A3LSCH8500Dual-Band Analog/PCS Phone (AMPS/CDMA)

CONFIDENTIAL TableofContents Gettingtoknowyourphone. Displayicons:Whattheytellyou. Battery:Puttinginthepower. Installingyourbattery. Turningyourphoneonandoff. Removingyourbattery. Chargingyourbattery. UsingtheRapidDesktopCharger. Functionkeys:Whattheymakehappen. Phonecalls:Howtomakeandreceivethem. Correctionamisdial. Rememberingyourphonenumber. Answeringcalls. UsingCallerID. RespondingtoCallWaiting. Redialingcalls. SettingupThree-WayCalling. Savingoreditingyourownemergencynumbers. Dialingwhenyourphoneislocked. Voicemail:Theinsandouts. Settingupyourvoicemail. Findingoutyouhaveamessage. Retrievingmessages. UsingspecialSamsungSPRINTPhoneFeatures. Internalphonebook. Understandingyourphone'smemory. Savingandstoringaphonenumber. Enteringahardpause. Dialingfromyourphonebooktoadifferentareacode. Checkingallyourstorednumbers. Findinganumberusingaperson'sname. Erasingaphonenumber. Keepingtrackofyourcalls. Mainmenu: Tailoringyourphone'sfeaturestoyourneeds. Navigatingyourthemenu. CONFIDENTIAL Takingamenushortcut. Understandingmenuitems: Managingyourphone'ssettings. Keepingtrackofcalls. Maintainingyourinternalphonebook. Selectinglanguage Adjustingyourphone'svolume. Determiningwhatisdisplayed. Maintainingphonesecurity. Choosingtherightalerts. Customizingthewayyourphoneworks. Selectingtheservicemode. Preventingaccidentalkeypress. Understandingmessagemenuitems: Listeningtothevoicemailorreadingthemessagesyou'vereceived. ReviewingVoiceMailMessages. ReviewingPageandTextMessages. ErasingMessages. Displayingthetimestamp. Usingguidelines: Allaboutperformanceandsafety. Keepingtabsonsignalstrength. UnderstandingPowerSavemode. Understandinghowyourphoneoperates. Radiofrequencysafety. Maintainingyourphone'speakperformance. Protectingyourbattery. Usingyourphonewhiledriving. Disposalofbatteries. FollowingSafetyGuidelines. Usingyourphonenearotherelectronicdevices. Turnoffyourphonebeforeflying. Restrictingchildren'saccesstoyourphone. Turnoffyourphoneindangerousareas. Cautions. FCCnotice. Tostartconnectingjustpressandhold<END> ThanksforchoosingSamsungSPRINT. CONFIDENTIAL Aswesaid-tostartconnecting,justpressandhold<END>. Gettingtoknowyourphone. 1.RedLight:Illuminateswhen<END>ispressedandheldandwhenyouhaveincomingcallsand messages. 2.Volume:Letsyouadjustthesoundlevel. 3.SEND:Letsyouplaceacall,answerCallWaitingandplaceathreewaycall. 4.ScrollKeys:Allowyoutoscrollthroughthemenuoptionsanddisplays. 5.CLR:Allowsyoutoclearyourlastentry. 6.OK/*:Allowsyoutosavephonenumbers,aswellasanysettingsyouselectinthemenu. 7.END:Letsyoudisconnectacallandreturntostandbymode. Pressandholdthekeytoturnthephoneonandoff. 8.MessageKey:Letsyouaccessyourvoicemailandlistentoyourmessages. 9.MENU:Letsyouaccessthephone'smenus. 