A3LSGHE335Dual-Band GSM Phone

World Wide Webhttp://www.samsungmobile.com * Some of the contents in this manual may differ from your phone, depending on the software installed or your service provider. Printed in Korea Code No.: GH68-0xxxxA English. 11/2004. Draft. 1.1 GPRS TELEPHONE SGH-E335 3 ContentsImportant safety precautions ...................... 7Unpacking .................................................... 9Your phone ................................................ 10 Phone layout ................................................... 10Displays .......................................................... 14External display ............................................... 17Service light .................................................... 18Camera........................................................... 18Built-in antenna ............................................... 19 Getting started........................................... 20 Inserting/Removing the SIM card ....................... 20Installing/Removing/Charging the battery............ 21Switching the phone on or off ............................ 25Selecting functions and options .......................... 26 Call functions ............................................. 28 Making a call ................................................... 28Ending a call.................................................... 31Answering a call ............................................... 31Rejecting a call ................................................ 31Adjusting the volume ........................................ 32Accessing options during a call ........................... 33Using the headset ............................................ 41 Entering text .............................................. 42 Changing the text input mode ............................ 43Using ABC mode .............................................. 44Using T9 mode................................................. 46Using symbolic mode ........................................ 49Using number mode ......................................... 49 Using the menus ........................................ 50 Accessing a menu function ................................ 50List of menu functions....................................... 51 Phonebook menu ....................................... 57 Find name (Phonebook 1.1) .................................. 57 Contents 4 Add entry (Phonebook 1.2) ................................... 60 Speed-dial list (Phonebook 1.3)............................. 61 Copy all to phone (Phonebook 1.4) ........................ 63 Delete all (Phonebook 1.5) .................................... 64 Own number (Phonebook 2.1)............................... 64 Group setting (Phonebook 2.2).............................. 65 Memory status (Phonebook 2.3) ............................ 66 Service directory (Phonebook 3.1) ......................... 66 SIM-AT (SIM Application Toolkit) .............. 67Call records ................................................ 68 Missed calls (Menu 2.1) ........................................ 68 Received calls (Menu 2.2) ..................................... 68 Dialled calls (Menu 2.3) ........................................ 69 Delete all (Menu 2.4) ........................................... 69 Call time (Menu 2.5) ............................................ 70 Call costs (Menu 2.6) ........................................... 70 Network services ....................................... 72 Call diverting (Menu 3.1) ...................................... 72 Call barring (Menu 3.2) ........................................ 74 Call waiting (Menu 3.3) ........................................ 77 Network selection (Menu 3.4) ............................... 78 Caller ID (Menu 3.5) ............................................ 79 Active line (Menu 3.6) .......................................... 79 Sound settings ........................................... 80 Incoming calls (Menu 4.1) .................................... 80 Messages (Menu 4.2) ........................................... 81 Power on/off (Menu 4.3)....................................... 82 Connection tone (Menu 4.4) ................................. 82 Key tone (Menu 4.5) ............................................ 82 Minute minder (Menu 4.6) .................................... 83 Quiet mode (Menu 4.7) ........................................ 83 Alerts on call (Menu 4.8) ...................................... 84 Messages ................................................... 85 Short messages (Menu 5.1) .................................. 85 Multimedia messages (Menu 5.2) .......................... 92 Push messages (Menu 5.3) ................................. 103 Contents 5 Preset messages (Menu 5.4)............................... 104 Voice mail (Menu 5.5) ........................................ 105 Broadcast (Menu 5.6)......................................... 106 Settings (Menu 5.7) ........................................... 107 Memory status (Menu 5.8).................................. 111 Fun box .................................................... 112 WWW services (Menu 6.1) ................................. 112 Media box (Menu 6.2) ........................................ 118 JAVA world (Menu 6.3) ....................................... 121 Organiser ................................................. 126 New memo (Menu 7.1)....................................... 126 Calendar (Menu 7.2) .......................................... 128 To do list (Menu 7.3).......................................... 130 Clock (Menu 7.4) ............................................... 132 Alarm (Menu 7.5)............................................... 133 Voice recorder (Menu 7.6) ................................. 136 Calculator (Menu 7.7)......................................... 138 Conversion (Menu 7.8) ....................................... 139 Timer (Menu 7.9) ............................................... 141 Stopwatch (…

Text truncated - open the document above for the full version.















































April 4, 2005        !"# $%&' ( &) "*   +,-   . / (0+1+//2(34 (5 /5 ///5 /4(0+1+// 2( 34(5555,4  .(5(65(5 / (5 1 # )57/(5)8 )94144 *4    1    1: ;&/ 1&19<;3<4




















































April 4, 2005
!
 ""
 ""
#$%"
 &
'
()
*+  !

