A3LHWA40RSoundBar

01 USING THE REMOTE CONTROL  Power button  (Mute) button  VOL (Volume) button  SURROUND or STANDARD button Press to select the desired sound effect by choosing SURROUND or STANDARD.  BASS button  D.IN button Press to enter the “D.IN” mode.  Bluetooth button Press to enter the “Bluetooth” mode.  AUX button Press to enter the “AUX” mode.  # / & / $ button Press the # button to select the previous music file. Press the & button to play/pause a music file. Press the $ button to select the next music file.  USB RANDOM button The playback mode of the USB storage device changes to random repeat.  USB button Press to enter the “USB” mode.  Bluetooth PAIR button Press this button to pair a new Bluetooth device.             02 INSTALLING THE WALL MOUNT (OPTIONAL) Installation Precautions •Install on a vertical wall only. •Do not install in a place with high temperature or humidity. •Verify whether the wall is strong enough to support the product’s weight. If not, reinforce the wall or choose another installation point. •Purchase and use the fixing screws or anchors appropriate for the kind of wall you have (plaster board, iron board, wood, etc.). If possible, fix the support screws into wall studs. •Purchase wall mounting screws according to the type and thickness of the wall you want to mount the Soundbar on. –Diameter: M4 –Length: 1.6 inches (40 mm) or longer recommended. •Connect cables from the unit to external devices before you install the Soundbar on the wall. •Make sure the unit is turned off and unplugged before you install it. Otherwise, it may cause an electric shock. Wallmount Components 2 inches (5cm) or more For Installation on Concrete Walls (not supplied) ABCD x 2 (M4 x L40) ABCD x 2 0.15” (4 mm) 0.31” (8 mm) Recommended specification 1.6’’ (40 mm) or longer 1. CENTER LINE --- 14.6” (370 mm) --- 2. 0.25’’ (6 mm) 2’’ (50 mm) ABCD 3. ABCD 0.41’’ (10.5mm) 4. AUX IN POWER DIGITAL AUDIO IN (OPTICAL) USB (5V 0.5A) POWER POWER AUX IN DIGITAL AUDIO IN (OPTICAL) USB (5V 0.5A) 5. CAUTION –Do not bump into or strike the Soundbar (especially from the bottom). The impact could detach the Soundbar from the wall, resulting in personal injury. 72-A40RZA-RCGB1-SS

