Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Connecting the Smart Remote (Bluetooth) to the TV Connect the Smart Remote (Bluetooth) to your TV to operate the TV. When you turn on the TV for the first time, the Smart Remote (Bluetooth) pairs to the TV automatically. If the Smart Remote (Bluetooth) does not pair to the TV automatically, point it at the front of the TV, then press and hold the and buttons simultaneously for 3 seconds or more. Remote Control and Peripherals You can control TV operations with your Remote Control. Pair external devices such as a keyboard for ease of use. About the Remote Control Learn about the buttons on the Remote Control. The image, buttons, and functions of the remote control may differ depending on the model or geographical area. Use the Smart Remote (Bluetooth) less than 6 m from the TV. The usable distance may vary with the wireless environmental conditions. To use the Remote Control to control a compatible external device that does support HDMI-CEC (Anynet+), connect the device to an HDMI port on the TV using an HDMI cable. For more information, refer to "Using Anynet+ (HDMI-CEC)". Basic buttons ButtonDescription (Power) Press to turn the TV on or off. (Voice Assistant) Runs Voice Assistant. Press and hold the button, say a command, and then release the button to run Voice Assistant. This button is optional and it is supported by only the Smart Remote that uses Bluetooth communication. Directional button (up, down, left, right) Use to navigate the menu or move the focus to highlight items on the Home Screen. Select Selects or runs a focused item. When pressed while you are watching a broadcast programme, detailed programme information appears. (Return) Press to return to the previous menu. When pressed for 1 second or more, the running function is terminated. When pressed while you are watching a programme, the previous channel appears. (Smart Hub) Press to return to the Home Screen. (Volume) Move the button up or down to adjust the volume. To mute the sound, press the button. When pressed for 1 second or more, the Accessibility Shortcuts appears. Press and hold the MUTE button if it exists on the remote control, to run the Accessibility Shortcuts. ButtonDescription (Channel) Move the button up or down to change the channel. To see the Guide screen, press the button. When pressed for 1 second or more, the Channel List screen appears. Press the GUIDE button if it exists on the remote control, to enter the Guide screen. Launch app button Launch the app indicated by the button. Available apps may differ depending on the geographical area or contents provider. Buttons for each type ButtonDescription 0-9, - (Number button)Enter numbers on each button. (Number button) Press to bring up the virtual numeric pad on the screen. Use the numeric keypad to enter numeric values. Select numbers and then select Done to enter a numeric value. Use to change the channel, enter a PIN, ZIP code and etc. When pressed for 1 second or more for a channel that supports the teletext service, the TTX menu appears on the TV screen. For more information, refer to " Teletext Feature". Red, Green, Yellow, Blue (Colour button) Press a button to run the additional option for the current function. (Colour button) When pressed, coloured buttons appear on the screen. Use this button to access additional options that are specific to the feature in use. Multimedia Button (Play/Pause/etc.)Run the assigned functions for each button (e.g. Rewind, Play, Pause). (Play/Pause) When pressed, the playback controls appear. Using these controls, you can control the media content that is playing.
