A3LGTS3778V850/1900 GSM/GPRS Phone with Bluetooth

User manual GT-S3778V This manual is a draft version using this manual This user manual has been specially designed to guide you through the functions and features of your mobile phone. To get started quickly, refer to introducing your mobile phone, assembling and preparing your mobile phone, and using basic functions. Instructional icons Before you start, familiarise yourself with the icons you will see in this manual: Warning—situations that could cause injury to yourself or others Caution—situations that could cause damage to your phone or other equipment Note—notes, usage tips, or additional information  Refer to—pages with related information; for example:  p. 12 (represents “see page 12”) Õ Followed by—the order of options or menus you must select to perform a step; for example: In Menu mode, select Messages Õ Create new message (represents Messages, followed by Create new message) [ ] Square brackets—phone keys; for example: [](represents the Power/ Menu exit key) < > Angled brackets—softkeys that control different functions at each screen; for example: <OK> (represents the OK softkey) Copyright information Rights to all technologies and products that comprise this device are the property of their respective owners:  Bluetooth ® is a registered trademark of the Bluetooth SIG, Inc. worldwide  Java™ is a trademark of Sun Microsystems, Inc.  Windows Media Player ® is a registered trademark of Microsoft Corporation. contents safety and usage information Safety warnings Safety precautions Important usage information introducing your mobile phone Unpack .. Phone layout Keys Display Icons assembling and preparing your mobile phone Install the SIM card and battery Charge the battery using basic functions Turn your phone on and off Access menus Customise your phone Use basic call functions Send and view messages Add and find contacts troubleshooting safety and usage information Comply with the following precautions to avoid dangerous or illegal situations and ensure peak performance of your mobile phone. Safety warnings Keep your phone away from small children and pets Keep your phone and all accessories out of the reach of small children or animals. Small parts may cause choking or serious injury if swallowed. Protect your hearing Listening to a headset at high volumes can damage your hearing. Use only the minimum volume setting necessary to hear your conversation or music. Install mobile phones and equipment with caution Ensure that any mobile phones or related equipment installed in your vehicle are securely mounted. Avoid placing your phone and accessories near or in an air bag deployment area. Improperly installed wireless equipment can cause serious injury when air bags inflate rapidly. Handle and dispose of batteries and chargers with care  Use only Samsung-approved batteries and chargers specifically designed for your phone. Incompatible batteries and chargers can cause serious injuries or damage to your phone.  Never dispose of batteries or phones in a fire. Follow all local regulations when disposing used batteries or phones.  Never place batteries or phones on or in heating devices, such as microwave ovens, stoves, or radiators. Batteries may explode when overheated.  Never crush or puncture the battery. Avoid exposing the battery to high external pressure, which can lead to an internal short circuit and overheating. Avoid interference with pacemakers Maintain a minimum of 15 cm (6 inches) between mobile phones and pacemakers to avoid potential interference, as recommended by manufacturers and the independent research group, Wireless Technology Research. If you have any reason to suspect that your phone is interfering with a pacemaker or other medical device, turn off the phone immediately and contact the manufacturer of the pacemaker or medical device for guidance. Turn off the phone in potentially explosive environments Do not use your phone at refuelling points (service stations) or near fuels or chemicals. Turn off your phone whenever directed by warning signs or instructions. Your phone could cause explosions or fire in and around fuel or chemical storage and transfer areas or blasting areas. Do not store or carry flammable liquids, gases, or explosive materials in the same compartment as the phone, its parts, or accessories. Reduce the risk of repetitive motion injuries When sending text messages or playing games on your phone, hold the phone with a relaxed grip, press the keys lightly, use special features that reduce the number of keys you have to press (such as templates and predictive text), and take frequent breaks. Safety precautions Drive safely at all times Avoid using your phone while driving and obey all regulations that restrict the use of mobile phones while driving. Use hands-free accessories to increase your safety when possible. Follow all safety warnings and regulations Comply with any regulations that restrict the use of a mobile phone in a certain area. Use only Samsung-approved accessories Using incompatible accessories may damage your phone or cause injury. Turn off the phone near medical equipment Your phone can interfere with medical equipment in hospitals or health care facilities. Follow all regulations, posted warnings, and directions from medical personnel. Turn off the phone or disable the wireless functions when in an aircraft Your phone can cause interference with aircraft equipment. Follow all airline regulations and turn off your phone or switch to a mode that disables the wireless functions when directed by airline personnel. Protect batteries and chargers from damage Avoid exposing batteries to very cold or very hot temperatures (below 0° C/32° F or above 45° C/ 113° F). Extreme temperatures can reduce the charging capacity and life of your batteries. Prevent batteries from contacting metal objects, as this can create a connection between the + and - terminals of your batteries and lead to temporary or permanent battery damage. Nev…

Text truncated - open the document above for the full version.

