A3LSCHA725Tri-Mode Dual-Band Analog/ PCS Phone (AMPS/CDMA)

Samsung Electronics Co Ltd

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Jun 14, 2004
Application Purpose: Original Equipment
Date of Application: Jun 14, 2004
Equipment Note: Tri-Mode Dual-Band Analog/ PCS Phone (AMPS/CDMA)
Frequency Range: 1851.25000000 - 1908.75000000
Company: Samsung Electronics Co Ltd
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

* Some of the contents of this manual may differ from your phone, depending on the software installed or your service provider. World Wide Webhttp://www.samsungmobile.com Printed in China Code No.: GH68-XXXXX English. 05/2004. Rev.1.0 ELECTRONIC S PORTABLE CELLULAR TELEPHONE SCH-A725 User’s Manual Please read this manual before operating your phone, and keep it for future reference. 3 Table of contentsImportant Safety Precautions................................. 6Unpacking .............................................................. 8Your phone ............................................................. 9Phone layout ............................................................. 9Display................................................................... 12Backlight ................................................................ 15Service light............................................................ 15Getting started ..................................................... 16Using the battery..................................................... 16Switching on or off the phone.................................... 21Using the soft keys .................................................. 23Your phone’s modes................................................. 24Call functions........................................................ 26Making a call........................................................... 26Ending a call ........................................................... 27Emergency dialing ................................................... 27Using the recent call logs .......................................... 28Redialing the last number ......................................... 28Making a call from contacts ....................................... 29Prepend dialing ....................................................... 29Speed dialing .......................................................... 30Four-digit dialing ..................................................... 31Pause dialing........................................................... 32Adjusting the volume ............................................... 35Answering a call ...................................................... 35Silencing an incoming call ......................................... 36Rejecting a call........................................................ 36Viewing missed calls ................................................ 37Options during a call ................................................ 37Using caller ID......................................................... 38Call forwarding ........................................................ 38Call waiting............................................................. 39Three-way calling .................................................... 39Entering text ........................................................ 41Changing the text input mode ................................... 42 Table of contents 4 Using the T9 (English) mode ..................................... 43Using the alphabet mode .......................................... 44Using the symbol mode ............................................ 47Using the number mode ........................................... 47Using the menus................................................... 48Accessing a menu function by scrolling ....................... 48Using shortcuts ....................................................... 49List of Menu Functions .............................................. 49Contacts ............................................................... 53Find (Menu 1-1) ....................................................... 53 Add new entry (Menu 1-2) ......................................... 54 Group setting (Menu 1-3) .......................................... 57 My phone # (Menu 1-4) ............................................ 58 Memory (Menu 1-5) .................................................. 58 Calls ..................................................................... 59Outgoing (Menu 2-1) ................................................. 59 Incoming (Menu 2-2) ................................................ 60 Missed (Menu 2-3) .................................................... 60 Erase history (Menu 2-4) ........................................... 61 Air time (Menu 2-5) .................................................. 61 Torpedo SMS......................................................... 62New message (Menu 3-1) .......................................... 62 Inbox (Menu 3-2) ..................................................... 64 Sent (Menu 3-3) ....................................................... 65 Draft (Menu 3-4) ...................................................... 66 Saved (Menu 3-5) ..................................................... 67 Web alert (Menu 3-6) ................................................ 67 Erase messages (Menu 3-7) ....................................... 68 Message setting (Menu 3-8) ....................................... 68 Other functions..................................................... 71Planner (Menu 4-1) ................................................... 71 Display (Menu 4-2) ................................................... 81 Sounds (Menu 4-3) ................................................... 85 Games (Menu 4-4) .................................................... 89 Setup (Menu 4-5) ..................................................... 90 WAP.................................................................... 101About the WAP browser .......................................... 101 Table of contents 5 Get in WAP (Menu 5-1) ............................................ 102 Prompt (Menu 5-2) ................................................. 106 Downloads.......................................................... 107Voice mail........................................................... 109Voice mail (Menu 7-1) ...........................…

Text truncated - open the document above for the full version.