Samsung Electronics Co., Ltd. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 04-13-2023 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID: A3LRE20 Samsung Electronics Co., Ltd. (“the applicant”) as required by section 2.911(d)(7), designates the following agent, located in the United States, for purposes of acting as the applicant’s agent for service of process. The applicant acknowledges that they will maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission‐related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the agent information changes. Designated U.S. Agent Information: Name: Samsung Electronics Co., Ltd. FRN: 0027908797 Address: 19 Chapin Rd., Building D Pine Brook, NJ 07058 Contact Person: Ms. Jenni Chun Tel.: +1-973-808-6375 Email: [email protected] Sincerely, Samsung Electronics Co., Ltd. Jenni Chun
Rev 1/26/2023 Samsung Electronics Co., Ltd. (Maetan dong) 129, Samsung-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 04-13-2023 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: A3LRE20 Samsung Electronics Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Samsung Electronics Co., Ltd. Jenni Chun Rev 1/26/2023 Samsung Electronics Co., Ltd. (Maetan dong) 129, Samsung-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 04-13-2023 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: A3LRE20 Samsung Electronics Co., Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Samsung Electronics Co., Ltd. Jenni Chun
Samsung Electronics Co., Ltd. (Maetan dong) 129, Samsung-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: A3LRE20 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram Schematics Operational Description Part List [RE20] BLK [RE20] SCH [RE20] OpDes [RE20] Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); Exhibit Type File Name External Photos Internal Photos Test Setup Photos Manual [RE20] EXT Photo [RE20] INT Photo [RE20] Test Setup Photo [RE20] Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. Sincerely, Samsung Electronics Co., Ltd. Jenni Chun
Samsung Electronics Co., Ltd. (Maetan dong) 129, Samsung-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea Apr 13, 2023 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Letter of Authorization We, the undersigned, hereby authorize Kenneth Kim of NCT Co.,Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCC ID: A3LRE20 / IC : 649E-RE20 including signing of all documents relating to these matters. Any and all acts carried out by Kenneth Kim of NCT Co.,Ltd. on our behalf shall have the same affect as acts of our own. “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Samsung Electronics America, Inc. Jenni Chun
PCB Label Position for CE
BT Antenna
Test Repot No.: NW2304-F002 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 2 of 7 Table of contents 1. General Information -------------------------------------------------------------------------------- 2. Information’s about Test Item ------------------------------------------------------------------- 3. Test Report -------------------------------------------------------------------------------------------- 3.1 Test Report Version ----------------------------------------------------------------------------- 3.2 SAR Test Exclusion Considerations for FCC ------------------------------------------ 3.3 SAR Test Exclusion Considerations for ISED ------------------------------------------ 3 3 5 5 6 7 Test Repot No.: NW2304-F002 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 3 of 7 1. General Information’s 1.1 Test Performed Laboratory : NCT Co., Ltd. Address : 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, 18511, Korea Telephone : +82-31-323-6070 Facsimile : +82-31-323-6071 FCC Designation No. : KR0166 FCC Registration Number : 409631 2. Information’s about Test Item 2.1 Applicant