A3LRMCSPA1AP1Smart Control

ButtonDescription (Power) Press to turn the TV on or off. (Voice Assistant) Runs Voice Assistant. Press and hold the button, say a command, and then release the button to run Voice Assistant. •The supported Voice Assistant's languages and features may differ by geographical region. [Keep the remote more than 0.6 inches (15.24 mm) from your face when using and speaking to Voice Assistant through the mic on the remote. (Color - Number button) Each time you press this button, the colored buttons window and the virtual numeric pad are displayed alternately. •Use this button to access additional options that are specific to the feature in use. •Press to bring up the virtual numeric pad on the screen. Use the numeric keypad to enter numeric values. Select numbers and then select Done to enter a numeric value. Use to change the channel, enter a PIN, enter a ZIP code, etc. (QuickAccess) Press the button to display the QuickAccess menu. You can select the desired feature from the menu to go directly, and you can change the menu.. 1 Directional button (up, down, left, right) Use to navigate the menu or move the focus to highlight items on the Home Screen. 2 Select Selects or runs a focused item. When pressed while you are watching a broadcast program, detailed program information appears. (Return) Press to return to the previous menu. When pressed for 1 second or more, the running function is terminated. When pressed while you are watching a program, the previous channel appears. (Smart Hub) Press to return to the Home Screen. (Play/pause) When pressed, the playback controls appear. Using these controls, you can control the media content that is playing. (Volume) Move the button up or down to adjust the volume. To mute the sound, press the button. (Channel) Move the button up or down to change the channel. To see the Guide screen, press the button. Press and hold the button up or down to quickly change the channel. 3 (Launch app button) Launch the app indicated by the button. + (Pairing) If the Samsung Smart Remote does not pair to the TV automatically, point it at the front of the TV, and then press and hold the and buttons simultaneously for 3 seconds or more. –Use the Samsung Smart Remote less than 20 feet (6 m) from the TV. The usable distance may vary with the wireless environmental conditions. –The images, buttons, and functions of the Samsung Smart Remote may differ with the model or geographical area. –The Universal Remote function operates normally only when you use the Samsung Smart Remote that comes with the TV. About the Buttons on the Samsung Smart Remote 3 2 1 The Accessibility Shortcuts button on your remote provides easy access to the accessibility functions on your TV. For more information, refer to the next page. Press and hold the Volume button to display the Accessibility Shortcuts menu. ENG BN68-******-X0 1 1 2 2 Using Accessibility Functions (may differ with model) Accessing your TV's accessibility functions The Accessibility Shortcuts button on your remote provides easy access to the accessibility functions on your TV. •Press and hold the Volume button to display the Accessibility Shortcuts menu. Voice Guide Settings You can activate voice guides that describe the menu options aloud to aid the visually impaired. To activate this function, set Voice Guide to On. With Voice Guide on, the TV provides voice guides for channel change, volume adjust, information on current and upcoming programs, schedule viewing, other TV functions, various content in the Web Browser, and in Search. •You can configure the volume, speed, pitch, and level of the Voice Guide. •The Voice Guide is provided in the language that is specified on the Language screen. English is always supported. However, some languages are not supported by Voice Guide even though they are listed in the Language screen. TV Background Volume By default, the volume of the broadcast content is set to be low so that you can hear the voice guide clearly. When the content volume is too low while the voice guide is coming out, you can adjust the content volume. Picture Off Turn off the TV screen and provide only sound to reduce overall power consumption. When you press any button on the remote control with the screen off, the TV screen is returned to on. Video Description You can activate an audio guide that provides an audio description of video scenes for the visually impaired. This function is only available with broadcasts that provide this service. High Contrast You can change major service screens to white text on a black background or change the transparent TV menus to opaque so that text can be more easily read. To activate this function, set High Contrast to On. Grayscale You can change the color of the TV screen to a black and white tone to sharpen blurred edges caused by colors. •If Grayscale is on, some Accessibility menus are not available. •This function may not be supported depending on the model or geographical area. Color Inversion You can invert the colors of the text and background for the setting menus displayed on the TV screen to make it easier to read them. •If Color Inversion is on, some Accessibility menus are not available. •This function may not be supported depending on the model or geographical area. Enlarge You can enlarge the size of the font on the screen. To activate, set Enlarge to On. Learn TV Remote This function helps individuals with a visual impairment to learn the positions of the buttons on the remote control. When this function is activated, you can press a button on the remote control and the TV will tell you its name. Press the RETURN button twice to exit Learn TV Remote. •This function is only available when Voice Guide is enabled. Learn Menu Screen Learn the menus on the TV screen. Once enabled, your TV will tell you the structure and features of the menus you select. •This function is only available when Voice Guide is enabled. Caption Settings Set Caption to On to watch programs with…

Text truncated - open the document above for the full version.

