PRINTINGTASKS 5.20 Reprinting the Last Page The Samsung ML-1200 Series printer’s memory always keeps the last page of the last job. If you canceled a print job due to a paper jam or other problems and you want to know which page was printed last, reprint the last page. Press Cancel/Reprintbriefly in Ready mode. TToo ddiissaabbllee tthhiiss ffeeaattuurree:: 1. From the SSttaarrtt menu, select SSeettttiinnggss and then PPrriinntteerrss . 2. Click the right mouse button on the SSaammssuunngg MMLL--11220000 SSeerriieess printer icon and select PPrrooppeerrttiieess to open the properties window. 3. From the GGrraapphhiicc tab, Select OOffff from the RReepprriinntt drop-down list. With this option Off, you cannot reprint the last page from the control panel. When you want to reprint the last page on the control panel, you must select OOnn from the list. 4. Click OOKK . Note: If you want to prevent somebody from reprinting your document, you can turn the Reprinting feature off in the printer’s properties dialog box. When you turn the feature off in the printer’s properties, the CCaanncceell//RReepprriinntt button on the control panel does not perform the reprinting operation. PRINTINGTASKS 5.21 Printing on a Network Environment If you work in a network environment, you can connect your ML-1200 Series printer directly to a selected computer (called the “host computer”) on the network. The printer can then be shared by other users on the network through a Windows 9x, Me, NT 4.0 or 2000 network printer connection. Note:You need to install the Samsung ML-1200 Series printer driver on each computer that will print documents to the printer. 1 Start Windows. 2 From the Startmenu, select Control Panel, and double-click on the Networkicon. 3 Check the File and Print Sharing box, then click OK. Close the window. 4 Click Start and select Printersfrom Settings, then double-click your printer name. 5 Select Propertiesin the Printers menu. 6 Click the Sharingtab, then check the Shared Asbox. Fill in the Shared Name field, then click OK. Setting Up Host Computer P RINTINGTASKS 1 Right-click Start, and selectExplorer. 2 Open your network folder in the left column. 3 Right-click the shared name, and select Capture Printer Port. 4 Select the port you want, check the Reconnect at log on box, then click OK. 5 From the Startmenu, select Settings, then Printers. 6 Double-click your printer icon. 7 From the Printersmenu, select Properties. 8 Press the Detailstab, select the printer port, then click OK. Setting Up Client PC Printing on a Network Environment 5.22 chapter This chapter provides suggestions for high-quality and economical printing and information for maintaining the toner cartridge and the printer. Topics included in this chapter are: Maintaining Toner Cartridge Cleaning the Printer 6 6 MAINTAININGYOURPRINTER 6.1 Maintaining Toner Cartridge To get the most from the toner cartridge, keep the following guidelines in your mind. • Do not remove the toner cartridge from its package until you are ready to use. • Do not refill toner cartridges.The printer warranty does not cover damage caused by using a refilled cartridge. • Store toner cartridges in the same environment as the printer. • Do not remove a toner cartridge from the printer except to replace it, clean it or clear a paper jam. Replace the cartridge immediately. • To prevent damage to the toner cartridge, do not expose it to light for more than a few minute. Toner cartridge storage The life of the toner cartridge depends on the amount of the toner that print jobs require. When printing text at 5 % coverage, a new toner cartridge lasts an average of 2,500 pages. (But, the toner cartridge supplied with the printer lasts an average of 1,000 pages.) Toner cartridge life expectancy After you install a new toner cartridge (see page 2.2), follow the instructions included in the toner cartridge box to recycle the old cartridge. Recycling toner cartridge To save toner, press the Toner Savebutton on the printer control panel. The button will be lit. You can also enable the Toner Save Modein your printer properties. Refer to “Using Toner Save Mode” on page 5.6. Selecting this option will expend the life of the toner cartridge and reduce your cost per page, but will reduce print quality. Saving toner MAINTAININGYOURPRINTER 6.2 Toner Cartridge When toner is low, faded or light areas may appear on a printed page. You may be able to temporarily improve print quality by redistributing the toner. The following procedures may allow you to finish the current print job before replacing the toner cartridge. Redistributing Toner 1Grasp the front cover by both sides of the cover and pull it toward you to open. 2Remove the toner cartridge from the printer. 3Gently shake the toner cartridge from side to side 5 or 6 times to redistribute the toner. Note:If the toner gets on your clothing, wipe it off with a dry cloth and wash clothing in cold water. Hot water sets toner into fabric. CAUTIONS: • Avoid reaching too far into the printer. The fusing area may be hot. • To prevent damage to the toner cartridge, do not expose it to light formore than a few minute. MAINTAININGYOURPRINTER 6.3 Toner Cartridge 4Reinsert the toner cartridge into the printer. Be sure that the toner cartridge snaps in its place. 5Firmly close the cover. If the print remains light Remove the old cartridge and install a new toner cartridge. See “Install the Toner Cartridge” on page 2.2. ATTENTION: OPC Cleaning • After every 500 page printing, your printer will automatically clean the OPC drum inside the toner cartridge and produce a OPC cleaning sheetwith the toner debris. MAINTAININGYOURPRINTER 6.4 Cleaning the Printer To maintain print quality, follow the cleaning procedures below every time the toner cartridge is replaced or whenever print quality problems occur. As much as possible, keep the printer free from dust and debris. Notes: • Do not use ammonia-based cleaners or volatile solvents such as thinne…

