A3LML2510Laser Printer

This manual is provided for information purposes only. All information included herein is subject to change without notice. Samsung Electronics is not responsible for any direct or indirect damages, arising from or related to the use of this manual. © 2006 Samsung Electronics Co., Ltd. All rights reserved. • ML-2510, ML-2570, and ML-2571N are model names of Samsung Electronics Co., Ltd. • Samsung and Samsung logo are trademarks of Samsung Electronics Co., Ltd. • Centronics is a trademark of Centronics Data Computer Corporation. • IBM and IBM PC are trademarks of International Business Machines Corporation. • PCL and PCL 6 are trademarks of Hewlett-Packard company. • Microsoft, Windows, Windows 98, Windows Me, Windows 2000, Windows NT 4.0, Windows XP, and Windows 2003 are registered trademarks of Microsoft Corporation. • PostScript 3 is a trademark of Adobe System, Inc. • UFST® and MicroType™ are registered trademarks of Monotype Imaging Inc. • TrueType, LaserWriter, and Macintosh are trademarks of Apple Computer, Inc. • All other brand or product names are trademarks of their respective companies or organizations. Contact SAMSUNG WORLD WIDE If you have any comments or questions regarding Samsung products, contact the SAMSUNG customer care center. CountryCustomer Care Center Web Site CANADA1-800-SAMSUNG (7267864) www.samsung.com/ca MEXICO01-800-SAMSUNG (7267864) www.samsung.com/mx U.S.A1-800-SAMSUNG (7267864) www.samsung.com ARGENTINE0800-333-3733www.samsung.com/ar BRAZIL0800-124-421www.samsung.com/br CHILE800-726-7864 (SAMSUNG)www.samsung.com/cl COSTA RICA0-800-507-7267www.samsung.com/latin ECUADOR1-800-10-7267www.samsung.com/latin EL SALVADOR800-6225www.samsung.com/latin GUATEMALA1-800-299-0013www.samsung.com/latin JAMAICA1-800-234-7267www.samsung.com/latin PANAMA800-7267www.samsung.com/latin PUERTO RICO1-800-682-3180www.samsung.com/latin REP. DOMINICA 1-800-751-2676www.samsung.com/latin TRINIDAD & TOBAGO 1-800-7267-864www.samsung.com/latin VENEZUELA1-800-100-5303www.samsung.com/latin BELGIUM02 201 2418www.samsung.com/be CZECH REPUBLIC 844 000 844www.samsung.com/cz DENMARK38 322 887www.samsung.com/dk FINLAND09 693 79 554www.samsung.com/fi FRANCE08 25 08 65 65 (€ 0,15/min) www.samsung.com/fr GERMANY01805 - 121213 (€ 0,12/min) www.samsung.de HUNGARY06 40 985 985www.samsung.com/hu ITALIA199 153 153www.samsung.com/it LUXEMBURG02 261 03 710www.samsung.lu NETHERLANDS0900 20 200 88 (€ 0,10/min) www.samsung.com/nl NORWAY231 627 22www.samsung.com/no POLAND0 801 801 881www.samsung.com/pl PORTUGAL80 8 200 128www.samsung.com/pt SLOVAKIA0850 123 989www.samsung.com/sk SPAIN902 10 11 30www.samsung.com/es SWEDEN08 585 367 87www.samsung.com/se U.K0870 242 0303www.samsung.com/uk RUSSIA8-800-200-0400www.samsung.ru UKRAINE8-800-502-0000www.samsung.com/ur AUSTRALIA1300 362 603www.samsung.com/au CHINA800-810-5858 010- 6475 1880 www.samsung.com.cn HONG KONG2862 6001www.samsung.com/hk INDIA3030 8282 1600 1100 11 www.samsung.com/in INDONESIA0800-112-8888www.samsung.com/id JAPAN0120-327-527www.samsung.com/jp MALAYSIA1800-88-9999www.samsung.com/my PHILIPPINES1800-10-SAMSUNG (7267864) www.samsung.com/ph SINGAPORE1800-SAMSUNG (7267864)www.samsung.com/sg THAILAND1800-29-3232 02-689-3232 www.samsung.com/th TAIWAN0800-329-999www.samsung.com/tw VIETNAM1 800 588 889www.samsung.com/vn SOUTH AFRICA0860 7267864 (SAMSUNG)www.samsung.com/za U.A.E800SAMSUNG (7267864)www.samsung.com/mea CountryCustomer Care Center Web Site CONTENTS 1. Introduction Special features ...................................................................................................................................................... 1.1 Printer overview ...................................................................................................................................................... 1.2 Control panel overview ............................................................................................................................................ 1.3 Finding more information ........................................................................................................................................ 1.3 Selecting a location ................................................................................................................................................. 1.4 2. Basic setup Printing a demo page .............................................................................................................................................. 2.1 Using toner save mode ........................................................................................................................................... 2.1 3. Software overview Supplied software .................................................................................................................................................... 3.1 Printer driver features .............................................................................................................................................. 3.2 System requirements .............................................................................................................................................. 3.2 4. Network setup Introduction ............................................................................................................................................................. 4.1 Supported operating systems ................................................................................................................................. 4.1 Installing an external wired network interface server .............................................................................................. 4.2 5. Loading print media Selecting print media ............................................................................................................................................... 5.1 Loading paper ......................................................................................…

Text truncated - open the document above for the full version.