Rev 11/20/07 19 Chapin Rd, Building D. Pine Brook, New Jersey Tel No : 973-808-6375 Fax No : - Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: A3LRMCSPA1AP1 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram Schematics Parts List Operational description (RMCSPA1AP1)_Block Diagram.pdf (RMCSPA1AP1)_Schematics.pdf (RMCSPA1AP1)_Schematics PCB Layout.pdf (RMCSPA1AP1)_Part List.pdf (RMCSPA1AP1) _Operational Description.pdf (RMCSPA1AP1)_Antenna Specification Operational Description.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Sincerely, HanSung You / Staff Engineer Samsung Electronics Co., Ltd.

19 Chapin Rd, Building D. Pine Brook, New Jersey Tel No : 973-808-6375 Fax No : - Special Power of Attorney I, HanSung You of Samsung Electronics Co., Ltd. hereby authorize appoint WonJae, Hwang of CTK Co., Ltd. to represent me to act on my behalf to do any and all of the following : Sign on my behalf the agency, anti-drug and confidentiality cover letters and apply to FCC for the products. The right, powers and authority in fact to exercise any and all of the rights and powers herein granted shell commence and be in full force from 2020/11/06 and continue to effective unless specifically terminated by either party. Applicant : Samsung Electronics Co., Ltd. FCC ID : A3LRMCSPA1AP1 Dated 2020/11/06 Sincerely, HanSung You / Staff Engineer Samsung Electronics Co., Ltd.

19 Chapin Rd, Building D. Pine Brook, New Jersey Tel No : 973-808-6375 Fax No : - MODEL ATTESTATION COVER LETTER Date: 2020-11-06 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Attn: OET Dept. FCC ID: A3LRMCSPA1AP1 Product/ Model Number : Smart Control / RMCSPA1AP1, RMCSPA1BP1 Addition of model name as follow: - Basic Model name : RMCSPA1AP1 - Variant Model name : RMCSPA1BP1 It is simply the difference between the presence of buttons on the exterior of the case, and the internal circuit is the same. The device remain electrically, Software Configuration and mechanically identical to the originally certified device and no changes have been made. Sincerely, NAME: HanSung You TITLE: Staff Engineer Applicant: Samsung Electronics Co., Ltd. 129, Samsung-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea

19 Chapin Rd, Building D. Pine Brook, New Jersey Tel No : 973-808-6375 Fax No : - Special Power of Attorney Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Attn: OET Dept. Product/ Model Number: Smart Control / RMCSPA1AP1, RMCSPA1BP1 I, JENNI CHUN of SAMSUNG Electronics Co., Ltd. hereby appoint HanSung You of SAMSUNG Electronics Co., Ltd. to represent me to act on my behalf to do any and all of the following : Sign on my behalf the agency, anti-drug and confidentiality cover letters and apply to FCC for the products. The right, powers and authority in fact to exercise any and all of the rights and powers herein granted shell commence and be in full force from 11/06/2020 and continue to 11/06/2021 effective unless specifically terminated by either party. This authorization is limited to the product of as following: FCC ID: A3LRMCSPA1AP1 Dated 11/06/2020, JENNI CHUN Sincerely,. NAME: JENNI CHUN TITLE: General Manager, Regulatory & Environmental Affairs Applicant: Samsung Electronics America, Inc Address: 19 Chapin Rd, Building D. Pine Brook, NJ 07058

CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com EUT External Photographs CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com

CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Label Photographs

CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com EUT Internal Photographs CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Antenna

In re : Samsung Electronics Co LtdFCC ID : A3LRMCSPA1AP1Conducted Output Power Mode Mode BLE Zigbee Output Power(dBm) Output Power(dBm) 2402 1.746 2405 7.523 2440 7.214 2445 7.248 2480 7.701 2475 7.734 2480 1.105 RF Exposure Evaluation Mode Antenna Gain (dBi) Conducted Output Power (dBm) EIRP (mW) BLE 0.97 7.701 7.364 Zigbee 0.97 7.734 7.420 SAR Test Exclusion CalculatorInsert values in yellow highlighted boxes to determine SAR Excl usion Max Power 7.420 mW Min Separation 5 mm Frequency 2.4 GHz Answer 2.3 KDB 628591 D01 TCB Exclusion List v16TCBs are excluded from granting if:Controlled Use: The Answer is equal to or greater than 60 (20x threshold) KDB 447498 D01 General RF Exposure Guidance v064.3.1. Standalone SAR test exclusion considerations Frequency (MHz) General Population: The Answer is equal to or greater than 24 (8x threshold) Please also note the following: [FCC KDB quote] These test exclusion conditions are based on source-based time -averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up to lerance, and the minimum test separation distance required for the exposure conditions. The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer sur face. [End quote] When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. 100 MHz to 6 GHz at separation distance less than or equal to 5 0 mm Must be less than or equal to 3.0 for SAR Exclusionand , when published RF exposure KDB procedures are not established for SAR testing or when SAR data is not provided to support compliance. Frequency (MHz)