HW-A40R FULL MANUAL Imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register ENG - 2 SAFETY INFORMATION ࡙The following also applies to the Wireless Surround Speaker SET (SWA-8500). SAFETY WARNINGS TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK). NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Refer to the table below for an explanation of symbols which may be on your Samsung product. CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN. This symbol indicates that high voltage is present inside. It is dangerous to make any kind of contact with any internal part of this product. This symbol indicates that this product has included important literature concerning operation and maintenance. Class II product : This symbol indicates that it does not require a safety connection to electrical earth (ground). If this symbol is not present on a product with a power cord, the product MUST have a reliable connection to protective earth (ground). AC voltage : This symbol indicates that the rated voltage marked with the symbol is AC voltage. DC voltage : This symbol indicates that the rated voltage marked with the symbol is DC voltage. Caution, Consult instructions for use : This symbol instructs the user to consult the user manual for further safety related information. WARNING ࡙ ƟͱθʪʒЇʀʪϩ˵ʪθ̈θ̧ͱ ̇ѣθʪͱθʪ̷ʪʀϩθ̈ʀθ˵ͱʀ̧ࡡʒͱ not expose this appliance to rain or moisture. ࡙To prevent injury, this apparatus must be θʪʀЇθʪ̷цɇϩϩɇʀ˵ʪʒϩͱϩ˵ʪѤͱͱθࢥиɇ̷̷̈͝ accordance with the installation instructions. ࡙This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. CAUTION ࡙Do not expose this apparatus to dripping or θΧ̷ɇθ˵̈͝ ̋ࢋUͱ͝ͱϩΧЇϩͱɵ̟ʪʀϩθѣ̷̷ʪʒӥϩ˵ liquids, such as vases, on the apparatus. ࡙To turn this apparatus off completely, you must pull the power plug out of the wall socket. Consequently, the power plug must be easily and readily accessible at all times. FCC NOTE (for U.S.A): FCC Supplier’s Declaration of Conformity Product name SoundBar .PEFM
)8"3 Responsible Party - U.S. Contact Information:
Samsung Electronics America, Inc. 85 Challenger Road. ŵ̈ʒ ̋ʪ ̇̈ʪ̷ʒťɇθ̧ࡡĘâߡߧߧߨߡ ࣎ߥߧߩߨࣗߧߣߨ࣍đƊƸĘࣗƊߡߡߩࣗߢࡠť˵ͱ͝ʪ FCC Compliance Statement : This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation. ENG - 3 FCC Caution : ࡙ ͝цʀ˵ɇ͝ ̋ʪθͱθ͔ͱʒ̈ѣʀɇϩ̈ͱ͝θ͝ͱϩʪуΧθʪθθ̷ц approved by the party responsible for compliance could void the user’s authority to operate this equipment. ࡙ Ɵ˵̈θΧθͱʒЇʀϩθɇϩ̈θѣʪθ˜AAθʪ ̋Ї̷ɇϩ̈ͱ͝θи˵ʪ͝ shielded cables and connectors are used to connect the unit to other equipment. To prevent electromagnetic interference with electric appliances, such as radios and televisions, use shielded cables and connectors for connections. Class B FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: ࡙Reorienting or relocating the receiving antenna. ࡙Increasing the separation between the equipment and receiver. ࡙Connecting the equipment to an outlet that is on a different circuit than the radio or TV. ࡙Consulting the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement : This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated so there is at least 8 inches (20 cm) between the radiator and your body. This device and its antenna(s) must not be co-located or operated in conjunction with any other antenna or transmitter. CALIFORNIA USA ONLY (Applicable for networking models only.) This Perchlorate warning applies only to primary CR(Manganese Dioxide) Lithium coin cells in the product sold or distributed ONLY in California USA “Perchlorate Material - special handling may apply, See www.dtsc.ca.gov/hazardouswaste/ perchlorate.” Dispose unwanted electronics through an ɇΧΧθͱЭʪʒθʪʀцʀ̷ʪθࢋƟͱѣ͝ʒϩ˵ʪ͝ʪɇθʪθϩθʪʀцʀ̷̈͝ ̋ location, go to our website:www.samsung.com/ θʪʀцʀ̷̈͝ ̋Įθʀɇ̷̷ࡡߢࣚߡߡߩࣚƊđƊƸʝ WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov. Important Safety Instructions Read these operating instructions carefully before using the unit. Follow all the safety instructions listed below. Keep these operating instructions handy for future reference. 1. Read these instructions. 2. Keep these Instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. kʝࣗߥ 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other ɇΧΧɇθɇϩЇθ࣍̈͝ʀ̷Їʒ̈͝ ̋ɇ͔Χ̷̈ѣʪθθ࣎ϩ˵ɇϩΧθͱʒЇʀʪ heat. 9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the …

Text truncated - open the document above for the full version.

USER MANUAL HW-A40R You can access the FULL MANUAL on Samsung’s on-line customer support center by scanning the QR code on the left. To see the manual on your PC or mobile device, download the manual in document format from Samsung’s website. (http://www.samsung.com/support) SAFETY INFORMATION •The following also applies to the Wireless Surround Speaker SET (SWA-8500). SAFETY WARNINGS TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK). NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Refer to the table below for an explanation of symbols which may be on your Samsung product. CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN. This symbol indicates that high voltage is present inside. It is dangerous to make any kind of contact with any internal part of this product. This symbol indicates that this product comes with important literature concerning operation and maintenance. Class II product : This symbol indicates that a safety connection to electrical earth (ground) is not required. If this symbol is not present on a product with a power cord, the product MUST have a reliable connection to protective earth (ground). AC voltage : Rated voltage marked with this symbol is AC voltage. DC voltage : Rated voltage marked with this symbol is DC voltage. Caution. Consult Instructions for use : This symbol instructs the user to consult the user manual for further safety related information. WARNING •To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. •To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation instructions. •This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. CAUTION •Do not expose this apparatus to dripping or splashing. Do not put objects filled with liquids, such as vases, on the apparatus. •To turn this apparatus off completely, you must pull the power plug out of the wall socket. Consequently, the power plug must be easily and readily accessible at all times. FCC NOTE (for U.S.A): FCC Supplier’s Declaration of Conformity Product name: SoundBar Model:HW-A40R Responsible Party - U.S. Contact Information: Samsung Electronics America, Inc. 85 Challenger Road. Ridgefield Park, NJ 07660 Phone: 1-800-SAMSUNG (726-7864) FCC Compliance Statement : This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Caution : •Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. •This product satisfies FCC regulations when shielded cables and connectors are used to connect the unit to other equipment. To prevent electromagnetic interference with electric appliances, such as radios and televisions, use shielded cables and connectors for connections. Class B FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: •Reorienting or relocating the receiving antenna. •Increasing the separation between the equipment and receiver. •Connecting the equipment to an outlet that is on a different circuit than the radio or TV. •Consulting the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement : This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated so there is at least 8 inches (20 cm) between the radiator and your body. This device and its antenna(s) must not be co-located or operated in conjunction with any other antenna or transmitter. CALIFORNIA USA ONLY (Applicable for networking models only.) This Perchlorate warning applies only to primary CR(Manganese Dioxide) Lithium coin cells in the product sold or distributed ONLY in California USA “Perchlorate Material - special handling may apply, See www.dtsc.ca.gov/hazardouswaste/perchlorate.” Dispose unwanted electronics through an approved recycler. To find the nearest recycling location, go to our website: www.samsung.com/recycling Or call, 1‐800‐SAMSUNG WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov. Important Safety Instructions Read these operating instructions carefully before using the unit. Follow all the safety instructions listed below. Keep these operating instructions handy for future reference. 1. Read these instructions. 2. Keep these Instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. Do not defeat the safety purpose of the polarized or grounding- type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong …

Text truncated - open the document above for the full version.

Samsung Electronics Co Ltd Address: 19 Chapin Rd., Building D Pine Brook New Jersey United States 07058 Confirmation Letter We, Samsung Electronics Co Ltd The product: SoundBar And model No.: HW-A40R FCC ID: A3LHWA40R HW-A40R***, HW-A40R/** ("*" represents any alphanumeric character or blank) have the same technical construction including circuit diagram, PCB Layout, components and component layout, all electrical construction and mechanical construction with HW-A40R. The difference lies only model number and marketing purpose. ______________________ Contact person：Jenni Chun Date：01/08/2021

Samsung Electronics Co Ltd Date: 01/08/2021 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 To whom it may concern: I, the undersigned, hereby authorize UL Verification Services Inc. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Verification Services Inc. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing UL Verification Services Inc. as our representative, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Signed by : Company Name: Samsung Electronics Co Ltd Contact Name: Jenni Chun Address: 19 Chapin Rd., Building D Pine Brook New Jersey United States 07058

Samsung Electronics Co Ltd DATE : 01/08/2021 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Request for Short-Term Confidentiality Company name: FCC ID: A3LHWA40R FCC Part 15 Certification Pursuant to Sections 0.457 and 0.459 of the commission rules, and in accordance with the FCC Public notice dated June 15, 2004 (DA 04-1705), we hereby request short-term confidentiality for the following items prior to marketing the device.: (1) Test Setup Photos (2) External Photos (3) Internal Photos (4) User Manual The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Sincerely, Company Name: Samsung Electronics Co Ltd Contact Name: Jenni Chun Address: 19 Chapin Rd., Building D Pine Brook New Jersey United States 07058 Date:01/08/2021

Samsung Electronics Co Ltd Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: A3LHWA40R To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Company Name: Samsung Electronics Co Ltd Contact Name: Jenni Chun Address: 19 Chapin Rd., Building D Pine Brook New Jersey United States 07058 Date: 01/08/2021

Appendix I External Photographs Page 2 of 6 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. View of EUT-1 View of EUT-2 Page 3 of 6 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. View of EUT-3 View of EUT-4 Page 4 of 6 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. View of EUT-5 View of EUT-6 Page 5 of 6 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. View of EUT-7 View of EUT-8 Page 6 of 6 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. View of EUT-9

A40R ZA Carton box Made in China version Made in Vietnam version A40R ZA Bar 80.5mm 80.5mm 23.5mm 23.5mm MFD./FABRIQUE : DECEMBER 2020 S/N: 4PD814PNC00001X AC110-120V~ 50/60Hz 20W MODEL CODE: HW-A40R/ZA MODEL / MODELE NO.: HW-A40R MADE IN CHINA(Factory ID:TQ) FABRIQUE AU CHINE(Factory ID:TQ) HECHO EN CHINA(Factory ID: TQ) FCC ID: A3LHWA40R Contains Tx FCC ID: A3LWSM520V Version No.: 1 MADE IN CHINA(Factory ID:TQ) FABRIQUE AU CHINE(Factory ID:TQ) HECHO EN CHINA(Factory ID: TQ) FCC ID: A3LHWA40R Contains Tx FCC ID: A3LWSM520V Version No.: 1 50mm 50mm 80mm Model : Model Code : HW-A40R/ZA HW-A40R S/N: 4PD814PNC00001 MADE IN CHINA(Factory ID: TQ) FABRIQUE AU CHINE(Factory ID: TQ) HECHO EN CHINA(Factory ID: TQ) 838727653083 A40R ZA Carton box A40R ZA Bar MODEL CODE: HW-A40R/ZA MODEL / MODELE NO.: HW-A40R MFD./FABRIQUE : DECEMBER 2020 S/N: 4PD814CNC00001W AC110-120V~ 50/60Hz 20W 80mm Model : Model Code : HW-A40R/ZA HW-A40R S/N: 4PD814CNC00001 838727653083 MADE IN VIETNAM(VN) FABRIQUE AU VIETNAM(VN) HECHO EN VIETNAM(VN)

