A3LSCHA850Dual-Band CDMA Phone

DIGITAL CELLULAR TELEPHONE SCH-A850 User’s Manual Printed in Korea Code No. : GH68-00000A English. 2005/03. Rev.1.0 World Wide Web http://www.samsungmobile.com ELECTRONICS Please read this manual before operating your phone, and keep it for future reference . Safety Quick Guide Read these guidelines before using your wireless phone. Failure to comply with these guidelines may be dangerous or illegal. For more detailed safety information, see “Health and Safety Information” on page 89. Road safety comes first Do not use a hand-held phone while driving; park the vehicle first. Switch off when refuelling Do not use the phone at a refuelling point (service station) or near fuels or chemicals. Switch off on aircraft Wireless phones can cause interference. Using them on aircraft is both illegal and dangerous. Switch off in hospital Switch off your phone near medical equipment. Follow any regulations or rules in force. Interference All wireless phones may get interference which could affect performance. Respect special regulations Follow any special regulations in force in any area and always switch off your phone whenever it is forbidden to use it, or when it may cause interference or danger (in a hospital for example). 1 YOUR PHONE Key Descriptions ................................................................................... 5 Display ................................................................................................ 6 Service light .......................................................................................... 8 Unpacking ............................................................................................. 8 GETTING STARTED Charging a Battery .................................................................................9 Low Battery Indicator ..........................................................................10 Switching the Phone On/Off ................................................................ 11 CALL FUNCTIONS Making a Call ......................................................................................12 Answering a Call .................................................................................. 18 In-Use Options .................................................................................... 19 Using Caller ID .................................................................................... 20 Viewing Missed Calls ........................................................................... 21 Three-Way Calling ............................................................................... 22 Call Waiting ........................................................................................ 23 Call Forwarding ....................................................................................23 Adjusting the Volume ........................................................................... 24 Quick Switching to Vibration Mode ....................................................... 24 ENTERING TEXT Changing Text Input Mode ................................................................... 25 T9 Mode .............................................................................................. 26 Alpha Mode ..........................................................................................27 Symbol Mode ...................................................................................... 29 Number Mode ..................................................................................... 29 Table of Contents Radio frequency exposure information In August 1996, the Federal Communications Commisision (FCC) of the U.S. adopted an updated safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated transmitters. The design of this phone complies with the FCC guidelines and those standards. To maintain compliance with FCC RF exposure guidelines, if you wear a handset on your body, use the Samsung-supplied or approved carrying case, holster, or other body-worn accessory. If you do not use a body-worn accessory, ensure the antenna is at least one inch (2.5cm) from your body when transmitting. Use of non-approved accessories may violate FCC RF exposure guidelines. Use sensibly Use only in the normal position (to ear). Avoid unnessary contact with the antenna when the phone is switched on. Accessories and batteries Use only SAMSUNG-approved accessories and batteries. Use qualified service Only qualified service personnel may install or repair your phone. 23 USING THE MENUS Accessing a Menu Functions by Scrolling .............................................. 30 Accessing a Menu Functions by Using its Shortcut.................................. 31 Your Phone’s Main Menu .................................................................... 32 GET IT NOW Get Tunes & Tones (MENU1-1)..................................................... 34 Get Fun & Games (MENU1-2)..................................................... 34 Get Pix & Flix (MENU1-3)............................................................ 34 Get News & Info (MENU1-4)........................................................ 34 Get Going (MENU1-5)................................................................. 34 MESSAGING New Text Msg (MENU 2-1)............................................................ 35 New Pix/Flix Msg (MENU 2-2)..................................................... 36 New Hnad. Msg (MENU 2-3)........................................................ 36 Inbox (MENU 2-4)........................................................................ 36 Sent (MENU2-5).......................................................................... 37 Drafts (MENU2-6)....................................................................... 37 Voicemail (MENU 2-7).................................................................. 37 E-Mail (MENU2-8)....................................................................... 38 C…

Text truncated - open the document above for the full version.















































May 13, 2005        !"# $%&' ( &) "*   +,-   . / (0+1+//2(34 (5 /5 ///5 /4(0+1+// 2( 34(5555,4  .(5(65(5 / (5 1 # )57/(5)8 )94144 *4    1    1: ;&/ 1&19<;3<4




















































May 13, 2005
!
 ""
 ""
#$%"
 &
'
()
*+  !

