A3LSCOR4MONOVideo Cassette Recorder (VHS)

Video Cassette Recorder W-422 OWNER’S MANUAL HEAD VIDEO SYSTEM 4 AUTO CLOCK SET W-422/ENG(1-9) 9/1/01, 10:44 AM1 2 In the spaces provided below, record the Model and Serial No. located at the rear of your video cassette recorder. Model No.Serial No. Retain this information for future reference. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE CABINET. REFER SERVICING TO QUALI- FIED PERSONNEL ONLY. CAUTION:TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT. Note to CATV system installer: This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical. Copyright It is permissible to record television programs, film, video tapes and other material only in the event that third party copyrights and other rights are not violated. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s en- closure that may be of sufficient magnitude to constitute a risk of electric shock to per- sons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and mainte- nance (servicing) instructions in the literature accompanying the appliance. SAFETY PRECAUTIONS Product Name: Video Cassette Recorder Model Number: W-422 FCC Notice: “Declaration of Corformity”. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful Interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Contact: Toshiba America Consumer Products, Inc. Address: 1420 Toshiba Drive, Lebanon, TN 37087 Telephone: 615-449-2360 User Installer Caution: Changes or modification made to this equipment not expressly approved by Toshiba Corporation or parties authorized by Toshiba Corporation could void the user’s authority to operate the equipment. W-422/ENG(1-9) 9/1/01, 10:44 AM2 3 IMPORTANT PRECAUTIONS Save Original Packing Materials The original shipping carton and packing materials will come in handy if you ever have to ship your VCR. For maximum protection, repack the set as it was originally packed at the factory. Avoid Volatile Liquid Do not use volatile liquids, such as an insect spray, near the unit. Do not leave rubber or plastic products touching the unit for a long time. They will mar the finish. Moisture Condensation Never operate this unit immediately after moving it from a cold location to a warm location. When the VCR is exposed to such a change in temperature, moisture may condense on the cylinder inside, one of its most crucial internal parts. To prevent the VCR from possible damage, do not use the unit for at least 2 hours when there is an extreme or sudden change in temperature. Compatibility This video cassette recorder (VCR) is compatible with any other VCR bearing the mark. HQ VHS equipment is also compatible with existing, non-HQ VHS equipment. INTRODUCTION As an ENERGY STAR Partner, TOSHIBA has determined that this product or product model meets the E NERGY STAR guidelines for energy efficiency. ® ® W-422/ENG(1-9) 9/1/01, 10:44 AM3 4 1.Read owner’s manual After unpacking this product, read the owner’s manual carefully, and follow all the operating and other instructions. 2.Power Sources This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your product dealer or local power company. For products intended to operate from battery power, or other sources, refer to the operating instructions. 3.Grounding or Polarization This product may be equipped with a polarized alternating current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug. 4.Ventilation Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug or other similar surface. This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to. 5.Heat The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat. IMPORTANT SAFETY INSTRUCTIONS CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS OWNER’S MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR FUTURE REFERENCE. This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. The safeguards incorporated in this unit will protect you if you observe the following procedures for installation, use and servicing. This unit is fully transistorized and does not contain any parts that can be repaired by the user. DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY. W-422/ENG(1-9) 9/1/01, 10:44 AM4 5 6.Water and Moisture Do not use this product near water - for example, ne…

Text truncated - open the document above for the full version.

Project No.: SE-01-0428 This reports shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory.

Project No.: SE-01-0428 This reports shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. FCC ID : A3LSCOR4MONO FACTORY ID: “I” E215927 MADE IN INDONESIA VIDEO CASSETTE RECORDER MODEL NO. W-422 120V AC 60Hz

Project No.: SE-01-0428 This reports shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Project No.: SE-01-0428 This reports shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Project No.: SE-01-0428 This reports shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory.

