A3LNX500Digital Camera

ENG This user manual includes detailed usage instructions for your camera. Please read this manual thoroughly. USER MANUAL 1 Copyright information • Camera specifications or contents of this manual may be changed without prior notice due to upgrade of camera functions. • You are not allowed to reuse or distribute any part of this manual without prior permission. • We recommend using your camera within the country where you purchase it. • Use this camera responsibly and adhere to all laws and regulations concerning its use. PlanetFirst represents Samsung Electronics' commitment to sustainable development and social responsibility through eco-driven business and management activities. • Microsoft Windows and the Windows logo are registered trademarks of the Microsoft Corporation. • Mac and Apple App Store are registered trademarks of the Apple Corporation. • Google Play Store is a registered trademark of Google, Inc. • Adobe, the Adobe logo, Photoshop and Lightroom are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries. • microSD™, microSDHC™, and microSDXC™ are registered trademarks of the SD Association. • HDMI, the HDMI logo, and the term “High Definition Multimedia Interface” are trademarks or registered trademarks of HDMI Licensing LLC. • Wi-Fi®, the Wi-Fi CERTIFIED logo, and the Wi-Fi logo are registered trademarks of the Wi-Fi Alliance. • Trademarks and trade names used in this manual are the property of their respective owners. 2 Health and safety information Prevent damage to subjects’ eyesight. Do not use the flash in close proximity (closer than 1 m/3 ft) to people or animals. If you use the flash too close to your subject’s eyes, this can cause temporary or permanent eyesight damage. Keep your camera away from small children and pets. Keep your camera and all accessories out of the reach of small children and animals. Small parts may cause choking or serious injury if swallowed. Moving parts and accessories may present physical dangers as well. Do not expose the camera to direct sunlight or high temperatures for an extended period of time. Prolonged exposure to sunlight or extreme temperatures can cause permanent damage to your camera’s internal components. Avoid covering the camera or charger with blankets or clothes. The camera may overheat, which may distort the camera or cause a fire. Do not handle the power supply cord or the charger during a thunderstorm. This may result in electric shock. Always comply with the following precautions and usage tips to avoid dangerous situations and ensure peak performance of your camera. Warning—situations that could cause injury to yourself or others Do not disassemble or attempt to repair your camera. You can damage the camera and expose yourself to the risk of an electric shock. Do not use your camera near flammable or explosive gases and liquids. This may cause a fire or explosion. Do not insert flammable materials into the camera or store these materials near the camera. This may cause a fire or electric shock. Do not handle your camera with wet hands. This may result in an electric shock. 3 Health and safety information If liquid or foreign objects enter your camera, immediately disconnect all power sources, such as the battery or charger, and then contact a Samsung service center. Comply with any regulations that restrict the use of a camera in a certain area. • Avoid interference with other electronic devices. • Turn off the camera when in an aircraft. Your camera can cause interference with aircraft equipment. Follow all airline regulations and turn off your camera when directed by airline personnel. • Turn off the camera near medical equipment. Your camera can interfere with medical equipment in hospitals or health care facilities. Follow all regulations, posted warnings, and directions from medical personnel. Avoid interference with pacemakers. Maintain a safe distance between this camera and all pacemakers to avoid potential interference, as recommended by the manufacturer and research groups. If you have any reason to suspect that your camera is interfering with a pacemaker or other medical device, turn off the camera immediately and contact the manufacturer of the pacemaker or medical device for guidance. Caution—situations that could cause damage to your camera or other equipment Remove the batteries from your camera when storing it for an extended period of time. Installed batteries may leak or corrode over time and cause serious damage to your camera. Use only authentic, manufacturer-recommended, Lithium-ion replacement batteries. Do not damage or heat the battery. Inauthentic, damaged, or heated batteries may cause a fire or personal injury. Use only Samsung-approved batteries, chargers, cables, and accessories. • Using unauthorized batteries, chargers, cables, or accessories can cause batteries to explode, damage your camera, or cause injury. • Samsung is not responsible for damage or injuries caused by unapproved batteries, chargers, cables, or accessories. Use the battery only for its intended purpose. Misusing the battery may cause a fire or electric shock. 4 Health and safety information Do not touch the flash while it fires. The flash is very hot when fired and may burn your skin. When you use the AC charger, turn off the camera before you disconnect the power to the AC charger. Failing to do so may result in fire or electric shock. Disconnect the charger from the wall socket when not in use. Failing to do so may result in fire or electric shock. Do not use a damaged power supply cord, plug, or loose outlet when you charge batteries. This may cause a fire or electric shock. Do not allow the AC charger to come in contact with the +/- terminals on the battery. This may cause a fire or electric shock. Do not drop or subject the camera to strong impacts. Doing so may damage the screen or external or internal components. Exercise caution when you connect …

Text truncated - open the document above for the full version.

