A3LML6100NLaser Printer

Laser Printer User’s Guide MMLL--66110000 SSeerriieess ELECTRONICS P/N. JC68-00xxxA Rev. 1.00 Visit us at: http://samsungelectronics.com If you have access to this online service, you can download the User’s Guide and drivers from Samsung Electronics. I Trademark Notices •ML-6100, ML-6100N and Samsung logo are trademarks of Samsung Electronics Co. Ltd. •Centronics is a registered trademark of Centronics Data Computer Corporation. •HP, PCL5e, and PCL6 are registered trademarks of Hewlett-Packard Company. •IBM, IBM PC, XT, AT, PS/2 are registered trademarks of International Business Machines Corporation. •Apple, AppleTalk, TrueType, Laser Writer, Macintosh, and LocalTalk are registered trademarks of Apple Computer, inc. •Microsoft, MS-Windows, and MS-DOS are registered trademarks of Microsoft Corporation. •PostScript, is a registered trademarks of Adobe Systems, Inc. •CompuServe is a registered trademark of CompuServe Inc. •All other brand or product names are trademarks or registered trademarks of their respective companies or organizations. Copyright This manual is provided for information purposes only. All information included herein is subject to change without notice. Samsung Electronics is not responsible for any damages, direct or indirect, arising from or related to use of this manual. © 1999 Samsung Electronics Co. Ltd. All rights reserved. II Notice FCC Regulations This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reason- able protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiv- er is connected. •Consult the dealer or an experienced radio/TV technician for help. Do not make any changes or modifications to the equipment unless otherwise specified in the manual. If such changes or modifications should be made, you could be required to stop operation of the equipment. Use of shielded cable is required to comply with Class B limits in Subpart B of Part 15 of FCC Rules. Canadian Radio Interference Regulations This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the interference-causing equipment standard entitled “Digital Apparatus”, ICES-003 of the Industry and Science Canada. Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux appareils numériques de Classe B prescrites dans la norme sur le matériel brouilleur: “Appareils Numériques”, ICES-003 édictée par l’Industrie et Sciences Canada. III EC Declaration of Conformity We , SAMSUNG ELECTRONICS CO.,LTD #259, Gong Dan-Dong, Gumi-City, Kyung Buk, Korea declare sole responsibility that the ML-6100, ML-6100N Laser printer meets the intent of Directive 89/336/EEC for Electromagnetic Compatibility and Low Voltage Directive 73/23/EEC. Compliance was demonstrated to the following specifications as listed in the official journal of the European Communities: EN 50081-Emissions: EN 55022 Radiated, Class B EN 55022 Conducted, Class B EN 61000-3-2 Power Harmonics EN 61000-3-3 Voltage Fluctuations and Flicker EN 50082-Immunity: IEC 801-2 Electrostatic Discharge IEC 801-3 RF Radiated IEC 801-4 Fast Transient/Burst EN 60950-Safety IV Laser Safety Statement The printer is certified in the U.S. to conform to the requirements of DHHS 21 CFR, chapter 1 Subchapter J for Class I(1) laser products, and elsewhere is certified as a Class I laser product conforming to the requirements of IEC 825. Class I laser products are not considered to be hazardous. The laser system and printer are designed so there is never any human access to laser radiation above a Class I level during normal operation, user maintenance, or prescribed service condition. WARNINGNever operate or service the printer with the protective cover removed from Laser/Scanner assembly. The reflected beam, although invisible, can damage your eyes. CAUTION-INVISIBLE LASER RADIATION WHEN THIS COVER IS OPEN. DO NOT OPEN THIS COVER VORSICHT -UNSICHTBARE LASERSTRAHLUNG, WENN ABDECKUNG GEÖFFENT. NICHT DEM STRAHL AUSETZEN. ATTENTION -RAYONNEMENT LASER INVISIBLE EN CAS D’OVERTURE. DANGEREUSE AU FAISCEAU. ATTENZIONE -RADIAZIONE LASER INVISIBILE IN CASO DIAPERTURA. EVITARE L’ESPOSIZIONE AL FASCIO. PRECAUCION -RADIACION LASER IVISIBLE CUANDO SE ABRE. EVITAR EXPONERSE AL RAYO. ADVARSEL-USYNLIG LASERSTRÅLNING VED ÅBNING NÅR SIKKERHEDSBRYDERE ER UDE AF FUNKTION UNDGÅ UDSAETTELSE FOR STRÅLNING. ADVARSER -USYNLIG LASERSTRÅLNING NÅR DEKSEL ÅPNES. STIRR IKKE INN I STRÅLEN. UNNGÅ EKSPONERING FOR STRÅLEN. VARNING -OSYNLIG LASERSTRÅLNING NÄR DENNA DEL ÄR ÖPPAND OCH SPÄRREN ÅR URKOPPLAD. BETRAKTA EJ STRÅLEN STRÅLEN AR FARLIG. VARO -AVATTAESSA JA SUOJALUKITUS OHITETTAESSA OLET ALTTIINA NÄKYMÄTTÖMÄLLE LASERSÄTEILYLLE ÄLÄ KATSO SÄTEESEEN. V Safety Information PRODUCT SAFETY USA & CANADAUL 1950 Third Edition (C-UL LISTING) EEC(Europe)EN 60950 (T ÜV GS Certification) CBIEC 60950 LASER SAFETY EEC(Europe)EN 60825 USA21 CFR, Chapter 1, Subchapter J (CDRH Certified) Power Saver This printer contains advanced energy conservation technology that reduces power con- sumption when it is not in active use. When the printer does not receive data for an extended period of time, …

Text truncated - open the document above for the full version.

