A3LHP2777ATWireless Internet Appliance - Refrigerator (DSS)

Samsung Electronics Co Ltd

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Nov 26, 2002
Application Purpose: Original Equipment
Date of Application: Nov 26, 2002
Equipment Note: Wireless Internet Appliance - Refrigerator (DSS)
Frequency Range: 2412.00000000 - 2462.00000000
Company: Samsung Electronics Co Ltd
Country: United States

Documents & Files

Select a file to view

Operational Description

RF Exposure Info

↗

Schematics

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Attestation Statements

February 4, 2002 Federal Communications Commission Authorization and Evaluation Div. Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: We, the undersigned, hereby authorize PCTEST Engineering Laboratory Inc., to act as agent on behalf of all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, Inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988,21 U.S.C.862. Sincerely, Wallace Oh Engineering Manager Samsun Electronics America

Block Diagram

TV Cable A/V Door PhoneLANWAN Ext Int Internal External (2) Residential Gateway Internet (3) Access Station DVD (VTR) (1) SMPS (1) SMPS AC 115V

Cover Letter(s)

November 26, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: SAMSUNG Electronics Co., Ltd. FCC ID: A3LHP2777AT Gentlemen: Submitted herewith, on behalf of SAMSUNG Electronics Co., Ltd., is an application for Certification of the HomePAD Refrigerator. Attached are the applicant’s Letter of Authorization, measurement report test data and plots, FCC ID label and location, test setup photographs, internal and external photographs, block diagram, schematics, operational description, the user's manual, and the SAR Measurement Report. Should you have any questions or comments concerning the above, please contact the undersigned. cc: SAMSUNG Electronics Co., Ltd.

Cover Letter(s)

January 17, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Martin Perrine SUBJECT: Samsung Electronics Co., Ltd. FCC ID: A3LHP2777AT 731 Confirmation No.: TC635579 Request for Tech. Info.: 12/27/2002 Correspondence Ref. Num.: 6322 Dear Martin: Transmitted herewith, on behalf of Samsung Electronics Co., Ltd., is an amendment provided in response to the request for technical information dated December 27, 2002. 1. Please find the attachment containing the new block diagram showing all LO frequencies. 2. Please find attached the complete schematic diagrams. 3. Please find attached the updated exhibits with all references to the HomePAD removed. Also, please find attached the internal, external, and test set-up photographs with all the HomePAD Photos removed. 4. This is to confirm that the output power is EIRP. The radiated power was measured on our OATS at a 3 meter distance using the signal substitution method. The 731 and the grant conditions have been revised accordingly. 5. Please find attached the updated MPE report showing the calculated RF exposure at 20 cm. 6. The submitted plastic case is the prototype. In production, the upper case will have two holes for the vertical antennas to stand upright. They will protrude 0.500 inches above the upper case. The antennas are permanently attached. If you have any further questions, please do not hesitate to contact us. cc: Samsung Electronics Co., Ltd.

External Photos

ID Label/Location Info

© 2002 PCTEST Lab SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE)

Internal Photos

© 2002 PCTEST Lab SAMSUNG FCC ID: A3LHP2777AT HomePAD Refrigerator (Model: HP2777AT) © 2002 PCTEST Lab SAMSUNG FCC ID: A3LHP2777AT HomePAD Refrigerator (Model: HP2777AT) © 2002 PCTEST Lab SAMSUNG FCC ID: A3LHP2777AT HomePAD Refrigerator (Model: HP2777AT) © 2002 PCTEST Lab SAMSUNG FCC ID: A3LHP2777AT HomePAD Refrigerator (Model: HP2777AT) © 2002 PCTEST Lab SAMSUNG FCC ID: A3LHP2777AT HomePAD Refrigerator (Model: HP2777AT) © 2002 PCTEST Lab SAMSUNG FCC ID: A3LHP2777AT HomePAD Refrigerator (Model: HP2777AT) © 2002 PCTEST Lab SAMSUNG FCC ID: A3LHP2777AT HomePAD Refrigerator (Model: HP2777AT) © 2002 PCTEST Lab SAMSUNG FCC ID: A3LHP2777AT HomePAD Refrigerator (Model: HP2777AT) © 2002 PCTEST Lab SAMSUNG FCC ID: A3LHP2777AT HomePAD Refrigerator (Model: HP2777AT) © 2002 PCTEST Lab SAMSUNG FCC ID: A3LHP2777AT HomePAD Refrigerator (Model: HP2777AT) © 2002 PCTEST Lab SAMSUNG FCC ID: A3LHP2777AT HomePAD Refrigerator (Model: HP2777AT) © 2002 PCTEST Lab SAMSUNG FCC ID: A3LHP2777AT HomePAD Refrigerator (Model: HP2777AT)