91 Shooting Functions > Metering Spot The Spot mode calculates the amount of light in the center. When you capture a photo in conditions where there is a strong backlight behind a subject, the camera adjusts the exposure so as to shoot a subject correctly. For example, when you select the Multi mode in a strong backlight condition, the camera calculates that the overall amount of light is abundant, which results in a darker photo. The Spot mode can prevent this situation as it calculates the amount of light in a designated area. The subject is in bright color while the background is dark. The Spot mode is recommended for a situation like this where a huge difference in the exposure exists between a subject and a background. Center-weighted The Center-weighted mode calculates a broader area than the Spot mode does. It sums up the amount of light in the center portion of the shot (60–80 %) and that of the rest of the shot (20–40 %). It is recommended for situations where there is a slight difference in brightness between a subject and a background or an area of the subject is large compared to the overall composition of the photo. 92 Shooting Functions > Metering Measuring the exposure value of the focus area When this function is turned on, the camera automatically sets an optimal exposure by calculating the brightness of the focus area. This function is only available when you select Spot metering or Multi metering, and Selection AF. To set this function, In Shooting mode, press [m] ĺ 1 ĺ Link AE to AF Point ĺ an option. Shooting Functions 9393 Shooting FunctionsShooting Functions This function automatically corrects the loss of bright detail that can occur due to shading differences in the photo. To set Smart Range options, In Shooting mode, press [m] ĺ 1 ĺ Dynamic Range ĺ an option. Without Dynamic Range effectWith Dynamic Range effect IconDescription Off: Do not use Dynamic Range. Smart Range+: Correct the loss of bright detail. You cannot set ISO 100. HDR: Capture 2 photos with different exposures, and then combine them to create a single image automatically. • You cannot set an ISO option higher than ISO 3200. • Dynamic Range options cannot be set at the same time as Picture Wizard options. Dynamic Range Shooting Functions 9494 Shooting FunctionsShooting Functions Smart Filter lets you apply special effects to your photos. You can select various filter options to create special effects that are difficult to be achieved with normal lenses. To set Smart Filter options, In Shooting mode, press [m] ĺ 1 ĺ Smart Filter ĺ an option. OptionDescription Off No effect Vignetting Apply the retro-looking colors, high contrast, and strong vignette effect of Lomo cameras. Miniature Apply a tilt-shift effect to make the subject appear in miniature. Colored Pencil Apply a colored pencil painting effect. Watercolor Apply a watercolor painting effect. Wash drawing Apply a washed-out effect. Oil Sketch Apply an oil sketching effect. Ink Sketch Apply an ink sketching effect. Acryl Apply an acryl painting effect. OptionDescription Negative Apply a negative film effect. Red Desaturate all colors but red. Green Desaturate all colors but green. Blue Desaturate all colors but blue. Yellow Desaturate all colors but yellow. Smart filter options cannot be set with Picture Wizard options at the same time. Smart Filter Shooting Functions 9595 Shooting FunctionsShooting Functions The camera automatically sets the exposure by measuring the levels of light from the photo’s composition and the position of a subject. If the exposure set by the camera is higher or lower than you expected, you can adjust the exposure value manually. The exposure value is adjustable in ±3 increments. The camera displays the exposure warning in red for each step beyond ±3 range. To adjust the exposure value, while holding down [W], scroll the jog dial. You can also adjust the exposure value by pressing [f], and then selecting EV. You can check the exposure value by the position of the exposure level indicator. Exposure level indicator Increased exposure (brighter) Decreased exposure (darker) Exposure warning Standard exposure index -2 Original +2 Exposure compensation Shooting Functions 9696 Shooting FunctionsShooting Functions When you cannot achieve an appropriate exposure because of a strong color contrast, lock the exposure, and then capture a photo. To lock the exposure value, adjust the photo’s exposure, and then press the custom button. After locking the exposure, aim the lens where you desire, and then press [Shutter]. • Set a function of the custom button to AEL to lock the current exposure value. (p. 143) • This feature is not available in Manual mode. Exposure lock Shooting Functions 9797 Shooting FunctionsShooting Functions The functions available for video are explained below. Movie size Set the movie size. To set movie size options, In Shooting mode, press [m] ĺ 6 ĺ Movie Size ĺ an option. IconSizeRecommended for 1920X1080 (60 fps) (16:9) View on a Full HDTV. (Playable only on full HDTVs capable of playback at 60 fps.) 1920X1080 (30 fps) (16:9)View on a Full HDTV. 1920X1080 (15 fps) (16:9) View on a Full HDTV. (Available only with some Smart Filter options.) 1920X810 (24 fps) (Approx. 2.35:1) View on an HDTV. 1280X720 (60 fps) (16:9)View on an HDTV. 1280X720 (30 fps) (16:9)View on an HDTV. 640X480 (30 fps) (4:3)View on a TV. 320X240 (30 fps) (4:3) Post on a website using the wireless network (30 seconds maximum). Movie quality Set the Movie quality. To set movie quality options, In Shooting mode, press [m] ĺ 6 ĺ Movie Quality ĺ an option. IconExtensionDescription MP4 (H.264)Normal: Record videos in normal quality. MP4 (H.264)HQ: Record videos in high quality. Video functions 98 Shooting Functions > Video functions Multi Motion Set the playing speed of a video. To set playing speed options, In Shooting mode, press [m] ĺ6 ĺMulti Motion ĺ an option. IconDescription x0.25: Record a video and play it at 1/4 normal speed. (Avail…

