A3LGTP8110Portable Tablet Computer with WLAN, RFID and Bluetooth

Some of the contents in this manual may differ from your device depending on the software of the device or your service provider. www.samsung.com English (EU). 01/2012. Rev. 1.0 To install Kies (PC Sync) Download the latest version of Kies from the 1. Samsung website (www.samsung.com/kies) and install it on your PC. Using a USB cable, connect your device to your PC. 2. Samsung Kies will launch automatically. Refer to the Kies help for more information. GT-P8110 user manual Using this manual 2 Using this manual Congratulations on your purchase of the Samsung mobile device. This powerful, “go anywhere” device, puts the best of the web and mobile computing at your fingertips in a lightweight, highly versatile platform that fits your active lifestyle. Built on the Google Android operating system, the Samsung mobile device gives you access to thousands of useful and entertaining applications to enrich your mobile web experience. With integrated wireless access and a responsive touch screen, you can read books and newspapers on the go; stay up-to-date on the latest news, sports, and weather; manage your multimedia and business files; and browse the web for maps, business locations, and more. Read me first Please read all safety precautions and this manual carefully ● before using your device to ensure safe and proper use. The descriptions in this manual are based on the default ● settings of your device. Images and screenshots used in this user manual may differ ● in appearance from the actual product. Content in this user manual may differ from the product, or ● from software provided by service providers or carriers, and is subject to change without prior notice. Refer to www.samsung.com for the latest version of the user manual. Available features and additional services may vary by ● device, software, or service provider. Using this manual 3 Formatting and delivery of this user manual is based ● on Google Android operating systems and may vary depending on the user’s operating system. Applications and their functions may vary by country, ● region, or hardware specifications. Samsung is not liable for performance issues caused by third-party applications. Samsung is not liable for performance issues or ● incompatibilities caused by edited registry settings or modified operating system software. Attempting to customise the operating system may cause your device or applications to work improperly. You may upgrade your mobile device’s software by ● accessing www.samsung.com. Software, sound sources, wallpapers, images, and other ● contents provided in this device are licenced for limited use between Samsung and their respective owners. Extracting and using these materials for commercial or other purposes is an infringement of copyright laws. Samsung is not liable for such copyright infringement by the user. Please keep this manual for future reference. ● Instructional icons Before you start, familiarise yourself with the icons you will see in this manual: Warning—situations that could cause injury to yourself or others Caution—situations that could cause damage to your device or other equipment Note—notes, usage tips, or additional information Using this manual 4 ► Refer to—pages with related information; for example: ► p.12 (represents “see page 12”) → Followed by—the order of options or menus you must select to perform a step; for example: Open the application list and select Settings → Wireless and networks (represents Settings, followed by Wireless and networks) Copyright Copyright © 2012 Samsung Electronics This user manual is protected under international copyright laws. No part of this user manual may be reproduced, distributed, translated, or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording, or storing in any information storage and retrieval system, without the prior written permission of Samsung Electronics. Trademarks SAMSUNG and the SAMSUNG logo are registered ● trademarks of Samsung Electronics. The Android logo, Google Search ● ™ , Google Maps ™ , Google Mail ™ , YouTube ™ , Android Market ™ , and Google Talk ™ are trademarks of Google, Inc. Bluetooth ● ® is a registered trademark of the Bluetooth SIG, Inc. worldwide. Oracle and Java are registered trademarks of Oracle and/ ● or its affiliates. Other names may be trademarks of their respective owners. Using this manual 5 Windows Media Player ● ® is a registered trademark of Microsoft Corporation. Wi-Fi ● ® , Wi-Fi Protected Setup ™ , Wi-Fi Direct ™ , Wi-Fi CERTIFIED ™ , and the Wi-Fi logo are registered trademarks of the Wi-Fi Alliance. DivX ● ® , DivX Certified ® , and associated logos are trademarks of Rovi Corporation or its subsidiaries and are used under licence. All other trademarks and copyrights are the property of ● their respective owners. Using this manual 6 ABOUT DIVX VIDEO DivX ® is a digital video format created by DivX, LLC, a subsidiary of Rovi Corporation. This is an official DivX Certified ® device that plays DivX video. Visit www.divx.com for more information and software tools to convert your files into DivX videos. DivX Certified ® to play DivX ® video up to HD 720p, including premium content ABOUT DIVX VIDEO-ON-DEMAND This DivX Certified ® device must be registered in order to play purchased DivX Video-on-Demand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device setup menu. Go to vod.divx.com for more information on how to complete your registration. Contents 7 Assembling ....................................................... 11 Unpack ................................................................................................. 11 Charge the battery .......................................................................... 12 Insert a memory card (optional) ................................................ 14 Getting started ................................................. 17 Turn your device on and off .........…

Text truncated - open the document above for the full version.