10.Antenna:Makesthevoiceontheotherendsoundclearest. Displayicons:Whattheytellyou. Displayiconsareallthesymbolsortextthatshowuponyourdisplayscreen.Inshort,tellyou what'sgoingon.They'reshownbelow. Signal:Measuresyourcurrentsignalstrength.Themorebarsthereare,thestrongerthe signal. InUse:Tellsyouacallisinprogress. NoSvc:ShowsthatyouareoutsideaSPRINTServiceAreaandcannotuseyourphone. Roaming:Iftheiconisnotdisplayed,youareinthe???SPRINTNetwork.Iftheiconis displayed(notflashing),youareinaSPRINTnetworkwithwhich???SPRINThasa roamingagreement.Iftheiconisflashing,youareinanunknownservicearea. Message:Indicateswhenyouhavemessageswaitinginvoicemail. Text:Indicateswhenyouhavetextmessagesorpages. Digital:IndicateswhenyouareinSPRINTservicearea. Battery:Showsthelevelofyourbatterycharge.Themorebarsyousee,themorepoweryou haveleft.Whenthechargeislow,theiconblinksandanalerttoneissounded. Battery:Puttinginthepower. YournewSamsungSPRINTPhonecomeswitharechargeablebatterythatispartiallychargedso CONFIDENTIAL youcanuseitimmediatelyafteryouactivate,withoutanyhassle.Usethebatteryuntilitis completelydrained.Rechargingthebatterywithoutfirstcompletelydrainingordischargingitmay shortenthelifeofthebattery. Installingyourbattery. Toinstallyourbattery,justfollowthesesimplesteps: 1.Holdthebatterywiththelabelracingdown,makingsurethemetalcontactsatthebaseofthe basebatterylineupwiththemetalcontactsonthebaseofthephone. 2.Placeitonthebackofthephonewiththetopofthebatteryaboutaquarterofaninchfrom thelatch. 3.Gentlyslidethebatterytowardthetopofthephoneuntilitclicksintoplace. Turningyourphoneonandoff Whenyou'rereadytoturnonyourSamsungSPRINTPhone,checktoseethatthechargedbattery hasbeeninstalledinthebackofthephoneorthatyouhaveanexternalpowersource(theRapid CigaretteLighterAdapterortheHands-FreeCarKit).Then,Simplypressandhold<END>. Theredlightflashesbrieflyandthebannerisdisplayed,whichmeansyou'rereadytomakeacall. Turningoffthephoneisjustassimple.Pressandhold<END>fortwoseconds.Thedisplaywillbe blankwhenthepowerisoff. Removingyourbattery. 1.First,turnthepowerofftoavoidlosingstorednumbersandmessages. 2.Pressthebatteryreleaselatchonthebackofthephonewhileslidingthebatterydowntoward thebaseofthephone. Chargingyourbattery. Youcantellwhetherornotyourbatteryneedstoberechargedjustbycheckingthelower-right cornerofyourphone'sdisplay,wherethebatterychargeindicatorislocated.Whenthebattery chargelevelislow,thebatteryiconwillblinkandthephonewillsoundatone. Ifyoucontinuetouseyourphonewithoutrechargingandthebatterylevelbecomestoolowitwill turnoffautomatically.Analerttonewillsoundjustbeforethephoneturnsitselfoff.Ifthishappens, unfortunatelyyou'lllosewhateveryouwerejustdoing.So,watchtheindicatorandmakesureyour levelisokay. Tochargeyourbattery,youshouldusetheSamsungSPRINTRapidDesktopCharger,Travel ChargerorRapidCigaretteLighterAdapterfromSamsung. Usingtherapiddesktopcharger. ShouldonlyusetheSamsung-approvedrapiddesktopchargerandACadapterwiththisSamsung SPRINTPhone.Usingthewrongonecouldcausedamage. CONFIDENTIAL 1.PlugoneendoftheACadapterintothechargerandtheotherendintoawalloutlet. 2.Inserteitherthebatterypackaloneorthephonewiththebatterypackinstalledintothecharger slot. Aredlightonthechargerwillletyouknowthebatteryisbeingcharged.Agreenlighttellsyou whenthebatteryisatleast90percentcharged. Ifyourbatter…

