A3LNX30Digital Camera

ENG This user manual includes detailed usage instructions for your camera. Please read this manual thoroughly. USER MANUAL 1 Copyright information • Camera specifications or contents of this manual may be changed without prior notice due to upgrade of camera functions. • You are not allowed to reuse or distribute any part of this manual without prior permission. • We recommend using your camera within the country where you purchase it. • Use this camera responsibly and adhere to all laws and regulations concerning its use. PlanetFirst represents Samsung Electronics' commitment to sustainable development and social responsibility through eco-driven business and management activities. • Microsoft Windows and the Windows logo are registered trademarks of the Microsoft Corporation. • Mac and Apple App Store are registered trademarks of the Apple Corporation. • Google Play Store is a registered trademark of Google, Inc. • Adobe, the Adobe logo, Photoshop and Lightroom are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries. • microSD™, microSDHC™, and microSDXC™ are registered trademarks of the SD Association. • HDMI, the HDMI logo, and the term "High Definition Multimedia Interface" are trademarks or registered trademarks of HDMI Licensing LLC. • Wi-Fi®, the Wi-Fi CERTIFIED logo, and the Wi-Fi logo are registered trademarks of the Wi-Fi Alliance. • Trademarks and trade names used in this manual are the property of their respective owners. 2 Health and safety information Prevent damage to subjects’ eyesight. Do not use the flash in close proximity (closer than 1 m/3 ft) to people or animals. If you use the flash too close to your subject’s eyes, this can cause temporary or permanent eyesight damage. Keep your camera away from small children and pets. Keep your camera and all accessories out of the reach of small children and animals. Small parts may cause choking or serious injury if swallowed. Moving parts and accessories may present physical dangers as well. Do not expose the camera to direct sunlight or high temperatures for an extended period of time. Prolonged exposure to sunlight or extreme temperatures can cause permanent damage to your camera’s internal components. Avoid covering the camera or charger with blankets or clothes. The camera may overheat, which may distort the camera or cause a fire. Do not handle the power supply cord or go near the charger during a thunderstorm. This may result in electric shock. Always comply with the following precautions and usage tips to avoid dangerous situations and ensure peak performance of your camera. Warning—situations that could cause injury to yourself or others Do not disassemble or attempt to repair your camera. This may result in electric shock or damage to the camera. Do not use your camera near flammable or explosive gases and liquids. This may cause a fire or explosion. Do not insert flammable materials into the camera or store these materials near the camera. This may cause a fire or electric shock. Do not handle your camera with wet hands. This may result in electric shock. 3 Health and safety information If liquid or foreign objects enter your camera, immediately disconnect all power sources, such as the battery or charger, and then contact a Samsung service center. Comply with any regulations that restrict the use of a camera in a certain area. • Avoid interference with other electronic devices. • Turn off the camera when in an aircraft. Your camera can cause interference with aircraft equipment. Follow all airline regulations and turn off your camera when directed by airline personnel. • Turn off the camera near medical equipment. Your camera can interfere with medical equipment in hospitals or health care facilities. Follow all regulations, posted warnings, and directions from medical personnel. Avoid interference with pacemakers. Maintain the distance between this camera and all pacemakers to avoid potential interference, as recommended by the manufacturer and research groups. If you have any reason to suspect that your camera is interfering with a pacemaker or other medical device, turn off the camera immediately and contact the manufacturer of the pacemaker or medical device for guidance. Caution—situations that could cause damage to your camera or other equipment Remove the batteries from your camera when storing it for an extended period of time. Installed batteries may leak or corrode over time and cause serious damage to your camera. Use only authentic, manufacturer-recommended, Lithium-ion replacement batteries. Do not damage or heat the battery. Inauthentic, damaged, or heated batteries may cause a fire or personal injury. Use only Samsung-approved batteries, chargers, cables, and accessories. • Using unauthorized batteries, chargers, cables, or accessories can cause batteries to explode, damage your camera, or cause injury. • Samsung is not responsible for damage or injuries caused by unapproved batteries, chargers, cables, or accessories. Use the battery only for its intended purpose. Misusing the battery may cause a fire or electric shock. 4 Health and safety information Do not touch the flash while it fires. The flash is very hot when fired and may burn your skin. When you use the AC charger, turn off the camera before you disconnect the power to the AC charger. Failing to do so may result in fire or electric shock. Disconnect the charger from the wall socket when not in use. Failing to do so may result in fire or electric shock. Do not use a damaged power supply cord, plug, or loose outlet when you charge batteries. This may cause a fire or electric shock. Do not allow the AC charger to come in contact with the +/- terminals on the battery. This may cause a fire or electric shock. Do not drop or subject the camera to strong impacts. Doing so may damage the screen or external or internal components. Exercise caution when you connect cables and install …

Text truncated - open the document above for the full version.

Date: December 24 , 2013 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Lab Manager Charles. Kim (or Feel. Jeong) and of SGS Korea Co., Ltd and hereafter referred to as SGS Korea, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Lab Manager Charles. Kim (or Feel. Jeong) of SGS Korea Co., Ltd on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing SGS Korea as our agent, we still recognize that we are responsible to: a)comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints ; c) make claims regarding certification only in respect of the scope for which certification has been gran ted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our pro duct certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Sang Kyung (Peter) Ra / General Manager Samsung Electronics Co., Ltd.

Date: December 24, 2013 Federal Communications Commission Au thorization and Evaluation Division 7435 Oakland Mills Road, Colu mbia, MD 21046 RE: Request of Confidentiality for FCC ID: A3LNX30 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Samsung Electronics Co., Ltd. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give Samsung Electronics Co., Ltd temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: CONFIDENTIALLIST 1Block Diagram 2Operational Descriptions Permanent 3Schematics 4External Photos 5Internal Photos 6Test-Setup Photos Short-Term 7User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely Yours, Sang K yung (Peter) Ra / General Manager Samsung Electronics Co., Ltd.

