A3LSF5800PFAX/LASTER PRINTER

Xerox Work Centre 385 User’s Guide Trademarks • Windows is a trademark of Microsoft Corporation. • IBM is a trademark of International Business Machines. • Centronics is a trademark of Centronics Data Computer. • Other names and trademarks mentioned in this manual are trademarks of their respective holders. Thank you for purchasing Xerox Work Centre 385—the multifunction office product for your home office and the whole family. We are sure that Xerox Work Centre 385 will provide all you need in one machine. Xerox Work Centre 385 combines these office machines: - Plain paper fax - Copier - Laser printer - Scanner Enjoy your new Xerox Work Centre 385! Important Safety Information Always be careful when using the machine. To reduce the risk of fire, electrical shock, and other injuries, keep these safety considerations in mind when installing, using, and maintaining your machine: • Stability. Place the machine on a secure, stable surface. The machine can cause serious damage if it falls. • Power Supply. Provide the correct power to the machine, as listed on its back. If you aren’t sure of the type of power that’s supplied to your home or office, call your electric company. • Grounding.If the plug has three prongs, it must be plugged into a grounded (three hole) outlet. Grounded plugs and outlets are designed for your safety–don’t try to make a three-prong plug fit into a two-prong outlet by modifying the plug or outlet in any way. If you can’t insert the plug into your wall outlet easily, the outlet should be inspected by a qualified electrician. • Overload. Don’t plug too many electrical devices into a wall outlet or extension cord. An overloaded outlet is a fire and electrical shock hazard. • Cleaning.Before cleaning the machine, unplug it from both the power outlet and the telephone jack. Clean exposed parts with a soft cloth slightly dampened with water. Don’t use aerosol cleaners. • Thunderstorms.Unplug electrical appliances during thunderstorms. Avoid using any telephone (except a cordless model) during a thunderstorm, since there’s a small chance you could get an electrical shock from lightning. • Gas Leaks.Never use any telephone close to a gas leak. If you think gas is leaking, call the gas company immediately, but use a telephone far away from the leak area. A small electrical spark in the telephone could cause a fire. vi 1.2 Set Up Your Machine MachineToner Cartridge Handset * 1 Document Tray Printer driver installation diskettes User’s Guide Document exit trayPrinter Exit Tray 0102030405 0607080910 1112131415 1617181920 AC power cord * 2 Telephone line cord * 2 One-touch Label Unpacking Set Up Your Machine *1 These parts may not be provided depending on country. *2 These parts may look different. The appearance varies according to country. Handset cradle * 1 1.3 Set Up Your Machine Control Locations and Functions Take a moment to familiarize yourself with the main components and understand their functions. Front View Paper Extension Automatic Paper Feeder Manual Paper Feeder Document Guides Paper Guides Document Tray Control Panel Document Exit Tray Print Exit Tray 1 Getting Started Note: Your machine may look slightly different than the illustration. 1.4 Set Up Your Machine Printer Connector Power Cord Connector TEL LINE Jack EXT. LINE Jack Image Cover Cover Release Buttons (right and left) Rear View Inside 1.5 Set Up Your Machine 1 Getting Started Choosing a Location To help guarantee trouble-free operation of your machine, place it on a flat, stable surface near your workstation. Leave enough space to allow for easy paper loading, paper out and opening the front cover. Do not place your machine: - In direct sunlight. - Near heat sources or air conditioners. - In dusty or dirty environments. Setting Up Your Machine Document Tray Insert two tabs on the tray into the slots as shown.Fold out the extender on the tray, if necessary. Document Exit Tray Insert the two tabs on the document exit tray into the slots on the front of your machine.Fold out the extender, if necessary. Extender Insert one end first, then the other end by pulling this leg inward to make the tray easy to insert. 1.8 Set Up Your Machine Telephone Line Plug one end of the telephone line cord into the TEL LINE jack and the other end into a standard phone wall jack. TEL LINE EXT. LINE Extension Phone If you want to use a regular phone or answering machine with your Work Centre 385 machine, connect the phone into the EXT.LINE jack. Plug the cord of your extension phone or answering machine into the socket marked EXT.LINE on the back of the machine. TEL LINE EXT. LINE To a standard phone wall jack To a regular phone 1.9 Set Up Your Machine 1 Getting Started Printer Cable Your Xerox Work Centre 385 has a parallel interface port, which allows you to use it with IBM PCs and compatible computers. You have to purchase a Centronics parallel interface cable that supports bi-directional communications (IEEE standard 1284). Ask your dealer for assistance if you need help selecting the right cable. To connect the printer to the computer, follow the steps below: 1. Make sure that both the Xerox Work Centre 385 and the computer are turned off. 2. Plug the cable into the connector on the back of the printer. Push the metal clips down to fit inside the notches on the cable plug. 3. Connect the other end of the cable to the parallel interface port on your computer. See your computer documentation if you need help. 1.10 Set Up Your Machine AC Power Cord Plug one end of the cord into the back of the machine and the other end into a standard AC power outlet. The machine turns on. If there is no cartridge installed, or no paper, the display shows ‘DOOR OPEN or NO TONER!!!’ or [NO PAPER]. If you want to turn it off, unplug the power cord. To AC outlet 4.2 Appendix FCC Information The following information is applicable only to the machines installed in the United States of America. Label Identification This equipment complies with Part…