, !
 "-

)


 .
/01
#
 23!

.
A3LSGHE335 , $
5
 5!

1  " .


 !
6
2)
5
 ,
)(
/01
#
 2
3!
  -
 $

 5!
5

' +
7"

7"

 %
8
3

 !
*%
 %
"
5

-9
%%  2

:
! "

!  !
  "
 !
$%"
! %
 !
  !
 5 "

-

% !
6
/01
#
 2
3!
 !
-  7
% %

 5!
 !

  "
! 7
 !
 6
6  !




7
%- 2




! 7


-
5 "
6
5
  7
% !
6

/01

#
 2
3!
 !


 5 "
6  !
-
5
- 5


 "%
 !


!
5

 5 "


! "
6  !
7
 "%

 5
! 7


"+ 2







;"
<
"
=
3-
/01
#
"
0





















































































April 4, 2005

!
 ""
 ""
 #
 !
$
%
$&'"
 #
(
)*
+,  !

- !
 ".

*



 /
012
$
 %
3!%

/
A3LSGHE335 - &
5
 67 "
 5!


7
8 "


   /


 !
9
%*)
 !
%*
5
 -
*)
012
$
 %
3!%
 &
 6  "
 5!
5


'
'
:
'

'
 !
 ;
"
5

 !

 ' %

7
! "

!  !
  "
 !
&'"
! '
 !
  !
 5 "
.

' !
9
012
$
 %3!

 !

.
' '
 5!
 !

  "
! <
 !
 9
9  !




<
'. %


! <


.
5 "
9
5
  <
' !
9

012
$
 %
3!
5


 5 "
9  !
.
5
. 5


 "'
 !


!
5

 5 "


! "
9  !
<

 "'

 5
! <


", %






="
>
"
?
3.
012
$
"
1%

© 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE335 Dual-Band GSM850/GSM1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE335 Dual-Band GSM850/GSM1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE335 Dual-Band GSM850/GSM1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE335 Dual-Band GSM850/GSM1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE335 Dual-Band GSM850/GSM1900 Phone

© 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE335 Dual-Band GSM850/GSM1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE335 Dual-Band GSM850/GSM1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE335 Dual-Band GSM850/GSM1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE335 Dual-Band GSM850/GSM1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE335 Dual-Band GSM850/GSM1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE335 Dual-Band GSM850/GSM1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE335 Dual-Band GSM850/GSM1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE335 Dual-Band GSM850/GSM1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE335 Dual-Band GSM850/GSM1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE335 Dual-Band GSM850/GSM1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE335 Dual-Band GSM850/GSM1900 Phone

