A3LSCH620Dual Mode Cellular Phone (AMPS/CDMA)

Printed in Korea Code No. : GG68-xxxxxA English 7/99. Rev.1.0 PORTABLE CELLULAR TELEPHONE SCH-620 Owner’s Manual 1 Contents GETTING STARTED Unpacking ..............................................................................................7 Phone Layout .........................................................................................8 Key Functions ......................................................................................9 Display .................................................................................................10 Icons .................................................................................................10 Installing Battery...................................................................................11 To Install the Battery.........................................................................11 To Remove the Battery......................................................................12 Charging a Battery................................................................................13 Low Battery Indicator ........................................................................14 Switching the Phone On/Off ..................................................................15 GENERAL FUNCTIONS Making a Call ........................................................................................16 Correcting the Number ......................................................................16 Ending a Call .....................................................................................16 Emergency Dialing ............................................................................17 Prepend Dialing ................................................................................17 Making a Call from the Phone Book ..................................................18 Voice Dialing .....................................................................................19 Last Number Redial ...............................................................................20 Answering a Call ....................................................................................21 Viewing Missed Calls ..............................................................................22 In-Call Options .......................................................................................23 Call Waiting ......................................................................................23 Three-Way Calling..............................................................................23 Call Forwarding..................................................................................24 Microphone Gain................................................................................24 Adjusting the Volume..............................................................................24 Quick Switching to Vibration Mode .........................................................25 Recording Voice Memo ...........................................................................25 Table of Contents 2 Contents 3 Contents USINGTHEMENUS Using the Scroll Keys .............................................................................26 Using the Index System .........................................................................27 Menu Map .............................................................................................28 CALLS Outgoing(MENU 1-1) .....................................................................30 Incoming(MENU 1-2) .....................................................................31 Erase Logs(MENU 1-3) ...................................................................32 Air Time(MENU 1-4) ......................................................................32 PHONE BOOK Find Name(MENU 2-1) ...................................................................33 My Phone Number(MENU 2-2) .......................................................34 Add Entry(MENU 2-3) ....................................................................34 Storing Phone Numbers at Call End .....................................................34 Entering a Name ................................................................................35 Find Entry(MENU 2-4) ....................................................................35 SOUNDS Ring(MENU 3-1) ............................................................................36 Ring Volume ......................................................................................36 Ring Type ...........................................................................................36 Ring Tone ...........................................................................................37 Key Volume(MENU 3-2) .................................................................37 Alert(MENU 3-3) ............................................................................37 Minute Beep.....................................................................................37 Service Area.....................................................................................37 Alarm(MENU 3-4) ..........................................................................37 Differential Ring(MENU 3-5) ..........................................................38 Power On/Off(MENU 3-6) ..............................................................38 Data/Fax(MENU 3-7) ....................................................................38 DISPLAY Backlight(MENU 4-1) .....................................................................39 Greeting(MENU 4-2) ......................................................................39 DISPLAY(Continued...) Version(MENU 4-3) ........................................................................39 Language(MENU 4-4) ....................................................................40 VOICE MEMO Review(MENU 5-1) ....................................................................…

Text truncated - open the document above for the full version.

December 01, 1999 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Frank Coperich / Kwok Chan SUBJECT:Samsung Electronics Co., Ltd. FCC ID: A3LSCH620 731 Confirmation Number: EA95008 Correspondence Reference No.: 10114 Request for Additional Info.: 10/13/99 Amended 10/27/99 (Body-Worn Statement) Dear Frank / Kwok: Please find attached a revision to the amendment previously submitted on October 27, 1999 regarding the warning statement to be placed in the users manual. “For body-worn operation, the phone and antenna should be kept at least 1 inch from the body when transmitting, to comply with FCC RF exposure requirements. An optional holster/belt-clip is available as an accessory. Users are cautioned that the use of non-tested accessories may exceed FCC RF exposure limits. Please contact your local dealer for optional accessory information.” Samsung Electronics Co., Ltd. hereby confirms that the above warning statement will be implemented at a prominent location in the users manual. If you have any further questions regarding this matter, please do not hesitate to contact PCTEST Lab at (301) 596-2120. Sincerely, Ben Kim Engineering Manager Samsung American QA Lab cc:Randy Ortanez President, PCTEST Lab

