A3LSGHF110Cellular/PCS GSM/EDGE Phone w/ BT and Low-power Tx

Samsung Electronics Co Ltd

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Nov 01, 2007
Application Purpose: Original Equipment
Date of Application: Nov 01, 2007
Equipment Note: Cellular/PCS GSM/EDGE Phone w/ BT and Low-power Tx
Frequency Range: 1850.20000000 - 1909.80000000
Company: Samsung Electronics Co Ltd
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

* Depending on the software installed or your service provider or country, some of the descriptions in this guide may not match your phone exactly. * Depending on your country, your phone and accessories may appear different from the illustrations in this guide.World Wide Webhttp://www.samsungmobile.com Printed in Korea Code No.:GH68-XXXXXA English (EU). 09/2007. Rev. 1.0 SGH-F110User’s Guide D r a f t _ 3 r d 2 0 0 7 . 0 9 . 0 5 ( V e r s i o n : F 1 1 0 X A G H 5 ) Important safety precautions Drive safely at all timesDo not use a hand-held phone while driving. Park your vehicle first. Switch off the phone when refuellingDo not use the phone at a refuelling point (service station) or near fuels or chemicals.Switch off in an aircraftWireless phones can cause interference. Using them in an aircraft is both illegal and dangerous.Switch off the phone near all medical equipmentHospitals or health care facilities may be using equipment that could be sensitive to external radio frequency energy. Follow any regulations or rules in force. InterferenceAll wireless phones may be subject to interference, which could affect their performance. Failure to comply with the following precautions may be dangerous or illegal. Copyright information• Bluetooth ® is a registered trademark of the Bluetooth SIG, Inc. worldwide. Bluetooth QD ID: B0XXXXX •Java TM is a trademark or registered trademark of Sun Microsystems, Inc. • Windows Media Player ® is a registered trademark of Microsoft Corporation. 1 Be aware of special regulationsMeet any special regulations in force in any area and always switch off your phone whenever it is forbidden to use it, or when it may cause interference or danger.Water resistanceYour phone is not water-resistant. Keep it dry.Sensible useUse only in the normal position (held to your ear). Avoid unnecessary contact with the antenna when the phone is switched on.Emergency callsKey in the emergency number for your present location, then press . Keep your phone away from small children Keep the phone and all its parts, including accessories, out of the reach of small children. Accessories and batteriesUse only Samsung-approved batteries and accessories, such as headsets and PC data cables. Use of any unauthorised accessories could damage you or your phone and may be dangerous.Qualified serviceOnly qualified service personnel may repair your phone.For more detailed safety information, see "Health and safety information" on page 44. • The phone could explode if the battery is replaced with an incorrect type. • Dispose of used batteries according to the manufacturer’s instructions. At very high volumes, prolonged listening to a headset can damage your hearing. 2 About this GuideThis User’s Guide provides you with condensed information about how to use your phone.In this guide, the following instruction icons appear: Indicates that you need to pay careful attention to the subsequent information regarding safety or phone features. → Indicates that you need to press the Navigation keys to scroll to the specified option and then select it. [ ] Indicates a key on the phone. For example, [ ] < > Indicates a soft key, whose function is displayed on the phone screen. For example, < Menu > • Workout assistant Work out with the virtual assistant and special adidas gear to train your body more effectively. Special features of your phone • Camera and camcorder Use the camera module on your phone to take a photo or record a video. •Synchronisation with Windows Media Player Transfer music files to your phone directly from the Windows Media Player. 3 • Music player Play music files using your phone as a music player. You can use other phone functions while listening to music. •FM radio Listen to your favourite radio stations anytime, anywhere. •Image editor Crop, resize, rotate, and decorate your photos. • Digital data printing Print images, messages, and other personal data directly from your phone. •Offline mode Switch your phone to use its none-wireless functions in an airplane. • Bluetooth Transfer media files and personal data and connect to other devices using free, wireless Bluetooth technology. •Email Send and receive emails with image, video, and audio attachments. •SOS message Send SOS message to your family or friends for help in an emergency. 4 Contents Unpack 6 Make sure you have each itemGet started 6 First steps to operating your phoneAssemble and charge the phone ..................... 6Power on or off.............................................. 7Your phone ................................................... 8Keys and icons .............................................. 9Access menu functions .................................. 13Enter text .................................................... 13Customise your phone ................................... 15Step outside the phone 17 Begin with call functions, camera, music player, web browser, and other special featuresMake or answer calls ..................................... 17Train with miCoach ....................................... 19 Use the camera............................................ 22Play music................................................... 23Listen to the FM radio ................................... 26Browse the web ........................................... 27Use Phonebook ............................................ 28Send messages ............................................ 29View messages ............................................ 31Use Bluetooth .............................................. 32 Menu functions 34 All menu options listedHealth and safety information 44 5 1 Call log1 Recent contacts2 Missed calls3 Dialled calls4 Received calls5 Delete all6 Call manager2 Phonebook3 Music4 Browser1 Home2 Enter URL3 Bookmarks4 Saved Pages5 History6 Browser settings 5 Messages1 Create new message2 My messages3 Templates4 Delete all5 Settings6 SOS messages7 Broadcast messages8 Memory status6 My filesImagesVideosSoundsMus…