SAMSUNG ELECTRONICS AMERICA, INC. American QA Lab 19 Chapin Rd, Building D. Pine Brook, NJ 07058 Date: July 30, 2012 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: A3LGTP8110 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, SAMSUNG ELECTRONICS CO.,LTD. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give SAMSUNG ELECTRONICS CO.,LTD. temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram PERMANENT 2 Operational Description 3 External Photos 4 Internal Photos 5 Test-Setup Photos SHORT-TERM 6 Users Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Peter Ra General Manager American QA Lab SAMSUNG Electronics America INC.

SAMSUNG ELECTRONICS CO., LTD 416,Maetan-3dong,Yeongtong-gu Suwon-si,Gyeonggi-do, 443-742 Korea Federal Communications Commission 7435 Oakland Mills Roaad Columbia, MD 21046 SUBJECT : Label Statement FCC ID : A3LGTP8110 Gentlemen: We hereby provide the label statement letter for the above-mentioned device by a new label statement policy instituted at the September 12, 2006, TCB-FCC Teleconference. The label statement is as follows: The FCC ID shown in the FCC ID label page will be readily visible when you take off rear top pannel of the device. The label is permanently lazer-marked and not easily erased from the device. This statement could not be included in the label. So we inform you of it through this letter. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely Yours, Seoung Ho Park Senior Manager SAMSUNG ELECTRONICS CO.,LTD Telecommunication Network Business Mobile Communication Division Regulatory Compliance Group. JULY 18, 2012

Samsung Electronics Co. Ltd. FCC ID: A3LGTP8110 Model: GT-P8110 External Photos EUT Type: Portable Tablet Computer Page 1 of 4 © 2012 PCTEST Engineering Laboratory Inc. EXTERNAL PHOTOGRAPHS Samsung Electronics Co. Ltd. FCC ID: A3LGTP8110 Model: GT-P8110 External Photos EUT Type: Portable Tablet Computer Page 2 of 4 © 2012 PCTEST Engineering Laboratory Inc. Samsung Electronics Co. Ltd. FCC ID: A3LGTP8110 Model: GT-P8110 External Photos EUT Type: Portable Tablet Computer Page 3 of 4 © 2012 PCTEST Engineering Laboratory Inc. Samsung Electronics Co. Ltd. FCC ID: A3LGTP8110 Model: GT-P8110 External Photos EUT Type: Portable Tablet Computer Page 4 of 4 © 2012 PCTEST Engineering Laboratory Inc.

CONFIDENTIAL Label and Location Sa msung TabletModel: FCC ID: GT-P8110 A3LGTP8110 Label: Location: Top Bac k plate of device Bottom FCC ID is printed insidethe reartoppanel

Samsung Electronics Co. Ltd. FCC ID: A3LGTP8110 Model: GT-P8110 Internal Photos EUT Type: Portable Tablet Computer Page 1 of 8 © 2012 PCTEST Engineering Laboratory Inc. INTERNAL PHOTOGRAPHS Samsung Electronics Co. Ltd. FCC ID: A3LGTP8110 Model: GT-P8110 Internal Photos EUT Type: Portable Tablet Computer Page 2 of 8 © 2012 PCTEST Engineering Laboratory Inc. Samsung Electronics Co. Ltd. FCC ID: A3LGTP8110 Model: GT-P8110 Internal Photos EUT Type: Portable Tablet Computer Page 3 of 8 © 2012 PCTEST Engineering Laboratory Inc. Samsung Electronics Co. Ltd. FCC ID: A3LGTP8110 Model: GT-P8110 Internal Photos EUT Type: Portable Tablet Computer Page 4 of 8 © 2012 PCTEST Engineering Laboratory Inc. Samsung Electronics Co. Ltd. FCC ID: A3LGTP8110 Model: GT-P8110 Internal Photos EUT Type: Portable Tablet Computer Page 5 of 8 © 2012 PCTEST Engineering Laboratory Inc. Samsung Electronics Co. Ltd. FCC ID: A3LGTP8110 Model: GT-P8110 Internal Photos EUT Type: Portable Tablet Computer Page 6 of 8 © 2012 PCTEST Engineering Laboratory Inc. Samsung Electronics Co. Ltd. FCC ID: A3LGTP8110 Model: GT-P8110 Internal Photos EUT Type: Portable Tablet Computer Page 7 of 8 © 2012 PCTEST Engineering Laboratory Inc. Samsung Electronics Co. Ltd. FCC ID: A3LGTP8110 Model: GT-P8110 Internal Photos EUT Type: Portable Tablet Computer Page 8 of 8 © 2012 PCTEST Engineering Laboratory Inc.

