A3LSGHA747Cellular/ PCS GSM/ EDGE/ WCDMA Phone w/ Bluetooth

9. Users Manual World Wide Webhttp://www.samsungmobile.com * Depending on the software installed or your service provider or country, some of the description in this guide may not match your phone. * Depending on your country, your phone and accessories may appear different from the illustra tions in this guide. Printed in Korea Code No.: GH68-xxxxxA English. 08/2007. Draft SGH-A747User’s Guide Important safety precautions Failure to comply with the following precautions may be dangerous or illegal. Drive safely at all timesDo not use a hand-held phone while driving. Park the vehicle first. Switch off the phone when refuellingDo not use the phone at a refuelling point (service station) or near fuels or chemicals.Switch off in an aircraftWireless phones can cause interference. Using them in an aircraft is both illegal and dangerous.Switch off the phone near all medical equipmentHospitals or health care facilities may be using equipment that could be sensitive to external radio frequency energy. Follow any regulations or rules in force.InterferenceAll wireless phones may be subject to interference, which could affect their performance. Important safety precautions 1 Be aware of special regulationsMeet any special regulations in force in any area and always switch off your phone whenever it is forbidden to use it, or when it may cause interference or danger.Water resistanceYour phone is not water-resistant. Keep it dry. Sensible useUse only in the normal position (held to the ear). Avoid unnecessary contact with the antenna when the phone is switched on.Emergency callKey in the emergency number for your present location, then press . Keep your phone away from small children Keep the phone and all its parts, including accessories, out of the reach of small children. Accessories and batteriesUse only Samsung-approved batteries and accessories, such as headse ts and PC data cables. Useof any unauthorised accessories could damage you or your phone and may be dangerous. Qualified serviceOnly qualified service personnel may repair your phone.For more detailed safety information, see "Health and safety information" on page 23. • The phone could explode if the battery is replaced with an incorrect type.• Dispose of used batteries according to the manufacturer’s instructions. At very high volumes, prolonged listening to a headset can damage your hearing. 2 Contents Unpack 4 Make sure you have each itemGet started 5 First steps to operating your phoneInstall and charge the phone ..................................... 5Power on or off........................................................ 6Keys and display ..................................................... 6Menu functions 9 All menu options listedSolve problems 17 Help and personal needsHealth and safety information 19 3 Overview of menu functions To access Menu mode, press < Menu > in Idle mode. 1 AT&T Music2 2 Messaging1 Create New Message2 Inbox3 Mobile Email4 IM5 Sent6 Outbox7 Drafts8 My Folder9 Templates10 Delete All11 Message Settings12 Memory Status 3 Recent Calls1 All Calls2 Missed Calls3 Calls Made4 Calls Received5 Voice Mail6 Speed Dial7 Delete All8 Call Time9 Data Volume10 Data Call Time11 Call Cost4 MEdia Net1 MEdia Net Home2 Enter URL3 Favorites4 Saved page5 History6 Advanced7 Browser Settings 5 AT&T Mall1 Shop Tones2 Shop Games3 Shop Graphics4 Shop Multimedia5 Shop Applications6 MEdia Net Home6 Cellular Video7 My Stuff 8 Address Book9 Settings1 Set Profiles2 Set Display3 Set Time & Date4 Set Phone5 Set Calls6 Set Connectivity7 Set Applications8 Reset Settings9 Set Memory10 Software Update11 Phone Information 4 Unpack Your package contains the following items.•Handset• Battery•Travel Adapter•User’s GuideIn addition, you can obtain various accessories from your local Samsung dealer.•Standard Battery• Extended Battery• Battery Charger•Headset• PC Data Link Kit• Car Charger/Adaptor The items supplied with your phone and the accessories at your Samsung dealer may vary, depending on your country or service provider. Yo ur phone 5 Get started First steps to operating your phoneSIM card informationWhen you subscribe to a cellular network, you receive a plug-in SIM (Subscriber Identity Module) card loaded with your subscripti on details, such as your PIN, and available optional services. Install and charge the phone Low battery indicatorWhen the battery is low:• a warning tone sounds,• the battery low message displays, and• the empty battery icon blinks. If the battery level becomes too low, the phone automatically turns off. Recharge your battery. Remove the battery. If the phone is already on, first turn it off by holding [ ]. Insert the SIM card. Make sure that the gold-coloured contacts on the card face down into the phone. Install the battery. Plug the travel adapter into the phone. Plug the adapter into a standard AC wall outlet. When the phone is completely charged (the battery icon becomes still), unplug the adapter from the power outlet.Remove the adapter from the phone. 6 Get started Power on or off Keys and display Switch onDo not turn on the phone when mobile phone use is prohibited. 1. Open the phone.2. Press and hold [ ] to turn on the phone. 3. If necessary, enter the PIN and press < OK >. Switch off 1. Open the phone.2. Press and hold [ ]. Key(s) Description Soft keys Perform the function indicated on the bottom line of the display. Navigation keys In Idle mode, access your favourite menus, directly.In Menu mode, scroll through the menu options. AT&T key In Idle mode, launch the web browser.In Menu mode, select the highlighted menu option. Cancel key Delete characters from the display.In Menu mode, return to the previous menu level. 7 Get started SEND key Send or answer a call.In Idle mode, retrieve the recent numbers dialled, missed, or received. ENDkey End a call. Press and hold to switch the phone on and off. In Menu mode, cancel input and return the phone to Idle mode. Numeric keys Enter numbers, letters, and some special c…