Attestation Statements

June 2, 2004 Federal Communications Commission Authorization and Evaluation Div. Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re: Samsung Electronics Co., Ltd. FCC ID.: A3LSCHA725 Request for Confidentiality To Whom It May Concern: In accordance with 0.459 of CFR 47, Samsung Electronics Co., Ltd. requests confidentiality for the Block Diagram, Schematics, Parts list, Tune-up Procedure, Operational and Circuit Description of the attached test report. These documents contain detailed system and equipment descriptions and related information about the product, which Samsung Electronics Co., Ltd. considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Samsung feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Sincerely, Wallace Oh Engineering Manager Samsun Samsung Electronics America May 25, 2004 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: FCC E911 REQUIREMENTS PER §22.921 Gentlemen: Samsung Electronics Co., Ltd. hereby certifies that the analog cellular telephone (FCC ID: A3LSCHA725), using the Automatic A/B Roaming — Intelligent Retry method, meets the E911 requirements specified in Section 22.921 of the FCC Rules. This procedure recognizes when a “9-1-1” call is made and, at such time, will override any programming in the mobile unit that determines the handling of a non-911 call and permit the call to be handled by other analog carriers. Should you have any questions or comments concerning the above, please contact the undersigned.

External Photos

ID Label/Location Info

Confidential SCH-A725 Dual Band TrippleMode 12,05,2004 Confidential SCH-A725 Dual Band TrippleMode 12,05,2004