Text truncated - open the document above for the full version.

129, Samsung‐Ro, Yeongtong‐Gu, Suwon‐City Gyeonggi‐Do, 443‐742, Korea JANUARY 12 , 2015 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 LETTER OF AUTHORIZATION To whom it may concern: I, the undersigned, hereby authorize Lab Manager Hyunchae, You (or Logan, Lee) and of SGS Korea Co., Ltd. and hereafter referred to as SGS Korea, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Lab Manager Feel. Jeong (or Logan. Lee) of SGS Korea Co., Ltd. on our behalf shall have the same effect as acts of ou r own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti‐Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing SGS Korea as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; 129, Samsung‐Ro, Yeongtong‐Gu, Suw on‐City Gyeonggi‐Do, 443‐742, Korea i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours Chan Ho, Youn / General Manager Samsung Electronics North America INC. TEL: +1-973-808-6362 E-mail: [email protected]

129, Samsun g‐Ro, Yeongtong‐Gu, Suwon‐City Gyeonggi‐Do, 443‐742, Korea JANURARY 12th, 2014 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 REQUEST OF CONFIDENTIALITY for FCC ID: A3LNX500 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Samsung Electronics Co., Ltd. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short‐Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04‐1705. This provision will give Samsung Electronics Co., Ltd temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: CONFIDENTIAL LIST Permanent 1 Block Diagram 2 Operational Descriptions 3 Schematics Short‐Term 4 External Photos 5 Internal Photos 6 Test‐Setup Photos 7 User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely Yours, Chan Ho, Youn / General Manager Samsung Electronics North America INC. TEL: +1-973-808-6362 E-mail: [email protected]

Model : NX500 External photos of EUT Model : NX500 Front view of EUT Rear view of EUT Model : NX500 Top view of EUT Bottom view of EUT Model : NX500 Side view of EUT

FCC/IC Label 1.(1) FCC Label Drawing (2) FCC Label Location 2.(1) IC Label Drawing (2) IC Label Location

Model : NX500 Internal photos of EUT Model : NX500 Internal view of EUT Model : NX500 Top view of Main PCB Bottom view of Main PCB Model : NX500 Top view of Sub Keypad PCB Bottom view of Sub Keypad PCB Model : NX500 Top view of Lens PCB Bottom view of Lens PCB Model : NX500 Top View of BT&WLAN Antenna Bottom View of BT&WLAN Antenna Model : NX500 Bottom View of NFC Tag Antenna View of BT&WLAN module

SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, 435-040 Tel. 031-428-5700 / Fax. 031-427-2371 http://www.sgsgroup.kr Page : 1 / 50 Report File No : F690501/RF-SAR002241-A2 Date of Issue : 2015-01-15 FCC SAR TEST REPORT Test File No : F690501/RF-SAR002241-A2 Equipment Under Test Digital Camera Model No. NX500 Applicant Samsung Electronics Co., Ltd. Address of Applicant 129, Samsung-ro, Yeongtong-gu Suwon-si, Gyeonggi-do, 443-742 Korea, Republic of FCC ID A3LNX500 Device Category Portable Device Exposure Category General Population/Uncontrolled Exposure Standards FCC 47 CFR Part 2 (2.1093) IEEE 1528, 2003 ANSI/IEEE C95.1, C95.3 Date of Receipt 2014-12-19 Date of Test(s) 2014-12-30 Date of Issue 2015-01-15 In the configuration tested, the EUT complied with the standards specified above. Remarks: Report prepared by / Changhyun Song Test Engineer Approved by / Nicky You Technical Manager This report details the results of the testing carried out on one sample, the results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS Korea Co., Ltd. or testing done by SGS Korea Co., Ltd. in connection with distribution or use of the product described in this report must be approved by SGS Korea Co., Ltd. in writing. SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, 435-040 Tel. 031-428-5700 / Fax. 031-427-2371 http://www.sgsgroup.kr Page : 2 / 50 Report File No : F690501/RF-SAR002241-A2 Date of Issue : 2015-01-15 Revision history Revision Date of issue Revisions Revised By - January 09, 2015 Initial issue - A1 January 13, 2015 Updated report 1. Added to note about BT and WLAN transmit simultaneously on the page 20. 2. Added to SAR test exclusion of Bluetooth. 3. Removed the IC ID. Changhyun Song A2 January 15, 2015 Updated report 1. Revised to note on the page 20. Changhyun Song SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, 435-040 Tel. 031-428-5700 / Fax. 031-427-2371 http://www.sgsgroup.kr Page : 3 / 50 Report File No : F690501/RF-SAR002241-A2 Date of Issue : 2015-01-15 Contents 1 Testing Laboratory 4 2 Details of Applicant 4 3 Description of EUT(s) 4 4 The Highest Reported SAR Values 4 5 Test Methodology 5 6 Test Environment 5 7 Specific Absorption Rate (SAR) 6 7.1 Introduction 6 7.2 SAR Definition 6 7.3 Test Standards and Limits 6 8 The SAR Measurement System 8 9 System Components 9 9.1 Probe 9 9.2 ELI Phantom 9 9.3 Device Holder 10 10 SAR Measurement Procedures 11 10.1 Normal SAR Measurement Procedure 11 11 SAR System Verification 13 12 Tissue Simulant Fluid for the Frequency Band 14 13 Test System Validation 15 14 Instruments List 16 15 FCC Power Measurement Procedures 17 16 Measured and Reported SAR 17 17 Maximum Output Power Specifications 17 18 RF Conducted Power Measurement 18 19 SAR Test configuration 19 19.1 UMPC Mini-Tablet Devices 19 19.2 IEEE 802.11 Transmitters 19 20 Transmit Antenna Separation Distances 20 20.1 UMPC mini-tablet transmitter for SAR Testing 20 21 SAR Test Exclusions Applied_________________________________________________________ 20 22 SAR Data Summary 21 23 SAR Measurement Variability 22 23.1 Measurement Variability 22 23.2 Measurement Uncertainty 22 Appendixes List 23 Appendixes A.1 24 Appendixes A.2 25 Appendixes B.1 26 Appendixes C.1 27 Appendixes C.2 38 Appendixes C.3 45 END 50 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, 435-040 Tel. 031-428-5700 / Fax. 031-427-2371 http://www.sgsgroup.kr Page : 4 / 50 Report File No : F690501/RF-SAR002241-A2 Date of Issue : 2015-01-15 1. Testing Laboratory Company Name SGS Korea Co., Ltd. (Gunpo Laboratory) Address Wireless Div. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, 435-040 Republic of Korea Telephone +82 +31 428 5700 FAX +82 +31 427 2371 Homepage All SGS services are rendered in accordance with the applicable SGS conditions of service available on request and accessible at http://www.sgs.com/en/Terms-and- Conditions.aspx 2. Details of Manufacturer Applicant Samsung Electronics Co., Ltd. Address 129, Samsung-ro, Yeongtong-gu, Suwon-city, Gyeonggi-do, 443-742 Korea, Republic of Contact Person Yongwook –Park Email [email protected] Phone No. +82 +31 277 7695 3. Description of EUT(s) EUT Type Digital Camera Model NX500 Serial Number DV3-276 Mode of Operation WLAN Duty Cycle 1 (WLAN) Body worn Accessory None Tx Frequency Range 2412 ~ 2462 (WLAN 802.11b/g/n) 2402 ~ 2480 (Bluetooth) Battery Type DC 7.6 V (Li-ion Battery) Antenna Information Manufacturer Partron Type FPCB Peak Antenna Gain 2400 MHz ~ 2484 MHz 1.32 dBi 4. The Highest Reported SAR Values Exposure Class Band & Mode Highest Reported SAR 1g Body (W/kg) DTS 2.4 GHz WLAN 0.24 DSS Bluetooth N/A Simultaneous SAR per KDB 690783 D01v01r03 N/A SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, 435-040 Tel. 031-428-5700 / Fax. 031-427-2371 http://www.sgsgroup.kr Page : 5 / 50 Report File No : F690501/RF-SAR002241-A2 Date of Issue : 2015-01-15 5. Test Methodology ANSI C95.1–1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. It specifies the maximum exposure limit of 1.6 W/kg as averaged over any 1 gram of tissue for portable devices being used within 20 cm of the user in the uncontrolled environment. Test tests documented in this report were performed in accordance with IEEE Standard 1528-2003 & IEEE 1528a- 2005 and the following published KDB procedures. In additions; KDB 865664 D01v01r03 SAR Measurement Requirements for 100 MHz to 6 GHz KDB 447498 D01v05r02 Mobile and Portable Devices RF E…

