˆ•GO\Ÿ\Ÿ^PVjœ‰ŒGWaGtŒˆšœ™Œ”Œ•›GŽ™‹aG‹Ÿd_””SG‹ d_””SG ‹¡d\””G yŒŒ™Œ•ŠŒG}ˆ“œŒGdG\YU`G}V”bGw–žŒ™Gk™›GdGTWUX`XG‹iG wŒˆ’GzhyGOŒŸ›™ˆ—–“ˆ›Œ‹PGdG]U_\G~V’ŽG zhyOXGŽPGdGZU_^G”~VŽbGzhyOXWGŽPGdGYUW\G”~VŽG tˆŸ”œ”Gˆ“œŒG–GzhyGO”Œˆšœ™Œ‹PGdG[UZYG”~VŽG 0 dB = 4.32mW/g DUT: Dipole 2450 MHz; Serial: 807 Program Name: 2450MHz Dipole Validation 2012.10.15 Procedure Name: 2450MHz @ 100mW Meas. Ambient Temp(celsius)-22.5,Tissue Temp(celsius)-22.2;Test Date-15/Oct/2012 j–””œ•Šˆ›–•Gz š›Œ”aGj~bGm™Œ˜œŒ•Š aGY[\WGto¡bkœ› Gj Š“ŒaGXaXG tŒ‹œ”G—ˆ™ˆ”Œ›Œ™šGœšŒ‹aGGdGY[\WGto¡bGɍ GdGXU_[G”–V”bGȿ ™ GdGZ`bGɋGdGXWWWG’ŽV” Z GG wˆ•›–”GšŒŠ›–•aGm“ˆ›GzŒŠ›–•GG khz€\Gj–•Žœ™ˆ›–•aG TGw™–‰ŒaGlZk}[GTGzuZ\YWbGj–•mO^U[ZSG^U[ZSG^U[ ZPbGjˆ“‰™ˆ›Œ‹aGYWXYTWYTYXG TGzŒ•š–™Tzœ™ˆŠŒaG[””GOtŒŠˆ•Šˆ“Gzœ™ˆŠŒGkŒ›ŒŠ›–•PG TGl“ŒŠ›™–•ŠšaGkhl[Gz •]_]bGjˆ“‰™ˆ›Œ‹aGYWXYTWZTX`G TGwˆ•›–”aGwohu{vtGJYbG{ —ŒaGzhtbGzŒ™ˆ“aG{wTX]W[G TGtŒˆšœ™Œ”Œ•›Gz~aGkhz€ [SG}[U^Giœ“‹G_WbGw–š›—™–ŠŒšš•ŽGz~aGzltjhkSG}XU_Giœ“‹GX_]G G Y[\Wto¡GgGXWW”~Vh™ŒˆGzŠˆ•GO\XŸ\XŸXPaGtŒˆšœ™Œ”Œ•›GŽ™‹aG‹ŸdYW””SG‹ dYW””G tˆŸ”œ”Gˆ“œŒG–GzhyGO•›Œ™—–“ˆ›Œ‹PGdG^UYZG”~VŽG G Y[\Wto¡GgGXWW”~V––”GzŠˆ•GO\Ÿ\Ÿ^PVjœ‰ŒGWaGtŒˆšœ™Œ”Œ•›GŽ™‹aG‹Ÿd_””SG‹ d_””SG ‹¡d\””G yŒŒ™Œ•ŠŒG}ˆ“œŒGdGZ\U`G}V”bGw–žŒ™Gk™›GdGWUW\_G‹iG wŒˆ’GzhyGOŒŸ›™ˆ—–“ˆ›Œ‹PGdGXXU`G~V’ŽG zhyOXGŽPGdG\U\]G”~VŽbGzhyOXWGŽPGdGYU\\G”~VŽG tˆŸ”œ”Gˆ“œŒG–GzhyGO”Œˆšœ™Œ‹PGdG]UZXG”~VŽG 0 dB = 6.31mW/g DUT: Dipole 2450 MHz; Serial: D2450V2 - SN:807 Program Name: 2450MHz Dipole Validation 2012.10.15 Procedure Name: 2450MHz @ 100mW Meas. Ambient Temp(celsius)-22.5,Tissue Temp(celsius)-22.2;Test Date-15/Oct/2012 j–””œ•Šˆ›–•Gz š›Œ”aGj~bGm™Œ˜œŒ•Š aGY[\WGto¡bkœ› Gj Š“ŒaGXaXG tŒ‹œ”G—ˆ™ˆ”Œ›Œ™šGœšŒ‹aGGdGY[\WGto¡bGɍ GdGXU`ZG”–V”bGȿ ™ GdG\XU`bGɋGdGXWWWG’ŽV” Z GG wˆ•›–”GšŒŠ›–•aGyŽ›GzŒŠ›–•GG khz€\Gj–•Žœ™ˆ›–•aG TGw™–‰ŒaGlZk}[GTGzuZ\YWbGj–•mO^U[\SG^U[\SG^U [\PbGjˆ“‰™ˆ›Œ‹aGYWXYTWYTYXG TGzŒ•š–™Tzœ™ˆŠŒaG[””GOtŒŠˆ•Šˆ“Gzœ™ˆŠŒGkŒ›ŒŠ›–•PG TGl“ŒŠ›™–•ŠšaGkhl[G z•]_]bGjˆ“‰™ˆ›Œ‹aGYWXYTWZTX`G TGwˆ•›–”aG{™—“ŒGm“ˆ›Gwˆ•›–”G\UXbG{ —ŒaG{™—“ŒGm“ˆ›Gwˆ•›–”G\UXbGzŒ™ ˆ“aGtwTXWXWG TGtŒˆšœ™Œ”Œ•›Gz~aGkhz€[SG}[U^Giœ“‹G_WbGw–š›—™–ŠŒšš•ŽGz~aGzltjhkSG}XU_Giœ“‹GX_]G G Y[\Wto¡GgGXWW”~Vh™ŒˆGzŠˆ•GO\XŸ\XŸXPaGtŒˆšœ™Œ”Œ•›GŽ™‹aG‹ŸdYW””SG‹ dYW””G tˆŸ”œ”Gˆ“œŒG–GzhyGO•›Œ™—–“ˆ›Œ‹PGdG]UXYG”~VŽG G Y[\Wto¡GgGXWW”~V––”GzŠˆ•GO\Ÿ\Ÿ^PVjœ‰ŒGWaGtŒˆšœ™Œ”Œ•›GŽ™‹aG‹Ÿd_””SG‹ d_””SG ‹¡d\””G yŒŒ™Œ•ŠŒG}ˆ“œŒGdG\WU\G}V”bGw–žŒ™Gk™›GdGTWUWXZG‹iG wŒˆ’GzhyGOŒŸ›™ˆ—–“ˆ›Œ‹PGdG`U_^G~V’ŽG zhyOXGŽPGdG[U`^G”~VŽbGzhyOXWGŽPGdGYUZ[G”~VŽG tˆŸ”œ”Gˆ“œŒG–GzhyGO”Œˆšœ™Œ‹PGdG\U\\G”~VŽG 0 dB = 5.55mW/g APPENDIX E Plots of The SAR Measurements DUT: GT-I8258; Serial: FJ-279-C Program Name: GT-I8258 GSM1900 Right (Job No. : FJ-279) Procedure Name: Cheek, Ch.661, Ant.Intenna, Bat.Standard Meas. Ambient Temp(celsius)-22.6,Tissue Temp(celsius)-22.4;Test Date-12/Oct/2012 j–””œ•Šˆ›–•Gz š›Œ”aGnztGX`WWbGm™Œ˜œŒ•Š aGX__WGto¡bkœ› Gj Š“ŒaGXa_UZG tŒ‹œ”G—ˆ™ˆ”Œ›Œ™šGœšŒ‹aGGdGX__ WGto¡bGɍGdGXU[G”–V”bGȿ ™ GdGZ`UZbGɋGdGXWWWG’ŽV” Z GG wˆ•›–”GšŒŠ›–•aGyŽ›GzŒŠ›–•GG khz€\Gj–•Žœ™ˆ›–•aG TGw™–‰ŒaGlZk}[GTGzuZ\YWbGj–•mO_U\[SG_U\[SG_U \[PbGjˆ“‰™ˆ›Œ‹aGYWXYTWYTYXG TGzŒ•š–™Tzœ™ˆŠŒaGY””GOtŒŠˆ•Šˆ“Gzœ™ˆŠŒGkŒ›ŒŠ›–•PG TGl“ŒŠ›™–•ŠšaGkhl[G z•]_]bGjˆ“‰™ˆ›Œ‹aGYWXYTWZTX`G TGwˆ•›–”aGwohu{vtGJYbG{ —ŒaGzhtbGzŒ™ˆ“aG{wTX]W[G TGtŒˆšœ™Œ”Œ•›Gz~aGkhz €[SG}[U^Giœ“‹G_WbGw–š›—™–ŠŒšš•ŽGz~aGzltjhkSG}XU_Giœ“‹GX_]G G jŒŒ’SGjU]]XSGh•›Up•›Œ••ˆSGiˆ›Uz›ˆ•‹ˆ™‹Vh™ŒˆGzŠˆ•GO\XŸ^XŸXPaGtŒˆšœ™Œ”Œ•›GŽ™‹aG ‹ŸdYW””SG‹ dYW””G tˆŸ”œ”Gˆ“œŒG–GzhyGO•›Œ™—–“ˆ›Œ‹PGdGWUY_\G”~VŽG G jŒŒ’SGjU]]XSGh•›Up•›Œ••ˆSGiˆ›Uz›ˆ•‹ˆ™‹V––”GzŠˆ•GO\Ÿ\Ÿ^PVjœ‰ŒGWaGtŒˆšœ™Œ”Œ•›GŽ™‹aG ‹Ÿd_””SG‹ d_””SG‹¡d\””G yŒŒ™Œ•ŠŒG}ˆ“œŒGdG`U[YG}V”bGw–žŒ™Gk™›GdGWUWYWG‹iG wŒˆ’GzhyGOŒŸ›™ˆ—–“ˆ›Œ‹PGdGWU[XYG~V’ŽG zhyOXGŽPGdGWUY]^G”~VŽbGzhyOXWGŽPGdGWUX]WG”~VŽG tˆŸ”œ”Gˆ“œŒG–GzhyGO”Œˆšœ™Œ‹PGdGWUZZXG”~VŽG 0 dB = 0.331mW/g DUT: GT-I8258; Serial: FJ-279-C Program Name: GT-I8258 GSM1900 Right (Job No. : FJ-279) Procedure Name: Tilt, Ch.661, A…

Text truncated - open the document above for the full version.

SAMSUNG ELECTRONICS Co., Ltd., Regulatory Compliance Group IT R&D Center 416 Maetan3-Dong, Yeongtong-gu, Suwon city, Gyeonggi-Do, Korea 443-742 FCC CFR47 PART 24 SUBPART CERTIFICATION REPORT Model Tested : GT-I8258 FCC ID(Requested) : A3LGTI8258 Report No : FJ-279-R1 Job No : FJ-279 Date issued : Nov 15, 2012 - Abstract - All measurement reported herein accordance with FCC Rules, 47CFR Part2, Part24. Prepared By HK LEE – Test Engineer Authorized By WT JANG – Technical Manager Report Number : FJ-279-R1 2 of 40 TABLE OF CONTENT MEASUREMENT REPORT Page 1. FCC CERTIFICATION INFORMATION ..................................................................... 3 1.1. §2.1033 General Information ......................................................................... 3 2. INTRODUCTION ....................................................................................................... 4 2.1. General .......................................................................................................... 4 3. MEASURING INSTRUMENT CALIBRATION ........................................................... 