A3LML1630Laser Printer

Monochrome Laser Printer User’s Guide ML-1630 Series © 2007 Samsung Electronics Co., Ltd. All rights reserved. This user’s guide is provided for information purposes only. All information included herein is subject to change without notice. Samsung Electronics is not responsible for any changes, direct or indirect damages, arising from or related to use of this user’s guide. • ML-1630 is model names of Samsung Electronics Co., Ltd. • Samsung and Samsung logo are trademarks of Samsung Electronics Co., Ltd. • Microsoft, Windows, Windows XP and Windows Vista are either registered trademarks or trademarks of Microsoft Corporation. • UFST® and MicroType™ are registered trademarks of Monotype Imaging Inc. • TrueType, LaserWriter and Macintosh are trademarks of Apple Computer, Inc. • All other brand or product names are trademarks of their respective companies or organizations. CONTACT SAMSUNG WORLD WIDE If you have any comments or questions regarding Samsung products, contact the Samsung customer care center. CountryCustomer Care Center Web Site ARGENTINE0800-333-3733www.samsung.com/ar AUSTRALIA1300 362 603www.samsung.com/au BELGIUM02 201 2418www.samsung.com/be BRAZIL0800-124-421 4004-0000 www.samsung.com/br CANADA1-800-SAMSUNG (7267864)www.samsung.com/ca CHILE800-726-7864 (SAMSUNG)www.samsung.com/cl CHINA800-810-5858 010- 6475 1880 www.samsung.com.cn COLOMBIA01-8000-112-112www.samsung.com/co COSTA RICA0-800-507-7267www.samsung.com/latin CZECH REPUBLIC 844 000 844www.samsung.com/cz Distributor pro ýeskou republiku : Samsung Zrt., þeska organizaþní složka Vyskoþilova 4, 14000 Praha 4 DENMARK70 70 19 70www.samsung.com/dk ECUADOR1-800-10-7267www.samsung.com/latin EL SALVADOR800-6225www.samsung.com/latin ESTONIA800-7267www.samsung.ee KAZAHSTAN8-800-080-1188www.samsung.kz FINLAND030-6227 515www.samsung.com/fi FRANCE3260 SAMSUNG or 08 25 08 65 65 (€ 0,15/min) www.samsung.com/fr GERMANY01805 - 121213 (€ 0,14/min) www.samsung.de GUATEMALA1-800-299-0013www.samsung.com/latin HONG KONG3698 4698www.samsung.com/hk HUNGARY06-80-SAMSUNG (7267864)www.samsung.com/hu INDIA3030 8282 1800 110 011 www.samsung.com/in/ INDONESIA0800-112-8888www.samsung.com/id ITALIA800-SAMSUNG(7267864)www.samsung.com/it JAMAICA1-800-234-7267www.samsung.com/latin JAPAN0120-327-527www.samsung.com/jp LATVIA800-7267www.samsung.com/lv/ index.htm LITHUANIA8-800-77777www.samsung.com/lt LUXEMBURG0032 (0)2 201 24 18www.samsung.lu MALAYSIA1800-88-9999www.samsung.com/my MEXICO01-800-SAMSUNG (7267864) www.samsung.com/mx NETHERLANDS0900 20 200 88 (€ 0,10/min)www.samsung.com/nl NORWAY815-56 480www.samsung.com/no PANAMA800-7267www.samsung.com/latin PHILIPPINES1800-10-SAMSUNG (7267864) www.samsung.com/ph POLAND0 801 801 881www.samsung.com/pl PORTUGAL80 8 200 128www.samsung.com/pt PUERTO RICO1-800-682-3180www.samsung.com/latin REP. DOMINICA 1-800-751-2676www.samsung.com/latin Republic of Ireland 0818 717 100www.samsung.com/uk RUSSIA8-800-200-0400www.samsung.ru SINGAPORE1800-SAMSUNG (7267864)www.samsung.com/sg SLOVAKIA0800-SAMSUNG (726786)www.samsung.com/sk SOUTH AFRICA 0860 726 7864 (SAMSUNG)www.samsung.com/za SPAIN902 10 11 30www.samsung.com/es SWEDEN0771-400 200www.samsung.com/se Switzerland0800-7267864www.samsung.com/ch/ TAIWAN0800-329-999www.samsung.com/tw THAILAND1800-29-3232 02-689-3232 www.samsung.com/th TRINIDAD & TOBAGO 1-800-7267-864www.samsung.com/latin U.A.E800-SAMSUNG (7267864)www.samsung.com/mea U.K0870 SAMSUNG (7267864)www.samsung.com/uk U.S.A1-800-SAMSUNG (7267864)www.samsung.com UKRAINE8-800-502-0000www.samsung.com/ur UZBEKISTAN8-800-120-0400www.samsung.com.uz VENEZUELA0-800-100-5303www.samsung.com/latin VIETNAM1 800 588 889www.samsung.com/vn CountryCustomer Care Center Web Site CONTENTS About this user’s guide .................................................................................................................................................i Finding more information .............................................................................................................................................i Safety and Regulatory Information .............................................................................................................................. ii 1. Introduction Special features ...................................................................................................................................................... 1.1 Machine overview ................................................................................................................................................... 1.2 Front view ........................................................................................................................................................... 1.2 Rear view ............................................................................................................................................................ 1.3 Control panel overview ........................................................................................................................................... 1.4 2. Software overview Supplied software .................................................................................................................................................... 2.1 Printer driver features .............................................................................................................................................. 2.2 System requirements .............................................................................................................................................. 2.2 3. Getting Started Setting up the hardware .......................................................................................................................................... 3.1 Altitude adjustment .................................................................................................................................................. 3.2 4. Selecting and loading print me…

Text truncated - open the document above for the full version.