SAMSUNG ELECTRONICS CO., LTD 416,Maetan-3dong,Yeongtong-gu Suwon-si,Gyeonggi-do, 443-742 Korea Federal Communicat ions Commission 7435 Oakland Mills Road Colum bia, MD 21046 SUBJECT : Label Statement FCC ID : A3L Gentlemen: We hereby provide the label statement letter for the above-mentioned phone by a new label statement policy instituted at the September 12, 2006, TCB-FCC Teleconference. The label statement is as follows: The FCC ID shown in the FCC ID label page will be readily visible at the time of purchase because the phone will be marketed without the battery installed. This statement could not be included in the label. So we inform you of it through this letter. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely Yours, Seoung Ho Park Senior Manager SAMSUNG ELECTRONICS CO.,LTD Telecommunication Network Business Mobile Communication Division Regulatory Compliance Group.

Date: June 29, 2011 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: A3LGTS3778V To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematics Block Diagram Operational Description Antenna Specification Parts List Tune-Up Procedure Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondence during certification review process cannot be granted as confidential documents and such information will be available for public review once the grant of equipment authorization is issued. Best Regards Sang Kyung (Peter), Ra/ General Manager Samsung Electronics CO. LTD TEL: 310-900-5250 FAX: 310-537-5500 E-mail: [email protected]

1 Lucy Tsai From:권기중 <[email protected]> Sent: 2011年7月11日星期一 上午 4:17 To: Lucy Tsai; Kyungyong Kim - TCB Cc: 김덕수; 장우태; 전자메일; 장재동; 정은화; 전봉환; 김정구; 이지혜 Subject: [SAMSUNG] A3LGTS3778V Attachments: GT-S3778V_ANT distance.pdf; FCC SAR Test Report (GT-S3778V).pdf Importance: High Dear CCS TCB, . Please find revised documents. This is 1st e-mail. . Q#1: Please provide additional external photo to indicate BT and GSM antenna location. -> Attached .[Lucy] The antenna indicated in attached antenna location file looks different from the internal photo exhibits. Please check again. Q#2: According to the operational description, the capability of the RF module equipped with may also support 3G and WIFI. And in page 1 and 5 of the block diagram, they indicated a WIFI module is equipped with. Please confirm again this mobile phone only supports GSM/GPRS and BT and at the same time, please clarify the way used to disable these transmitters is by software or hardware. -> This model is not support WLAN and document is revised. This model does not support 3G in USA Bands by S/W. Q#3: SAR value indicated in page 7 of user manual does not agree with SAR report. Please correct. -> Removed . JBP report Q#4: The FCC ID indicated on the report and setup photo does not agree with this filing. Please correct. -> Revised . DSS report Q#5: The antenna gain indicated in page 3 does not agree with antenna specification. Please check and correct. -> Revised . SAR report Q#6: This is GPRS Class 12 phone and based on the conducted output power table in page 21, the highest output power is in 1TX slot in cellular and PCS bands. Looking to test result table in page 24 and page 26, 1TX slot was not investigated. Please explain. Besides, according to the test plots, the current test result was measured with display down configuration. Please conduct test with display up to the phantom as well. -> Revised, all data have been attached. . Part 22/24 Report Q#7: The antenna specification does not cover 850MHz band. Please check. -> Revised . Q#8: Please take a look to page 15- 16 for ERP and EIRP test results and address following issues. - Based on the conducted output power documented in page 14, the output power in 850 band is about 32.5dBm. Compared to the ERP value, the ERP value seems to be too low. - Please provide a formula to explain how the ERP/EIPR value come out. -> The ERP/EIRP value comes out like this. Ex. Ch.128) the test level is -10.98. We measured 26 dBm at Tx terminal withS/G, and we can get -11.50 dBm at S/A (include tx antenna gain -0.67). And we can calculate that 26dBm is -10.83 dBm [= -11.50 + (-0.67)] at S/A. Finally, the tested level "-10.98" is 25.85 dBm (0.385 W). 