Information Company name : Samsung Electronics Co., Ltd. Address : (Maetan dong) 129, Samsung-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea Telephone / Facsimile : +82-10-2666-5199 / +82-31-277-9027 2.2 Equipment Under Test (EUT) description Test item particulars : SMART CONTROL Model and/or type reference : RE20 Additional model name : - Serial number : Prototype Antenna type and gain : Chip Antenna with Max gain: 0.50 dBi Date (s) of performance of tests: : 2023-03-24 ~ 2023-04-04 Date of receipt of test item : 2023-03-24 EUT condition : Pre-production, not damaged Number of channel : 40 EUT Power Source : DC 3.00 V Type of Modulation : GFSK Firmware version : 1.0 Hardware version : 1.0 Test software name(version) : RadioControlConsole(Version 4.0.0.0) Test Repot No.: NW2304-F002 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 4 of 7 2.3 Tested Frequency Test Mode Test frequency (MHz) Low frequency Middle frequency High frequency BLE 2 402 2 440 2 480 Test Repot No.: NW2304-F002 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 5 of 7 3. Test Report 3.1 Test Report Version Test Report No. Date Description NW2304-F002 2023-04-06 Initial issue Test Repot No.: NW2304-F002 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 6 of 7 3.2 SAR Test Exclusion Considerations for FCC Following FCC KDB 447498 D01 “General SAR test exclusion guidance” - 4.3.1 a) a) For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where - f(GHz) is the RF channel transmit frequency in GHz - Power and distance are rounded to the nearest mW and mm before calculation - The result is rounded to one decimal place for comparison Modulation Frequency (MHz) Min. Test separation distance Measured Maximum Average power Tune-up tolerance Max. Power with tune-up tolerance Standalone SAR Test exclusion thresholds for 100MHz to 6GHz at test separation distance ≤ 50 mm Limit Result (mm) (dBm) (dB) (dBm) (mW) BT LE 2402 5.00 2.17 ± 0.50 2.67 1.85 0.57 3.00 PASS 2440 0.56 1.06 1.28 0.40 3.00 PASS 2480 -1.90 -1.40 0.72 0.23 3.00 PASS Test Repot No.: NW2304-F002 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 7 of 7 3.3 SAR Test Exclusion Considerations for ISED Following RSS-102 “Radio Frequency (RF) Rxposure Compliance of Radiocommunication Apparatus” Mode Frequency (MHz) Measured Max. Average power Antenna Gain EIRP for Max. Average power Limit Result (dBm) (dBi) (dBm) (mW) (mW) BT LE 2402 2.17 0.50 2.67 1.85 4.26 PASS 2440 0.56 1.06 1.28 4.05 PASS 2480 -1.90 -1.40 0.72 3.94 PASS
INPAQ TECHNOLOGY CO., LTD 2008/12/19 UNLESS OTHER SPECIFIED TOLERANCES ON: INPAQ TECHNOLOGY CO., LTD. X=± X.X=± X.XX= ANGLES=± HOLEDIA=± SCALE: xxxx UNIT:mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY: 張芳榕 CHECKED BY: 楊奇峰 DESIGNED BY: 謝立庭 APPROVED BY: 蔡岳霖 TITLE:ACA-3216-A2-MC-S SPECIFICATION DOCUMENT ENS000015380 SPEC REV. NO. P3 Page 1 Of 6 ACA-3216-A2-MC-S SPECIFICATION 1. EXPLANATION OF PART NUMBER: AC A _ 3216 A2 _ MC _ S _ _ (1) (2) (3) (4) (5) (6) (7) (1) Product Type: Chip Antenna (2) Center Frequency/Band Code: A -2.45GHz (3) Size Code: 3.2mm(length) x 1.6mm(width) (4) Design Revision Code: A2= Rev. 2 (5) Series No.: MC=MONOPOLE Ceramics type (6) Special Code: S= RoHS Compliant (7) Suffix For Special Requirements 2. ELECTRICAL SPECIFICATION ITEM SPECIFICATION Frequency Band 2400MHz〜2500MHz Return Loss Less than -10 Polarization Linear *Gain Max peak gain: 0.5 dBi Typ peak gain: -0.5 dBi Impedance 50Ω typ. *Test condition :Test board size 53*20 mm,ground clearance 13*20 mm Matching circuit : Pi matching circuit will be required 3. DIMENSIONS: Mark L W H a Dimensions 3.2±0.2 1.6±0.2 0.7±0.15 0.35±0.15 INPAQ TECHNOLOGY CO., LTD 2008/12/19 UNLESS OTHER SPECIFIED TOLERANCES ON: INPAQ TECHNOLOGY CO., LTD. X=± X.X=± X.XX= ANGLES=± HOLEDIA=± SCALE: xxxx