A3LSCHS229Single-Band CDMA Phone

* Depending on the software installed or your service provider or country, some of the descriptions in this guide may not match your phone exactly. * Depending on your country, your phone and accessories may appear different from the illustrations in this guide. Printed in Korea Code No.:GH68-XXXXXA English. 07/2006. Rev.1.0 World Wide Web http://www.samsungmobile.com Draft 01 2006. 07. 22 SCH-S229 User’s Guide Drive safely at all times Do not use a hand-held phone while driving. Park the vehicle first. Switch off the phone when refuelling Do not use the phone at a refuelling point (service station) or near fuels or chemicals. Switch off in an aircraft Wireless phones can cause interference. Using them in an aircraft is both illegal and dangerous. Switch off the phone near all medical equipment Hospitals or health care facilities may be using equipment that could be sensitive to external radio frequency energy. Follow any regulations or rules in force. Important safety precautions Failure to comply with the following precautions may be dangerous or illegal. Important safety precautions 1 Interference All wireless phones may be subject to interference, which could affect their performance. Be aware of special regulations Meet any special regulations in force in any area and always switch off your phone whenever it is forbidden to use it, or when it may cause interference or danger. Water resistance Your phone is not water-resistant. Keep it dry. Sensible use Use only in the normal position (held to the ear). Avoid unnecessary contact with the antenna when the phone is switched on. Emergency calls Key in the emergency number for your present location, then press []. Keep your phone away from small children Keep the phone and all its parts, including accessories, out of the reach of small children. Accessories and batteries Use only Samsung-approved accessories and batteries. Use of any unauthorised accessories could damage your phone and may be dangerous. Use of authorised software Use only Samsung-authorised software. The use of any unauthorised software could damage your phone. Qualified service Only qualified service personnel may repair your phone. For more detailed safety information, see "Health and safety information" on page 31 • The phone could explode if the battery is replaced with an incorrect type. • Dispose of used batteries according to the manufacturer’s instructions. 2 About this Guide This User’s Guide provides you with condensed information about how to use your phone. To quickly learn the basics for your phone, please refer to “Step outside the phone.” In this guide, the following instruction icons appear: Indicates that you need to pay careful attention to the subsequent information regarding safety or phone features.  Indicates that you can get more information on the referenced page. → Indicates that you need to press the Navigation keys to scroll to the specified option and then select it. [ ] Indicates a key on the phone. For example, [] < > Indicates a soft key, whose function is displayed on the phone screen. For example, < Menu> • Simple, sleek design with Intenna Samsung’s powerful intenna technology allows the best call quality without an annoying external antenna. Special features of your phone • Phonebook Store home, office, or cellular phone numbers for your contacts. 3 Special features of your phone • Short message service (SMS) Chat and share interest with your friends, family, or co-workers by SMS messages. •Game Enjoy embedded games on your phone.. •Calendar Keep track of your daily and monthly schedule. •Alarm Use your phone as an alarm clock to wake you up in the morning or notify you of an impending event. • Calculator Perform basic calculations and do currency conversions. 4 Contents Unpack 6 Make sure you have each item Your phone 6 Buttons, features, and locations Get started 7 First steps to operating your phone Install and charge the phone ..................................... 7 Power on or off........................................................ 8 Keys and display ..................................................... 9 Access menu functions ............................................ 11 Customise your phone ............................................. 12 Make/Answer calls .................................................. 13 Step outside the phone 14 Begin with Phonebook, messages, and other features Use Phonebook....................................................... 14 Send/View messages .............................................. 15 Use the alarm clock ................................................ 16 Manage schedule .................................................... 16 Enter text 18 ABC, T9 Word, 123, and Symbol mode Call functions 22 Advanced calling features Menu functions 25 All menu options listed Solve problems 46 Help and personal needs Health and safety information 48 5 Overview of menu functions To access Menu mode, press <Menu> in Idle mode. 1 Callsp.23 1 Missed 2 Incoming 3 Outgoing 4 Air time p.23 p.23 p.23 p.23 2 Phonebookp.24 1 Find 2 Add 3 Group settings 4 My phone # 5 Memory status p.24 p.24 p.24 p.24 p.24 3 Messagep.25 1 Write 2 Inbox 3 Outbox 4 Draft 5 Voice mail 6 Erase 7 Settings 8 Memory status 9 SMS groups 0 SOS message p.25 p.25 p.25 p.25 p.25 p.25 p.26 p.26 p.26 p.33 4 Schedulerp.26 1 Today 2 View month 3 Jump to date 4 Alarm 5 Calculator 6 To do list 7 Memo pad 8 Countdown 9 World time 0 Unit converter * Stopwatch p.26 p.27 p.27 p.27 p.27 p.27 p.27 p.27 p.27 p.27 p.27 5 Gamesp.28 6 Setupp.28 1 Sounds 2 Display 3 Calls 4 Phone 5 Security 6 My Menu p.28 p.28 p.28 p.29 p.44 p.44 7 do mOrep.29 1 TATAT Zone 2 SMS service p.29 p.29 6 Unpack Make sure you have each item You can obtain various accessories from your local Samsung dealer. Yo u r p h o n e First steps to operating your phone UIM card information When you subscribe to a cellular network, you receive a plu…

Text truncated - open the document above for the full version.


















