A3LSGHP716Dual-Band GSM Phone

TRI BAND GPRS Series SGH-P71 6 Portable Digital Telephone User Manual Please read this manual before operating your phone, and keep it for future reference. Printed in Korea Code No.: GH68-xxxxxA English.11/2003. Rev. 1.0 2nd version (11 26) Intellectual PropertyAll Intellectual Property, as defined below, owned by or which is otherwise the property of Samsun g or its respective suppliers relating to the SAMSUNG Phone, including but not limited to, accessories, parts, or software relating thereto (the “Phone System”), is proprietary to Samsung and protected under federal laws, state laws, and international treaty provisions. Intellectual Property includes, but is not limited to, inventions (patentable or unpatentable) , patents, trade secrets, copyrights, software, computer programs, and related documentation and other works of authorship. You may not infringe or otherwise violat e the rights secured by the Intellectual Property. Moreover, yo u agree that you will not (and will not attempt to) modify, prepare derivative works of, reverse engineer, decompile, disassemble, or otherwise attempt to create source code from the software. No title to or ownership in the Intellectual Property is transferred to you. All applicable rights of the Intellectual Property shall remain with SAMSUNG and its suppliers. Samsung Telecommunications America (STA), Inc.Headquarters:1130 E. Arapaho RoadRichardson, TX 75081Tel: 972-761-7000Fax: 972-761-7001Customer Care Center:1601 E. Plano ParkwaySuite 150Plano, TX 75047Tel: 888-987-HELP (4357)Fax: 972-761-7501Internet Address: http ://www.samsungusa.com/ wireless ©2003 Samsung Telecommunications America. All rights reserved. No reproduction in wh ole or in part allowed without prior written approval. Samsung is a registered trademark of Samsung Electronics America, In c. and its related entities. Table of Contents 1 Table of Contents Important Safety Precautions......................... 7Unpacking ...................................................... 9Your Phone ................................................... 10 Phone Layo ut ........................................................ 10 Display ................................................................. 13Service Light ......................................................... 16Camera ................................................................ 16 Getting Started ............................................. 17 Installing the SI M Card ......................................... .. 17 Charging the Battery .............................................. 19Switching the Phone On or Off ................................. 21 Call Functions ............................................... 23 Making a Ca ll......................................................... 23 Adjusting the Volume ............................................. 25Answering a Call .................................................... 26Viewing Missed Calls............................................... 27Quickly Switching to Silent Mode .............................. 29 Selecting Functions and Options................... 31Phonebook.................................................... 33 Storing a Number wi th a Name ................................ 33 Using Phonebook Entry Options................................ 36Searching for and Dialing a Number in Phonebook ...... 37Editing a Caller Group............................................. 39 Speed-dialing ........................................................ 40Deleting All of the Phonebook Entries........................ 41Checking the Memo ry Status ................................... 42 Table of Contents2 Entering Text ................................................ 43 Changing the Text Input Mode ................................. 44 Using T9 Mode....................................................... 45Using Alphabet Mode .............................................. 47Using Number Mode ............................................... 48Using Symbol Mode ................................................ 48 Options During a Call .................................... 49 Putting a Call on Hold ............................................. 49Switching the Micropho ne Off (Mute) ........................ 50 Muting or Sending Key Tones................................... 51Sending a Sequence of DTMF Tones ......................... 51Searching for a Number in Phonebook ...................... 52Using the Message Service ...................................... 52 Call Waiting........................................................... 53Making a Multi-pa rty Call......................................... 53 Using the Menus ........................................... 57 Accessing a Menu Function by Scrolling..................... 57Using Shortcuts ..................................................... 58List of Menu F unctions ............................................ 58 Messages ...................................................... 65 Text Messages (Menu 1.1) ........................................ 65 Multimedia Messages (Menu 1.2) .............................. 71 E-Mail Messages (Menu 1.3) ..................................... 80 Push Message (Menu 1.4) ........................................ 86 Delete All (Menu 1.5) .............................................. 87 Voice Mail (Menu 1.6) .............................................. 88 Memory Status (Menu 1.7) ....................................... 89 Settings (Menu 1.8) ................................................ 89 Table of Contents 3 Call Records.................................................. 97 Missed Calls (Menu 2.1) ........................................... 97 Received Calls (Menu 2.2) ........................................ 98 Dialled Calls (Menu 2.3) ........................................... 98 Delete All (Menu 2.4) .............................................. 99 Call Time (Menu 2.5) .....................................…

Text truncated - open the document above for the full version.

