SGH-E350EUser’s Guide Drive safely at all timesDo not use a hand-held phone while driving. Park the vehicle first. Switch off the phone when refuellingDo not use the phone at a refuelling point (service station) or near fuels or chemicals.Switch off in an aircraftWireless phones can cause interference. Using them in an aircraft is both illegal and dangerous.Switch off the phone near all medical equipmentHospitals or health care facilities may be using equipment that could be sensitive to external radio frequency energy. Follow any regulations or rules in force. Important safety precautions Failure to comply with the following precautions may be dangerous or illegal. Important safety precautions 1 InterferenceAll wireless phones may be subject to interference, which could affect their performance. Be aware of special regulationsMeet any special regulations in force in any area and always switch off your phone whenever it is forbidden to use it, or when it may cause interference or danger.Water resistanceYour phone is not water-resistant. Keep it dry. Sensible useUse only in the normal position (held to the ear). Avoid unnecessary contact with the antenna when the phone is switched on.Emergency callsKey in the emergency number for your present location, then press . Keep your phone away from small children Keep the phone and all its parts, including accessories, out of the reach of small children.Accessories and batteriesUse only Samsung-approved accessories and batteries. Use of any unauthorised accessories could damage your phone and may be dangerous.Qualified serviceOnly qualified service personnel may repair your phone.For more detailed safety information, see "Health and safety information" on page 87. • The phone could explode if the battery is replaced with an incorrect type. • Dispose of used batteries according to the manufacturer’s instructions. 2 About this GuideThis User’s Guide provides you with condensed information about how to use your phone. To quickly learn the basics for your ph one, please refer to “Get started” and “Step outside the phone.”In this guide, the following instruction icons appear: Indicates that you need to pay careful attention to the subsequent information regarding safety or phone features. Indicates that you can get more information on the referenced page. → Indicates that you need to press the Navigation keys to scroll to the specified option and then select it. [ ] Indicates a key on the phone. For example, [] < > Indicates a soft key, whose function is displayed on the phone screen. For example, < Menu > • Camera and camcorder Use the camera module on your phone to take a photo or record a video. Special features of your phone •MP3 player Play MP3 music files on your phone. •IrDA Send and receive Address book and Media album data via an infrared port. 3 Special features of your phone • Get personal with photo caller ID See who’s calling you when the phone displays their very own photo displays. • Name card Create name cards with your number and profile. Whenever introducing yourself to others, use this convenient electronic name card. •Web browser Access the wireless web and access various services and current information. • Multimedia message service (MMS) Send and receive MMS messages with a combination of text, image, video, and audio. •E-mail Send and receive e-mails with image, video, and audio attachments. •Java Enjoy Java ™ -based embedded games and download new games. •Calendar Keep track of your daily, weekly, and monthly schedule. • Voice recorder Record memos or sounds. 4 Contents Unpack 6 Make sure you have each itemYour phone 6 Buttons, features, and locationsGet started 7 First steps to operating your phoneInstall and charge the phone ................................... 7Power on or off ...................................................... 8Keys and display .................................................... 9Access menu functions.......................................... 11Access Home Screen menus .................................. 12Customise your phone .......................................... 12Make/Answer calls................................................ 14Step outside the phone 15 Begin with your camera, music, and other special featuresUse camera ......................................................... 15 Play MP3s............................................................ 16Play games.......................................................... 17Browse the web ................................................... 18Use Address book................................................. 18Send messages.................................................... 19View messages .................................................... 21 Enter text 22 ABC, T9, Number, and Symbol modesCall functions 24 Advanced calling featuresMenu functions 29 All menu options listedSolve problems 85 Help and personal needsHealth and safety information 87 Index 94 5 Overview of menu functions To access Menu mode, press < Menu > in Idle mode. 1 Call history p.29 1 Current contacts2 Missed calls3 Dialled calls4 Received calls5 Select and delete6 Call time7 Call costs * p.29 p.30 p.30 p.30 p.30 p.30 p.31 2 Address book p.31 1 Contact list2 FDN list3 Add new contact4 Group5 Speed dial6 My name card7 Own number8 Management9 Service number * p.31 p.32 p.33 p.33 p.34 p.34 p.35 p.35 p.36 3 Settings p.36 1 Time & Date2 Phone settings3 Display settings4 Sound settings5 Network services6 Infrared7 Security8 Memory status9 Reset settings p.36 p.36 p.37 p.38 p.40 p.42 p.43 p.44 p.44 4 Camera p.45 5 Messaging p.51 1 Create new message2 My messages3 Templates4 Select and delete5 Settings6 Broadcast messages7 Memory status p.51 p.54 p.59 p.60 p.60 p.65 p.66 6 Browser p.66 1 Home2 Bookmarks3 Go to URL4 Clear cache5 Streaming settings6 Profile settings7 Current profile p.66 p.67 p.68 p.68 p.…
Text truncated - open the document above for the full version.