1 of 25 SAMSUNG ELECTRONICS Co., Ltd., Regulatory Compliance Team IT R&D Center 416, Maetan-3dong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea 442-742 TEST REPORT ON SAR Model Tested: SGH-E335 FCC ID (Requested): A3LSGHE335 Job No: FC-024 Report No: FC-024-S1 Date issued: Apr. 15, 2005 - Abstract – This document reports on SAR Tests carried out in accordance with FCC/OET Bulletin 65, Supplement C(July 2001). Prepared By Date KS AN - Test Engineer Checked By Date SH PARK – Senior Manager Authorized By Date JK CHOI - General Manager Report Number : FC-024-S1 2 of 31 Contents 1. General Information.............................................................................................3 2. Description of Device...........................................................................................3 3. Description of Test Equipment..............................................................................4 3.1 SAR Measurement Setup.........................................................................................4 3.2 DASY4 E-Field Probe.............................................................................................5 3.3 SAM Phantom.....................................................................................................6 3.4 Brain & Muscle Simulating Mixture Characterization.......................................................7 3.5 Device Holder for transmitters....................................................................................8 3.6 Validation Dipole....................................................................................................8 3.7 Equipment Calibration.............................................................................................9 4. SAR Measurement Procedure.............................................................................10 5. Description of test position..............................................................................11 5.1 SAM Phantom Shape.............................................................................................11 5.2 Cheek/Touch Position............................................................................................11 5.3 Ear/Tilt 15 Position..............................................................................................13 5.4 Body/Holster/Belt Clip Configuration..........................................................................14 6. Measurement Uncertainty...................................................................................16 7. System Verification............................................................................................18 7.1 Tissue Verification.................................................................................................18 7.2 Test System Validation...........................................................................................18 8. SAR Measurement Results.................................................................................19 8.1 Measurement Results(GSM850 Right Head SAR-Touch)............................................20 8.2 Measurement Results(GSM850 Right Head SAR-Tilt)................................................21 8.3 Measurement Results(GSM850 Left Head SAR-Touch)..............................................22 8.4 Measurement Results(GSM850 Left Head SAR-Tilt)..................................................23 8.5 Measurement Results(GSM1900 Right Head SAR-Touch)............................................24 8.6 Measurement Results(GSM1900 Right Head SAR-Tilt)................................................25 8.7 Measurement Results(GSM1900 Left Head SAR-Touch)..............................................26 8.8 Measurement Results(GSM1900 Left Head SAR-Tilt)..................................................27 8.9 Measurement Results(GPRS850 Body SAR w/o Holster)..........................................28 8.10 Measurement Results(GPRS1900 Body SAR w/o Holster)..........................................29 9. Conclusion.......................................................................................................30 10. Reference.......................................................................................................31 Report Number : FC-024-S1 3 of 31 1. GENERAL INFORMATION Test Sample : Dual-Band GSM850 / 1900 Phone Model Number : SGH-E335 Serial Number : Identical prototype (S/N : FC-024-H) Manufacturer : SAMSUNG ELECTRONICS Co., Ltd. Contact : KS KIM, Engineer Phone : +82-32-279-6046 Fax : +82-32-279-6162 Test Standard : §2.1093; FCC/OET Bulletin 65, Supplement C(July 2001) FCC Classification : Licensed Portable Transmitter Held to Ear (PCE) Test Dates : Apr. 08, 2005 - Apr. 09, 2005 Tested for : FCC/TCB Certification 2. DESCRIPTION OF DEVICE Tx Freq. Range : 824.2 – 848.8 MHz (GSM850) 1850.20 – 1909.80 MHz (GSM1900) Rx Freq. Range : 869.2 – 893.8 MHz (GSM850) 1930.20 – 1989.80 MHz (GSM1900) Max. RF Output Power : 1.020W ERP GSM850 ( 30.09dBm) 1.758 W EIRP GSM1900 (32.45 dBm) Antenna Manufacturer : TYCO ELECTRONICS Model No.: SGH-E335 Antenna Dimensions : 35.6mm 14.5mm5.5mm Report Number : FC-024-S1 4 of 31 3. DESCRIPTION OF TEST EQUIPMENT 3.1 SAR Measurement Setup Robotic System Measurements are performed using the DASY4 automated dosimetric assessment system. Which is made by Schmid & Partner Engineering AG (SPEAG) in Zurich, Switzerland and consists of high precision robotics system (Stäubli), robot controller, measurement server, Samsung computer, near- field probe, probe alignment sensor, and the SAM twin phantom containing the brain equivalent material. The robot is a six-axis industrial robot performing precise movements to position the probe to the location (points) of maximum electromagnetic field (EMF) (see Fig. 3.1). Figure 3.1 SAR Measurement System Setup System Hardware A cell controller system contains the power supply, robot controller, teach pendant (Joystick), and a remote control is used t…

Text truncated - open the document above for the full version.