2(11) Fig 01 (SCX-4500***) Fig 02 (SCX-4500***) 3(11) Fig 03 (SCX-4500***) Fig 04 (SCX-4500***) 4(11) Fig 05 (ML-163****) Fig 06 (ML-163****) 5(11) Fig 07 (ML-163****) Fig 08 (ML-163****) 6(11) Fig 09 (SCX-4500***, ML-163****) Fig 10 (SCX-4500***, ML-163****)

-25/27- 4.3 Label and Label Location ( Samsung Electronics Co., Ltd ) -26/27- ( Samsung Electronics(Shandong)Digital Printing Co., Ltd ) Picture 7. Label -27/27- Picture 8. Label location

7(11) Fig 11 (SCX-4500***, ML-163****) Fig 12 (SCX-4500***, ML-163****) 8(11) Fig 13 (SCX-450***, ML-163****) Fig 14 (SCX-4500***, ML-163****) 9(11) Fig 15 (SCX-4500***, ML-163****) Fig 16 (SCX-4500***, ML-163****) 10(11) Fig 17 (SCX-4500***, ML-163****) Fig 18 (SCX-4500***, ML-163****) 11(11) Fig 19 (SCX-4500***, ML-163****) Fig 20 (SCX-4500***, ML-163****)

-5/27- 1.2 Detail Information related product 1.2.1 Specification ItemSpecification and Description Processor Jupiter4e(ARM940T, 150MHz) Standard System memory 8MB SDRAM Resolution 600x600dpi(1200 dpi Class) Copy Quality mode NA Paper Handling Paper Tray(standard) 100 Sheets 2nd Tray(optional) : NA Bypass Tray : NA Power Rating 110~127 VAC, 4.0A, 50/60 Hz Power Consumption Power save mode : 8.12Watts Stand by mode : 8.12Watts Printing simplex : 300Watts Printer Language GDI Interfaces USB2.0 OS compatibility Windows 2000 / XP / 2003 / Vista Linux Mac OS 10.3 Modes of Operation USB Printing Intended Class for Emissions Class B Operating Frequency Main Source Clock : 12MHz, Video Clock : 19.75MHz, CPU Internal Clock : 150MHz SDRAM Clock : 75MHz, USB Device Clock : 12MHz, OPE : 115.2KHz

