A3LGTP7320Tablet PC with Cellular/PCS GSM/EDGE, WLAN and Bluetooth

Using this guide 2 Using this guide Congratulations on your purchase of the Samsung GT-P7320. This powerful, “go anywhere” device, puts the best of the web and mobile computing at your fingertips in a lightweight, highly versatile platform that fits your active lifestyle. Built on the Google Android operating system, the GT-P7320 gives you access to thousands of useful and entertaining applications to enrich your mobile web experience. With integrated wireless access and a responsive touch screen, you can keep in touch with versatile messaging and video calling applications; read books and newspapers on the go; stay up-to-date on the latest news, sports, and weather; manage your multimedia and business files; and browse the web for maps, business locations, and more. Read me first Please read all safety precautions and this guide carefully before using your device to ensure ‡ safe and proper use. The descriptions in this guide are based on the default settings of your device. ‡ Images and screenshots used in this guide may differ in appearance from the actual product.‡ Content in this guide may differ from the product, or from software provided by service ‡ providers or carriers, and is subject to change without prior notice. Using this guide 3 Available features and additional services may vary by device, software, or service provider.‡ Formatting and delivery of this guide is based on Google Android operating systems and may ‡ vary depending on the user’s operating system. Applications and their functions may vary by country, region, or hardware specifications. ‡ Samsung is not liable for performance issues caused by third-party applications. Samsung is not liable for performance issues or incompatibilities caused by user editing of ‡ registry settings. You may upgrade your mobile device’s software by accessing www.samsungmobile.com. ‡ Sound sources, wallpapers, and images provided in this device are licenced for limited use ‡ between Samsung and their respective owners. Extracting and using these materials for commercial or other purposes is an infringement of copyright laws. Samsung is not liable for such copyright infringement by the user. Please keep this guide for future reference. ‡ Using this guide 4 Instructional icons Before you start, familiarise yourself with the icons you will see in this guide: Warning—situations that could cause injury to yourself or others Caution—situations that could cause damage to your device or other equipment Note—notes, usage tips, or additional information Ź Refer to—pages with related information; for example: Ź p.12 (represents “see page 12”) ĺ Followed by—the order of options or menus you must select to perform a step; for example: In Menu mode, select Settings ĺ Wireless and network (represents Settings, followed by Wireless and network) []Square brackets—device keys; for example: [ ] (represents the Power key) Using this guide 5 Copyright Copyright © 2011 Samsung Electronics This user manual is protected under international copyright laws. No part of this user manual may be reproduced, distributed, translated, or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording, or storing in any information storage and retrieval system, without the prior written permission of Samsung Electronics. Trademarks SAMSUNG and the SAMSUNG logo are registered trademarks of Samsung Electronics.‡ The Android logo, Google Search‡ ™ , Google Maps ™ , Google Mail ™ , YouTube ™ , Android Market ™ , and Google Talk ™ are trademarks of Google, Inc. Bluetooth ‡ ® is a registered trademark of the Bluetooth SIG, Inc. worldwide. Oracle and Java are registered trademarks of Oracle and/or its affiliates. Other names may be ‡ trademarks of their respective owners. Windows Media Player ‡ ® is a registered trademark of Microsoft Corporation. Wi-Fi ‡ ® , the Wi-Fi CERTIFIED logo, and the Wi-Fi logo are registered trademarks of the Wi-Fi Alliance. Using this guide 6 DivX‡ ® , Divx Certified ® , and associated logos are trademarks of DivX, Inc. and are used under license. Covered by one or more of the following U.S. patents: Pat. 7,295,673; 7,460,668; 7,515,710; 7,519,274 All other trademarks and copyrights are the property of their respective owners. ‡ Using this guide 7 ABOUT DIVX VIDEO DivX ® is a digital video format created by DivX, Inc. This is an official DivX Certified ® device that plays DivX video. Visit www.divx.com for more information and software tools to convert your files into DivX video. DivX Certified ® to play DivX ® video up to HD 720p, including premium content May play DivX ® video up to HD 1080p (LCD resolution : 1024x600) ABOUT DIVX VIDEO-ON-DEMAND This DivX Certified ® device must be registered in order to play purchased DivX Video-on-Demand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device setup menu. Go to vod.divx.com for more information on how to complete your registration. Contents 8 Assembling ...........................................................................................11 Unpack ............................................................................................................................... 11 Charge the battery .......................................................................................................... 12 Insert the SIM or USIM card ........................................................................................... 13 Insert a memory card (optional) .................................................................................. 15 Getting started .....................................................................................18 Turn your device on and off .......................................................................................... 18 Get to know your device ................................................................................................ 20 Use the touch sc…