SAMSUNG FCC ID : A3LSGHE335 -- 835MHz GSM850 Head SAR DUT: SGH-E335; Serial: FC-024-H Program Name: SGH-E335 GSM850 Right (Job No. : FC-024) Procedure Name: Cheek/Touch, Ch.251, Ant.Intenna, Bat.Standard Procedure Notes: Meas.Tissue Temp(celsius)-21.2; Test Date-08/April/2005 [OET Bulletin 65- Supplement C, July 2001] Communication System: GSM850; Frequency: 848.8 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 848.8 MHz; σ = 0.9 mho/m; ε r = 41.2; ρ = 1000 kg/m 3 Phantom section: Right Section DASY4 Configuration: - Probe: EX3DV4 - SN3537; ConvF(9.24, 9.24, 9.24); Calibrated: 2004-12-15 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn533; Calibrated: 2004-12-03 - Phantom: SAM 835/900 MHz; Type: SAM; Serial: TP-1141 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Cheek/Touch, Ch.251, Ant.Intenna, Bat.Standard/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 7.01 V/m; Power Drift = -0.046 dB Peak SAR (extrapolated) = 1.03 W/kg SAR(1 g) = 0.696 mW/g Maximum value of SAR (measured) = 0.749 mW/g Cheek/Touch, Ch.251, Ant.Intenna, Bat.Standard/Area Scan (51x71x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 0.782 mW/g 0 dB = 0.782mW/g SAMSUNG FCC ID : A3LSGHE335 -- 835MHz GSM850 Head SAR DUT: SGH-E335; Serial: FC-024-H Program Name: SGH-E335 GSM850 Right (Job No. : FC-024) Procedure Name: Tilted, Ch.190, Ant.Intenna, Bat.Standard Procedure Notes: Meas.Tissue Temp(celsius)-21.2; Test Date-08/April/2005 [OET Bulletin 65- Supplement C, July 2001] Communication System: GSM850; Frequency: 836.6 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 836.6 MHz; σ = 0.9 mho/m; ε r = 41.2; ρ = 1000 kg/m 3 Phantom section: Right Section DASY4 Configuration: - Probe: EX3DV4 - SN3537; ConvF(9.24, 9.24, 9.24); Calibrated: 2004-12-15 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn533; Calibrated: 2004-12-03 - Phantom: SAM 835/900 MHz; Type: SAM; Serial: TP-1141 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Tilted, Ch.190, Ant.Intenna, Bat.Standard/Area Scan (51x71x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 0.235 mW/g Tilted, Ch.190, Ant.Intenna, Bat.Standard/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 9.92 V/m; Power Drift = -0.056 dB Peak SAR (extrapolated) = 0.284 W/kg SAR(1 g) = 0.219 mW/g Maximum value of SAR (measured) = 0.231 mW/g 0 dB = 0.231mW/g SAMSUNG FCC ID : A3LSGHE335 -- 835MHz GSM850 Head SAR DUT: SGH-E335; Serial: FC-024-H Program Name: SGH-E335 GSM850 Left (Job No. : FC-024) Procedure Name: Cheek/Touch, Ch.251, Ant.Intenna, Bat.Standard Procedure Notes: Meas.Tissue Temp(celsius)-21.2; Test Date-08/April/2005 [OET Bulletin 65- Supplement C, July 2001] Communication System: GSM850; Frequency: 848.8 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 848.8 MHz; σ = 0.9 mho/m; ε r = 41.2; ρ = 1000 kg/m 3 Phantom section: Left Section DASY4 Configuration: - Probe: EX3DV4 - SN3537; ConvF(9.24, 9.24, 9.24); Calibrated: 2004-12-15 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn533; Calibrated: 2004-12-03 - Phantom: SAM 835/900 MHz; Type: SAM; Serial: TP-1141 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Cheek/Touch, Ch.251, Ant.Intenna, Bat.Standard/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 8.49 V/m; Power Drift = -0.078 dB Peak SAR (extrapolated) = 0.899 W/kg SAR(1 g) = 0.627 mW/g Maximum value of SAR (measured) = 0.664 mW/g Cheek/Touch, Ch.251, Ant.Intenna, Bat.Standard/Area Scan (51x71x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 0.679 mW/g 0 dB = 0.679mW/g SAMSUNG FCC ID : A3LSGHE335 -- 835MHz GSM850 Head SAR DUT: SGH-E335; Serial: FC-024-H Program Name: SGH-E335 GSM850 Left (Job No. : FC-024) Procedure Name: Tilted, Ch.190, Ant.Intenna, Bat.Standard Procedure Notes: Meas.Tissue Temp(celsius)-21.2; Test Date-08/April/2005 [OET Bulletin 65- Supplement C, July 2001] Communication System: GSM850; Frequency: 836.6 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 836.6 MHz; σ = 0.9 mho/m; ε r = 41.2; ρ = 1000 kg/m 3 Phantom section: Left Section DASY4 Configuration: - Probe: EX3DV4 - SN3537; ConvF(9.24, 9.24, 9.24); Calibrated: 2004-12-15 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn533; Calibrated: 2004-12-03 - Phantom: SAM 835/900 MHz; Type: SAM; Serial: TP-1141 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Tilted, Ch.190, Ant.Intenna, Bat.Standard/Area Scan (51x71x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 0.219 mW/g Tilted, Ch.190, Ant.Intenna, Bat.Standard/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 10.9 V/m; Power Drift = -0.019 dB Peak SAR (extrapolated) = 0.266 W/kg SAR(1 g) = 0.205 mW/g Maximum value of SAR (measured) = 0.215 mW/g 0 dB = 0.215mW/g SAMSUNG FCC ID : A3LSGHE335 -- 1900MHz GSM1900 Head SAR DUT: SGH-E335; Serial: FC-024-H Program Name: SGH-E335 GSM1900 Right (Job No. : FC-024) Procedure Name: Cheek/Touch, Ch.512, Ant.Intenna, Bat.Standard Procedure Notes: Meas.Tissue Temp(celsius)-21.4; Test Date-09/April/2005 [OET Bulletin 65- Supplement C, July 2001] Communication System: GSM 1900; Frequency: 1850.2 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 1850.2 MHz; σ = 1.41 mho/m; ε r = 38.5; ρ = 1000 kg/m 3 Phantom section: Right Section DASY4 Configuration: - Probe: EX3DV4 - SN3537; ConvF(8.29, 8.29, 8.29); Calibrated: 2004-12-15 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn533; Calibrated: 2004-12-03 - Phantom: SAM 1800/1900 MHz; Type: SAM; Serial: TP-1248 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Cheek/Touch, Ch.512, Ant.Intenna, Bat.Standard/Zoom Scan (5x5x7)/Cube 0: Measurement…