Internal Photos

RF Exposure Info

SAMSUNG FCC ID: A3LSCHA725-- 835MHz AMPS Head SAR SAM(900MHz) Phantom; Right Hand Section; Probe:ET3DV6 - SN1735; ConvF(7.00,7.00,7.00) Head 835 MHz: σ = 0.87 mho/m ε r = 40.1 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 1.29 mW/g SAMSUNG Tri-Mode Dual-Band Analog/PCS Phone(AMPS/CDMA) Model: SCH-A725 AMPS Mode, Ch.991 [824.04MHz]; Standard Battery; Meas. Ambient Temp. (°C) - 22.8 Conducted Power=26dBm; Right Head Phantom, Cheek/Touch Position; Meas. Tissue Temp. (°C) - 21.3 Test Date--05/17/2004 [FCC/OET Bulletin 65-Supplement C, July 2001] SAR Tot [mW/g] 1.35E-1 4.04E-1 6.72E-1 9.41E-1 1.21E+0 <SAMSUNG Electronics co.,Ltd> SAMSUNG FCC ID: A3LSCHA725 -- 835MHz AMPS Head SAR SAM(900MHz) Phantom; Right Hand Section; Probe:ET3DV6 - SN1735; ConvF(7.00,7.00,7.00) Head 835 MHz: σ = 0.87 mho/m ε r = 40.1 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.293 mW/g SAMSUNG Tri-Mode Dual-Band Analog/PCS Phone(AMPS/CDMA) Model: SCH-A725 AMPS Mode, Ch.383 [826.49MHz]; Standard Battery; Meas. Ambient Temp. (°C) - 22.8 Conducted Power=26dBm; Right Head Phantom, Ear/Tilt 15 deg Position; Meas. Tissue Temp. (°C) - 21.3 Test Date--05/17/2004 [FCC/OET Bulletin 65-Supplement C, July 2001] SAR Tot [mW/g] 3.26E-2 9.78E-2 1.63E-1 2.28E-1 2.93E-1 <SAMSUNG Electronics co.,Ltd> SAMSUNG FCC ID: A3LSCHA725 -- 835MHz AMPS Head SAR SAM(900MHz) Phantom; Left Hand Section; Probe:ET3DV6 - SN1735; ConvF(7.00,7.00,7.00) Head 835 MHz: σ = 0.87 mho/m ε r = 40.1 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 1.12 mW/g SAMSUNG Tri-Mode Dual-Band Analog/PCS Phone(AMPS/CDMA) Model: SCH-A725 AMPS Mode, Ch.991 [824.04MHz]; Standard Battery; Meas. Ambient Temp. (°C) - 22.8 Conducted Power=26dBm; Left Head Phantom, Cheek/Touch Position; Meas. Tissue Temp. (°C) - 21.3 Test Date--05/17/2004 [FCC/OET Bulletin 65-Supplement C, July 2001] SAR Tot [mW/g] 1.06E-1 3.17E-1 5.27E-1 7.38E-1 9.49E-1 <SAMSUNG Electronics co.,Ltd> SAMSUNG FCC ID: A3LSCHA725 -- 835MHz AMPS Head SAR SAM(900MHz) Phantom; Left Hand Section; Probe:ET3DV6 - SN1735; ConvF(7.00,7.00,7.00) Head 835 MHz: σ = 0.87 mho/m ε r = 40.1 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.244 mW/g SAMSUNG Tri-Mode Dual-Band Analog/PCS Phone(AMPS/CDMA) Model: SCH-A725 AMPS Mode, Ch.383 [826.49MHz]; Standard Battery; Meas. Ambient Temp. (°C) - 22.8 Conducted Power=26dBm; Left Head Phantom, Ear/Tilt 15 deg Position; Meas. Tissue Temp. (°C) - 21.3 Test Date--05/17/2004 [FCC/OET Bulletin 65-Supplement C, July 2001] SAR Tot [mW/g] 2.50E-2 7.50E-2 1.25E-1 1.75E-1 2.25E-1 <SAMSUNG Electronics co.,Ltd> SAMSUNG FCC ID: A3LSCHA725 -- 1900MHz PCS CDMA Head SAR SAM(1800MHz) Phantom; Right Hand Section; Probe:ET3DV6 - SN1735; ConvF(5.60,5.60,5.60) Head 1900 MHz: σ = 1.38 mho/m ε r = 38.5 ρ = 1.00 g/cm 3 ; Antenna Position -- In; Crest Factor 1.0 SAR (1g): 1.32 mW/g SAMSUNG Tri-Mode Dual-Band Analog/PCS Phone(AMPS/CDMA) Model: SCH-A725 PCS Mode, Ch.25 [1851.25MHz]; Standard