Text truncated - open the document above for the full version.

SAMSUNG ELECTRONICS AMERICA, INC. American QA Lab 18600 Broadwick St. Rancho Dominguez, CA 90220 DATE : 4, 2007 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Subject: HAC filing FCC ID: A3LSGH Gentlemen: We, Samsung Electronics, hereby declare the samples evaluated in this application are equivalent to production samples. Should you have any questions or comments concerning the above, please contact the undersigned. Steve Kim General Manager American QA Lab SAMSUNG Electronics America INC.

SAMSUNG ELECTRONICS CO.,LTD. 416 Maetan3-Dong Yeongtong-gu, Suwon city, Gyeonggi-Do, Korea 442-742 Date: October 17, 2007 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, http Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: A3LSGHA747 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, SAMSUNG ELECTRONICS CO.,LTD. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give SAMSUNG ELECTRONICS CO.,LTD. temporary confidentiality of commercially sensitive information prior to product release. The requested Confidential and Temporary Confidential exhibits are listed as follows: CONFIDENTIAL AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Operational Description 3 Schematics CONFIDENTIAL 4 Parts List & Tune-Up Procedure 5 External Photos 6 Internal Photos 7 Test-Setup Photos SHORT-TERM CONFIDENTIAL 8 Users Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, SEOUNG HO PARK SAMSUNG ELECTRONICS CO.,LTD.

SAMSUNG FCC ID: A3LSGHA747 EUT Photographs © 2007 PCTEST Lab. 850/1900 GSM/EDGE/WCDMA Phone with Bluetooth Model: SGH-A747 SAMSUNG FCC ID: A3LSGHA747 EUT Photographs © 2007 PCTEST Lab. 850/1900 GSM/EDGE/WCDMA Phone with Bluetooth Model: SGH-A747 SAMSUNG FCC ID: A3LSGHA747 EUT Photographs © 2007 PCTEST Lab. 850/1900 GSM/EDGE/WCDMA Phone with Bluetooth Model: SGH-A747 SAMSUNG FCC ID: A3LSGHA747 EUT Photographs © 2007 PCTEST Lab. 850/1900 GSM/EDGE/WCDMA Phone with Bluetooth Model: SGH-A747 SAMSUNG FCC ID: A3LSGHA747 EUT Photographs © 2007 PCTEST Lab. 850/1900 GSM/EDGE/WCDMA Phone with Bluetooth Model: SGH-A747 SAMSUNG FCC ID: A3LSGHA747 EUT Photographs © 2007 PCTEST Lab. 850/1900 GSM/EDGE/WCDMA Phone with Bluetooth Model: SGH-A747