Text truncated - open the document above for the full version.

Cover Letter(s)

SAMSUNG ELECTRONICS AMERICA, INC. American QA Lab 18600 Broadwick St. Rancho Dominguez, CA 90220 Date: October 11, 2007 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, http Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: A3LSGHF110 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, SAMSUNG ELECTRONICS CO.,LTD. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give SAMSUNG ELECTRONICS CO.,LTD. temporary confidentiality of commercially sensitive information prior to product release. The requested Confidential and Temporary Confidential exhibits are listed as follows: CONFIDENTIAL AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Operational Description 3 Schematics CONFIDENTIAL 4 Parts List & Tune-Up Procedure 5 External Photos 6 Internal Photos 7 Test-Setup Photos SHORT-TERM CONFIDENTIAL 8 Users Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Steve Kim General Manager American QA Lab SAMSUNG Electronics America INC.

External Photos

ID Label/Location Info

SGH-F110 A3LSGHF110 -F110GSMH 800 SGH-F110 A3LSGHF110 -F110GSMH 800

Internal Photos

SAMSUNG FCC ID: A3LSGHF110 EUT Photographs © 2007 PCTEST Lab. 850/1900 GSM/GPRS/EDGE Phone with Bluetooth Model: SGH-F110 SAMSUNG FCC ID: A3LSGHF110 EUT Photographs © 2007 PCTEST Lab. 850/1900 GSM/GPRS/EDGE Phone with Bluetooth Model: SGH-F110 SAMSUNG FCC ID: A3LSGHF110 EUT Photographs © 2007 PCTEST Lab. 850/1900 GSM/GPRS/EDGE Phone with Bluetooth Model: SGH-F110 SAMSUNG FCC ID: A3LSGHF110 EUT Photographs © 2007 PCTEST Lab. 850/1900 GSM/GPRS/EDGE Phone with Bluetooth Model: SGH-F110 SAMSUNG FCC ID: A3LSGHF110 EUT Photographs © 2007 PCTEST Lab. 850/1900 GSM/GPRS/EDGE Phone with Bluetooth Model: SGH-F110 SAMSUNG FCC ID: A3LSGHF110 EUT Photographs © 2007 PCTEST Lab. 850/1900 GSM/GPRS/EDGE Phone with Bluetooth Model: SGH-F110 SAMSUNG FCC ID: A3LSGHF110 EUT Photographs © 2007 PCTEST Lab. 850/1900 GSM/GPRS/EDGE Phone with Bluetooth Model: SGH-F110 SAMSUNG FCC ID: A3LSGHF110 EUT Photographs © 2007 PCTEST Lab. 850/1900 GSM/GPRS/EDGE Phone with Bluetooth Model: SGH-F110 SAMSUNG FCC ID: A3LSGHF110 EUT Photographs © 2007 PCTEST Lab. 850/1900 GSM/GPRS/EDGE Phone with Bluetooth Model: SGH-F110