Battery; Meas. Ambient Temp. (°C) - 22.3 Conducted Power=25dBm; Right Head Phantom, Cheek/Touch Position; Meas. Tissue Temp. (°C) - 21.4 Test Date--05/19/2004 [FCC/OET Bulletin 65-Supplement C, July 2001] SAR Tot [mW/g] 1.34E-1 4.02E-1 6.69E-1 9.37E-1 1.21E+0 <SAMSUNG Electronics co.,Ltd> SAMSUNG FCC ID: A3LSCHA725 -- 1900MHz PCS CDMA Head SAR SAM(1800MHz) Phantom; Right Hand Section; Probe:ET3DV6 - SN1735; ConvF(5.60,5.60,5.60) Head 1900 MHz: σ = 1.38 mho/m ε r = 38.5 ρ = 1.00 g/cm 3 ; Antenna Position -- In; Crest Factor 1.0 SAR (1g): 0.117 mW/g SAMSUNG Tri-Mode Dual-Band Analog/PCS Phone(AMPS/CDMA) Model: SCH-A725 PCS Mode, Ch.600 [1880MHz]; Standard Battery; Meas. Ambient Temp. (°C) - 22.3 Conducted Power=25dBm; Right Head Phantom, Ear/Tilt 15 deg Position; Meas. Tissue Temp. (°C) - 21.4 Test Date--05/19/2004 [FCC/OET Bulletin 65-Supplement C, July 2001] SAR Tot [mW/g] 1.35E-2 4.05E-2 6.75E-2 9.45E-2 1.22E-1 <SAMSUNG Electronics co.,Ltd> SAMSUNG FCC ID: A3LSCHA725 -- 1900MHz PCS CDMA Head SAR SAM(1800MHz) Phantom; Left Cheek(CRP) Section; Probe:ET3DV6 - SN1735; ConvF(5.60,5.60,5.60) Head 1900 MHz: σ = 1.38 mho/m ε r = 38.5 ρ = 1.00 g/cm 3 ; Antenna Position -- In; Crest Factor 1.0 SAR (1g): 0.838 mW/g SAMSUNG Tri-Mode Dual-Band Analog/PCS Phone(AMPS/CDMA) Model: SCH-A725 PCS Mode, Ch.25 [1851.25MHz]; Standard Battery; Meas. Ambient Temp. (°C) - 22.3 Conducted Power=25dBm; Left Head Phantom, Cheek/Touch Position; Meas. Tissue Temp. (°C) - 21.4 Test Date--05/19/2004 [FCC/OET Bulletin 65-Supplement C, July 2001] SAR Tot [mW/g] 9.37E-2 2.81E-1 4.69E-1 6.56E-1 8.43E-1 <SAMSUNG Electronics co.,Ltd> SAMSUNG FCC ID: A3LSCHA725 -- 1900MHz PCS CDMA Head SAR SAM(1800MHz) Phantom; Left Hand Section; Probe:ET3DV6 - SN1735; ConvF(5.60,5.60,5.60) Head 1900 MHz: σ = 1.38 mho/m ε r = 38.5 ρ = 1.00 g/cm 3 ; Antenna Position -- In; Crest Factor 1.0 SAR (1g): 0.134 mW/g SAMSUNG Tri-Mode Dual-Band Analog/PCS Phone(AMPS/CDMA) Model: SCH-A725 PCS Mode, Ch.600 [1880MHz]; Standard Battery; Meas. Ambient Temp. (°C) - 22.3 Conducted Power=25dBm; Left Head Phantom, Ear/Tilt 15 deg Position; Meas. Tissue Temp. (°C) - 21.4 Test Date--05/19/2004 [FCC/OET Bulletin 65-Supplement C, July 2001] SAR Tot [mW/g] 1.38E-2 4.14E-2 6.90E-2 9.66E-2 1.24E-1 <SAMSUNG Electronics co.Ltd> SAMSUNG FCC ID: A3LSCHA725 -- 835MHz AMPS Body SAR SAM(900MHz) Phantom; Flat Section; Probe:ET3DV6 - SN1735; ConvF(6.90,6.90,6.90) Body 835 MHz: σ = 0.95 mho/m ε r = 54.5 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 1.04 mW/g SAMSUNG Tri-Mode Dual-Band Analog/PCS Phone(AMPS/CDMA) Model: SCH-A725 AMPS Mode, Ch.997 [824.04MHz]; Standard Battery; Meas. Ambient Temp. (°C) - 22.8 Conducted Power=26dBm; Spacing=1.5cm from flat phantom to phone, w/o beltclip or holster, Tissue Temp. (°C) - 21.8 Test Date--05/20/2004 [FCC/OET Bulletin 65-Supplement C, July 2001] SAR Tot [mW/g] 1.14E-1 3.41E-1 5.68E-1 7.95E-1 1.02E+0 <SAMSUNG Electronics co.,Ltd> SAMSUNG FCC ID: A3LSCHA725 -- 83…