SGH-A747(ATT) PP + OPP (T=0.08) 홍문기 조경환 070829070829 MODEL : SGH-A747 FCC ID : A3LSGHA747 FOR INFORMATION CALL : 1 888 987 4357 MODEL : SGH-A747 FCC ID : A3LSGHA747 FOR INFORMATION CALL : 1 888 987 4357

SAMSUNG FCC ID: A3LSGHA747 EUT Photographs © 2007 PCTEST Lab. 850/1900 GSM/EDGE/WCDMA Phone with Bluetooth Model: SGH-A747 SAMSUNG FCC ID: A3LSGHA747 EUT Photographs © 2007 PCTEST Lab. 850/1900 GSM/EDGE/WCDMA Phone with Bluetooth Model: SGH-A747 SAMSUNG FCC ID: A3LSGHA747 EUT Photographs © 2007 PCTEST Lab. 850/1900 GSM/EDGE/WCDMA Phone with Bluetooth Model: SGH-A747 SAMSUNG FCC ID: A3LSGHA747 EUT Photographs © 2007 PCTEST Lab. 850/1900 GSM/EDGE/WCDMA Phone with Bluetooth Model: SGH-A747 SAMSUNG FCC ID: A3LSGHA747 EUT Photographs © 2007 PCTEST Lab. 850/1900 GSM/EDGE/WCDMA Phone with Bluetooth Model: SGH-A747 SAMSUNG FCC ID: A3LSGHA747 EUT Photographs © 2007 PCTEST Lab. 850/1900 GSM/EDGE/WCDMA Phone with Bluetooth Model: SGH-A747

