A3LLS23C570LCD Monitor

- English - • The slots and openings in the cabinet and in the back or bottom are provided for necessary ventilation. To ensure reliable operation of this apparatus, and to protect it from overheating, these slots and openings must never be blocked or covered. - Do not cover the slots and openings with a cloth or other materials. - Do not block the slots and openings by placing this apparatus on a bed, sofa, rug or other similar surface. - Do not place this apparatus in a confined space, such as a bookcase, or built-in cabinet, unless proper ventilation is provided. • Do not place this apparatus near or over a radiator or heat resistor, or where it is exposed to direct sunlight. • Do not place a water containing vessel(vases etc.) on this apparatus, as this can result in a risk of fire or electric shock. • Do not expose this apparatus to rain or place it near water(near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool etc.). If this appratus accidentally gets wet, unplug it and contact an authorized dealer immediately. Make sure to pull out the power cord from the outlet before cleaning. • This appratus use batteries. In your community there might be regulations that require you to dispose of these batteries properly under environmental considerations. Please contact your local authorities for disposal or recycling information. • Do not overload wall outlets, extension cords or adaptors beyond their capacity, since this can result in fire or electric shock. • Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plug end, adaptors and the point where they exit from the appliance. • To protect this apparatus from a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the set due to lightning and power line surges. • Before connecting the AC power cord to the DC adaptor outlet, make sure the voltage designation of the DC adaptor corrsponds to the local electrical supply. • Never insert anything metallic into the open parts of this apparatus. Doing so many create a danger of electric shock. • To avoid electric shock, never touch the inside of this apparatus. Only a qualified technician should open this apparatus. • Make sure to plug the power cord in until it is firmly inserted. When removing the power cord, make sure to hold the power plug when pulling the plug from the outlet. Do not touch the power cord with wet hands. • If this appratus does not operate normally - in particular, if there are any unusual sounds or smells coming from it - unplug it immediately and contact an authorized dealer or service center. • Be sure to pull the power plug out of the outlet if the TV is to remain unused or if you are to leave the house for an extended period of time (especially when children, elderly or disabled people will be left alone in the house). - Accumulated dust can cause an electric shock, an electric leakage or a fire by causing the power cord to generate sparks and heat or the insulation to deteriorate. • Be sure to contact an authorized service center, when installing your set in a location with heavy dust, high or low temperatures, high humidity, chemical substances and where it operates for 24 hours such as the airport, the train station etc. Failure to do so may cause serious damage to your set. • Use only a properly grounded plug and receptacle. - An improper ground may cause electric shock or equipment damage. (Class l Equipment only.) • To disconnect the apparatus from the mains, the plug must be pulled out from the mains socket, therefore the mains plug shall be readily operable. • Do not allow children to hang onto the product. • Store the accessories (battery, etc.) in a location safely out of the reach of children. • Do not install the product in an unstable location such as a shaky self, a slanted floor or a location exposed to vibration. • Do not drop or impart any shock to the product. If the product is damaged, disconnect the power cord and contact a service center. • Unplug the power cord from the power outlet and wipe the product using a soft, dry cloth. Do not use any chemicals such as wax, benzene, alcohol, thinners, insecticide, air freshener, lubricant or detergent. This may damage the appearance or erase the printing on the product. • Apparatus shall not be exposed to dripping or splashing. • Do not dispose of batteries in a fire. • Do not short circuit, disassemble or overheat the batteries. • Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. • WARNING - TO PREVENT THE SPREAD OF FIRE, KEEP CANDLES OR OTHER OPEN FLAMES AWAY FROM THIS PRODUCT AT ALL TIMES. Warning! Important Safety Instructions (Please read the appropriate section that corresponds to the marking on your Samsung product before attempting to install the product.) CAUTION CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO QUALIFIED PERSONNEL. RISK OF ELECTRIC SHOCK DO NOT OPEN This symbol indicates that high voltage is present inside. It is dangerous to make any kind of contact with any internal part of this product. This symbol alerts you that important literature concerning operation and maintenance has been included with this product. - Français - • Les fentes et les ouvertures ménagées dans le boîtier ainsi qu'à l’arrière et au-dessous de l'appareil assurent la ventilation de ce dernier. Afin de garantir le bon fonctionnement de l'appareil et éviter les risques de surchauffe, ces fentes et ouvertures ne doivent être ni obstruées ni couvertes. - Ne couvrez pas les fentes et les ouvertures avec un morceau de tissu ou tout autre objet. - Ne les obstruez pas non plus en pl…

Text truncated - open the document above for the full version.

Samsung Electronics Co., Ltd. 416 Maetan 3-Dong,Yeongtong-Gu,Suwon-Si, Gyeonggi-Do, 443-742 Republic of Korea 022311 – 6 Request for Confidentiality Date: ___2012-12-10_____ Subject: Confidentiality Request for: _A3LLS23C570____ Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 3 Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual *Note: ______(Insert Explanation as Necessary)______ ____ Samsung Electronics Co., Ltd. _____ has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, By: _ Peter Ra, Manager __ (Signature/Title 4 ) (Print name) 3 - The asterisked items (*) require further justification before permanent confidentiality will be allowed. These also currently require review by the FCC under their Permit-But-Ask policy before the grant is issued and can delay completion of an application. Further justification should be added to the note above. One such example for a potted device would be: “The EUT is FULLY potted using a non-removable epoxy based material. Removal of potting material causes irreparable damage to internal circuitry. See photographs exhibits that outline the device before and after potting.” 4 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