Text truncated - open the document above for the full version.

July 23, 1999 Federal Communications Commission Authorization and Evaluation Div. Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concerns: We, the undersigned, hereby authorize PCTEST Engineering Laboratory inc., to act as on our agent in behalf of all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988,21 U.S.C.853(a) Sincerely, Ben Kim Ben Kim Engineering Manager Samsung Electronics America

July 23, 1999 Federal Communications Commission Authorization and Evaluation Div. Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re: Samsung Electronics Co., Ltd. FCC ID: A3LSCH8500 Dual-Band Analog/PCS Phone AMPS/CDMA - Certification Request for Confidentiality To whom it may concern: In accordance with 0.459 of CFR 47, Samsung Electronics Co., Ltd. Requests confidentiality for the Block Diagram, Schematics and Circuit Description attachments of the attached test report. These documents contains detailed system and equipment description and related information about the product which Samsung Electronics Co., Ltd. considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Samsung feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Sincerely, Ben Kim Ben Kim Engineering Manager Samsung Electronics America

AFFIDAVIT FOR ESN PROTECTION OF CELLULAR MOBILE TELEPHONES We hereby certify that the Portable Cellular Telephone (FCC ID:A3LSCH8500) is so designed that it complies with all the requirements for ESN protection specified in Sec.22.919 of the FCC Rules. a) The transmitter in service has a unique ESN b) The ESN host component is permanently attached to a main circuit board of the mobile transmitter and the integrity of the unit operating software cannot be altered. The ESN is plated from fraudulent contact and tampering. The ESN is encoded using multiplication by a polynomial and the ESN data programmed in the memory with other information. c) The ESN is factory set and cannot be altered, transferred, removed or otherwise able to be manipulated. Cellular mobile equipment is specifically designed such that any attempt to remove, tamper with, or change the ESN chip, its logic system, or firmware originally programmed by the manufacturer will render the mobile transmitter inoperative. Sincerely, Ben Kim Ben Kim Engineering Manager Samsung Electronics America

(IA Labof SAMSUNG AMERICA 85 West Tasman Drive San Jose, CA 95134 February 7, 2000 Federal Communications Commission Equipment Approval Services 1435 Oakland Mills Road Columbia, MD 21046 Attn: Errol Chang / Kwok Chan SUBJECT: Samsung Electronics Co., Ltd. FCC ID: ABLSCH8500 731 Confirmation Number: EA95488 Correspondence Reference No.: 11803 Request for Additional Info.: 02/02/2000 Dear Errol / Kwok: Submitted herewith is an amendment in response to your e-mail dated February 2, 2000 requesting additional information for the above dual-band phone. Samsung Electronics Co., Ltd. hereby confirms the following information: 1. 2. 3. If The attached RF exposure warning page will be readily visible and placed at a prominent location in the front section of the users manual. All production units will be tested for conducted power measurements before shipment to ensure that the maximum power does not exceed 25.5 dBm + 0.2 dB tolerance to comply with FCC RF exposure limits. Production units that do not meet this requirement will be readjusted. Attached is the revised Tune-Up Procedure reflecting this change. The only currently available optional accessories for this phone are the belt-clip, ear-microphone, extended and slim batteries, and battery charger. Samsung confirms that any future accessories available for this phonethat may require SAR evaluation will be tested and filed to the FCC prior to marketing. you have any further questions regarding this matter, please do not hesitate to contact PCTEST Lab at (301) 596-2120. Sincer- Ben Kim Engineering Manager Samsung American QA Lab cc: Randy Ortanez President, PCTEST Lab

September 23, 1999 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT:SAMSUNG ELECTRONICS CO., LTD. FCC ID: A3LSCH8500 Part 24/22 Certification Gentlemen: Attached herewith, on behalf of SAMSUNG ELECTRONICS CO., LTD. is an application for Part 24/22 Certification of the following Dual-Band Analog/PCS Phone (AMPS/CDMA): FCC ID:A3LSCH8500 TRADE / MODEL(s):SAMSUNG SCH-8500 EUT TYPE:Licensed Portable Transmitter Held to Ear (PCE) Tx Freq. Range:824.04 – 848.97 MHz (AMPS) 1851.25 – 1908.75 MHz (CDMA) Rx Freq. Range:869.04 – 893.97 MHz (AMPS) 1931.25 – 1988.75 MHz (CDMA) Max. Output Power:0.33 W EIRP / 0.6 W ERP Attached is the Letter of Authorization, Confidentiality Request, ESN Affidavit, measurement report data and plots, RF Exposure measurement report, FCC ID label and location, test setup photographs, internal and external photographs, block diagrams (confidential), schematic diagrams & circuit description (confidential), operational description, parts list & tune-up procedure, and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc:Mr. Ben Kim Engineering Manager, SAMSUNG Electronics QA Lab America.

January 21, 2000 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Errol Chang / Kwok Chan SUBJECT:Samsung Electronics Co., Ltd. FCC ID: A3LSCH8500 731 Confirmation Number: EA95488 Correspondence Reference No.: 11325 Dear Errol / Kwok: Submitted herewith, on behalf of Samsung Electronics Co., Ltd., is an amendment in response to your e- mail dated January 05, 2000 requesting additional information for the subject application. 1. Attached is the remeasured radiated data, SAR test data, and SAR photographs for SCH-8500 phone. 2. Attached are the hand SAR test setup photographs showing phone orientation, antenna position, and glove position. 3. Please see attached letter from Samsung clarifying the optional accessory items available for this phone. 4. Attached is the SAR test setup photo showing the antenna position with respect to the head phantom. 5. Attached are the re-uploaded operational description attachments (2 files – exhibit 12). 6. Attached is the hand SAR measurement data for PCS band and FM band (retest). 7. Attached is the body-worn SAR measurement data, test photographs, and photographs of the optional holster. 8. Attached is the revised tune-up procedure with + 0.5dB tolerance for AMPS mode (25.5dBm + 0.5dB/- 4.0dB). Please also see attached letter from Samsung stating that all production units will be tested for conducted power measurements before shipment to ensure the maximum power does not exceed the tolerance level. 9. Attached is the revised RF exposure warning statement which will be placed towards the front location in the user’s manual (see also attached confirmation letter from Samsung). We trust this information is sufficient to issue the grant asap. If you have any further questions, please do not hesitate to contact us. Thank you. Sincerely, cc:Ben Kim, Engineering Manager Samsung American QA Lab