Text truncated - open the document above for the full version.

835MHz Brain Dipole Validation DUT: Dipole 835 MHz; Serial: 451 Program Name: 835MHz Dipole Validation 2005.04.08 Procedure Name: 835MHz @ 250mW Procedure Notes: Meas.Tissue Temp(celsius)-21.2;Test Date-08/Apr/2005 Communication System: GSM 850; Frequency: 835 MHz;Duty Cycle: 1:1 Medium parameters used: f = 835 MHz; σ = 0.9 mho/m; ε r = 41.2; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: EX3DV4 - SN3537; ConvF(9.24, 9.24, 9.24); Calibrated: 2004-12-15 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn533; Calibrated: 2004-12-03 - Phantom: SAM 835/900 MHz; Type: SAM; Serial: TP-1141 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 835MHz @ 250mW/Area Scan (51x51x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 2.69 mW/g 835MHz @ 250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 54.8 V/m; Power Drift = -0.033 dB Peak SAR (extrapolated) = 3.74 W/kg SAR(1 g) = 2.49 mW/g Maximum value of SAR (measured) = 2.68 mW/g 0 dB = 2.68mW/g 1900MHz Brain Dipole Validation DUT: Dipole 1900 MHz; Serial: 5d023 Program Name: 1900MHz Dipole Validation 2005.04.09 Procedure Name: 1900MHz @ 250mW Procedure Notes: Meas.Tissue Temp(celsius)-21.4;Test Date-09/Apr/2005 Communication System: CW; Frequency: 1900 MHz;Duty Cycle: 1:1 Medium parameters used: f = 1900 MHz; σ = 1.41 mho/m; ε r = 38.5; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: EX3DV4 - SN3537; ConvF(8.29, 8.29, 8.29); Calibrated: 2004-12-15 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn533; Calibrated: 2004-12-03 - Phantom: SAM 1800/1900 MHz; Type: SAM; Serial: TP-1143 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 1900MHz @ 250mW/Area Scan (51x51x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 17.1 mW/g 1900MHz @ 250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 91.5 V/m; Power Drift = -0.028 dB Peak SAR (extrapolated) = 19.2 W/kg SAR(1 g) = 10.3 mW/g; SAR(10 g) = 5.37 mW/g Maximum value of SAR (measured) = 11.5 mW/g 0 dB = 11.5mW/g

© 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE335 Dual-Band GSM850/GSM1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE335 Dual-Band GSM850/GSM1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE335 Dual-Band GSM850/GSM1900 Phone 1.5cm © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE335 Dual-Band GSM850/GSM1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE335 Dual-Band GSM850/GSM1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE335 Dual-Band GSM850/GSM1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE335 Dual-Band GSM850/GSM1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE335 Dual-Band GSM850/GSM1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE335 Dual-Band GSM850/GSM1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE335 Dual-Band GSM850/GSM1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE335 Dual-Band GSM850/GSM1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE335 Dual-Band GSM850/GSM1900 Phone

