A3LGTS7392Portable Handset

User manual GT-S7392 Draft 6.1 2012-07-20 Only for Approval using this manual This user manual has been specially designed to guide you through the functions and features of your mobile phone. To get started quickly, refer to “introducing your mobile phone, Instructional icons Before you start, familiarise yourself with the icons you will see in this manual: Warning—situations that could cause injury to yourself or others Caution—situations that could cause damage to your phone or other equipment Note—notes, usage tips, or additional information Refer to— (represents “see page 12”) Õ Followed by—the order of options or menus you must select to perform a step; for example: In Menu mode, select Messages Õ Create new message (represents Messages, followed by Create new message) [ ] Square brackets—phone keys; for example: [](represents the Power/ Menu exit key) < > Angled brackets—softkeys that control different functions at each screen; for example: <OK> (represents the OK softkey) Copyright information Rights to all technologies and products that comprise this device are the property of their respective owners:  Bluetooth ® is a registered trademark of the Bluetooth SIG, Inc. worldwide  Java™ is a trademark of Sun Microsystems, Inc.  Windows Media Player ® is a registered trademark of Microsoft Corporation. contents safety and usage information Safety warnings Safety precautions Important usage information introducing your mobile phone Unpack .. Phone layout Keys Display Icons assembling and preparing your mobile phone Install the SIM card and battery Charge the battery using basic functions Turn your phone on and off Access menus Customise your phone Use basic call functions Send and view messages Add and find contacts troubleshooting safety and usage information Comply with the following precautions to avoid dangerous or illegal situations and ensure peak performance of your mobile phone. Safety warnings Keep your phone away from small children and pets Keep your phone and all accessories out of the reach of small children or animals. Small parts may cause choking or serious injury if swallowed. Protect your hearing Excessive exposure to sound at high volumes can cause hearing damage. Always turn the volume down before plugging the earphones into an audio source and use only the minimum volume setting necessary to hear your conversation or music. Install mobile phones and equipment with caution Ensure that any mobile phones or related equipment installed in your vehicle are securely mounted. Avoid placing your phone and accessories near or in an air bag deployment area. Improperly installed wireless equipment can cause serious injury when air bags inflate rapidly. Handle and dispose of batteries and chargers with care  Use only Samsung-approved batteries and chargers specifically designed for your phone. Incompatible batteries and chargers can cause serious injuries or damage to your phone.  Never dispose of batteries or phones in a fire. Follow all local regulations when disposing used batteries or phones.  Never place batteries or phones on or in heating devices, such as microwave ovens, stoves, or radiators. Batteries may explode when overheated.  Never crush or puncture the battery. Avoid exposing the battery to high external pressure, which can lead to an internal short circuit and overheating. Avoid interference with pacemakers Maintain a minimum of 15 cm (6 inches) between mobile phones and pacemakers to avoid potential interference, as recommended by manufacturers and the independent research group, Wireless Technology Research. If you have any reason to suspect that your phone is interfering with a pacemaker or other medical device, turn off the phone immediately and contact the manufacturer of the pacemaker or medical device for guidance. Turn off the phone in potentially explosive environments Do not use your phone at refuelling points (service stations) or near fuels or chemicals. Turn off your phone whenever directed by warning signs or instructions. Your phone could cause explosions or fire in and around fuel or chemical storage and transfer areas or blasting areas. Do not store or carry flammable liquids, gases, or explosive materials in the same compartment as the phone, its parts, or accessories. Reduce the risk of repetitive motion injuries When sending text messages or playing games on your phone, hold the phone with a relaxed grip, press the keys lightly, use special features that reduce the number of keys you have to press (such as templates and predictive text), and take frequent breaks. Safety precautions Drive safely at all times Avoid using your phone while driving and obey all regulations that restrict the use of mobile phones while driving. Use hands-free accessories to increase your safety when possible. Follow all safety warnings and regulations Comply with any regulations that restrict the use of a mobile phone in a certain area. Use only Samsung-approved accessories Using incompatible accessories may damage your phone or cause injury. Turn off the phone near medical equipment Your phone can interfere with medical equipment in hospitals or health care facilities. Follow all regulations, posted warnings, and directions from medical personnel. Turn off the phone or disable the wireless functions when in an aircraft Your phone can cause interference with aircraft equipment. Follow all airline regulations and turn off your phone or switch to a mode that disables the wireless functions when directed by airline personnel. Protect batteries and chargers from damage Avoid exposing batteries to very cold or very hot temperatures (below 0° C/32° F or above 45° C/ 113° F). Extreme temperatures can reduce the charging capacity and life of your batteries. Prevent batteries from contacting metal objects, as this can create a connection between the + and - terminals of your batteries and lead to temporary or permanent battery damage. Never use a damaged charger or …

Text truncated - open the document above for the full version.