February 09, 2000 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Errol Chang / Kwok Chan SUBJECT:Samsung Electronics Co., Ltd. FCC ID: A3LSCH8500 731 Confirmation Number: EA95488 Correspondence Reference No.: 11803 Request for Additional Info.: February 02, 2000 Dear Errol / Kwok: Submitted herewith, on behalf of Samsung Electronics Co., Ltd., is an amendment in response to your e- mail dated February 02, 2000 requesting additional information for the subject application. 1. We confirm that the entire peak SAR location is not indicated on the submitted head SAR plots due to the plotting software. The entire peak SAR locations have been considered for 1-gram averaging to determine SAR compliance, and the measurement results or compliance are not affected. 2. For future filings the SAR plots will occupy at least 75% of the page with the entire peak SAR location. 3. We confirm that vehicle-mounted antennas are not applicable for this filing. 4. Attached is the final draft of the user’s manual with RF exposure warning page. 5. Attached is the revised tune-up procedure with + 0.2dB tolerance for AMPS mode (25.5dBm + 0.2dB/- 4.0dB). Please also see attached letter from Samsung stating that all production units will be tested for conducted power measurements before shipment to ensure the maximum power does not exceed the tolerance level. 6. Attached are additional validations to support E-field probe calibration and system accuracy for the muscle tissue parameters in both cellular and PCS bands. We trust this information is sufficient to issue the grant asap. If you have any further questions, please do not hesitate to contact us. Thank you. Sincerely, cc:Ben Kim, Engineering Manager Samsung American QA Lab

Test Report S/N: 24/22.990907534.A3LFCC Parts 24 & 22 Test Date(s): September 09-10 & 13-14, 1999FCC Part 24/22 Certification © 1999 PCTEST Lab FCC ID: A3LSCH8500 (Model: SCH-8500) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Band Analog/PCS Phone (AMPS/CDMA) Test Report S/N: 24/22.990907534.A3LFCC Parts 24 & 22 Test Date(s): September 09-10 & 13-14, 1999FCC Part 24/22 Certification © 1999 PCTEST Lab FCC ID: A3LSCH8500 (Model: SCH-8500) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Band Analog/PCS Phone (AMPS/CDMA) Test Report S/N: 24/22.990907534.A3LFCC Parts 24 & 22 Test Date(s): September 09-10 & 13-14, 1999FCC Part 24/22 Certification © 1999 PCTEST Lab FCC ID: A3LSCH8500 (Model: SCH-8500) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Band Analog/PCS Phone (AMPS/CDMA) Test Report S/N: 24/22.990907534.A3LFCC Parts 24 & 22 Test Date(s): September 09-10 & 13-14, 1999FCC Part 24/22 Certification © 1999 PCTEST Lab FCC ID: A3LSCH8500 (Model: SCH-8500) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Band Analog/PCS Phone (AMPS/CDMA) Test Report S/N: 24/22.990907534.A3LFCC Parts 24 & 22 Test Date(s): September 09-10 & 13-14, 1999FCC Part 24/22 Certification © 1999 PCTEST Lab FCC ID: A3LSCH8500 (Model: SCH-8500) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Band Analog/PCS Phone (AMPS/CDMA) Test Report S/N: 24/22.990907534.A3LFCC Parts 24 & 22 Test Date(s): September 09-10 & 13-14, 1999FCC Part 24/22 Certification © 1999 PCTEST Lab FCC ID: A3LSCH8500 (Model: SCH-8500) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Band Analog/PCS Phone (AMPS/CDMA)

© 1999 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) MODEL NO: SCH-8500 FCC ID: A3LSCH8500 CANADA: I I MADE IN KOREA 1