June 20, 2005 !"# $%&' ( &) "* +,- . / (0+1+//2(34 (5 /5 ///5 /4(0+1+// 2( 34(5555,4 .(5(65(5 / (5 1 # )57/(5)8 )94144 *4 1 1: ;&/ 1&19<;3<4 June 20, 2005 ! "" "" #$%" & ' ()*+ ! , ! "-) . /01# 23! . A3LSGHE350E , $ 5 5! 1 " . ! 6 2) 5 , )( /01 # 2 3! - $ 5! 5 ' + 7" 7" % 8 3 !*% % " 5 -9 %% 2 : ! " ! ! " ! $%" ! % ! ! 5 " - % ! 6 /01 # 2 3! ! - 7 % % 5! ! "! 7 ! 6 6 ! 7 %- 2 ! 7 - 5 " 6 5 7 % ! 6 /01 # 23! ! 5 " 6 !- 5- 5 "% ! ! 5 5 " ! " 6 !7 "% 5 ! 7 "+ 2 ;"<" =3- /01# " 0 June 20, 2005 ! "" "" # !$ % $&'" # ( )*+, ! - ! ".* /012$ %3!% / A3LSGHE350E - & 5 67 " 5! 7 8 " / ! 9%*) !%* 5 -*)012$ %3!% & 6 " 5! 5 '' : ' ' ! ; " 5 ! ' % 7 ! " ! ! " ! &'" ! ' ! ! 5 " . ' ! 9 012 $ %3! ! . ' ' 5! ! "! < ! 9 9 ! < '. % ! < . 5 " 9 5 < ' ! 9 012 $ %3!5 5 " 9 !. 5. 5 "' ! ! 5 5 " ! " 9 !< "' 5! < ", % =">" ?3. 012$ " 1%
© 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE350E Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE350E Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE350E Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE350E Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE350E Single-Band PCS GSM Phone
3. FCC ID Label Location
© 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE350E Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE350E Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE350E Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE350E Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE350E Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE350E Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE350E Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE350E Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE350E Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE350E Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE350E Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE350E Single-Band PCS GSM Phone
1 of 39 SAMSUNG ELECTRONICS Co., Ltd., Regulatory Compliance Group IT R&D Center 416, Maetan-3dong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea 443-742 TEST REPORT ON SAR Model Tested: SGH-E350E FCC ID (Requested): A3LSGHE350E Job No: FC-073 Report No: FC-073-S1 Date issued: May. 31, 2005 - Abstract – This document reports on SAR Tests carried out in accordance with FCC/OET Bulletin 65, Supplement C(July 2001). Prepared By Date KS AN – Test Engineer Checked By Date SH PARK – Senior Manager Authorized By Date JK CHOI – General Manager 2005.06.09 2005.06.09 2005.06.09 Report Number : FC-073-S1 2 of 39 Contents 1. General Information...........................................................................................................3 2. Description of Device.........................................................................................................3 3. Description of Test Equipment.............................................................................................4 3.1 SAR Measurement Setup...........................................................................................................4 3.2 DASY4 E-Field Probe................................................................................................................5 3.3 SAM Phantom..........................................................................................................................6 3.4 Brain & Muscle Simulating Mixture Characterization.........................................................................7 3.5 Device Holder for transmitters......................................................................................................8 3.6 Validation Dipole.......................................................................................................................8 3.7 Equipment Calibration...............................................................................................................9 4. SAR Measurement Procedure............................................................................................10 5. Description of test position...............................................................................................11 5.1 SAM Phantom Shape...............................................................................................................11 5.2 Cheek/Touch Position...............................................................................................................11 5.3 Ear/Tilt 15° Position.................................................................................................................13 