A3LHPN503950-inch PDP TV Monitor

BN68-00413A-00(ENG) Owner’s Instructions HPN5039 SERVICE DIVISION 400 Valley Road, Suite 201 Mount Arlington, NJ 07856 TEL : 1-800-SAMSUNG (1-800-726-7864) www.samsungusa.com Thank you for choosing Samsung! Your new Samsung product represents the latest in television technology. We designed it with easy-to-use on-screen menus and closed captioning capabilities, making it one of the best products in its class. We are proud to offer you a product that will provideconvenient, dependable service and enjoyment for years to come.Important Safety InformationAlways be careful when using your PDP. To reduce the risk of fire, electrical shock, and other injuries,keep these safety precautions in mind when installing, using, and maintaining your machine.• Read all safety and operating instructions before operating your PDP.• Keep the safety and operating instructions for future reference.• Heed all warnings on the PDP and in the operating instructions.• Follow all operating and use instructions.• Unplug the PDP from the wall outlet before cleaning. Use a damp cloth; do not use liquid or aerosol cleaners. • Never add any attachments and/or equipment without approval of the manufacturer. Such additions can increase the risk of fire, electric shock, or other personal injury. • Do not use the PDP where contact with or immersion in water is a possibility, such as near bath tubs, sinks, washing machines, swimming pools, etc. • Do not place the PDP on an unstable cart, stand, tripod, bracket, table, or floor where it can fall. A falling PDP can cause serious injuryto a child or adult, and serious damage to the appliance. Use onlywith a cart, stand, tripod, bracket, or table recommended by the man-ufacturer or sold with the PDP. Follow the manufacturer's instructionswhen mounting the unit, and use a mounting accessory recommendedby the manufacturer. Move the PDP and cart with care. Quick stops,excessive force, and uneven surfaces can make the unit and cartunsteady and likely to overturn. • Provide ventilation for the PDP. The unit is designed with slots in the cabinet for ventilation to protect it from overheating. Do not block these openings with any object, and do not place the PDP on a bed,sofa, rug, or other similar surface. Do not place it near a radiator or heat register. If you place thePDP on a rack or bookcase, ensure that there is adequate ventilation and that you've followed themanufacturer's instructions for mounting. • Operate your PDP only from the type of power source indicated on the marking label. If you are not sure of the type of power supplied to your home, consult your appliance dealer or local power com-pany. • Use only a grounded or polarized outlet. For your safety, this PDP is equipped with a polarized alter- nating current line plug having one blade wider than the other. This plug will fit into the power outletonly one way. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug still does not fit, contact your electrician to replace your outlet. Warning! Important Safety Instructions 3 2 CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USERSERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates high voltage is present inside. It is dangerous to make any kind of contactwith any inside part of this product. This symbol alerts you that important literature concerning operation and maintenance has beenincluded with this product. Note to CATV system installer: This reminder is provided to call CATV system installer's attention to Arti- cle 820-40 of the National Electrical Code (Section 54 of Canadian Electrical Code, Part I), that providesguidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to thegrounding system of the building as close to the point of cable entry as practical.Caution: FCC/CSA regulations state that any unauthorized changes or modifications to this equipment may void the user's authority to operate it.Caution: To prevent electric shock, match the wide blade of plug to the wide slot, and fully insert the plug. Attention: pour eviter les chocs electriques, introduire la lame le plus large de la fiche dans la borne corre- spondante de la prise et pousser jusqu'au fond.Important: One Federal Court has held that unauthorized recording of copyrighted TV programs is an infringement of U.S. copyright laws.Certain Canadian programs may also be copyrighted and any unauthorized recording in whole or in partmay be in violation of these rights. TO PREVENT DAMAGE WHICH MAY RESULT IN FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THISAPPLIANCE TO RAIN OR MOISTURE. Thank You for Choosing Samsung User InstructionsThe Federal Communications Commission RadioFrequency Interference Statement includes the fol-lowing warning:NOTE: This equipment has been tested and foundto comply with the limits for a Class B digitaldevice, pursuant to Part 15 of the FCC Rules.These limits are designed to provide reasonableprotection against harmful interference in a resi-dential installation. This equipment generates,uses, and can radiate radio frequency energyand, if not installed and used in accordance withthe instructions, may cause harmful interference toradio communications. However, there is no guar-antee that interference will not occur in a particu-lar installation .If this equipment does cause harmful interferenceto radio or television receptions, which can bedetermined by turning the equipment off and on,the user is encouraged to try to correct the inter-ference by one or more of the following mea-sures:• Reorient or relocate the receiving antenna.• Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a cir- cuit different from that to which the receiver isconnected. • Consult the dealer or an experienced radio/TV technician for help. User InformationChanges or modifications not expressly a…

Text truncated - open the document above for the full version.