9.9 <Troubleshooting> Common Windows problems Horizontal stripes If horizontally aligned black streaks or smears appear: • The toner cartridge may be installed improperly. Remove the cartridge and reinsert. • The toner cartridge may be defective. Install a new toner cartridge. See page 8.4. • If the problem persists, the printer may require repair. Contact a service representative. CurlIf the printed paper is curled or paper does not feed into the printer: • Turn over the stack of paper in the tray. Also try rotating the paper 180° in the tray. An unknown image repetitively appears on a next few sheets or loose toner, light print or contamination occurs. Your printer is probably being used at an altitude of 2,500 m (8,200 ft) or above. The high altitude may affect the print quality such as loose toner or light imaging. You can set this option through Printer Settings Utility or Printer Tab in printer driver’s properties. Refer to the Software Section for detail. ConditionSuggested solutions “File in Use” message appears during installation. Exit all software applications. Remove all software from the StartUp Group, then restart Windows. Reinstall the printer driver. “Error Writing to LPTx” message appears. • Ensure that the cables are connected correctly and the printer is on. • If bi-directional communication is not turned on in the driver, it will also cause this message. “General Protection Fault”, “Exception OE”, “Spool32”, or “Illegal Operation” messages appear. Close all other applications, reboot Windows, and try printing again. ConditionSuggested solutions Common PostScript problems The following situations are PostScript language specific and may occur when several printer languages are being used. “Fail To Print,” “A printer timeout error occurred,” messages appear. These messages may appear during printing. Just keep waiting until the printer finishes printing. If the message appears in standby mode or after printing has been completed, check the connection and/or whether an error has occurred. Note • Refer to Microsoft Windows 98/Me/NT 4.0/2000/XP/2003 User’s Guide that came with your PC for further information on Windows error messages. Note • To receive a printed or screen displayed message when PostScript errors occur, open the Print Options window and click the desired selection next to the PostScript errors section. ConditionPossible causeSuggested solutions PostScript file can not be printed. The PostScript driver may not be installed correctly. • Print a configuration page and verify that the PostScript version is available for printing. • Install the PostScript driver; to installing the PS printer driver, see the Software Section. • If problem consists, contact a service representative. “Limit Check Error” message appears. The print job was too complex. You might need to reduce the complexity of the page or install more memory. A PostScript error page prints. Print job may not be PostScript. Make sure that the print job is a PostScript job. Check to see whether the software application expected a setup or PostScript header file to be sent to the printer. When print a document in Macintosh with Acrobat Reader 6.0 or higher, colors print incorrectly. The resolution setting in the printer driver may not be matched with that in Acrobat Reader. Make sure that the resolution setting in your printer driver matches that in Acrobat Reader. ConditionSuggested solutions 9.10 <Troubleshooting> Common Linux problems ConditionSuggested solutions The print doesn’t print. • Check if the printer driver is installed in your system. Open Unified Driver Configurator and switch to the Printers tab in Printers configuration window to look at the list of available printers. Make sure that your machine is displayed on the list. If not, please, invoke Add new printer wizard to set up your device. • Check if the printer is started. Open Printers configuration and select your machine on the printers list. Look at the description in the Selected printer pane. If its status contains “(stopped)” string, please, press the Start button. After that normal operation of the printer should be restored. The "stopped" status might be activated when some problems in printing occurred. For instance, this could be an attempt to print document when MFP port is claimed by a scanning application. • Check if the port is not busy. Since functional components of MFP (printer and scanner) share the same I/O interface (MFP port), the situation of simultaneous access of different “consumer” application to the same MFP port is possible. To avoid possible conflicts, only one of them at a time is allowed to gain control over the device. The other “consumer” will encounter “device busy” response. You should open port configuration and select the port assigned to your printer. In the Selected port pane you can see if the port is occupied by some other application. If this is the case, you should wait for completion of the current job or should press Release port button, if you are sure that the present owner is not functioning properly. Check if your application has special print option such as “-oraw”. If “-oraw” is specified in the command line parameter then remove it to print properly. For Gimp front-end, select “print” -> “Setup printer” and edit command line parameter in the command item. The printer does not appear on the scanners list. • Check if your machine is attached to your computer. Make sure that it is connected properly via the USB port and is turned on. • Check if the scanner driver for you machine is installed in your system. Open Unified Driver Configurator, switch to Scanners configuration, then press Drivers. Make sure that driver with a name corresponding to your machine's name is listed in the window. • Check if the port is not busy. Since functional components of MFP (printer and scanner) share the same I/O interface (MFP port), the situation of simultaneous access of different “consumer” applicati…

Text truncated - open the document above for the full version.

