A3LGTS6310TPortable Handset

User manual GT-S6310T Draft 6.1 2012-09-08 Only for Approval using this manual This user manual has been specially designed to guide you through the functions and features of your mobile phone. To get started quickly, refer to “introducing your mobile phone, Instructional icons Before you start, familiarise yourself with the icons you will see in this manual: Warning—situations that could cause injury to yourself or others Caution—situations that could cause damage to your phone or other equipment Note—notes, usage tips, or additional information Refer to—pages with related information; for example: p. 12 (represents “see page 12”) Õ Followed by—the order of options or menus you must select to perform a step; for example: In Menu mode, select Messages Õ Create new message (represents Messages, followed by Create new message) [ ] Square brackets—phone keys; for example: [ ](represents the Power/ Menu exit key) < > Angled brackets—softkeys that control different functions at each screen; for example: <OK> (represents the OK softkey) Copyright information Rights to all technologies and products that comprise this device are the property of their respective owners:  Bluetooth ® is a registered trademark of the Bluetooth SIG, Inc. worldwide  Java™ is a trademark of Sun Microsystems, Inc.  Windows Media Player ® is a registered trademark of Microsoft Corporation. contents safety and usage information Safety warnings Safety precautions Important usage information introducing your mobile phone Unpack .. Phone layout Keys Display Icons assembling and preparing your mobile phone Install the SIM card and battery Charge the battery using basic functions Turn your phone on and off Access menus Customise your phone Use basic call functions Send and view messages Add and find contacts troubleshooting safety and usage information Comply with the following precautions to avoid dangerous or illegal situations and ensure peak performance of your mobile phone. Safety warnings Keep your phone away from small children and pets Keep your phone and all accessories out of the reach of small children or animals. Small parts may cause choking or serious injury if swallowed. Protect your hearing Excessive exposure to sound at high volumes can cause hearing damage. Always turn the volume down before plugging the earphones into an audio source and use only the minimum volume setting necessary to hear your conversation or music. Install mobile phones and equipment with caution Ensure that any mobile phones or related equipment installed in your vehicle are securely mounted. Avoid placing your phone and accessories near or in an air bag deployment area. Improperly installed wireless equipment can cause serious injury when air bags inflate rapidly. Handle and dispose of batteries and chargers with care  Use only Samsung-approved batteries and chargers specifically designed for your phone. Incompatible batteries and chargers can cause serious injuries or damage to your phone.  Never dispose of batteries or phones in a fire. Follow all local regulations when disposing used batteries or phones.  Never place batteries or phones on or in heating devices, such as microwave ovens, stoves, or radiators. Batteries may explode when overheated.  Never crush or puncture the battery. Avoid exposing the battery to high external pressure, which can lead to an internal short circuit and overheating. Avoid interference with pacemakers Maintain a minimum of 15 cm (6 inches) between mobile phones and pacemakers to avoid potential interference, as recommended by manufacturers and the independent research group, Wireless Technology Research. If you have any reason to suspect that your phone is interfering with a pacemaker or other medical device, turn off the phone immediately and contact the manufacturer of the pacemaker or medical device for guidance. Turn off the phone in potentially explosive environments Do not use your phone at refuelling points (service stations) or near fuels or chemicals. Turn off your phone whenever directed by warning signs or instructions. Your phone could cause explosions or fire in and around fuel or chemical storage and transfer areas or blasting areas. Do not store or carry flammable liquids, gases, or explosive materials in the same compartment as the phone, its parts, or accessories. Reduce the risk of repetitive motion injuries When sending text messages or playing games on your phone, hold the phone with a relaxed grip, press the keys lightly, use special features that reduce the number of keys you have to press (such as templates and predictive text), and take frequent breaks. Safety precautions Drive safely at all times Avoid using your phone while driving and obey all regulations that restrict the use of mobile phones while driving. Use hands-free accessories to increase your safety when possible. Follow all safety warnings and regulations Comply with any regulations that restrict the use of a mobile phone in a certain area. Use only Samsung-approved accessories Using incompatible accessories may damage your phone or cause injury. Turn off the phone near medical equipment Your phone can interfere with medical equipment in hospitals or health care facilities. Follow all regulations, posted warnings, and directions from medical personnel. Turn off the phone or disable the wireless functions when in an aircraft Your phone can cause interference with aircraft equipment. Follow all airline regulations and turn off your phone or switch to a mode that disables the wireless functions when directed by airline personnel. Protect batteries and chargers from damage Avoid exposing batteries to very cold or very hot temperatures (below 0° C/32° F or above 45° C/ 113° F). Extreme temperatures can reduce the charging capacity and life of your batteries. Prevent batteries from contacting metal objects, as this can create a connection between the + and - terminals of your batteries and lead to temporary or perma…