February 17, 2004 Federal Communications Commission Authorization and Evaluation Div. Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: We, the undersigned, hereby authorize PCTEST Engineering Laboratory Inc., to act as agent on behalf of all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, Inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988,21 U.S.C.862. Sincerely, Wallace Oh Engineering Manager Samsun Electronics America February 17, 2004 Federal Communications Commission Authorization and Evaluation Div. Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re: Samsung Electronics Co., Ltd. FCC ID.: A3LSGHP716 Request for Confidentiality To Whom It May Concern: In accordance with 0.459 of CFR 47, Samsung Electronics Co., Ltd. requests confidentiality for the Block Diagram, Schematics, Parts list, Tune-up Procedure, Operational and Circuit Description of the attached test report. These documents contain detailed system and equipment descriptions and related information about the product, which Samsung Electronics Co., Ltd. considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Samsung feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Sincerely, Wallace Oh Engineering Manager Samsun Samsung Electronics America

April 26, 2004 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: SAMSUNG Electronics Co., Ltd. FCC ID: A3LSGHP716 Part 22/24 Certification Gentlemen: Submitted herewith, on behalf of SAMSUNG Electronics Co., Ltd., is an application for Part 22/24 Certification of the Dual-Band GSM Phone. Attached is the applicant’s Letter of Authorization, Confidentiality Request, measurement report test data and plots, RF Exposure measurement report and data, FCC ID label and location, test setup photographs, internal and external photographs, block diagram (confidential), circuit diagrams & description (confidential), operational description (confidential), parts list & tune-up procedure (confidential), and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: SAMSUNG Electronics Co., Ltd.

SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716

© 2004 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) 2. Sample Label

SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716

PCTEST ENGINEERING LABORATORY, INC. 6660 – B Dobbin Road • Columbia, MD 21045 • USA Telephone 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com (email: [email protected]) CERTIFICATE OF COMPLIANCE (SAR EVALUATION) PCTEST SAR REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: SAR-240217116.A3L Test Dates: March 25-26, 2004 Phone Type: Dual-Band GSM FCC ID: A3LSGHP716 Page 1 of 30 © 2004 PCTEST Engineering Laboratory, Inc APPLICANT NAME & ADDRESS: DATE & LOCATION OF TESTING: SAMSUNG ELECTRONICS CO., LTD. Dates of Tests: March 25-26, 2004 3351 Michelson Drive, Suite 290 Test Report S/N: SAR.240217116.A3L Irvine, CA 92612 Test Site: PCTEST Lab, Columbia MD FCC ID: A3LSGHP716 APPLICANT: SAMSUNG ELECTRONICS CO., LTD. EUT Type: Dual-Band GSM Phone Tx Frequency: 824.20 – 848.80 MHz (GSM850) / 1850.20 – 1909.80 MHz (GSM1900) Rx Frequency Range: 869.20 – 893.80 MHz (GSM850) / 1930.20 – 1989.80 MHz (GSM1900) Max. RF Output Power: 1.597 W ERP GSM850 (32.033 dBm) / 33.0 dBm Conducted 1.165 W EIRP GSM1900 (30.651 dBm) / 30.0 dBm Conducted Max. SAR Measurement: 1.160 W/kg GSM850 Head SAR; 0.938 W/kg GSM850 Body SAR; 1.150 W/kg GSM1900 Head SAR; 0.300 W/kg GSM1900 Body SAR Trade Name/Model(s): SGH-P716 FCC Classification: Licensed Portable Transmitter Held to Ear (PCE) FCC Rule Part(s): §2.1093; FCC/OET Bulletin 65 Supplement C [July 2001] Application Type: Certification Test Device Serial No.: identical prototype [S/N: #FCC1] This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. P1528 D1.2 (April 2003). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant Conditions: Output power listed is ERP for Part 22 and EIRP for Part 24. SAR compliance for body-worn operating configuration is based on a separation distance of 1.5 cm between the back of the unit and the body of the user. End-users must be informed of the body-worn operating configurations for satisfying RF exposure compliance. Belt-clips or holsters may not contain metallic components. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST SAR REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: SAR-240217116.A3L Test Dates: March 25-26, 2004 Phone Type: Dual-Band GSM FCC ID: A3LSGHP716 Page 2 of 30 © 2004 PCTEST Engineering Laboratory, Inc TABLE OF CONTENTS 1. INTRODUCTION / SAR DEFINITION................................................................................3 2. SAR MEASUREMENT SETUP............................................................................................4 3. DASY4 E-FIELD PROBE SYSTEM.......................................................................................5 4. Probe Calibration Process.................................................................................................6 5. PHANTOM & EQUIVALENT TISSUES................................................................................7 6. TEST SYSTEM SPECIFICATIONS........................................................................................8 7. DOSIMETRIC ASSESSMENT & PHANTOM SPECS...............................................................9 8. DEFINITION OF REFERENCE POINTS.............................................................................10 9. TEST CONFIGURATION POSITIONS..............................................................................11 10. ANSI/IEEE C95.1 - 1992 RF EXPOSURE LIMITS................................................................14 11. MEASUREMENT UNCERTAINTIES..................................................................................15 12. SYSTEM VERIFICATION.................................................................................................16 13. SAR TEST DATA SUMMARY...........................................................................................17 14. SAR DATA SUMMARY...................................................................................................18 15. SAR TEST EQUIPMENT..................................................................................................28 16. CONCLUSION..............................................................................................................29 17. REFERENCES.................................................................................................................30 PCTEST SAR REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: SAR-240217116.A3L Test Dates: March 25-26, 2004 Phone Type: Dual-Band GSM FCC ID: A3LSGHP716 Page 3 of 30 © 2004 PCTEST Engineering Laboratory, Inc 1. INTRODUCTION / SAR DEFINITION The FCC has adopted the guidelines for evaluating the environmental effects of radiofrequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. (c) 1992 by the Institute of Electrical and Electronics Engineers, Inc., New York, New York 10017.[2] The measurement procedure described in IEEE/ANSI C95.3-1992 Recommen…