-1/13- E E E M M M C C C T T T E E E S S S T T T R R R E E E P P P O O O R R R T T T Project No. LBE20123552 Issue No. 0 Applicant Name of organizationSamsung Electronics Co., Ltd. Address 416, Maetan 3-dong, Yeongtong-gu, Suwon-si, Gyeonggi-do, 443-742, Republic of Korea Date of application July 10, 2012 EUT Type of device Class B personal computers and peripherals All other devices Equipment authorization Declaration of Conformity Certification Verification FCC ID A3LGTP8110 Kind of product Mobile Phone Model No. GT-P8110 Variant Model No. Refer to clause 4.6 Manufacturer SAMSUNG ELECTRONICS CO., LTD. 94-1, Imsu-dong, Gumi-si, Gyeongsangbuk-do, 730-722, Republic of Korea Applied Standards FCC Part 15, Subpart B, Class B / ANSI C63.4-2003 Test Period July 12, 2012 ~ July 13, 2012 Issue date July 23, 2012 Test result : Complied The equipment under test has found to be compliant with the applied standards. (Refer to the attached test result for more detail.) Tested by : Young-Jin Kim Reviewed by : Tae-Young Jang The test results in this report only apply to the tested sample. This report must not be reproduced, except in full, without written permission from CS & Environment center. 416, Maetan 3-dong, Yeongtong-gu, Suwon-si, Gyeonggi-so, 443-742, Republic of Korea Tel: 82 31 279 1750, Fax: 82 31 279 1745 Project No. : LBE20123552 Mobile Phone : GT-P8110 - 2/13- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-46/0 Table of contents 1. Report Information 1.1 Revision history ------------------------------------------------------------------------------------------------------------------ 3 2. Summary of test results 2.1 Emission ------------------------------------------------------------------------------------------------------------------------------- 3 3. General Information 3.1 Test facility ---------------------------------------------------------------------------------------------------------------------------- 3 4. Test Configuration 4.1 Test Peripherals ----------------------------------------------------------------------------------------------------------------- 4 4.2 EUT operating mode -------------------------------------------------------------------------------------------------------- 4 4.3 Details of Sampling ----------------------------------------------------------------------------------------------------------- 4 4.4 Used cable description ---------------------------------------------------------------------------------------------------- 5 4.5 Test arrangement -------------------------------------------------------------------------------------------------------------- 5 4.6 EUT Description ----------------------------------------------------------------------------------------------------------------- 6 4.7 Clock Frequencies ------------------------------------------------------------------------------------------------------------ 6 4.8 Test configuration and condition ---------------------------------------------------------------------------------- 6 4.9 Measurement uncertainty ---------------------------------------------------------------------------------------------- 7 5. Result of individual tests 5.1 Conducted disturbance --------------------------------------------------------------------------------------------------- 8 5.2 Radiated disturbance ------------------------------------------------------------------------------------------------------- 10 Project No. : LBE20123552 Mobile Phone : GT-P8110 - 3/13- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-46/0 1. Report Information 1.1 Revision history No Revised detailed information Issue 0 - LBE20123552 (SAMSUNG) 2. Summary of test results 1.1 Emission The EUT has been tested according to the following specifications: Applied Test type Applied standard Result Conducted Disturbance (Mains port) FCC Part 15 Subpart B / ANSI C63.4-2003 (Class B) Complied Radiated Disturbance Complied 3. General Information 3.1 Test facility The CS & Environment center is located on Samsung Electronics Co., Ltd. at 416, Maetan 3-dong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Republic of Korea. All testing are performed in Semi-anechoic chambers conforming to the site attenuation characteristics defined by ANSI C63.4, CISPR 22, 16-1 and 16-2. and Shielded rooms. The CS & Environment center is operated as testing laboratory in accordance with the requirements of ISO/IEC 17025:2005. Project No. : LBE20123552 Mobile Phone : GT-P8110 - 4/13- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-46/0 4. Test Setup configuration 4.1 Test Peripherals The cables used for these peripherals are either permanently attached by the peripheral manufacturer or coupled with an assigned cable as defined below. The following is a listing of the EUT and peripherals utilized during the performance of EMC test: Mark Description Model No. Serial No. Manufacturer / Trademark FCC ID / DoC A Mobile Phone GT-P8110 - SAMSUNG A3LGTP8110 B Headset EHS64AVFWE - SAMSUNG - C Data Cable ECB-DU1ABB - SAMSUNG - D Desktop PC DCME 8JBVSBX DELL DoC E LCD Monitor GH15LS N719HVELA11890LSAMSUNG DoC F Mouse MOARUO MS-S5-AR03-01 SAMSUNG DoC G Keyboard GP-K5000U 15000099 SAMSUNG DoC H Router 3CGS U08 AB/ 9XRQAC0024825 3COM DoC I Power Supply PW150 KA1203N03 AULT DoC 4.2 EUT operating mode To achieve compliance applied standard specification, the following mode(s) were made during compliance testing: Operating Mode 1 USB Mode (Data Communication) 4.3 Details of Sampling Customer selected, single unit. Project No. : LBE20123552 Mobile Phone : GT-P8110 - 5/13- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-46/0 4.4 Used cable description The EUT is configured, installed,…