Reviewed by: FCC ID: A3LSGHA747 CERTIFICATION REPORT Quality Manager SAR Filename: Test Dates: EUT Type: 0709211098.A3L 10/02/07 - 10/05/07 850/1900 GSM/W CDMA Phone with Bluetooth Page 1 of 26 © 2007 PCTEST Engineering Laboratory, Inc. REV 4.5U 09/04/07 Applicant Name: Date of Testing: Samsung Electronics, Co. Ltd. 10/02/07 - 10/05/07 18600 Broadwick St. Test Site/Location: Rancho Dominguez, CA 90220 PCTEST Lab, Columbia, MD, USA United States Test Report Serial No.: 0709211098.A3L FCC ID: A3LSGHA747 APPLICANT: SAMSUNG ELECTRONICS, CO. LTD. EUT Type: 850/1900 GSM/WCDMA Phone with Bluetooth Application Type: Certification FCC Rule Part(s): §2.1093; FCC/OET Bulletin 65 Supplement C [July 2001] FCC Classification: Licensed Transmitter Held to Ear (PCE) Model(s): SGH-A747 Tx Frequency: 824.20 - 848.80 MHz (Cellular GSM) 1850.20 - 1909.80 MHz (GSM PCS) 826.40 - 846.60 MHz (Cellular WCDMA) 1852.4 - 1907.6 MHz (PCS WCDMA) Conducted Power: 32.64 dBm GSM850 / 29.48 dBm GSM1900 23.26 dBm WCDMA / 23.64 dBm PCS Max. SAR Measurement: 0.478 W/kg GSM850 Head SAR / 1.31 W/kg GPRS850 Body SAR 0.243 W/kg GSM1900 Head SAR / 0.569 W/kg GPRS1900 Body SAR 0.373 W/kg WCDMA850 Head SAR / 0.565 W/kg WCDMA850 Body SAR 0.782 W/kg WCDMA1900 Head SAR / 0.579 W/kg WCDMA1900 Body SAR Test Device Serial No.: Pre-Production [S/N: FE-184-F] This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-2005 and has been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. 1528-2003. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant Conditions: Power output listed is ERP for Part 22 and EIRP for Part 24. SAR compliance for body-worn operating configuration is based on a separation distance of 1.5 cm between the back of the unit and the body of the user. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. Belt clips or holsters not specified in this filing may not contain metallic components. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) Reviewed by: FCC ID: A3LSGHA747 CERTIFICATION REPORT Quality Manager SAR Filename: Test Dates: EUT Type: 0709211098.A3L 10/02/07 - 10/05/07 850/1900 GSM/W CDMA Phone with Bluetooth Page 2 of 26 © 2007 PCTEST Engineering Laboratory, Inc. REV 4.5U 09/04/07 TABLE OF CONTENTS 1 INTRODUCTION ........................................................................................................................ 3 2 TEST SITE LOCATION............................................................................................................... 4 3 SAR MEASUREMENT SETUP ................................................................................................... 5 4 DASY E-FIELD PROBE SYSTEM............................................................................................... 7 5 PROBE CALIBRATION PROCESS............................................................................................. 8 6 PHANTOM AND EQUIVALENT TISSUES .................................................................................. 9 7 DOSIMETRIC ASSESSMENT & PHANTOM SPECS................................................................ 10 8 DEFINITION OF REFERENCE POINTS ................................................................................... 11 9 TEST CONFIGURATION POSITIONS ...................................................................................... 12 10 ANSI/IEEE C95.1-2005 RF EXPOSURE LIMITS...................................................................... 14 11 MEASUREMENT UNCERTAINTIES......................................................................................... 15 12 SYSTEM VERIFICATION ......................................................................................................... 16 13 FCC 3G MEASUREMENT PROCEDURES – JUNE 2007......................................................... 17 14 SAR DATA SUMMARY............................................................................................................. 18 15 EQUIPMENT LIST.................................................................................................................... 23 16 CONCLUSION.......................................................................................................................... 24 17 REFERENCES ......................................................................................................................... 25 Reviewed by: FCC ID: A3LSGHA747 CERTIFICATION REPORT Quality Manager SAR Filename: Test Dates: EUT Type: 0709211098.A3L 10/02/07 - 10/05/07 850/1900 GSM/W CDMA Phone with Bluetooth Page 3 of 26 © 2007 PCTEST Engineering Laboratory, Inc. REV 4.5U 09/04/07 1 INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radio frequency (RF) radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-2005 Standard for Safety Levels with Respect to Human Exposure …

Text truncated - open the document above for the full version.