ML-2510 H/W Block Diagram Fuser Control JUPITER4e ARM940T CACHE(4K) FLASH MEMORY (0.5MB) DMAC PLL USB 1.1 UART*2 PVC MOTORC LSUC RESET XC61FN3112F N SDRAM K4S641632 8MB CRYSTAL CY25811 12MHz FEED SENSOR FUSER FUSER Control INLET & POWER SWITCH +5V / +24V Generation 1P 2P MAIN CLUTCH AC 110V / 220V SMPS 2P MHV SUPPLY DEV THV OPC Customer Replace Unit 24VS2 COVER S/W 24VS1 Jam COVER S/W 24V EMPTY SENSOR LVDS DS90LV017A READY /ERROR T.SAVE KEY_IN 4P 3P FAN 3P HVPS 24VS1 User Interface LD PBA P-MOTOR LSU STEP MOTOR 5V LSU_5V DEVE FUSE Control MAIN SMPS FAN EEPROM FM93C66 512Kb 5V MOTOR DRIVE IC A3977 HR(Zener) 2P THERM. +3.3V / +1.8V Regulator · USB 1.1 · IEEE1284 Parallel

Report No. : LBE060422 -18/23- 4.2 EUT and Internal Photographs Picture 5. EUT (front view) Picture 6. EUT (rear view) Report No. : LBE060422 -19/23- Picture 7. EUT (right view) Picture 8. EUT (left view)

Report No. : LBE060422 -21/23- Picture 9-3. Internal(3) Report No. : LBE060422 -22/23- 4.3 Label and Label Location - Samsung Electronics Co., Ltd. ( Gumi ) - Shandong Samsung Telecommunications Co., Ltd. - Weihai Shin Heung Digital Electronics Co., Ltd. Picture 10. Label

Report No. : LBE060422 -20/23- Picture 9-1. Internal(1) Picture 9-2. Internal(2) Report No. : LBE060422 -21/23- Picture 9-3. Internal(3)

