A3LNFA455Wireless LAN Module

OEM/Intergrator manual of NFA455 1. Introduction NFA455 is a Wi-Fi / Bluetooth Combo module compliant with Dual-band 1x1 IEEE802.11a/b/g/n/ac and Bluetooth 4.1+HS optimized for low-power applications. The core chipset is from Qualcomm, part number QCA9377. 2. Hardware Architecture: 2.1 M ain Chipset Information Item Vendor Part Number IEEE802.11 a.b.g.n.ac mac/baseband/radio Bluetooth 4.1 + HS Qualcomm QCA9377 2.2 Circuit Block Diagram The major internal and external block diagram of NFA455 is illustrated in Figure 1-1. F igure 1-1 NFA455 block diagram and System Interface Main (ANT0): WLAN 2.4G(2412~2462MHz), 5G(5180~5825MHz) Aux (ANT1): Bluetooth (2402~2480MHz) OSC: 48MHz Version 1.0 Samsung Electronics page 1 of 5 3. O perational Description NFA455 is the 802.11a/b/g/n /ac and Bluetooth 4.1 COMBO Module that acts as a communication controller for users of a wireless device to connect to PC - Features >IEEE 802.11ac Draft compliant. >Dual-band 2.4GHz /5 GHz >Supports 20 MHz/40 MHz at 2.4 GHz and supports 20 MHz, 40 MHz, or 80 MHz at 5 GHz >On-chip power amplifiers and low –noise amplifiers for both bands >Complies with Bluetooth Core Specification Version 4.1 + HS >Supports BT for class 1 and class 2 power-level transmissions without requiring an external PA - Time base of the RF frequency For RF frequency, 48MHz crystal is a clock reference. - Synthesizer Synthesizer and Internal voltage controlled oscillator (VCO) inside Transceiver provides the desired LO- signal based on the phase-locked loop (PLL) with a relatively wide tuning range for this application. Also, generate the desired RF frequency through up-converting or down-converting using frequency direct conversion method - WIFI Transmission Baseband data is modulated and upconverted to the 2.4GHz ISM and 5-GHz U-NII bands, respectively. Linear on chip power amplifier are included, which are capable of delivering high output powers while meeting IEEE802.11ac and IEEE802.a/b/g/n specifications without the need for external PAs. When using the internal PAs, closed-loop output power control is completely integrated. Base-band Processing (BBP) IC has DSSS (BPSK/QPSK/CCK) and OFDM (BPSK/QPSK/16QAM/64QAM/25QAM) modulation function, it provides transmission data rate are 1, 2, 5.5, 11Mbps on DSSS and 6, 12, 18, 24, 36, 48, 54 Mbps on OFDM. Digital data signal will be converted to analog (TX IQ) signals through DAC in BBP IC, TX IQ pass through to low pass filter. TX I/Q signal use direct conversion (zero-IF) architecture converter to generate carrier frequency signal. Transceiver IC and internal PA magnify output power. - WIFI Receiver The NFA455 has a wide dynamic range, direct conversion receiver that employs high-order on-chip channel filtering to ensure reliable operation in the noisy 2.4GHz ISM band or the entire 5GHz U-NII band. Control signals are available that can support the use of optional LNAs for each band, which can increase the receive sensitivity by several decibels. Reverse direction isolation of LNA inside Transceiver IC suppresses unwanted radiation. Then RF signal will be directly down to IF signal (RX IQ) and high frequency spurious emissions are suppressed by LPF. At last RX IQ signal will be demodulated digital data. - Bluetooth Low Energy Version 1.0 Samsung Electronics page 2 of 5 The NFA455 support the Bluetooth 4.1 Low Energy operating mode. - Product Details > Data Modulation DSSS: CCK, BPSK, QPSK for 802.11b OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM for 802.11a,g,n,ac FHSS: GFSK, OQPSK, 8DPSK, π/4DPSK for Bluetooth > Frequency: 2.4GHz/ 5GHz > Power: +3.3V ±5% (+3.135V ~ +3.465V) Version 1.0 Samsung Electronics page 3 of 5 4.OEM Section - to whom wants to install the radio. FCC Statement This device complies with Part 15 of FCC Rules, Operation is Subject to following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received including interference that cause undesired operation. Caut ion: Any changes or modifications to the equipment not expressly approved by the party responsible for compliance could void user s authority to operate the equipment. This equipment has been tested and found to comply within the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna • Increase the separation between the equipment and receiver • Connect the equipment into an outlet on a different circuit from that to which the receiver is connected • Consult the dealer or an experienced radio/TV technician for help. For product available in the USA/Canada market, only channel 1~11 can be operated and these channel a ssignments deal with only the 2.4GHz range This device and its antenna(s) must not be co-located or operation in conjuction with any other antenna or transmitter. This device is going to be operated in 5.15~5.25GHz frequency range, it is restricted in indoor environment only IMPORTANT NOTE: FCC Radiation Exposure Statement; This appliance and its antenna must not be co-located or operation in conjunction with any other antenna or transmitter. A minimum separation distance of 20 ㎝ must be maintained between the antenna and the person for this appliance to satisfy the RF exposure requirements. USER MANUAL OF THE END PRODUCT: In the users manual of …