Text truncated - open the document above for the full version.

SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716

PCTEST PT. 22/24 REPORT FCC MEASUREMENT REPORT Reviewed By: Quality Manager Test Report S/N: 22/24.240217115.A3L Test Dates: March 25-26, 2004 Phone Type: Dual-Band GSM FCC ID: A3LSGHP716 Page 1 of 25 © 2004 PCTEST ENGINEERING LABORATORY, INC. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE FCC Part 24 & 22 Certification SAMSUNG ELECTRONICS CO., LTD. Dates of Tests: March 25-26, 2004 3351 Michelson Drive, Suite 290 Test Report S/N: 22/24.240217115.A3L Irvine, CA 92612 Test Site: PCTEST Lab, Columbia MD FCC ID A3LSGHP716 APPLICANT SAMSUNG ELECTRONICS CO., LTD. Classification: Licensed Portable Transmitter Held to Ear (PCE) FCC Rule Part(s): §24(E), §22H; §2 EUT Type: Dual-Band GSM Phone Model: SGH-P716 Tx Frequency Range: 824.20 – 848.80MHz (GSM850) / 1850.20MHz – 1909.80MHz (GSM1900) Rx Frequency Range: 869.20 – 893.80MHz (GSM850) / 1930.20MHz – 1989.80MHz (GSM1900) Max. RF Output Power: 1.597 W ERP GSM850 (32.033 dBm) / 1.165 W EIRP GSM1900 (30.651 dBm) Max. SAR Measurement: 1.160 W/kg GSM850 Head SAR; 0.938 W/kg GSM850 Body SAR; 1.150 W/kg GSM1900 Head SAR; 0.300 W/kg GSM1900 Body SAR Emission Designator(s): 250KGXW (GSM) & 250KG7W (EDGE) Test Device Serial No. Identical Prototype [S/N: #FCC1] This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in §2.947. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant Conditions: Output power listed is ERP for Part 22 and EIRP for Part 24. SAR compliance for body- worn operating configuration is based on a separation distance of 1.5 cm between the back of the unit and the body of the user. End-users must be informed of the body-worn operating configurations for satisfying RF exposure compliance. Belt-clips or holsters may not contain metallic components. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST PT. 22/24 REPORT FCC MEASUREMENT REPORT Reviewed By: Quality Manager Test Report S/N: 22/24.240217115.A3L Test Dates: March 25-26, 2004 Phone Type: Dual-Band GSM FCC ID: A3LSGHP716 Page 2 of 25 © 2004 PCTEST ENGINEERING LABORATORY, INC. TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT 1.1 SCOPE 3 2.1 INTRODUCTION 4 3.1 INSERTS 5 4.1 DESCRIPTION OF TESTS 6-9 5.1 EFFECTIVE RADIATED POWER OUTPUT 10 6.1 EQUIVALENT ISOTROPIC RADIATED POWER 11 7.1 RADIATED MEASUREMENTS 12-17 8.1 FREQUENCY STABILITY 18-21 9.1 PLOTS OF EMISSIONS 22 10.1 LIST OF