Text truncated - open the document above for the full version.

Report Number: F690501/RF-RTL008316 Page: 2 of 65 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Korea Co., Ltd. (Gunpo Laboratory) 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 435-040 http://www.sgsgroup.kr RTT5041-20(2014.01.20)(2) Tel. +82 31 428 5700 / Fax. +82 31 427 2370 A4(210mmx297mm) INDEX Table of contents 1. General information -------------------------------------------------------------------------------------- 3 2. Transmitter radiated spurious emissions and conducted spurious emission -------------- 6 3. 6 ㏈ bandwidth & 99 % Occupied bandwidth ---------------------------------------------------- 37 4. Maximum peak output power -------------------------------------------------------------------------- 50 5. Power Spectral Density --------------------------------------------------------------------------------- 53 6. Transmitter AC Power Line Conducted Emission------------------------------------------------- 60 7. Antenna Requirement ----------------------------------------------------------------------------------- 65 Report Number: F690501/RF-RTL008316 Page: 3 of 65 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Korea Co., Ltd. (Gunpo Laboratory) 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 435-040 http://www.sgsgroup.kr RTT5041-20(2014.01.20)(2) Tel. +82 31 428 5700 / Fax. +82 31 427 2370 A4(210mmx297mm) 1. General Information 1.1. Testing Laboratory SGS Korea Co., Ltd. (Gunpo Laboratory) - Wireless Div. 2FL, 10-2, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 435-837 All SGS services are rendered in accordance with the applicable SGS conditions of service available on request and accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx. Telephone : + 82 31 688 0901 FAX : + 82 31 688 0921 1.2. Details of Applicant Applicant : Samsung Electronics Co., Ltd. Address : 129, Samsung-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do,443-742 Republic of Korea Contact Person : Park Yong-wook Phone No. : + 82 31 277 7695 1.3. Description of EUT Kind of Product Digital Camera Model Name NX500 Power Supply DC 7.6 V Frequency Range 2 412 ㎒ ~ 2 462 ㎒ (11b/g/n_HT20) Modulation Technique DSSS, OFDM Number of Channels 11 channels Antenna Type Internal type (SISO) Antenna Gain 1.32 ㏈i 1.4. Declaration by the manufacturer - Duty Cycle ≥ 98 percent. Report Number: F690501/RF-RTL008316 Page: 4 of 65 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Korea Co., Ltd. (Gunpo Laboratory) 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 435-040 http://www.sgsgroup.kr RTT5041-20(2014.01.20)(2) Tel. +82 31 428 5700 / Fax. +82 31 427 2370 A4(210mmx297mm) 1.5. Test Equipment List Equipment Manufacturer Model S/N Cal Date Cal Interval Cal Due. Signal Generator R&S SMBV100A 255834 Jun. 25, 2014 Annual Jun. 25, 2015 Signal Generator R&S SMR40 100272 Jul. 18, 2014 Annual Jul. 18, 2015 Spectrum Analyzer Agilent N9030A US51350132 Sep. 24, 2014 Annual Sep. 24, 2015 Attenuator AEROFLEX/INMET 18N-20dB 2 Mar. 18, 2014 Annual Mar. 18, 2015 High Pass Filter Wainwright WHK3.0/18G-10SS 344 Jun. 10, 2014 Annual Jun. 10, 2015 High Pass Filter Wainwright WHK7.5/26.5G-6SS 11 Jun. 10, 2014 Annual Jun. 10, 2015 Low Pass Filter Mini circuits NLP-1200+ V8979400903-2 Mar. 21, 2014 Annual Mar. 21, 2015 Power Sensor R&S NRP-Z81 100669 Mar. 19. 