18600 Broadwick Street






August 28, 2006        !"# $%&' ( &) "*   +,-   . / (0+1+//2(34 (5 /5 ///5 /4(0+1+// 2( 34(5555,4  .(5(65(5 / (5 1 # )57/(5)8 )94144 *4    1    1: ;&/ 1&19<;3<4 SAMSUNG ELECTRONICS CO.,LTD. 416 Maetan3-Dong Yeongtong-gu, Suwon city, Gyeonggi-Do, Korea 442-742 Date: August 28, 2006 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: A3LS CHS229 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, SAMSUNG ELECTRONICS CO.,LTD. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 45 days after the grant as outlined in Public Notice DA 04-1705. This provision will give SAMSUNG ELECTRONICS CO.,LTD. temporary confidentiality of commercially sensitive information prior to product release. The requested Confidential and Temporary Confidential exhibits are listed as follows: CONFIDENTIAL AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Operational Descriptions 3 Parts Lists and Tune-Up Procedure CONFIDENTIAL 4 Schematics 5 External Photos 6 Internal Photos 7 Test-Setup Photos SHORT-TERM CONFIDENTIAL 8 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, SEOUNG HO PARK SAMSUNG ELECTRONICS CO.,LTD.

Federal Communications Commission. 7435 Oakland Mills Road Columbia, MD 21046 DATE: August 25, 2006 Re: Data cable for SCH-S229 FCC ID: A3LSCHS229 DOC to FCC ID: A3LSCHS229 To Whom It May Concern: This letter is to confirm to all concerned parties that FCC ID: A3LSCHS229 has never use any oscillator or active device on the PBA of the Data cable It does not have any oscillator or active device on the PBA of the data cable. There is just passive device. Data cable M/N: PCB129SBE Should you have any questions or comments concerning the above, Please contact the undersigned. Sincerely Yours, Seoung Ho Park Senior Manager SAMSUNG ELECTRONICS CO.,LTD Telecommunication Network Business Mobile Communication Division Regulatory Compliance Group . SAMSUNG ELECTRONICS CO., LTD 416,Maetan-3dong,Yeongtong-gu, Suwon-si,Gyeonggi-do,442-600 Korea

Samsung FCC ID: A3LSCHS229 EUT Photographs © 2006 PCTEST Lab. Single-Band CDMA Phone NVLAP Lab Code: 100431-0 Samsung FCC ID: A3LSCHS229 EUT Photographs © 2006 PCTEST Lab. Single-Band CDMA Phone NVLAP Lab Code: 100431-0 Samsung FCC ID: A3LSCHS229 EUT Photographs © 2006 PCTEST Lab. Single-Band CDMA Phone NVLAP Lab Code: 100431-0

㙼␴ἰ W]W\WZ W]W\WZ zYY` zjoT GthklGi€Gzhtz|un no]_T 䔨⫠䘸⦐䙸⥀ zYY` zYY` O{h{P GthklGi€Gzhtz|un zYY` zYY`