5 4. TEST EQUIPMENT LIST ........................................................................................... 6 5. DESCRIPTION OF TESTS ........................................................................................ 7 5.1. Effective Radiated Power / Equivalent Isotropic Radiated Power .................. 7 5.2. Radiated Spurious & Harmonic Emission ...................................................... 8 5.3. Peak-Average Ratio ....................................................................................... 9 5.4. Occupied Bandwidth .................................................................................... 10 5.5. Spurious and Harmonic Emission at Antenna Terminal ................................ 10 5.5.1. Occupied Bandwidth Emission Limits .............................................. 10 5.5.2. Conducted Spurious Emission ......................................................... 12 5.6. Frequency Stability / Temperature Variation ................................................. 13 6. TEST DATA ............................................................................................................. 14 6.1. Equivalent Isotropic Radiated Power (E.I.R.P.) ............................................ 14 6.2. GSM1900 Radiated Spurious & Harmonic measurement ............................ 15 6.3. Frequency Stability ....................................................................................... 16 6.3.1. GSM1900 Frequency Stability Table ................................................ 16 6.3.2. GSM1900 Frequency Stability Graph ............................................... 17 7. CONCLUSION ......................................................................................................... 19 8. TEST PLOTS ........................................................................................................... 20 Report Number : FJ-279-R1 3 of 40 MEASUREMENT REPORT 1. FCC Certification Information The following information is in accordance with FCC Rules, 47CFR Part2, Subpart J, Sections 2.1033 – 2.1055. 