Text truncated - open the document above for the full version.

This manual is provided for information purposes only. All information included herein is subject to change without notice. Samsung Electronics is not responsible for any damages, direct or indirect, arising from or related to use of this manual. © 2001 Samsung Electronics Co., Ltd. All rights reserved. • ML-1200 Series and Samsung logo are trademarks of Samsung Electronics Co., Ltd. • Centronics is a trademark of Centronics Data Computer Corporation. • IBM and IBM PC are trademarks of International Business Machines Corporation. • Microsoft, Windows, Windows 9x, Windows Me, Windows NT and Windows 2000 are trademarks of Microsoft Corporation. • GNU Ghostscript software, Copyright (C) 1999. Aladdin Enterprise, Menlo Park, California, and other authors as indicated in its documentation. • Apple, Macintosh, Power Macintosh, iMac and iBook are trademarks of Apple Computer, Inc. • Adobe and Adobe Acrobat Reader are trademarks of Adobe Systems. • All other brand or product names are trademarks of their respective companies or organizations. I Special Features ––––––––––––––––––––––––––––––––– 1.1 Printer Components ––––––––––––––––––––––––––––––1.3 Control Panel Buttons –––––––––––––––––––––––––––––– 3.1 Control Panel Lights ––––––––––––––––––––––––––––––– 3.3 Contents Introduction STEP 1 :Unpack Your Printer –––––––––––––––––––––––––– 2.1 STEP 2 :Install the Toner Cartridge ––––––––––––––––––––– 2.2 STEP 3 : Load Paper ––––––––––––––––––––––––––––––––– 2.4 STEP 4 :Connect to the Computer with a Parallel Cable ––––– 2.6 STEP 5 :Turn on the Printer ––––––––––––––––––––––––––– 2.7 STEP 6 : Print a Demo Page! ––––––––––––––––––––––––––– 2.7 STEP 7 :Install the Printer Software ––––––––––––––––––––– 2.8 Installing Software from Diskette –––––––––––––––––––– 2.13 Choosing Paper and Other Media ––––––––––––––––––––– 4.1 Selecting the Output Location ––––––––––––––––––––––– 4.4 Loading Paper –––––––––––––––––––––––––––––––––––– 4.5 Printing on Envelopes –––––––––––––––––––––––––––––– 4.7 Printing on Heavy Paper –––––––––––––––––––––––––––– 4.9 Printing on Labels –––––––––––––––––––––––––––––––– 4.10 Printing on Transparencies ––––––––––––––––––––––––– 4.11 Printing on Preprinted Paper ––––––––––––––––––––––– 4.12 Printing on Card Stocks –––––––––––––––––––––––––––– 4.13 1 2 Setting Up Your Printer 3 Using Control Panel 4 Print Media II Maintaining Toner Cartridge ––––––––––––––––––––––––– 6.1 Cleaning the Printer ––––––––––––––––––––––––––––––– 6.4 Maintaining Your Printer 6 Printing a Document ––––––––––––––––––––––––––––––– 5.1 Using Toner Save Mode –––––––––––––––––––––––––––– 5.6 Printing Multiple Pages on One Sheet of Paper ––––––––––5.7 Fitting Your Document to a selected Paper Size –––––––––5.8 Printing Posters––––––––––––––––––––––––––––––––5.9 Setting Graphic Properties ––––––––––––––––––––––––– 5.11 Printing Watermarks –––––––––––––––––––––––––––––– 5.13 Using Page Overlay ––––––––––––––––––––––––––––––– 5.16 Reprinting the Last Page –––––––––––––––––––––––––– 