2014 Annual Mar. 19. 2015 DC Power Supply Agilent U8002A MY50060028 Mar. 27, 2014 Annual Mar. 27, 2015 Preamplifier H.P. 8447F 2944A03909 Aug. 27, 2014 Annual Aug. 27, 2015 Preamplifier R&S SCU 18 10117 Dec. 26, 2014 Annual Dec. 26, 2016 Preamplifier MITEQ Inc. JS44-18004000-35-8P 1546891 Apr. 28, 2014 Annual Apr. 28, 2015 Test Receiver R&S ESU26 100109 Mar. 04, 2014 Annual Mar. 04, 2015 Bilog Antenna SCHWARZBECK MESSELEKTRONIK VULB9163 396 Jun. 07, 2013 Biennial Jun. 07, 2015 Loop Antenna SCHWARZBECK MESSELEKTRONIK FMZB 1519 1519-039 Jul. 09, 2013 Biennial Jul. 09, 2015 Horn Antenna R&S HF906 100326 Dec. 10, 2013 Biennial Dec. 10, 2015 Horn Antenna SCHWARZBECK MESSELEKTRONIK BBHA9170 BBHA9170223 Sep. 01, 2014 Biennial Sep. 01, 2016 Antenna Master INNCO MM4000 N/A N.C.R. N/A N.C.R. Turn Table INNCO DS 1200S N/A N.C.R. N/A N.C.R. Test Receiver R&S ESCI7 100911 Dec, 24. 2014 Annual Dec, 24. 2015 Two-Line V-Network R&S ENV216 100190 Dec. 25, 2014 Annual Dec. 25, 2015 Anechoic Chamber SY Corporation L × W × H (6.5 m × 3.5 m × 3.5 m) N/A N/A N/A N.C.R. Anechoic Chamber SY Corporation L × W × H (9.6 m × 6.4 m × 6.4 m) N/A N.C.R. N/A N.C.R. ▶ Support equipment Description Manufacturer Model Serial Number N/A - - - Report Number: F690501/RF-RTL008316 Page: 5 of 65 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Korea Co., Ltd. (Gunpo Laboratory) 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 435-040 http://www.sgsgroup.kr RTT5041-20(2014.01.20)(2) Tel. +82 31 428 5700 / Fax. +82 31 427 2370 A4(210mmx297mm) 1.6. Summary of Test Results The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part15 Subpart C § 15.247, RSS-210 Issue 8, RSS-Gen Issue 4 Standard section Test Item(s) Result 15.205 15.209 15.247(d) RSS-210 A8.5 Transmitter Radiated Spurious Emissions Conducted Spurious Emission Complied 15.247(a)(2) RSS-210 A8.2(a) RSS-Gen 6.6 6 ㏈ Bandwidth and 99 % Occupied Bandwidth Complied 15.247(b)(3) RSS-210 A8.4(4) Maximum Conducted Output Power Complied 15.247(e) RSS-210 A8.2(b) Power Spectral Density Complied 15.207 RSS…

Text truncated - open the document above for the full version.

SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, 435-040 Tel. 031-428-5700 / Fax. 031-427-2371 http://www.sgsgroup.kr Page : 1 / 6 Report File No : F690501/RF-SAR002241 Date of Issue : 2015-01-09 EUT Photographs a) Front View b) Rear View SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, 435-040 Tel. 031-428-5700 / Fax. 031-427-2371 http://www.sgsgroup.kr Page : 2 / 6 Report File No : F690501/RF-SAR002241 Date of Issue : 2015-01-09 c) Battery View d) Edge 1 View SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, 435-040 Tel. 031-428-5700 / Fax. 031-427-2371 http…
