A3LSGHC207LDual-Band GSM Phone

Samsung Electronics Co Ltd

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Jul 27, 2004
Application Purpose: Original Equipment
Date of Application: Jul 27, 2004
Equipment Note: Dual-Band GSM Phone
Frequency Range: 1850.20000000 - 1909.80000000
Company: Samsung Electronics Co Ltd
Country: United States

Documents & Files

Select a file to view

Internal Photos

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

* Some of the contents in this manual may differ from your phone, depending on the software installed or your service provider. World Wide Webhttp://www.samsungmobile.com Printed in Korea Code No.: GH68-0XXXXA English. 07/2004. Rev. 1.0 ELECTRONIC S GPRS TELEPHONE SGH-C207L 3 ContentsImportant safety precautions ...................... 7Unpacking .................................................... 9Your phone ................................................ 10Phone layout...................................................... 10Display.............................................................. 13Getting started........................................... 17Installing the SIM card ........................................ 17Charging the battery........................................... 19Switching the phone on or off............................... 21Selecting functions and options ............................ 22Locking or unlocking the keypad........................... 24Call functions ............................................. 25Making a call...................................................... 25Adjusting the volume .......................................... 27Answering a call ................................................. 28Viewing missed calls ........................................... 28Quickly switching to silent mode ........................... 30Options during a call .................................. 31Putting a call on hold .......................................... 31Using the menu functions .................................... 32Switching the microphone off (Mute) ..................... 32Muting/Sending key tones ................................... 33Sending DTMF tones ........................................... 34Searching for a number in phonebook ................... 34 Answering a second call ...................................... 35Making a multi-party call ..................................... 36 Entering text .............................................. 38Changing the text input mode .............................. 39Using the T9 mode ............................................. 40Using the alphabet mode ..................................... 42Using the number mode ...................................... 43Using the symbol mode ....................................... 44 Contents 4 Using the menus ........................................ 45Accessing a menu function by scrolling .................. 45Accessing a menu fu nction by using its shortcut ..... 46 List of menu functions ......................................... 47Phonebook ................................................. 52Storing a number with a name ............................. 52Using phonebook entry options............................. 55Searching for a number in phonebook ................... 57 Editing a caller group .......................................... 59Speed-dialling .................................................... 60Deleting all of the phonebook entries .................... 61Checking the memory status................................ 62Using the service dialling numbers ........................ 63 Text messages ........................................... 64Inbox (Menu 1.1) .................................................. 64 Outbox (Menu 1.2) ................................................ 65 Write new (Menu 1.3)............................................ 66 Templates (Menu 1.4) ........................................... 69 Settings (Menu 1.5)............................................... 70 Delete all (Menu 1.6)............................................. 71 Memory status (Menu 1.7) ..................................... 72 Voice mail (Menu 1.8)............................................ 72 Broadcast (Menu 1.9) ............................................ 73 Multimedia messages................................. 75Inbox (Menu 2.1) .................................................. 75 Outbox (Menu 2.2) ................................................ 78 Draft (Menu 2.3) ................................................... 79 Write new (Menu 2.4)............................................ 79 Templates (Menu 2.5) ........................................... 83 Delete all (Menu 2.6)............................................. 84 Memory status (Menu 2.7) ..................................... 84 Setup (Menu 2.8) .................................................. 85 MMS profile (Menu 2.9) ......................................... 86 Call records ................................................ 87Missed calls (Menu 3.1) ......................................... 87 Received calls (Menu 3.2) ...................................... 88 Dialled calls (Menu 3.3) ......................................... 88 Contents 5 Delete all (Menu 3.4)............................................. 89 Call time (Menu 3.5).............................................. 89 Call cost (Menu 3.6) .............................................. 90 Sound settings ........................................... 91Ring tone (Menu 4.1)............................................. 91 Ring volume (Menu 4.2) ........................................ 91 Alert type (Menu 4.3) ............................................ 92 Keypad tone (Menu 4.4) ........................................ 92 Message tone (Menu 4.5)....................................... 93 Alert on call (Menu 4.6) ......................................... 94 Power on/off (Menu 4.7) ........................................ 94 Extra tones (Menu 4.8) .......................................... 95 Phone settings ........................................... 96Display settings (Menu 5.1) ................................... 96 Greeting message (Menu 5.2) ................................ 98 Own number (Menu 5.3)........................................ 98 Language (Menu 5.4) ............................................ 99 Security (Menu 5.5)......................................…

Text truncated - open the document above for the full version.