5.20 Printing on a Network Environment ––––––––––––––––––– 5.21 Printing Tasks 5 Troubleshooting Checklist ––––––––––––––––––––––––––– 7.1 Solving General Printing Problems –––––––––––––––––––– 7.2 Clearing Paper Jams ––––––––––––––––––––––––––––––– 7.6 Solving Print Quality Problems –––––––––––––––––––––– 7.11 Troubleshooting Error Messages ––––––––––––––––––––– 7.17 Common Windows Problems –––––––––––––––––––––––– 7.19 Problem Solving 7 Printer Specifications ––––––––––––––––––––––––––––––– A.1 Paper Specifications –––––––––––––––––––––––––––––––– A.2 Using Your Printer with a USB cable –––––––––––––––––– A.10 Using Your Printer with Macintosh –––––––––––––––––––– A.16 Linux Driver Installation ––––––––––––––––––––––––––– A.23 Appendix INDEX III Environmental and Safety Consideration The printer is certified in the U.S. to conform to the requirements of DHHS 21 CFR, chapter 1 Subchapter J for Class I(1) laser products, and elsewhere is certified as a Class I laser product conforming to the requirements of IEC 825. Class I laser products are not considered to be hazardous. The laser system and printer are designed so there is never any human access to laser radiation above a Class I level during normal operation, user maintenance, or prescribed service condition. WARNING Never operate or service the printer with the protective cover removed from Laser/Scanner assembly. The reflected beam, although invisible, can damage your eyes. CAUTION - INVISIBLE LASER RADIATION WHEN THIS COVER OPEN. DO NOT OPEN THIS COVER. VORSICHT - UNSICHTBARE LASERSTRAHLUNG, WENN ABDECKUNG GEÖFFNET. NICHT DEM STRAHL AUSSETZEN. ATTENTION - RAYONNEMENT LASER INVISIBLE EN CAS D’OUVERTURE.EXPOSITION DAN GEREUSE AU FAISCEAU. ATTENZIONE -RADIAZIONE LASER INVISIBILE IN CASO DI APERTURA. EVITARE L’ESPOSIZIONE AL FASCIO. PRECAUCION -RADIACION LASER IVISIBLE CUANDO SE ABRE. EVITAR EXPONERSE AL RAYO. ADVARSEL. - USYNLIG LASERSTRÅLNING VED ÅBNING NÅR SIKKERHEDSBRYDERE ER UDE AF FUNKTION. UNDGÅ UDSAETTELSE FOR STRÅLNING. ADVARSEL. - USYNLIG LASERSTRÅLNING NÅR DEKSEL ÅPNES. STIRR IKKE INN I STRÅLEN. UNNGÅ EKSPONERING FOR STRÅLEN. VARNING - OSYNLIG LASERSTRÅLNING NÄR DENNA DEL ÄR ÖPPAND OCH SPÄRREN ÄR URKOPPLAD. BETRAKTA EJ STRÅLEN. STRÅLEN ÄR FARLIG. VARO! - AVATTAESSA JASUOJALUKITUS OHITETTAESSA OLET ALTTIINA NÄKYMÄTTÖMÄLLE LASERSÄTEILYLLE ÄLÄ KATSO SÄTEESEEN. Laser Safety Statement IV Ozone Safety Power Saver During normal operation, the Samsung ML-1200 Series printer produces ozone. the ozone produced does not present a hazard to the operator. However, it is advisable that the machine be operated in a well ventilated area. If you need additional information about ozone, please request your nearest Samsung dealer. This printer contains advanced energy conservation technology that reduces power consumption when it is not in active use. When the printer does not receive data for an extended period of time, power consumption is automatically lowered. The energy star emblem d…

Text truncated - open the document above for the full version.