Appendix II Internal Photographs Page 2 of 10 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-1 Internal View of EUT-2 Page 3 of 10 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-3 Internal View of EUT-4 Page 4 of 10 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-5 Internal View of EUT-6 Page 5 of 10 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-7 Internal View of EUT-8 Antenna Page 6 of 10 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-9 Internal View of EUT-10 Page 7 of 10 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-11 Internal View of EUT-12 Page 8 of 10 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-13 Internal View of EUT-14 Page 9 of 10 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-15 Internal View of EUT-16 Page 10 of 10 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-17

The results reported herein have been performed in accordance with the laboratory’s terms of accreditation. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report apply to the test sample(s) mentioned above at the time of the testing period only and are not to be used to indicate applicability to other similar products. FCC RF EXPOSURE REPORT CERTIFICATION TEST REPORT For SoundBar MODEL NUMBER: HW-A40R, HW-A40R***, HW-A40R/** ("*" represents any alphanumeric character or blank) FCC ID: A3LHWA40R REPORT NUMBER: 4789781474.2-3 ISSUE DATE: January 14, 2021 Prepared for Samsung Electronics Co Ltd 19 Chapin Rd., Building D Pine Brook New Jersey United States 07058 Prepared by UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch Building 10, Innovation Technology Park, No. 1, Li Bin Road, Song Shan Lake Hi- Tech Development Zone Dongguan, 523808, People’s Republic of China Tel: +86 769 22038881 Fax: +86 769 33244054 Website: www.ul.com REPORT NO.: 4789781474.2-3 Page 2 of 8 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Revision History Rev. Issue Date Revisions Revised By V0 01/14/2021 Initial Issue REPORT NO.: 4789781474.2-3 Page 3 of 8 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS ................................................................................. 4 2. TEST METHODOLOGY ..................................................................................................... 5 3. FACILITIES AND ACCREDITATION ................................................................................. 5 4. DESCRIPTION OF EUT ..................................................................................................... 6 5. REQUIREMENT ................................................................................................................. 7 REPORT NO.: 4789781474.2-3 Page 4 of 8 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. 1. ATTESTATION OF TEST RESULTS Applicant Information Company Name: Samsung Electronics Co Ltd Address: 19 Chapin Rd., Building D Pine Brook New Jersey United States 07058 Manufacturer Information Company Name: Samsung Electronics Co Ltd Address: 19 Chapin Rd., Building D Pine Brook New Jersey United States 07058 EUT Information EUT Name: SoundBar Model: HW-A40R Brand: SAMSUNG Serial Model: HW-A40R***, HW-A40R/** ("*" represents any alphanumeric character or blank) Model difference: See section 5.1 of this report for detail Sample Received Date: January 6, 2021 Sample Status: Normal Sample ID: 3577691 Date of Tested: January 7, 2021 ~ January 14, 2021 APPLICABLE STANDARDS STANDARD TEST RESULTS FCC 47CFR§2.1091 PASS Prepared By: Checked By: Denny Huang Shawn Wen Project Engineer Laboratory Leader Approved By: Stephen Guo Laboratory Manager REPORT NO.: 4789781474.2-3 Page 5 of 8 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. 2. TEST METHODOLOGY The tests documented in this report were performed in accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091. 3. FACILITIES AND ACCREDITATION Accreditation Certificate A2LA (Certificate No.: 4102.01) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. has been assessed and proved to be in compliance with A2LA. FCC (FCC Designation No.: CN1187) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. Has been recognized to perform compliance testing on equipment subject to the Commission's Delcaration of Conformity (DoC) and Certification rules ISED (Company No.: 21320) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. has been registered and fully described in a report filed with ISED. The Company Number is 21320 and the test lab Conformity Assessment Body Identifier (CABID) is CN0046. VCCI (Registration No.: G-20019, R-20004, C-20012 and T-20011) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. has been assessed and proved to be in compliance with VCCI, the Membership No. is 3793. Facility Name: Chamber D, the VCCI registration No. is G-20019 and R-20004 Shielding Room B , the VCCI registration No. is C-20012 and T-20011 Note: All tests measurement facilities use to collect the measurement data are located at Building 10, Innovation Technology Park, Song Shan Lake Hi tech Development Zone, Dongguan, 523808, Chin…

Text truncated - open the document above for the full version.