Reviewed by: FCC ID: A3LSCHS229 FCC Pt. 15B CERTIFICATION TEST REPORT Quality Manager Test Report S/N: Test Dates: EUT Type: 0608250732 August 31, 2006 Single-Band CDMA Phone Page 1 of 13 © 2006 PCTEST Engineering Laboratory, Inc. Ver. 2.3 Applicant Name: Date of Testing: SAMSUNG ELECTRONICS CO., LTD. August 31, 2006 416 Maetan-3 Dong, Paldal-Ku Test Site/Location: Suwon City, Kyungki-Do 441-742, Korea PCTEST Lab, Columbia, MD, USA Test Report Serial No.: 0608250732 FCC ID: A3LSCHS229 APPLICANT: SAMSUNG ELECTRONICS CO., LTD. EUT Type: Single-Band CDMA Phone FCC Rule Part(s): FCC Part 15 Subpart B FCC Classification: FCC Class B Digital Device (JBP) Test Procedure: ANSI C63.4-2003 / EN55022: 1998 w/ A1 (2000) + A2 (2003) The device bearing the FCC Identifier specified above has been shown to comply with the applicable technical standards as indicated in the measurement report and has been tested in accordance with the measurement procedures specified in ANSI C63.4-2003 (See Test Report). These measurements were performed with no deviation from the standards. I authorize and attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE Reviewed by: FCC ID: A3LSCHS229 FCC Pt. 15B CERTIFICATION TEST REPORT Quality Manager Test Report S/N: Test Dates: EUT Type: 0608250732 August 31, 2006 Single-Band CDMA Phone Page 2 of 13 © 2006 PCTEST Engineering Laboratory, Inc. Ver. 2.3 TABLE OF CONTENTS ATTACHMENT A. ATTESTATION STATEMENT(S) ATTACHMENT B. TEST REPORT FCC Class B MEASUREMENT REPORT....................................................................................3 1.0 INTRODUCTION ..............................................................................................................................4 1.1 EVALUATION PROCEDURE................................................................................................................ 4 1.2 SCOPE .................................................................................................................................................. 4 1.3 PCTEST TEST LOCATION ................................................................................................................... 4 2.0 PRODUCT INFORMATION..............................................................................................................5 2.1 EQUIPMENT DESCRIPTION ................................................................................................................ 5 2.2 OPERATION MODE.............................................................................................................................. 5 2.3 EMI SUPPRESSION DEVICE(S)/MODIFICATIONS ............................................................................. 5 3.0 DESCRIPTION OF TEST.................................................................................................................6 3.1 CONDUCTED EMISSIONS ................................................................................................................... 6 3.2 RADIATED EMISSIONS........................................................................................................................ 7 4.0 SAMPLE CALCULATIONS ..............................................................................................................8 4.1 CONDUCTED EMISSION MEASUREMENT SAMPLE CALCULATION: .............................................. 8 4.2 RADIATED EMISSION MEASUREMENT SAMPLE CALCULATION:................................................... 8 5.0 UNCERTAINTY OF MEASUREMENT .............................................................................................9 5.1 LINE CONDUCTED MEASUREMENT UNCERTAINTY CALCULATIONS: .......................................... 9 5.2 RADIATED EMISSIONS MEASUREMENT UNCERTAINTY CALCULATIONS: ................................. 10 6.0 TEST EQUIPMENT CALIBRATION DATA ....................................................................................11 7.0 ENVIRONMENTAL CONDITIONS .................................................................................................12 8.0 CONCLUSION................................................................................................................................13 ATTACHMENT C. SUMMARY OF TEST RESULTS RADIATED TEST DATA LINE-CONDUCTED TEST DATA/PLOT(S) SUPPORT EQUIPMENT USED ATTACHMENT D. FCC ID LABEL & LOCATION ATTACHMENT E. BLOCK(S)/ SCHEMATIC(S) DIAGRAM ATTACHMENT F. OPERATIONAL DESCRIPTION ATTACHMENT G. TEST SETUP PHOTOGRAPHS ATTACHMENT H. EXTERNAL PHOTOGRAPHS ATTACHMENT I. INTERNAL PHOTOGRAPHS ATTACHMENT J. USER’S MANUAL Reviewed by: FCC ID: A3LSCHS229 FCC Pt. 15B CERTIFICATION TEST REPORT Quality Manager Test Report S/N: Test Dates: EUT Type: 0608250732 August 31, 2006 Single-Band CDMA Phone Page 3 of 13 © 2006 PCTEST Engineering Laboratory, Inc. Ver. 2.3 MEASUREMENT REPORT FCC Part 15B – Unintentional Radiators A. § 2.1033 General Information APPLICANT: SAMSUNG ELECTRONICS CO., LTD. APPLICANT ADDRESS: 416 Maetan-3 Dong, Paldal-Ku Suwon City, Kyungki-Do 441-742, Korea TEST SITE: PCTEST ENGINEERING LABORATORY, INC. TEST SITE ADDRESS: 6660-B Dobbin Road, Columbia, MD 21045 USA FCC RULE PART(S): FCC Part 15 Subpart B FCC ID: A3LSCHS229 Test Device Serial No.: FD-143-G Production Pre-Production Engineering FCC CLASSIFICATION: FC…

Text truncated - open the document above for the full version.

Samsung FCC ID: A3LSCHS229 EUT Photographs © 2006 PCTEST Lab. Single-Band CDMA Phone NVLAP Lab Code: 100431-0 Samsung FCC ID: A3LSCHS229 EUT Photographs © 2006 PCTEST Lab. Single-Band CDMA Phone NVLAP Lab Code: 100431-0 Samsung FCC ID: A3LSCHS229 EUT Photographs © 2006 PCTEST Lab. Single-Band CDMA Phone NVLAP Lab Code: 100431-0
