A3LSGHP408Single-Band PCS GSM Phone

TRI BAND GPRS TELEPHONE SGH-P408 * Some of the contents in this manual may differ from your phone, depending on the software installed or your service provider. Printed in Korea Code No.: GH68-03546A English. 04/2003. Rev. 1.0 World Wide Web http://www.samsungmobile.com 3 Contents Important Safety Precautions. . . . . . . . . 7 Unpacking . . . . . . . . . . . . . . . . . . . . . . . . 9 Your Phone . . . . . . . . . . . . . . . . . . . . . . 10 Phone Layout. . . . . . . . . . . . . . . . . . . . . . 10 Display . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Service Light . . . . . . . . . . . . . . . . . . . . . . 15 Getting Started . . . . . . . . . . . . . . . . . . . 16 Installing the SIM Card . . . . . . . . . . . . . . . 16 Charging a Battery . . . . . . . . . . . . . . . . . . 18 Switching the Phone On or Off. . . . . . . . . . 22 Call Functions . . . . . . . . . . . . . . . . . . . . 23 Making a Call. . . . . . . . . . . . . . . . . . . . . . 23 Adjusting the Volume . . . . . . . . . . . . . . . . 25 Answering a Call . . . . . . . . . . . . . . . . . . . 26 Viewing Missed Calls. . . . . . . . . . . . . . . . . 27 Quickly Switching to Silent mode . . . . . . . . 29 Selecting Functions and Options. . . . . . 30 Example: Setting the Display Language . . . 32 Phonebook. . . . . . . . . . . . . . . . . . . . . . . 34 Storing a Number with a Name . . . . . . . . . 34 Using Phonebook Entry Options . . . . . . . . . 36 Searching for a Number in the Phonebook . 38 Editing a Caller Group . . . . . . . . . . . . . . . 40 Speed-Dialing . . . . . . . . . . . . . . . . . . . . . 41 Checking the Memory Status. . . . . . . . . . . 42 SDN . . . . . . . . . . . . . . . . . . . . . . . . . . . 43 Entering Text. . . . . . . . . . . . . . . . . . . . . 44 Changing the Text Input Mode. . . . . . . . . . 45 Using the Chinese Pinyin Mode . . . . . . . . . 47 Using the Chinese Stroke Mode . . . . . . . . . 49 Using the Quick English Mode . . . . . . . . . . 52 Using the English Mode. . . . . . . . . . . . . . . 54 Using the Number Mode . . . . . . . . . . . . . 56 Using the Symbolic Mode . . . . . . . . . . . . . 56 Using Help . . . . . . . . . . . . . . . . . . . . . . . 56 5 4 ContentsContents Options During a Call . . . . . . . . . . . . . . 57 Putting a Call on Hold. . . . . . . . . . . . . . . . 57 Switching the Microphone Off (Mute) . . . . . 58 Muting/Sending Key Tones . . . . . . . . . . . . 58 Sending DTMF Tones . . . . . . . . . . . . . . . . 59 Searching for a Number in the Phonebook . 59 Using the SMS Service . . . . . . . . . . . . . . . 60 Answering a Second Call. . . . . . . . . . . . . . 60 Making a Multiparty Call . . . . . . . . . . . . . . 61 Using the Menus . . . . . . . . . . . . . . . . . . 63 Accessing Menu Functions by Scrolling . . . . 63 Accessing Menu Functions by Using Shortcuts 64 List of Menu Functions . . . . . . . . . . . . . . . 64 Messages . . . . . . . . . . . . . . . . . . . . . . . . 