Project No.: SE-01-0428 Page 1 of 49 EMC TEST REPORT Project No.: SE-01-0428 1. Applicant Name :SAMSUNG ELECTRONICS CO., LTD. 416 Maetan 3 Dong, Paldal-Ku, Suwon City, Kyungki Do, Korea, 442-742 2. Identification of tested device 2.1 FCC ID :A3LSCOR4MONO 2.2 Device Name :VIDEO CASSETTE RECORDER 2.3 Trade Name :TOSHIBA 2.4 Model Number :W-422 3. Test Procedure and Items 3.1 Radiated Emissions Measurement : ANSI C63.4-1992 3.2 Output Signal Level Measurement : ANSI C63.4-1992 3.3 Output Terminal Conducted Spurious Emission Measurement : ANSI C63.4-1992 3.4 Antenna Transfer Switch Measurement : ANSI C63.4-1992 Date of test : September 20. 2001 ~ September 21. 2001 Issued Date : September 24. 2001 Tested by: Chun Kyu, PARK / Test Engineer Reviewed by: Seung Kyu, CHA / Manager of EMC Lab. Authorised by: Kyu Baek, CHUNG / Chief of EMC Lab. This reports shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Project No.: SE-01-0428 Page 2 of 49 TABLE OF CONTENTS 1. GENERAL INFORMATION 2. TEST MODE 3. AC POWERLINE CONDUCTED EMISSION MEASUREMENT 4. RADIATED EMISSION MEASUREMENT 5. OUTPUT SIGNAL LEVEL MEASUREMENT 6. OUTPUT TERMINAL CONDUCTED SPURIOUS EMISSION MEASUREMENT 7. ANTENNA TRANSFER SWITCH MEASUREMENT 8. LIST OF TEST INSTRUMENTS This reports shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Project No.: SE-01-0428 Page 3 of 49 1. GENERAL INFORMATION 1.1 Description for Equipment Authorization 1.1.1 Rules Part(s) under which Equipment Authorization FCC Rule Part 15, Subpart B : Unintentional Radiators TV Interface Devices. This Product is a Video Cassette Recorder containing RF modulator. 1.1.2 Kind of Equipment Authorization : CERTIFICATION 1.1.3 FCC ID Number : A3LSCOR4MONO 1.1.4 Applied TM-BLOCK(RF Units) :TMDH2-A32made by Alps 115VD025APmade by Sanyo TMZH2-002Amade by Alps 1.1.5 RF Modulator Frequency :CH.3 Visual Carrier 61.25MHz, Aural Carrier 65.75MHz CH.4 Visual Carrier 67.25MHz, Aural Carrier 71.75MHz 1.1.6 Rate Power Supply : AC 120V, 60Hz 1.1.7 Type of RF Output Connector : Type "F" Connector 75ohm(Unbalanced) 1.1.8 Measurement Facility : Semi-anechoic chamber #1 (FCC Registration Number : 98856) This reports shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Project No.: SE-01-0428 Page 4 of 49 2. TEST MODE The EUT was tested in the following operating modes(at both channel 3 and 4) for the tests mention in this report: 1) Playback mode [ VHS Play] in this test mode, a video tape recorded with VITS signal was played on the EUT. 2) Record mode [ 1V VITS Signal Input] A 1V peak-to-peak VITS signal was supplied through the video input connector for recording. 3) Record mode [ 5V VITS Signal Input] A 5V peak-to-peak VITS signal was supplied through the video input connector for recording. 4) Record mode [ NTSC Signal Input] A NTSC signal(Color bar with grea lines) was supplied at ch. 5(77.25MHz) through the Ant. input connector for recording. Note: The NTSC TV signal input record mode is not applicable to the antenna transfer switch test. The explanation of measuring instrument setup when respective function is used in any frequency band is as following: Frequency Band InstrumentDetectorResolutionVideo [MHz]fuctionBandwidthBandwidth Spectrum analyzerPeak1MHz1MHz EMI Test receiverQuasi-Peak120kHz- Above 1000EMI Test receiverAverage1MHz- This reports shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 30 to 1000 Project No.: SE-01-0428 Page 5 of 49 3. AC POWERLINE CONDUCTED EMISSION MEASUREMENT 3.1 Reference Rule and Specification FCC Rule Part 15, Section 15.107(a) 3.2 Test Procedure 3.2.1 Configurate the EUT System in accordance with ANSI C63.4-1992 section 7 and 12.2. Connect the EUT's AC line cord to the EUT port of LISN. 3.2.2 All input terminals are terminated in the proper impedance. The output ports are connected to the cable provided with the device and the ending port are terminated in the proper impedance. 3.2.3 Using a calibrated coaxial cable, the TEST RECEIVER is connected to the measuring port of the LISN for EUT. To the find out an EUT condition procedures the maximum emission, the position of cables, EUT operations mode are the position of cables, EUT operations mode are checked under normal usage of EUT. Then, the emission are scanned from 0.45MHz to 30MHz relative to the limit are recorded. This reports shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Project No.: SE-01-0428 Page 6 of 49 3.3 Test Results * TM-BLOCK(RF UNIT) :TMDH2-A32 1) EUT Mode : Playback mode [ VHS Play] FrequencyTotalResultsLimitsMargin Loss(b)(a) + (b) [MHz]L1L2[dB][dBuV][dBuV][dB] 0.60017.523.40.0623.548.024.5 1.39822.721.80.0622.848.025.2 5.31619.518.60.0519.648.028.5 14.05220.418.70.4420.848.027.2 20.36418.016.80.818.848.029.2 28.63832.732.01.233.948.014.1 2) EUT Mode : Record mode [ 1V & 5V VITS Signal Input] FrequencyTotalResultsLimitsMargin Loss(b)(a) + (b) [MHz]L1L2[dB][dBuV][dBuV][dB] 0.52827.125.40.0727.248.020.8 2.02825.625.70.0625.848.022.2 7.68021.221.80.0521.948.026.2 13.74018.116.00.418.548.029.5 19.17019.617.80.7820.448.027.6 28.29023.827.41.228.648.019.4 3) EUT Mode : Record mode [ NTSC Signal Input] FrequencyTotalResultsLimitsMargin Loss(b)(a) + (b) [MHz]L1L2[dB][dBuV][dBuV][dB] 0.47425.024.70.0725.148.022.9 1.80627.322.80.0627.448.020.6 3.61821.721.20.0521.848.026.3 8.29824.319.10.0624.448.023.6 17.37629.927.70.6330.548.017.5 20.42429.825.90.830.648.017.4 * Margin = Limits - Results This reports shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Meter reading(a) LISN Port Meter reading(a) LISN Port Meter reading(a) LISN Port Project No.: SE-01-0428 Page 7 of 49 * TM-BLOCK(RF UNIT) :115VD025AP 1) EUT Mode : Playback mode [ VHS Play] FrequencyTotalResultsLimitsMargin Loss(b)(a) + (b) [MHz]L1L2…

Text truncated - open the document above for the full version.

Project No.: SE-01-0428 1. AC POWERLINE CONDUCTED EMISSION MEASUREMENT 2. RADIATED EMISSION MEASUREMENT This reports shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Project No.: SE-01-0428 3. OUTPUT SIGNAL LEVEL & OUTPUT TERMINAL CONDUCTED SPURIOUS EMISSION MEASUREMENT This reports shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Project No.: SE-01-0428 4. ANTENNA TRANSFER SWITCH MEASUREMENT This reports shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory.