chapter This chapter describes how to use the printer’s control panel. It provides information on the following topics: Control Panel Buttons Control Panel Lights 3 3 USINGCONTROLPANEL 3.1 Control Panel Buttons The printer has three buttons: Toner Save, Cancel/Reprint and Demo. Demo Clean the inside of the printer Press and hold Demofor about 2 seconds until the control panel lights blink slowly to print a demo page. The printer must be in the Ready mode. Press and hold Demofor about 10 seconds until the control panel lights remain lit. After cleaning the printer, one cleaning sheet prints. For further information, see page 6.5. Print demo page Start manual feeding When you select Manualfor Paper Sourcefrom your software application, you should press Demoeach time you load a sheet of paper manually. For further information, see “Using the Manual Input tray” on page 4.5. USINGCONTROLPANEL 3.2 Control Panel Buttons Cancel/Reprint Reprint last page of the job Press Cancel/Reprintand hold until the control panel lights blink to cancel a job the printer is currently printing. The Errorlight will blink while the print job is cleared from both the printer and the computer, and then return to the Ready mode. This may take some time, depending on the size of the print job. Note:If the Cancel/Reprintbutton is accidentally pushed, the job must be reprinted. There is no undo function. If you press Cancel/Reprintin the Ready mode, the printer prints the last page of the last print job. See page 5.20. Cancel job Toner Save Toner Save Press Toner Saveto turn the Toner save mode on or off. The printer must be in the Ready mode. • If the button backlight is on, toner save mode activates and the printer uses less toner to print a document. • If the button backlight is off, toner save mode is disabled and you will print in normal quality. To enable or disable the Toner Save mode using this button, the Toner Save Modeoption in the printer driver must be set to Printer Setting. For further information on the Toner Save mode, see page 5.6. (on) (off) Turn the Toner Save Mode on/off USINGCONTROLPANEL Control Panel Lights The control panel lights indicate the status of your printer. If the Errorlight is on, the printer is experiencing an error. See “Troubleshooting Error Messages” on page 7.17. Control Panel Light Message The Datalight is on and the printer is ready to print. No action is needed. If you press and hold the Demobutton for about 2 seconds, a demo page will print. Ready mode Error Paper Data The printer is out of paper. Load paper into the printer. For the automatic tray, there is no need to press any button to reset. For the manual tray, press the Demobutton after loading. Paper out Data Error Paper In the Manual Feed mode, the printer is waiting the Demobutton to be pressed. Press the Demobutton to start printing. You must press the button to print each page after loading paper into the manual input tray. Waiting the Demo button to be pressed Data Error Paper The printer is receiving or processing data. Wait for the job to print. Pressing the Cancel/Reprintbutton cancels the current job. One or two pages may print as the printer clears the print job. The printer will return to the Ready mode after the job has been canceled. Processing Data Error Paper 3.3 chapter This chapter will help you understand what kind of paper you can use with the Samsung ML-1200 Series printer and how to properly load paper in the different paper input trays for the best print quality. Topics included in this chapter are:  Choosing Paper and Other Media  Selecting the Output Location  Loading Paper  Printing on Envelopes  Printing on Heavy Paper  Printing on Labels  Printing on Transparencies  Printing on Preprinted Paper  Printing on Card Stocks 4 4 PRINTMEDIA 4.1 Choosing Paper and Other Media You can print on a variety of print media, such as plain paper, envelopes, labels, transparencies, card stocks, and so on. See “Paper Specification” on page A.2. To get the best possible print quality, use only high-quality copier-grade paper. When you choose print media, consider the followings: • Desired outcome: The paper you choose should be appropriate for the project. • Size: You can use any size paper that fits easily within the paper adjusters of the paper tray. • Weight: Your printer supports paper weight as follows: • 16~24 lbs bond for the automatic input tray • 16~43 lbs bond for the manual input tray • Brightness: Some papers are whiter than others and produce sharper, more vibrant images. • Surface smoothness: The smoothness of the paper affects how crisp the printing looks on the paper. Always test a sample of paper before purchasing large quantities. CAUTION:Using media that does not confirm to the specification listed in the paper specification can cause problems that may require service. This service is not covered by the warranty or service agreements. PRINTMEDIA 4.2 Choosing Paper and Other Media Plain Paper Letter (8.5 x 11 in.) Legal (8.5 x 14 in.) Executive (7.25 x 10.5 in.) A4 (210 x 297 mm) A5 (148 x 210 mm) A6 (105 x 148 mm) Folio (8.5 x 13 in.) B5 (182 x 257 mm) Envelopes No. 10 (4.12 x 9.5 in.) DL (110 x 220 mm) C5 (162 x 229 mm) C6 (114 x 162 mm) B5 (176 x 250 mm) Monarch (3.87 x 7.5 in.) Labels Letter (8.5 x 11 in.) A4 (210 x 297 mm) Transparency films Letter (8.5 x 11 in.) A4 (210 x 297 mm) Card stocks Bond Automatic Input Tray 150 150 150 150 150 50 150 – 5 5 5 5 5 5 5 5 5 5 5 5 Manual Input Tray 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 Media Sizes and Capacities Input Source/Capacity* Media Size *Depending on paper thickness, maximum capacity may be reduced. When selecting or loading paper, envelopes, or other special media, keep these guidelines in your mind: • Attempting to print on damp, curled, wrinkled, or torn paper cancause paper jamsand poor print quality. • Usecut-sheet paper only. You cannot use multi-part paper. • Use onlyhigh-quality, copier grade paper. • Do notuse paper th…

