A3LOTR10STSNMicrowave Oven

Safety Instructions . . . . . . . . 2–7 Operating Instructions Care and Cleaning . . . . . . . .37–40 Cooking Features . . . . . . . . .12–18 Defrosting Features . . . . . . .21–27 Easy Guide ™ Menu System . . . . .9 Help Features . . . . . . . . . . . . . .34 Home Screen . . . . . . . . . . . . . . .10 Microwave Oven Features . . . . . .8 Microwave Terms . . . . . . . . . . . .36 Options . . . . . . . . . . . . . . . .28–32 Other Features . . . . . . . . . . .33, 35 Power Levels . . . . . . . . . . . . . . .11 Reheating Features . . . . . . .19–20 Troubleshooting Tips . . . . . . .41 Consumer Support Consumer Support . . . Back Cover Warranty . . . . . . . . . . . . . . . . . . 42 www.GEAppliances.com Microwave Oven 164D3370P262 49-40329-1 04-03 JR JVM2070 Owner’s Manual Spacemaker 2.0 Write the model and serial numbers here: Model #________________ Serial # __________________ Find these numbers on a label on the left front when the door is open. 2 IMPORTANT SAFETY INSTRUCTIONS PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do Not Attemptto operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. (b) Do Not Placeany object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces. (c) Do Not Operatethe oven if it is damaged. It is particularly important that the oven door close properly and that there is no damage to the: (1) door (bent), (2) hinges and latches (broken or loosened), (3) door seals and sealing surfaces. (d) The Oven Should Notbe adjusted or repaired by anyone except properly qualified service personnel. • This microwave oven is UL listed for installation over electric and gas ranges. • This microwave oven is not approved or tested for marine use. • Read and follow the specific precautions in the Precautions to Avoid Possible Exposure to Excessive Microwave Energy section on page 2. • This appliance must be grounded. Connect only to properly grounded outlet. See the Grounding Instructions section on page 7. • Install or locate this appliance only in accordance with the provided Installation Instructions. • Do not mount this appliance over a sink. • This over-the-range oven was designed for use over ranges no wider than 36.′′It may be installed over both gas and electric cooking equipment. • Do not operate this appliance if it has a damaged power cord or plug, if it is not working properly or if it has been damaged or dropped. If the power cord is damaged, it must be replaced by General Electric Service or an authorized service agent using a power cord available from General Electric. • Do not cover or block any openings on the appliance. • Use this appliance only for its intended use as described in this manual. Do not use corrosive chemicals or vapors in this appliance. This microwave oven is specifically designed to heat, dry or cook food, and is not intended for laboratory or industrial use. • Do not store this appliance outdoors. Do not use this product near water— for example, in a wet basement, near a swimming pool, near a sink, or in similar locations. • Keep power cord away from heated surfaces. • Do not immerse power cord or plug in water. • To reduce the risk of fire in the oven cavity: — Do not overcook food. Carefully attend appliance when paper, plastic or other combustible materials are placed inside the oven while cooking. — Remove wire twist-ties and metal handles from paper or plastic containers before placing them in the oven. — Do not use the oven for storage purposes. Do not leave paper products, cooking utensils or food in the oven when not in use. — If materials inside oven ignite, keep the oven door closed, turn the oven off and disconnect the power cord, or shut off power at the fuse or circuit breaker panel. If the door is opened, the fire may spread. — Do not use the Sensor Features twice in succession on the same food portion. If food is undercooked after the first countdown, use TIME COOK for additional cooking time. • See door surface cleaning instructions in the Care and Cleaning of the microwave oven section of this manual. • This appliance should be serviced only by qualified service personnel. Contact nearest authorized service facility for examination, repair or adjustment. • As with any appliance, close supervision is necessary when used by children. • Do not store anything directly on top of the microwave oven surface when the microwave oven is in operation. 3 IMPORTANT SAFETY INSTRUCTIONS WARNING! For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury, or loss of life. SAFETY PRECAUTIONS Use this appliance only for its intended purpose as described in this Owner’s Manual. When using electrical appliances, basic safety precautions should be followed, including the following: 4 VENT FAN The fan will operate automatically under certain conditions (see Automatic Fan feature). Take care to prevent the starting and spreading of accidental cooking fires while the vent fan is in use. • Clean the underside of the microwave often. Do not allow grease to build up on the microwave or the fan filters. • In the event of a grease fire on the surface units below the microwave oven, smother a flaming pan on the surface unit by covering the pan completely with a lid, cookie sheet or flat tray. • Use care when cleaning the vent fan filters. Corrosive cleaning agents, such as lye-based oven cleaners, may damage the filters. • When preparing flaming foods under the microwave, turn the fan on. • Never leave surface units beneath your microwave oven unattended at high heat settings. Boilovers cause smoking and greasy spillovers that may ignite and spread if the microwave vent fan is operating. To minimize automatic fan operation, use adequate-siz…