69 Inbox (Menu 1.1) . . . . . . . . . . . . . . . . . . 69 Outbox (Menu 1.2) . . . . . . . . . . . . . . . . . 70 Write New (Menu 1.3) . . . . . . . . . . . . . . . 72 Templates (Menu 1.4) . . . . . . . . . . . . . . . 74 Settings (Menu 1.5) . . . . . . . . . . . . . . . . 75 My Objects (Menu 1.6) . . . . . . . . . . . . . . 76 Memory Status (Menu 1.7) . . . . . . . . . . . 77 Voice Mail (Menu 1.8) . . . . . . . . . . . . . . . 77 Broadcast (Menu 1.9) . . . . . . . . . . . . . . . 78 Call Records. . . . . . . . . . . . . . . . . . . . . . 80 Missed Calls (Menu 2.1). . . . . . . . . . . . . . 80 Received Calls (Menu 2.2) . . . . . . . . . . . . 80 Dialled Calls (Menu 2.3) . . . . . . . . . . . . . 81 Delete All (Menu 2.4) . . . . . . . . . . . . . . . 81 Call Time (Menu 2.5). . . . . . . . . . . . . . . . 82 Call Cost (Menu 2.6) . . . . . . . . . . . . . . . . 83 Camera . . . . . . . . . . . . . . . . . . . . . . . . . 84 New Photo (Menu 3.1). . . . . . . . . . . . . . . 84 My Photos (Menu 3.2) . . . . . . . . . . . . . . . 86 Sound Settings . . . . . . . . . . . . . . . . . . . 87 Ring Tone (Menu 4.1) . . . . . . . . . . . . . . . 87 Ring Volume (Menu 4.2) . . . . . . . . . . . . . 87 Alert Type (Menu 4.3) . . . . . . . . . . . . . . . 88 Keypad Tone (Menu 4.4) . . . . . . . . . . . . . 88 Message Tone (Menu 4.5) . . . . . . . . . . . . 89 Folder Tone (Menu 4.6) . . . . . . . . . . . . . . 90 Power On/Off (Menu 4.7) . . . . . . . . . . . . 90 Extra Tones (Menu 4.8) . . . . . . . . . . . . . 90 Phone Settings . . . . . . . . . . . . . . . . . . . 92 Infrared Activate (Menu 5.1) . . . . . . . . . . 92 My Settings (Menu 5.2) . . . . . . . . . . . . . . 93 Greeting Message (Menu 5.3). . . . . . . . . . 94 Own Number (Menu 5.4) . . . . . . . . . . . . . 94 Language (Menu 5.5) . . . . . . . . . . . . . . . 95 Security (Menu 5.6) . . . . . . . . . . . . . . . . 95 Display Settings (Menu 5.7) . . . . . . . . . . 99 Extra Settings (Menu 5.8) . . . . . . . . . . . 101 Short Cut (Menu 5.9) . . . . . . . . . . . . . . 102 Reset Settings (Menu 5.10) . . . . . . . . . . 102 Organiser. . . . . . . . . . . . . . . . . . . . . . . 103 Calendar (Menu 6.1) . . . . . . . . . . . . . . . 103 To Do List (Menu 6.2) . . . . . . . . . . . . . . 105 Time & Date (Menu 6.3) . . . . . . . . . . . . 108 Alarm (Menu 6.4) . . . . . . . . . . . . . . . . . 109 Calculator (Menu 6.5) . . . . . . . . . . . . . . 110 Currency Exchange (Menu 6.6). . . . . . . . 111 Network Services . . . . . . . . . . . . . . . . 112 Call Diverting (Menu 7.1) . . . . . . . . . . . . 112 Call Barring (Menu 7.2) . . . . . . . . . . . . 114 Call Waiting (Menu 7.3) . . . . . . . . . . . . . 116 Network Selection (Menu 7.4) . . . . . . . . 117 Caller ID (Menu 7.5) . . . . . . . . . . . . . . . 118 Closed User Group (CUG) (Menu 7.6) . . . 118 Band Selection (Menu 7.7) . . . . . . . . . . . 120 7 6 Contents Important Safety Precautions Read these guidelines before using your wireless phone. Failure to follow with them may be dangerous or illega…

