A3LSCHS279Cellular CDMA Phone

8 14 37 MODEL : SCH-S279 RATED : MADE IN CHINA BY SAMSUNG 1000 mA 3,7V FCC ID : A3LSCHS279 MODEL : SCH-S279 RATED : MADE IN CHINA BY SAMSUNG 1000 mA 3,7V FCC ID : A3LSCHS279

of 29 SAMSUNG ELECTRONICS Co., Ltd., Regulatory Compliance Group IT R&D Center 416, Maetan-3dong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea 443-742 TEST REPORT ON SAR Model Tested: SCH-S279 FCC ID (Requested): A3LSCHS279 Job No: FG-081 Report No: FG-081-S1 Date issued: Apr.15, 2009 - Abstract – This document reports on SAR Tests carried out in accordance with FCC/OET Bulletin 65, Supplement C(July 2001). Prepared By YB KIM - Test Engineer Authorized By JD JANG - Technical Manager Report Number: FG-081-S1 2 of 29 Contents 1. GENERAL INFORMATION............................................................................................................. 3 2. DESCRIPTION OF DEVICE ........................................................................................................... 3 3. DESCRIPTION OF TEST EQUIPMENT ......................................................................................... 4 3.1 SAR Measurement Setup ......................................................................................................4 3.2 E-field Probe..................................................................................................................... 6 3.3 SAM Phantom ........................................................................................................................ 8 3.4 Modular Flat Phantom............................................................................................................ 8 3.5 Brain & Muscle Simulating Mixture Characterization ............................................................. 9 3.6 Device Holder for Transmitters ............................................................................................ 10 3.7 Validation Dipole .................................................................................................................. 10 3.8 Equipment Calibration...........................................................................................................11 4. SAR MEASUREMENT PROCEDURE ......................................................................................... 12 5. DESCRIPTION OF TEST POSITION ........................................................................................... 13 5.1 SAM Phantom Shape...........................................................................................................13 5.2 Cheek/Touch Position .......................................................................................................... 13 5.3 EAR/Tilt 15° Position ............................................................................................................ 15 5.4 Body Holster/Belt Clip Configurations.................................................................................. 16 6. MEASUREMENT UNCERTAINTY................................................................................................ 18 7. SYSTEM VERIFICATION ............................................................................................................. 19 7.1 Tissue Verification ................................................................................................................ 19 7.2 Test System Validation ......................................................................................................... 19 8. SAR MEASUREMENT RESULTS ................................................................................................ 20 8.1 Measurement Results(CDMA Right Head SAR - Touch) ..................................................... 23 8.2 Measurement Results(CDMA Right Head SAR - Tilt) .......................................................... 24 8.3 Measurement Results(CDMA Left Head SAR - Touch) ....................................................... 25 8.4 Measurement Results(CDMA Left Head SAR - Tilt) ............................................................ 26 8.5 Measurement Results(CDMA Body SAR without Holster)................................................... 27 9. CONCLUSION .............................................................................................................................. 28 10. REFERENCES ............................................................................................................................ 29 Report Number: FG-081-S1 3 of 29 1. GENERAL INFORMATION Test Sample : Single-Mode Cellular Phone Model Number : SCH-S279 Serial Number : Identical prototype (S/N : # FG-081-B) Manufacturer : SAMSUNG ELECTRONICS Co., Ltd. Contact : JS YOUN Phone : +82-31-301-8355 Fax : - Test Standard : §2.1093; FCC/OET Bulletin 65, Supplement C(July 2001) FCC Classification : Licensed Non-Broadcast Transmitter Held to Ear (TNE) Test Dates : Apr.08, 2009 Tested for : FCC/TCB Certification 2. DESCRIPTION OF DEVICE Tx Freq. Range : 824.70 ~ 848.31 MHz (CDMA) Rx Freq. Range : 869.70 ~ 893.31 MHz (CDMA) Antenna Manufacturer : Skycross Model No.: SCH-S279 Antenna Dimensions : 39.2mm × 14.75mm × 8.55mm CDMA 2000 1x Support Report Number: FG-081-S1 4 of 29 3. DESCRIPTION OF TEST EQUIPMENT 3.1 SAR Measurement Setup Robotic System Measurements are performed using the DASY4(DASY5) automated dosimetric assessment system. Which is made by Schmid & Partner Engineering AG (SPEAG) in Zurich, Switzerland and consists of high precision robotics system (Stäubli), robot controller, measurement server, Samsung computer, near-field probe, probe alignment sensor, and the SAM twin phantom containing the brain equivalent material. The robot is a six-axis industrial robot performing precise movements to position the probe to the location (points) of maximum electromagnetic field (EMF) (see Fig. 3.1). Figure 3.1 SAR Measurement System Setup System Hardware A cell controller system contains the power supply, robot controller, teach pendant (Joystick), and a remote control is used to drive the robot motors. The PC consists of the Samsung computer with Windows XP system and SAR Measurement Software DASY4(DASY5), LCD monitor, mouse and key…