FCC CFR47 PART 15 DIGITAL DEVICE TEST REPORT FOR LASER PRINTER MODEL: ML-6100N, QWIKLASER 6100N, DOCUPRINT P1202, QWIKLASER 6100, QWIKLASER 6100P, QWIKLASER 6100S FCC ID: A3LML6100N REPORT NUMBER: 99U0358-1 ISSUE DATE: JUNE 24, 1999 Prepared for SAMSUNG ELECTRONICS CO., LTD. 85 WEST TASMAN DRIVE SAN JOSE, CA 95134 USA Prepared by COMPLIANCE ENGINEERING SERVICES, INC. d.b.a. COMPLIANCE CERTIFICATION SERVICES 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089, USA TEL: (408) 752-8166 FAX: (408) 752-8168 REPORT NO: 99U0358-1DATE: JUNE 24, 1999FCC ID: A3LML6100N EUT: LASER PRINTER COMPLIANCE CERTIFICATION SERVICESDOCUMENT NO:CCSUP4002C 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS PAGE 1. VERIFICATION OF COMPLIANCE............................................................................................................ 1 2. PRODUCT DESCRIPTION ............................................................................................................................ 2 3. TESTED SYSTEM DETAILS ......................................................................................................................... 2 4. TEST FACILITY .............................................................................................................................................. 3 5. ACCREDITATION AND LISTING ............................................................................................................... 3 6. MEASUREMENT INSTRUMENTATION.................................................................................................... 3 7. MEASURING INSTRUMENT CALIBRATION .......................................................................................... 4 8. UNITS OF MEASUREMENT ......................................................................................................................... 4 9. ANTENNAS....................................................................................................................................................... 5 10. CLASSIFICATION OF DIGITAL DEVICE ................................................................................................. 5 11. RADIATED EMISSION LIMITS ................................................................................................................... 5 12. CONDUCTED EMISSION LIMITS............................................................................................................... 6 13. CONDUCTED EMISSION TEST PROCEDURE......................................................................................... 8 14. RADIATED EMISSION TEST PROCEDURE ............................................................................................. 8 15. AMBIENT CONDITIONS ............................................................................................................................... 9 17. EQUIPMENT MODIFICATIONS................................................................................................................ 10 18. EUT SETUP PHOTOS ................................................................................................................................... 11 19.TEST EQUIPMENT LIST ............................................................................................................................. 12 20.TEST RESULT SUMMARY.......................................................................................................................... 13 APPENDICES ........................................................................................................................................................... 15 .EXTERNAL I/O CABLE CONSTRUCTION DESCRIPTION .CONFIGURATION BLOCK DIAGRAM .CONDUCTED EMISSION PLOT .RADIATED EMISSION DATA .EUT PHOTOGRAPHS REPORT NO: 99U0358-1DATE: JUNE 24, 1999FCC ID: A3LML6100N EUT: LASER PRINTER 1OF19 COMPLIANCE CERTIFICATION SERVICESDOCUMENT NO:CCSUP4002C 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 1. VERIFICATION OF COMPLIANCE COMPANY NAME: SAMSUNG ELECTRONICS CO., LTD. 85 WEST TASMAN DRIVE SAN JOSE, CA 95134 USA CONTACT PERSON: BEN KIM / MANAGER TELEPHONE NO:408-544-5124 MODEL NO/NAME: ML-6100N, QWIKLASER 6100N, DOCUPRINT P1202, QWIKLASER 6100, QWIKLASER 6100P, QWIKLASER 6100S SERIAL NO:N/A DATE TESTED:JUNE 24, 1999 TYPE OF EQUIPMENT:INFORMATION TECHNOLOGY EQUIPMENT (ITE) MEASUREMENT DISTANCE:(X) 3 METER ( ) 10 METER TECHNICAL LIMIT:CLASS B FCC RULES:PART 15 MEASUREMENT PROCEDUREANSI C63.4:92 EQUIPMENT AUTHORIZATION PROCEDURE DECLARATION OF CONFORMITY MODIFICATIONS MADE ON EUT YES NO DEVIATIONS FROM MEASUREMENT PROCEDURE YES (refer to section 20 for comments) NO RADIATED EMISSION TEST RESULT-2.88 dB @ 660.0 MHz/HORIZONTAL CONDUCTED EMISSION TEST RESULT-5.22 dB @ 0.863 MHz/L2 The above equipment was tested by Compliance Certification Services for compliance with the requirements set forth in the FCC CFR 47, PART 15. The results of testing in this report apply to the product/system which was tested only. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Approved By MIKE C.I. KUO / VICE PRESIDENT COMPLIANCE CERTIFICATION SERVICES REPORT NO: 99U0358-1DATE: JUNE 24, 1999FCC ID: A3LML6100N EUT: LASER PRINTER 2OF19 COMPLIANCE CERTIFICATION SERVICESDOCUMENT NO:CCSUP4002C 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 2. PRODUCT DESCRIPTION CHASSIS TYPEPLASTIC LIST OF EACH OSC. OR XTAL. FREQ. (FREQ.>=1 MHz) 40, 47.778, 48, 25, 33, 47.78 MHz POWER SUPPLY/NAME/MODEL/S.N.BUILT-IN LINE FILTER NAME AND MODELBUILT-IN POWER REQUIREMENTS110 V AC, 60 Hz NO. OF EXTERNAL I/O CONN…