Attestation Statements

July 16, 2004 Federal Communications Commission Authorization and Evaluation Div. Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re: Samsung Electronics Co., Ltd. FCC ID.: A3LSGHE830 Request for Confidentiality To Whom It May Concern: In accordance with 0.459 of CFR 47, Samsung Electronics Co., Ltd. requests confidentiality for the Block Diagram, Schematics, Parts list, Tune-up Procedure, Operational and Circuit Description of the attached test report. These documents contain detailed system and equipment descriptions and related information about the product, which Samsung Electronics Co., Ltd. considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Samsung feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Sincerely, Wallace Oh Engineering Manager Samsun Samsung Electronics America July 16, 2004 Federal Communications Commission Authorization and Evaluation Div. Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re: Samsung Electronics Co., Ltd. FCC ID: A3LSGHE830 Request for Short-Term Confidentiality To Whom It May Concern: In accordance with 0.457 and 0.459 of CFR 47, Samsung Electronics Co., Ltd. requests short-term confidentiality for the test setup photos, external photos, internal photos, and user’s manual of the attached test report. These documents contain detailed system and equipment descriptions and related information about the product, which Samsung Electronics Co., Ltd. considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Samsung feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Sincerely, Wallace Oh Engineering Manager Samsun Samsung Electronics America