Text truncated - open the document above for the full version.

TRI BAND GPRS TELEPHONE SGH-P408 * Some of the contents in this manual may differ from your phone, depending on the software installed or your service provider. Printed in Korea Code No.: GH68-03546A English. 04/2003. Rev. 1.0 World Wide Web http://www.samsungmobile.com 3 Contents Important Safety Precautions. . . . . . . . . 7 Unpacking . . . . . . . . . . . . . . . . . . . . . . . . 9 Your Phone . . . . . . . . . . . . . . . . . . . . . . 10 Phone Layout. . . . . . . . . . . . . . . . . . . . . . 10 Display . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Service Light . . . . . . . . . . . . . . . . . . . . . . 15 Getting Started . . . . . . . . . . . . . . . . . . . 16 Installing the SIM Card . . . . . . . . . . . . . . . 16 Charging a Battery . . . . . . . . . . . . . . . . . . 18 Switching the Phone On or Off. . . . . . . . . . 22 Call Functions . . . . . . . . . . . . . . . . . . . . 23 Making a Call. . . . . . . . . . . . . . . . . . . . . . 23 Adjusting the Volume . . . . . . . . . . . . . . . . 25 Answering a Call . . . . . . . . . . . . . . . . . . . 26 Viewing Missed Calls. . . . . . . . . . . . . . . . . 27 Quickly Switching to Silent mode . . . . . . . . 29 Selecting Functions and Options. . . . . . 30 Example: Setting the Display Language . . . 32 Phonebook. . . . . . . . . . . . . . . . . . . . . . . 34 Storing a Number with a Name . . . . . . . . . 34 Using Phonebook Entry Options . . . . . . . . . 36 Searching for a Number in the Phonebook . 38 Editing a Caller Group . . . . . . . . . . . . . . . 40 Speed-Dialing . . . . . . . . . . . . . . . . . . . . . 41 Checking the Memory Status. . . . . . . . . . . 42 SDN . . . . . . . . . . . . . . . . . . . . . . . . . . . 43 Entering Text. . . . . . . . . . . . . . . . . . . . . 44 Changing the Text Input Mode. . . . . . . . . . 45 Using the Chinese Pinyin Mode . . . . . . . . . 47 Using the Chinese Stroke Mode . . . . . . . . . 49 Using the Quick English Mode . . . . . . . . . . 52 Using the English Mode. . . . . . . . . . . . . . . 54 Using the Number Mode . . . . . . . . . . . . . 56 Using the Symbolic Mode . . . . . . . . . . . . . 56 Using Help . . . . . . . . . . . . . . . . . . . . . . . 56 5 4 ContentsContents Options During a Call . . . . . . . . . . . . . . 57 Putting a Call on Hold. . . . . . . . . . . . . . . . 57 Switching the Microphone Off (Mute) . . . . . 58 Muting/Sending Key Tones . . . . . . . . . . . . 58 Sending DTMF Tones . . . . . . . . . . . . . . . . 59 Searching for a Number in the Phonebook . 59 Using the SMS Service . . . . . . . . . . . . . . . 60 Answering a Second Call. . . . . . . . . . . . . . 60 Making a Multiparty Call . . . . . . . . . . . . . . 61 Using the Menus . . . . . . . . . . . . . . . . . . 63 Accessing Menu Functions by Scrolling . . . . 63 Accessing Menu Functions by Using Shortcuts 64 List of Menu Functions . . . . . . . . . . . . . . . 64 Messages . . . . . . . . . . . . . . . . . . . . . . . . 