5.4 Body/Leather Configuration.......................................................................................................14 6. Measurement Uncertainty.................................................................................................16 7. System Verification............................................................................................................17 7.1 Tissue Verification....................................................................................................................17 7.2 Test System Validation.............................................................................................................17 8. SAR Measurement Results...............................................................................................18 8.1 Measurement Results(GSM1900 Right Head SAR-Touch)...............................................................19 8.2 Measurement Results(GSM1900 Right Head SAR-Tilt)...................................................................20 8.3 Measurement Results(GSM1900 Left Head SAR-Touch).................................................................21 8.4 Measurement Results(GSM1900 Left Head SAR-Tilt).....................................................................22 8.5 Measurement Results(GPRS1900 Body SAR w/o Holster)..............................................................23 9. Conclusion...................................................................................................................24 10. Reference...................................................................................................................25 Report Number : FC-073-S1 3 of 39 1. GENERAL INFORMATION Test Sample : Single-Band PCS GSM Phone Model Number : SGH-E350E Serial Number : Identical prototype (S/N : # FC-073-A ) Manufacturer : SAMSUNG ELECTRONICS Co., Ltd. Contact : BK CHA, Engineer Phone : +82-31-279-6046 Fax : +82-31-279-6162 Test Standard : §2.1093; FCC/OET Bulletin 65, Supplement C(July 2001) FCC Classification : Licensed Portable Transmitter Held to Ear (PCE) Test Dates : May. 20, 2005 Tested for : FCC/TCB Certification 2. DESCRIPTION OF DEVICE Tx Freq. Range : 1850.00 – 1910.00 MHz (GSM1900) Rx Freq. Range : 1930.00 – 1990.00 MHz (GSM1900) Max. RF Output Power : 0.906 W EIRP CDMA (29.57 dBm) Antenna Manufacturer : Samsung Electro-Mechanics Model No.: EWPADF013A Antenna Dimensions : Length = 18.55mm * 33.18mm * 8.7 Report Number : FC-073-S1 4 of 39 3. DESCRIPTION OF TEST EQUIPMENT 3.1 SAR Measurement Setup Robotic System Measurements are performed using the DASY4 automated dosimetric assessment system. Which is made by Schmid & Partner Engineering AG (SPEAG) in Zurich, Switzerland and consists of high precision robotics system (Stäubli), robot controller, measurement server, Samsung computer, near- field probe, probe alignment sensor, and the SAM twin phantom containing the brain equivalent material. The robot is a six-axis industrial robot performing precise movements to position the probe to the location (points) of maximum electromagnetic field (EMF) (see Fig. 3.1). Figure 3.1 SAR Measurement System Setup System Hardware A cell controller system contains the power supply, robot controller, teach pendant (Joystick), and a remote control is used to drive the robot motors. The PC consists of the Samsung compu…
Text truncated - open the document above for the full version.
APPENDIX G Plots of The SAR Measurements SAMSUNG FCC ID : A3LSGHE350E 1900MHz GSM1900 Head SAR DUT: SGH-E350E (Down); Serial: FC-073-A Program Name: SGH-E350E GSM1900 Right (Slide.Down, Job No. : FC-073) Procedure Name: Cheek/Touch, Ch.810, Ant.Intenna, Bat.Standard Procedure Notes: Meas.Tissue Temp(celsius)-21.9; Test Date-20/May/2005 [OET Bulletin 65- Supplement C, July 2001] Communication System: GSM 1900; Frequency: 1909.8 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 1909.8 MHz; σ = 1.38 mho/m; ε r = 38.5; ρ = 1000 kg/m 3 Phantom section: Right Section DASY4 Configuration: - Probe: EX3DV4 - SN3537; ConvF(8.29, 8.29, 8.29); Calibrated: 2004-12-15 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn468; Calibrated: 2004-12-07 - Phantom: SAM 1800/1900 MHz; Type: SAM; Serial: TP-1248 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Cheek/Touch, Ch.810, Ant.Intenna, Bat.Standard/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 8.71 V/m; Power Drift = 0.033 dB Peak SAR (extrapolated) = 0.922 W/kg SAR(1 g) = 0.476 mW/g Maximum value of SAR (measured) = 0.548 