TEST EQUIPMENT 23 11.1 SAMPLE CALCULATIONS 24 12.1 CONCLUSION 25 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL / LOCATION ATTACHMENT F: TEST SETUP PHOTOGRAPHS ATTACHMENT G: EXTERNAL PHOTOGRAPHS ATTACHMENT H: INTERNAL PHOTOGRAPHS ATTACHMENT I: BLOCK DIAGRAM(S) ATTACHMENT J: SCHEMATIC DIAGRAM(S) ATTACHMENT K: OPERATIONAL / CIRCUIT DESCRIPTION ATTACHMENT L: PARTS LIST/TUNE UP PROCEDURE ATTACHMENT M: USER’S MANUAL ATTACHMENT N: SAR MEASUREMENT REPORT ATTACHMENT O: SAR TEST DATA ATTACHMENT P: SAR TEST SETUP PHOTOGRAPHS ATTACHMENT Q: DIPOLE VALIDATION ATTACHMENT R: PROBE CALIBRATION PCTEST PT. 22/24 REPORT FCC MEASUREMENT REPORT Reviewed By: Quality Manager Test Report S/N: 22/24.240217115.A3L Test Dates: March 25-26, 2004 Phone Type: Dual-Band GSM FCC ID: A3LSGHP716 Page 3 of 25 © 2004 PCTEST ENGINEERING LABORATORY, INC. MEASUREMENT REPORT 1.1 Scope Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. §2.1033 General Information Applicant Name: SAMSUNG ELECTRONICS CO., LTD. Address: 3351 Michelson Drive, Suite 290 Irvine, CA 92612 • FCC ID: A3LSGHP716 • Quantity: Quantity production is planned • Emission Designators: 250KGXW (GSM) & 250KG7W (EDGE) • Tx Freq. Range: 824.20 – 848.80 MHz (GSM850) 1850.20 – 1909.80 MHz (GSM1900) • Rx Freq. Range: 869.20 – 893.80 MHz (GSM850) 1930.20 – 1989.80 MHz (GSM1900) • Max. Power Rating: 1.597 W ERP GSM (32.033 dBm) 1.165 W EIRP PCS GSM (30.651 dBm) • FCC Classification(s): Licensed Portable Tx Held to Ear (PCE) • Equipment (EUT) Type: Dual-Band GSM Phone • Modulation(s): GSM • Frequency Tolerance: ± 0.00025% (2.5 ppm) • FCC Rule Part(s): § 24(E), §22H • Dates of Tests: March 25-26, 2004 • Place of Tests: PCTEST Lab, Columbia, MD U.S.A. • Test Report S/N: 22/24.240217115.A3L PCTEST PT. 22/24 REPORT FCC MEASUREMENT REPORT Reviewed By: Quality Manager Test Report S/N: 22/24.240217115.A3L Test Dates: March 25-26, 2004 Phone Type: Dual-Band GSM FCC ID: A3LSGHP716 Page 4 of 25 © 2004 PCTEST ENGINEERING LABORATORY, INC. 2.1 INTRODUCTION These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39° 11'15" N latitude and 76° 49'38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of the measurement facility was found to be in compliance with the requirements of § 2.948 a…

Text truncated - open the document above for the full version.

SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716 SAMSUNG FCC ID: A3LSGHP716 EUT Photographs © 2004 PCTEST Lab. Dual-Band GSM Phone Model: SGH-P716