Text truncated - open the document above for the full version.

RF Exposure Info

835MHz Brain Dipole Validation DUT: Dipole 835 MHz; Serial: 494 Program Name: 835MHz Dipole Validation Procedure Name: 835MHz @ 250mW Procedure Notes: Meas.Tissue Temp(celsius)-21.3;Test Date-15/Jun/2004 Communication System: CW; Frequency: 835 MHz;Duty Cycle: 1:1 Medium parameters used: f = 835 MHz; σ = 0.86 mho/m; ε r = 39.9; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: ET3DV6 - SN1734; ConvF(6.55, 6.55, 6.55); Calibrated: 2004-02-02 - Sensor-Surface: 4mm (Mechanical And Optical Surface Detection) - Electronics: DAE3 Sn486; Calibrated: 2003-11-17 - Phantom: SAM 835/900 MHz; Type: SAM; Serial: TP-1247 - Measurement SW: DASY4, V4.2 Build 44; Postprocessing SW: SEMCAD, V1.8 Build 112 835MHz @ 250mW/Area Scan (61x61x1): Measurement grid: dx=15mm, dy=15mm Reference Value = 57.3 V/m; Power Drift = 0.0 dB Maximum value of SAR (interpolated) = 2.63 mW/g 835MHz @ 250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 57.3 V/m; Power Drift = 0.0 dB Maximum value of SAR (measured) = 2.62 mW/g Peak SAR (extrapolated) = 3.63 W/kg SAR(1 g) = 2.43 mW/g 0 dB = 2.62mW/g