Reviewed by: FCC ID: A3LSGHA747 FCC Pt. 22/24 GSM/EDGE/WCDMA MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0710011139.A3L October 5 - 8, 2007 850/1900 GSM/EDGE/WCDMA Phone with Bluetooth Page 1 of 56 © 2007 PCTEST Engineering Laboratory, Inc. REV 2.6GWC 06/06/07 Applicant Name: Date of Testing: Samsung Electronics, Co. Ltd. October 5 - 8, 2007 18600 Broadwick St. Test Site/Location: Rancho Dominguez, CA 90220 PCTEST Lab., Columbia, MD, USA United States Test Report Serial No.: 0710011139.A3L FCC ID: A3LSGHA747 APPLICANT: SAMSUNG ELECTRONICS, CO. LTD. Application Type: Certification FCC Classification: PCS Licensed Transmitter Held to Ear (PCE) FCC Rule Part(s): §2; §22(H), §24(E) EUT Type: 850/1900 GSM/EDGE/WCDMA Phone with Bluetooth Model(s): SGH-A747 Tx Frequency Range: 824.20 - 848.80MHz (Cell. GSM) / 1850.20 - 1909.80MHz (PCS GSM) 826.40 - 846.60MHz (Cell. WCDMA) / 1852.4 - 1907.6MHz (PCS WCDMA) Max. RF Output Power: 0.551 W ERP Cell. GSM (27.41 dBm) / 1.449 W EIRP PCS GSM (31.61 dBm) 0.058 W ERP Cell. WCDMA (17.62 dBm) / 0.446 W EIRP PCS WCDMA (26.49 dBm) 0.272 W ERP EDGE850 (24.35 dBm) / 0.6 W EIRP EDGE1900 (27.78 dBm) Emission Designator(s): 246KGXW (Cellular GSM), 246KGXW (PCS GSM) 250KG7W (EDGE850), 248KG7W (EDGE1900) 4M16F9W (Cellular WCDMA), 4M17F9W (PCS WCDMA) Test Device Serial No.: identical prototype [S/N: FE-184-G] This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in §2.947. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant Conditions: Power output listed is ERP for Part 22 and EIRP for Part 24. This device also contains functions that are not operational in U.S. territories. This report is applicable only to U.S. operations. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE FCC Part 22 & 24 Certification Reviewed by: FCC ID: A3LSGHA747 FCC Pt. 22/24 GSM/EDGE/WCDMA MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0710011139.A3L October 5 - 8, 2007 850/1900 GSM/EDGE/WCDMA Phone with Bluetooth Page 2 of 56 © 2007 PCTEST Engineering Laboratory, Inc. REV 2.6GWC 06/06/07 TABLE OF CONTENTS FCC PART 22 & 24 MEASUREMENT REPORT............................................................................3 1.0 INTRODUCTION ..............................................................................................................................4 1.1 MEASUREMENT PROCEDURE......................................................................................................... 4 1.2 SCOPE ................................................................................................................................................ 4 1.3 TESTING FACILITY............................................................................................................................. 4 2.0 PRODUCT INFORMATION..............................................................................................................5 2.1 EQUIPMENT DESCRIPTION .............................................................................................................. 5 2.2 EMI SUPPRESSION DEVICE(S)/MODIFICATIONS ........................................................................... 5 2.3 LABELING REQUIREMENTS.............................................................................................................. 5 3.0 DESCRIPTION OF TESTS ..............................................................................................................6 3.1 OCCUPIED BANDWIDTH EMISSION LIMITS .................................................................................... 6 3.2 CELLULAR - BASE FREQUENCY BLOCKS....................................................................................... 6 3.3 CELLULAR - MOBILE FREQUENCY BLOCKS ................................................................................... 6 3.4 PCS - BASE FREQUENCY BLOCKS .................................................................................................. 7 3.5 PCS - MOBILE FREQUENCY BLOCKS .............................................................................................. 7 3.6 SPURIOUS AND HARMONIC EMISSIONS AT ANTENNA TERMINAL.............................................. 7 3.7 RADIATED SPURIOUS AND HARMONIC EMISSIONS ..................................................................... 7 3.8 FREQUENCY STABILITY / TEMPERATURE VARIATION ................................................................. 8 4.0 TEST EQUIPMENT CALIBRATION DATA ......................................................................................9 5.0 SAMPLE CALCULATIONS ............................................................................................................10 6.0 TEST RESULTS .............................................................................................................................11 6.1 SUMMARY......................................................................................................................................... 11 6.2 CONDUCTED OUTPUT POWER ...................................................................................................... 12 6.3 EFFECTIVE RADIATED POWER OUTPUT DATA ........................................................................... 13 6.4 EQUIVALENT ISOTROPIC…

Text truncated - open the document above for the full version.