Text truncated - open the document above for the full version.

To Whom It May Concern: We attest to the following for this application: 1.We attest that the Wireless Router Hotspot mode will not operate in conjunction with 5 GHz in US or any country. This is disabled at the factory via software and cannot be modified by any party or persons other than Samsung Electronics. 2. We attest that the LTE operations in this device are for non-US operations and will not have any capability to roam or register on any US networks. This LTE operational capability can not be modified by any party or persons other than Samsung Electronics. December 16, 2011 Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely, Signature Park soo-pyoung, Engineer Samsung Electronics SAMSUNG ELECTRONICS AMERICA, INC. American QA Lab 18600 Broadwick St. Rancho Dominguez, CA 90220 Date : Dec 16, 2011 PCTEST TCB/CB Div. of PCTEST Engineering Lab., Inc. 6660-B Dobbin Road Columbia, MD 21045 SUBJECT: Samsung Electronics Co.,Ltd. FCC ID : A3LGTP7320

SAMSUNG ELECTRONICS AMERICA, INC. American QA Lab 18600 Broadwick St. Rancho Dominguez, CA 90220 Date: November 10, 2011 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: A3LGTP7320 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, SAMSUNG ELECTRONICS CO.,LTD. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give SAMSUNG ELECTRONICS CO.,LTD. temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Operational Description PERMANENT 3 Schematics 4 External Photos 5 Internal Photos 6 Test-Setup Photos SHORT-TERM 7 Users Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Peter Ra General Manager American QA Lab SAMSUNG Electronics America INC.

PCTEST Engineering Laboratory Inc. 6660 Dobbin Road Suite A-E Columbia, Maryland 21045-4844 Tel.: 410-290-6652 / Fax: 410-290-6654 © 2011 PCTEST Engineering Laboratory Inc. December 28, 2011 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: SAMSUNG Electronics Co., Ltd. FCC ID: A3LGTP7320 Notice of Superseding Exhibit To Whom It May Concern: On behalf of SAMSUNG Electronics Co., Ltd., we have superseded the following exhibit for Tablet PC with Cellular/PCE GSM/EDGE, WLAN and Bluetooth. 1. RF Exposure Info The exhibit has been superseded on 12/28/2011 since the DTS SAR value on Page 1 of the SAR Report should be 0.35 W/kg and not "0.36 W/kg." The DTS grant notes are amended to reflect the SAR data (i.e. 0.35 W/kg). The PCB and NII grant notes remain unchanged. Should you have any questions or comments concerning the above, please contact the undersigned.

Samsung FCC ID: A3LGTP7320 Model: GT-P7320 External Photos EUT Type: Portable Tablet Computer Page 1 of 4 © 2011 PCTEST Engineering Laboratory Inc. E X T E R N A L P H O T O G R A P H S Samsung FCC ID: A3LGTP7320 Model: GT-P7320 External Photos EUT Type: Portable Tablet Computer Page 2 of 4 © 2011 PCTEST Engineering Laboratory Inc. Samsung FCC ID: A3LGTP7320 Model: GT-P7320 External Photos EUT Type: Portable Tablet Computer Page 3 of 4 © 2011 PCTEST Engineering Laboratory Inc. Samsung FCC ID: A3LGTP7320 Model: GT-P7320 External Photos EUT Type: Portable Tablet Computer Page 4 of 4 © 2011 PCTEST Engineering Laboratory Inc.