RF Exposure Info

© 2004 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSCHA725 Tri-Mode Dual-Band Analog/ PCS Phone (AMPS/CDMA) © 2004 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSCHA725 Tri-Mode Dual-Band Analog/ PCS Phone (AMPS/CDMA) © 2004 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSCHA725 Tri-Mode Dual-Band Analog/ PCS Phone (AMPS/CDMA) © 2004 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSCHA725 Tri-Mode Dual-Band Analog/ PCS Phone (AMPS/CDMA) © 2004 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSCHA725 Tri-Mode Dual-Band Analog/ PCS Phone (AMPS/CDMA) © 2004 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSCHA725 Tri-Mode Dual-Band Analog/ PCS Phone (AMPS/CDMA) © 2004 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSCHA725 Tri-Mode Dual-Band Analog/ PCS Phone (AMPS/CDMA) © 2004 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSCHA725 Tri-Mode Dual-Band Analog/ PCS Phone (AMPS/CDMA) © 2004 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSCHA725 Tri-Mode Dual-Band Analog/ PCS Phone (AMPS/CDMA) © 2004 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSCHA725 Tri-Mode Dual-Band Analog/ PCS Phone (AMPS/CDMA) © 2004 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSCHA725 Tri-Mode Dual-Band Analog/ PCS Phone (AMPS/CDMA) © 2004 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSCHA725 Tri-Mode Dual-Band Analog/ PCS Phone (AMPS/CDMA)