External Photos

RF Exposure Info

1 of 33 SAMSUNG ELECTRONICS Co., Ltd., Regulatory Compliance Team IT R&D Center 416, Maetan-3dong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea 442-742 TEST REPORT ON SAR Model Tested: SGH-C207L FCC ID (Requested): A3LSGHC207L Job No: FB-041 Report No: FB-041-S1 Date issued: Jul. 20, 2004 - Abstract – This document reports on SAR Tests carried out in accordance with FCC/OET Bulletin 65, Supplement C(July 2001). Prepared By Date DC KANG – Test Engineer Checked By Date JH CHOI - Manager Authorized By Date JK CHOI – Senior Manager Report Number : FB-041-S1 2 of 33 Contents 1. General Information.............................................................................................3 2. Description of Device...........................................................................................3 3. Description of Test Equipment..............................................................................4 3.1 SAR Measurement Setup.........................................................................................4 3.2 DASY4 E-Field Probe.............................................................................................5 3.3 SAM Phantom.....................................................................................................6 3.4 Brain & Muscle Simulating Mixture Characterization....................................................7 3.5 Device Holder for transmitters.................................................................................8 3.6 Validation Dipole...................................................................................................8 3.7 Equipment Calibration.............................................................................................9 4. SAR Measurement Procedure.............................................................................10 5. Description of test position..............................................................................11 5.1 SAM Phantom Shape............................................................................................11 5.2 Cheek/Touch Position............................................................................................11 5.3 Ear/Tilt 15 Position..............................................................................................13 5.4 Body/Holster/Belt Clip Configuration.......................................................................14 6. Measurement Uncertainty..................................................................................16 7. System Verification.........................................................................................18 7.1 Tissue Verification..............................................................................................18 7.2 Test System Validation...........................................................................................18 8. SAR Measurement Results.................................................................................19 8.1 Measurement Results(GSM 850 Right Head SAR-Touch)........................................20 8.2 Measurement Results(GSM 850 Right Head SAR-Tilt)............................................21 8.3 Measurement Results(GSM 850 Left Head SAR-Touch)..........................................22 8.4 Measurement Results(GSM 850 Left Head SAR-Tilt)...............................................23 8.5 Measurement Results(PCS GSM Right Head SAR-Touch).....................................24 8.6 Measurement Results(PCS GSM Right Head SAR-Tilt)............................................25 8.7 Measurement Results(PCS GSM Left Head SAR-Touch)..........................................26 8.8 Measurement Results(PCS GSM Left Head SAR-Tilt)...............................................27 8.9 Measurement Results(GSM850 Body SAR w/o Holster)..............................................28 88.11 Measurement Results(GPRS850 Body SAR w/o Holster)........................................29 8.10 Measurement Results(GSM1900 Body SAR w/o Holster)............................................30 8.10 Measurement Results(GPRS1900 Body SAR w/o Holster).........................................31 9. Conclusion.......................................................................................................32 10. Reference.......................................................................................................33 Report Number : FB-041-S1 3 of 33 1. GENERAL INFORMATION Test Sample : Dual-Band GSM 850/ GSM 1900 Phone Model Number : SGH-C207L Serial Number : Identical prototype (S/N : FB-041-D) Manufacturer : SAMSUNG ELECTRONICS Co., Ltd. Contact : YH SEO, Assistant Manager Phone : +82-31-279-6039 Fax : +82-31-279-6162 Test Standard : §2.1093; FCC/OET Bulletin 65, Supplement C(July 2001) FCC Classification : Licensed Portable Transmitter Held to Ear (PCE) Test Dates : July 14, 2004 ~ July 15, 2004 Tested for : FCC/TCB Certification 2. DESCRIPTION OF DEVICE Tx Freq. Range : 824.2 – 848.8 MHz (GSM 850) 1850.2 – 1909.8 MHz (GSM1900) Rx Freq. Range : 869.2 – 893.8 MHz (GSM 850) 1930.2 – 1989.8 MHz (GSM1900) Max. RF Output Power : 1.256 W ERP GSM 850 ( 30.99 dBm) 1.799 W EIRP GSM 1900 (32.55 dBm) Antenna Manufacturer : EMW antenna Model No.: HIR-01473-0000AA Antenna Dimensions : 34.8 mm [Fixed] Report Number : FB-041-S1 4 of 33 3. DESCRIPTION OF TEST EQUIPMENT 3.1 SAR Measurement Setup Robotic System Measurements are performed using the DASY4 automated dosimetric assessment system. Which is made by Schmid & Partner Engineering AG (SPEAG) in Zurich, Switzerland and consists of high precision robotics system (Stäubli), robot controller, measurement server, Samsung computer, near- field probe, probe alignment sensor, and the SAM twin phantom containing the brain equivalent material. The robot is a six-axis industrial robot performing precise movements to position the probe to the location (points) of maximum electromagnetic field (EMF) (see Fig. 3.1). Figure 3.1 SAR M…

Text truncated - open the document above for the full version.