Label and Location Samsung Phone Model: GT-P7320 FCC ID: A3LGTP7320 Label: Location: Top Back plate of GT-P7320 Bottom FCC ID is printed on the bottom of device.

Samsung FCC ID: A3LGTP7320 Model: GT-P7320 Internal Photos EUT Type: Portable Tablet Computer Page 1 of 8 © 2011 PCTEST Engineering Laboratory Inc. I N T E R N A L P H O T O G R A P H S Samsung FCC ID: A3LGTP7320 Model: GT-P7320 Internal Photos EUT Type: Portable Tablet Computer Page 2 of 8 © 2011 PCTEST Engineering Laboratory Inc. Samsung FCC ID: A3LGTP7320 Model: GT-P7320 Internal Photos EUT Type: Portable Tablet Computer Page 3 of 8 © 2011 PCTEST Engineering Laboratory Inc. Samsung FCC ID: A3LGTP7320 Model: GT-P7320 Internal Photos EUT Type: Portable Tablet Computer Page 4 of 8 © 2011 PCTEST Engineering Laboratory Inc. Samsung FCC ID: A3LGTP7320 Model: GT-P7320 Internal Photos EUT Type: Portable Tablet Computer Page 5 of 8 © 2011 PCTEST Engineering Laboratory Inc. Samsung FCC ID: A3LGTP7320 Model: GT-P7320 Internal Photos EUT Type: Portable Tablet Computer Page 6 of 8 © 2011 PCTEST Engineering Laboratory Inc. Samsung FCC ID: A3LGTP7320 Model: GT-P7320 Internal Photos EUT Type: Portable Tablet Computer Page 7 of 8 © 2011 PCTEST Engineering Laboratory Inc. Samsung FCC ID: A3LGTP7320 Model: GT-P7320 Internal Photos EUT Type: Portable Tablet Computer Page 8 of 8 © 2011 PCTEST Engineering Laboratory Inc.