Text truncated - open the document above for the full version.

Front view of EUT Rear view of EUT Internal view of EUT Side view of EUT

Page 13 of 14 JOB NO. : 01ISM025 7. Label and Label Location 7.1 Label 7.2 Label location This test reports does not constitute an endorsement by NIST/NVLAP or U.S Government.

PCBs view of HVPS b'd Solder view of HVPS b'd FRONT view of LSU REAR view of LSU PCB view of OP b'd Solder view of OP b'd PCB view of POWER b'd Solder view of POWER b'd PCB view of PTL b'd Solder view of PTL b'd PCB view of Sensor b'd Solder view of Sensor b'd PCB view of Controller b'd Solder view of Controller b'd

Page 2 of 14 JOB NO. : 01ISM025 Table of Contents 1. General Information 1.1 Product Description 1.2 Tested System Details 1.3 Test Methodology 1.4 Test Facility 2. System Test Configuration 2.1 Operation Environment 2.2 Justification 2.3 EUT Exercise Software 2.4 Test Procedure 2.5 Test System configuration 3. Conducted and Radiated Measurement Photos 3.1 Conducted Measurement Photos 3.2 Radiated Measurement Photos 4. Measurement Uncertainty 4.1 Conducted Emission Test 4.2 Radiated Emission Test 5. Conducted Emission Test Data 6. Radiated Emission Test Data 7. Label and Label Location 8. Test Equipment Used This test reports does not constitute an endorsement by NIST/NVLAP or U.S Government. Page 3 of 14 JOB NO. : 01ISM025 1. General Information APPLICANT :SAMSUNG ELECTRONICS CO., LTD. ADDRESS :416, Maetan-3Dong, Paldal-Gu Suwon-City, Kyungki-Do, Korea 442-742 CONTACT PERSON :KyungMook,Kang TEL. +82-31-200-1449 CONTACT ADDRESS :416, Maetan-3Dong, Paldal-Gu Suwon-City, Kyungki-Do, Korea 442-742 REGULATION(S) :FCC Part 15 Subpart B, Class B MODEL NUMBER :ML-1210 SERIAL NUMBER :- KIND OF PRODUCT :LBP TESTED DATE :April 11,2001 TEST SITE :3meter semi-anechoic chamber TEST SITE ADDRESS :San 14, Nongseo-Ri, Kihung-Eup, Yongin-City, Kyungki-Do, Korea, 449-900 This test reports does not constitute an endorsement by NIST/NVLAP or U.S Government. Page 4 of 14 JOB NO. : 01ISM025 1.1 Product Description The Samsung ML-1200 print at 600 dots per inch,12 pages-per-minute. Standard 150 sheet automatic input tray and a 1-sheet manual input tray support various sizes,types. Main System Clock is 66MHz,and Vedeo clock is 44MHz, 10MHz Cristal. Power rating is AC100~127V and 250W Power consumption during operation and less than in sleep mode. See the attached ML-1210 User's Guide for more information. 1.2 Tested System Details The FCC IDs for all equipment, plus descriptions of all products used in the tested system are: Device TypeManufacturerModel NumberSerial No.FCC ID / DoC (1)LBPSamsungML-1210N/AA3LML1210 (EUT) (2)PCSAMSUNGTD260-DTC92DK409981FCC DoC (3)MonitorSamsungSyncMaster400TFTH4KH700353FCC DoC (4)KeyboardHP5183-9980J94003612FCC DoC (5)MouseSejinSMB-4004FEF027845GJJS965CO (6)External ModemUS RoboticsSPORTSTER33083962CJE-0149-217 1.3 Test Methodology Both conducted and radiated testing were performed according to the procedures in FCC/ANSI C63.4(1992). Radiated testing was performed at a distance of 3 meters from the antenna to EUT. 1.4 Test Facility All test described in this report were performed by : Open area test site : 781-14, Chung-Ri, Dongtan-Myun, Hwasung-Kun, Kyungki-Do, Korea Conducted measurement facility and 3meter Semi-anechoic chamber : San 14, Nongseo-Ri, Kihung-Eup,Yongin-City, Kyungki-Do, Korea, 449-900 This test reports does not constitute an endorsement by NIST/NVLAP or U.S Government. Power rating is AC100~127V and 250W Power consumption during operation and less than in sleep mode. Page 5 of 14 JOB NO. : 01ISM025 2. System Test Configuration 2.1 Operation Environment ConductionRadiation Temperature [] :25.525.5 Humidity [%] :2222 Power supply :AC120V/60HzAC120V/60Hz 2.2 Justification The system was configured in typical fashion(as a customer would normally use it) for testing. 