RF Exposure Info

SAMSUNG FCC ID : A3LSGHC207L -- 835 MHz GSM850 Head SAR DUT: SGH-C207L; Serial: FB-041-D Program Name: SGH-C207L GSM850 Right (Job No.: FB-041) Procedure Name: Cheek/Touch, Ch.251, Ant.Intenna, Bat.Standard Procedure Notes: Meas.Tissue Temp(celsius)-21.7; Test Date-15/July/2004 [OET Bulletin 65- Supplement C, July 2001] Communication System: GSM850; Frequency: 848.8 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 848.8 MHz; σ = 0.89 mho/m; ε r = 42.6; ρ = 1000 kg/m 3 Phantom section: Right Section DASY4 Configuration: - Probe: ET3DV6 - SN1551; ConvF(6.54, 6.54, 6.54); Calibrated: 2004-04-27 - Sensor-Surface: 4mm (Mechanical And Optical Surface Detection) - Electronics: DAE3 Sn533; Calibrated: 2003-12-16 - Phantom: SAM 835/900 MHz; Type: SAM; Serial: TP-1247 - Measurement SW: DASY4, V4.2 Build 44; Postprocessing SW: SEMCAD, V1.8 Build 112 Cheek/Touch, Ch.251, Ant.Intenna, Bat.Standard/Area Scan (51x71x1): Measurement grid: dx=20mm, dy=20mm Reference Value = 23.2 V/m; Power Drift = -0.1 dB Maximum value of SAR (interpolated) = 0.775 mW/g Cheek/Touch, Ch.251, Ant.Intenna, Bat.Standard/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 23.2 V/m; Power Drift = -0.1 dB Maximum value of SAR (measured) = 0.728 mW/g Peak SAR (extrapolated) = 0.922 W/kg SAR(1 g) = 0.691 mW/g 0 dB = 0.728mW/g SAMSUNG FCC ID : A3LSGHC207L -- 835 MHz GSM850 Head SAR DUT: SGH-C207L; Serial: FB-041-D Program Name: SGH-C207L GSM850 Right (Job No.: FB-041) Procedure Name: Ear/Tilt, Ch.251, Ant.Intenna, Bat.Standard Procedure Notes: Meas.Tissue Temp(celsius)-21.7; Test Date-15/July/2004 [OET Bulletin 65- Supplement C, July 2001] Communication System: GSM850; Frequency: 848.8 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 848.8 MHz; σ = 0.89 mho/m; ε r = 42.6; ρ = 1000 kg/m 3 Phantom section: Right Section DASY4 Configuration: - Probe: ET3DV6 - SN1551; ConvF(6.54, 6.54, 6.54); Calibrated: 2004-04-27 - Sensor-Surface: 4mm (Mechanical And Optical Surface Detection) - Electronics: DAE3 Sn533; Calibrated: 2003-12-16 - Phantom: SAM 835/900 MHz; Type: SAM; Serial: TP-1247 - Measurement SW: DASY4, V4.2 Build 44; Postprocessing SW: SEMCAD, V1.8 Build 112 Ear/Tilt, Ch.251, Ant.Intenna, Bat.Standard/Area Scan (51x71x1): Measurement grid: dx=20mm, dy=20mm Reference Value = 19.8 V/m; Power Drift = -0.0 dB Maximum value of SAR (interpolated) = 0.405 mW/g Ear/Tilt, Ch.251, Ant.Intenna, Bat.Standard/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 19.8 V/m; Power Drift = -0.0 dB Maximum value of SAR (measured) = 0.390 mW/g Peak SAR (extrapolated) = 0.487 W/kg SAR(1 g) = 0.367 mW/g 0 dB = 0.390mW/g SAMSUNG FCC ID : A3LSGHC207L -- 835 MHz GSM850 Head SAR DUT: SGH-C207L; Serial: FB-041-D Program Name: SGH-C207L GSM850 Left (Job No.: FB-041) Procedure Name: Cheek/Touch, Ch.251, Ant.Intenna, Bat.Standard Procedure Notes: Meas.Tissue Temp(celsius)-21.7; Test Date-15/July/2004 [OET Bulletin 65- Supplement C, July 2001] Communication