-1/23- EMC TEST REPORT Samsung Electronics Co., Ltd. 416 Maetan 3-Dong, Yeongtong-Gu, Suwon-Si,Gyeonggi-Do, 443-742 Korea (Tel: 031 277 7752, Fax: 031 277 7753) FCC Registration No. : KR0004, NVLAP Code : 200623-0 1. Applicant ◦ Name of organization : Samsung Electronics Co., Ltd. ◦ Address : 416 Maetan 3-Dong, Yeongtong-Gu, Suwon-Si, Gyeonggi-Do, 443-742 Korea ◦ Date of application : 2006.02.13 2. Manufacturer 1) Samsung Electronics Co., Ltd. 259, Gongdan-Dong, Gumi-City, Gyeongsangbuk-Do, Korea 730-030 2) Shandong Samsung Telecommunications Co., Ltd. 264209, Samsung Road, Weihai Hi-Tech. IDZ, Shandong Province, P.R.China 3) Weihai Shin Heung Digital Electronics Co., Ltd. 98, Samsung Road, Weihai Hi-Tech. IDZ, Shandong Province, P.R.China 3. Purpose for the report : Approval for EMC 4. Description of EUT 1) Kind of product : Laser Printer 2) Model name : ML-2510 3) Brand name : Samsung 4) FCC ID or DoC/Verification : A3LML2510 5) Variant model : None 5. Date of test : 2006.02.13 6. Applied standard : FCC Part 15, Subpart B, Class B 7. Report No. : LBE060422 Issue 1 8. Test result : The equipment under test has found to be compliant with the applied standards. (Refer to the attached test result for more detail.) Tested by Name : Kyeong Dong, Kim Reviewed by Name : No Cheon, Park This report is the test result about the sphere accredited by KOLAS which signed the Mutual Recognition Arrangement of International Laboratory Accreditation Cooperation. 2006. 02. 15 Samsung Electornics Co., Ltd. Chief of CS Management Center Report No. : LBE060422 -2/23- Table of contents 1. General information 1.1 Basic information related product 1.2 Detail information related product 1.3 Operating mode and condition 1.4 Equipment modifications 1.5 Test procedure 1.6 Test configuration 1.7 Applied standard 1.8 Test facility 2. Summary of test results 3. Description of individual tests 3.1 Conducted emission 3.2 Radiated emission 4. Appendix 4.1 Test Photographs 4.2 EUT and Internal photographs 4.3 Label & Label location Report No. : LBE060422 -3/23- 1. General information 1.1 Basic information related product Applicant Samsung Electronics Co., Ltd. Model name ML-2510 Applicant address 416 Maetan 3-Dong, Yeongtong-Gu,Suwon-Si,Gyeonggi-Do 443-742 Korea Contact person Kyeong Dong, Kim Kind of product Laser Printer Valiant model None Manufacturer 1) Samsung Electronics Co., Ltd. 259, Gongdan-Dong, Gumi-City, Gyeongsangbuk-Do, Korea 730-030 2) Shandong Samsung Telecommunications Co., Ltd. 264209, Samsung Road, Weihai Hi-Tech. IDZ, Shandong Province, P.R.China 3) Weihai Shin Heung Digital Electronics Co., Ltd. 98, Samsung Road, Weihai Hi-Tech. IDZ, Shandong Province, P.R.China Rated power AC 110-127 V, 50/60 Hz, 5.5 A New / Alternative / Permissive change information New 1.2 Detail Information related product 1.2.1 Specification Item Specification Remark Printing Speed Up to 24 ppm in A4 (25 ppm in Letter) - Printing Resolution Up to 1 200 x 600 dpi effective output - Memory 8 MB (not expandable) - Interface USB 1.1, IEEE 1284 Parallel - Power Rating AC 110-127 V, 50/60 Hz, 5.5 A Power Consumption 380 W average during operation / Less than 5 W in power save mode - External Dimensions 378 mm(W) X 299 mm(D) X 277 mm(H) - - Operating frequencies Main Clock(12 MHz), Video(22.503 5 MHz), SDRAM clock(75 MHz), Internal PLL(150 MHz) Report No. : LBE060422 -4/23- 1.3 Operating mode and condition The system was configured for testing in typical fashion use. Cable were attached to each of the available I/O port. Where applicable, peripherals were attached to the I/O cables. The EUT is supporting the Stand-by, USB and Parallel printing mode. In each test mode, finally we found worst case emission that is above configuration with the worst case components. So, the data of the maximum EUT operation, USB printing(1 200 dpi) was reported. - Standby mode - USB Printing mode (1 200 dpi, toner save on) : worst case emissions - Parallel Printing mode - Test Voltage : 115 V, 60 Hz 1.4 Equipment modifications No equipment modification 1.5 Test procedure 1.5.1 Conducted emission The EUT was placed on a platform nominal size, 1 m by 1.5 m, raised 80 cm above the conducting Ground plane. The rear of tabletop was located 40 cm to the vertical conducting ground plane. The rear of EUT, including peripherals was aligned and flush with rear of tabletop. All other surfaces of tabletop was at least 80 cm from any other grounded conducting surface. I/O cables and AC cables that were connected to the peripherals were bundled in center. They were folded back and forth forming a bindle 30 cm to 40 cm long and were handed at a 40 cm height to the ground plane. Each EUT current-carrying power lead, except the ground(safety) lead, were individually connected through a LISN to the input power source. All unused 50 ohm connectors of the LISN were resistively terminated in 50 ohm when not connected to the measuring equipment. Frequency Band [MHz] Instrument Detector Resolution Bandwidth Video Bandwidth Quasi-Peak 9 kHz - 0.15 to 30 EMI Receiver Average 9 kHz - Report No. : LBE060422 -5/23- 1.5.2 Radiated emission EUT was placed on a platform of nominal size, 1 m by 1.5 m, raised 80 cm above the conducting ground plane. The rear of EUT, including peripherals was aligned and flush with rear of tabletop. The I/O cables that were connected to the peripherals were bundle in center. They were folded back and forth forming a bundle 30 cm to 40 cm long and were hanged 40 cm height to the ground plane. Test was made with the antenna positioned in both the horizontal and vertical planes of polarization. The measurement antenna was varied in height above the conducting ground plane and the trun table azimuth was varied to obtain the maximum signal strength The system configuration, clock speed, mode of operation or video resolution, turntable azimuth with respect to the antenna were noted for each frequency found. The spectrum was scanned from 30 to 1 000 MHz using b…

Text truncated - open the document above for the full version.

Report No. : LBE060422 -16/23- 4. Appendix 4.1 Test Photographs Picture 1. Conducted emission (Front) Picture 2. Conducted emission (Rear) Report No. : LBE060422 -17/23- Picture 3. Radiated emission (Front) Picture 4. Radiated emission (Rear)