AFFIDAVIT FOR ESN PROTECTION OF CELLULAR MOBILE TELEPHONES We hereby certify that the Portable Cellular Telephone (FCC ID:A3LSCH620) is so designed that it complies with all the requirements for ESN protection specified in Sec.22.919 of the FCC Rules. a) The transmitter in service has a unique ESN b) The ESN host component is permanently attached to a main circuit board of the mobile transmitter and the integrity of the unit operating software cannot be altered. The ESN is plated from fraudulent contact and tampering. The ESN is encoded using multiplication by a polynomial and the ESN data programmed in the memory with other information. c) The ESN is factory set and cannot be altered, transferred, removed or otherwise able to be manipulated. Cellular mobile equipment is specifically designed such that any attempt to remove, tamper with, or change the ESN chip, its logic system, or firmware originally programmed by the manufacturer will render the mobile transmitter inoperative. Sincerely, Ben Kim Ben Kim Engineering Manager Samsung Electronics America

August 01, 1999 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT:SAMSUNG ELECTRONICS CO., LTD. FCC ID: A3LSCH620 Part 22 Certification Gentlemen: Attached herewith, on behalf of SAMSUNG ELECTRONICS CO., LTD. is an application for Part 22 Certification of the following dual mode cellular phone (AMPS/CDMA): FCC ID:A3LSCH620 TRADE / MODEL(s):SAMSUNG SCH-620 EUT TYPE:Non-Broadcast Transmitter Held to Ear (TNE) Tx Freq. Range:824.04 – 848.97 MHz (AMPS) / 824.64 – 848.37 MHz (CDMA) Rx Freq. Range:869.04 – 893.97 MHz (AMPS) / 869.64 – 893.37 MHz (CDMA) Max. Output Power:0.36 Watts ERP (AMPS) / 0.32 Watts ERP (CDMA) Attached is the applicant’s Letter of Authorization, Confidentiality Request, ESN Affidavit, measurement report data and plots, RF Exposure measurement report, FCC ID label and location, test setup photographs, internal and external photographs, block diagrams (confidential), schematic diagrams & circuit description (confidential), operational description, parts list & tune-up procedure, and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc:Mr. Ben Kim Engineering Manager SAMSUNG Electronics America (QA Lab)

July 23, 1999 Federal Communications Commission Authorization and Evaluation Div. Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concerns: We, the undersigned, hereby authorize PCTEST Engineering Laboratory inc., to act as on our agent in behalf of all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988,21 U.S.C.853(a) Sincerely, Ben Kim Ben Kim Engineering Manager Samsung Electronics America

July 23, 1999 Federal Communications Commission Authorization and Evaluation Div. Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re: Samsung Electronics Co., Ltd. FCC ID: A3LSCH620 Dual-Mode AMPS/CDMA Phone - Certification Request for Confidentiality To whom it may concern: In accordance with 0.459 of CFR 47, Samsung Electronics Co., Ltd. Requests confidentiality for the Block Diagram, Schematics and Circuit Description attachments of the attached test report. These documents contains detailed system and equipment description and related information about the product which Samsung Electronics Co., Ltd. considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Samsung feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Sincerely, Ben Kim Ben Kim Engineering Manager Samsung Electronics America

October 26, 1999 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Frank Coperich / Kwok Chan SUBJECT:Samsung Electronics Co., Ltd. FCC ID: A3LSCH620 731 Confirmation Number: EA95008 Correspondence Reference No.: 10114 Request for Additional Info.: 10/13/99 Dear Frank / Kwok: Submitted herewith, on behalf of Samsung Electronics Co., Ltd., is an amendment in response to your e-mail dated October 13, 1999 requesting additional information for the subject application. 1. Attached is the SAR measurement data and photographs for hands-free body-worn configuration, with the phone placed in the holster designed for use with this phone. Also attached is a letter from the applicant, confirming the warning statement that will be placed in the users manual. We trust this information is sufficient to issue the grant. Should you have any further questions, please do not hesitate to contact us. Thank you. Sincerely, cc:Ben Kim Engineering Manager Samsung American QA Lab