Internal Photos

RF Exposure Info

RF Exposure Measurement 1. Introduction 2.4 GHz frequency band is regarded specially as a dangerous band for its heating harmfulness to the human body. That’s why microwave oven is operating in this frequency band. The manufacturer whose product is working in this frequency band is obligatory to prove the harmfulness of this product. In this document, we try to prove the safety of radiation harmfulness to the human body. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1210 is followed. The Gain of the antenna used in this product is measured by power meter. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits For Occupational / Control Exposures 300-1500 ... ... F/300 6 1500-100,000 ... ... 5 6 (B) Limits For General Population / Uncontrolled Exposure 300-1500 ... ... F/1500 6 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. Friis Formula Friis transmission formula: Pd = (Pout*G) / (4πr 2 ) Where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale π = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm2. If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Ref.: David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11.133) 4. EUT Operating Condition Software provided by the client enabled the EUT to transmit and receive data at lowest, middle, and highest channel individually. 5. Climate Condition The temperature and related humidity: 22 ̊C and 78% RH 6. Test Results (Antenna Configuration) 6.1 Output Power into Antenna & RF Exposure Distance: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Minimum Allowable Distance from Skin (cm) 1 2412 0.063 2.2396

RF Exposure Info

PCTEST MPE REPORT FCC CERTIFICATION REVIEWED BY: QUALITY MANAGER TEST REPORT S/N: 15.220620323a.A3L TEST DATES: June 27, 2002 EUT TYPE: HOMEPAD REFRIGERATOR FCC ID: A3LHP2777AT PAGE 1 OF 2 © 2002 PCTEST Engineering Laboratory, Inc. RF Exposure Evaluation - Maximum Permissible Exposure (MPE) 1. Introduction 2.4 GHz frequency band is regarded specially as a dangerous band for its heating harmfulness to the human body. That’s why microwave oven is operating in this frequency band. The manufacturer whose product is working in this frequency band is obligatory to prove the harmfulness of this product. In this document, we try to prove the safety of radiation harmfulness to the human body. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1210 is followed. The Gain of the antenna used in this product is measured by power meter. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits For Occupational / Control Exposures 300-1500 ... ... F/300 6 1500-100,000 ... ... 5 6 (B) Limits For General Population / Uncontrolled Exposure 300-1500 ... ... F/1500 6 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. Friis Formula Friis transmission formula: Pd = (Pout*G) / (4pr 2 ) Where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale p = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm2. If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. PCTEST MPE REPORT FCC CERTIFICATION REVIEWED BY: QUALITY MANAGER TEST REPORT S/N: 15.220620323a.A3L TEST DATES: June 27, 2002 EUT TYPE: HOMEPAD REFRIGERATOR FCC ID: A3LHP2777AT PAGE 2 OF 2 © 2002 PCTEST Engineering Laboratory, Inc. Ref.: David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11.133) 4. EUT Operating Condition Software provided by the client enabled the EUT to transmit and receive data at lowest, middle, and highest channel individually. 5. Climate Condition The temperature and related humidity: 22°C and 78% RH 6. Test Results (Antenna Configuration) 6.1 Output Power into Antenna & RF Exposure Distance: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) 1 824.70 247 0.0501 7. Conclusion The device meets the mobile 20cm. separation distance as specified in Section 2.1091 of the FCC Rules and an appropriate RF exposure compliance statement will be placed in the users manual.