2 . Q#9: Please take look to band edge test. In page 42-43, the detector setting is average detector with LgAV and in page 56-57, the setting is average detector with Power average. Please explain why different setting is used. -> Revised . Thank you Best Regards Kijoong Kwon ------- Original Message ------- Sender : [email protected]<[email protected]> Date : 2011-07-08 13:30 (GMT+09:00) Title : Fw: SAMSUNG Electronics Co., Ltd., //A3LGTS3778V //AN11T0491 Hello Mr. Kim, Please refer to the TCB comment on the above reference application and respond your answer to TCB Reviewer directly. Thanks and Best Regards, K.Y ----- Forwarded by KyungYong Kim/SEO/ULI on 07/08/2011 01:24 PM ----- From: "Lucy Tsai" <[email protected]> To: <[email protected]>, "Amy Lie" <[email protected]>, "Thu Chan" <[email protected]> Cc: "Lucy Tsai" <[email protected]> Date: 07/08/2011 01:47 AM Subject: FW: SAMSUNG Electronics Co., Ltd., //A3LGTS3778V //AN11T0491 Hi, Amy, Thu and KY, Please address following issues. Q#1: Please provide additional external photo to indicate BT and GSM antenna location. Q#2: According to the operational description, the capability of the RF module equipped with may also support 3G and WIFI. And in page 1 and 5 of the block diagram, they indicated a WIFI module is equipped with. Please confirm again this mobile phone only supports GSM/GPRS and BT and at the same time, please clarify the way used to disable these transmitters is by software or hardware. Q#3: SAR value indicated in page 7 of user manual does not agree with SAR report. Please correct. JBP report Q#4: The FCC ID indicated on the report and setup photo does not agree with this filing. Please correct. DSS report Q#5: The antenna gain indicated in page 3 does not agree with antenna specification. Please check and correct. SAR report Q#6: This is GPRS Class 12 phone and based on the conducted output power table in page 21, the highest output power is in 1TX slot in cellular and PCS bands. Looking to test result table in page 24 and page 26, 1TX slot was not investigated. Please explain. 3 Besides, according to the test plots, the current test result was measured with display down configuration. Please conduct test with display up to the phantom as well. Part 22/24 Report Q#7: The antenna specification does not cover 850MHz band. Please check. Q#8: Please take a look to page 15- 16 for ERP and EIRP test results and address following issues. - Based on the conducted output power documented in page 14, the output power in 850 band is about 32.5dBm. Compared to the ERP value, the ERP value seems to be too low. - Please provide a formula to explain how the ERP/EIPR value come out. Q#9: Please take look to band edge test. In page 42-43, the detector setting is average detector with LgAV and in page 56-57, the setting is average detector with Power average. Please explain why different setting is used. Best Regards, Lucy - For more information about UL, its Marks, and its services for EMC, quality registrations and product certifications for global markets, please access our web sites at http://www.ul.com and http://www.ul-asia.com or contact your local sales representative. -- ********* Internet E-mail Confidentiality Disclaimer ********** This e-mail me…