mW/g Cheek/Touch, Ch.810, Ant.Intenna, Bat.Standard/Area Scan (51x71x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 0.449 mW/g 0 dB = 0.449mW/g SAMSUNG FCC ID : A3LSGHE350E 1900MHz GSM1900 Head SAR DUT: SGH-E350E (Up); Serial: FC-073-A Program Name: SGH-E350E GSM1900 Right (Slide.Up, Job No. : FC-073) Procedure Name: Ear/Tilt, Ch.661, Ant.Intenna, Bat.Standard Procedure Notes: Meas.Tissue Temp(celsius)-21.9; Test Date-20/May/2005 [OET Bulletin 65- Supplement C, July 2001] Communication System: GSM 1900; Frequency: 1880 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 1880 MHz; σ = 1.38 mho/m; ε r = 38.5; ρ = 1000 kg/m 3 Phantom section: Right Section DASY4 Configuration: - Probe: EX3DV4 - SN3537; ConvF(8.29, 8.29, 8.29); Calibrated: 2004-12-15 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn468; Calibrated: 2004-12-07 - Phantom: SAM 1800/1900 MHz; Type: SAM; Serial: TP-1248 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Ear/Tilt, Ch.661, Ant.Intenna, Bat.Standard/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 8.91 V/m; Power Drift = -0.020 dB Peak SAR (extrapolated) = 0.233 W/kg SAR(1 g) = 0.152 mW/g Maximum value of SAR (measured) = 0.165 mW/g Ear/Tilt, Ch.661, Ant.Intenna, Bat.Standard/Area Scan (51x71x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 0.190 mW/g 0 dB = 0.190mW/g SAMSUNG FCC ID : A3LSGHE350E 1900MHz GSM1900 Head SAR DUT: SGH-E350E (Down); Serial: FC-073-A Program Name: SGH-E350E GSM1900 Left (Slide.Down, Job No. : FC-073) Procedure Name: Cheek/Touch, Ch.810, Ant.Intenna, Bat.Standard Procedure Notes: Meas.Tissue Temp(celsius)-21.9; Test Date-20/May/2005 [OET Bulletin 65- Supplement C, July 2001] Communication System: GSM 1900; Frequency: 1909.8 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 1909.8 MHz; σ = 1.38 mho/m; ε r = 38.5; ρ = 1000 kg/m 3 Phantom section: Left Section DASY4 Configuration: - Probe: EX3DV4 - SN3537; ConvF(8.29, 8.29, 8.29); Calibrated: 2004-12-15 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn468; Calibrated: 2004-12-07 - Phantom: SAM 1800/1900 MHz; Type: SAM; Serial: TP-1248 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Cheek/Touch, Ch.810, Ant.Intenna, Bat.Standard/Area Scan (51x71x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 0.333 mW/g Cheek/Touch, Ch.810, Ant.Intenna, Bat.Standard/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 8.27 V/m; Power Drift = 0.104 dB Peak SAR (extrapolated) = 0.615 W/kg SAR(1 g) = 0.343 mW/g Maximum value of SAR (measured) = 0.366 mW/g 0 dB = 0.366mW/g SAMSUNG FCC ID : A3LSGHE350E 1900MHz GSM1900 Head SAR DUT: SGH-E350E (Up); Serial: FC-073-A Program Name: SGH-E350E GSM1900 Left (Slide.Up, Job No. : FC-073) Procedure Name: Ear/Tilt, Ch.661, Ant.Intenna, Bat.Standard Procedure Notes: Meas.Tissue Temp(celsius)-21.9; Test Date-20/May/2005 [OET Bulletin 65- Supplement C, July 2001] Communication System: GSM 1900; Frequency: 1880 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 1880 MHz; σ = 1.38 mho/m; ε r = 38.5; ρ = 1000 kg/m 3 Phantom section: Left Section DASY4 Configuration: - Probe: EX3DV4 - SN3537; ConvF(8.29, 8.29, 8.29); Calibrated: 2004-12-15 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn468; Calibrated: 2004-12-07 - Phantom: SAM 1800/1900 MHz; Type: SAM; Serial: TP-1248 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Ear/Tilt, Ch.661, Ant.Intenna, Bat.Standard/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 8.16 V/m; Power Drift = 0.057 dB Peak SAR (extrapolated) = 0.175 W/kg SAR(1 g) = 0.116 mW/g Maximum value of SAR (measured) = 0.122 mW/g Ear/Tilt, Ch.661, Ant.Intenna, Bat.Standard/Area Scan (51x71x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 0.127 mW/g 0 dB = 0.127mW/g SAMSUNG FCC ID : A3LSGHE350E 1900MHz GSM1900 Body SAR DUT: SGH-E350E (Down); Serial: FC-073-A Program Name: SGH-E350E GSM1900 Body (Job No. : FC-061) Procedure Name: Body, Ch.512, Ant.Intenna, Bat.Standard Procedure Notes: Meas.Tissue Temp(celsius)-21.9;Test Date-20/May/2005[OET Bulletin 65- Supplement C, July 2001] Communication System: Body GPRS ; Frequency: 1850.2 MHz;Duty Cycle: 1:4.15 Medium parameters used: f = 1850.2 MHz; σ = 1.53 mho/m; ε r = 51.6; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: EX3DV4 - SN3537; ConvF(7.76, 7.76, 7.76); Calibrated: 2004-12-15 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn468; Calibrated: 2004-12-07 - Phantom: SAM 1800/1900 MHz; Type: SAM; Serial: TP-1248 - Measurement SW: DASY4, V…
Text truncated - open the document above for the full version.