Text truncated - open the document above for the full version.

Samsung Electronics Co., Ltd. 19 Chapin Rd. Building D Pine Brook NJ 07058 Tel. +1-973-808-6362/ Fax. +1-310-609-1355 Date: March 23, 2015 To: TIMCO Engineering, Inc Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Samsung Electronics Co., Ltd., hereby authorize TIMCO Engineering, Inc. to act as a Certification Body for certifying for the following project : Product: Wireless Lan Module Model name: NFA455 FCC ID: A3LNFA455 Variant model: - I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This authorization is valid until further written notice from the applicant. Sincerely Yours, ___________________________ NAME : ChanHo Youn TITLE : /Manager E-MAIL: [email protected] TEL: +1-973-808-6362 Samsung Electronics Co., Ltd. 19 Chapin Rd. Building D Pine Brook NJ 07058

Samsung Electronics Co., Ltd. 19 Chapin Rd. Building D Pine Brook NJ 07058 Tel. +1-973-808-6362/ Fax. +1-310-609-1355 FCC Confidentiality Request Letter Date: March 23, 2015 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia MD 21046 Subject: Permanent Confidentiality Request for FCC ID: A3LNFA455 We hereby request confidential treatment of information accompanying this application as outlined below: • Block diagram • Operation Description • Schematics The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely Yours, ___________________________ NAME : ChanHo Youn TITLE : /Manager E-MAIL: [email protected] TEL: +1-973-808-6362 Samsung Electronics Co., Ltd. 19 Chapin Rd. Building D Pine Brook NJ 07058