Text truncated - open the document above for the full version.

April 19, 2013 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: A3L GTS6310T To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematics Block Diagram Operational Description Antenna Specification Parts List Tune-Up Procedure Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondence during certification review process cannot be granted as confidential documents and such information will be available for public review once the grant of equipment authorization is issued. Best Regards Sang Kyung (Peter), Ra/ General Manager Samsung Electronics CO. LTD TEL: 310-900-5250 FAX: 310-537-5500 E-mail: [email protected]

Date: April 1, 2013 UL LLC Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize UL LLC to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL LLC on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing UL LLC as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Sang Kyung (Peter), RA Head of QA Lab (General Manager) Samsung Electronics America, Inc 19 Chapin Rd, Bldg. D, Pine Brook, NJ 07058

SAMSUNG ELECTRONICS CO., LTD 129,Samsung-ro,Yeongtong-gu Suwon-city,Gyeonggi-do, 443-742 Korea April 19, 2013 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT : Label Statement FCC ID : A3LGT S6310T Gentlemen: We hereby provide the label statement letter for the above-mentioned device by a new label statement policy instituted at the September 12, 2006, TCB-FCC Teleconference. The label statement is as follows: The FCC ID shown in the FCC ID label page will be readily visible at the time of purchase because the device will be marketed without the battery installed. The label is permanently attached by acrylic glue and not easily removed from the device. This statement could not be included in the label. So we inform you of it through this letter. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely Yours, Seoung Ho Park Senior Manager SAMSUNG ELECTRONICS CO.,LTD Telecommunication Network Business Mobile Communication Division Regulatory Compliance Group.

dLabel and Location Samsung Phone Model: GT-S6310T FCC ID: A3LGTS6310T Label: Location: Top Back of device Bottom Phone: Label is placed inside of the battery compartment. Label 실제 back View를 photo로 추가바랍니다. ( The FCC ID label is located in the battery compartment. While the battery cover is installed when the unit is shipped from the factory, the battery is never installed prior to sale, so the user must remove the cover in order to install the battery and operate the device. At this time the FCC ID is readily visible to the user. The label is permanently attached by acrylic glue and not easily removed from the device.”