Test Report S/N: 24/22.990907534.A3LFCC Parts 24 & 22 Test Date(s): September 09-10 & 13-14, 1999FCC Part 24/22 Certification © 1999 PCTEST Lab FCC ID: A3LSCH8500 (Model: SCH-8500) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Band Analog/PCS Phone (AMPS/CDMA) Test Report S/N: 24/22.990907534.A3LFCC Parts 24 & 22 Test Date(s): September 09-10 & 13-14, 1999FCC Part 24/22 Certification © 1999 PCTEST Lab FCC ID: A3LSCH8500 (Model: SCH-8500) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Band Analog/PCS Phone (AMPS/CDMA) Test Report S/N: 24/22.990907534.A3LFCC Parts 24 & 22 Test Date(s): September 09-10 & 13-14, 1999FCC Part 24/22 Certification © 1999 PCTEST Lab FCC ID: A3LSCH8500 (Model: SCH-8500) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Band Analog/PCS Phone (AMPS/CDMA) Test Report S/N: 24/22.990907534.A3LFCC Parts 24 & 22 Test Date(s): September 09-10 & 13-14, 1999FCC Part 24/22 Certification © 1999 PCTEST Lab FCC ID: A3LSCH8500 (Model: SCH-8500) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Band Analog/PCS Phone (AMPS/CDMA) Test Report S/N: 24/22.990907534.A3LFCC Parts 24 & 22 Test Date(s): September 09-10 & 13-14, 1999FCC Part 24/22 Certification © 1999 PCTEST Lab FCC ID: A3LSCH8500 (Model: SCH-8500) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Band Analog/PCS Phone (AMPS/CDMA) Test Report S/N: 24/22.990907534.A3LFCC Parts 24 & 22 Test Date(s): September 09-10 & 13-14, 1999FCC Part 24/22 Certification © 1999 PCTEST Lab FCC ID: A3LSCH8500 (Model: SCH-8500) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Band Analog/PCS Phone (AMPS/CDMA) Test Report S/N: 24/22.990907534.A3LFCC Parts 24 & 22 Test Date(s): September 09-10 & 13-14, 1999FCC Part 24/22 Certification © 1999 PCTEST Lab FCC ID: A3LSCH8500 (Model: SCH-8500) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Band Analog/PCS Phone (AMPS/CDMA) Test Report S/N: 24/22.990907534.A3LFCC Parts 24 & 22 Test Date(s): September 09-10 & 13-14, 1999FCC Part 24/22 Certification © 1999 PCTEST Lab FCC ID: A3LSCH8500 (Model: SCH-8500) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Band Analog/PCS Phone (AMPS/CDMA) Test Report S/N: 24/22.990907534.A3LFCC Parts 24 & 22 Test Date(s): September 09-10 & 13-14, 1999FCC Part 24/22 Certification © 1999 PCTEST Lab FCC ID: A3LSCH8500 (Model: SCH-8500) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Band Analog/PCS Phone (AMPS/CDMA)