System: GSM850; Frequency: 848.8 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 848.8 MHz; σ = 0.89 mho/m; ε r = 42.6; ρ = 1000 kg/m 3 Phantom section: Left Section DASY4 Configuration: - Probe: ET3DV6 - SN1551; ConvF(6.54, 6.54, 6.54); Calibrated: 2004-04-27 - Sensor-Surface: 4mm (Mechanical And Optical Surface Detection) - Electronics: DAE3 Sn533; Calibrated: 2003-12-16 - Phantom: SAM 835/900 MHz; Type: SAM; Serial: TP-1247 - Measurement SW: DASY4, V4.2 Build 44; Postprocessing SW: SEMCAD, V1.8 Build 112 Cheek/Touch, Ch.251, Ant.Intenna, Bat.Standard/Area Scan (51x71x1): Measurement grid: dx=20mm, dy=20mm Reference Value = 22.7 V/m; Power Drift = -0.0 dB Maximum value of SAR (interpolated) = 0.728 mW/g Cheek/Touch, Ch.251, Ant.Intenna, Bat.Standard/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 22.7 V/m; Power Drift = -0.0 dB Maximum value of SAR (measured) = 0.671 mW/g Peak SAR (extrapolated) = 0.838 W/kg SAR(1 g) = 0.636 mW/g 0 dB = 0.671mW/g SAMSUNG FCC ID : A3LSGHC207L -- 835 MHz GSM850 Head SAR DUT: SGH-C207L; Serial: FB-041-D Program Name: SGH-C207L GSM850 Left (Job No.: FB-041) Procedure Name: Ear/Tilt, Ch.251, Ant.Intenna, Bat.Standard Procedure Notes: Meas.Tissue Temp(celsius)-21.7; Test Date-15/July/2004 [OET Bulletin 65- Supplement C, July 2001] Communication System: GSM850; Frequency: 848.8 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 848.8 MHz; σ = 0.89 mho/m; ε r = 42.6; ρ = 1000 kg/m 3 Phantom section: Left Section DASY4 Configuration: - Probe: ET3DV6 - SN1551; ConvF(6.54, 6.54, 6.54); Calibrated: 2004-04-27 - Sensor-Surface: 4mm (Mechanical And Optical Surface Detection) - Electronics: DAE3 Sn533; Calibrated: 2003-12-16 - Phantom: SAM 835/900 MHz; Type: SAM; Serial: TP-1247 - Measurement SW: DASY4, V4.2 Build 44; Postprocessing SW: SEMCAD, V1.8 Build 112 Ear/Tilt, Ch.251, Ant.Intenna, Bat.Standard/Area Scan (51x71x1): Measurement grid: dx=20mm, dy=20mm Reference Value = 19.6 V/m; Power Drift = -0.008 dB Maximum value of SAR (interpolated) = 0.359 mW/g Ear/Tilt, Ch.251, Ant.Intenna, Bat.Standard/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 19.6 V/m; Power Drift = -0.008 dB Maximum value of SAR (measured) = 0.321 mW/g Peak SAR (extrapolated) = 0.409 W/kg SAR(1 g) = 0.305 mW/g 0 dB = 0.321mW/g SAMSUNG FCC ID : A3LSGHC207L -- 1900MHz GSM1900 Head SAR DUT: SGH-C207L; Serial: FB-041-D Program Name: SGH-C207L GSM1900 Right (Job No.: FB-041) Procedure Name: Cheek/Touch, Ch.512, Ant.Intenna, Bat.Standard Procedure Notes: Meas.Tissue Temp(celsius)-21.4; Test Date-14/July/2004 [OET Bulletin 65- Supplement C, July 2001] Communication System: GSM 1900; Frequency: 1850.2 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 1850.2 MHz; σ = 1.39 mho/m; ε r = 38.5; ρ = 1000 kg/m 3 Phantom section: Right Section DASY4 Configuration: - Probe: ET3DV6 - SN1551; ConvF(5, 5, 5); Calibrated: 2004-04-27 - Sensor-Surface: 4mm (Mechanical And Optical Surface Detection) …

