Samsung FCC ID: A3LSCHU540T EUT Photographs © 2007 PCTEST Lab. Cellular/PCS CDMA Phone with EvDO and Bluetooth Model: SCH-U540T Samsung FCC ID: A3LSCHU540T EUT Photographs © 2007 PCTEST Lab. Cellular/PCS CDMA Phone with EvDO and Bluetooth Model: SCH-U540T Samsung FCC ID: A3LSCHU540T EUT Photographs © 2007 PCTEST Lab. Cellular/PCS CDMA Phone with EvDO and Bluetooth Model: SCH-U540T Samsung FCC ID: A3LSCHU540T EUT Photographs © 2007 PCTEST Lab. Cellular/PCS CDMA Phone with EvDO and Bluetooth Model: SCH-U540T Samsung FCC ID: A3LSCHU540T EUT Photographs © 2007 PCTEST Lab. Cellular/PCS CDMA Phone with EvDO and Bluetooth Model: SCH-U540T Samsung FCC ID: A3LSCHU540T EUT Photographs © 2007 PCTEST Lab. Cellular/PCS CDMA Phone with EvDO and Bluetooth Model: SCH-U540T Samsung FCC ID: A3LSCHU540T EUT Photographs © 2007 PCTEST Lab. Cellular/PCS CDMA Phone with EvDO and Bluetooth Model: SCH-U540T

Samsung FCC ID: A3LSCHU540T EUT Photographs © 2007 PCTEST Lab. Cellular/PCS CDMA Phone with EvDO and Bluetooth Model: SCH-U540T Samsung FCC ID: A3LSCHU540T EUT Photographs © 2007 PCTEST Lab. Cellular/PCS CDMA Phone with EvDO and Bluetooth Model: SCH-U540T Samsung FCC ID: A3LSCHU540T EUT Photographs © 2007 PCTEST Lab. Cellular/PCS CDMA Phone with EvDO and Bluetooth Model: SCH-U540T Samsung FCC ID: A3LSCHU540T EUT Photographs © 2007 PCTEST Lab. Cellular/PCS CDMA Phone with EvDO and Bluetooth Model: SCH-U540T Samsung FCC ID: A3LSCHU540T EUT Photographs © 2007 PCTEST Lab. Cellular/PCS CDMA Phone with EvDO and Bluetooth Model: SCH-U540T Samsung FCC ID: A3LSCHU540T EUT Photographs © 2007 PCTEST Lab. Cellular/PCS CDMA Phone with EvDO and Bluetooth Model: SCH-U540T Samsung FCC ID: A3LSCHU540T EUT Photographs © 2007 PCTEST Lab. Cellular/PCS CDMA Phone with EvDO and Bluetooth Model: SCH-U540T Samsung FCC ID: A3LSCHU540T EUT Photographs © 2007 PCTEST Lab. Cellular/PCS CDMA Phone with EvDO and Bluetooth Model: SCH-U540T Samsung FCC ID: A3LSCHU540T EUT Photographs © 2007 PCTEST Lab. Cellular/PCS CDMA Phone with EvDO and Bluetooth Model: SCH-U540T

Reviewed by: FCC ID: A3LSCHU540T CERTIFICATION REPORT Quality Manager SAR Filename: Test Dates: EUT Type: 0703260227.A3L 03/27/07 - 03/28/07 Cellular/PCS CDMA Phone with Bluetooth and EvDO Page 1 of 25 © 2007 PCTEST Engineering Laboratory, Inc. REV 4.3C 03/22/07 Applicant Name: Date of Testing: Samsung Electronics, Co. Ltd. 03/27/07 - 03/28/07 18600 Broadwick St. Test Site/Location: Rancho Dominguez, CA 90220 PCTEST Lab, Columbia, MD, USA United States Test Report Serial No.: 0703260227.A3L FCC ID: A3LSCHU540T APPLICANT: SAMSUNG ELECTRONICS, CO. LTD. EUT Type: Cellular/PCS CDMA Phone with Bluetooth and EvDO Application Type: Certification FCC Rule Part(s): §2.1093; FCC/OET Bulletin 65 Supplement C [July 2001] FCC Classification: Licensed Transmitter Held to Ear (PCE) Model(s): SCH-U540T Tx Frequency: 824.70 - 848.31 MHz (Cellular CDMA) 1851.25 - 1908.75 MHz (PCS CDMA) Conducted Power: 25 dBm CDMA / 24.5 dBm PCS Max. SAR Measurement: 1.22 W/kg CDMA850 Head SAR / 0.369 W/kg CDMA850 Body SAR 1.23 W/kg CDMA1900 Head SAR / 0.732 W/kg CDMA1900 Body SAR Test Device Serial No.: Pre-Production [S/N: FE-047-B] This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-2005 and has been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. 1528-2003. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant Conditions: Power output listed is ERP for Part 22 and EIRP for Part 24. SAR compliance for body-worn operating configuration is based on a separation distance of 1.5 cm between the back of the unit and the body of the user. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. Belt clips or holsters not specified in this filing may not contain metallic components. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) Reviewed by: FCC ID: A3LSCHU540T CERTIFICATION REPORT Quality Manager SAR Filename: Test Dates: EUT Type: 0703260227.A3L 03/27/07 - 03/28/07 Cellular/PCS CDMA Phone with Bluetooth and EvDO Page 2 of 25 © 2007 PCTEST Engineering Laboratory, Inc. REV 4.3C 03/22/07 TABLE OF CONTENTS 1 INTRODUCTION....................................................................................................................3 2 TEST SITE LOCATION...........................................................................................................4 3 SAR MEASUREMENT SETUP................................................................................................5 4 DASY E-FIELD PROBE SYSTEM............................................................................................7 5 PROBE CALIBRATION PROCESS..........................................................................................8 6 PHANTOM AND EQUIVALENT TISSUES................................................................................9 7 DOSIMETRIC ASSESSMENT & PHANTOM SPECS..............................................................10 8 DEFINITION OF REFERENCE POINTS................................................................................11 9 TEST CONFIGURATION POSITIONS...................................................................................12 10 ANSI/IEEE C95.1-2005 RF EXPOSURE LIMITS....................................................................14 11 MEASUREMENT UNCERTAINTIES......................................................................................15 12 SYSTEM VERIFICATION......................................................................................................16 13 FCC 3G MEASUREMENT PROCEDURES – JUNE 2006.......................................................17 14 SAR DATA SUMMARY.........................................................................................................19 15 EQUIPMENT LIST................................................................................................................22 16 CONCLUSION.....................................................................................................................23 17 REFERENCES.....................................................................................................................24 Reviewed by: FCC ID: A3LSCHU540T CERTIFICATION REPORT Quality Manager SAR Filename: Test Dates: EUT Type: 0703260227.A3L 03/27/07 - 03/28/07 Cellular/PCS CDMA Phone with Bluetooth and EvDO Page 3 of 25 © 2007 PCTEST Engineering Laboratory, Inc. REV 4.3C 03/22/07 1 INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radio frequency (RF) radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-2005 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. (c) 2005 by the Institute of Electrical and Electronics Engineers, Inc., New York, New York 10017.[2] The measurement procedure described in IEEE/ANSI C95.3-2002 Recommended Practice for the Measurement of Potenti…

Text truncated - open the document above for the full version.

PCTEST ENGINEERING LABORATORY, INC. DUT: Samsung SCH-U540T; Type: CDMA Dual Band Phone with EvDO + BT; SN: FE-047-B Conducted Power: 25.0 dBm Communication System: Cellular CDMA; Frequency: 824.7 MHz;Duty Cycle: 1:1 Medium: 835 Brain (σ = 0.88 mho/m, ε r = 40.82, ρ = 1000 kg/m 3 ) Phantom section: Right Section Test Date: 03-27-2007; Ambient Temp: 23.7°C; Tissue Temp: 21.4°C Probe: EX3DV4 - SN3589; ConvF(8.36, 8.36, 8.36); Calibrated: 7/14/2006 Sensor-Surface: 3mm (Mechanical Surface Detection) Electronics: DAE4 Sn704; Calibrated: 6/1/2006 Phantom: SAM Main; Type: SAM 4.0; Serial: TP:1197 Measurement SW: DASY4, V4.7 Build 53; Postprocessing SW: SEMCAD, V1.8 Build 172 Right Head, Touch, Low.ch, Standard Battery, Antenna Internal Area Scan (7x15x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 11.5 V/m Peak SAR (extrapolated) = 1.72 W/kg SAR(1 g) = 1.16 mW/g; SAR(10 g) = 0.758 mW/g 0 dB = 1.32mW/g