APPENDIX H Probe Calibration
APPENDIX F The Validation Measurements SAMSUNG FCC ID : A3LSGHE350E 1900MHz GSM1900 Head SAR DUT: Dipole 1900 MHz; Serial: 5d023 Program Name: 1900 Dipole Validation 2005.05.20 Procedure Name: 1900MHz @250mW Procedure Notes: Communication System: CW; Frequency: 1900 MHz;Duty Cycle: 1:1 Medium parameters used: f = 1900 MHz; σ = 1.38 mho/m; ε r = 38.5; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: EX3DV4 - SN3537; ConvF(8.29, 8.29, 8.29); Calibrated: 2004-12-15 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn468; Calibrated: 2004-12-07 - Phantom: SAM 1800/1900 MHz; Type: SAM; Serial: TP-1248 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 1900MHz @250mW/Area Scan (51x51x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 16.1 mW/g 1900MHz @250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 91.2 V/m; Power Drift = -0.103 dB Peak SAR (extrapolated) = 18.8 W/kg SAR(1 g) = 10 mW/g Maximum value of SAR (measured) = 11.2 mW/g 0 dB = 11.2mW/g
APPENDIX I Calibration of The Validation Dipole
SAMSUNG ELECTRONICS Co., Ltd., Regulatory Compliance Group IT R&D Center 416 Maetan3-Dong, Yeongtong-gu, Suwon city, Gyeonggi-Do, Korea 442-742 FCC CFR47 PART 24 SUBPART CERTIFICATION REPORT Model Tested: SGH-E350E FCC ID (Requested): A3LSGHE350E Report No: FC-073-R1 Job No: FC-073 Date issued: May 31,2005 - Abstract – All measurement reported herein accordance with FCC Rules, 47CFR Part2, Part24. Prepared By Date YE PARK – Test Engineer Checked By Date SH PARK – Senior Manager Authorized By Date JK CHOI – General Manager © Copyright SAMSUNG Electronics 2005 Report Number : FC-073-R1 TABLE OF CONTENT MEASUREMENT REPORT Page 1. FCC Certification Information 3 1.1 2.1033 General Information 3 2. INTRODUCTION 4 2.1 General 4 3. MEASURING INSTRUMENT CALIBRATION 5 4. TEST EQUIPMENT LIST 6 5. DESCRIPTION OF TESTS 7 5.1 Equivalent Isotropic Radiated Power 7 5.2 Radiated Spurious & Harmonic Emission 8 5.3 Occupied Bandwidth 9 5.4 Spurious and Harmonic Emissions at Antenna Terminal 9 5.4.1 Occupied Bandwidth Emission Limits 9 5.4.2 Conducted Spurious Emission 11 5.5 Frequency Stability / Temperature Variation 13 6. TEST DATA 14 6.1 Equivalent Isotropic Radiated Power (E.I.R.P.) 14 6.2 Radiated Spurious & Harmonic Measurement 15 6.3 Radiated Spurious & Harmonic Conversion Table 16 6.4 Frequency Stability 17 6.4.1 Frequency Stability Table 17 6.4.2 Frequency Stability Graph 18 7. CONCLUSION 20 8. TEST PLOTS 21 Report Number : FC-073-R1 MEASUREMENT REPORT 1. FCC Certification Information The following information is in accordance with FCC Rules, 47CFR Part2, Subpart J, Sections 2.1033 – 2.1055. 2.1033 General Information Applicant Name: SAMSUNG ELECRONICS CO., LTD. Address: 416 Maetan3-Dong, Yeongtong-gu, Suwon City Gyeonggi-Do, Korea 442-742 Attention: FCC ID: SungJoo KIM, Engineering Manager (QA Lab) A3LSGHE350E Quantity: Quantity production is planned Emission Designators: 300KG7W Tx Freq. Range: 1850.2MHz -1909.8MHz Rx Freq. Range: 1930.2MHz – 1989.8MHz Max. Power Rating: 0.906W EIRP GSM1900 (29.57dBm) FCC Classification(s): Licensed Portable Tx Held to Ear (PCE) Equipment (EUT) Type: Single-Band PCS GSM Phone Frequency Tolerance: 0.00025% (2.5ppm) FCC Rule Part(s): 24(E), Dates of Test: May 19,24-26 , 2005 Place of Test: SAMSUNG Lab, Test Report S/N: FC-073-R1 - End of page - Report Number : FC-073-R1 2. INTRODUCTION General These measurement test were conducted at SAMSUNG ELECTRONICS CO., LTD(SUWON). The