Software Security Declaration Product: Wireless Lan Module Model name: NFA455 FCC ID: A3LNFA455 This device is fully compliant w ith the requirement of KDB 594280D02 version to V01r01. SOFTWARE SECURITY DESCRIPTION General Desc rip tio n 1. Describe how any software/f irmware upd ate will be obtain ed, do wnloaded, and in stalle d. All Software downloads are supplied and controlled by the host device manufacturer. Download is implemented via a secure server. 2. Describe all the radio frequency parameters that are modifie d by any software/f irmware w ithout any hardware changes. Are these parameters in so me way limited, such that, it will not exceed t he authorized parameters? Centre Frequencies of channels, channel bandwidth, modulations, active or passive scanning and transmit power levels are defined in software. Hardware specific configuration data is stored in non- volatile memory which limits frequency and transmit power levels to U.S. compliant values. 3. Are there any authentication protocols in pl ace to ensu re that the so urce of the software/firmware is legi timate? If so, desc ribe in details; if not, explain how the software is secured from modific ation. The software image is installed at time of manufacture of the module. The correct embedded software is verified and installed by the module manufacturer. The signature validation procedure in 4) below is used to validate the authenticity of the image using a public key or hash of the public key stored in the module’s non-volatile memory. 4. Are there any verification protocols in pl ace to e nsu re that the software/f irmware is legi timate? If so, describe in details. A hash on the firmware binary is computed at the CASS server using SHA256 hashing algorithm. The hash is then secured using the private key using RSA-PSS algorithm. The secured hash is downloaded from the host to the target along with the firmware binary. After firmware binary download from the host, the target uses the public key to decrypt the hash that is sent & computes the hash on the firmware binary & compares them for authentication. If the hash does not match the firmware binary is discarded from target memory. 5. Describ e, if any, encryption methods used. RSA-PSS for encrypting/decrypting the hash.SHA256 for computing the hash. 6. For a devic e that can be configured as a master and c lie nt (with active or passi ve sc annin g), explain how the devic e ensures compliance for each mode? In particular if the devic e acts as master in some band of operation and client in another; how is c ompliance ensured in each band of operatio n? Software limits operation to passive only and No Master modes (WiFi Direct, SoftAP, etc) in radar channels. This configuration cannot be changed by end user or installer. SOFTWARE SECURITY DESCRIPTION Third Party Ac cess Control 1. How are unauthorized software/firmware changes prevented? The verification/authentication features described in previous section prevents unauthorized software changes. 2. Is it p ossible for third partie s to load devic e dr ivers that could modify the RF parameters, country of operation or other parameters whic h im pact devic e Embedded software is protected via the measures explained in the previous section. Distributions of host operating software are digitally signed with a private key and matching public key. 3. Explain if any third pa rtie s have the c apability to operate a U S so ld devic e on any other regulatory do main, frequencie s, or in any mann er that is in violation of the c ertif ication Country domain is set in non-volatile memory during manufacture. The software and user interface does not provide any option to choose a country of operation. 4. What pr events third p arties from loading non-US versions of t he software/firmware on the devic e? Embedded software is protected via the same measures explained in previous section. 5. For modular devic es, describe how authentication is achieved when used wit h diffe rent hosts. The module is not available for sale or installation outside of company licensing agreements. Modules are always installed in host systems in a factory by end integrators responsible for loading authorized software. SOFTWARE CONFIGURATION DESCRIPTION User Config uration Gu ide 1. To whom is the UI accessible? (Professional installer, end user, other.) End User. a) What parameters are viewable to the professional installer/end-user? Misc. device status information is viewable by the end user (channel of operation, connection status, etc). b) What parameters are accessible or modifiable to the professional installer? General configuration options are available.Regulatory related parameters are not modifiable. i) A re the parameters in some way limited, so that the i nstalle rs will not enter parameters that exceed those authorized? Configuration of channel/frequency, modulation type and transmit power are not modifiable by installer or user. ii) What controls exist that the user cann ot operate the d evic e outside it s authorization in the U.S.? The user interface does not allow access to parameters affecting regulatory compliance. c) What configuration options are available to the end-user? Misc. device configuration options. Regulatory related parameters are not accessible. i) A re the parameters in some way limited, so that the i nstalle rs will not enter parameters that exceed those authorized? There are no configuration options available to the installer or end user that can impact regulatory compliance. ii) What controls exist that the user cann ot operate the d evic e outside it s authorization in the U.S.? Regulatory Domain & country code is stored in nonvolatile memory and cannot be changed in the user interface by installer or end user. This is set to U.S.operation. d) Is the country code factory set? Can it be changed in the UI? Regulatory Domain & country code is stored in nonvolatile memory and cannot be changed in the user interface by inst…

Text truncated - open the document above for the full version.

Samsung Electronics Co., Ltd. 19 Chapin Rd. Building D Pine Brook NJ 07058 Tel. +1-973-808-6362/ Fax. +1-310-609-1355 26 March 2015 (Product name) FCC ID : A3LNFA455 , is seeking FCC Authorization as a Single Modular transmitter / Single Limited Modular Approval (Please check one). The EUT meets the requirements for Single Modular approval / Single Limited Modular Approval (please check one) as detailed in FCC KDB 996369 D01 v01r04. Compliance to each of the requirements is described below: Questions are: * Please provide a detailed explanation if the answer is “No.” Item Modular requirement Yes No 1 The radio elements must have the radio frequency circuitry shielded. Physical components and tuning capacitor(s) may be located external to the shield, but must be on the module assembly; Yes 2 The module must have buffered modulation/data inputs to ensure that the device will comply with Part 15 requirements with any type of input signal; Yes 3 The module must contain power supply regulation on the module; Yes 4 The module must contain a permanently attached antenna, or contain a unique antenna connector, and be marketed and operated only with specific antenna(s), per Sections 15.203, 15.204(b), 15.204(c), 15.212(a), 2.929(b); Yes 5 The module must demonstrate compliance in a stand-alone configuration; Yes 6 The module must be labelled with its permanently affixed FCC ID label, or use an electronic display (See KDB Publication 784748 about labelling requirements); Yes 7 The module must comply with all specific rules applicable to the transmitter including all the conditions provided in the integration instructions by the grantee; Yes 8 The module must comply with RF exposure requirements Yes ChanHo Youn & Manager Samsung Electronics Co., Ltd.