December 06, 1999 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Frank Coperich / Kwok Chan SUBJECT:Samsung Electronics Co., Ltd. FCC ID: A3LSCH620 731 Confirmation Number: EA95008 Dear Frank / Kwok: Submitted herewith, on behalf of Samsung Electronics Co., Ltd., is an amendment for verification of the Body-worn configuration of the Samsung Electronics Co., Ltd. Dual-Mode Cellular phone. The SAR tests were done with the IDX measurement system with a torso phantom. Please note the location of the hot-spot was identical in both systems. Attached are the SAR Test Data Summary Pages, SAR data from the IDX measurement system, and SAR Test Setup Photos. In addition, listed below is the information we received from SPEAG on 12/3/99 stating the conversion factor for the muscle material at 835 MHz, and the appropriate conductivity and permittivity parameters used during the body SAR measurement using the SPEAG probe S/N: 1368. Based on this information, the data derived from the SPEAG system is comparable to the data derived using the IDX system for Body SAR. SN:1368 – brain 900MHz – eps=42.5, sig=0.85, ConvF=5.76 SN:1368 – muscle 900MHz – eps=55.96, sig=0.97, ConvF=5.59 (3% lower than 5.76) SN:1368 – muscle 835MHz – eps=56.2, sig=0.95, ConvF=5.7 (1% lower than 5.76) We trust this information is sufficient to issue the grant. Should you have any further questions, please do not hesitate to contact us. Thank you. Sincerely, cc:Ben Kim, Engineering Manager Samsung American QA Lab

January 06, 2000 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Frank Coperich / Kwok Chan SUBJECT:Samsung Electronics Co., Ltd. FCC ID: A3LSCH620 731 Confirmation Number: EA95008 Correspondence Reference No.: 11002 Request for Tech. Info.: 12/13/99 Dear Frank / Kwok: Submitted herewith, on behalf of Samsung Electronics Co., Ltd., is an amendment in response to your e-mail dated December 13, 1999 requesting additional information for the subject application. 1. Attached is the retest of body-worn SAR data for CDMA mode. Please note that the originally submitted body-worn SAR data for CDMA mode appears to have intermittent antenna connector problem, which was rectified herewith. We trust this information is sufficient to issue the grant. Should you have any further questions, please do not hesitate to contact us. Thank you. Sincerely, cc:Ben Kim Engineering Manager Samsung American QA Lab

Test Report S/N: SAR.990704417.A3L FCC Part 22 Test Date(s): July 26-30, 1999 Certification © 1999 PCTEST Lab FCC ID: A3LSCH620 NVLAP Lab Code: 100431-0 SAMSUNG Electronics Co., Ltd. Test Report S/N: SAR.990704417.A3L FCC Part 22 Test Date(s): July 26-30, 1999 Certification © 1999 PCTEST Lab FCC ID: A3LSCH620 NVLAP Lab Code: 100431-0 SAMSUNG Electronics Co., Ltd. Test Report S/N: SAR.990704417.A3L FCC Part 22 Test Date(s): July 26-30, 1999 Certification © 1999 PCTEST Lab FCC ID: A3LSCH620 NVLAP Lab Code: 100431-0 SAMSUNG Electronics Co., Ltd. Test Report S/N: SAR.990704417.A3L FCC Part 22 Test Date(s): July 26-30, 1999 Certification © 1999 PCTEST Lab FCC ID: A3LSCH620 NVLAP Lab Code: 100431-0 SAMSUNG Electronics Co., Ltd. Test Report S/N: SAR.990704417.A3L FCC Part 22 Test Date(s): July 26-30, 1999 Certification © 1999 PCTEST Lab FCC ID: A3LSCH620 NVLAP Lab Code: 100431-0 SAMSUNG Electronics Co., Ltd. Test Report S/N: SAR.990704417.A3L FCC Part 22 Test Date(s): July 26-30, 1999 Certification © 1999 PCTEST Lab FCC ID: A3LSCH620 NVLAP Lab Code: 100431-0 SAMSUNG Electronics Co., Ltd.

© 1999 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) MODEL NO: SCH-620 FCC ID: A3LSCH620 CANADA: I I MADE IN KOREA 1