1.1. §2.1033 General Information • Applicant Name : SAMSUNG ELECTRONICS CO., LTD. • Address : 416 Maetan3-Dong, Yeongtong-gu, Suwon City Gyeonggi-Do, Korea 443-742 • FCC ID • Model : A3LGTI8258 GT-I8258 • Quantity : Quantity production is planned • Emission Designators : 246KGXW(GSM1900), 246KG7W(GSM1900 EDGE) • Tx Freq. Range : 1850.2MHz -1909.8MHz (GSM1900) • Rx Freq. Range : 1930.2MHz - 1989.8MHz (GSM1900) • Max. Power Rating : 1.109 W EIRP GSM1900 (30.45 dBm) 0.525 W EIRP GSM1900 EDGE(27.20 dBm) • FCC Classification(s) : PCS Licensed Portable Tx Held to Ear (PCE) • Equipment (EUT) Type : Portable Handset • Device Capabilities 1900 GSM/GPRS/EDGE Phone with Bluetooth and WLAN • Frequency Tolerance : ±0.00025% (2.5ppm) • FCC Rule Part(s) : §24(E), §2. • Dates of Test : October 5-6, 2012 • Place of Test : SAMSUNG Lab, • Test Report S/N : FJ-279-R1 Report Number : FJ-279-R1 4 of 40 2. INTRODUCTION 2.1. General These measurement test were conducted at SAMSUNG ELECTRONICS CO., LTD(SUWON). The site address is 416 Maetan3-Dong, Yeongtong-gu, Suwon City, Gyeonggi-Do, Korea 443-742 The site have 1 Fully-anechoic chamber and measurement facility. Measurement Procedure The radiated and spurious measurements were made Fully-anechoic chamber at a 3-meter test range (see Figure2). The equipment under testing was placed on the rotating device at the same height and at a distance of 3-meters from the receive antenna. The rotating device which can rotate horizontal axis was mounted on the turn unit to facilitate rotation around a vertical axis. The measurement was made for each horizontal/vertical position combination with receive antenna horizontally polarized. This measurement was repeated with receive antenna vertically polarized. The substitution antenna will replace the EUT antenna it the same position and in vertical polarization. The frequency of the signal generator shall be set to the frequencies that were measured on the EUT. The signal generator, output level, shall be adjusted until an equal or a known related level to what was measured from the EUT is obtained in the spectrum analyzer. This level was recorded. For readings above 1 GHz, the above procedure is repeated using horn antennas and the difference between the gain of the horn and an isotropic antenna are taken into consideration. Figure1. Map of the Suwon City area. Fi gure2. Photograph of 3m Fully-Anechoic Chamber Report Number : FJ-279-R1 5 of 40 3. MEASURING INSTRUMENT CALIBRATION The measuring equipment, which was utilized in performing the tests documented herein, has been calibrated in accordance with the manufacturer’s recommendations for utilizing calibration equipment, which is traceable to recognized national standards. Report Number : FJ-279-R1 6 of 40 4. TEST EQUIPMENT LIST N…