Test Report

Project No. : LBE020770 Page 1 of 11 Project No. : LBE020770 Product : Refrigerator Model No. : RH2777A T Date of test:September 12 - 16, 2002 Issued Date:September 18, 2002 Tested by: No Cheon, PARK / Test Engineer Reviewed by: Yang Soo, KIM / Manager of EMC Lab. Authorized by: Kyu Baek, CHUNG / Chief of EMC Lab. SAMSUNG ELECTRONICS Co., Ltd. EMC Test Laborator y 416 Maetan-3 Dong, Paldal-Ku, Suwon City, Kyungki-Do, Korea,442-742 Tel. : 81-31-200-2185 Fax. : 81-31-200-2189 This reports shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. EMC TEST REPORT According to FCC Part 15 Subpart B Project No. : LBE020770 Page 2 of 11 TABLE OF CONTENTS 1. General Information 1.1 Description for Equipment Authorization 1.2 Measuring Standards 1.3 Manufacturer Information 1.4 EUT Description 1.5 Operation Environment 1.6 Measuring instrument setup 1.7 Test facility 1.8 Accreditation and Listing 2. Accuracy of Measurement 2.1 AC Powerline Conducted Emission Measurement 2.2 Radiated emission Measurement 3. Test Results 3.1 AC Powerline Conducted Emission Measurement 3.2 Radiated emission Measurement 4. List of Test Instrument This reports shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Project No. : LBE020770 Page 3 of 11 1. General Information 1.1 Description for Equipment Authorization Type of Device :Refrigerator Kind of Equipment Authorization : Verification 1.2 Measuring Standards Applied Standard :FCC Part 15 Subpart B Measuring Procedure :ANSI C63.4-1992 1.3 Manufacturer Information Name of manufacturer :SAMSUNG ELECTRONICS Co., Ltd. Address of manufacturer :416 Maetan-3 Dong, Paldal-Ku, Suwon City, Kyungki-Do, Korea,442-742 1.4 EUT Description Operating Frequency :133MHz, 33MHz, 48MHz, 24.57MHz Power supply :120V, 60Hz 1.5 Operation Environment Temperature [C] : Humidity [%] : This reports shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. ConductionRadiation 21 44 22 48 Project No. : LBE020770 Page 4 of 11 1.6 Measuring instrument setup The explanation of measuring instrument setup when respective function is used in any frequency band is as following: Frequency Band InstrumentDetectorResolutionVideo [MHz]functionBandwidthBandwidth 0.45 to 30EMI Test receiverQuasi-Peak9kHz- Spectrum analyzerPeak100kHz1MHz EMI Test receiverQuasi-Peak120kHz- Above 1000EMI Test receiverAverage1MHz- 1.7 Test facility The EMI/EMS measurement facilities used to collect the tested data are located at 416 Maetan 3 Dong, Paldal-Ku, Suwon City, Kyungki Do, Korea. The sites are constructed in conformance with the requirements of ANSI C63.4 and CISPR 16-1 & 16-2. In addition, the test facilities are listed with Federal Communications Commission (Registration Number:98856, Anechoic Chamber #1). Also, SAMSUNG Electronics Co.,Ltd is accredited by Korea Laboratory Accreditation Scheme(KOLAS) which signed the International Laboratory Accreditation Cooperation (ILAC) Mutual Recognition Arrangement (MRA) for the above test item(s) and test method(s). 