RF Exposure Info

Reviewed by: FCC ID: A3LSGHF110 CERTIFICATION REPORT Quality Manager SAR Filename: Test Dates: EUT Type: 0710121195.A3L 10/18/07 - 10/20/07 850/1900 GSM/GPRS/EDGE Phone with Bluetooth Page 1 of 23 © 2007 PCTEST Engineering Laboratory, Inc. REV 4.3G 03/22/07 Applicant Name: Date of Testing: Samsung Electronics, Co. Ltd. 10/18/07 - 10/20/07 18600 Broadwick St. Test Site/Location: Rancho Dominguez, CA 90220 PCTEST Lab, Columbia, MD, USA United States Test Report Serial No.: 0710121195.A3L FCC ID: A3LSGHF110 APPLICANT: SAMSUNG ELECTRONICS, CO. LTD. EUT Type: 850/1900 GSM/GPRS/EDGE Phone with Bluetooth Application Type: Certification FCC Rule Part(s): §2.1093; FCC/OET Bulletin 65 Supplement C [July 2001] FCC Classification: Licensed Transmitter Held to Ear (PCE) Model(s): SGH-F110 Tx Frequency: 824.20 - 848.80 MHz (Cellular GSM) 1850.20 - 1909.80 MHz (GSM PCS) Conducted Power: 32.56 dBm GSM / 29.78 dBm PCS Max. SAR Measurement: 0.286 W/kg GSM850 Head SAR / 1.46 W/kg GPRS850 Body SAR 0.481 W/kg GSM1900 Head SAR / 1.35 W/kg GPRS1900 Body SAR Test Device Serial No.: Pre-Production [S/N: FE-165-P] This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-2005 and has been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. 1528-2003. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant Conditions: Power output listed is ERP for Part 22 and EIRP for Part 24. SAR compliance for body-worn operating configuration is based on a separation distance of 1.5 cm between the back of the unit and the body of the user or with the specific body-worn accessory in this filing. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. Belt clips or holsters not specified in this filing may not contain metallic components. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) Reviewed by: FCC ID: A3LSGHF110 CERTIFICATION REPORT Quality Manager SAR Filename: Test Dates: EUT Type: 0710121195.A3L 10/18/07 - 10/20/07 850/1900 GSM/GPRS/EDGE Phone with Bluetooth Page 2 of 23 © 2007 PCTEST Engineering Laboratory, Inc. REV 4.3G 03/22/07 TABLE OF CONTENTS 1 INTRODUCTION ........................................................................................................................ 3 2 TEST SITE LOCATION............................................................................................................... 4 3 SAR MEASUREMENT SETUP ................................................................................................... 5 4 DASY E-FIELD PROBE SYSTEM............................................................................................... 7 5 PROBE CALIBRATION PROCESS............................................................................................. 8 6 PHANTOM AND EQUIVALENT TISSUES .................................................................................. 9 7 DOSIMETRIC ASSESSMENT & PHANTOM SPECS................................................................ 10 8 DEFINITION OF REFERENCE POINTS ................................................................................... 11 9 TEST CONFIGURATION POSITIONS ...................................................................................... 12 10 ANSI/IEEE C95.1-2005 RF EXPOSURE LIMITS...................................................................... 14 11 MEASUREMENT UNCERTAINTIES......................................................................................... 15 12 SYSTEM VERIFICATION ......................................................................................................... 16 13 SAR DATA SUMMARY............................................................................................................. 17 14 EQUIPMENT LIST.................................................................................................................... 20 15 CONCLUSION.......................................................................................................................... 21 16 REFERENCES ......................................................................................................................... 22 Reviewed by: FCC ID: A3LSGHF110 CERTIFICATION REPORT Quality Manager SAR Filename: Test Dates: EUT Type: 0710121195.A3L 10/18/07 - 10/20/07 850/1900 GSM/GPRS/EDGE Phone with Bluetooth Page 3 of 23 © 2007 PCTEST Engineering Laboratory, Inc. REV 4.3G 03/22/07 1 INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radio frequency (RF) radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-2005 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. (c) 2005 by the Institute of Electrical and Electronics Engineers, Inc., New York, New York 10017.[2] The measurement procedure described in IEEE/ANSI C95.3-2002 Recommended Practice for the Measurement of …

Text truncated - open the document above for the full version.