Report No.: HCTA1304FS06 FCC ID: A3LGTS6310T Date of Issue: Apr.15, 2013 HCT CO., LTD. 105-1, Jangam-ri, Majang-myeon, Icheon-si,Gyeonggi-do,Korea 467-811 TEL: +82 31 645 6300 FAX: +82 31 645 6401 www.hct.co.kr 2 of 142 Table of Contents 1. INTRODUCTION .......................................................................................................................................... ４ 2. TEST METHODOLOGY ............................................................................................................................... ５ 3. DESCRIPTION OF DEVICE ......................................................................................................................... ６ 4. DESCRIPTION OF TEST EQUIPMENT ...................................................................................................... ７ 5. SAR MEASUREMENT PROCEDURE ..................................................................................................... １４ 6. DESCRIPTION OF TEST POSITION ....................................................................................................... １６ 7. MEASUREMENT UNCERTAINTY ........................................................................................................... １８ 8. ANSI/ IEEE C95.1 - 1992 RF EXPOSURE LIMITS ................................................................................. １９ 9. SAR SYSTEM VALIDATION .................................................................................................................... ２０ 10. SYSTEM VERIFICATION ....................................................................................................................... ２１ 11. RF CONDUCTED POWER MEASUREMENT ....................................................................................... ２３ 12. SAR Test configuration & Antenna Information ................................................................................ ３２ 13. SAR TEST DATA SUMMARY ................................................................................................................ ３３ 13.1 Measurement Results (GSM850 Head SAR) ................................................................................ ３３ 13.2 Measurement Results (GSM1900 Head SAR) .............................................................................. ３４ 13.3 Measurement Results (WCDMA850 Head SAR) .......................................................................... ３５ 13.4 Measurement Results (802.11b/g/n Head SAR) ........................................................................... ３６ 13.5 Measurement Results (GSM850 Hotspot SAR) ............................................................................ ３７ 13.6 Measurement Results (GSM1900 Hotspot SAR) .......................................................................... ３８ 13.7 Measurement Results (WCDMA850 Hotspot SAR) ...................................................................... ３９ 13.8 Measurement Results (802.11b/g/n Hotspot SAR) ....................................................................... ４０ 13.9 Measurement Results (Body-worn SAR) ...................................................................................... ４１ 14. SAR Measurement Variability and Uncertainty.................................................................................. ４２ 15. SAR Summation Scenario ................................................................................................................... ４３ 16. CONCLUSION ........................................................................................................................................ ４７ 17. REFERENCES ....................................................................................................................................... ４８ Attachment 1. – SAR Test Plots ................................................................................................................ ４９ Attachment 2. – Dipole Verification Plots ................................................................................................. ９９ Attachment 3. – Probe Calibration Data ................................................................................................ １０６ Attachment 4. – Dipole Calibration Data ............................................................................................... １１８ Report No.: HCTA1304FS06 FCC ID: A3LGTS6310T Date of Issue: Apr.15, 2013 HCT CO., LTD. 105-1, Jangam-ri, Majang-myeon, Icheon-si,Gyeonggi-do,Korea 467-811 TEL: +82 31 645 6300 FAX: +82 31 645 6401 www.hct.co.kr 3 of 142 Version Rev DATE DESCRIPTION Apr. 15, 2013 First Approval Report Report No.: HCTA1304FS06 FCC ID: A3LGTS6310T Date of Issue: Apr.15, 2013 HCT CO., LTD. 105-1, Jangam-ri, Majang-myeon, Icheon-si,Gyeonggi-do,Korea 467-811 TEL: +82 31 645 6300 FAX: +82 31 645 6401 www.hct.co.kr 4 of 142 1. INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radio frequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices. The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. 1992 by the Institute of Electrical and Electronics Engineers, Inc., New York, New York 10017. The measurement procedure described in IEEE/ANSI C95.3-1992 Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields - RF and Microwave is used for guidance in measuring SAR due to the RF radiation exposure from the Equipment Under Test (EUT). These criteria for SAR evaluation are similar to those recommended by the National Council on Radiation Protection and Measurements (NCRP) in Biologi…

Text truncated - open the document above for the full version.