1.8 Accreditation and Listing This reports shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 30 to 1000 LAB CODE 200447-0 Acc. No.13294 R-1221,C-1095 No.189 Reg. No.98856 Reg. No. KR0004 App. No.001 H9354285 Reg. No. 124 Project No. : LBE020770 Page 5 of 11 2. Accuracy of Measurement The measurement uncertainties stated were calculated in accordance with the requirements of NIST Technical Note 1297 and NIS 81 (1994). 2.1 AC Powerline Conducted Emission Measurement Probability Distribution9 kHz-150 kHz 150 kHz-30 MHz Receiver specification Rectangular1.01 LISN coupling specification Rectangular1.41.4 Cable and input attenuator calibration Normal (k=2)0.30.3 Mismatch Receiver VRC: G l = 0.03 LISN VRC: G g = 0.8 (9 kHz) 0.2 (30 MHz) U-shaped0.20.05 Uncertainty limits 20Log (1+ G l G g ) System repeatability (previous assessment of Standard0.20.35 s(q k ) from 10 repeats, 1 reading on EUT) deviation Repeatability of EUT -- Combined standard uncertainty u c (y) normal 1.041.06 Expanded uncertainty U= 2u c (y) normal (k = 2)2.092.13 2.2 Radiated emission Measurement Probability Distribution Ambient signals-- Antenna factor calibrationNormal (k=2)+1-1 Cable loss calibration Normal (k=2)+0.5-0.5 Receiver specification Rectangular+1.5-1.5 Antenna directivity Rectangular+0.5-0 Antenna factor variation with height Rectangular+2-2 Antenna phase center variation Rectangular+0-0 Antenna factor frequency interpolation Rectangular+0.25-0.25 Measurement distance variation Rectangular+0.6-0.6 Site imperfections Rectangular+2-2 Mismatch Receiver VRC: G l = 0.2 Antenna VRC: G g = 0.67 (Bi) 0.3 (Lp) U-shaped+1.1-1.25 Uncertainty limits 20Log(1+ G l G g ) System repeatability (previous assessment Standard+0.5-0.5 of s(qk) from 5 repeats, 1 reading on EUT) deviation Repeatability of EUT -- Combined standard uncertainty u c (y) Normal 2.192.21 Expanded uncertainty U= 2u c (y) Normal (k=2)4.394.43 This reports shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Contribution Uncertainty(+/- dB) Contribution 3m Uncertainty(+/- dB) Project No. : LBE020770 Page 6 of 11 3. Test Results 3.1 AC Powerline Conducted Emission Measurement 1) Reference Rule and Specification FCC Part 15, Subpart B Section 15.107(a) 2) Test Procedure 2-1) All input terminals are terminated in the proper impedance. The output ports are connected to the cable provided with the device and the ending port are terminated in the proper impedance. 2-2) Connect the EUT's AC line cord to the EUT port of LISN. Configuration the EUT system in accordance with ANSI C63.4-1992. 2-3) Using a calibrated coaxial cable, the Test Receiver is connected to the measuring port of the LISN for EUT. 2-4) Activates the EUT system. 2-5) The network allows the measuring receiver to be switched between the neutral to groun…