Test Report S/N: SAR.990704417.A3L FCC Part 22 Test Date(s): July 26-30, 1999 Certification © 1999 PCTEST Lab FCC ID: A3LSCH620 NVLAP Lab Code: 100431-0 SAMSUNG Electronics Co., Ltd. Test Report S/N: SAR.990704417.A3L FCC Part 22 Test Date(s): July 26-30, 1999 Certification © 1999 PCTEST Lab FCC ID: A3LSCH620 NVLAP Lab Code: 100431-0 SAMSUNG Electronics Co., Ltd. Test Report S/N: SAR.990704417.A3L FCC Part 22 Test Date(s): July 26-30, 1999 Certification © 1999 PCTEST Lab FCC ID: A3LSCH620 NVLAP Lab Code: 100431-0 SAMSUNG Electronics Co., Ltd. Test Report S/N: SAR.990704417.A3L FCC Part 22 Test Date(s): July 26-30, 1999 Certification © 1999 PCTEST Lab FCC ID: A3LSCH620 NVLAP Lab Code: 100431-0 SAMSUNG Electronics Co., Ltd. Test Report S/N: SAR.990704417.A3L FCC Part 22 Test Date(s): July 26-30, 1999 Certification © 1999 PCTEST Lab FCC ID: A3LSCH620 NVLAP Lab Code: 100431-0 SAMSUNG Electronics Co., Ltd. Test Report S/N: SAR.990704417.A3L FCC Part 22 Test Date(s): July 26-30, 1999 Certification © 1999 PCTEST Lab FCC ID: A3LSCH620 NVLAP Lab Code: 100431-0 SAMSUNG Electronics Co., Ltd. Test Report S/N: SAR.990704417.A3L FCC Part 22 Test Date(s): July 26-30, 1999 Certification © 1999 PCTEST Lab FCC ID: A3LSCH620 NVLAP Lab Code: 100431-0 SAMSUNG Electronics Co., Ltd. Test Report S/N: SAR.990704417.A3L FCC Part 22 Test Date(s): July 26-30, 1999 Certification © 1999 PCTEST Lab FCC ID: A3LSCH620 NVLAP Lab Code: 100431-0 SAMSUNG Electronics Co., Ltd. Test Report S/N: SAR.990704417.A3L FCC Part 22 Test Date(s): July 26-30, 1999 Certification © 1999 PCTEST Lab FCC ID: A3LSCH620 NVLAP Lab Code: 100431-0 SAMSUNG Electronics Co., Ltd. Test Report S/N: SAR.990704417.A3L FCC Part 22 Test Date(s): July 26-30, 1999 Certification © 1999 PCTEST Lab FCC ID: A3LSCH620 NVLAP Lab Code: 100431-0 SAMSUNG Electronics Co., Ltd.