Report No.: HCTA1304FS06 FCC ID: A3LGTS6310T Date of Issue: Apr.15, 2013 HCT CO., LTD. 105-1, Jangam-ri, Majang-myeon, Icheon-si,Gyeonggi-do,Korea 467-811 TEL: +82 31 645 6300 FAX: +82 31 645 6401 www.hct.co.kr 91 of 142 Test Laboratory: HCT CO., LTD EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth v3.0+EDR, WLAN 2.4GHz and Hotsport and EDGE Rx only Liquid Temperature: 21.2 °C Ambient Temperature: 21.4 °C Test Date: Apr. 08, 2013 Plot NO. 3 DUT: GT-S6310T; Type: bar; Serial: FK-082-A Communication System: GSM 850; Frequency: 848.8 MHz;Duty Cycle: 1:8.3 Medium parameters used (interpolated): f = 848.8 MHz; σ = 0.93 mho/m; ε r = 40.3; ρ = 1000 kg/m 3 Phantom section: Left Section ; Measurement SW: DASY4, V4.7 Build 71; Postprocessing SW: SEMCAD, V1.8 Build 184 DASY4 Configuration: - Probe: ET3DV6 - SN1605; ConvF(6.64, 6.64, 6.64); Calibrated: 2012-04-26 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn652; Calibrated: 2013-03-21 - Phantom: 835/900 Phamtom ; Type: SAM Left Touch 251/Area Scan (61x91x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 0.829 mW/g Left Touch 251/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 5.76 V/m; Power Drift = -0.024 dB Peak SAR (extrapolated) = 1.22 W/kg SAR(1 g) = 0.766 mW/g; SAR(10 g) = 0.500 mW/g Maximum value of SAR (measured) = 0.815 mW/g Report No.: HCTA1304FS06 FCC ID: A3LGTS6310T Date of Issue: Apr.15, 2013 HCT CO., LTD. 105-1, Jangam-ri, Majang-myeon, Icheon-si,Gyeonggi-do,Korea 467-811 TEL: +82 31 645 6300 FAX: +82 31 645 6401 www.hct.co.kr 92 of 142 Test Laboratory: HCT CO., LTD EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth v3.0+EDR, WLAN 2.4GHz and Hotsport and EDGE Rx only Liquid Temperature: 21.3 °C Ambient Temperature: 21.5 °C Test Date: Apr. 09, 2013 Plot NO. 9 DUT: GT-S6310T; Type: bar; Serial: FK-082-A Communication System: GSM 1900; Frequency: 1880 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 1880 MHz; σ = 1.39 mho/m; ε r = 39.9; ρ = 1000 kg/m 3 Phantom section: Right Section ; Measurement SW: DASY4, V4.7 Build 71; Postprocessing SW: SEMCAD, V1.8 Build 184 DASY4 Configuration: - Probe: ET3DV6 - SN1605; ConvF(5.26, 5.26, 5.26); Calibrated: 2012-04-26 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn652; Calibrated: 2013-03-21 - Phantom: 800/900 Phantom; Type: SAM Right Touch 661/Area Scan (61x91x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 0.730 mW/g Right Touch 661/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 12.0 V/m; Power Drift = 0.182 dB Peak SAR (extrapolated) = 0.964 W/kg SAR(1 g) = 0.648 mW/g; SAR(10 g) = 0.403 mW/g Maximum value of SAR (measured) = 0.685 mW/g Report No.: HCTA1304FS06 FCC ID: A3LGTS6310T Date of Issue: Apr.15, 2013 HCT CO., LTD. 105-1, Jangam-ri, Majang-myeon, Icheon-si,Gyeonggi-do,Korea 467-811 TEL: +82 31 645 6300 FAX: +82 31 645 6401 www.hct.co.kr 93 of 142 Test Laboratory: HCT CO., LTD EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth v3.0+EDR, WLAN 2.4GHz and Hotsport and EDGE Rx only Liquid Temperature: 21.2 °C Ambient Temperature: 21.4 °C Test Date: Apr. 08, 2013 Plot NO. 11 DUT: GT-S6310T; Type: bar; Serial: FK-082-A Communication System: WCDMA850; Frequency: 836.6 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 836.6 MHz; σ = 0.921 mho/m; ε r = 40.4; ρ = 1000 kg/m 3 Phantom section: Left Section ; Measurement SW: DASY4, V4.7 Build 71; Postprocessing SW: SEMCAD, V1.8 Build 184 DASY4 Configuration: - Probe: ET3DV6 - SN1605; ConvF(6.64, 6.64, 6.64); Calibrated: 2012-04-26 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn652; Calibrated: 2013-03-21 - Phantom: 835/900 Phamtom ; Type: SAM Left Touch 4183/Area Scan (61x91x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 0.523 mW/g Left Touch 4183/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 5.62 V/m; Power Drift = -0.196 dB Peak SAR (extrapolated) = 0.885 W/kg SAR(1 g) = 0.509 mW/g; SAR(10 g) = 0.316 mW/g Maximum value of SAR (measured) = 0.562 mW/g Report No.: HCTA1304FS06 FCC ID: A3LGTS6310T Date of Issue: Apr.15, 2013 HCT CO., LTD. 105-1, Jangam-ri, Majang-myeon, Icheon-si,Gyeonggi-do,Korea 467-811 TEL: +82 31 645 6300 FAX: +82 31 645 6401 www.hct.co.kr 94 of 142 Test Laboratory: HCT CO., LTD EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth v3.0+EDR, WLAN 2.4GHz and Hotsport and EDGE Rx only Liquid Temperature: 21.3 °C Ambient Temperature: 21.5 °C Test Date: Apr. 09, 2013 Plot NO. 15 DUT: GT-S6310T; Type: bar; Serial: FK-082-A Communication System: 2450MHz FCC; Frequency: 2437 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 2437 MHz; σ = 1.79 mho/m; ε r = 37.7; ρ = 1000 kg/m 3 Phantom section: Left Section ; Measurement SW: DASY4, V4.7 Build 71; Postprocessing SW: SEMCAD, V1.8 Build 184 DASY4 Configuration: - Probe: ET3DV6 - SN1605; ConvF(4.59, 4.59, 4.59); Calibrated: 2012-04-26 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn652; Calibrated: 2013-03-21 - Phantom: 1800/1900 Phantom; Type: SAM Left Touch 6ch 1Mbps/Area Scan (71x111x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (interpolated) = 0.380 mW/g Left Touch 6ch 1Mbps/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 7.51 V/m; Power Drift = 0.163 dB Peak SAR (extrapolated) = 0.874 W/kg SAR(1 g) = 0.361 mW/g; SAR(10 g) = 0.164 mW/g Maximum value of SAR (measured) = 0.404 mW/g Report No.: HCTA1304FS06 FCC ID: A3LGTS6310T Date of Issue: Apr.15, 2013 HCT CO., LTD. 105-1, Jangam-ri, Majang-myeon, Icheon-si,Gyeonggi-do,Korea 467-811 TEL: +82 31 645 6300 FAX: +82 31 645 6401 www.hct.co.kr 95 of 142 Test Laboratory: HCT CO., LTD EUT Type: 850/1900 GSM/GPRS Phone with Bluetooth v3.0+EDR, WLAN 2.4GHz and Hotsport and EDGE Rx only Liquid Temperature: 21.2 °C Ambient Temperature: 21.4 °C Test Date: Apr. 08, 2013 Separation Di…