Test Report

Reviewed by: FCC ID: A3LSGHF110 FCC Pt. 22/24 GSM / EDGE MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0710121194.A3L October 15, 2007 850/1900 GSM/GPRS/EDGE Phone with Bluetooth Page 1 of 1 © 2007 PCTEST Engineering Laboratory, Inc. REV 6.0G 10/09/07 Applicant Name: Date of Testing: Samsung Electronics, Co. Ltd. October 15, 2007 18600 Broadwick St. Test Site/Location: Rancho Dominguez, CA 90220 PCTEST Lab, Columbia, MD, USA United States Test Report Serial No.: 0710121194.A3L FCC ID: A3LSGHF110 APPLICANT: SAMSUNG ELECTRONICS, CO. LTD. Application Type: Certification FCC Classification: PCS Licensed Transmitter Held to Ear (PCE) FCC Rule Part(s): §2; §22(H), §24(E) EUT Type: 850/1900 GSM/GPRS/EDGE Phone with Bluetooth Model(s): SGH-F110 Tx Frequency Range: 824.20 - 848.80MHz (Cell. GSM) / 1850.20 - 1909.80MHz (PCS GSM) Max. RF Output Power: 1.143 W ERP Cell. GSM (30.58 dBm) / 0.914 W EIRP PCS GSM (29.61 dBm) 0.753 W ERP EDGE850 (28.77 dBm) / 0.526 W EIRP EDGE1900 (27.21 dBm) Emission Designator(s): 247KGXW (Cellular GSM), 262KGXW (PCS GSM) / 240KG7W (EDGE850), 239KG7W (EDGE1900) Test Device Serial No.: identical prototype [S/N: FE-165-P] This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in §2.947. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant Conditions: Power output listed is ERP for Part 22 and EIRP for Part 24. This device also contains functions that are not operational in U.S. territories. This report is applicable only to U.S. operations. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE FCC Part 22 & 24 Certification Reviewed by: FCC ID: A3LSGHF110 FCC Pt. 22/24 GSM / EDGE MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0710121194.A3L October 15, 2007 850/1900 GSM/GPRS/EDGE Phone with Bluetooth Page 2 of 2 © 2007 PCTEST Engineering Laboratory, Inc. REV 6.0G 10/09/07 TABLE OF CONTENTS FCC PART 22 & 24 MEASUREMENT REPORT............................................................................3 1.0 INTRODUCTION ..............................................................................................................................4 1.1 MEASUREMENT PROCEDURE......................................................................................................... 4 1.2 SCOPE ................................................................................................................................................ 4 1.3 TESTING FACILITY............................................................................................................................. 4 2.0 PRODUCT INFORMATION..............................................................................................................5 2.1 EQUIPMENT DESCRIPTION .............................................................................................................. 5 2.2 EMI SUPPRESSION DEVICE(S)/MODIFICATIONS ........................................................................... 5 2.3 LABELING REQUIREMENTS.............................................................................................................. 5 3.0 DESCRIPTION OF TESTS ..............................................................................................................6 3.1 OCCUPIED BANDWIDTH EMISSION LIMITS .................................................................................... 6 3.2 CELLULAR - BASE FREQUENCY BLOCKS....................................................................................... 6 3.3 CELLULAR - MOBILE FREQUENCY BLOCKS ................................................................................... 6 3.4 PCS - BASE FREQUENCY BLOCKS .................................................................................................. 7 3.5 PCS - MOBILE FREQUENCY BLOCKS .............................................................................................. 7 3.6 SPURIOUS AND HARMONIC EMISSIONS AT ANTENNA TERMINAL.............................................. 7 3.7 RADIATED SPURIOUS AND HARMONIC EMISSIONS ..................................................................... 7 3.8 FREQUENCY STABILITY / TEMPERATURE VARIATION ................................................................. 8 4.0 TEST EQUIPMENT CALIBRATION DATA ......................................................................................9 5.0 SAMPLE CALCULATIONS ............................................................................................................10 6.0 TEST RESULTS .............................................................................................................................11 6.1 SUMMARY......................................................................................................................................... 11 6.2 CONDUCTED OUTPUT POWER ...................................................................................................... 12 6.3 EFFECTIVE RADIATED POWER OUTPUT DATA ........................................................................... 13 6.4 EQUIVALENT ISOTROPIC RADIATED POWER OUTPUT DATA .................................................... 14 6.5 CELLULAR GSM RADIATED MEASUREMENTS ............................................................................. 15 6.6 …

Text truncated - open the document above for the full version.