Test Report

SAMSUNG ELECTRONICS Co., Ltd., Regulatory Compliance Group IT R&D Center 416, Maetan-3Dong, Youngtong-Gu, Suwon-city, Gyeonggi-Do, Korea 442-600 FCC CFR47 PART 22 & 24 SUBPART CERTIFICATION REPORT Model Tested: SCH-A725 FCC ID (Requested): A3LSCHA725 Additional Models: SCH-A726, SCH-A727 SCH-A728, SCH-A729 Report No: FB-024-R1 Job No: FB-024 Date issued: May 24,2004 - Abstract – All measurement reported herein accordance with FCC Rules, 47CFR Part2, Part22, Part24. Prepared By Date EH JUNG – Test Engineer Checked By Date JH CHOI - Engineer Authorized By Date JK CHOI – Senior Manager © Copyright SAMSUNG Electronics 2004 Report Number : FB-024-R1 TABLE OF CONTENT MEASUREMENT REPORT Page 1. FCC Certification Information 3 1.1 2.1033 General Information 3 2. INTRODUCTION 4 2.1 General 4 3. MEASURING INSTRUMENT CALIBRATION 5 4. TEST EQUIPMENT LIST 6 5. DESCRIPTION OF TESTS 7 5.1 Effective Radiated Power/Equivalent Isotropic Radiated Power 7 5.2 Radiated Spurious & Harmonic Emission 8 5.3 Occupied Bandwidth 10 5.4 Spurious and Harmonic Emissions at Antenna Terminal 10 5.4.1 Occupied Bandwidth Emission Limits 10 5.4.2 Conducted Spurious Emission 11 5.5 Frequency Stability / Temperature Variation 12 6. TEST DATA 13 6.1 Effective Radiated Power(E.R.P.) 13 6.2 Equivalent Isotropic Radiated Power(E.I.R.P.) 14 6.3 Cellular CDMA Radiated Spurious & Harmonic Measurement 15 6.4 PCS CDMA Radiated Spurious & Harmonic Measurement 16 6.5 CDMA Radiated Spurious & Harmonic Conversion Table 17 6.6 PCS Radiated Spurious & Harmonic Conversion Table 18 6.7 Frequency Stability 19 6.7.1 CDMA Frequency Stability Table 19 6.7.2 PCS Frequency Stability Table 20 6.7.3 CDMA Frequency Stability Graph 21 6.7.4 PCS Frequency Stability Graph 23 7.SAMPLE CALCULATION 25 7.1 Emission Designator 8. CONCLUSION 26 9. TEST PLOTS 27 Report Number : FB-024-R1 MEASUREMENT REPORT 1. FCC Certification Information The following information is in accordance with FCC Rules, 47CFR Rart2, Subpart J, Sections 2.1033 – 2.1055. 1.1 §2.1033 General Information Applicant Name: SAMSUNG ELECRONICS CO., LTD. Address: 416, Maetan-3Dong, Youngtong-Gu, Suwon City Gyeonggi-Do, KOREA 442-600 Attention: FCC ID: Wallace Oh, Engineering Manager (QA Lab) A3LSCHA725 Quantity: Quantity production is planned Emission Designators: 40K0F8W, 40K0F1D (AMPS), 1M25F9W Tx Freq. Range: 824.04-848.97MHz (AMPS) 824.70-848.31MHz (CDMA) 1851.25-1908.75MHz (PCS CDMA) Rx Freq. Range: 869.04-893.97 MHz (AMPS) 869.70-893.31 MHz (CDMA) 1931.25-1988.75 MHz (PCS CDMA) Max. Power Rating: 24.78 W ERP AMPS (0.301 dBm) 24.11 W ERP CDMA (0.258 dBm) 27.72 W EIRP PCS CDMA (0.592 dBm) FCC Classification(s): Licensed Portable Tx Held to Ear (PCE) Equipment (EUT) Type: Tri-Mode Dual-Band Analog/PCS Phone Modulation(s): AMPS/CDMA Frequency Tolerance: 0.00025% (2.5ppm) FCC Rule Part(s): 24(E), 22(H), 2. Dates of Test: May 12, 21~24,2004 Place of Test: SAMSUNG Lab, Test Report S/N: FB-024-R1 Report Number : FB-024-R1 2. INTRODUCTION 2.1 General These measurement test were conducted at SAMSUNG ELECTRONICS CO., LTD(SUWON). The site address is 416,Maetan-3Dong, Youngtong-Gu, Suwon City, Gyeonggi-Do, KOREA 442- 600 The site have 1 Fully-anechoic chamber and measurement facility. Measurement Procedure The radiated and spurious measurements were made Fully-anechoic chamber at a 3-meter test range (see Figure2). The equipment under testing was placed on a wooden turntable 3-meters from the receive antenna. The receive antenna height and turntable rotations were adjusted for the highest reading on the receive spectrum analyzer. The substitution antenna will replace the EUT antenna it the same position and in vertical polarization. The frequency of the signal generator shall be set to the frequencies that were measured on the EUT. The test antenna shall be raised and lowered, if necessary, to ensure that the maximum signal is still being received. The signal generator, output level, shall be adjusted until an equal or a known related level to what was measured from the EUT is obtained in the spectrum analyzer. This level was recorded. For readings above 1 GHz, the above procedure is repeated using horn antennas and the difference between the gain of the horn and an isotropic antenna are taken into consideration. Figure1. Map of the Suwon City area. Fi gure2. Photograph of 3m Fully-Anechoic Chamber Report Number : FB-024-R1 3.MEASURING INSTRUMENT CALIBRATION The measuring equipment, which was utilized in performing the tests documented herein, has been calibrated in accordance with the manufacturer’s recommendations for utilizing calibration equipment, which is traceable to recognized national standards. - End of page - . . Report Number : FB-024-R1 4. TEST EQUIPMENT LIST Name of Equipment Model Serial No. Due Date ESI26 836119/010 2004-09-15 E4440A(3Hz~26.5GHz) MY41000236 2004-11-07 Spectrum Analyzer E4440A(3Hz~26.5GHz) MY41000233 2004-11-14 SMIQ03B 83824/021 2005-01-15 Signal Generator SMR20 835197/030 2005-01-15 Power Meter E4419B GB41293846 2004-10-02 8481B 3318A10325 2004-10-06 Power Sensor 8485A 3318A19924 2004-10-04 Amplifier 5S1G4 304866 2004-11-17 Pre-Amplifier 8449B 3008A00691 2005-01-16 8960 GB42230535 2004-11-17 Communication test set 8960 GB42360886 2004-11-10 Antenna Master MA0001 ANT0967 Not Required Controller HD100 100/756 Not Required PL-4S 13005454 2004-08-22 SH-241 92000548 2004-12-04 Environmental Chamber SH-241 92000549 2004-12-04 Horn Antenna HF906 360306/011 2005-03-11 Receive Antenna HL040 353255/019 2004-07-14 8494A 3308A31997 2005-01-17 Attenuator 8496A 3308A14426 2005-01-17 4278-311-2 B3679637 2005-01-14 Directional Coupler 4278-111-2 B103DC8722 2005-01-14 WHK1.0/15G-10SS 1 Not Required WHK1.0/15G-10SS 1 Not Required WHK/3.5/18G-10SS 3 Not Required High Pass Filter WHK/3.5/18G-10SS 4 Not Required Shielded Semi-Anechoic Chamber RF0002 ANT0001 Not Required Report Number : FB-024-R1 5. DESCRIPTION OF TESTS 5.1 Effective Radiated Power / Equivalent Isotropic Radiated Power Tes…

Text truncated - open the document above for the full version.

