A3LIWBD1Communication dongle

Communication dongle IWB-D1 Company Samsung Electronics Device Name Wireless Device for Data Communication (IWB-D1) Manufacture Date 2011 Manufacturer/Country Alpha Networks / (confirmation needed) 1. Certification Mark 2. Product Specification Frequency range 2405 MHz ~ 2480 MHz Temperature 0°C~ 40°C Data rate 500 kbps Power Supply DC 5V 3. Appearance 4. How it works - Cursor coordinates recognition : IR sensor of the pen receives IR signal from the PDP panel, then process the coordinate recognition from the signal. - Data Transmission through USB Dongle : Pen receives the coordinate data and other input commands from the PDP panel, and then transmit to USB dongle. Through computer, the data is processed and generating the output result on the panel. Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IMPORTANT NOTE: Radiation Exposure Statement: The product comply with the US/Canada portable RF exposure limit set forth for an uncontrolled environment and are safe for intended operation as described in this manual. The further RF exposure reduction can be achieved if the product can be kept as far as possible from the user body or set the device to lower output power if such function is available. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

Federal Communications Commission Authorization and Evaluation Division Confidentiality Request FCC ID: A3LIWBD1 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ------------------------------------------ Sang Kyung (Peter) Ra/ S. Manager SAMSUNG ELECTRONICS AMERICA INC. 2011/2/25

Federal Communications Commission Authorization and Evaluation Division Power of Attorney FCC ID: A3LIWBD1 To whom it may concern: We, the undersigned SAMSUNG ELECTRONICS CO., LTD. hereby authorize BV CPS (H.K.) Ltd., Taoyuan Branch of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C approvals and any communication needed with the national authority. Any and all acts carried out by BV CPS (H.K.) Ltd., Taoyuan Branch of Taiwan on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ------------------------------------------ Sang Kyung (Peter) Ra/ S. Manager SAMSUNG ELECTRONICS AMERICA INC. 2011/2/25

Page 1 CONSTRUCTION PHOTOS OF EUT

IWB-D1 Label drawing & location

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3

FCC ID: A3LIWBD1 Report No.: RF110117E03A OPERATIONAL DESCRIPTION This device is a ZigBee dongle, which operates in 2.4GHz band; the maximum data rate could be up to 250 kbps which O-QPSK technique. The transmitter of the EUT is powered by 5Vdc host equipment. The antenna is chip antenna without antenna connector. For more detailed instruction, please take a look at the user’s manual.

Report No.: RF110117E03A 1 Report Format Version 4.0.0 Reference No.: 110210E05 FCC TEST REPORT REPORT NO.: RF110117E03A MODEL NO.: IWB-D1 FCC ID: A3LIWBD1 RECEIVED: Feb. 10, 2011 TESTED: Feb. 15 to 18, 2011 ISSUED: Mar. 18, 2011 APPLICANT: Samsung Electronics Co., Ltd. ADDRESS: 416 Maetan-dong, Young-Tong gu, Suwon, Korea 442-742 ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan This test report consists of 32 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced, except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF110117E03A 2 Report Format Version 4.0.0 Reference No.: 110210E05 Table of Contents RELEASE CONTROL RECORD.................................................................................3 1 CERTIFICATION.............................................................................................4 2 SUMMARY OF TEST RESULTS.....................................................................5 2.1 MEASUREMENT UNCERTAINTY..................................................................5 3 GENERAL INFORMATION.............................................................................6 3.1 GENERAL DESCRIPTION OF EUT................................................................6 3.2 DESCRIPTION OF TEST MODES..................................................................7 3.3 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL..................7 3.4 GENERAL DESCRIPTION OF APPLIED STANDARDS.................................9 3.5 DESCRIPTION OF SUPPORT UNITS..........................................................10 3.6 CONFIGURATION OF SYSTEM UNDER TEST............................................11 4 TEST PROCEDURES AND RESULTS.........................................................12 4.1 CONDUCTED EMISSION MEASUREMENT................................................12 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT..............................12 4.1.2 TEST INSTRUMENTS..................................................................................12 4.1.3 TEST PROCEDURES...................................................................................13 4.1.4 TEST SETUP................................................................................................13 4.1.5 EUT OPERATING CONDITIONS..................................................................14 4.1.6 TEST RESULTS............................................................................................15 4.2 RADIATED EMISSION MEASUREMENT.....................................................17 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...................................17 4.2.2 TEST INSTRUMENTS..................................................................................18 4.2.3 TEST PROCEDURES...................................................................................19 4.2.4 DEVIATION FROM TEST STANDARD.........................................................19 4.2.5 TEST SETUP................................................................................................20 4.2.6 EUT OPERATING CONDITIONS..................................................................20 4.2.7 TEST RESULTS............................................................................................21 4.3 CONDUCTED - OUT BAND MEASUREMENT.............................................28 4.3.1 LIMITS OF CONDUCTED - OUT BAND MEASUREMENT..........................28 4.3.2 TEST INSTRUMENTS..................................................................................28 4.3.3 TEST PROCEDURE.....................................................................................28 4.3.4 DEVIATION FROM TEST STANDARD.........................................................28 4.3.5 EUT OPERATING CONDITION....................................................................28 4.3.6 TEST RESULTS............................................................................................29 5 INFORMATION ON THE TESTING LABORATORIES..................................31 6 APPENDIX A - MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB..........................................................32 Report No.: RF110117E03A 3 Report Format Version 4.0.0 Reference No.: 110210E05 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED Original release NA Mar. 18, 2011 Report No.: RF110117E03A 4 Report Format Version 4.0.0 Reference No.: 110210E05 1 CERTIFICATION PRODUCT : Communication dongle BRAND NAME : SAMSUNG MODEL NO. : IWB-D1 TEST SAMPLE : MASS-PRODUCTION APPLICANT : Samsung Electronics Co., Ltd. TESTED : Feb. 15 to 18, 2011 STANDARDS : FCC Part 15, Subpart C (Section 15.249) ANSI C63.4-2003 ANSI C63.10-2009 The above equipment (Model: IWB-D1) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: Mar. 18, 2011 ( Carol Liao, Specialist ) APPROVED BY : , DATE: Mar. 18, 2011 ( May Chen, Deputy Manager ) Report No.: RF110117E03A 5 Report Format Version 4.0.0 Reference No.: 110210E05 2 SUMMARY OF TEST RESULTS The EUT …

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST 2 RADIATED EMISSION TEST