Text truncated - open the document above for the full version.

Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia MD 21046 Attention:Application Examiner Subject :Application for Certification Reference:FCC ID:A3LSF5800P Dear Application Examiner : On behalf of Samsung Electronics Co.,Ltd., I, the undersigned, hereby submit the application for certification per FCC Part 15 rules. EUT is an unintentional radiator to be classified as computing device peripherals. The following attachments are included in the electronic filling : Attachment A:This letter Attachment B: Agent authorization letter Attachment C: FCC ID label format and location Attachment D: Block Diagram Attachment E: Technical report w/ setup photo Attachment F: Internal / External photo Attachment G: User Manual If you have any question, please feel free to contact me. Best Regards Mike C.I. Kuo / Vice President Compliance Engineering Services, Inc. 1366 Bordeaux Drive Sunnyvale CA 94089 Tel(408)752-8166 x:105 E-Mail :[email protected]

FCC ID LABEL LOCATION Applicant:Samsung Electronics Co., Ltd. FCC ID:A3LSF5800P FCC ID LABEL LOCATION

FCC CFR47 PART 15 DIGITAL DEVICE TEST REPORT FOR FAX/LASER PRINTER MODEL: WORKCENTRE 385 FCC ID: A3LSF5800P REPORT NUMBER: 98E7637 ISSUE DATE: JULY 29, 1998 Prepared for SAMSUNG ELECTRONICS CO., LTD. 416 MAETAN DONG, PALDAL GU SUWON SHI, KOREA Prepared by COMPLIANCE ENGINEERING SERVICES, INC. 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089, USA TEL: (408) 752-8166 FAX: (408) 752-8168 REPORT NO:98E7637 DATE:JULY 29, 1998 FCC ID:A3LSF5800P EUT: FAX/LASER PRINTER COMPLIANCE CONSULTING SERVICESDOCUMENT NO:CCSUP4002C 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS PAGE 1.VERIFICATION OF COMPLIANCE..............................................1 2.PRODUCT DESCRIPTION.....................................................2 3.TESTED SYSTEM DETAILS...................................................2 4.TEST FACILITY...........................................................3 5.ACCREDITATION AND LISTING...............................................3 6.MEASUREMENT INSTRUMENTATION.............................................3 7.MEASURING INSTRUMENT CALIBRATION........................................3 8.UNITS OF MEASUREMENT....................................................4 9.ANTENNAS................................................................4 10.CLASSIFICATION OF DIGITAL DEVICE........................................5 11.RADIATED EMISSION LIMITS................................................5 12.CONDUCTED EMISSION LIMITS...............................................6 13.CONDUCTED EMISSION TEST PROCEDURE.......................................8 14.RADIATED EMISSION TEST PROCEDURE........................................8 15.AMBIENT CONDITIONS......................................................9 16.SYSTEM TEST CONFIGURATION...............................................9 17.EQUIPMENT MODIFICATIONS................................................10 18.EUT SETUP PHOTOS.......................................................11 19.TEST EQUIPMENT LIST....................................................12 20.TEST RESULT SUMMARY....................................................13 APPENDICES ..................................................................15 .EXTERNAL I/O CABLE CONSTRUCTION DESCRIPTION .CONFIGURATION BLOCK DIAGRAM .EUT PHOTOGRAPHS REPORT NO:98E7637 DATE:JULY 29, 1998FCC ID:A3LSF5800P EUT: FAX/LASER PRINTER 1 OF 18 COMPLIANCE CONSULTING SERVICESDOCUMENT NO:CCSUP4002D 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 1.VERIFICATION OF COMPLIANCE COMPANY NAME:SAMSUNG ELECTRONICS CO., LTD. 416 MAETAN DONG, PALDAL GU SUWON SHI, KOREA CONTACT PERSON:BEN KIM / MANAGER TELEPHONE NO:408-544-5124 MODEL NO/NAME:WORKCENTRE 385 SERIAL NO:N/ADATE TESTED:JULY 29, 1998 TYPE OF EQUIPMENT:INFORMATION TECHNOLOGY EQUIPMENT (ITE) MEASUREMENT DISTANCE:(X) 3 METER ( ) 10 METER TECHNICAL LIMIT:CLASS B FCC RULES:PART 15 MEASUREMENT PROCEDUREANSI C63.4:92 EQUIPMENT AUTHORIZATION PROCEDURECERTIFICATION MODIFICATIONS MADE ON EUT YES NO DEVIATIONS FROM MEASUREMENT PROCEDURE YES (refer to section 20 for comments) NO RADIATED EMISSION TEST RESULT-6.2 dB @ 912 MHz/VERTICAL CONDUCTED EMISSION TEST RESULT-7.0 dB @ 5.59 MHz/L2 The above equipment was tested by Compliance Consulting Services for compliance with the requirements set forth in the FCC CFR 47, PART 15. The results of testing in this report apply to the product/system which was tested only. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Approved By MIKE C.I. KUO / VICE PRESIDENT COMPLIANCE CONSULTING SERVICES REPORT NO:98E7637 DATE:JULY 29, 1998FCC ID:A3LSF5800P EUT: FAX/LASER PRINTER 2 OF 18 COMPLIANCE CONSULTING SERVICESDOCUMENT NO:CCSUP4002D 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 2.PRODUCT DESCRIPTION CHASSIS TYPEPLASTIC CPU SPEEDS TESTED266 MHz CELERON P11 LIST OF EACH OSC. OR XTAL. FREQ. (FREQ.>=1 MHz) 66, 30, 38, 28.6925 MHz CHIPSET BRAND AND PART NO.ARM KS32C6100-01 POWER SUPPLY/NAME/MODEL/S.N.BUILT-IN NUMBER OF PCB LAYERS4 BOARD REVISION NOREV 01 LINE FILTER NAME AND MODELBUILT-IN POWER REQUIREMENTS120 V AC, 60 Hz NO. OF EXTERNAL I/O CONNECTORS3 3.TESTED SYSTEM DETAILS The Model names for all equipment, plus descriptions of all cables used in the tested system (including inserted cards) are: External Peripheral Devices Device Type ManufacturerModel NumberSerial No.FCC ID / DoC MONITORSAMSUNG CHA 4217L N/AFCC DoC KEYBOARDHPE0633KUS201-CJ8131E0819FCC DoC MOUSEHPM-S34LZB75058664DZL211029 MODEMHAYES4007AMA00840073172BFJ4000AM COMPUTERHP VEC/266 SERIES 7MT US82210063FCC DoC REPORT NO:98E7637 DATE:JULY 29, 1998FCC ID:A3LSF5800P EUT: FAX/LASER PRINTER 3 OF 18 COMPLIANCE CONSULTING SERVICESDOCUMENT NO:CCSUP4002D 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 4.TEST FACILITY The open area test sites and conducted measurement facilities used to collect the radiated data are located at 561F Monterey Road, Morgan Hill, California, USA. The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 and CISPR Publication 22. 5.ACCREDITATION AND LISTING The test facilities used to perform radiated and conducted emissions tests are accredited by National Voluntary Laboratory Accreditation Program for the specific scope of accreditation under Lab Code:200065-0 to perform Electromagnetic Interference tests according to FCC PART 15 AND CISPR 22 requirements. No part of this report may be used to claim or imply product endorsement by NVLAP or any agency of the US G…

Text truncated - open the document above for the full version.