Text truncated - open the document above for the full version.

RF Exposure Info

© 2004 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHC207L Dual-Band GSM 850/ GSM 1900 Phone © 2004 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHC207L Dual-Band GSM 850/ GSM 1900 Phone © 2004 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHC207L Dual-Band GSM 850/ GSM 1900 Phone © 2004 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHC207L Dual-Band GSM 850/ GSM 1900 Phone © 2004 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHC207L Dual-Band GSM 850/ GSM 1900 Phone © 2004 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHC207L Dual-Band GSM 850/ GSM 1900 Phone © 2004 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHC207L Dual-Band GSM 850/ GSM 1900 Phone © 2004 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHC207L Dual-Band GSM 850/ GSM 1900 Phone © 2004 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHC207L Dual-Band GSM 850/ GSM 1900 Phone © 2004 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHC207L Dual-Band GSM 850/ GSM 1900 Phone © 2004 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHC207L Dual-Band GSM 850/ GSM 1900 Phone © 2004 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHC207L Dual-Band GSM 850/ GSM 1900 Phone

RF Exposure Info

835MHz Brain Dipole Validation DUT: Dipole 835 MHz; Serial: 451 Program Name: 835MHz Diploe Validation Procedure Name: 835MHz @ 250mW Procedure Notes: Meas.Tissue Temp(celsius)-21.7;Test Date-15/Jul/2004[OET Bulletin 65- Supplement C, July 2001] Communication System: CW; Frequency: 835 MHz;Duty Cycle: 1:1 Medium parameters used: f = 835 MHz; σ = 0.89 mho/m; ε r = 42.6; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: ET3DV6 - SN1551; ConvF(6.54, 6.54, 6.54); Calibrated: 2004-04-27 - Sensor-Surface: 4mm (Mechanical And Optical Surface Detection) - Electronics: DAE3 Sn533; Calibrated: 2003-12-16 - Phantom: SAM 835/900 MHz; Type: SAM; Serial: TP-1247 - Measurement SW: DASY4, V4.2 Build 44; Postprocessing SW: SEMCAD, V1.8 Build 112 835MHz @ 250mW/Area Scan (51x51x1): Measurement grid: dx=20mm, dy=20mm Reference Value = 56.7 V/m; Power Drift = -0.0 dB Maximum value of SAR (interpolated) = 2.68 mW/g 835MHz @ 250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 56.7 V/m; Power Drift = -0.0 dB Maximum value of SAR (measured) = 2.71 mW/g Peak SAR (extrapolated) = 3.75 W/kg SAR(1 g) = 2.49 mW/g 0 dB = 2.71mW/g 1900MHz Brain Dipole Validation DUT: Dipole 1900 MHz; Serial: 548 Program Name: 1900 Dipole Validation Procedure Name: 1900MHz @250mW Procedure Notes: Meas.Tissue Temp(celsius)-20.8;Test Date-14/Jul/2004 Communication System: CW; Frequency: 1900 MHz;Duty Cycle: 1:1 Medium parameters used: f = 1900 MHz; σ = 1.39 mho/m; ε r = 38.5; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: ET3DV6 - SN1551; ConvF(5, 5, 5); Calibrated: 2004-04-27 - Sensor-Surface: 4mm (Mechanical And Optical Surface Detection) - Electronics: DAE3 Sn533; Calibrated: 2003-12-16 - Phantom: SAM 1800/1900 MHz; Type: SAM; Serial: TP-1143 - Measurement SW: DASY4, V4.2 Build 44; Postprocessing SW: SEMCAD, V1.8 Build 112 1900MHz @250mW/Area Scan (51x51x1): Measurement grid: dx=20mm, dy=20mm Reference Value = 94.8 V/m; Power Drift = 0.2 dB Maximum value of SAR (interpolated) = 15.6 mW/g 1900MHz @250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 94.8 V/m; Power Drift = 0.2 dB Maximum value of SAR (measured) = 11.9 mW/g Peak SAR (extrapolated) = 18.2 W/kg SAR(1 g) = 10.5 mW/g 0 dB = 11.9mW/g