Project No. : LBE20125475 LCD Monitor LS23C5** -2/26- This report must not be reproduced, except in full, without written permission from CSQAL According to Sec. 2.1077, 47 CFR of the FCC Rules. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Equipment EUT Type Class B personal computers and peripherals Kind of product LCD Monitor Trade Name Samsung Electronics Model LS23C5** (The character“*”may be 0-9，A-Z or blank，it means different color or outlook) Applied Rules FCC Part 15, Subpart B Class B ANSI C63.4-2009 Manufacturer Tianjin Samsung Electronics Co., LTD. Weisi Rd. Micro-Electronic Industrial Park, Jingang Rd. Xiqing Dist, Tianjin,300385 China We hereby declare that the equipment bearing the trade name and model number specified above was tested conforming to the applicable FCC Rules under the most accurate measurement standards possible, and that all the necessary steps have been taken and are in force to assure that production units of the same equipment will continue to comply with the Commission’s requirements. U.S. RESPONSIBLE PARTY Samsung Electronics America QA Lab 18600 Broad wick St. Rancho Dominguez CA 90220 CONTACT PERSON Mr. Peter Ra, Manager E-Mail : [email protected] Tel : 1-310-900-5250 Fax : 1-310-537-5500 Project No. : LBE20125475 LCD Monitor LS23C5** -3/26- This report must not be reproduced, except in full, without written permission from CSQAL Table of contents 1. Summary of test results 1.1 Emission 2. General Information 2.1 Test facility 3. Test configuration 3.1 Test Peripherals 3.2 EUT operating mode 3.3 Details of Sampling 3.4 Used cable description 3.5 EUT Description 3.6 Description of the EUT exercising method 3.7 Measurement uncertainty 4. Result of individual tests 4.1 Conducted disturbance 4.2 Radiated disturbance Appendix – EUT photography Project No. : LBE20125475 LCD Monitor LS23C5** -4/26- This report must not be reproduced, except in full, without written permission from CSQAL 1. Summary of test results The EUT has been tested according to the following specifications: Applied Test type Applied standard Result Remarks Conducted Disturbance FCC Part 15 Subpart B ANSI C63.4-2009 Complied Meets Class B Limit Radiated Disturbance Complied Meets Class B Limit - Note : These results are deemed satisfactory evidence of compliance with ICES-003 of the Canadian Interference-Causing Equipment Regulations. 2. General Information 2.1 Test facility The following firm has submitted the information required by Section 2.948 of the FCC Rules for measuring devices subject to Certification under Parts 15 & 18. The FCC takes no responsibility regarding the capability of this firm for performing the required measurements. Accordingly, this firm should not advertise or otherwise imply FCC approval of CSQAL. CHINA SAMSUNG QUALITY ASSURANCE LABORATORY is LOCATED ON Block D, 17‐19, Wei 4 Road, Microelectronics Industrial Park, Jingang Highway, Tianjin China. Registration Number: 745769 E-mail Address:[email protected] Phone Number:86-22-2396-1234-5211 All testing are performed in Semi-anechoic chambers conforming to the site attenuation Characteristics defined by ANSI C63.4, CISPR 22, 16-1 and 16-2 and Shielded rooms. CSQAL is operated as testing laboratory in accordance with the requirements of ISO/IEC 17025:2005. Project No. : LBE20125475 LCD Monitor LS23C5** -5/26- This report must not be reproduced, except in full, without written permission from CSQAL 3. Test Setup configuration 3.1 Test Peripherals The peripherals which were interconnected to the EUT during the test are as follows: Item Model No. Serial No. Manufacturer Note LCD Monitor LS23C570 - Samsung EUT Adaptor AD-3014B CN07BN4400394KSE38C9K05XX Samsung PC DM-V200-PA15 ZLPZ9WAZ500828F Samsung - USB Keyboard SK-8185 OY526K Dell - USB Mouse MOC5UO J0F0217Q Dell - Printer ML-2545 Z6FJBACB600011N Samsung - 3.2 EUT operating mode(s) To achieve compliance applied standard specification, the following mode(s) were made during compliance testing: Operating Mode 1 D-Sub (PC Video IN or Analog) IN Display Operating Mode 2 HDMI IN Display 3.3 Details of Sampling Customer selected, single unit. 3.4 Cable description The type(s) of cables which were connected to the ports (of the EUT) are as follows: No Connect Cable Length [m] Ferrite core [Y/N] Remark 1 VGA in 1.5 Y To PC 2 HDMI in 1.8 Y To PC 3 POWER 1.8 N FOR EUT 4 Earphone 1.5 N FOR EUT Project No. : LBE20125475 LCD Monitor LS23C5** -6/26- This report must not be reproduced, except in full, without written permission from CSQAL 3.5 EUT Description The following features describe EUT represented by this report: Model Name: LS23C570 Project No. : LBE20125475 LCD Monitor LS23C5** -7/26- This report must not be reproduced, except in full, without written permission from CSQAL Project No. : LBE20125475 LCD Monitor LS23C5** -8/26- This report must not be reproduced, except in full, without written permission from CSQAL 3.6 Description of the EUT exercising method The EUT exercise program used during EMI testing was CSQAL standardized test program for MS Windows. The program repetitively sends a screen of H – Character to the display. Connect video output of computer on EUT’s PC IN (D-sub),HDMI port and scrolled H – character continuously on EUT’s screen. The EUT system includes a monitor, the operational conditions shown as follows, within the selected area. Notes: 1. Set the brightness control to maximum 2. Set the contrast control to maximum 3. Display a pattern of a full screen of scrolling letter-H characters with a font size to get as close as possible to three characters per linear cm and use single line spacing Project No. : LBE20125475 LCD Monitor LS23C5** -9/26- This report must not be reproduced, except in full, without written permis…

Text truncated - open the document above for the full version.