site address is 416 Maetan3-Dong, Yeongtong-gu, Suwon City, Gyeonggi-Do, Korea 442-742 The site have 1 Fully-anechoic chamber and measurement facility. Measurement Procedure The radiated and spurious measurements were made Fully-anechoic chamber at a 3-meter test range (see Figure2). The equipment under testing was placed on a Non-conducted turntable 3- meters from the receive antenna. The receive antenna height and turntable rotations were adjusted for the highest reading on the receive spectrum analyzer. The substitution antenna will replace the EUT antenna it the same position and in vertical polarization. The frequency of the signal generator shall be set to the frequencies that were measured on the EUT. The test antenna shall be raised and lowered, if necessary, to ensure that the maximum signal is still being received. The signal generator, output level, shall be adjusted until an equal or a known related level to what was measured from the EUT is obtained in the spectrum analyzer. This level was recorded. For readings above 1 GHz, the above procedure is repeated using horn antennas and the difference between the gain of the horn and an isotropic antenna are taken into consideration. Figure1. Map of the Suwon City area. Fi gure2. Photograph of 3m Fully-Anechoic Chamber Report Number : FC-073-R1 3. MEASURING INSTRUMENT CALIBRATION The measuring equipment, which was utilized in performing the tests documented herein, has been calibrated in accordance with the manufacturer’s recommendations for utilizing calibration equipment, which is traceable to recognized national standards. - End of page - Report Number : FC-073-R1 4. TEST EQUIPMENT LIST Name of Equipment Model Serial No. Due Date ESI26 836119/010 2005-09-20 E4440A(3Hz~26.5GHz) MY41000236 2005-10-27 Spectrum Analyzer E4440A(3Hz~26.5GHz) MY41000233 2005-11-04 SMIQ03B 83824/021 2005-12-27 Signal Generator SMR20 835197/030 2006-01-18 Power Meter E4419B GB41293846 2005-09-21 8481B 3318A10325 2005-10-06 Power Sensor 8485A 3318A19924 2005-09-20 Amplifier 5S1G4 304866 2005-10-19 Pre-Amplifier 8449B 3008A00691 2006-01-11 8960 GB42230535 2005-11-04 Communication test set 8960 GB42360886 2005-10-27 Antenna Master MA0001 ANT0967 Not Required Controller HD100 100/756 Not Required PL-4S 13005454 2005-07-31 SH-241 92000548 2005-11-22 Environmental Chamber SH-241 92000549 2005-11-22 HF906 360306/011 2006-03-17 Horn Antenna HF906 100134 2006-04-25 Dipole Antenna 3121C-DB4 9007-587 2005-12-02 HL040 353255/019 2005-08-13 Receive Antenna HL040 353255/020 2005-06-07 8494A 3308A31997 2006-01-03 Attenuator 8496A 3308A14426 2006-01-04 11636B 51941 Not Required 11636B 51942 Not Required Divider 11636B 51946 Not Required WHK1.0/15G-10SS 1 Not Required WHK1.0/15G-10SS 1 Not Required WHK/3.5/18G-10SS 3 Not Required High Pass Filter WHK/3.5/18G-10SS 4 Not Required Shielded Fully Anechoic Chamber RF0002 ANT0001 Not Required Report Number : FC-073-R1 5. DESCRIPTION OF TESTS 5.1 Equivalent Isotropic Radiated Power Test Set-up for the EIRP TEST Effective Radiated Power Output and Equivalent Isotropic Radiated Power Measurements by Substitution Method according to ANSI/TIA/EIA-603-A-2001, Aug. 15, 2001: The EUT was placed on a Non-conduct…
Text truncated - open the document above for the full version.
6660-B Dobbin Road · Columbia, Maryland · United States
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|---|---|---|---|---|
| 1 | 24E | 1.85 GHz - 1.91 GHz | 906.00 mW | 300KG7W | 2.5000000000 ppm |