CONFIDENTIAL 1.General ITEMPCSAMPS TxFreq.range RxFreq.range ChannelBandwidth ChannelSpacing NumberofChannel DuplexSeparation TypeofEmission In/OutputImpedance TxIntermediateFreq. RxIntermediateFreq. TxLocalFreq. RxLocalFreq TCXOfreq. Freq.Stability OperatingTemperature 1850~1910MHz 1930~1990MHz 1.23MHz 50KHz 1200 80MHz 1M25F9W 50 •ÿ 130.38MHz 210.38MHz 1st(F TX-130.38MHz) 2nd(260.76MHz) 1st(420.76MHz) 2nd(FRX-210.38MHz) 19.68MHz (FRX-80MHz) °æ 150Hz -30 °... ~+60 °... 824~849MHz 869~894MHz 30KHz 30KHz 832 45MHz 40K0F8W,40K0F1D 50 •ÿ 130.38MHz 85.38MHz 1st(F TX+130.38MHz) 2nd(260.76MHz) 1st(170.76MHz) 2nd(FRX+85.38MHz) 19.68MHz °æ 2.5ppm -30 °... ~+60 °... SupplyVoltage SizeandWeight 3.6V Slim :88mmX50mmX23.5mm, 105g, 500mA STD :88mmX50mmX25.7mm, 135g, 1000mA EXT :88mmX50mmX27.5mm, 151g, 1600mA CONFIDENTIAL 1.1.9GHzCDMA(USPCS) 1).General FrequencyRange .Transmitter:1850-1910MHz .Receiver:1930-1990MHz ChannelBandwidth:1.23MHz ChannelSpacing:50kHz NumberofChannels:1200 DuplexSeperation:80MHz TypeofEmission:1M25F9W Input/OutputImpedance:50 ߟ IntermediateFrequency .Transmitter:130.38MHz .Receiver:210.38MHz LocalFrequency .Transmitter:1st(FTX-130.38),2nd(260.76MHz), .Receiver:1st(FRX-210.38MHz),2nd(420.76MHz), TCXOFrequency:19.68MHz FrequencyStability:(FRX-80MHz) °æ 150Hz OperationTemperature:-30 °...°≠ 60 °... SupplyVoltage:+3.6V CONFIDENTIAL 2).Transmitt er WaveformQuality:0.944ormore OpenLoopPowerControlRange .-25dBm :-60.5dBm °≠ -41.5dBm .-65dBm :-20.5dBm °≠ +1.5dBm .-104dBm:+15.0dBm °≠ +30dBm MinimumTxPowerControl:below-50dBm ClosedLoopPowerControlRange: °æ 24dB MaximumRFOutputPower:330mW(+23dBm) OccupiedBandwidth:1.23MHz [email protected]:-42dBc/30kHz 3).Receiver RxSensitivityandDynamicRange:-104dBm,FER=0.5%orless :-25dBm,FER=0.5%orless ConductedSpuriousEmission .1930 °≠ 1990MHz:<-81dBm .1850 °≠ 1910MHz:<-61dBm .AllOtherFrequencies:<-47dBm SingleToneDesensitization:lowerthan1% Rxpower=-101dBm Tonepower=-30dBm Toneoffsetfromcarrier= °æ 1.25MHz IntermodulationSpuriousResponseAttenuation:lowerthan1% Rxpower=-101dBm Tone1power=-43dBm Tone2power=-43dBm Tone1:offsetfromcarrier= °æ 1.25MHz Tone2:offsetfromcarrier= °æ 2.05MHz CONFIDENTIAL 3.800MHzCELLULAR(AMPS) 1).General FrequencyRange .Transmitter:824 °≠ 849MHz .Receiver:869 °≠ 894MHz ChannelSpacing:30kHz NumberofChannels:832 DuplexSpacing:45MHz FrequencyStability: °æ 2.5ppm(-30 °...°≠ 60 °... ,-22 °£ F °≠ 140 °£ F) Modulation/Demodulation .Voice:PM .Data:FM OperatingTemperature:-30 °...°≠ 60 °... ,-22 °£ F °≠ 140 °£ F SupplyVoltate:3.6V 2).Transmitter RFoutputpower:0.6W(+2/-4dB) CarrierON/OFFconditions "ON"Condition:within °æ 3dBofspecificationoutput(in2ms) "OFF"Condition:below-60dBm(in2ms) Compresssor CompressionRate:2:1 AttackTime:3ms RecoveryTime:13.5ms ReferenceInput:inputpowerlevelforproducinganominal °æ 2.9kHz :peakfrequencydeviationoftransmittedcarrier Preamphasis:6dB/OCTwithin0.3 °≠ 3kHz MaximumFrequencyDeviation F3ofG3: °æ 12kHz SupervisoryAudioTone: °æ 2kHz( °æ 10%) SignalingTone: °æ 8kHz( °æ 10%) WidebandData: °æ 8kHz( °æ 10%) CONFIDENTIAL PostDeviationLimiterFilter 3.0 °≠ 5.9kHz:above40LOG(F/3000)dB 5.9 °≠ 6.1kHz:above35dB 6.1 °≠ 15kHz:above40LOG(F/3000)dB Over15kHz:above28dB SpectrumNoiseSuppression Forallmodulation fo+20kHz °≠ fo+45kHz:above26dB FormodulationbyvoiceandSAT fo+45kHz:above63dB+10LOG(PY)dB FormodulationbyWBD(withoutSAT)andST(withSAT) fo+45kHz °≠ fo+60kHz:above45dB fo+60kHz °≠ fo+90kHz:above65dB fo+90kHz °≠ 2fo:above63dB+10LOG(PY)dB (wherefo=carrierfrequency PY=meanoutputpowerinwatts) HarmonicandconductedSpuriousEmissions:below43+10LOG(PY)dB 3).Receiver De-emphasis:-6dB/OCTwithin0.3 °≠ 3kHz Expandor ExpandorRate:1:2 Attacktime:within3ms RecoveryTime:within13.5ms Referenceinput:outputpowerleveltoa1000Hztonefromacarrierwithin °æ 2.9kHz peakfrequencydeviation Sensitivity:12dBSINAD/-116dBm IntermodulationSpuriousResponseAttenuation:above65dB RSSIRange:above60dB ProtectionAgainstSpuriousResponseInterference:above60dB CONFIDENTIAL InBandConductedSpuriousEmission TransmitBand:below-60dBm ReceiveBand:below-80dBm OutofBandConductedSpuriousEmissions:below-47dBm RadiatedSpuriousEmission FrequencyRange:MaximumAllowableEIRP 25 °≠ 70MHz:-45dBm 70 °≠ 130MHz:-41dBm 130 °≠ 174MHz:-41 °≠ -32dBm 174 °≠ 260MHz:-32dBm 260 °≠ 470MHz:-32 °≠ -26dBm 470 °≠ 1GMHz:-21dBm