http://www.emc2000.co.kr External photos of EUT EMC compliance Ltd. Page: 1 of 1 480-5, Sin-dong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea 82-31-336-9919 (Main) 82-505-299-8311 (Fax) This test report shall not be reproduced except in full, Without the written approval.

1 NFA455 FCC ID Label Information

http://www.emc2000.co.kr Internal photos of EUT EMC compliance Ltd. Page: 1 of 2 480-5, Sin-dong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea 82-31-336-9919 (Main) 82-505-299-8311 (Fax) This test report shall not be reproduced except in full, Without the written approval. http://www.emc2000.co.kr * Test Zig Photo Antenna EMC compliance Ltd. Page: 2 of 2 480-5, Sin-dong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea 82-31-336-9919 (Main) 82-505-299-8311 (Fax) This test report shall not be reproduced except in full, Without the written approval.

http://www.emc2000.co.kr * RF Exposure 1. Regulation According to §15.247(i), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines. See § 1.1307(b)(1) of this Chapter. Limits for Maximum Permissive Exposure: RF exposure is calculated. Frequency Range Electric Field Strength [V/m] Magnetic Field Strength [A/m] Power Density [㎽/㎠] Averaging Time [minute] Limits for General Population / Uncontrolled Exposure 0.3 ~ 1.34 614 1.63 *(100) 30 1.34 ~ 30 824/f 2.19/f *(180/f 2 ) 30 30 ~ 300 27.5 0.073 0.2 30 300 ~ 1 500 / / f/1 500 30 1 500 ~ 15 000 / / 1.0 30 f=frequency in ㎒, *= plane-wave equivalent power density MPE (Maximum Permissive Exposure) Prediction Predication of MPE limit at a given distance: Equation from page 18 of OET Bulletin 65, Edition 97-01 () SPGRRPGSππ4 4 2 =⇒= S = power density [㎽/㎠] P = Power input to antenna [㎽] G = Power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna [㎝] EMC compliance Ltd. Page: 1 of 3 480-5 Shin-dong, Yeongtong-gu, Suwon-city, Gyunggi-do, 443-390, Korea 82-31-336-9919 (Main) 82-505-299-8311 (Fax) This test report shall not be reproduced except in full, Without the written approval. http://www.emc2000.co.kr 2. RF Exposure Compliance Issue The information should be included in the user’s manual: This appliance and its antenna must not be co-located or operation in conjunction with any other antenna or transmitter. A minimum separation distance of 20 ㎝ must be maintained between the antenna and the person for this appliance to satisfy the RF exposure requirements. 