Reviewed by: FCC ID: A3LSGHA747 HAC (RF EMISSIONS) TEST REPORT Quality Manager HAC Filename: Test Dates: EUT Type: 0710011143.A3L October 6 - 9, 2007 850/1900 GSM/WCDMA Phone with Bluetooth Page 1 of 74 © 2007 PCTEST Engineering Laboratory, Inc. REV 6.1U 07/20/07 Applicant Name: Date of Testing: Samsung Electronics, Co. Ltd. October 6 - 9, 2007 18600 Broadwick St. Test Site/Location: Rancho Dominguez, CA 90220 PCTEST Lab, Columbia, MD, USA United States Test Report Serial No.: 0710011143.A3L FCC ID: A3LSGHA747 APPLICANT: SAMSUNG ELECTRONICS, CO. LTD. Application Type: Certification FCC Rule Part(s): § 20.19(b), §6.3(v), §7.3(v) HAC Standard: ANSI C63.19-2006 v3.12; FCC Classification: Licensed Transmitter Held to Ear (PCE) EUT Type: 850/1900 GSM/WCDMA Phone with Bluetooth Model(s): SGH-A747 Tx Frequency: 824.20 - 848.80 MHz (Cellular GSM) 1850.20 - 1909.80 MHz (GSM PCS) 826.40 - 846.60 MHz (Cellular WCDMA) 1852.4 - 1907.6 MHz (PCS WCDMA) Test Device Serial No.: Pre-Production Sample [S/N: AE-052-D] C63.19-2006 HAC Category: M3 (RF EMISSIONS CATEGORY) This wireless portable device has been shown to be hearing-aid compatible under the above rated category, specified in ANSI/IEEE Std. C63.19-2006 and had been tested in accordance with the specified measurement procedures. Hearing-Aid Compatibility is based on the assumption that all production units will be designed electrically identical to the device tested in this report. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com HEARING AID COMPATIBILITY CERTIFICATE Reviewed by: FCC ID: A3LSGHA747 HAC (RF EMISSIONS) TEST REPORT Quality Manager HAC Filename: Test Dates: EUT Type: 0710011143.A3L October 6 - 9, 2007 850/1900 GSM/WCDMA Phone with Bluetooth Page 2 of 74 © 2007 PCTEST Engineering Laboratory, Inc. REV 6.1U 07/20/07 TABLE OF CONTENTS 1. INTRODUCTION ............................................................................................................................. 3 2. TEST SITE LOCATION ................................................................................................................... 4 3. EUT DESCRIPTION ........................................................................................................................ 5 4. ANSI/IEEE C63.19 PERFORMANCE CATEGORIES .................................................................... 6 5. SYSTEM SPECIFICATIONS...........................................................................................................7 6. TEST PROCEDURE ..................................................................................................................... 13 7. SYSTEM CHECK .......................................................................................................................... 15 8. MODULATION FACTOR...............................................................................................................18 9. FCC 3G MEASUREMENT PROCEDURES – JUNE 2007 ........................................................... 20 10. OVERALL MEASUREMENT SUMMARY ..................................................................................... 21 11. EQUIPMENT LIST......................................................................................................................... 24 12. MEASUREMENT UNCERTAINTY ................................................................................................ 25 13. TEST DATA ................................................................................................................................... 26 14. CALIBRATION CERTIFICATES.................................................................................................... 39 15. CONCLUSION............................................................................................................................... 69 16. REFERENCES .............................................................................................................................. 70 17. TEST PHOTOGRAPHS ................................................................................................................72 Reviewed by: FCC ID: A3LSGHA747 HAC (RF EMISSIONS) TEST REPORT Quality Manager HAC Filename: Test Dates: EUT Type: 0710011143.A3L October 6 - 9, 2007 850/1900 GSM/WCDMA Phone with Bluetooth Page 3 of 74 © 2007 PCTEST Engineering Laboratory, Inc. REV 6.1U 07/20/07 1. INTRODUCTION On July 10, 2003, the Federal Communications Commission (FCC) adopted new rules requiring wireless manufacturers and service providers to provide digital wireless phones that are compatible with hearing aids. The FCC has modified the exemption for wireless phones under the Hearing Aid Compatibility Act of 1998 (HAC Act) in WT Docket 01-309 RM-8658 1 to extend the benefits of wireless telecommunications to individuals with hearing disabilities. These benefits encompass business, social and emergency communications, which increase the value of the wireless network for everyone. An estimated more than 10% of the population in the United States show signs of hearing impairment and of that fraction, almost 80% use hearing aids. Approximately 500 million people worldwide suffer from hearing loss. Compatibility Tests Involved: The standard calls for wireless communications devices to be measured for: ƒ RF Electric-field emissions ƒ RF Magnetic-field emissions ƒ T-coil mode, magnetic-signal strength in the audio band ƒ T-coil mode, magneti…

Text truncated - open the document above for the full version.