, !
 "-

)


 .
/01
#
 23!

.
A3LSCHA850 , $
5
 5!

1  " .


 !
6
2)
5
 ,
)(
/01
#
 2
3!
  -
 $

 5!
5

' +
7"

7"
8
3
and Operational
 %
"
5

-9
%%  2

:
! "

!  !
  "
 !
$%"
! %
 !
  !
 5 "

-

% !
6
/01
#
 2
3!
 !
-  7
% %

 5!
 !

  "
! 7
 !
 6
6  !




7
%- 2




! 7


-
5 "
6
5
  7
% !
6

/01

#
 2
3!
 !


 5 "
6  !
-
5
- 5


 "%
 !


!
5

 5 "


! "
6  !
7
 "%

 5
! 7


"+ 2







;"
<
"
=
3-
/01
#
"
0





















































































May 13, 2005

!
 ""
 ""
 #
 !
$
%
$&'"
 #
(
)*
+,  !

- !
 ".

*



 /
012
$
 %
3!%
FCC ID: A3LSCHA850 - &
5
 67 "
 5!


7
8 "


   /


 !
9
%*)
 !
%*
5
 -
*)
012
$
 %
3!%
 &
 6  "
 5!
5


'
'
:
'

'
 !
 ;
"
5

 !

 ' %

7
! "

!  !
  "
 !
&'"
! '
 !
  !
 5 "
.

' !
9
012
$
 %3!

 !

.
' '
 5!
 !

  "
! <
 !
 9
9  !




<
'. %


! <


.
5 "
9
5
  <
' !
9

012
$
 %
3!
5


 5 "
9  !
.
5
. 5


 "'
 !


!
5

 5 "


! "
9  !
<

 "'

 5
! <


", %






="
>
"
?
3.
012
$
"
1%

June 1, 2005 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: SAMSUNG ELECTRONICS CO., LTD. FCC ID: A3LSCHA850 Part 22/24 Certification Gentlemen: Submitted herewith, on behalf of SAMSUNG ELECTRONICS CO., LTD., is an application for Part 22/24 Certification of the Dual-Band CDMA Phone. Attached is the applicant’s Letter of Authorization, Confidentiality Request, measurement report test data and plots, RF Exposure measurement report and data, FCC ID label and location, test setup photographs, internal and external photographs, block diagram (confidential), circuit diagrams & description (confidential), operational description (confidential), parts list & tune-up procedure (confidential), and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: SAMSUNG ELECTRONICS CO., LTD.

SAMSUNG FCC ID: A3LSCHA850 EUT Photographs © 2005 PCTEST Lab. Dual-Band CDMA Phone Model: SCH-A850 SAMSUNG FCC ID: A3LSCHA850 EUT Photographs © 2005 PCTEST Lab. Dual-Band CDMA Phone Model: SCH-A850 SAMSUNG FCC ID: A3LSCHA850 EUT Photographs © 2005 PCTEST Lab. Dual-Band CDMA Phone Model: SCH-A850 SAMSUNG FCC ID: A3LSCHA850 EUT Photographs © 2005 PCTEST Lab. Dual-Band CDMA Phone Model: SCH-A850 SAMSUNG FCC ID: A3LSCHA850 EUT Photographs © 2005 PCTEST Lab. Dual-Band CDMA Phone Model: SCH-A850 SAMSUNG FCC ID: A3LSCHA850 EUT Photographs © 2005 PCTEST Lab. Dual-Band CDMA Phone Model: SCH-A850 SAMSUNG FCC ID: A3LSCHA850 EUT Photographs © 2005 PCTEST Lab. Dual-Band CDMA Phone Model: SCH-A850