Text truncated - open the document above for the full version.

MOBILE PHONE MODEL : GT-S3778V FCC ID : A3LGTS3778V SSN : -S3778VGSMH RATED : 3.7 V 1000 mA MADE IN KOREA BY SAMSUNG ; The label is placed inside the battery compartment 5 MOBILE PHONE MODEL : GT-S3778V FCC ID : A3LGTS3778V SSN : -S3778VGSMH RATED : 3.7 V 1000 mA MADE IN KOREA BY SAMSUNG ; The label is placed inside the battery compartment 5

BT antenna * Placement of each antenna BT antenna Main antenna * Antenna distance 65mm BT 5mm ANT. 40mm 75mm * Antenna pattern GSM850GSM900DCS1800PCS1900WCDMA Band IIWCDMA Band VWCDMA Band V

FCC ID: A3LGTS3778VReport Number: FI-130-S1 Page : 1 of 29 SAMSUNG Electronics C0. LTD EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Only Issue Date : Jun.02, 2011 SAMSUNG ELECTRONICS Co., Ltd., Regulatory Compliance Group IT R&D Center 416, Maetan-3dong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea 443-742 TEST REPORT ON SAR Model Tested: GT-S3778V FCC ID (Requested): A3LGTS3778V Job No: FI-130 Report No: FI-130-S1 - Abstract – This document reports on SAR Tests carried out in accordance with FCC/OET Bulletin 65, Supplement C(June 2001). Prepared By JG KIM - Test Engineer Authorized By JD JANG - Technical Manager FCC ID: A3LGTS3778VReport Number: FI-130-S1 Page : 2 of 29 SAMSUNG Electronics C0. LTD EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Only Issue Date : Jun.02, 2011 Contents 1. GENERAL INFORMATION .............................................................................. 3 2. DESCRIPTION OF DEVICE ............................................................................ 3 3. DESCRIPTION OF TEST EQUIPMENT .......................................................... 4 3.1 SAR Measurement Setup ............................................................................................................... 4 3.2 E-field Probe ................................................................................................................................... 5 3.3 Phantom.......................................................................................................................................... 7 3.4 Brain Simulating Mixture Characterization .................................................................................... 9 3.5 Device Holder for Transmitters........................................................................................................ 9 3.6 Validation Dipole ........................................................................................................................... 10 3.7 Equipment Calibration................................................................................................................... 11 4. SAR MEASUREMENT PROCEDURE ........................................................... 12 5. DESCRIPTION OF TEST POSITION ............................................................ 13 5.1 SAM Phantom Shape.................................................................................................................... 13 5.2 “cheek” Position ............................................................................................................................ 13 5.3 “tilted” Position .............................................................................................................................. 15 5.4 Body Holster/Belt Clip Configurations ........................................................................................... 16 6. MEASUREMENT UNCERTAINTY ................................................................. 18 7. SYSTEM VERIFICATION............................................................................... 20 7.1 Tissue Verification ......................................................................................................................... 20 7.2 Test System Validation .................................................................................................................. 20 8. SAR MEASUREMENT RESULTS.................................................................. 21 8.1 GSM850 Head SAR Results ......................................................................................................... 23 8.2 GPRS850 Body SAR Results(Without Holster)............................................................................. 24 8.3 GSM1900 Head SAR Results ....................................................................................................... 25 8.4 GPRS1900 Body SAR Results(Without Holster)........................................................................... 26 9. CONCLUSION ............................................................................................... 27 10. REFERENCES ............................................................................................. 28 APPENDIX A SAR Definition ........................................................................... 30 APPENDIX B Probe Calibration Process ........................................................ 31 APPENDIX C ANSI/IEEE C95.1 – 1992 RF EXPOSURE LIMITS.................. 32 APPENDIX D The Validation Measurements .................................................. 33 APPENDIX E Plots of The SAR Measurements.............................................. 38 APPENDIX F Probe Calibration ...................................................................... 65 APPENDIX G Calibration of The Validation Dipole ......................................... 77 FCC ID: A3LGTS3778VReport Number: FI-130-S1 Page : 3 of 29 SAMSUNG Electronics C0. LTD EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Only Issue Date : Jun.02, 2011 1. GENERAL INFORMATION Test Dates : May.31, 2011 Manufacturer : SAMSUNG ELECTRONICS Co., Ltd. Address : 416 Maetan3-Dong, Suwon City, Korea Test Standard : §2.1093; FCC/OET Bulletin 65, Supplement C(June 2001) FCC Classification : Licensed Transmitter Held to Ear (PCE) Tested for : FCC/TCB Certification 2. DESCRIPTION OF DEVICE Test Sample : 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Only Model Number : GT-S3778V Serial Number : Identical prototype (S/N : # FI-130-A) Tx Freq. Range : 824.2 ~ 848.8 MHz (GSM850) 1850.20 ~ 1909.80 MHz (GSM1900) Rx Freq. Range : 869.2 ~ 893.8 MHz (GSM850) 1930.20 ~ 1989.80 MHz (GSM1900) Antenna Manufacturer : SKYCROSS Model No.: B110070 GPRS Class 12 GSM Class B DTM Multislots N/A Antenna Dimensions : 48.29 X 12.93 X 3.58 (mm) Separation distance between Main and Bluetooth antenna : 65 mm FCC ID: A3LGTS3778VReport Number: FI-130-S1 Page : 4 of 29 SAMSUNG Electronics C0. LT…

Text truncated - open the document above for the full version.