FCC ID: A3LGTP7320 FCC Pt. 15.407 802.11a/n UNII MEASUREMENT REPORT (CERTIFICATION) Reviewed by: Quality Manager Test Report S/N: Test Dates: EUT Type: Page 1 of 71 0Y1110031751.A3L October 12-17, 2011 Portable Tablet Computer © 2011 PCTEST Engineering Laboratory, Inc. REV 2.3UAN 09/14/11 Applicant Name: Date of Testing: Samsung Electronics, Co. Ltd. October 12-17, 2011 18600 Broadwick St. Test Site/Location: Rancho Dominguez, CA 90220 PCTEST Lab, Columbia, MD, USA United States Test Report Serial No.: 0Y1110031751.A3L FCC ID: A3LGTP7320 APPLICANT: Samsung Electronics, Co. Ltd. Application Type: Certification Model(s): GT-P7320, GT-P7320T EUT Type: Portable Tablet Computer Max. RF Output Power: 10.52 mW (10.22 dBm) Conducted (802.11a UNII Band 1) 10.89 mW (10.37 dBm) Conducted (802.11a UNII Band 2) 10.59 mW (10.25 dBm) Conducted (802.11a UNII Band 3) 10.42 mW (10.18 dBm) Conducted (802.11n UNII Band 1) 10.54 mW (10.23 dBm) Conducted (802.11n UNII Band 2) 10.81 mW (10.34 dBm) Conducted (802.11n UNII Band 3) Frequency Range: 5180MHz – 5240MHz (UNII Band 1), 5260MHz – 5320MHz (UNII Band 2), 5500MHz – 5700MHz (UNII Band 3) FCC Classification: Unlicensed National Information Infrastructure (UNII) FCC Rule Part(s): Part 15.407 IC Specification(s): RSS-210 Issue 8 This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C-63.4-2003. Test results reported herein relate only to the item(s) tested. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant Conditions: Listed output power is conducted. PCTEST certifies that no party to this application has been subject to a denial of Federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com MEASUREMENT REPORT FCC PART 15.407 / IC RSS-210 802.11a/n (UNII) FCC ID: A3LGTP7320 FCC Pt. 15.407 802.11a/n UNII MEASUREMENT REPORT (CERTIFICATION) Reviewed by: Quality Manager Test Report S/N: Test Dates: EUT Type: Page 2 of 71 0Y1110031751.A3L October 12-17, 2011 Portable Tablet Computer © 2011 PCTEST Engineering Laboratory, Inc. REV 2.3UAN 09/14/11 TABLE OF CONTENTS FCC PART 15.407 MEASUREMENT REPORT...................................................................................3 1.0 INTRODUCTION ...................................................................................................................................... 4 1.1 SCOPE ........................................................................................................................................................... 4 1.2 PCTEST TEST LOCATION ............................................................................................................................ 4 2.0 PRODUCT INFORMATION ..................................................................................................................... 5 2.1 EQUIPMENT DESCRIPTION......................................................................................................................... 5 2.2 DEVICE CAPABILITIES ................................................................................................................................. 5 2.3 EMI SUPPRESSION DEVICE(S)/MODIFICATIONS ...................................................................................... 5 2.4 LABELING REQUIREMENTS ........................................................................................................................ 5 3.0 DESCRIPTION OF TEST ........................................................................................................................ 6 3.1 EVALUATION PROCEDURE ......................................................................................................................... 6 3.2 CONDUCTED EMISSIONS ........................................................................................................................... 6 3.3 RADIATED EMISSIONS ................................................................................................................................ 7 4.0 ANTENNA REQUIREMENTS .................................................................................................................. 8 5.0 TEST EQUIPMENT CALIBRATION DATA .............................................................................................. 9 6.0 TEST RESULTS .................................................................................................................................... 10 6.1 SUMMARY ................................................................................................................................................... 10 6.2 26DB BANDWIDTH MEASUREMENT ......................................................................................................... 11 6.3 UNII OUTPUT POWER MEASUREMENT – 802.11A/N .............................................................................. 21 6.4 PEAK POWER SPECTRAL DENSITY ......................................................................................................... 22 6.5 PEAK EXCURSION RATIO ......................................................................................................................... 32 6.6 FREQUENCY STABILITY ............................................................................................................................ 42 6.7 RADIATED SPURIOUS EMISSION MEASUREMENTS .............................................................................. …

Text truncated - open the document above for the full version.