SAMSUNG ELECTRONICS Co., Ltd., Regulatory Compliance Group IT R&D Center 416, Maetan-3Dong, Youngtong-Gu, Suwon-city, Gyeonggi-Do, Korea 442-600 FCC CFR47 PART 22 & 24 SUBPART CERTIFICATION REPORT Model Tested: SGH-E335 FCC ID (Requested): A3LSGHE335 Report No: FC-024-R1 Job No: FC-024 Date issued: April 14,2005 - Abstract – All measurement reported herein accordance with FCC Rules, 47CFR Part2, Part22, Part24. Prepared By Date WW JANG – Test Engineer Checked By Date SH PARK - Senior Manager Authorized By Date JK CHOI – Senior Manager © Copyright SAMSUNG Electronics 2004 Report Number : FC-024-R1 TABLE OF CONTENT MEASUREMENT REPORT Page 1. FCC Certification Information 3 1.1 2.1033 General Information 3 2. INTRODUCTION 4 2.1 General 4 3. MEASURING INSTRUMENT CALIBRATION 5 4. TEST EQUIPMENT LIST 6 5. DESCRIPTION OF TESTS 7 5.1 Effective Radiated Power/Equivalent Isotropic Radiated Power 7 5.2 Radiated Spurious & Harmonic Emission 8 5.3 Occupied Bandwidth 10 5.4 Spurious and Harmonic Emissions at Antenna Terminal 10 5.4.1 Occupied Bandwidth Emission Limits 10 5.4.2 Conducted Spurious Emission 11 5.5 Frequency Stability / Temperature Variation 12 6. TEST DATA 13 6.1 Effective Radiated Power(E.R.P.) 13 6.2 Equivalent Isotropic Radiated Power(E.I.R.P.) 14 6.3 GSM850 Radiated Spurious & Harmonic Measurement 15 6.4 GSM1900 Radiated Spurious & Harmonic Measurement 16 6.5 GSM850 Radiated Spurious & Harmonic Conversion Table 17 6.6 GSM1900 Radiated Spurious & Harmonic Conversion Table 18 6.7 Frequency Stability 19 6.7.1 GSM850 Frequency Stability Table 19 6.7.2 GSM850 Frequency Stability Graph 20 6.7.3 GSM1900 Frequency Stability Table 22 6.7.4 GSM1900 Frequency Stability Graph 23 7.SAMPLE CALCULATION 25 7.1 Emission Designator 8. CONCLUSION 26 9. TEST PLOTS 27 Report Number : FC-024-R1 MEASUREMENT REPORT 1. FCC Certification Information The following information is in accordance with FCC Rules, 47CFR Rart2, Subpart J, Sections 2.1033 – 2.1055. 2.1033 General Information Applicant Name: SAMSUNG ELECRONICS CO., LTD. Address: 416, Maetan3-Dong, Yeongtong-gu, Suwon City Gyeonggi-Do, Korea 442-742 Attention: FCC ID: SungJoo KIM, Engineering Manager (QA Lab) A3LSGHE335 Quantity: Quantity production is planned Emission Designators: 250KGXW Tx Freq. Range: 824.2 - 848.8MHz (GSM850) 1850.2 -1909.8MHz (GSM1900) Rx Freq. Range: 869.2 - 893.8 MHz (GSM850) 1930.2 -1989.8 MHz (GSM1900 ) Max. Power Rating: 1.020W ERP GSM850 ( 30.09dBm) 1.758 W EIRP GSM1900 ( 32.45 dBm) FCC Classification(s): Licensed Portable Tx Held to Ear (PCE) Equipment (EUT) Type: Dual-Band GSM850/1900 Phone Modulation(s): GSM850/ GSM1900 Frequency Tolerance: 0.00025% (2.5ppm) FCC Rule Part(s): 24(E), 22(H), 2. Dates of Test: April 07, 11-14, 2005 Place of Test: SAMSUNG Lab, Test Report S/N: FC-024-R1 Report Number : FC-024-R1 2. INTRODUCTION General These measurement test were conducted at SAMSUNG ELECTRONICS CO., LTD(SUWON). The site address is 416,Maetan-3Dong, Youngtong-Gu, Suwon City, Gyeonggi-Do, KOREA 442- 600. The site have 1 Fully-anechoic chamber and measurement facility. Measurement Procedure The radiated and spurious measurements were made Fully-anechoic chamber at a 3-meter test range (see Figure2). The equipment under testing was placed on a wooden turntable 3-meters from the receive antenna. The receive antenna height and turntable rotations were adjusted for the highest reading on the receive spectrum analyzer. The substitution antenna will replace the EUT antenna it the same position and in vertical …

Text truncated - open the document above for the full version.