Test Report

SAMSUNG ELECTRONICS Co., Ltd., Regulatory Compliance Group IT R&D Center 416, Maetan-3Dong, Youngtong-Gu, Suwon-city, Gyeonggi-Do, Korea 442-600 FCC CFR47 PART 22 & 24 SUBPART CERTIFICATION REPORT Model Tested: SGH-C207L FCC ID (Requested): A3LSGHC207L Report No: FB-041-R1 Job No: FB-041 Date issued: July 20, 2004 - Abstract – All measurement reported herein accordance with FCC Rules, 47CFR Part2, Part22, Part24. Prepared By Date SY KIM – Test Engineer Checked By Date JH CHOI - Engineer Authorized By Date JK CHOI – Senior Manager © Copyright SAMSUNG Electronics 2004 Report Number : FB-041-R1 TABLE OF CONTENT MEASUREMENT REPORT Page 1. FCC Certification Information 3 1.1 2.1033 General Information 3 2. INTRODUCTION 4 2.1 General 4 3. MEASURING INSTRUMENT CALIBRATION 5 4. TEST EQUIPMENT LIST 6 5. DESCRIPTION OF TESTS 7 5.1 Effective Radiated Power/Equivalent Isotropic Radiated Power 7 5.2 Radiated Spurious & Harmonic Emission 8 5.3 Occupied Bandwidth 10 5.4 Spurious and Harmonic Emissions at Antenna Terminal 10 5.4.1 Occupied Bandwidth Emission Limits 10 5.4.2 Conducted Spurious Emission 11 5.5 Frequency Stability / Temperature Variation 12 6. TEST DATA 13 6.1 Effective Radiated Power(E.R.P.) 13 6.2 Equivalent Isotropic Radiated Power(E.I.R.P.) 14 6.3 GSM850 Radiated Spurious & Harmonic Measurement 15 6.4 GSM1900 Radiated Spurious & Harmonic Measurement 16 6.5 GSM850 Radiated Spurious & Harmonic Conversion Table 17 6.6 GSM1900 Radiated Spurious & Harmonic Conversion Table 18 6.7 Frequency Stability 19 6.7.1 GSM850 Frequency Stability Table 19 6.7.2 GSM850 Frequency Stability Graph 20 6.7.3 GSM1900 Frequency Stability Table 22 6.7.4 GSM1900 Frequency Stability Graph 23 7.SAMPLE CALCULATION 25 7.1 Emission Designator 8. CONCLUSION 26 9. TEST PLOTS 27 Report Number : FB-041-R1 MEASUREMENT REPORT 1. FCC Certification Information The following information is in accordance with FCC Rules, 47CFR Rart2, Subpart J, Sections 2.1033 – 2.1055. 2.1033 General Information Applicant Name: SAMSUNG ELECRONICS CO., LTD. Address: 416, Maetan-3Dong, Youngtongl-Gu, Suwon City Gyeonggi-Do, KOREA 442-600 Attention: FCC ID: Wallace Oh, Engineering Manager (QA Lab) A3LSGHC207L Quantity: Quantity production is planned Emission Designators: 250KGXW Tx Freq. Range: 824.2 - 848.8 MHz (GSM850) 1850.2 -1909.8 MHz (GSM1900) Rx Freq. Range: 869.2 - 893.8 MHz (GSM850) 1930.2 -1989.8 MHz (GSM1900 ) Max. Power Rating: 1.256W ERP GSM850 ( 30.99 dBm) 1.799W EIRP GSM1900 ( 32.55 dBm) FCC Classification(s): Licensed Portable Tx Held to Ear (PCE) Equipment (EUT) Type: Dual-Mode GSM850/GSM1900 Phone Modulation(s): GSM850/ GSM1900 Frequency Tolerance: 0.00025% (2.5ppm) FCC Rule Part(s): 24(E), 22(H), 2. Dates of Test: July.13, 16-19, 2004 Place of Test: SAMSUNG Lab, Test Report S/N: FB-041-R1 Report Number : FB-041-R1 2. INTRODUCTION General These measurement test were conducted at SAMSUNG ELECTRONICS CO., LTD(SUWON). The site address is 416,Maetan-3Dong, Youngtong-Gu, Suwon City, Gyeonggi-Do, KOREA 442- 600. The site have 1 Fully-anechoic chamber and measurement facility. Measurement Procedure The radiated and spurious measurements were made Fully-anechoic chamber at a 3-meter test range (see Figure2). The equipment under testing was placed on a wooden turntable 3-meters from the receive antenna. The receive antenna height and turntable rotations were adjusted for the highest reading on the receive spectrum analyzer. The substitution antenna will replace the EUT antenna it the same position and