1.SPECIFICATION 1.GENERAL FreqencyRang e Transmitter Rece iver CDMAMod e 824.64~848.37 869.64~893.37 AnalogMod e 82 4~84 9 86 9~89 4 Chann elSpacing1.2330 NumberofChann els20FA83 2CHs Dup lexSpacing45 Frequ encyStability300Hz2.5ppm Operati ngTemperature-20 ~+50(-4~+12 2) Operati ngVolt age HHP 3.6VDC(10 %) SizeandWeigh t Includ ingsli mbatt ery Includ ingstand ardbatt ery Includ ingextend ed-life batt ery 10 5x45x18 (slim), 10 5x45x21 (stand ard) 10 5x45x24 (extend ed) 89g 120g 138g Operati ngTime StandbyTime TalkTime 30~ 80hours (wit hstand ardbatt ery) 50~13 0hours (wit hextend ed-li febatt ery) 15 0min (wit hstand ardbatt ery) 24 0min (wit hextend ed-li febatt ery) AnalogMod e 6~7hours (wit hstand ardbatt ery) 15~17hours (wit hextend ed-li febatt ery) about55min (wit hstand ardbatt ery) about16 0min (wit hextend ed-li febatt ery) 2.FMMODE TRANSMITTER RFou tpu tpo wer0.36W CarrierON/OFFconditi on "ON"Conditi on "OFF"Conditi on within3d Bofspec ificationou tpu t(in2ms) below-60dBm(2ms) Compressor CompressionRate AttackTime Rec ov eryTime ReferenceInput 2:1 3 13.5 Inputlevelforproducingano minal2.9pea kfrequ ency deviati onoftransmittedcarrier Prea mph asis6d B/OCTwit hin0. 3~3 MaximumFrequ encyDeviati on F3ofG3 Sup ervisoryAud ioTon e Sign ali ngTon e WidebandData 12 2 8 8 PostDeviati onlimiterFilt er 3. 0~5.9 5. 9~6.1 6. 1~15 Over15 above40 Log (F/3000)dB above35dB above40 Log (F/3000)dB above28dB SpectrumNoiseSurpreion Forallmodulati on f 0 +20 ~f 0 +45 Formodulati onbyvo iceandSAT f 0 +45 Formodulati onbyWBD(wit hout SAT)andST(wit hSAT) f 0 +45 ~f 0 +60 f 0 +60 ~f 0 +90 f 0 +90 ~2f 0 above26dB above63+10 Log (PY)dB above45dB above65dB above63+10 Log (PY)dB (wheref 0 =ca rr ierfr equ ency PY=mea nou tpu tpo werinwatt s) Harmon icandconductSpu riou sEmissionbelow43+10 Log (PY)dB RECEIVER De-Emph asis-6d B/OCTwit hin0. 33 Exp andor Exp andorRate AttackTime Rec ov eryTime ReferenceInput 1:2 within3 within13.5 ou tpu tleveltoa1000ton efr omacarrierwit hin2.9 peakfrequ encydeviati on Sensiti vit y12dBSINAD/-116dBm Intermodulati onSpu riou sResponseAtt enu ati onabove65dB RSSIRang eabove60dB Protec ti onAgainstSpu riou sResponseInterf aceabove60dB InBandConductedSpu riou sEmission TransmitBand Rec eiveBand below-60dBm below-80dBm OutofBandConductedSpu riou sEmissionbelow-47dBm RadiatedSpu riou sEmission Frequ encyRang e 25~70 70~130 13 0~174 17 4~260 26 0~470 47 0~1 MaximumAll owableEIRP -45dBm -41dBm -41~-32dBm -32dBm -32~-26dBm -21dBm 3.CDMAMODE WaveformQualit yabove0.944 TimeReferencewit hin1 RxSensiti vit yand Dyn amicRang e -104dBm, FER=within0.5% -104dBm~-25dBm,FER=wit hin0.5% TxOutpu tPowerMaximum320mW(25dBm) TxFrequ encyDeviati onwit hin300 Occup iedBandWidth1.32 TxConductedSpu riou sEmission900:below-42dBc/30 1.98:below-54dBc/30 MinimumTxPowerCon trolbelow-50dBm OpenLoo pPowerCon trol-25dBm: -57.0dBm~-38.5dBm -65dBm: -17.5dBm~+1.5dBm -104dBm:+18.0dBm~+30.0dBm StandbyOutpu tPowerbelow-61dBm ColsedLoo pTxPowerCon trolRang eTest1:above24dB Test2:0~2.5 Test3:above24dB Test4:above24dB Test5:above24dB 2.FREQUENCYRANGE TransmitterFrequ ency FANO.CHNO.CenterFrequ ency 11011824.64 229825.87 370827.10 4111828.33 5152829.56 6193830.79 7234832.02 8275833.25 9316834.48 10363835.89 11404837.12 12445838.35 13486839.58 14527840.81 15568842.04 16609843.27 17650844.27 18697845.91 19738847.14 20779848.37 ReceiverFrequ ency FANO.CHNO.CenterFrequ ency 11011869.64 229870.87 370872.10 4111873.33 5152874.56 6193875.79 7234877.02 8275878.25 9316879.58 10363880.89 11404882.12 12445883.35 13486884.58 14527885.81 15568887.04 16609888.27 17650889.27 18697890.91 19738892.14 20779893.37