69 Inbox (Menu 1.1) . . . . . . . . . . . . . . . . . . 69 Outbox (Menu 1.2) . . . . . . . . . . . . . . . . . 70 Write New (Menu 1.3) . . . . . . . . . . . . . . . 72 Templates (Menu 1.4) . . . . . . . . . . . . . . . 74 Settings (Menu 1.5) . . . . . . . . . . . . . . . . 75 My Objects (Menu 1.6) . . . . . . . . . . . . . . 76 Memory Status (Menu 1.7) . . . . . . . . . . . 77 Voice Mail (Menu 1.8) . . . . . . . . . . . . . . . 77 Broadcast (Menu 1.9) . . . . . . . . . . . . . . . 78 Call Records. . . . . . . . . . . . . . . . . . . . . . 80 Missed Calls (Menu 2.1). . . . . . . . . . . . . . 80 Received Calls (Menu 2.2) . . . . . . . . . . . . 80 Dialled Calls (Menu 2.3) . . . . . . . . . . . . . 81 Delete All (Menu 2.4) . . . . . . . . . . . . . . . 81 Call Time (Menu 2.5). . . . . . . . . . . . . . . . 82 Call Cost (Menu 2.6) . . . . . . . . . . . . . . . . 83 Camera . . . . . . . . . . . . . . . . . . . . . . . . . 84 New Photo (Menu 3.1). . . . . . . . . . . . . . . 84 My Photos (Menu 3.2) . . . . . . . . . . . . . . . 86 Sound Settings . . . . . . . . . . . . . . . . . . . 87 Ring Tone (Menu 4.1) . . . . . . . . . . . . . . . 87 Ring Volume (Menu 4.2) . . . . . . . . . . . . . 87 Alert Type (Menu 4.3) . . . . . . . . . . . . . . . 88 Keypad Tone (Menu 4.4) . . . . . . . . . . . . . 88 Message Tone (Menu 4.5) . . . . . . . . . . . . 89 Folder Tone (Menu 4.6) . . . . . . . . . . . . . . 90 Power On/Off (Menu 4.7) . . . . . . . . . . . . 90 Extra Tones (Menu 4.8) . . . . . . . . . . . . . 90 Phone Settings . . . . . . . . . . . . . . . . . . . 92 Infrared Activate (Menu 5.1) . . . . . . . . . . 92 My Settings (Menu 5.2) . . . . . . . . . . . . . . 93 Greeting Message (Menu 5.3). . . . . . . . . . 94 Own Number (Menu 5.4) . . . . . . . . . . . . . 94 Language (Menu 5.5) . . . . . . . . . . . . . . . 95 Security (Menu 5.6) . . . . . . . . . . . . . . . . 95 Display Settings (Menu 5.7) . . . . . . . . . . 99 Extra Settings (Menu 5.8) . . . . . . . . . . . 101 Short Cut (Menu 5.9) . . . . . . . . . . . . . . 102 Reset Settings (Menu 5.10) . . . . . . . . . . 102 Organiser. . . . . . . . . . . . . . . . . . . . . . . 103 Calendar (Menu 6.1) . . . . . . . . . . . . . . . 103 To Do List (Menu 6.2) . . . . . . . . . . . . . . 105 Time & Date (Menu 6.3) . . . . . . . . . . . . 108 Alarm (Menu 6.4) . . . . . . . . . . . . . . . . . 109 Calculator (Menu 6.5) . . . . . . . . . . . . . . 110 Currency Exchange (Menu 6.6). . . . . . . . 111 Network Services . . . . . . . . . . . . . . . . 112 Call Diverting (Menu 7.1) . . . . . . . . . . . . 112 Call Barring (Menu 7.2) . . . . . . . . . . . . 114 Call Waiting (Menu 7.3) . . . . . . . . . . . . . 116 Network Selection (Menu 7.4) . . . . . . . . 117 Caller ID (Menu 7.5) . . . . . . . . . . . . . . . 118 Closed User Group (CUG) (Menu 7.6) . . . 118 Band Selection (Menu 7.7) . . . . . . . . . . . 120 7 6 Contents Important Safety Precautions Read these guidelines before using your wireless phone. Failure to follow with them may be dangerous or illega…