3. FCC ID Label Location

SAMSUNG FCC ID: A3LSCHA850 EUT Photographs © 2005 PCTEST Lab. Dual-Band CDMA Phone Model: SCH-A850 SAMSUNG FCC ID: A3LSCHA850 EUT Photographs © 2005 PCTEST Lab. Dual-Band CDMA Phone Model: SCH-A850 SAMSUNG FCC ID: A3LSCHA850 EUT Photographs © 2005 PCTEST Lab. Dual-Band CDMA Phone Model: SCH-A850 SAMSUNG FCC ID: A3LSCHA850 EUT Photographs © 2005 PCTEST Lab. Dual-Band CDMA Phone Model: SCH-A850 SAMSUNG FCC ID: A3LSCHA850 EUT Photographs © 2005 PCTEST Lab. Dual-Band CDMA Phone Model: SCH-A850 SAMSUNG FCC ID: A3LSCHA850 EUT Photographs © 2005 PCTEST Lab. Dual-Band CDMA Phone Model: SCH-A850 SAMSUNG FCC ID: A3LSCHA850 EUT Photographs © 2005 PCTEST Lab. Dual-Band CDMA Phone Model: SCH-A850 SAMSUNG FCC ID: A3LSCHA850 EUT Photographs © 2005 PCTEST Lab. Dual-Band CDMA Phone Model: SCH-A850 SAMSUNG FCC ID: A3LSCHA850 EUT Photographs © 2005 PCTEST Lab. Dual-Band CDMA Phone Model: SCH-A850 SAMSUNG FCC ID: A3LSCHA850 EUT Photographs © 2005 PCTEST Lab. Dual-Band CDMA Phone Model: SCH-A850

PCTEST ENGINEERING LABORATORY, INC. 6660 – B Dobbin Road • Columbia, MD 21045 • USA Telephone 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com (email: [email protected]) CERTIFICATE OF COMPLIANCE (SAR EVALUATION) PCTEST SAR REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: 0504010235 Test Dates: April 27, 2005 Phone Type: Dual-Band CDMA Phone FCC ID: A3LSCHA850 Page 1 of 30 © 2005 PCTEST Engineering Laboratory, Inc APPLICANT NAME & ADDRESS: DATE & LOCATION OF TESTING: SAMSUNG ELECTRONICS CO., LTD. Dates of Tests: April 27, 2005 3351 Michelson Drive, Suite 290 Test Report S/N: 0504010235 Irvine, CA 92612 Test Site: PCTEST Lab, Columbia MD FCC ID: A3LSCHA850 APPLICANT: SAMSUNG ELECTRONICS CO., LTD. EUT Type: Dual-Band CDMA Phone Tx Frequency: 824.70 – 848.31 MHz (CDMA)/1851.25 – 1908.75 MHz (PCS CDMA) Rx Frequency: 869.70 – 893.31 MHz (CDMA)/ 1931.25 – 1988.75 MHz (PCS CDMA) Max. RF Output Power: 0.334 W ERP CDMA (25.23 dBm) / 24.5 dBm Conducted 0.376 W EIRP PCS CDMA (25.7 dBm) / 24.5 dBm Conducted Max. SAR Measurement: 1.45 W/kg CDMA Head SAR; 1.02 W/kg CDMA Body SAR; 1.43 W/kg PCS CDMA Head SAR; 0.92 W/kg PCS CDMA Body SAR Trade Name/Model(s): SCH-A850 FCC Classification: Licensed Portable Transmitter Held to Ear (PCE) FCC Rule Part(s): §2.1093; FCC/OET Bulletin 65 Supplement C [July 2001] Application Type: Certification Test Device Serial No.: identical prototype [S/N: # FCC1] This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. 1528 - 2003. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant Conditions: Power output listed is ERP for Part 22 and EIRP for Part 24. SAR compliance for body-worn operating configuration is limited to the specific holster/belt clip tested for this filing. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST SAR REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: 0504010235 Test Dates: April 27, 2005 Phone Type: Dual-Band CDMA Phone FCC ID: A3LSCHA850 Page 2 of 30 © 2005 PCTEST Engineering Laboratory, Inc TABLE OF CONTENTS 1. INTRODUCTION / SAR DEFINITION.................................................................................3 2. SAR MEASUREMENT SETUP.............................................................................................4 3. DASY4 E-FIELD PROBE SYSTEM........................................................................................5 4. PROBE CALIBRATION PROCESS.......................................................................................6 5. PHANTOM & EQUIVALENT TISSUES................................................................................7 6. TEST SYSTEM SPECIFICATIONS.........................................................................................8 7. DOSIMETRIC ASSESSMENT & PHANTOM SPECS...............................................................9 8. DEFINITION OF REFERENCE POINTS..............................................................................10 9. TEST CONFIGURATION POSITIONS...............................................................................11 10. ANSI/IEEE C95.1 - 1992 RF EXPOSURE LIMITS.................................................................14 11. MEASUREMENT UNCERTAINTIES...................................................................................15 12. SYSTEM VERIFICATION..................................................................................................16 13. SAR TEST DATA SUMMARY.......................................................................................17-32 15. SAR TEST EQUIPMENT..........................................................................................33 16. CONCLUSION...............................................................................................................29 17. REFERENCES..................................................................................................................30 PCTEST SAR REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: 0504010235 Test Dates: April 27, 2005 Phone Type: Dual-Band CDMA Phone FCC ID: A3LSCHA850 Page 3 of 30 © 2005 PCTEST Engineering Laboratory, Inc 1. INTRODUCTION / SAR DEFINITION The FCC has adopted the guidelines for evaluating the environmental effects of radiofrequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. (c) 1992 by the Institute of Electrical and Electronics Engineers, Inc., New York, New York 10017.[2] The measurement procedure described in IEEE/ANSI C95.3-1992 Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields - RF and Microwave[3] is used for guidance in measuring SAR due to the RF radiation exposure from the Equipment Under Test (EUT). These criteria for SAR evaluation are similar to those recomm…