17 16 4 After inserting the plastic hangers of the PDP panel into the groove of the wall attach-ment panel( Œ ), lift down ( ́ ) and tightly hang the PDP panel on the wall attachment panel. Adjusting the angle of the wall attachment panelAdjust the angle you want before installing the wall attachment panel on the wall. Notice Notice : The factory default angle is 5 degrees. Changing the angle to 0 degree PDP panel Wall attachment panel bracket Bracket for hanging the PDP display Bolt "A" for angle adjustmentBracket for wall attachment panelBracket for adjusting the angleof the wall attachment panelBolt"B"for angle adjustment Wall 1 Loosen the screws for adjusting the wall attachment panel, “A” and “B”. 2 Remove the bracket for adjusting the angle of the wall attachment panel. 3 Fit the bracket for hanging the PDP display into the hole on the PDP display. 4 Fit the screw for adjusting the wall attachment panel into the hole indicated by 0 degree and tighten it again. 1 Loosen the screw for adjusting the wall attachment panel, “A”. 2 Fit the bracket for angle adjustment to the hole indicated by 10 degrees on the wall attachment panel. 3 Fit the screw “A” for adjusting the wall attachment panel to the hole indicated by 0 degree and tighten it again. Factory default The factory default angle of wallattachment panel is 5 degrees. • Change the angle to 15 degrees, 20 degrees and other degrees in the same methods as 10 degrees. Changing the angle to 10 degrees PLASMA DISPLAY PANEL Connections Connecting VHF and UHF Antennas ..............................................20Connecting Cable TV....................................................................21Connecting Speakers.................................................................. ..23Connecting a VCR........................................................................24Connecting a Camcorder ..............................................................25Connecting a DVD Player ..............................................................26Connecting a DTV Receiver ..........................................................27 21 Connecting VHF and UHF Antennas 20 Antennas with 75-ohm Round LeadsIf your antenna looks like this: it has 75-ohm round leads. 1 Plug the antenna lead into the VHF/UHF terminal on the PDP.Use the Antenna Cable (BN39-00333A), an accessory included in the product package. Connecting Cable TVYou can connect different cable systems to your PDP, including cable without a cable box, and cable with a cable box that descrambles some or all channels. Cable without a Cable Box 1 Plug the incoming cable into the VHF/UHF terminal on the PDP.Use the Antenna Cable (BN39-00333A), an accessory included in the product package. Cable with a Cable Box that Descrambles All Channels. 1 Find the cable connected to the ANTENNA OUT terminal on your cable box. This terminalmight be labeled "ANT OUT", "VHF OUT", or simply "OUT". 2 Connect the cable to the VHF/UHF terminal on the PDP. Use the Antenna Cable (BN39-00333A), an accessory included in the product package. 22 Cable with a Cable Box that Descrambles Some (But Not All) ChannelsTo complete this connection you will need a two-way splitter, a RF (A/B) switch, and four coaxialcables (which you can buy from your Samsung dealer or any electronics store). 1 Find and disconnect the cable that is con-nected to the ANTENNA IN terminal of your cable box. This terminal might be labeled "ANT IN", "VHF IN", or simply, "IN". Connect this cable to a two-way splitter. 2 Connect a coaxial cable between an OUT-PUT terminal of the splitter and the IN termi- nal of the cable box. 3 Connect a coaxial cable between theANTENNA OUT terminal of the cable box and the B-IN terminal of the A/B switch. 4 Connect a coaxial cable between theANTENNA OUT terminal of the cable box and the B-IN terminal of the A/B switch. 