SAMSUNG FCC ID: A3LSGHA747 EUT Photographs © 2007 PCTEST Lab. 850/1900 GSM/EDGE/WCDMA Phone with Bluetooth Model: SGH-A747 SAMSUNG FCC ID: A3LSGHA747 EUT Photographs © 2007 PCTEST Lab. 850/1900 GSM/EDGE/WCDMA Phone with Bluetooth Model: SGH-A747 SAMSUNG FCC ID: A3LSGHA747 EUT Photographs © 2007 PCTEST Lab. 850/1900 GSM/EDGE/WCDMA Phone with Bluetooth Model: SGH-A747 SAMSUNG FCC ID: A3LSGHA747 EUT Photographs © 2007 PCTEST Lab. 850/1900 GSM/EDGE/WCDMA Phone with Bluetooth Model: SGH-A747

SAMSUNG FCC ID: A3LSGHA747 Model: SGH-A747 SAR Test Setup Photos 850/1900 GSM/WCDMA Phone With Bluetooth Page 1 of 5 © 2007 PCTEST Lab. REV 2.1 05/24/2007 1. Right Head SAR 2. Left Head SAR SAMSUNG FCC ID: A3LSGHA747 Model: SGH-A747 SAR Test Setup Photos 850/1900 GSM/WCDMA Phone With Bluetooth Page 2 of 5 © 2007 PCTEST Lab. REV 2.1 05/24/2007 3. Right Head SAR, Cheek Touch 4. Right Head SAR, 15° Tilt SAMSUNG FCC ID: A3LSGHA747 Model: SGH-A747 SAR Test Setup Photos 850/1900 GSM/WCDMA Phone With Bluetooth Page 3 of 5 © 2007 PCTEST Lab. REV 2.1 05/24/2007 5. Left Head SAR, Cheek Touch 6. Left Head SAR, 15° Tilt SAMSUNG FCC ID: A3LSGHA747 Model: SGH-A747 SAR Test Setup Photos 850/1900 GSM/WCDMA Phone With Bluetooth Page 4 of 5 © 2007 PCTEST Lab. REV 2.1 05/24/2007 7. Body SAR 8. Body SAR, Back Side with 15mm Space SAMSUNG FCC ID: A3LSGHA747 Model: SGH-A747 SAR Test Setup Photos 850/1900 GSM/WCDMA Phone With Bluetooth Page 5 of 5 © 2007 PCTEST Lab. REV 2.1 05/24/2007 9. Body SAR 10. Body SAR, Front Side with 15mm Space

Reviewed by: FCC ID: A3LSGHA747 HAC (RF EMISSIONS) TEST REPORT Quality Manager HAC Filename: Test Dates: EUT Type: 0710011143.A3L October 6 - 9, 2007 850/1900 GSM/WCDMA Phone with BT & HSDPA Page 72 of 74 © 2007 PCTEST Engineering Laboratory, Inc. REV 6.1U 07/20/07 17. TEST PHOTOGRAPHS See following Attached Pages for setup photographs. Reviewed by: FCC ID: A3LSGHA747 HAC (RF EMISSIONS) TEST REPORT Quality Manager HAC Filename: Test Dates: EUT Type: 0710011143.A3L October 6 - 9, 2007 850/1900 GSM/WCDMA Phone with BT & HSDPA Page 73 of 74 © 2007…