Text truncated - open the document above for the full version.

JVM2070SH 01 1.58 NOVEMBER-2004 gplymnnnnn 1 YEAR FULL RF OUTPUT FREQUENCY : 2450MHz kW : VAC/Hz : 120/60 WARRANTY : FCC ID : A3LOTR10STSN MADE IN MALAYSIA

C 910 5 6 1 F EngineerDrawn by R&D CHK 1 8 H 23 Date Changed of 2 Sheet 9 MFG ENGR CHK SAMSUNG ELECTRONICS QA CHK B 4 Size Time Changed VENT HI/MID/LO/OFF VENT B DOC CTRL CHK 8 Drawing Number Address City 12 BOOST FG COOK TOP REV 12 A 11 EDA 5 7 DE 10 11 Wednesday, November 14, 2002 5:48:51 pm M.S.JEONM.S.JEON RA-OTR10 A2 Changed by 67 C H 3 TITLE 4 G BRIGHT/NIGHT/OFF SMW250-03AV_REDCN05 13 +3.3V KRC246TR01 D06 MM4148 +3.3V KRC246TR07 DGND OJ4 DGND DGND 100nFC42 DGND C41100nF DGND 100nFC40 100nF C39100nF C38C36 100nF100nF C37 CN06SMW250-04V_WHT 1234 P77 23 P80 24 P8125 P8226 P83 4 RESET7 TEST 31 VAREF30 VASS32 VDD 1 VSS3 XIN2 XOUT P52 33 P60 34 P61 35 P62 36 P63 37 P64 38 P65 39 P6640 P67 41 P70 42 P71 43 P72 44 P7345 P7446 P7547 P7648 P30 63 P31 62 P32 61 P33 60 P34 59 P35 58 P36 57 P37 17 P40 18 P41 19 P42 20 P43 21 P44 22 P45 29 P5028 P5127 P03 52 P04 51 P0550 P06 49 P07 9 P10 10 P11 11 P12 12 P13 13 P14 14 P15 15 P16 16 P17 8 P20 6 P21 5 P22 64 IC02TMP87PH48DF 56 P00 55 P01 54 P02 53 C11 R2547K DGND 100nF 10K TR02KRC246 PTC1270M R04 10D471ZNR1 KRC246TR03 R6747K D19MM4148 DGND R661K C12 KRC246TR05 DGND 100nF DGND OJ2 0.02nF C30C31 0.02nF KRC246TR12 +24V R061K 100nFC05 100nFC14 +5V D09 MM4148 132 54678 22uFC15 SLV-2070U(P)LVT1 IC12 KIA78D33F GND IN OUT TR16 KRC246 IC10 KIA7805AF GND IN OUT 13 FTR-JRJC024WRY01 SPC-717M PC01 64 100uFC08 470uFC01 C10 +3.3V 2200uFC07 PT01 TLP-560J 123 46 100uF TR15 KRC246 TR04KRC246 MM4148 D05 +29V TAC1 T835-600B T1 T2 RY03FTR-F3AA024E R2220K D02GS1GGS1GD01 DGND DGND DGND D10MM4148 1nFC29 C171nF DGND OJ1 1KR21 RY02FTR-JRJB024W DGND 100nFC06 R111K DGND DGND 1KR07 DGND 1nFC16 C04100nF R231K +24V DGND DGND DGND R10100K DGND 47KR26 1K R05 3.3K +24V DGND DGND DGND R13 IC11 KIA7805AF GND IN OUT DGND DGND TR11KRC246 KRC246 TR18 TR13 KRA226 1KR61 R601K KRC246 DGND 47uFC02 TR09 1K +3.3V +3.3V D12MM4148 D16 R16 R18 1K GS1G 1K R17 RY08FTR-F3AA024E TR06KRC246 54 32 1 DGND R021K CN02FCZ12511HS-05A00 4.7nFC13 DGND R12470K +3.3V 47uFC03 DGND 2K DGND DGND +3.3V DGND D11 DGND R09 MM4148 DGND DGND +5V BD1DF06S D17MM4148 1KR24 MM4148 D08 RY04FTR-F3AA024ERY05 100nFC34 FTR-F3AA024E GND IN OUT DGND IC09 KIA7824AF +3.3V R0147K GS1GD15C09100uF KRA226 TR17 1KR65 +3.3V XTL1 4.194304MHz DB4DWDAC1 DGND +24V DGND DGND RY07 123 FTR-F3AA024E DGND +5V SMW250-03V_WHTCN07 R14330 1K R19 D04 R031M +3.3V DGND MM4148 1uFC43 KIC7S14FU IC17 1 2 3 4 5 R08470 FTR-F3AA024ERY06 SMW250-07AV_REDCN03 1375 5V-1 123456789 SMW250-09V_REDCN04 DGND CBE2220BA BZ01 MM4148D18 MM4148 D03 3 OUT 4 VCC 1 R20 1K IC13 DISA8115 2 GND IN 5NC DGND KRC246TR10 D14MM4148 MM4148 D13 GS1G KRC246TR08 UART_2UART_1 KEY_IN_3 KEY_OUT_3KEY_OUT_2 MAIN D07 BZ_M BZ_H VENT CT_L TCO_IN VENT TCO RY_MAIN VT_CTCO VT_C L1 L1 LIVETCO LIVE LV_1LV_2 KEY_OUT_1 KEY_OUT_2 KEY_OUT_3 LED_O(12) TCO_IN RELAY_V DOOR CLOCK_ICLOCK_O CLOCK_O CLOCK_I T_TRY_MAINCT_LCT_HRY_LVINRUSHPOWER_HPOWER_L RELAY_V RY_LV BZ BZ_L S2 S1 S1 S2 E_INT E_INT BZ_MBZ_LBZBZ_H LV_1LV_2LV LED_O(8)LED_O(10)LED_O(6)LED_O(7)LED_O(9)PENIRQDCLKDINKEY_OUT_1 CT_H LV CSDOUT H_RESET LED_O(1)LED_O(2)LED_O(3)LED_O(4)LED_O(5)LED_O(11)CNCONT_1CONT_3CONT_2CONT_4 KEY_IN_1KEY_IN_2