CONFIDENTIAL 1.General ITEMPCSAMPS TxFreq.range RxFreq.range ChannelBandwidth ChannelSpacing NumberofChannel DuplexSeparation TypeofEmission In/OutputImpedance TxIntermediateFreq. RxIntermediateFreq. TxLocalFreq. RxLocalFreq TCXOfreq. Freq.Stability OperatingTemperature 1850~1910MHz 1930~1990MHz 1.23MHz 50KHz 1200 80MHz 1M25F9W 50 130.38MHz 210.38MHz 1st(F TX-130.38MHz) 2nd(260.76MHz) 1st(420.76MHz) 2nd(FRX-210.38MHz) 19.68MHz (FRX-80MHz)150Hz -30~+60 824~849MHz 869~894MHz 30KHz 30KHz 832 45MHz 40K0F8W,40K0F1D 50 130.38MHz 85.38MHz 1st(F TX+130.38MHz) 2nd(260.76MHz) 1st(170.76MHz) 2nd(FRX+85.38MHz) 19.68MHz +/-2.5ppm -30~+60 SupplyVoltage SizeandWeight 3.6V Slim :88mmX50mmX23.5mm, 105g, 500mA STD :88mmX50mmX25.7mm, 135g, 1000mA EXT :88mmX50mmX27.5mm, 151g, 1600mA CONFIDENTIAL 1.1.9GHzCDMA(USPCS) 1).General FrequencyRange .Transmitter:1850-1910MHz .Receiver :1930-1990MHz ChannelBandwidth:1.23MHz ChannelSpacing: 50kHz NumberofChannels:1200 DuplexSeperation:80MHz TypeofEmission:1M25F9W Input/OutputImpedance:50 IntermediateFrequency .Transmitter:130.38MHz .Receiver :210.38MHz LocalFrequency .Transmitter: 1st(F TX-130.38),2nd(260.76MHz), .Receiver : 1st(F RX-210 .38 MHz),2nd(420.76MHz), TCXOFrequency:19.68MHz FrequencyStability:(FRX-80MHz)150Hz OperationTemperature:-3060 SupplyVoltage:+3.6V CONFIDENTIAL 2).Transmitt er WaveformQuality:0.944ormore OpenLoopPowerControlRange .-25dBm :-60.5dBm -41.5dBm .-65dBm :-20.5dBm +1.5dBm .-104dBm:+15.0dBm +30dBm MinimumTxPowerControl:below-50dBm ClosedLoopPowerControlRange: 24dB MaximumRFOutputPower:330mW(+23dBm) OccupiedBandwidth:1.23MHz [email protected]:-42dBc/30kHz 3).Receiver RxSensitivityandDynamicRange:-104dBm,FER=0.5%orless :-25dBm,FER=0.5%orless ConductedSpuriousEmission .19301990MHz:<-81dBm .18501910MHz:<-61dBm .AllOtherFrequencies:<-47dBm SingleToneDesensitization:lowerthan1% Rxpower=-101dBm Tonepower=-30dBm Toneoffsetfromcarrier= 1.25MHz IntermodulationSpuriousResponseAttenuation:lowerthan1% Rxpower=-101dBm Tone1power=-43dBm Tone2power=-43dBm Tone1:offsetfromcarrier= 1.25MHz Tone2:offsetfromcarrier= 2.05MHz CONFIDENTIAL 3.800MHzCELLULAR(AMPS) 1).General FrequencyRange .Transmitter:824849MHz .Receiver :869894MHz ChannelSpacing:30kHz NumberofChannels:832 DuplexSpacing:45MHz FrequencyStability:+/-2.5ppm Modulation/Demodulation .Voice :PM .Data :FM OperatingTemperature:-3060,-22F140F SupplyVoltate:3.6V 2).Transmitt er RFoutputpower:0.6W(+2/-4dB) CarrierON/OFFconditions "ON"Condition:within3dBofspecificationoutput(in2ms) "OFF"Condition:below-60dBm(in2ms) Compresssor CompressionRate: 2:1 AttackTime : 3ms RecoveryTime :13.5ms ReferenceInput:inputpowerlevelforproducinganominal2.9kHz :peakfrequencydeviationoftransmittedcarrier Preamphasis :6dB/OCTwithin0.33kHz MaximumFrequencyDeviation F3ofG3 :12kHz SupervisoryAudioTone :2kHz(10%) SignalingTone :8kHz(10%) WidebandData :8kHz(10%) CONFIDENTIAL PostDeviationLimiterFilter 3.05.9kHz :above40LOG(F/3000)dB 5.96.1kHz :above35dB 6.115kHz :above40LOG(F/3000)dB Over 15kHz :above28dB SpectrumNoiseSuppression Forallmodulation fo+20kHzfo+45kHz :above26dB FormodulationbyvoiceandSAT fo+45kHz :above63dB+10LOG(PY)dB FormodulationbyWBD(withoutSAT)andST(withSAT) fo+45kHzfo+60kHz :above45dB fo+60kHzfo+90kHz :above65dB fo+90kHz2fo :above63dB+10LOG(PY)dB (wherefo=carrierfrequency PY=meanoutputpowerinwatts) HarmonicandconductedSpuriousEmissions:below43+10LOG(PY)dB 3).Receiver De-emphasis :-6dB/OCTwithin0.33kHz Expandor ExpandorRate :1:2 Attacktime :within3ms RecoveryTime :within13.5ms Referenceinput :outputpowerleveltoa1000Hztonefromacarrierwithin2.9kHz peakfrequencydeviation Sensitivity :12dBSINAD/-116dBm IntermodulationSpuriousResponseAttenuation:above65dB RSSI Range :above60dB ProtectionAgainstSpuriousResponseInterference :above60dB CONFIDENTIAL InBandConductedSpuriousEmission TransmitBand :below -60dBm Receive Band :below -80dBm OutofBandConductedSpuriousEmissions : below-47dBm RadiatedSpuriousEmission FrequencyRange :MaximumAllowableEIRP 2570MHz :-45dBm 70130MHz :-41dBm 130174MHz :-41-32dBm 174260MHz :-32dBm 260470MHz :-32-26dBm 4701GMHz :-21dBm