Text truncated - open the document above for the full version.

May 30, 2003 Federal Communications Commission Authorization and Evaluation Div. Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re: Samsung Electronics Co., Ltd. FCC ID.: A3LSGHP408 Request for Confidentiality To Whom It May Concern: In accordance with 0.459 of CFR 47, Samsung Electronics Co., Ltd. requests confidentiality for the Block Diagram, Schematics, Parts list, Tune-up Procedure, Operational and Circuit Description of the attached test report. These documents contain detailed system and equipment descriptions and related information about the product, which Samsung Electronics Co., Ltd. considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Samsung feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Sincerely, Wallace Oh Engineering Manager Samsun Samsung Electronics America

© 2003 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHP408 Single-Band PCS Only Phone © 2003 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHP408 Single-Band PCS Only Phone © 2003 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHP408 Single-Band PCS Only Phone © 2003 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHP408 Single-Band PCS Only Phone © 2003 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHP408 Single-Band PCS Only Phone

© 2003 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHP408 Single-Band PCS Only Phone

© 2003 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHP408 Single-Band PCS Only Phone © 2003 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHP408 Single-Band PCS Only Phone © 2003 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHP408 Single-Band PCS Only Phone

2 of 25 Contents 1. General Information.............................................................................................3 2. Description of Device...........................................................................................3 3. Description of Test Equipment..............................................................................4 3.1 SAR Measurement Setup.........................................................................................4 3.2 DASY3 E-Field Probe.............................................................................................5 3.3 SAM Phantom.....................................................................................................6 3.4 Brain & Muscle Simulating Mixture Characterization....................................................7 3.5 Device Holder for transmitters.................................................................................8 3.6 Validation Dipole...................................................................................................8 3.7 Equipment Calibration.............................................................................................9 4. SAR Measurement Procedure.............................................................................10 5. Description of test position..............................................................................11 5.1 SAM Phantom Shape............................................................................................11 5.2 Cheek/Touch Position............................................................................................11 5.3 Ear/Tilt 15 Position..............................................................................................13 5.4 Body/Holster/Belt Clip Configuration.......................................................................14 6. Measurement Uncertainty..................................................................................16 7. System Verification.........................................................................................17 7.1 Tissue Verification..............................................................................................17 7.2 Test System Validation...........................................................................................17 8. SAR Measurement Results.................................................................................18 8.1 Measurement Results(PCS GSM Right Head SAR-Touch)........................................19 8.2 Measurement Results(PCS GSM Right Head SAR-Tilt)............................................20 8.3 Measurement Results(PCS GSM Left Head SAR-Touch)..........................................21 8.4 Measurement Results(PCS GSM Left Head SAR-Tilt)...............................................22 8.5 Measurement Results(PCS GSM Body SAR w/o Holster)........................................23 9. Conclusion.......................................................................................................24 10. Reference......................................................................................................25 3 of 25 1. GENERAL INFORMATION Test Sample : Single-Band PCS Only Phone Model Number : SGH-P408 Serial Number : Identical prototype (S/N : # FA-006-E ) Manufacturer : SAMSUNG ELECTRONICS Co., Ltd. Contact : DH Lee, Engineer Phone : +82- 54-479-5695 Fax : +82- 54-479-5715 Test Standard : §2.1093; FCC/OET Bulletin 65, Supplement C(July 2001) FCC Classification : Licensed Portable Transmitter Held to Ear (PCE) Test Dates : April 28,2003 ~ April 29,2003 Tested for : FCC/TCB Certification 2. DESCRIPTION OF DEVICE Tx Freq. Range : 1850.20– 1909.80 MHz (PCS GSM) Rx Freq. Range : 1930.20 – 1989.80 MHz (PCS GSM) Max. RF Output Power : 1.449W EIRP PCS (31.61dBm) Antenna Manufacturer : ACE Technology Model No. : SGH-P408 Antenna Dimensions : Length = 21.4mm [Fixed] 4 of 25 3. DESCRIPTION OF TEST EQUIPMENT 3.1 SAR Measurement Setup Robotic System Measurements are performed using the DASY3 automated dosimetric assessment system. Which is made by Schmid & Partner Engineering AG (SPEAG) in Zurich, Switzerland and consists of high precision robotics system (Stäubli), robot controller, Pentium computer, near-field probe, probe alignment sensor, and the SAM twin phantom containing the brain equivalent material. The robot is a six-axis industrial robot performing precise movements to position the probe to the location (points) of maximum electromagnetic field (EMF) (see Fig. 3.1). Figure 3.1 SAR Measurement System Setup System Hardware A cell controller system contains the power supply, robot controller, teach pendant (Joystick), and a remote control is used to drive the robot motors. The PC consists of the Samsung Pentium 550MHz computer with Windows 2000 system and SAR Measurement Software DASY3, A/D interface card, LCD monitor, mouse and keyboard. The Stäubli Robot is connected to the cell controller to allow software manipulation of the robot. A data acquisition electronic (DAE) circuit that performs the signal amplification, signal multiplexing, AD-conversion, offset measurements, mechanical surface detection, collision detection, etc. is connected to the Electro-optical coupler (EOC). The EOC performs the conversion from the optical into digital electric signal of the DAE and transfers data to the PC plug-in card. 5 of 25 System Electronics The DAE3 consists of a highly sensitive electrometer-grade preamplifier with auto-zeroing, a channel and gain-switching multiplexer, a fast 16-bit AD-converter and a command decoder and control logic unit. Transmission to the PC-card is accomplished through an optical downlink for data and status information and an optical uplink for commands and clock lines. The mechanical probe mounting device includes two different sensor systems for frontal and sidewise probe contacts. They are also used for mechanical surface detection and probe collision detection…

Text truncated - open the document above for the full version.