SEC-CODEB'DPARTNODECRIPTIONREMARK 0405-001035D302DIODE-VARACTOR1SV279,15V,3nA,USC,TP 0405-001035D303DIODE-VARACTOR1SV279,15V,3nA,USC,TP 0405-001035D402DIODE-VARACTOR1SV279,15V,3nA,USC,TP 0405-001035D403DIODE-VARACTOR1SV279,15V,3nA,USC,TP 0406-001005ZD206DIODE-TVSSM05,6V/1mA,300,SOT-23 0406-001051ZD101DIODE-TVSSMS05C,6V,300W,SOT-23-6 0406-001051ZD102DIODE-TVSSMS05C,6V,300W,SOT-23-6 0406-001051ZD103DIODE-TVSSMS05C,6V,300W,SOT-23-6 0407-000115D206DIODE-ARRAYDAN202U,80V,100mA,CA2-3,SC-70, 0407-001006D204DIODE-ARRAYDA221,20V,100mA,C2-3,EM3,TR 0407-001006D205DIODE-ARRAYDA221,20V,100mA,C2-3,EM3,TR 0407-001006D401DIODE-ARRAYDA221,20V,100mA,C2-3,EM3,TR 0407-001006ZD104DIODE-ARRAYDA221,20V,100mA,C2-3,EM3,TR 0407-001006ZD201DIODE-ARRAYDA221,20V,100mA,C2-3,EM3,TR 0407-001006ZD202DIODE-ARRAYDA221,20V,100mA,C2-3,EM3,TR 0407-001006ZD203DIODE-ARRAYDA221,20V,100mA,C2-3,EM3,TR 0407-001006ZD205DIODE-ARRAYDA221,20V,100mA,C2-3,EM3,TR 0409-001016D301DIODE-PINBAR63-02W,50V,100mA,SCD-80,TP 0501-000162Q403TR-SMALLSIGNAL2SA1576,PNP,200MW,SOT-323,TP,180-390 0501-000218Q301TR-SMALLSIGNAL2SC4081,NPN,200mW,UMT,TP,180-3 0501-000225Q205TR-SMALLSIGNAL2SC4617,NPN,200mW,EM3,TP,120-5 0501-000225Q207TR-SMALLSIGNAL2SC4617,NPN,200mW,EM3,TP,120-5 0501-000225Q504TR-SMALLSIGNAL2SC4617,NPN,200mW,EM3,TP,120-5 0501-002110Q303TR-SMALLSIGNALAT32033,NPN,200mW,SOT-23,TP,70 0501-002202Q202TR-SMALLSIGNALMMBT2222AWT1,NPN,150mW,SOT-323 0501-002202Q204TR-SMALLSIGNALMMBT2222AWT1,NPN,150mW,SOT-323 0501-002250Q206TR-SMALLSIGNAL2SA1579,PNP,200MW,SC-70,TP,180-390 0504-000167Q402TR-DIGITALRN1102,NPN,100MW,10K/10K,SSM,TP 0504-000168Q101TR-DIGITALRN1104,NPN,100MW,47K/47K,SSM,TP 0504-000168Q208TR-DIGITALRN1104,NPN,100MW,47K/47K,SSM,TP 0504-000168Q304TR-DIGITALRN1104,NPN,100MW,47K/47K,SSM,TP 0504-000168Q502TR-DIGITALRN1104,NPN,100MW,47K/47K,SSM,TP 0504-000172Q201TR-DIGITALRN2104,PNP,100MW,47K/47K,SSM,TP 0504-000172Q404TR-DIGITALRN2104,PNP,100MW,47K/47K,SSM,TP 0504-000172Q501TR-DIGITALRN2104,PNP,100MW,47K/47K,SSM,TP 0505-001165Q203FET-SILICONSI3443DV,P,-20V,+-3.5mA,65mohm 0505-001165Q401FET-SILICONSI3443DV,P,-20V,+-3.5mA,65mohm 0505-001165Q503FET-SILICONSI3443DV,P,-20V,+-3.5mA,65mohm 0505-001183Q302FET-GAASNE34018,5V,-3V,80mA,125mW 0601-001226LED101LEDCHIP,RED,1.2x0.8mm,660nm 0801-002345U202IC-CMOSLOGIC7S04FU,INVERTER,SOP,5P,-,-,TP, 1001-001048U303IC-ANALOGSWITCHSW395TR,SPDP,SOT-26,6P,-,DUAL, 1003-001226U209IC-POWERDRIVERD361A,SOP,8P,120MIL,SINGLE,90MA 1103-001147U105IC-EEPROM24256,256KBIT,SOP,8P,150MIL,-,3V,10% 9.PARTSLIST 1106-001287U110IC-SRAM68U4100,512x8BIT,BGA 1107-001111U111IC-FLASHMEMORY29LV800,512Kx16BIT,BGA,48P,354 1107-001164U112IC-FLASHMEMORY29LV160,2MX8BIT,FBGA,48P,-,90NS,3V,10% 1201-001248U503IC-CASCODEAMP0916,SOT-143,4P,-,-,2.7V,-,6Vd 1201-001259U401IC-POWERAMP23124,LCC,8P,-,SINGLE,-,PLASTI 1201-001348U403IC-OPAMP821,SOT23-5,5P,63MIL,SINGLE,-, 1201-001384U302IC-MMICAMPMD57-0001,SOT-26,6P,114MIL,SIN 1202-001022U201IC-VOLTAGECOMP.75W56,SSOP,8P,110MIL,DUAL,7V,C 1203-001285U208IC-SWITCHVOL.REG.5205,SOT-23,5P,150MIL,PLASTIC, 1203-001285U305IC-SWITCHVOL.REG.5205,SOT-23,5P,150MIL,PLASTIC, 1203-001285U306IC-SWITCHVOL.REG.5205,SOT-23,5P,150MIL,PLASTIC, 1203-001285U407IC-SWITCHVOL.REG.5205,SOT-23,5P,150MIL,PLASTIC, 1203-001511U206IC-RESET809,SOT-23,3P,-,PLASTIC,0.3/6. 