PCTEST ENGINEERING LABORATORY, INC. DUT: Samsung SCH-U540T; Type: CDMA Dual Band Phone with EvDO + BT; SN: FE-047-B Conducted Power: 25.0 dBm Communication System: Cellular CDMA; Frequency: 836.52 MHz;Duty Cycle: 1:1 Medium: 835 Brain (σ = 0.88 mho/m, ε r = 40.82, ρ = 1000 kg/m 3 ) Phantom section: Right Section Test Date: 03-27-2007; Ambient Temp: 23.7°C; Tissue Temp: 21.4°C Probe: EX3DV4 - SN3589; ConvF(8.36, 8.36, 8.36); Calibrated: 7/14/2006 Sensor-Surface: 3mm (Mechanical Surface Detection) Electronics: DAE4 Sn704; Calibrated: 6/1/2006 Phantom: SAM Main; Type: SAM 4.0; Serial: TP:1197 Measurement SW: DASY4, V4.7 Build 53; Postprocessing SW: SEMCAD, V1.8 Build 172 Right Head, Tilt, Mid.ch, Standard Battery, Antenna Internal Area Scan (7x15x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 15.4 V/m Peak SAR (extrapolated) = 0.285 W/kg SAR(1 g) = 0.220 mW/g; SAR(10 g) = 0.165 mW/g 0 dB = 0.243mW/g PCTEST ENGINEERING LABORATORY, INC. DUT: Samsung SCH-U540T; Type: CDMA Dual Band Phone with EvDO + BT; SN: FE-047-B Conducted Power: 25.0 dBm Communication System: Cellular CDMA; Frequency: 824.7 MHz;Duty Cycle: 1:1 Medium: 835 Brain (σ = 0.88 mho/m, ε r = 40.82, ρ = 1000 kg/m 3 ) Phantom section: Left Section Test Date: 03-27-2007; Ambient Temp: 23.7°C; Tissue Temp: 21.4°C Probe: EX3DV4 - SN3589; ConvF(8.36, 8.36, 8.36); Calibrated: 7/14/2006 Sensor-Surface: 3mm (Mechanical Surface Detection) Electronics: DAE4 Sn704; Calibrated: 6/1/2006 Phantom: SAM Main; Type: SAM 4.0; Serial: TP:1197 Measurement SW: DASY4, V4.7 Build 53; Postprocessing SW: SEMCAD, V1.8 Build 172 Left Head, Touch, Low.ch, Standard Battery, Antenna Internal Area Scan (7x15x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 14.5 V/m Peak SAR (extrapolated) = 1.71 W/kg SAR(1 g) = 1.22 mW/g; SAR(10 g) = 0.807 mW/g 0 dB = 1.40mW/g PCTEST ENGINEERING LABORATORY, INC. DUT: Samsung SCH-U540T; Type: CDMA Dual Band Phone with EvDO + BT; SN: FE-047-B Conducted Power: 25.0 dBm Communication System: Cellular CDMA; Frequency: 836.52 MHz;Duty Cycle: 1:1 Medium: 835 Brain (σ = 0.88 mho/m, ε r = 40.82, ρ = 1000 kg/m 3 ) Phantom section: Left Section Test Date: 03-27-2007; Ambient Temp: 23.7°C; Tissue Temp: 21.4°C Probe: EX3DV4 - SN3589; ConvF(8.36, 8.36, 8.36); Calibrated: 7/14/2006 Sensor-Surface: 3mm (Mechanical Surface Detection) Electronics: DAE4 Sn704; Calibrated: 6/1/2006 Phantom: SAM Main; Type: SAM 4.0; Serial: TP:1197 Measurement SW: DASY4, V4.7 Build 53; Postprocessing SW: SEMCAD, V1.8 Build 172 Left Head, Tilt, Mid.ch, Standard Battery, Antenna Internal Area Scan (7x15x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 15.4 V/m Peak SAR (extrapolated) = 0.413 W/kg SAR(1 g) = 0.310 mW/g; SAR(10 g) = 0.231 mW/g 0 dB = 0.347mW/g PCTEST ENGINEERING LABORATORY, INC. DUT: Samsung SCH-U540T; Type: CDMA Dual Band Phone with EvDO + BT; SN: FE-047-B Conducted Power: 24.5 dBm Communication System: PCS CDMA; Frequency: 1908.75 MHz;Duty Cycle: 1:1 Medium: 1900 Brain (σ = 1.43 mho/m, ε r = 38.10, ρ = 1000 kg/m 3 ) Phantom section: Right Section Test Date: 03-28-2007; Ambient Temp: 23.9°C; Tissue Temp: 21.3°C Probe: EX3DV4 - SN3589; ConvF(7.11, 7.11, 7.11); Calibrated: 7/14/2006 Sensor-Surface: 3mm (Mechanical Surface Detection) Electronics: DAE4 Sn704; Calibrated: 6/1/2006 Phantom: SAM Main; Type: SAM 4.0; Serial: TP:1197 Measurement SW: DASY4, V4.7 Build 53; Postprocessing SW: SEMCAD, V1.8 Build 172 Right Head, Touch, High.ch, Standard Battery, Antenna Internal Area Scan (7x15x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 7.14 V/m Peak SAR (extrapolated) = 2.49 W/kg SAR(1 g) = 1.23 mW/g; SAR(10 g) = 0.625 mW/g 0 dB = 1.60mW/g PCTEST ENGINEERING LABORATORY, INC. DUT: Samsung SCH-U540T; Type: CDMA Dual Band Phone with EvDO + BT; SN: FE-047-B Conducted Power: 24.5 dBm Communication System: PCS CDMA; Frequency: 1880 MHz;Duty Cycle: 1:1 Medium: 1900 Brain (σ = 1.43 mho/m, ε r = 38.10, ρ = 1000 kg/m 3 ) Phantom section: Right Section Test Date: 03-28-2007; Ambient Temp: 23.9°C; Tissue Temp: 21.3°C Probe: EX3DV4 - SN3589; ConvF(7.11, 7.11, 7.11); Calibrated: 7/14/2006 Sensor-Surface: 3mm (Mechanical Surface Detection) Electronics: DAE4 Sn704; Calibrated: 6/1/2006 Phantom: SAM Main; Type: SAM 4.0; Serial: TP:1197 Measurement SW: DASY4, V4.7 Build 53; Postprocessing SW: SEMCAD, V1.8 Build 172 Right Head, Tilt, Mid.ch, Standard Battery, Antenna Internal Area Scan (7x15x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 8.09 V/m Peak SAR (extrapolated) = 0.139 W/kg SAR(1 g) = 0.089 mW/g; SAR(10 g) = 0.052 mW/g 0 dB = 0.108mW/g PCTEST ENGINEERING LABORATORY, INC. DUT: Samsung SCH-U540T; Type: CDMA Dual Band Phone with EvDO +…

Text truncated - open the document above for the full version.

PCTEST ENGINEERING LABORATORY, INC. DUT: Dipole 835 MHz; Type: D835V2; Serial: 4d026 Communication System: CW; Frequency: 835 MHz;Duty Cycle: 1:1 Medium: 835 Brain ( σ = 0.88 mho/m, ε r = 40.82, ρ = 1000 kg/m 3 ) Phantom section: Flat Section Test Date: 03-27-2007; Ambient Temp: 23.7 C Tissue Temp: 21.4 C Probe: EX3DV4 - SN3589; ConvF(8.36, 8.36, 8.36); Calibrated: 7/14/2006 Sensor-Surface: 3mm (Mechanical Surface Detection) Electronics: DAE4 Sn704; Calibrated: 6/1/2006 Phantom: SAM Main; Type: SAM 4.0; Serial: TP:1197 Measurement SW: DASY4, V4.7 Build 53; Postprocessing SW: SEMCAD, V1.8 Build 172 835MHz Dipole Validation Area Scan (7x13x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Input Power = 24.0 dBm (250 mW) SAR(1 g) = 2.35 mW/g; SAR(10 g) = 1.59 mW/g Target SAR(1g) = 2.25 mW/g; Deviation = + 4.33 % 0 dB = 2.76mW/g PCTEST ENGINEERING LABORATORY, INC. DUT: Dipole 1900 MHz; Type: D1900V2; Serial: 5d080 Communication System: CW; Frequency: 1900 MHz;Duty Cycle: 1:1 Medium: 1900 Brain ( σ = 1.43 mho/m, ε r = 38.10, ρ = 1000 kg/m 3 ) Phantom section: Flat Section Test Date: 03 -28-2007; Ambient Temp: 23.9° C; Tissue Temp: 21.3 °C Probe: EX3DV4 - SN3589; ConvF(7.11, 7.11, 7.11); Calibrated: 7/14/2006 Sensor-Surface: 3mm (Mechanical Surface Detection) Electronics: DAE4 Sn704; Calibrated: 6/1/2006 Phantom: SAM Main; Type: SAM 4.0; Serial: TP:1197 Measurement SW: DASY4, V4.7 Build 53; Postprocessing SW: SEMCAD, V1.8 Build 172 1900MHz Dipole Validation Area Scan (5x7x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Input Power = 20.0 dBm (100 mW) SAR(1 g) = 3.98 mW/g; SAR(10 g) = 2.23mW/g Target SAR(1g) = 3.77 mW/g; Deviation = + 5.57 % 0 dB = 5.62mW/g

Reviewed by: FCC ID: A3LSCHU540T FCC Pt. 22/24 CDMA / EvDO MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0703260226.A3L March 29-30, 2007 Cellular/PCS CDMA Phone with EVDO and Bluetooth Page 1 of 35 © 2007 PCTEST Engineering Laboratory, Inc. REV 6.3C 03/19/07 Applicant Name: Date of Testing: Samsung Electronics, Co. Ltd. March 29-30, 2007 18600 Broadwick St. Test Site/Location: Rancho Dominguez, CA 90220 PCTEST Lab., Columbia, MD, USA United States Test Report Serial No.: 0703260226.A3L FCC ID: A3LSCHU540T APPLICANT: SAMSUNG ELECTRONICS, CO. LTD. Application Type: Certification FCC Classification: PCS Licensed Transmitter Held to Ear (PCE) FCC Rule Part(s): §2; §22(H), §24(E) EUT Type: Cellular/PCS CDMA Phone with EVDO and Bluetooth Model(s): SCH-U540T Tx Frequency Range: 824.70 - 848.31MHz (Cell. CDMA) / 1851.25 - 1908.75MHz (PCS CDMA) Max. RF Output Power: 0.254 W ERP Cell. CDMA (24.05 dBm) / 0.257 W EIRP PCS CDMA (24.10 dBm) Emission Designator(s): 1M25F9W (CDMA) / 1M25F9W (PCS) Test Device Serial No.: identical prototype [S/N: FE-047-A] This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in §2.947. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant Conditions: Power output listed is ERP for Part 22 and EIRP for Part 24. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE FCC Part 22 & 24 Certification Reviewed by: FCC ID: A3LSCHU540T FCC Pt. 22/24 CDMA / EvDO MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0703260226.A3L March 29-30, 2007 Cellular/PCS CDMA Phone with EVDO and Bluetooth Page 2 of 35 © 2007 PCTEST Engineering Laboratory, Inc. REV 6.3C 03/19/07 TABLE OF CONTENTS FCC PART 22 & 24 MEASUREMENT REPORT...........................................................................3 1.0 INTRODUCTION ..............................................................................................................................4 1.1 MEASUREMENT PROCEDURE......................................................................................................... 4 1.2 SCOPE ................................................................................................................................................ 4 1.3 TESTING FACILITY............................................................................................................................. 4 2.0 PRODUCT INFORMATION..............................................................................................................5 2.1 EQUIPMENT DESCRIPTION .............................................................................................................. 5 2.2 EMI SUPPRESSION DEVICE(S)/MODIFICATIONS ........................................................................... 5 2.3 LABELING REQUIREMENTS.............................................................................................................. 5 3.0 DESCRIPTION OF TESTS ..............................................................................................................6 3.1 OCCUPIED BANDWIDTH EMISSION LIMITS .................................................................................... 6 3.2 CELLULAR - BASE FREQUENCY BLOCKS....................................................................................... 6 3.3 CELLULAR - MOBILE FREQUENCY BLOCKS ................................................................................... 6 3.4 PCS - BASE FREQUENCY BLOCKS .................................................................................................. 7 3.5 PCS - MOBILE FREQUENCY BLOCKS .............................................................................................. 7 3.6 SPURIOUS AND HARMONIC EMISSIONS AT ANTENNA TERMINAL.............................................. 7 3.7 RADIATED SPURIOUS AND HARMONIC EMISSIONS ..................................................................... 7 3.8 FREQUENCY STABILITY / TEMPERATURE VARIATION ................................................................. 8 4.0 TEST EQUIPMENT CALIBRATION DATA ......................................................................................9 5.0 SAMPLE CALCULATIONS ............................................................................................................10 6.0 TEST RESULTS .............................................................................................................................11 6.1 SUMMARY......................................................................................................................................... 11 6.2 EFFECTIVE RADIATED POWER OUTPUT DATA ........................................................................... 12 6.3 EQUIVALENT ISOTROPIC RADIATED POWER OUTPUT DATA .................................................... 13 6.4 CELLULAR CDMA RADIATED MEASUREMENTS........................................................................... 14 6.5 PCS CDMA RADIATED MEASUREMENTS...................................................................................... 17 6.6 FREQUENCY STABILITY (CELLULAR CDMA) ................................................................................ 20 6.7 FREQUENCY STABILITY (PCS CDMA)..................................................................................…