Text truncated - open the document above for the full version.

FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1304FR12 Date of Issue: April 15, 2013 EUT Type: 850/1900 GSM/GPRS and 850 WCDMA/HSDPA/HSUPA Phone with Bluetooth v3.0+EDR, WLAN 2.4GHz and Hotspot and EDGE Rx only FCC ID: A3LGTS6310T Page 2 of 43 Version TEST REPORT NO. DATE DESCRIPTION HCTR1304FR12 April 15, 2013 First Approval Report FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1304FR12 Date of Issue: April 15, 2013 EUT Type: 850/1900 GSM/GPRS and 850 WCDMA/HSDPA/HSUPA Phone with Bluetooth v3.0+EDR, WLAN 2.4GHz and Hotspot and EDGE Rx only FCC ID: A3LGTS6310T Page 3 of 43 Table of Contents 1. GENERAL INFORMATION ........................................................................................................................... 4 2. INTRODUCTION ........................................................................................................................................... 5 2.1. EUT DESCRIPTION ............................................................................................................................ 5 2.2. MEASURING INSTRUMENT CALIBRATION .................................................................................... 5 2.3. TEST FACILITY .................................................................................................................................. 5 3. DESCRIPTION OF TESTS ........................................................................................................................... 6 3.1 ERP/EIRP RADIATED POWER AND RADIATED SPURIOUS EMISSIONS ..................................... 6 3.2 PEAK- TO- AVERAGE RATIO ............................................................................................................ 6 3.3 OCCUPIED BANDWIDTH. .................................................................................................................. 7 3.4 SPURIOUS AND HARMONIC EMISSIONS AT ANTENNA TERMINAL. ........................................... 8 3.5 FREQUENCY STABILITY / VARIATION OF AMBIENT TEMPERATURE ........................................ 9 4. LIST OF TEST EQUIPMENT ...................................................................................................................... 10 5. SUMMARY OF TEST RESULTS ................................................................................................................. 11 6. SAMPLE CALCULATION ........................................................................................................................... 12 7. TEST DATA ................................................................................................................................................. 13 7.1 EFFECTIVE RADIATED POWER OUTPUT (GSM / WCDMA) ........................................................ 13 7.2 EQUIVALENT ISOTROPIC RADIATED POWER (GSM) ................................................................. 14 7.3 RADIATED SPURIOUS EMISSIONS ................................................................................................ 15 7.3.1 RADIATED SPURIOUS EMISSIONS (GSM850) .................................................................... 15 7.3.2 RADIATED SPURIOUS EMISSIONS (GSM1900) .................................................................. 16 7.3.3 RADIATED SPURIOUS EMISSIONS (WCDMA850) .............................................................. 17 7.4 PEAK-TO-AVERAGE RATIO ............................................................................................................ 18 7.5 OCCUPIED BANDWIDTH ................................................................................................................. 18 7.6 CONDUCTED SPURIOUS EMISSIONS ........................................................................................... 19 7.6.1 BAND EDGE ............................................................................................................................ 19 7.7 FREQUENCY STABILITY / VARIATION OF AMBIENT TEMPERATURE ...................................... 20 7.7.1 FREQUENCY STABILITY (GSM850) ..................................................................................... 20 7.7.2 FREQUENCY STABILITY (GSM1900) ................................................................................... 21 7.7.3 FREQUENCY STABILITY (WCDMA850) ............................................................................... 22 8. TEST PLOTS ............................................................................................................................................... 23 FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1304FR12 Date of Issue: April 15, 2013 EUT Type: 850/1900 GSM/GPRS and 850 WCDMA/HSDPA/HSUPA Phone with Bluetooth v3.0+EDR, WLAN 2.4GHz and Hotspot and EDGE Rx only FCC ID: A3LGTS6310T Page 4 of 43 MEASUREMENT REPORT 1. GENERAL INFORMATION Applicant Name: SAMSUNG Electronics Co., Ltd. Address: 129, Samsung-ro, Yeongtong-gu Suwon-si, Gyeonggi-do, 443-742 Rep. of Korea FCC ID: A3LGTS6310T Application Type: Certification FCC Classification: Licensed Portable Transmitter Held to Ear (PCE) FCC Rule Part(s): §22, §24, §2 EUT Type: 850/1900 GSM/GPRS and 850 WCDMA/HSDPA/HSUPA Phone with Bluetooth v3.0+EDR, WLAN 2.4GHz and Hotspot and EDGE Rx only FCC Model(s): GT-S6310T Tx Frequency: 824.20 - 848.80 MHz (GSM850), 826.40 - 846.60 MHz (WCDMA850), 1 850.20 - 1 909.80 MHz (GSM1900) Rx Frequency: 869.20 - 893.80 MHz (GSM850), 871.40 - 891.60 (WCDMA850), 1 930.20 - 1 989.80 MHz (GSM1900) Max. RF Output Power: 0.497 W ERP GSM850 (26.96 dBm)/ 0.728 W EIRP GSM1900 (28.62 dBm)/ 0.087 W ERP WCDMA850 (19.41 dBm) Emission Designator(s): 247 KGXW (GSM850)/ 248 KGXW (GSM1900)/ 4M19F9W (WCDMA850) Date(s) of Tests: April 05, 2013 ~ April 15, 2013 Antenna Specification Manufacturer: GALTRONICS Co, Ltd Antenna type: In…

Text truncated - open the document above for the full version.