1203-001720U210 IC-VOLTAGE REGULATOR 5219,SOT-23,5P,63MIL,PLASTIC,2.91/3.09V 1204-001375U204IC-ENCODER/DECODERST5092TQFPTR,QFP,44P,-,PLASTIC 1204-001504U304IC-IFCIRCUITIFR3000,TQFP,48P,-,PLASTIC,3.5V 1204-001505U406IC-IFCIRCUITIFT3000,TQFP,48P,-,PLASTIC,3.5V 1205-001670U104IC-TRANSCEIVERMSM3000,PBGA,196P,-,PLASTIC,3.5V 1405-001019ZD204VARISTOR5.6V,-,1.6x0.8mm,TP 2007-000029R140R-CHIP0OHM,5%,1/10W,DA,TP,2012 2007-000070R556R-CHIP0ohm,5%,1/16W,DA,TP,1608 2007-000137R218R-CHIP2Kohm,5%,1/16W,DA,TP,1005 2007-000138L430R-CHIP100ohm,5%,1/16W,DA,TP,1005 2007-000138R103R-CHIP100ohm,5%,1/16W,DA,TP,1005 2007-000138R105R-CHIP100ohm,5%,1/16W,DA,TP,1005 2007-000138R107R-CHIP100ohm,5%,1/16W,DA,TP,1005 2007-000138R109R-CHIP100ohm,5%,1/16W,DA,TP,1005 2007-000138R113R-CHIP100ohm,5%,1/16W,DA,TP,1005 2007-000138R144R-CHIP100ohm,5%,1/16W,DA,TP,1005 2007-000138R424R-CHIP100ohm,5%,1/16W,DA,TP,1005 2007-000139R314R-CHIP220ohm,5%,1/16W,DA,TP,1005 2007-000140R112R-CHIP1Kohm,5%,1/16W,DA,TP,1005 2007-000140R121R-CHIP1Kohm,5%,1/16W,DA,TP,1005 2007-000140R128R-CHIP1Kohm,5%,1/16W,DA,TP,1005 2007-000140R129R-CHIP1Kohm,5%,1/16W,DA,TP,1005 2007-000140R137R-CHIP1Kohm,5%,1/16W,DA,TP,1005 2007-000140R160R-CHIP1Kohm,5%,1/16W,DA,TP,1005 2007-000140R203R-CHIP1Kohm,5%,1/16W,DA,TP,1005 2007-000140R207R-CHIP1Kohm,5%,1/16W,DA,TP,1005 2007-000140R212R-CHIP1Kohm,5%,1/16W,DA,TP,1005 2007-000140R217R-CHIP1Kohm,5%,1/16W,DA,TP,1005 2007-000140R227R-CHIP1Kohm,5%,1/16W,DA,TP,1005 2007-000140R232R-CHIP1Kohm,5%,1/16W,DA,TP,1005 2007-000140R248R-CHIP1Kohm,5%,1/16W,DA,TP,1005 2007-000140R253R-CHIP1Kohm,5%,1/16W,DA,TP,1005 2007-000140R301R-CHIP1Kohm,5%,1/16W,DA,TP,1005 2007-000141R503R-CHIP2.2Kohm,5%,1/16W,DA,TP,1005 2007-000142R211R-CHIP2.7Kohm,5%,1/16W,DA,TP,1005 2007-000142R450R-CHIP2.7Kohm,5%,1/16W,DA,TP,1005 2007-000143R101R-CHIP4.7Kohm,5%,1/16W,DA,TP,1005 2007-000143R131R-CHIP4.7Kohm,5%,1/16W,DA,TP,1005 2007-000145R452R-CHIP6.2Kohm,5%,1/16W,DA,TP,1005 2007-000146R143R-CHIP6.8Kohm,5%,1/16W,DA,TP,1005 2007-000146R239R-CHIP6.8Kohm,5%,1/16W,DA,TP,1005 2007-000147R454R-CHIP8.2Kohm,5%,1/16W,DA,TP,1005 2007-000148R110R-CHIP10Kohm,5%,1/16W,DA,TP,1005 2007-000148R119R-CHIP10Kohm,5%,1/16W,DA,TP,1005 2007-000148R123R-CHIP10Kohm,5%,1/16W,DA,TP,1005 2007-000148R127R-CHIP10Kohm,5%,1/16W,DA,TP,1005 2007-000148R139R-CHIP10Kohm,5%,1/16W,DA,TP,1005 2007-000148R171R-CHIP10Kohm,5%,1/16W,DA,TP,1005 2007-000148R175R-CHIP10Kohm,5%,1/16W,DA,TP,1005 2007-000148R224R-CHIP10Kohm,5%,1/16W,DA,TP,1005 2007-000148R453R-CHIP10Kohm,5%,1/16W,DA,TP,1005 2007-000151R136R-CHIP15Kohm,5%,1/16W,DA,TP,1005 2007-000152R130R-CHIP20Kohm,5%,1/16W,DA,TP,1005 2007-000152R407R-CHIP20Kohm,5%,1/16W,DA,TP,1005 2007-000153R102R-CHIP22Kohm,5%,1/16W,DA,TP,1005 2007-000153R133R-CHIP22Ko…