Test Setup Photos

SAMSUNG FCC ID: A3LSGHF110 Model: SGH-F110 SAR Test Setup Photos 850/1900 GSM/GPRS/EDGE Phone With Bluetooth Page 1 of 8 © 2007 PCTEST Lab. REV 2.1 05/24/2007 1. Right Head SAR 2. Left Head SAR SAMSUNG FCC ID: A3LSGHF110 Model: SGH-F110 SAR Test Setup Photos 850/1900 GSM/GPRS/EDGE Phone With Bluetooth Page 2 of 8 © 2007 PCTEST Lab. REV 2.1 05/24/2007 3. Right Head SAR, Slide In, Cheek Touch 4. Right Head SAR, Slide In, 15° Tilt SAMSUNG FCC ID: A3LSGHF110 Model: SGH-F110 SAR Test Setup Photos 850/1900 GSM/GPRS/EDGE Phone With Bluetooth Page 3 of 8 © 2007 PCTEST Lab. REV 2.1 05/24/2007 5. Right Head SAR, Slide Out, Cheek Touch 6. Right Head SAR, Slide Out, 15° Tilt SAMSUNG FCC ID: A3LSGHF110 Model: SGH-F110 SAR Test Setup Photos 850/1900 GSM/GPRS/EDGE Phone With Bluetooth Page 4 of 8 © 2007 PCTEST Lab. REV 2.1 05/24/2007 7. Left Head SAR, Slide In, Cheek Touch 8. Left Head SAR, Slide In, 15° Tilt SAMSUNG FCC ID: A3LSGHF110 Model: SGH-F110 SAR Test Setup Photos 850/1900 GSM/GPRS/EDGE Phone With Bluetooth Page 5 of 8 © 2007 PCTEST Lab. REV 2.1 05/24/2007 9. Left Head SAR, Slide Out, Cheek Touch 10. Left Head SAR, Slide Out, 15° Tilt SAMSUNG FCC ID: A3LSGHF110 Model: SGH-F110 SAR Test Setup Photos 850/1900 GSM/GPRS/EDGE Phone With Bluetooth Page 6 of 8 © 2007 PCTEST Lab. REV 2.1 05/24/2007 11. Body SAR 12. Armband SAR SAMSUNG FCC ID: A3LSGHF110 Model: SGH-F110 SAR Test Setup Photos 850/1900 GSM/GPRS/EDGE Phone With Bluetooth Page 7 of 8 © 2007 PCTEST Lab. REV 2.1 05/24/2007 13. Body SAR, Back side, 15mm Space 14. Body SAR, Front Side , 15mm Space SAMSUNG FCC ID: A3LSGHF110 Model: SGH-F110 SAR Test Setup Photos 850/1900 GSM/GPRS/EDGE Phone With Bluetooth Page 8 of 8 © 2007 PCTEST Lab. REV 2.1 05/24/2007 15. Armband SAR, Touch

Contact Information

Applicant

Jenni Chun(General Manager)

[email protected]973-808-6375Fax: 973-808-6361

Technical Contact

PCTEST Engineering Lab., Inc.Randy Ortanez

[email protected]410-290-6652

6660-B Dobbin Road · Columbia, Maryland · United States

Test Firm

PCTEST Engineering Laboratory, Inc.Randy Ortanez

[email protected]410-290-6652Fax: 410-290-6654

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
4	24E	1.85 GHz - 1.91 GHz	526.00 mW	239KG7W	2.5 ppm

Confidentiality

Long Term

Grant Notes

Power output listed is ERP for Part 22 and EIRP for Part 24. SAR compliance for body-worn operation is based on a separation distance of 1.5 cm between the unit and the body of the user, and the specific armband configuration documented in this filing. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. Belt clips or holsters not listed in this filing may not contain metallic components. SAR compliance was evaluated with the integral Bluetooth active. The highest reported SAR values are: Part 22 - Head: 0.286 W/kg; Body-worn: 1.46 W/kg; Part 24 - Head: 0.481 W/kg; Body-worn: 1.35 W/kg. This device also contains functions that are not operational in U.S. Territories. This filing is only applicable for US operations.