SAMSUNG FCC ID: A3LSGHP408 -- 1900MHz.PCS GSM Head SAR SAM Phantom; Right Cheek(CRP) Section; Probe:ET3DV6 - SN1551; ConvF(5.30,5.30,5.30) Head 1900 MHz: σ = 1.39 mho/m ε r = 38.6 ρ = 1.00 g/cm 3 ; Antenna Position- Fixed; Crest Factor 8.0 SAR (1g): 0.551 mW/g SAMSUNG Single-Band PCS Only Phone Model: SGH-P408 GSM 1900 Mode, Ch.512 [1850.2MHz]; Standard Battery; Flip = open; Ambient Temp. (°C) - 22.9 Conducted Power = 30.0dBm; Right Head Phantom, Cheek/Touch Position; Meas. Tissue Temp. (°C) - 20.8 Test Date -- 04/28/2002 [FCC/OET Bulletin 65 - Supplement C, July 2001 SAR Tot [mW/g] 4.52E-2 1.36E-1 2.26E-1 3.16E-1 4.07E-1 SAMSUNG FCC ID: A3LSGHP408 -- 1900MHz.PCS GSM Head SAR SAM Phantom; Right Cheek(CRP) Section; Probe:ET3DV6 - SN1551; ConvF(5.30,5.30,5.30) Head 1900 MHz: σ = 1.39 mho/m ε r = 38.6 ρ = 1.00 g/cm 3 ; Antenna Position -Fixed; Crest Factor 8.0 SAR (1g): 0.0422 mW/g SAMSUNG Single-Band PCS Only Phone Model: SGH-P408 GSM 1900 Mode, Ch.512 [1850.2MHz]; Standard Battery; Flip = open Ambient Temp. (°C) - 22.9 Conducted Power = 30.0dBm; Right Head Phantom, Ear/Tilt 15 deg Position; Meas. Tissue Temp. (°C) - 20.8 Test Date -- 04/28/2002 [FCC/OET Bulletin 65 - Supplement C, July 2001 SAR Tot [mW/g] 4.70E-3 1.41E-2 2.35E-2 3.29E-2 4.23E-2 SAMSUNG FCC ID: A3LSGHP408 -- 1900MHz.PCS GSM Head SAR SAM Phantom; Left Cheek(CRP) Section; Probe:ET3DV6 - SN1551; ConvF(5.30,5.30,5.30) Head 1900 MHz: σ = 1.39 mho/m ε r = 38.6 ρ = 1.00 g/cm 3 ; Antenna Position-Fixede; Crest Factor 8.0 SAR (1g): 0.374 mW/g SAMSUNG Single-Band PCS Only Phone Model: SGH-P408 GSM 1900 Mode, Ch.512 [1850.2MHz]; Standard Battery; Flip = open; Ambient Temp. (°C) - 22.9 Conducted Power = 30.0dBm; Left Head Phantom, Cheek/Touch Position; Meas. Tissue Temp. (°C) - 20.8 Test Date -- 04/28/2002 [FCC/OET Bulletin 65 - Supplement C, July 2001 SAR Tot [mW/g] 3.81E-2 1.14E-1 1.91E-1 2.67E-1 3.43E-1 SAMSUNG FCC ID: A3LSGHP408 -- 1900MHz.PCS GSM Head SAR SAM Phantom; Left Cheek(CRP) Section; Probe:ET3DV6 - SN1551; ConvF(5.30,5.30,5.30) Head 1900 MHz: σ = 1.39 mho/m ε r = 38.6 ρ = 1.00 g/cm 3 ; Antenna Position - Fixed; Crest Factor 8.0 SAR (1g): 0.0171 mW/g SAMSUNG Single-Band PCS Only Phone Model: SGH-P408 GSM 1900 Mode, Ch.512 [1850.2MHz]; Standard Battery; Flip = open; Ambient Temp. (°C) - 22.9 Conducted Power = 30.0dBm; Left Head Phantom, Ear/ Tilt 15 deg Position; Meas. Tissue Temp. (°C) - 20.8 Test Date -- 04/28/2002 [FCC/OET Bulletin 65 - Supplement C, July 2001 SAR Tot [mW/g] 1.80E-3 5.40E-3 9.00E-3 1.26E-2 1.62E-2 SAMSUNG FCC ID: A3LSGHP408 -- 1900MHz.PCS GSM Body SAR SAM Phantom; Flat Section; Probe:ET3DV6 - SN1551; ConvF(4.90,4.90,4.90) Body 1900 MHz: σ = 1.53 mho/m ε r = 52.2 ρ = 1.00 g/cm 3 ; Antenna Position-Fixed; Crest Factor 8.0 SAR (1g): 0.141 mW/g SAMSUNG Single-Band PCS Only Phone Model: SGH-P408 GSM 1900 Mode, Ch.512 [1850.2MHz]; Standard Battery; Flip = close; Ambient Temp. (°C) - 22.0 Conducted Power = 30.0dBm; Spacing = 1.5cm. from flat phantom to phone, w/o beltclip or holster; Meas.Tissue Temp. (°C) - 21.1 Test Date -- 04/29/2003 [ FCC/OET Bulletin 65- Supplement C - July 2001 ]] SAR Tot [mW/g] 1.25E-2 3.75E-2 6.25E-2 8.75E-2 1.13E-1