Text truncated - open the document above for the full version.

PCTEST PT. 22/24 REPORT FCC MEASUREMENT REPORT Reviewed By: Quality Manager Test Report S/N: 0504010234 Test Dates: April 11-12, 2005 Phone Type: Dual-Band CDMA FCC ID: A3LSCHA850 Page 1 of 24 © 2005 PCTEST ENGINEERING LABORATORY, INC. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE FCC Part 24 & 22 Certification SAMSUNG ELECTRONICS CO., LTD. Dates of Tests: April 11-12, 2005 3351 Michelson Drive, Suite 290 Test Report S/N: 0504010234 Irvine, CA 92612 Test Site: PCTEST Lab, Columbia MD FCC ID A3LSCHA850 APPLICANT SAMSUNG ELECTRONICS CO., LTD. Classification: Licensed Portable Transmitter Held to Ear (PCE) FCC Rule Part(s): §24(E), §22(H); §2 EUT Type: Dual-Band CDMA Phone Model: SCH-A850 Tx Frequency Range: 824.70 – 848.31MHz (CDMA) / 1851.25MHz – 1908.75MHz (PCS CDMA) Rx Frequency Range: 869.70 – 893.31MHz (CDMA) / 1931.25MHz – 1988.75MHz (PCS CDMA) Max. RF Output Power: 0.334 W ERP CDMA (25.233 dBm) / 24.5 dBm Conducted 0.376 W EIRP PCS CDMA (25.751 dBm) / 24.5 dBm Conducted Max. SAR Measurement: 1.45 W/kg CDMA Head SAR; 1.02 W/kg CDMA Body SAR; 1.43 W/kg PCS CDMA Head SAR; 0.92 W/kg PCS CDMA Body SAR Emission Designator(s): 1M25F9W (CDMA) Test Device Serial No. Identical Prototype [S/N: # FCC1] This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in §2.947. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant Conditions: Power output listed is ERP for Part 22 and EIRP for Part 24 SAR compliance for body- worn operating configuration is based on a separation distance of 1.5 cm between the back of the unit and the body of the user. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST PT. 22/24 REPORT FCC MEASUREMENT REPORT Reviewed By: Quality Manager Test Report S/N: 0504010234 Test Dates: April 11-12, 2005 Phone Type: Dual-Band CDMA FCC ID: A3LSCHA850 Page 2 of 24 © 2005 PCTEST ENGINEERING LABORATORY, INC. TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: TEST REPORT ATTACHMENT C: ATTESTATION STATEMENT(S) 1.1 SCOPE 3 2.1 INTRODUCTION 4 3.1 DESCRIPTION OF TESTS 5-8 4.1 EFFECTIVE RADIATED POWER OUTPUT 9 5.1 EQUIVALENT ISOTROPIC RADIATED POWER 10 6.1 RADIATED MEASUREMENTS 11-16 7.1 FREQUENCY STABILITY 17-20 8.1 PLOTS OF EMISSIONS 21 9.1 LIST OF TEST EQUIPMENT 22 10.1 SAMPLE CALCULATIONS 23 11.1 CONCLUSION 24 ATTACHMENT D: TEST PLOTS ATTACHMENT E: TEST SETUP PHOTOGRAPHS ATTACHMENT F: EXTERNAL PHOTOGRAPHS ATTACHMENT G: INTERNAL PHOTOGRAPHS ATTACHMENT H: SAR MEASUREMENT REPORT ATTACHMENT I: SAR TEST DATA ATTACHMENT J: SAR TEST SETUP PHOTOGRAPHS ATTACHMENT K: DIPOLE VALIDATION ATTACHMENT L: PROBE CALIBRATION ATTACHMENT M: COPY OF GRANT PCTEST PT. 22/24 REPORT FCC MEASUREMENT REPORT Reviewed By: Quality Manager Test Report S/N: 0504010234 Test Dates: April 11-12, 2005 Phone Type: Dual-Band CDMA FCC ID: A3LSCHA850 Page 3 of 24 © 2005 PCTEST ENGINEERING LABORATORY, INC. MEASUREMENT REPORT 1.1 Scope Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. §2.1033 General Information Applicant Name: SAMSUNG ELECTRONICS CO., LTD. Address: 3351 Michelson Drive, Suite 290 Irvine, CA 92612 • FCC ID: A3LSCHA850 • Quantity: Quantity production is planned • Emission Designators: 1M25F9W • Tx Freq. Range: 824.70 – 848.31 MHz (CDMA) 1851.25 – 1908.75 MHz (PCS CDMA) • Rx Freq. Range: 869.70 – 893.31 MHz (CDMA) 1931.25 – 1988.75 MHz (PCS CDMA) • Max. Power Rating: 0.334 W ERP CDMA (25.233 dBm) / 24.5 dBm Conducted 0.376 W EIRP PCS CDMA (25.751 dBm) / 24.5 dBm Conducted • FCC Classification(s): Licensed Portable Tx Held to Ear (PCE) • Equipment (EUT) Type: Dual-Band CDMA Phone • Modulation(s): CDMA • Frequency Tolerance: ± 0.00025% (2.5 ppm) • FCC Rule Part(s): § 24(E), §22(H) • Dates of Tests: April 11-12, 2005 • Place of Tests: PCTEST Lab, Columbia, MD U.S.A. • Test Report S/N: 0504010234 PCTEST PT. 22/24 REPORT FCC MEASUREMENT REPORT Reviewed By: Quality Manager Test Report S/N: 0504010234 Test Dates: April 11-12, 2005 Phone Type: Dual-Band CDMA FCC ID: A3LSCHA850 Page 4 of 24 © 2005 PCTEST ENGINEERING LABORATORY, INC. 2.1 INTRODUCTION These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39° 11'15" N latitude and 76° 49'38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of the measurement facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. Measurement Procedure The radiated and spurious measurements were made outdoors at a 3-meter test range (see Figure2). The equipment under test is placed on a wooden turntable 3-meters from the receive antenna. The receive antenna height …