5 Connect the last coaxial cable between theOUT terminal of the RF (A/B) switch and the VHF/UHF ter-minal on the PDP. After you've made this connection, set the A/B switch to the "A" position for normal viewing. Set the A/B switch to the "B" position to view scrambled channels. (When you set the A/B switch to "B", you will need to tune your Set-Top Box to the cable box's output channel, which is usuallychannel 3 or 4.) 23 Connecting SpeakersExternal speakers are sold saparately. Check with your dealer. Speaker Audio Cable(BN39-00315A) Connect the speaker audio cable to the external speaker output jack on the PDP matching the“+” and “-” ends of the cable with the diagram on the PDP. How to Connect Fix the bracket onto the guide pole located on the rear of speaker and fasten the screws.After removing the four screws on the rear of PDP.As shown in figure, insert the loop on a speaker into the groove on the PDP.Clamp the speaker and the PDP together and fasten the screws. Connecting PDP and Speakers 1234 GuidepoleGuidepole ✱ External speakers MUST have to a power handling capability of 10 watts minimum (impedance 8 ohm). Speaker Audio Cable (BN39-00315A) Subwoofer Speaker (Option) 25 Connecting a Camcorder 24 Connecting a VCR to the Video or S-Video/Audio jack S-Video Cable Audio Cable Video Cable Power Plug Connect the Video/Audio cables between the AUDIO(L/R)/VIDEO jacks on the PDP andAUDIO/VIDEO OUT jacks on the VCR. (Note: For better video, you can use an S-Video cable.) Videotape Playback:1. Turn on your PDP, and press the SOURCE button on the remote control.2. Move the joystick up or down to select “Video” or “S-Video”, then press the joystick to enter.3. Turn on your VCR, insert a videotape and press the play button. How to Connect The ferrite cores are used to attenuate undesired signals. When connecting audio cable (PC, DVI,S-Video, Video) , attach one of these ferrite cores to the cable near the connector. When you connect the audio cable (PC, DVI, S-Video, Video) to theconnectors, first bind round the ferrite core to secure it. Ferrite Cores (3301-001110) Connecting a VCR Audio Cable…

Text truncated - open the document above for the full version.

PLASMA DISPLAY PANEL Picture Control Customizing the Picture ................................................................40Using Automatic Picture Settings ....................................................41Selecting the Color Tone................................................................42Viewing the Picture-in-Picture ..........................................................43Changing the Screen Size ............................................................49Freezing the Picture ......................................................................50 Customizing the PictureYou can use the on-screen menus to change the Contrast, Brightness, Sharpness, Color, and Tint settings of your PDP. 41 1 Press the Menu button, then press the joystick toenter. 2 Move the joystick left or right to select “Custom”,“Dynamic”, “Standard” or “Movie” picture setting. • You can select “High”, “Middle”, “Low” or “Custom” in PC/DVI mode. 3 Press the Menu button to exit. Using Automatic Picture SettingsYour PDP has automatic picture settings that allow you to adjust the video display easily. Picture ModeAdjustColor Tone Move Select Exit CustomCustom Picture ModeAdjustColor Tone Move Select Exit Dynamic Custom 40 1 Press the Menu button, then press the joystick toenter. 2 Move the joystick up or down to select “Adjust”,then press the joystick to enter. You will also see the items “Contrast”, “Brightness”, “Sharpness”, “Color” and “Tint”. 3 Move the joystick up or down to select the item you wish to change. 4 Move the joystick left or right to change the value ofthe item. 5 Press the Menu button to exit. Note• In the PC/DVI mode, you can’t adjust the Sharpness, Color and Tint.• The Tint doesn’t operate in Component(480p, 720p, 1080i) mode. Picture ModeAdjustColor Tone Move Select Exit CustomCustom Picture ModeAdjustColor Tone Move Enter Exit Custom Normal Adjust ContrastBrightnessSharpnessColorTint R 50 G 50 Move Adjust Exit 80505050 82 Contrast Quick way to access the picture setting: Just press the “P.Mode” button on the remote control. ! 