Test Report

PCTEST PT. 22/24 SUPPLEMENT FCC MEASUREMENT SUPPLEMENT Reviewed By: Quality Manager Test Report S/N: 22/24.240601330.A3L Test Dates: June 11, 2004 Phone Type: Tri-Mode Dual-Band FCC ID: A3LSCHA725 Page 1 of 6 © 2004 PCTEST ENGINEERING LABORATORY, INC. 1.1 Test Data 1.2 Effective Radiated Power Output A. POWER: Low (Analog Mode) Freq. Tuned REF. LEVEL POLERPERP (MHz)(dBm)(H/V)(W)(dBm) 824.04-36.550H0.0034.723 836.49-36.650H0.0034.779 848.97-36.850H0.0034.735 B. POWER: High (Analog Mode) Freq. Tuned REF. LEVEL POLERPERPBATTERY (MHz)(dBm)(H/V)(W)(dBm) 824.04-16.550H0.29724.723Standard 836.49-16.650H0.30124.779Standard 848.97-16.850H0.29824.735Standard Note: Standard batteries are options for this phone NOTES: Effective Radiated Power Output Measurements by Substitution Method according to ANSI/TIA/EIA-603-A-2001, Aug. 15, 2001: The EUT was placed on a wooden turn table 3-meters from the receive antenna. The receive antenna height and turntable rotation was adjusted for the highest reading on the receive spectrum analyzer. For CDMA signals, a peak detector is used, with RBW = VBW = 3 MHz. For AMPS, GSM, and NADC TDMA signals, a peak detector is used, with RBW = VBW = 1 MHz. A half-wave dipole was substituted in place of the EUT. This dipole antenna was driven by a signal generator and the level of the signal generator was adjusted to obtain the same receive spectrum analyzer reading. The conducted power at the terminals of the dipole is measured. The ERP is recorded. PCTEST PT. 22/24 SUPPLEMENT FCC MEASUREMENT SUPPLEMENT Reviewed By: Quality Manager Test Report S/N: 22/24.240601330.A3L Test Dates: June 11, 2004 Phone Type: Tri-Mode Dual-Band FCC ID: A3LSCHA725 Page 2 of 6 © 2004 PCTEST ENGINEERING LABORATORY, INC. 2.1 Test Data 2.2 AMPS Radiated Measurements Field Strength of SPURIOUS Radiation OPERATING FREQUENCY: 824.04MHz CHANNEL: 0991 (Low) MEASURED OUTPUT POWER: 24.779 dBm =0.301W MODULATION SIGNAL: FM (Internal) DISTANCE: 3meters LIMIT: 43 + 10 log 10 (W) = 37.78 dBc FREQ. LEVEL @ ANTENNA SUBSTITUTE ANTENNA CORRECT GENERATOR POL (MHz)TERMINALS (dBm) GAIN (dBd) LEVEL (dBm) (H/V) 1648.08-35.586.10-29.48H 2472.12-34.486.70-27.78H 3296.16-30.286.80-23.48H 4120.20-38.686.50-32.18H 4944.24-55.487.00-48.48H NOTES: 73.3 57.0 48.3 52.6 54.3 (dBc) Radiated Spurious Emission Measurements by Substitution Method according to ANSI/TIA/EIA-603-A-2001, Aug. 15, 2001: The EUT was placed on a wooden turn table 3-meters from the receive antenna. The receive antenna height and turntable rotation was adjusted for the highest reading on the receive spectrum analyzer. For CDMA signals, a peak detector is used, with RBW = VBW = 3 MHz. For AMPS, GSM, and NADC TDMA signals, a peak detector is used, with RBW = VBW = 1 MHz. A half-wave dipole was substituted in place of the EUT. This dipole antenna was driven by a signal generator and the level of the signal generator was adjusted to obtain the same receive spectrum analyzer reading. This spurious level is recorded. For readings above 1GHz, the above procedure is repeated using horn antennas and the difference between the gain of the horn and an isotropic or dipole antenna are taken into consideration. PCTEST PT. 22/24 SUPPLEMENT FCC MEASUREMENT SUPPLEMENT Reviewed By: Quality Manager Test Report S/N: 22/24.240601330.A3L Test Dates: June 11, 2004 Phone Type: Tri-Mode Dual-Band FCC ID: A3LSCHA725 Page 3 of 6 © 2004 PCTEST ENGINEERING LABORATORY, INC. 2.1 Test Data (Continued) 2.3 AMPS Radiated Measurements Field Strength of SPURIOUS Radiation OPERATING FREQUENCY: 836.49MHz CHANNEL: 0383 (Mid) MEASURED OUTPUT POWER: 24.779 dBm =0.301W MODULATION SIGNAL: FM (Internal) DISTANCE: 3meters LIMIT: 43 + 10 log 10 (W) = 37.78 dBc FREQ. LEVEL @ ANTENNA SUBSTITUTE ANTENNA CORRECT GENERATOR POL (MHz)TERMINALS (dBm) GAIN (dBd) LEVEL (dBm) (H/V) 1672.98-29.186.10-23.08H 2509.47-39.186.70-32.48H 3345.96-30.786.80-23.98H 4182.45-43.386.50-36.88H 5018.94-59.187.00-52.18H NOTES: 77.0 61.7 48.8 57.3 47.9 (dBc) Radiated Spurious Emission Measurements by Substitution Method according to ANSI/TIA/EIA-603-A-2001, Aug. 15, 2001: The EUT was placed on a wooden turn table 3-meters from the receive antenna. The receive antenna height and turntable rotation was adjusted for the highest reading on the receive spectrum analyzer. For CDMA signals, a peak detector is used, with RBW = VBW = 3 MHz. For AMPS, GSM, and NADC TDMA signals, a peak detector is used, with RBW = VBW = 1 MHz. A half-wave dipole was substituted in place of the EUT. This dipole antenna was driven by a signal generator and the level of the signal generator was adjusted to obtain the same receive spectrum analyzer reading. This spurious level is recorded. For readings above 1GHz, the above procedure is repeated using horn antennas and the difference between the gain of the horn and an isotropic or dipole antenna are taken into consideration. PCTEST PT. 22/24 SUPPLEMENT FCC MEASUREMENT SUPPLEMENT Reviewed By: Quality Manager Test Report S/N: 22/24.240601330.A3L Test Dates: June 11, 2004 Phone Type: Tri-Mode Dual-Band FCC ID: A3LSCHA725 Page 4 of 6 © 2004 PCTEST ENGINEERING LABORATORY, INC. 2.1 Test Data (Continued) 2.4 AMPS Radiated Measurements Field Strength of SPURIOUS Radiation OPERATING FREQUENCY: 848.97MHz CHANNEL: 0799 (High) MEASURED OUTPUT POWER: 24.779 dBm =0.301W MODULATION SIGNAL: FM (Internal) DISTANCE: 3meters LIMIT: 43 + 10 log 10 (W) = 37.78 dBc FREQ. LEVEL @ ANTENNA SUBSTITUTE ANTENNA CORRECT GENERATOR POL (MHz)TERMINALS (dBm) GAIN (dBd) LEVEL (dBm) (H/V) 1697.94-28.386.10-22.28H 2546.91-37.386.70-30.68H 3395.88-32.186.80-25.38H 4244.85-49.186.50-42.68H 5093.82-55.687.00-48.68H NOTES: 73.5 67.5 50.2 55.5 47.1 (dBc) Radiated Spurious Emission Measurements by Substitution Method according to ANSI/TIA/EIA-603-A-2001, Aug. 15, 2001: The EUT was placed on a wooden turn table 3-meters from the receive antenna. The receive antenna height and turntable rotation was adjusted for the highest reading on the receive sp…

Text truncated - open the document above for the full version.

Test Setup Photos

Text truncated - open the document above for the full version.

Contact Information

Applicant

Jenni Chun(General Manager)

[email protected]973-808-6375Fax: 973-808-6361

Technical Contact

PCTEST Engineering Lab., Inc.Randy Ortanez

[email protected]410-290-6652

6660-B Dobbin Road · Columbia, Maryland · United States

Test Firm

SAMSUNG ELECTRONICS CO., LTD.No Cheon Park

[email protected]82-31-200-2185Fax: 82-31-200-2189