UNIT:mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY: 張芳榕 CHECKED BY: 楊奇峰 DESIGNED BY: 謝立庭 APPROVED BY: 蔡岳霖 TITLE:ACA-3216-A2-MC-S SPECIFICATION DOCUMENT ENS000015380 SPEC REV. NO. P3 Page 2 Of 6 4. RECOMMENDED PCB LAYOUT: (unit: mm) 5. TERMINAL CONFIGURATION: Bottom Layer: Top Layer: INPAQ TECHNOLOGY CO., LTD 2008/12/19 UNLESS OTHER SPECIFIED TOLERANCES ON: INPAQ TECHNOLOGY CO., LTD. X=± X.X=± X.XX= ANGLES=± HOLEDIA=± SCALE: xxxx UNIT:mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY: 張芳榕 CHECKED BY: 楊奇峰 DESIGNED BY: 謝立庭 APPROVED BY: 蔡岳霖 TITLE:ACA-3216-A2-MC-S SPECIFICATION DOCUMENT ENS000015380 SPEC REV. NO. P3 Page 3 Of 6 6. ELECTRICAL CHARACTERISTICS Return Loss 7. RADIATION PATTERN The gain pattern is measured in INPAQ’s far-field chamber. AUT is placed on the table of rotator, a standard horn antenna and vector network analyzer is used to collect data. ( Please contact with INPAQ for more detail ) Measuring factors definition 2400MHz 2450MHz 2500MHz Freq. Return Loss 2400 MHz -13.78 dB 2450 MHz -27.17 dB 2500 MHz -13.74 dB X Y Z INPAQ TECHNOLOGY CO., LTD 2008/12/19 UNLESS OTHER SPECIFIED TOLERANCES ON: INPAQ TECHNOLOGY CO., LTD. X=± X.X=± X.XX= ANGLES=± HOLEDIA=± SCALE: xxxx UNIT:mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY: 張芳榕 CHECKED BY: 楊奇峰 DESIGNED BY: 謝立庭 APPROVED BY: 蔡岳霖 TITLE:ACA-3216-A2-MC-S SPECIFICATION DOCUMENT ENS000015380 SPEC REV. NO. P3 Page 4 Of 6 8. PACKAGING (1) Quantity: 3000pcs/Reel (2) Plastic Tape: (unit: mm) (3) Tape Packing (4) Cover Tape Reel Off Force (5) Reel Dimensions: (unit: mm) A 8.0±0.3 B 3.5±0.05 C 1.75±0.1 D 2.0±0.05 E 4.0±0.1 F 1.5~1.6 L 3.5±0.2 W 1.9±0.2 A 178.0±2.0 B 2.0±0.5 C 13.0±0.5 D 21.0±0.8 E 60.0±1.0 F 9.0±0.5 G 12.0±0.2 INPAQ TECHNOLOGY CO., LTD 2008/12/19 UNLESS OTHER SPECIFIED TOLERANCES ON: INPAQ TECHNOLOGY CO., LTD. X=± X.X=± X.XX= ANGLES=± HOLEDIA=± SCALE: xxxx UNIT:mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY: 張芳榕 CHECKED BY: 楊奇峰 DESIGNED BY: 謝立庭 APPROVED BY: 蔡岳霖 TITLE:ACA-3216-A2-MC-S SPECIFICATION DOCUMENT ENS000015380 SPEC REV. NO. P3 Page 5 Of 6 9. Environmental Specifications: (1) Reliability Test Item Condition Specification Thermal shock 1. 30±3 minutes at -40°C±5°C, 2. Convert to +105°C (5 minutes) 3. 30±3 minutes at +105°C±5°C, 4. Convert to -40°C (5 minutes) 5. Total 24 continuous cycles No apparent damage Fulfill the electrical spec. after test. Humidity resistance 1. Humidity: 85% R.H. 2. Temperature: 85±5°C 3. Time: 500 hours. No apparent damage Fulfill the electrical spec. after test. High temperature resistance 1. Temperature: 150°C±5°C 2. Time: 1000 hours. No apparent damage Fulfill the electrical spec. after test. Low temperature resistance 1. Temperature: -40°C±5°C 2. Time: 1000 hours. No apparent damage Fulfill the electrical spec. after test. Soldering heat resistance 1. Solder bath temperature : 260±5°C 2. Bathing time: 10±1 seconds No apparent damage Solderability The dipped surface of the terminal shall be at least 95% covered with solder after dipped in solder bath of 245±5°C for 3±1 seconds. No apparent damage (2) Storage condition (a) At warehouse: The temperature should be within 0 ~ 30°C and humidity should be less than 75% RH. The product should be used within 1 year from the time of delivery. (b) On board: The temperature should be within -40~85°C and humidity should be less than 85% RH. (3) Operating temperature range Operating temperature range : -40°C to +105°C. INPAQ TECHNOLOGY CO., LTD 2008/12/19 UNLESS OTHER SPECIFIED TOLERANCES ON: INPAQ TECHNOLOGY CO., LTD. X=± X.X=± X.XX= ANGLES=± HOLEDIA=± SCALE: xxxx UNIT:mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY: 張芳榕 CHECKED BY: 楊奇峰 DESIGNED BY: 謝立庭 APPROVED BY: 蔡岳霖 TITLE:ACA-3216-A2-MC-S SPECIFICATION DOCUMENT ENS000015380 SPEC REV. NO. P3 …
Text truncated - open the document above for the full version.