SAMSUNG ELECTRONICS Co., Ltd., Regulatory Compliance Group IT R&D Center 416 Maetan3-Dong, Yeongtong-gu, Suwon city, Gyeonggi-Do, Korea 443-742 FCC CFR47 PART 22 & 24 SUBPART CERTIFICATION REPORT Model Tested : GT-S3778V FCC ID(Requested) : A3LGTS3778V Report No : FI-130-R1 Job No : FI-130 Date issued : June 24, 2011 - Abstract - All measurement reported herein accordance with FCC Rules, 47CFR Part2, Part22, Part24. Prepared By KJ KWON – Test Engineer Authorized By WT JANG – Technical Manager Report Number : FI-130-R1 2 of 58 TABLE OF CONTENT MEASUREMENT REPORT Page 1. FCC CERTIFICATION INFORMATION .....................................................................3 1.1. §2.1033 General Information .........................................................................3 2. INTRODUCTION .......................................................................................................4 2.1. General..........................................................................................................4 3. MEASURING INSTRUMENT CALIBRATION ...........................................................5 4. TEST EQUIPMENT LIST...........................................................................................6 5. DESCRIPTION OF TESTS ........................................................................................7 5.1. Effective Radiated Power / Equivalent Isotropic Radiated Power ..................7 5.2. Radiated Spurious & Harmonic Emission ......................................................8 5.3. Peak-Average Ratio .......................................................................................9 5.4. Occupied Bandwidth ....................................................................................10 5.5. Spurious and Harmonic Emission at Antenna Terminal................................10 5.5.1. Occupied Bandwidth Emission Limits ..............................................10 5.5.2. Conducted Spurious Emission .........................................................12 5.6. Frequency Stability / Temperature Variation .................................................13 6. TEST DATA .............................................................................................................14 6.1. Conducted Output Power.............................................................................14 6.2. Effective Radiated Power (E.R.P.)................................................................15 6.3. Equivalent Isotropic Radiated Power (E.I.R.P.) ............................................16 6.4. GSM850 Radiated Spurious & Harmonic measurement ..............................17 6.5. GSM1900 Radiated Spurious & Harmonic measurement ............................18 6.6. GSM850 Radiated Spurious & Harmonic Conversion Table ........................19 6.7. GSM1900 Radiated Spurious & Harmonic Conversion Table ......................20 6.8. Frequency Stability.......................................................................................21 6.8.1. GSM850 Frequency Stability Table ..................................................21 6.8.2. GSM850 Frequency Stability Graph.................................................22 6.8.3. GSM1900 Frequency Stability Table ................................................24 6.8.4. GSM1900 Frequency Stability Graph...............................................25 7. CONCLUSION.........................................................................................................27 8. TEST PLOTS...........................................................................................................28 Report Number : FI-130-R1 3 of 58 MEASUREMENT REPORT 1. FCC Certification Information The following information is in accordance with FCC Rules, 47CFR Part2, Subpart J, Sections 2.1033 – 2.1055. 1.1. §2.1033 General Information • Applicant Name : SAMSUNG ELECTRONICS CO., LTD. • Address : 416 Maetan3-Dong, Yeongtong-gu, Suwon City Gyeonggi-Do, Korea 443-742 • FCC ID : A3LGTS3778V • Model : GT-S3778V • Quantity : Quantity production is planned • Emission Designators : 249KGXW(GSM850) 251KGXW(GSM1900) • Tx Freq. Range : 824.2 - 848.8MHz (GSM850) 1850.2MHz - 1909.8MHz (GSM1900) • Rx Freq. Range : 869.2 - 893.8 MHz (GSM850) 1930.2MHz - 1989.8MHz (GSM1900) • Max. Power Rating : 0.385 W ERP GSM850 (25.85 dBm) 0.867 W EIRP GSM1900 (29.38 dBm) • FCC Classification(s) : PCS Licensed Portable Tx Held to Ear (PCE) • Equipment (EUT) Type : 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Only • Frequency Tolerance : ±0.00025% (2.5ppm) • FCC Rule Part(s) : §24(E), §22(H), §2. • Dates of Test : June 22-24, 2011 • Place of Test : SAMSUNG Lab, • Test Report S/N : FI-130-R1 Report Number : FI-130-R1 4 of 58 2. INTRODUCTION 2.1. General These measurement test were conducted at SAMSUNG ELECTRONICS CO., LTD(SUWON). The site address is 416 Maetan3-Dong, Yeongtong-gu, Suwon City, Gyeonggi-Do, Korea 443-742 The site have 1 Fully-anechoic chamber and measurement facility. Measurement Procedure The radiated and spurious measurements were made Fully-anechoic chamber at a 3-meter test range (see Figure2). The equipment under testing was placed on a Non-conducted turntable 3- meters from the receive antenna. The receive antenna height and turntable rotations were adjusted for the highest reading on the receive spectrum analyzer. The substitution antenna will replace the EUT antenna it the same position and in vertical polarization. The frequency of the signal generator shall be set to the frequencies that were measured on the EUT. The test antenna shall be raised and lowered, if necessary, to ensure that the maximum signal is still being received. The signal generator, output level, shall be adjusted until an equal or a known related level to what was measured from the EUT is obtained in the spectrum analyzer. This level was recorded. For readings above 1 GHz, the above procedure is repeated using horn antennas and the difference between the gai…

Text truncated - open the document above for the full version.

SAMSUNG FCC ID: A3LGTS3778V 850/1900 GSM/GPRS Phone with Bluetooth and EDGE Rx Only

Test Setup Photographs 1.5 cm 1.5 cm