CONFIDENTIAL NAMfeaturescanbeprogrammedasfollows: LCDDisplay KeyinFunction menu+60,654321-selectsNAMprogramming NAMprogram 1-choose'SetupNAM1' 1:SetupNAM1 2:SetupNAM2 NAM1 Phone#-directorynumber 1234567890Phonenumber-tochange,enternewone. OK -storeit. NAM1 Directory#-directorynumber 1234567890Phonenumber-tochange,enternewone. OK -storeit. NAM1 ActivatePRL-PRLstatus No<or>-toactivatePRL,press<or> OK -storeit. NAM1 AnlgHomeSIDSystemIDforhome,currentststusisdisplayed. 4369IDnumber-tochange,enternewone. OK -storeit. NAM1 DgtlHomeSIDSystemIDforhome,currentststusisdisplayed. 4369IDnumber-tochange,enternewone. OK -storeit. NAM1 MoreProg.?GeneralNAMsetup No<or>-tochange,press<or> OK -storeit CONFIDENTIAL NAMprogram1 Choose'General' 1.General 2.SetupNAM1 3.SetupNAM2 General ESN-ElectronicSerialNumberofthephoneisdisplayed B0000000 OK -Press OK ,toviewnextstatusitem. General CAIversion-CommonAirInterfaceversionisdisplayed 3 OK -Press OK ,toviewnextstatusitem. General VOCSelect SO_VOICE_08K<or>-tochangeVocoderrate,press<or> OK -storeit General SCM-StationClassMarkdisplaysthepowerclass, 01101010transmission,slottedclass,dualmode. OK -Press OK ,toviewnextstatusitem. General ServiceCodeServicecode,currentststusisdisplayed 6543216-digitcode-tochange,enternewcode. OK -storeit General LockCodeLockcode,currentststusisdisplayed 00004-digitcode-tochange,enternewcode. OK -storeit General SlotModeSlotmode.'Yes'indicatestheslotmode. Yes <or>- changesthestatus. OK -storeit. General SlotIndexSlotmodeindex.Thehigher,thelongersleepingtime 2 0-7 -tochange,enternewone. OK -storeit. General RoundupTimerRoundupTimer. No<or>-tochangethestatus. OK -storeit. CONFIDENTIAL NAMprogram3 choose'SetupNAM2' 1.General 2.SetupNAM1 3.SetupNAM2 NAM2Digital IMSI_MCCIMSIMobleCountryCode,currentcodeisdisplayed. 000number-tochange,enternewone. OK -storeit. NAM2Digital IMSI_MNCIMSIMobileNetw…