43 42 Selecting the Color Tone 1 Press the Menu button, then press the joystick toenter. 2 Move the joystick up or down to select “ColorTone”, then move the joystick left or right to select “Normal”, “Warm1”, “Warm2”, “Cool2” or “Cool1”.• You can select “Custom”, “Color1”, “Color2” or “Color3” in PC mode. • You can select “Color1”, “Color2” or “Color3” in DVI mode. 3 Press the Menu button to exit. . Picture ModeAdjustColor Tone Move Select Exit CustomCustom Picture ModeAdjustColor Tone Move Select Exit Custom Normal Viewing the Picture-in-Picture Selecting the PIP Screen 1 Press the Menu button. Move the joystick up ordown to select “PIP”, then press the joystick to enter. 2 Move the joystick left or right to select “On”. The PIP image will appear in the corner of the screen. 3 Press the Menu button to exit. PIP Settings PIP Select Select Exit Off PIP SelectSourceSwapSizeLocateAnt/CATVChannel Move Select Exit On TVLargeAntAnt 5 Quick way to access the PIP: Just press the“PIP” button on the remote control. ! PIP screen Main screen TV Video S-Video Component 1 Component 2 PC DVI TV OOOOOOO O X OOOOO OO X OOOO OOO XXXX OOO XXXX OOO XXXX OOO XXXX Video S-Video Component 1Component 2 PC DVI O: PIP and Swap Operate X: PIP doesn’t Operate 45 44 Selecting an External SignalYou can use PIP to view a signal from an external source, such as a VCR. 1 Press the Menu button. Move the joystick up ordown to select “PIP”, then press the joystick to enter. 2 Move the joystick up or down to select “Source”. 3 Move the joystick left or right to cycle through all of the available signal sources: “TV”, “Video”, “S-Video”, “Component 1”, “Component 2”, “PC” and “DVI”.The signal from these inputs will not appear if you have not connected any equipment to the PDP’s input jacks. 4 Press the Menu button to exit. Note• The PIP function operates in Wide screen.• Using Multi-Screen in the Normal, Zoom1 or Zoom2 screen will change the size of the main screen to Wide screen. PIP SelectSourceSwapSizeLocateAnt/CATVChannel Move Select Exit On TVLargeAntAnt 5 PIP SelectSourceSwapSizeLocateAnt/CATVChannel Move Select Exit On TVLargeAntAnt 5 PIP SelectSourceSwapSizeLocate Move Select Exit On Video Large Quick way to access the PIP source: Just press “Source” button in the cover on the remote control. ! Swapping the Contents of the PIP Image and Main Image 1 Press the Menu button. Move the joystick up ordown to select “PIP”, then press the joystick to enter. 2 Move the joystick up or down to select “Swap”,then press the joystick to enter. • The image in the PIP window will appear on the main screen, and vice versa. 3 Press the Menu button to exit. Selecting the Sound Source S.SwapPress the S.Swap button to switch between the Main or Sub(PIP) audio source. PIP SelectSourceSwapSizeLocateAnt/CATVChannel Move Select Exit On TVLargeAntAnt 5 PIP SelectSourceSwapSizeLocateAnt/CATVChannel Move Enter Exit On TVLargeAntAnt 5 Quick way to access swapping: Just press the“Swap” button on the remote control. ! 46 47 Changing the Size of the PIP Window 1 Press the Menu button. Move the joystick up ordown to select “PIP”, then press the joystick to enter. 2 Move the joystick up or down to select “Size”. 3 Move the joystick left or right to select “Small”,“Double” or “Large”. 4 Press the Menu button to exit. PIP SelectSourceSwapSizeLocateAnt/CATVChannel Move Select Exit On TVLargeAntAnt 5 PIP SelectSourceSwapSizeLocateAnt/CATVChannel Move Select Exit On TVLargeAntAnt 5 PIP SelectSourceSwapSizeLocateAnt/CATVChannel Move Select Exit On TVSmallAntAnt 5 Quick way to access the PIP size: Just press the “Size” button in the cover on the remote control. ! Changing the Location of the PIP Image 1 Press the Menu button. Move the joystick up ordown to select “PIP”, then press the joystick to enter. 2 Move the joystick up or down to select “Locate”. 3 Move the joystick left or right to move the PIP screenwhere you want. 4 …