Model : NX30 External photos of EUT Model : NX30 Top view of EUT Bottom view of EUT Model : NX30 Front view of EUT Rear view of EUT Model : NX30 Side view of EUT Model : NX30 Side view of EUT

FCC/IC Label 1.(1) FCC Label Drawing (2) FCC Label Location WB350F 2.(1) IC Label Drawing (2) IC Label Location

Report File No. : F690501/RF-SAR002142 Date of Issue : 2013-12-25 Page : 1 / 56 éééé SAR TEST REPORT Equipment Under Test : Digital Camera Model No. : NX30 Applicant : Samsung Electronics Co., Ltd. Address of Applicant : 129, Samsung-ro, Yeongtong-gu, Suwon-city, Gyeonggi-do, 443-742 Korea, Republic of FCC ID : A3LNX30 IC ID 649E-NX30 Device Category : Portable Device Exposure Category : General Population/Uncontrolled Exposure Date of Receipt : 2013-11-27 Date of Test(s) : 2013-12-21 Date of Issue : 2013-12-25 Standards: FCC OET Bulletin 65 supplement C RSS-102 (Issue 4) IEEE 1528, 2003 ANSI/IEEE C95.1, C95.3 In the configuration tested, the EUT complied with the standards specified above. Remarks: Tested by : Minhyuk Han 2013-12-25 Approved by : Nicky You 2013-12-25 This report details the results of the testing carried out on one sample, the results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS Korea Co., Ltd. (Gunpo Laboratory) or testing done by SGS Korea Co., Ltd. (Gunpo Laboratory) in connection with distribution or use of the product described in this report must be approved by SGS Korea Co., Ltd. (Gunpo Laboratory) in writing. Report File No. : F690501/RF-SAR002142 Date of Issue : 2013-12-25 Page : 2 / 56 éééé Contents 1. General Information 1.1 Testing Laboratory........................................................................................... 3 1.2 Details of Applicant.......................................................................................... 3 1.3 Version of Report............................................................................................. 3 1.4 Description of EUT(s)....................................................................................... 3 1.5 Nominal and Maximum Output Power Specifications................................................... 4 1.6 Test Environment............................................................................................. 4 1.7 Operation description........................................................................................ 4 1.8 Evaluation procedures....................................................................................... 4 1.9 SAR Measurement Procedures.............................................................................. 4 1.10 The SAR Measurement System............................................................................ 6 1.11 System Components.......................................................................................... 8 1.12 SAR System Verification.................................................................................... 10 1.13 Tissue Simulant Fluid for the Frequency Band.......................................................... 11 1.14 Test System Validation...................................................................................... 12 1.15 Test Standards and Limits................................................................................. 12 2. Instruments List.................................................................................... 14 3. Summary of Results................................................................................ 15 3.1 FCC Power Measurement Procedures............................................................... 15 3.2 Measured and Reported SAR...........................................................................15 3.3 RF Conducted Power.................................................................................... 15 3.4 Test Configuration.........................................................................................17 3.5 SAR Test Exclusions Applied...........................................................................18 3.6 SAR Data Summary.......................................................................................19 APPENDIX A. DASY4 SAR Report B. Uncertainty Analysis C. Calibration certificate Report File No. : F690501/RF-SAR002142 Date of Issue : 2013-12-25 Page : 3 / 56 éééé 1. General Information 1.1 Testing Laboratory SGS Korea Co., Ltd. (Gunpo Laboratory) 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, 435-040, Korea Telephone : +82 +31 428 5700 FAX : +82 +31 427 2371 Homepage : All SGS services are rendered in accordance with the applicable SGS conditions of service available on request and accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx 1.2 Details of Manufacturer Manufacturer : Samsung Electronics Co., Ltd. Address : 129, Samsung-ro, Yeongtong-gu, Suwon-city, Gyeonggi-do, 443-742 Korea, Republic of Contact Person : JeongHwan-Kim Phone No. : 82-31-277-3308 E-mail : [email protected] 1.3 Version of Report Version Number Date Revision 00 2013-12-25 Initial issue 1.4 Description of EUT(s) EUT Type : Digital Camera Model : NX30 Serial Number : NX30PV1-024 Mode of Operation : WLAN Duty Cycle : 1(WLAN) Body worn Accessory : None Tx Frequency Range : 2412 ~ 2462 (WLAN_11b/g/n) : 5180 ~ 5240 , 5260 ~ 5320 (WLAN_11a/n) : 5500 ~ 5700 , 5745 ~ 5825 (WLAN_11a/n) Battery Type : 3.7 V d.c. (Lithum-ion Battery) Equipment Class Band Measured Conducted Power [m] Reported SAR 1g Body-Worn (W/kg) DTS 2.4 WLAN 13.33 0.849 Simultaneous SAR per KDB 690783 D01v01r02 N/A Report File No. : F690501/RF-SAR002142 Date of Issue : 2013-12-25 Page : 4 / 56 éééé 1.5 Nominal and Maximum Output Power Specifications This device operates using the following maximum and nominal output power specifications. SAR values were scaled to the maximum allowed power to determine compliance per KDB Publication 44798 D01v05. Aver…

Text truncated - open the document above for the full version.

Test Setup Photographs Edge 3 Rear EUT Photo Front Back Right Edge Left Edge To p Bottom Battery

Test setup photos of EUT A. The photo of Radiated Emission B Transmitter AC Power Line Conducted Emission(WLAN)