2.3 EUT Exercise Soft ware The EUT exercise program used during radiated and conducted testing is word editor(Hun2000).Type H character on decument 10 page and then execute print to EUT continuously. 2.4 Test Procedure 2.4.1 Conducted Emissions EUT was placed on a platform of nominal size, 1m by 1.5m, raised 80cm above the conducting ground plane. The rear of tabletop was located 40cm to the vertical conducting ground plane. The rear of EUT, including peripherals was aligned and flush with rear of tabletop. All other surfaces of tabletop was at least 80cm from any other grounded conducting surface. I/O cables and AC cables that were connected to the peripherals were bundled in center. They were folded back and forth forming a bundle 30cm to 40cm long and were hanged at a 40cm height to the ground plane. Each EUT current-carrying power lead, except the ground(safety) lead, were individually connected through a LISN to the input power source. This test reports does not constitute an endorsement by NIST/NVLAP or U.S Government. Page 6 of 14 JOB NO. : 01ISM025 All unused 50 ohm connectors of the LISN were resistively terminated in 50 ohm when not connected to the measuring equipment. 2.4.2 Radiated Emissions EUT was placed on a platform of nominal size, 1m by 1.5m, raised 80cm above the conducting ground plane. The rear of EUT, including peripherals was aligned and flush with rear of tabletop. I/O cables that were connected to the peripherals were bundle in center. They were folded back and forth forming a bundle 30cm to 40cm long and were hanged 40cm height to the ground plane. Test was made with the antenna positioned in both the horizontal and vertical planes of polarization. The measurement antenna was varied in height above the conducting ground plane to obtain the maximum signal strength. 2.5 Test System configuration 2.5.1 System Block Diagram of Test Configuration This test reports does not constitute an endorsement by NIST/NVLAP or U.S Government. 6 D D 5 4 2 1 3 9 F B A C E 11 10 8 G 7 Page 7 of 14 JOB NO. : SEMC1007 2.5.2 Configuration of EUT and peripherals MarkItemModel No.Serial No.ManufacturerRemark ADesktop computerTD260-DTC92DK409981Samsung BExternal ModemSPORTSTER33083962US ROBOTICS CMonitorSyncMaster400TFTH4KH700353Samsung DLaser PrinterML-1210-SamsungEUT EPS/2 MouseSMB-4004FEF027845SEJIN FKeyboard 5183-9980J94003612 HP GAC/DC AdaptorAW-1220A-AnJeon 2.5.3 Used Cable Description No.ItemLength[m]Shielded(Y/N) 1AC Power cable1.7N 2Video cable1.5Y 3Serial cable1.5Y 4Mouse cable2Y 5Printer cable1.5Y 6Keyboard Cable1.5Y 7DC Power cable1.7N 8AC Power cable1.7N 9AC Power cable1.7N 10AC Power cable1.7N 11USB1.8Y This report shall not be reproduced except in full, without the written approval of SEC…

Text truncated - open the document above for the full version.

Page 8 of 14 JOB NO. : 01ISM025 3. Conducted and Radiated Measurement Photos * Cabling was taken into consideration and test data was taken under worse case conditions. 3.1 Conducted Measurement Photos Conduction(Front View) Conduction(Rear View) This test reports does not constitute an endorsement by NIST/NVLAP or U.S Government. Page 9 of 14 JOB NO. : 01ISM025 * Cabling was taken into consideration and test data was taken under worse case conditions. 3.2 Radiated Measurement Photos Radiation(Front View) Radiation(Rear View) This test reports does not constitute an endorsement by NIST/NVLAP or U.S Government.