TEST REPORT CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2020-04118 Page (1) / (37) Pages QF-QP15-03 R101 Rev.0 1. Client ◦ Name : Samsung Electronics Co Ltd ◦ Address : 19 Chapin Rd, Building D. Pine Brook, New Jersey, United States ◦ Date of Receipt : 2020-08-07 2. Manufacturer ◦ Name : Samsung Electronics Co., Ltd. ◦ Address : 129, Samsung-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea 3. Use of Report : For FCC Report/ ISED Report 4. Test Sample / Model: Smart Control / RMCSPA1AP1 and RMCSPA1BP1 5. Date of Test : 2020-10-16 to 2020-10-22 6. Test Standard(method) used : FCC 47 CFR part 15 subpart C 15.247 RSS-247 & RSS-Gen 7. Testing Environment: Temp.: (23 ± 1) °C, Humidity: (49 ± 3) % R.H. 8. Test Results : Compliance The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This Test Report cannot be reproduced, except in full. Affirmation Tested by Ji-Hye, Kim: (Signature) Technical Manager Won-Jae, Hwang: (Signature) 2020-10-23 Republic of KOREA CTK Co., Ltd. CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2020-04118 Page (2) / (37) Pages QF-QP15-03 R101 Rev.0 REPORT REVISION HISTORY Date Revision Page No 2020-10-23 Issued (CTK-2020-04118) all This report shall not be reproduced except in full, without the written approval of CTK Co., Ltd. This document may be altered or revised by CTK Co., Ltd. personnel only, and shall be noted in the revision section of the document. Any alteration of this document not carried out by CTK Co., Ltd. will constitute fraud and shall nullify the document. CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2020-04118 Page (3) / (37) Pages QF-QP15-03 R101 Rev.0 CONTENTS 1. General Product Description ....................................................................................... 4 1.1 Client Information ............................................................................................. 4 1.2 Product Information ........................................................................................... 4 1.3 Peripheral Devices ............................................................................................. 4 1.4 Model Differences .............................................................................................. 5 2. Facility and Accreditations .......................................................................................... 6 2.1 Test Facility ...................................................................................................... 6 2.2 Laboratory Accreditations and Listings .................................................................. 6 2.3 Calibration Details of Equipment Used for Measurement .......................................... 6 3. Test Specifications .................................................................................................... 7 3.1 Standards ........................................................................................................ 7 3.2 Mode of operation during the test ........................................................................ 8 3.3 Device Modifications .......................................................................................... 8 3.4 Maximum Measurement Uncertainty .................................................................... 8 3.5 Test Software ................................................................................................... 8 4. Technical Characteristic Test ....................................................................................... 9 4.1 6dB Bandwidth ................................................................................................. 9 4.2 Maximum peak Conducted Output Power ............................................................ 12 4.3 Transmitter Power Spectral Density .................................................................... 15 4.4 Conducted Spurious emission ............................................................................ 18 4.5 Radiated Emission ........................................................................................... 20 4.6 AC Conducted Emissions .................................................................................. 34 APPENDIX A – Test Equipment Used For Tests ................................................................ 37 CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2020-04118 Page (4) / (37) Pages QF-QP15-03 R101 Rev.0 1. General Product Description 1.1 Client Information Company Samsung Electronics Co., Ltd. Contact Point 129, Samsung-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea Contact Person Name : HanSung You E-mail : [email protected] Tel : +82 31-277-2746 Fax : - 1.2 Product Information FCC ID A3LRMCSPA1AP1 ISED 649E-RMCSPA1AP1 Product Description Smart Control Model name RMCSPA1AP1 Variant Model name RMCSPA1BP1 Operating Frequency 2 402 MHz - 2 480 MHz RF Output Power 7.701 dBm (5.890 mW) Antenna Specification Antenna type : Chip Antenna Peak Gain : 0.97 dBi Number of channels 40 Channel Spacing 1 MHz Type of Modulation GFSK (Bluetooth LE) Power Source DC 3 V Hardware Rev TM2180A_200821 Software Rev A 1.3 Peripheral Devices Device Manufacturer Model No. Serial No. Note Computer HP 15-bs563TU CND7253QPR AC/DC Adapter HP HSTNN-LA40 - CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 Report No.: CTK-2020-04118 Page (5) / (37) Pages QF-QP15-03 R101 Rev.0 1.4 Model Differences It is simply the difference between the presence of buttons on the exterior of the case, and the internal circuit…