Text truncated - open the document above for the full version.

3.NAMPROGRAMMING NAMfeaturescanbeprog rammedasfoll ows: Notes: -Ifyo uentertheNAMprog rammod e,eachit emsho wsthecurrenlystoreddata.Gotothenextit emby pressingOK. -Youcanmod ifythedatabyenteringanewdata. -Ifyo uenterawron gdigit ,pressCLRtodeletethelastdigit.Pressandho ldCLRtodeletealldigit s. -Toscrollitemsbackwardsorforwards,presstheVOLUMEbu tt onontheleftsideofthephone. Gener alSetup LCDDisplay Keyin Function 47*869#08#9 47*869#08#9 -selectNAMprog ramming NAMprog ram 1 -choose 'GENERAL' 1:General 2:SetupNAM1 ESN Volume- Electron icSerialNumberofthephone B0000000 CAIversion Volume -TheversionofCommonAirInterfacesupported 2 bythemob il e VOC8/13 /EVRC Volume evrc,vo ice08k,vo ice 13k SO_VOIC_EVRC SCM Volume -Stati onClassMarkdisplaysthepo werclass (bit 0~1), 00101010 transmission (bit 2),slott edclass(bit 5),du almod e(bit 6). LockCod e (0000) -Lockcod e,curr entstatusisdisplayed 0000 4-digitcod e tochang e,enternewcod e. OK -storesit SlotMod e -Slotmod e. 'Yes'ind icatestheslotmod e. Yes *or# chang esthestatus. OK -storesit . SlotInd ex -Slotmod eind ex.Thehigh er,thelongersleepingtime 2 0-7 tochang e,enternewon e. OK -storesit . PrefNAM1... -Preferr edsystemselecti onforNAM1 Digit alpref OK chang esthesystem. -storesit . LCDDisplayKeyinFunction PrefNAM2...-PreferredsystemselectionforNAM2 DigitalprefOKchangesthesystem. -storesit. PrefNAM3...-PreferredsystemselectionforNAM3 DigitalprefOKchangesthesystem. -storesit. PrefNAM4...-PreferredsystemselectionforNAM4 DigitalprefOKchangesthesystem. -storesit. SettingUpNAM1 LCDDisplayKeyinFunction NAMProgram2Choose'SetupNAM1.' 1:General 2:SetupNAM1 3:SetupNAM2 4:SetupNAM3 5:SetupNAM4 SetupNAM12Choose'Phone#' 1:Phone# 2.FM 2:CDMA Phone#Phonenumbercurrentlyused. 1234567890phonenumber-tochange,enternewone. OK-storeit. MobileID#MobileIDnumbercurrentlyused. 3003003000mobileIDnumber-tochange,enternewone. OK-storeit. SetupNAM12-Choose'FM' 1:Phone# 2.FM 2:CDMA FMHomeSIDSystemIDforhome,currentstatusisdisplayed. 4369IDnumber-tochange,enternewone. OK-storeit. FM1stChnCurrent1…