3. Calculation Result of RF Exposure Mode Ta rg e t power Tune up tolerance Max tune up power Max tune up power Ant Gain Ant Gain Power Density at 20 ㎝ Limit [㏈] [㏈] [㏈] [㎽] [㏈m] [㎽] [㎽/㎠] [㎽/㎠] 802.11b 17 .00 ±1.50 18.50 70.79 -0.2 0.95 0.031 45 1.000 00 802.11g 16.50 ±1.50 18 .00 63.10 -0.2 0.95 0.011 99 1.000 00 802.11n_HT20 16.50 ±1.50 18 .00 63.10 -0.2 0.95 0.011 99 1.000 00 802.11n_HT40 16.50 ±1.50 18 .00 63.10 -0.2 0.95 0.011 99 1.000 00 Wifi 5 GHz_5 150 Band 13.00 ±2.00 15.00 31.62 0.95 1.24 0.007 83 1.000 00 Wifi 5 GHz_5 250 Band 13.00 ±2.00 15.00 31.62 1.06 1.27 0.008 03 1.000 00 Wifi 5 GHz_5 470 Band 13.00 ±2.00 15.00 31.62 2.04 1.60 0.010 06 1.000 00 Wifi 5 GHz_5 725 Band 13.00 ±2.00 15.00 31.62 -1.08 0.78 0.004 91 1.000 00 GFSK 9.00 ±2.00 11.00 12.59 0.57 1.14 0.002 86 1.000 00 8DPSK 6.00 ±2.00 8.00 6.30 0.57 1.14 0.001 43 1.000 00 Bluetooth Low Energy 2.00 ±2.00 4.00 2.51 0.57 1.14 0.000 57 1.000 00 To t a l WiFi 2.4 GHz + Bluetooth 0.034 31 1.000 00 WiFi 5 GHz + Bluetooth 0.012 92 1.000 00 Note: Total = (MPE 1 / MPE 1 Limit)+ (MPE 2 / MPE 2 Limit)+ ... + (MPE n / MPE n Limit) 4. Target power and tolerance, Max tuneup power Wifi 2.4 GHz Mode Target power Tolerance Max tuneup power 802.11b 17.00 ±1.50 18.50 802.11g 16.50 ±1.50 18.00 802.11n_HT20 16.50 ±1.50 18.00 802.11n_HT40 16.50 ±1.50 18.00 EMC compliance Ltd. Page: 2 of 3 480-5 Shin-dong, Yeongtong-gu, Suwon-city, Gyunggi-do, 443-390, Korea 82-31-336-9919 (Main) 82-505-299-8311 (Fax) This test report shall not be reproduced except in full, Without the written approval. http://www.emc2000.co.kr Wifi 5 GHz Mode Target power Tolerance Max tuneup power 802.11a 5150-5250 Band 13.00 ±2.00 15.00 802.11a 5250-5350 Band 13.00 ±2.00 15.00 802.11a 5470-5725 Band 13.00 ±2.00 15.00 802.11a 5725-5825 Band 13.00 ±2.00 15.00 Mode Target power Tolerance Max tuneup power 802.11n_HT20 5150-5250 Band 13.00 ±2.00 15.00 802.11n_HT20 5250-5350 Band 13.00 ±2.00 15.00 802.11n_HT20 5470-5725 Band 13.00 ±2.00 15.00 802.11n_HT20 5725-5825 Band 13.00 ±2.00 15.00 802.11n_HT40 5150-5250 Band 13.00 ±2.00 15.00 802.11n_HT40 5250-5350 Band 13.00 ±2.00 15.00 802.11n_HT40 5470-5725 Band 13.00 ±2.00 15.00 802.11n_HT40 5725-5825 Band 13.00 ±2.00 15.00 802.11n_VHT20 5150-5250 Band 13.00 ±2.00 15.00 802.11n_VHT20 5250-5350 Band 13.00 ±2.00 15.00 802.11n_VHT20 5470-5725 Band 13.00 ±2.00 15.00 802.11n_VHT20 5725-5825 Band 13.00 ±2.00 15.00 802.11n_VHT40 5150-5250 Band 13.00 ±2.00 15.00 802.11n_VHT40 5250-5350 Band 13.00 ±2.00 15.00 802.11n_VHT40 5470-5725 Band 13.00 ±2.00 15.00 802.11n_VHT40 5725-5825 Band 13.00 ±2.00 15.00 802.11n_VHT80 5150-5250 Band 13.00 ±2.00 15.00 802.11n_VHT80 5250-5350 Band 13.00 ±2.00 15.00 802.11n_VHT80 5470-5725 Band 13.00 ±2.00 15.00 802.11n_VHT80 5725-5825 Band 13.00 ±2.00 15.00 Bluetooth Mode Target power Tolerance Max tuneup power GFSK 9.00 ±2.00 11.00 8DPSK 6.00 ±2.00 8.00 Low energy 2.00 ±2.00 4.00 EMC compliance Ltd. Page: 3 of 3 480-5 Shin-dong, Yeongtong-gu, Suwon-city, Gyunggi-do, 443-390, Korea 82-31-336-9919 (Main) 82-505-299-8311 (Fax) This test report shall not be reproduced except in full, Without the written approval.