-1/27- EMC TEST REPORT Samsung Electronics Co., Ltd. 416 Maetan 3-Dong, Yeongtong-Gu, Suwon-Si,Gyeonggi-Do, 443-742 Korea (Tel: 82 31 277 7752, Fax: 82 31 277 7753) Project No. : LBE071509 Page (1)/(27) 1. Applicant ◦ Name of organization : Samsung Electronics Co., Ltd. ◦ Address : 416 Maetan 3-Dong, Yeongtong-Gu, Suwon-Si, Gyeonggi-Do, 443-742 Korea ◦ Date of application : 2007. 04. 27 2. Purpose for the report : Approval for EMC 3. Kind of product : Printer (Model name :ML-1630) 4. Date of test : 2007. 05. 02 ~ 2007. 05. 11 5. Applied standard : FCC Part 15, Subpart B 6. Test result : Complied The equipment under test has found to be compliant with the applied standards. (Refer to the attached test result for more detail.) Tested by Name : Sang Kyu, seo Reviewed by Name : No Cheon Park This report is the test result about the sphere accredited by KOLAS which signed the Mutual Recognition Arrangement of International Laboratory Accreditation Cooperation. 2007. 05. 18 Samsung Electornics Co., Ltd. Chief of CS Management Center -2/27- TEST RESULT Test Report No. : LBE071509 Applicant / Address : Samsung Electronics Co., Ltd. 416 Maetan 3-Dong, Yeongtong-Gu,Suwon-Si,Gyeonggi-Do 443-742 Korea Manufacture / Address : 1) Samsung Electronics Co.,Ltd. 259, Gongdan-Dong, Gumi-City, Gyeongsangbuk-Do, 730-030 Korea 2) Samsung Electronics(Shandong) Digital Printing Co., Ltd. 264209, Samsung Road, Weihai Hi-Tech IDZ, Shandong Province, China 3) Weihai Shin Heung Digital Electronics Co., Ltd. 98, Samsung Road, Weihai H-Tech. IDZ, Shandong Province, P.R.China EUT : 1. Product name : Printer 2. Model name : ML-1630 3. Brand name : SAMSUNG 4. Variant model : ML-1630S 5. FCC ID : A3LML1630 Test Method : ANSI C 63.4:2003 Test Result : PASS The equipment under test has found to be compliant with the applied standards Test Lab. : CS Management Center, Samsung Electronics Co., Ltd. Tested by : Sang Kyu, Seo Reviewed by : No Cheon Park Date of Issue : 2007. 05. 18 -3/27- Table of contents 1. General information 1.1 Basic information related product 1.2 Detail information related product 1.3 Operating mode and condition 1.4 Equipment modifications 1.5 Test procedure 1.6 Test configuration 1.7 Applied standard 1.8 Test facility 2. Summary of test results 3. Description of individual tests 3.1 Conducted emission 3.2 Radiated emission 4. Appendix 4.1 Test photography 4.2 EUT photography -4/27- 1. General information 1.1 Basic information related product Applicant Samsung Electronics Co., Ltd. Model name ML-1630 Applicant address 416 Maetan 3-Dong, Yeongtong-Gu,Suwon-Si,Gyeonggi-Do 443-742 Korea Contact person Sangsu ROH Kind of product Printer Valiant model ML-1630S FCC ID A3LML1630 Manufacturer 1) Samsung Electronics Co.,Ltd. 259, Gongdan-Dong, Gumi-City, Gyeongsangbuk-Do, 730-030 Korea 2) Samsung Electronics(Shandong) Digital Printing Co., Ltd. 264209, Samsung Road, Weihai Hi-Tech IDZ, Shandong Province, China 3) Weihai Shin Heung Digital Electronics Co., Ltd. 98, Samsung Road, Weihai H-Tech. IDZ, Shandong Province, P.R.China Rated power AC 120 V, 60 Hz New / Alternative / Permissive change information New -5/27- 1.2 Detail Information related product 1.2.1 Specification ItemSpecification and Description Processor Jupiter4e(ARM940T, 150MHz) Standard System memory 8MB SDRAM Resolution 600x600dpi(1200 dpi Class) Copy Quality mode NA Paper Handling Paper Tray(standard) 100 Sheets 2nd Tray(optional) : NA Bypass Tray : NA Power Rating 110~127 VAC, 4.0A, 50/60 Hz Power Consumption Power save mode : 8.12Watts Stand by mode : 8.12Watts Printing simplex : 300Watts Printer Language GDI Interfaces USB2.0 OS compatibility Windows 2000 / XP / 2003 / Vista Linux Mac OS 10.3 Modes of Operation USB Printing Intended Class for Emissions Class B Operating Frequency Main Source Clock : 12MHz, Video Clock : 19.75MHz, CPU Internal Clock : 150MHz SDRAM Clock : 75MHz, USB Device Clock : 12MHz, OPE : 115.2KHz -6/27- 1.3 Operating mode and condition The system was configured for testing in typical fashion use. Cable were attached to each of the available I/O port. Where applicable, peripherals were attached to the I/O cables. This EUT is supporting the USB printind mode. So, all the data of EUT operation were reported. - Operating Mode - USB Printing Mode - Standby Mode - Test Voltage : 120 V, 60 Hz 1.4 Equipment modifications No equipment modifications were required. -7/27- 1.5 Test procedure 1.5.1 Conducted emission EUT was placed on a platform nominal size, 1 m by 1.5 m, raised 80 cm above the conducting ground plane. The rear of tabletop was located 40 cm to the vertical conducting ground plane. The rear of EUT, including peripherals was aligned and flush with rear of tabletop. All other surfaces of tabletop was at least 80 cm from any other grounded conducting surface. I/O cables and AC cables that were connected to the peripherals were bundled in center. They were folded back and forth forming a bindle 30 cm to 40 cm long and were handed at a 40 cm height to the ground plane. Each EUT current-carrying power lead, except the ground(safety) lead, were individually connected through a LISN to the input power source. All unused 50 ohm connectors of the LISN were resistively terminated in 50 ohm when not connected to the measuring equipment. Frequency Band [MHz] Instrument Detector Resolution Bandwidth Video Bandwidth Quasi-Peak 9 kHz - 0.15 to 30 EMI Receiver Average 9 kHz - -8/27- 1.5.2 Radiated emission EUT was placed on a platform of nominal size, 1 m by 1.5 m, raised 80 cm above the conducting ground plane. The rear of EUT, including peripherals was aligned and flush with rear of tabletop. The I/O cables that were connected to the peripherals were bundle in center. They were folded back and forth forming a bundle 30 cm to 40 cm long and were hanged 40 cm height to the ground plane. Test was made with the antenna positioned in both the horizontal and vertical planes of polarization. The measurement antenna was varied in height abo…

Text truncated - open the document above for the full version.

-22/27- 4. Appendix 4.1 Test photography Picture 1. Conducted Emission (Front) Picture 2. Conducted Emission (Rear) -23/27- Picture 3. Radiated emission (Front) Picture 4. Radiated emission (Rear)