Text truncated - open the document above for the full version.

Test Report

PCTEST PT. 15.247 REPORT EVALUATION REPORT Reviewed By: Quality Manager Test Report S/N: 15.220620323.A3L Test Dates: June 27, 2002 EUT Type: HomePAD Refrigerator FCC ID: A3LHP2777A T Page 1 of 31 PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE SAMSUNG Electronics Co., Ltd. Dates of Tests: June 27, 2002 #271, Oseon-Dong, Gwangsan-Gu Test Report S/N: 15.220620323.A3L Gwangju-City, 506-723, KOREA Test Site: PCTEST Lab, Columbia MD Attention: Mr. Gi-Hyeong Lee FCC ID A3LHP2777AT APPLICANT SAMSUNG Electronics Co., Ltd. FCC Rule Part(s): § 15.247; ANSI C-63.4 (1992) Classification: Digital Transmission System (DTS) Max Output Power: 0.063 W / 18.0 dBm Conducted (Refrigerator-Base) Method/System: Direct Sequence System (DSS) Equipment Type: HomePAD Refrigerator Frequency Range: 2412 — 2462 MHz Model No(s).: HP2777AT This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C-63-4. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 220620323.A3L PCTEST PT. 15.247 REPORT EVALUATION REPORT Reviewed By: Quality Manager Test Report 15.220620323.A3L Test Dates: June 27, 2002 EUT Type: HomePAD Refrigerator FCC ID: A3LHP2777A T Page 2 of 31 TABLE OF CONTENTS APPENDIX A – COVER LETTER APPENDIX B - ATTESTATION STATEMENT APPENDIX C - TEST REPORT SCOPE 3 INTRODUCTION (SITE DESCRIPTION) 4 PRODUCT INFORMATION 5 DESCRIPTION OF TESTS A. CONDUCTED EMISSIONS 6 B. RADIATED EMISSIONS 7 C. RESTRICTED BANDS 8 D. ANTENNA REQUIREMENT 9 E. DIRECT SEQUENCE BANDWIDTH 10 F. MAXIMUM PEAK POWER OUTPUT 11 G. POWER DENSITY 12 - 13 RADIATED MEASUREMENTS (FUNDAMENTAL & HARMONICS) 17 - 25 RADIATED MEASUREMENTS (RESTRICTED BAND) 25 - 29 LIST OF TEST EQUIPMENT 30 CONCLUSION 31 APPENDIX D - RECEIVER VERIFICATION REPORT APPENDIX E - TEST PLOTS APPENDIX F - FCC ID LABEL & LOCATION APPENDIX G - TEST SETUP PHOTOGRAPHS APPENDIX H - EXTERNAL PHOTOGRAPHS APPENDIX I - INTERNAL PHOTOGRAPHS APPENDIX J- BLOCK DIAGRAM(S) APPENDIX K - SCHEMATIC DIAGRAM(S) APPENDIX L - OPERATIONAL DESCRIPTION APPENDIX M - USER’S MANUAL APPENDIX N - MPE REPORT PCTEST PT. 15.247 REPORT EVALUATION REPORT Reviewed By: Quality Manager Test Report 15.220620323.A3L Test Dates: June 27, 2002 EUT Type: HomePAD Refrigerator FCC ID: A3LHP2777A T Page 3 of 31 MEASUREMENT REPORT Scope - Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. §2983(a) General Information Applicant Name: SAMSUNG Electronics Co., Ltd. Address: #271, Oseon-Dong, Gwangsan-Gu Gwangju-City, 506-723, KOREA Attention: Mr. Gi-Hyeong Lee • FCC ID: A3LHP2777AT • Class: Spread Spectrum Transceiver (DSS) • Type: HomePAD Refrigerator • Freq. Range: 2412 — 2462 MHz • Method/System: Direct Sequence System (DSS) • Model No(s): HP2777AT • Max. RF Output Power: 0.063 W / 18.0 dBm Conducted • Rule Part(s): § 15.247 • Dates of Tests: June 27, 2002 • Place of Tests: PCTEST Lab, Columbia, MD U.S.A. • Test Report S/N: 220620323.A3L NOTE: The receiver portion was tested and complies with Part 15B under the verification procedure. PCTEST PT. 15.247 REPORT EVALUATION REPORT Reviewed By: Quality Manager Test Report 15.220620323.A3L Test Dates: June 27, 2002 EUT Type: HomePAD Refrigerator FCC ID: A3LHP2777A T Page 4 of 31 INTRODUCTION The measurement procedure described in American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz (ANSI C63.4-1992) and FCC Public Notice dated July 12, 1995 entitled “Guidance on Measurement for Direct Sequence Spread Spectrum Systems” were used in the measurement of Samsung Spread Spectrum HomePAD Refrigerator. These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39° 11'15" N latitude and 76° 49'38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of the measurement facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. PCTEST Location The map at right shows the location of the PCTEST Lab, its proximity to the FCC Lab, the Columbia vicinity area, the Baltimore- Washington International (BWI) airport, and the city of Baltimore, and the Washington, D.C. area. (see Figure1). Figure 1. Map of the Greater Baltimore and Metropolitan Washington, D.C. area. PCTEST PT. 15.247 REPORT EVALUATION REPORT Reviewed By: Quality Manager Test Report 15.220620323.A3L Test Dates: June 27, 2002 EUT Type: HomePAD Refrigerator FCC ID: A3LHP2777A T Page 5 of 31 PRODUCT INFORMATION Equipment Description: The Equipment under test (EUT) is the Samsung Spread Spectrum HomePAD Refrigerator using spread spectrum direct sequence and time division duplex techni…

Text truncated - open the document above for the full version.

Test Setup Photos

Contact Information

Applicant

Jenni Chun(General Manager)

[email protected]973-808-6375Fax: 973-808-6361

Technical Contact

PCTEST Engineering Lab., Inc.Randy Ortanez

[email protected]410-290-6652

6660-B Dobbin Road · Columbia, Maryland · United States

Test Firm

PCTEST Engineering Laboratory, Inc.Randy Ortanez

[email protected]410-290-6652Fax: 410-290-6654

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.41 GHz - 2.46 GHz	63.00 mW

Grant Notes

Power Output listed is EIRP. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antennas or transmitters. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This application was originally granted on October 31, 2002.