SAMSUNG ELECTRONICS AMERICA, INC. American QA Lab 18600 Broadwick St. Rancho Dominguez, CA 90220 Date: August 22, 2013 FCC ID: A3LGTS7392 We attest about Bluetooth AFH mode as below. a. The minimum number of hopping channel in AFH mode is 20 channels. b. The output power do not transmit over than 125 mW c. The channel separation is based upon 2/3 of 20 dB channel bandwidth. This model is compliance with the Bluetooth Core Spec v4.0 with LE as listed in the operational Description. Should you have any further concerns, please l et me know. Sang Kyung (Peter), Ra General Manager Samsung Electronics CO. LTD TEL: +1-310-900-5250 E-mail: [email protected]

August 22, 2013 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: A3LGTS7392 To Whom It May Concern: Pursuant to the provisi ons of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematics Block Diagram Operational Description Antenna Specification Parts List Tune-Up Procedure Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondence during certification review process cannot be granted as confidential documents and such information will be available for public review once the grant of equipment authorization is issued. Best Regards Sang Kyung (Peter), Ra/ General Manager Samsung Electronics CO. LTD TEL: 310-900-5250 FAX: 310-537-5500 E-mail: [email protected]

Date: April 1, 2013 UL LLC Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize UL LLC to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL LLC on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing UL LLC as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Sang Kyung (Peter), RA Head of QA Lab (General Manager) Samsung Electronics America, Inc 19 Chapin Rd, Bldg. D, Pine Brook, NJ 07058

Label and Location Samsung Phone Model: GT-S7392 FCC ID: A3LGTS7392 Label: Location: Top Back of device Bottom Phone: Label is placed inside of the battery compartment.

August, 22, 2 013 SAMSUNG ELECTRONICS CO., LTD 129,Samsung-ro,Yeongtong-gu Suw on- si,Gyeo nggi-do, 443-742 Korea Federal Commu nic atio ns Commission 7435 Oakland Mills R oaad Columbia, MD 21046 SU BJECT : La bel Statement FCC ID : A3 LGTS7392 Gentl emen: We hereby pro vide the label statement letter for the above-mentio ned devi ce by a new label statement p olicy instituted at the Septemb er 1 2, 2006, TCB -FCC Te leco nference. The label statement is as follows: The FCC ID shown in the FCC ID label page will be rea dily visi ble at the time of purchase bec ause the de vice w ill be marketed wi thout the ba ttery installed. The label is permanently att ached by acrylic glue and not easily re mov ed from the device. This st atement could not be included in the label. So we inf orm you of it thr ough th is le tter. Should you have any questions or comments concerning the above, plea se contact the undersigned. Sincerely Your s, Seoung Ho Pa rk Se nior Manager SAMSUNG ELECTRONICS CO.,LT D Teleco mmu nicati on Netw ork Bu sine ss Mobile Communic ati on Division Regulatory Compliance Group.