Test Repot No.: NW2304-F001 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 2 of 52 Table of contents 1. General Information -------------------------------------------------------------------------------- 2. Information’s about Test Item ------------------------------------------------------------------- 3. Test Report -------------------------------------------------------------------------------------------- 3.1 Test Summary ------------------------------------------------------------------------------------- 3.2 Test Report Version ----------------------------------------------------------------------------- 3.3 Transmitter Requirements 3.3.1 Antenna Requirement --------------------------------------------------------------------- 3.3.2 6 dB Bandwidth & Occupied Bandwidth --------------------------------------------- 3.3.3 Maximum Peak Output Power ---------------------------------------------------------- 3.3.4 Peak Power Spectral Density ----------------------------------------------------------- 3.3.5 TX Radiated Spurious Emission and Conducted Spurious Emission --------- 3.3.6 Conducted Emission ----------------------------------------------------------------------- APPENDIX APPENDIX I TEST SETUP --------------------------------------------------------------------- - APPENDIX II TEST EQUIPMENT USED FOR TESTS ---------------------------------- APPENDIX III UNCERTAIN --------------------------------------------------------------------- 3 3 5 5 6 7 8 12 15 18 46 47 49 51 Test Repot No.: NW2304-F001 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 3 of 52 1. General Information’s 1.1 Test Performed Laboratory : NCT Co., Ltd. Address : 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, 18511, Korea Telephone : +82-31-323-6070 Facsimile : +82-31-323-6071 FCC Designation No. : KR0166 FCC Registration Number : 409631 2. Information’s about Test Item 2.1 Applicant Information Company name : Samsung Electronics Co., Ltd. Address : (Maetan dong) 129, Samsung-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea Telephone / Facsimile : +82-10-2666-5199 / +82-31-277-9027 2.2 Equipment Under Test (EUT) description Test item particulars : SMART CONTROL Model and/or type reference : RE20 Additional model name : - Serial number : Prototype Antenna type and gain : Chip Antenna with Max gain: 0.50 dBi Date (s) of performance of tests: : 2023-03-24 ~ 2023-04-04 Date of receipt of test item : 2023-03-24 EUT condition : Pre-production, not damaged Number of channel : 40 EUT Power Source : DC 3.00 V Type of Modulation : GFSK Firmware version : 1.0 Hardware version : 1.0 Test software name(version) : RadioControlConsole(Version 4.0.0.0) Test Repot No.: NW2304-F001 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 4 of 52 2.3 Tested Frequency Test Mode Test frequency (MHz) Low frequency Middle frequency High frequency BLE 2 402 2 440 2 480 2.4 Used Test Software Setting Value Test Mode Setting Item Power BLE Default Test Repot No.: NW2304-F001 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 5 of 52 3. Test Report 3.1 Test Summary Applied FCC Rule IC Rule Test Items Test Condition Result 15.203 - Antenna Requirement Conducted C 15.247(a) RSS-247 (5.2) 6 dB Bandwidth C - RSS GEN (6.7) Occupied Bandwidth (99%) C 15.247(b) RSS-247 (5.4) Maximum Peak Output Power C 15.247(e) RSS-247 (5.2) Peak Power Spectral Density C 15.247(d) RSS-247 (5.5) Conducted Spurious Emission C 15.247(d) 15.205 & 15.209 RSS-247 (5.5) RSS-GEN (8.9 & 8.10) Radiated Spurious Emission Radiated C 15.207 RSS-GEN (8.8) Conducted Emissions AC Line Conducted N/A note2 Note 1: C=Complies NC=Not Complies NT=Not Tested NA=Not Applicable Note 2: This product is only using DC power. So, AC conducted emission test has not been performed. The sample was tested according to the following specification: ANSI C63.10:2020. Compliance was determined by specification limits of the applicable standard according to customer requirements. Test Repot No.: NW2304-F001 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 6 of 52 3.2 Test Report Version Test Report No. Date Description NW2304-F001 2023-04-06 Initial issue Test Repot No.: NW2304-F001 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 7 of 52 3.3 Transmitter Requirements 3.3.1 Antenna Requirement Accoding to §15.203 An intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. The use of a permanently attached antenna or of an antenna that uses a unique coupling to the intentional radiator shall be considered sufficient to comply with the provisions of this section. The manufacturer may design the unit so that a broken antenna can be replaced by the user, but the use of a standard antenna jack or electrical connector is prohibited. Accoding to §15.247(b)(4) e conducted output power limit specified in paragraph (b) of this section is based on the use of antennas with directional gains that do not exceed 6 dBi. Except as shown in paragraph (c) of this section, if transmitting antennas of directional gain greater than 6 dBi are used, the conducted output power from the intentional radiator shall be reduced below the stated values in paragraphs (b)(1), (b)(2), and (b)(3) of this section, as appropriate, by the amount in dB that the directional gain of the antenna exceeds 6 dBi. 3.3.1.1 Result Complies (The transmitter has a Chip Antenna. The directional peak gain of the antenna is 0.50 dBi.) Test Repot No.: NW2304-F001 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82…
Text truncated - open the document above for the full version.
Below 30 MHz Below 1 GHz Above 1 GHz
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 1.60 mW |
