FCC CFR47 PART 15 DIGITAL DEVICE TEST REPORT FOR DVD ROM DRIVE MODEL: SDR-430 FCC ID: A3LSDR430 REPORT NUMBER: 98E7557 ISSUE DATE: JULY 15, 1998 Prepared for SAMSUNG ELECTRONICS CO., LTD. 416 MAETAN DONG, PALDAL GU SUWON SHI, KOREA Prepared by COMPLIANCE ENGINEERING SERVICES, INC. 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089, USA TEL: (408) 752-8166 FAX: (408) 752-8168 REPORT NO:98E7557 DATE:JULY 15, 1998 FCC ID:A3LSDR430 EUT: DVD ROM DRIVE COMPLIANCE CONSULTING SERVICESDOCUMENT NO:CCSUP4002B2 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS PAGE 1.VERIFICATION OF COMPLIANCE.......................................................................................................1 2.PRODUCT DESCRIPTION.......................................................................................................................2 3.TESTED SYSTEM DETAILS....................................................................................................................2 4.TEST FACILITY........................................................................................................................................3 5.ACCREDITATION AND LISTING..........................................................................................................3 6.MEASUREMENT INSTRUMENTATION...............................................................................................3 7.MEASURING INSTRUMENT CALIBRATION......................................................................................4 8.UNITS OF MEASUREMENT....................................................................................................................4 9.ANTENNAS................................................................................................................................................5 10.CLASSIFICATION OF DIGITAL DEVICE.............................................................................................5 11. RADIATED EMISSION LIMITS..............................................................................................................5 12. CONDUCTED EMISSION LIMITS..........................................................................................................6 13.CONDUCTED EMISSION TEST PROCEDURE.....................................................................................8 14. RADIATED EMISSION TEST PROCEDURE.........................................................................................8 15.AMBIENT CONDITIONS.........................................................................................................................9 16.SYSTEM TEST CONFIGURATION........................................................................................................9 17.EQUIPMENT MODIFICATIONS...........................................................................................................10 18.EUT SETUP PHOTOS.............................................................................................................................11 19. TEST EQUIPMENT LIST........................................................................................................................12 20.TEST RESULT SUMMARY....................................................................................................................13 APPENDICES....................................................................................................................................................15 .EXTERNAL I/O CABLE CONSTRUCTION DESCRIPTION .CONFIGURATION BLOCK DIAGRAM .EUT PHOTOGRAPHS REPORT NO:98E7557 DATE:JULY 15, 1998 FCC ID:A3LSDR430 EUT: DVD ROM DRIVE 1 OF 15 COMPLIANCE CONSULTING SERVICESDOCUMENT NO:CCSUP4002B2 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 1.VERIFICATION OF COMPLIANCE COMPANY NAME:SAMSUNG ELECTRONICS CO., LTD. 416 MAETAN DONG, PALDAL GU SUWON SHI, KOREA CONTACT PERSON:BEN KIM / MANAGER TELEPHONE NO:408-544-5124 MODEL NO/NAME:SDR-430 SERIAL NO:N/ADATE TESTED:JULY 15, 1998 TYPE OF EQUIPMENT:INFORMATION TECHNOLOGY EQUIPMENT (ITE) MEASUREMENT DISTANCE:(X) 3 METER ( ) 10 METER TECHNICAL LIMIT: CLASS B FCC RULES:PART 15 MEASUREMENT PROCEDUREANSI C63.4:92 EQUIPMENT AUTHORIZATION PROCEDURE CERTIFICATION MODIFICATIONS MADE ON EUT YES NO DEVIATIONS FROM MEASUREMENT PROCEDURE YES (refer to section 21 for comments) NO RADIATED EMISSION TEST RESULT -15.56 dB@ 166.47 MHz/VERTICAL CONDUCTED EMISSION TEST RESULT -14.3 dB @ 22.165 MHz/L2 The above equipment was tested by Compliance Consulting Services for compliance with the requirements set forth in the FCC CFR 47, PART 15. The results of testing in this report apply to the product/system which was tested only. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Approved By MIKE C.I. KUO / VICE PRESIDENT COMPLIANCE CONSULTING SERVICES REPORT NO:98E7557 DATE:JULY 15, 1998 FCC ID:A3LSDR430 EUT: DVD ROM DRIVE 2 OF 15 COMPLIANCE CONSULTING SERVICESDOCUMENT NO:CCSUP4002B2 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 2.PRODUCT DESCRIPTION CHASSIS TYPEPLASTIC & METAL CPU SPEEDS TESTED133 Mhz PENTIUM LIST OF EACH OSC. OR XTAL. FREQ. (FREQ.>=1 MHz) 22.5792, 20, 50 MHz CHIPSET BRAND AND PART NO.TOSHIBA TC9453F NUMBER OF PCB LAYERS4 BOARD REVISION NO01 POWER REQUIREMENTS120 V AC, 60 Hz NO. OF EXTERNAL I/O CONNECTORS1 3.TESTED SYSTEM DETAILS The Model names for all equipment, plus descriptions of all cables used in the tested system (including inserted cards) are: External Peripheral Devices Device Type ManufacturerModel NumberSerial No.FCC ID / DoC MONITORSAMSUNGCKE5507LN/ADoC KE…