in vertical polarization. The frequency of the signal generator shall be set to the frequencies that were measured on the EUT. The test antenna shall be raised and lowered, if necessary, to ensure that the maximum signal is still being received. The signal generator, output level, shall be adjusted until an equal or a known related level to what was measured from the EUT is obtained in the spectrum analyzer. This level was recorded. For readings above 1 GHz, the above procedure is repeated using horn antennas and the difference between the gain of the horn and an isotropic antenna are taken into consideration. Figure1. Map of the Suwon City area. Fi gure2. Photograph of 3m Fully-Anechoic Chamber Report Number : FB-041-R1 3.MEASURING INSTRUMENT CALIBRATION The measuring equipment, which was utilized in performing the tests documented herein, has been calibrated in accordance with the manufacturer’s recommendations for utilizing calibration equipment, which is traceable to recognized national standards. - End of page - Report Number : FB-041-R1 4.TEST EQUIPMENT LIST Name of Equipment Model Serial No. Due Date ESI26 836119/010 2004-09-15 E4440A(3Hz~26.5GHz) MY41000236 2004-11-07 Spectrum Analyzer E4440A(3Hz~26.5GHz) MY41000233 2004-11-14 SMIQ03B 83824/021 2005-01-15 Signal Generator SMR20 835197/030 2005-01-15 Power Meter E4419B GB41293846 2004-10-02 8481B 3318A10325 2004-10-06 Power Sensor 8485A 3318A19924 2004-10-04 Amplifier 5S1G4 304866 2004-11-17 Pre-Amplifier 8449B 3008A00691 2005-01-16 8960 GB42230535 2004-11-17 Communication test set 8960 GB42360886 2004-11-10 Antenna Master MA0001 ANT0967 Not Required Controller HD100 100/756 Not Required PL-4S 13005454 2004-08-22 SH-241 92000548 2004-12-04 Environmental Chamber SH-241 92000549 2004-12-04 HF906 360306/011 2005-03-11 Horn Antenna HF906 100134 2005-05-02 3121C-DB4 9007-587 2004-10-21 Dipole Antenna 3121C-DB4 9007-588 2004-10-21 Receive Antenna HL040 353255/020 2005-06-07 8494A 3308A31997 2005-01-17 Attenuator 8496A 3308A14426 2005-01-17 4278-311-2 B3679637 2005-01-14 Directional Coupler 4278-111-2 B103DC8722 2005-01-14 WHK1.0/15G-10SS 1 Not Required WHK1.0/15G-10SS 1 Not Required WHK/3.5/18G-10SS 3 Not Required High Pass Filter WHK/3.5/18G-10SS 4 Not Required Shielded Semi-Anechoic Chamber RF0002 ANT0001 Not Required Report Number : FB-041-R1 5. DESCRIPTION OF…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Jenni Chun(General Manager)

[email protected]973-808-6375Fax: 973-808-6361

Technical Contact

PCTEST Engineering Lab., Inc.Randy Ortanez

[email protected]410-290-6652

6660-B Dobbin Road · Columbia, Maryland · United States

Test Firm

SAMSUNG ELECTRONICS CO., LTD.No Cheon Park

[email protected]82-31-200-2185Fax: 82-31-200-2189

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
2	24E	1.85 GHz - 1.91 GHz	1.799 W	248KGXW	2.5 ppm

Confidentiality

Long Term

Grant Notes

Output power listed is ERP for Part 22 and EIRP for Part 24. SAR compliance for body-worn operating congfiguration is based on a separation distance of 1.5 cm between the back of the unit and the body of the user. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. Belt-clip or holsters may not contain metallic components. The highest reported SAR values are: Part 22 - Head: 0.691 W/kg; Body-worn: 0.951 W/kg; Part 24 - Head: 0.279 W/kg; Body-worn: 0.373 W/kg. This device contains 900 MHz GSM and 1800 MHz DCS functions that are not operational in U.S. Territories. This filing is only applicable for 835/ 1900 MHz GSM operations.