FCCPT.15.247 TEST REPORT FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1308FR30-1 Date of Issue: August 27, 2013 EUT Type: 850/1900 GSM/GPRS Phone with BT v4.0(LE) , 802.11b/g/n and EDGE Rx only, Hotspot FCC ID: A3LGTS7392 Page 2 of 72 Version TEST REPORT NO. DATE DESCRIPTION HCTR1308FR30 August 22, 2013 - First Approval Report HCTR1308FR30-1 August 27, 2013 - Retest the Conducted Spurious Emissions Using 100 kHz RBW FCCPT.15.247 TEST REPORT FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1308FR30-1 Date of Issue: August 27, 2013 EUT Type: 850/1900 GSM/GPRS Phone with BT v4.0(LE) , 802.11b/g/n and EDGE Rx only, Hotspot FCC ID: A3LGTS7392 Page 3 of 72 Table of Contents 1.GENERAL INFORMATION ....................................................................................................................... 4 2.EUT DESCRIPTION .................................................................................................................................. 4 3.TEST METHODOLOGY ............................................................................................................................ 5 3.1EUT CONFIGURATION ............................................................................................................. 5 3.2EUT EXERCISE ......................................................................................................................... 5 3.3GENERAL TEST PROCEDURES ............................................................................................. 5 3.4DESCRIPTION OF TEST MODES ............................................................................................ 6 4.INSTRUMENT CALIBRATION .................................................................................................................. 6 5.FACILITIES AND ACCREDITATIONS ...................................................................................................... 6 5.1FACILITIES ................................................................................................................................ 6 5.2EQUIPMENT .............................................................................................................................. 6 6.ANTENNA REQUIREMENTS.................................................................................................................... 6 7.SUMMARY OF TEST RESULTS ............................................................................................................... 7 8.FCC PART 15.247 REQUIREMENTS ....................................................................................................... 8 8.1PEAK POWER ........................................................................................................................... 8 8.2BAND EDGES .......................................................................................................................... 15 8.3FREQUENCY SEPARATION / OCCUPIED BANDWIDTH (99% BW) ................................... 23 8.4NUMBER OF HOPPING FREQUENCY .................................................................................. 32 8.5TIME OF OCCUPANCY (DWELL TIME) ................................................................................. 36 8.6SPURIOUS EMISSIONS .......................................................................................................... 43 8.6.1CONDUCTED SPURIOUS EMISSIONS .......................................................................... 43 8.6.2RADIATED SPURIOUS EMISSIONS .............................................................................. 52 8.6.3RADIATED RESTRICTED BAND EDGES ...................................................................... 63 8.7POWERLINE CONDUCTED EMISSIONS ............................................................................... 67 9.LIST OF TEST EQUIPMENT ................................................................................................................... 72 FCCPT.15.247 TEST REPORT FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1308FR30-1 Date of Issue: August 27, 2013 EUT Type: 850/1900 GSM/GPRS Phone with BT v4.0(LE) , 802.11b/g/n and EDGE Rx only, Hotspot FCC ID: A3LGTS7392 Page 4 of 72 1. GENERAL INFORMATION Applicant: SAMSUNG Electronics Co., Ltd. Address: 129, Samsung-ro, Yeongtong-gu Suwon-si, Gyeonggi-do, 443-742 Rep. of Korea FCC ID: A3LGTS7392 EUT Type: 850/1900 GSM/GPRS Phone with BT v4.0(LE) , 802.11b/g/n and EDGE Rx only, Hotspot Model name(s): GT-S7392 Date(s) of Tests: August 12, 2013 ~ August 22, 2013 Place of Tests: HCT Co., Ltd. 105-1, Jangam-ri , Majang-Myeon, Icheon-si, Kyunggi-Do, 467-811, KOREA. (IC Recognition No. : 5944A-3) 2. EUT DESCRIPTION EUT Type 850/1900 GSM/GPRS Phone with BT v4.0(LE) , 802.11b/g/n and EDGE Rx only, Hotspot FCC Model Name GT-S7392 Power Supply DC 3.8 V Battery type Li-ion Battery(Standard) Frequency Range 2402 MHz - 2480 MHz (Bluetooth) Transmit Power 9.228 dBm (8.371 mW) BT Operating Mode Normal, EDR, AFH Modulation Type GFSK(Normal), π/4DQPSK and 8DPSK(EDR) Modulation Technique FHSS Number of Channels 79Channels, Minimum 20 Channels(AFH) Antenna Specification Antenna type: Capacitor Antenna Peak Gain : 0.13 dBi 15.247 Requirements for Bluetooth transmitter ▪ This Bluetooth module has been tested by a Bluetooth Qualification Lab, and we confirm the following: 1) This system is hopping pseudo-randomly. 2) Each frequency is used equally on the average by each transmitter. 3) The receiver input bandwidths that match the hopping channel bandwidths of their corresponding transmitters 4) The receiver shifts frequencies in synchronization with the transmitted signals. ▪ 15.247(g): The system, consisting of both the transmitter and the receiver, must be designed to comply with all of the regulations in this Section 15.247 should the transmitter be presented with a continuous data (or information) stream. ▪ 15.247(h): The coordination of frequency hopping systems in any other manner …