FCC ID: A 3LGTP7320 FCC Pt. 15.407 DFS TEST REPORT (CERTIFICATION) Reviewed by: Quality Manager Test Report S/N: Test Dates: EUT Type: Page 1 of 22 0Y1110031752.A3L October 12-17, 2011 Portable Tablet Computer © 2011 PCTEST Engineering Laboratory, Inc. REV 1.3DFS 3/3/08 Company Name: Date of Testing: Samsung Electronics, Co. Ltd. October 12-17, 2011 18600 Broadwick St. Test Site/Location: Rancho Dominguez, CA 90220 PCTEST Lab. Columbia, MD, USA United States Test Report Serial No.: 0Y1110031752.A3L FCC ID: A 3LGTP7320 COMPANY: Samsung Electronics, Co. Ltd. Model(s): GT-P7320, GT-P7320T EUT Type: Portable Tablet Computer Type of Device: Client Only Device, No Radar Detection Capability Frequency Range: 5260 – 5320 MHz (UNII-II Band) 5500 – 5700 MHz (UNII-III Band) Output Power: 10.89 mW (10.37 dBm) Conducted (802.11a UNII Band 2) 10.81 mW (10.34 dBm) Conducted (802.11n UNII Band 3) FCC Classification: Unlicensed National Information Infrastructure (UNII) FCC Rule Part(s): Part 15.407(UNII) This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.4-2003 and FCC 06-96 Appendix B Compliance Measurement Procedures for Unlicensed-National Information Infrastructure Devices Operating in the 5.25 – 5.35 GHz and 5.47 – 5.725 GHz Bands Incorporating Dynamic Frequency Selection. Test results reported herein relate only to the item(s) tested. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been subject to a denial of Federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.665 4 http://www.pctestlab.com MEASUREMENT REPORT FCC PART 15.407 / IC RSS-210 FCC ID: A3LGTP7320 FCC Pt. 15.407 DFS TEST REPORT (CERTIFICATION) Reviewed by: Quality Manager Test Report S/N: Test Dates: EUT Type: Page 2 of 22 0Y1110031752.A3L October 12-17, 2011 Portable Tablet Computer © 2011 PCTEST Engineering Laboratory, Inc. REV 1.3DFS 3/3/08 T A B L E O F C O N T E N T S FCC PART 15.407 MEASUREMENT REPORT...................................................................................3 1.0 INTRODUCTION ...................................................................................................................................... 4 1.1 SCOPE ....................................................................................................................................................... 4 1.2 EVALUATION PROCEDURE ..................................................................................................................... 4 1.3 SUMMARY OF TEST RESULTS ............................................................................................................... 4 2.0 PRODUCT INFORMATION ..................................................................................................................... 5 2.1 EQUIPMENT DESCRIPTION ..................................................................................................................... 5 2.2 MODIFICATIONS ....................................................................................................................................... 5 3.0 DESCRIPTION OF DYNAMIC FREQUENCY SELECTION TEST ......................................................... 6 3.1 APPLICABILITY ......................................................................................................................................... 6 3.2 REQUIREMENTS ...................................................................................................................................... 6 3.3 DFS DETECTION THRESHOLD VALUES ................................................................................................ 8 3.4 PARAMETERS OF DFS TEST SIGNALS .................................................................................................. 8 3.5 PROCEDURE ............................................................................................................................................ 9 4.0 TEST EQUIPMENT ................................................................................................................................11 4.1 ADDITIONAL EQUIPMENT...................................................................................................................... 11 5.0 TEST PLOTS AND DATA UNII - II BAND .............................................................................................12 6.0 TEST PLOTS AND DATA UNII – III BAND............................................................................................17 7.0 CONCLUSION .......................................................................................................................................22 FCC ID: A3LGTP7320 FCC Pt. 15.407 DFS TEST REPORT (CERTIFICATION) Reviewed by: Quality Manager Test Report S/N: Test Dates: EUT Type: Page 3 of 22 0Y1110031752.A3L October 12-17, 2011 Portable Tablet Computer © 2011 PCTEST Engineering Laboratory, Inc. REV 1.3DFS 3/3/08 DFS MEASUREMENT REPORT FCC Part 15.407 § 2.1033 General Information APPLICANT: Samsung Electronics, Co. Ltd. APPLICANT ADDRESS: 18600 Broadwick St. Rancho Dominguez, CA 90220, United States TEST SITE: PCTEST ENGINEERING LABORATORY, INC. TEST SITE ADDRESS: 6660-B Dobbin Road, Columbia, MD 21045 USA FCC RULE PART(S): Part 15.407(h) BASE MODEL: GT-P7320 FCC ID: A3LGTP7320 Test Device Serial No.: N/A Production Pre-Production Engineering DEVICE CLASSIFICATION: Client Onl…

Text truncated - open the document above for the full version.

Samsung FCC ID: A3LGTP7320 Model: GT-P7320 Test Set-Up Photos EUT Type: Portable Tablet Computer Page 1 of 3 © 2011 PCTEST Engineering Laboratory Inc. T E S T S E T U P P H O T O G R A P H S Samsung FCC ID: A3LGTP7320 Model: GT-P7320 Test Set-Up Photos EUT Type: Portable Tablet Computer Page 2 of 3 © 2011 PCTEST Engineering Laboratory Inc. Samsung FCC ID: A3LGTP7320 Model: GT-P7320 Test Set-Up Photos EUT Type: Portable Tablet Computer Page 3 of 3 © 2011 PCTEST Engineering Laboratory Inc.