JOB Number : LBE042053 Page 5 of 16 4.2 Input Power Measurement Input power and current were measured using a Power Analyzer. A 700ml water load was placed in the center of the oven and the oven set to maximum power. A 700 ml water load was chosen for its compatibility. Manufacturers to determine their input ratings commonly use this procedure. Fig. 2 Test Setup for Input power The results of this test are as follows. InputInputMeasuredEUT Spec. VoltageCurrentInput powerInput power [Vac][amps][watts][watts] 12013.616161580 Based on the measured input power, the EUT was found to be operating within the intended specifications. This reports shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. JOB Number : LBE042053 Page 6 of 16 4.3 RF Output Power Measurement The Caloric Method was used to determine maximum output power. The initial temperature of a 1000-ml water load was measured. The water load was placed in the center of the oven. The oven was operated at maximum output power for 120 seconds. Then the temperature of the water re-measured. Fig.3 Test Setup for RF output power QuantityStartingFinalElapsedRF Power of waterTemperature TemperatureTime [ml][centigrade][centigrade][seconds][watts] 10001034.4120851.4 10001034120837.4 10001033.8120830.4 839.7 Power = (4.187 Joules/Cal) x (Volume in ml) x (Temp. Rise) Time in seconds The measured output was found to be ABOVE 500Watts. Therefore, in accordance with section 18.305 of Subpart C, the measured out-of-band emissions were compared to the 25xSQRT(power/500)[uV/m] @ 300M limit. This reports shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Average RF Power of 3 Trials
