A3LSGHT709Dual-Band GSM Phone with WLAN

Samsung Electronics Co Ltd

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Apr 06, 2006
Application Purpose: Original Equipment
Date of Application: Apr 06, 2006
Equipment Note: Dual-Band GSM Phone with WLAN
Frequency Range: 2412.00000000 - 2462.00000000
Company: Samsung Electronics Co Ltd
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

World Wide Webhttp://www.samsungmobile.com Printed in Korea Code No.:GH68-0xxxxA English. 10/2005. Draft * Depending on the software installed or your service provider or country, some of the description in this guide may not match your phone. * Depending on your country, your phone and accessories may appear different from the illustra tions in this guide. SGH-T709User’s Guide SGH-T709 Draft01 Important safety precautions Failure to comply with the following precautions may be dangerous or illegal. Drive safely at all timesDo not use a hand-held phone while driving. Park the vehicle first. Switch off the phone when refuellingDo not use the p hone at a refuelling point (service station) or near fuels or chemicals.Switch off in an aircraftWireless phones can cause interference. Using them in an aircraft is both illegal and dangerous.Switch off the phone near all medical equipmentHospitals or health care facilities may be using equipment that could be sensitive to external radio frequency energy. Follow any regulations or rules in force. Important safety precautions 1 InterferenceAll wireless phones may be subject to interference, which could affect their performance. Be aware of special regulationsMeet any special regulations in force in any area and always switch off your phone whenever it is forbidden to use it, or when it may cause interference or danger.Water resistanceYour phone is not water-resistant. Keep it dry. Sensible useUse only in the normal position (held to the ear). Avoid unnecessary contact with the antenna when the phone is switched on.Emergency callsKey in the emergency number for your present location, then press . Keep your phone away from small children Keep the phone and all its parts, including accessories, out of the reach of small children.Accessories and batteriesUse only Samsung-approved accessories and batteries. Use of any unauthorised accessories could damage your phone and may be dangerous.Qualified serviceOnly qualified service personnel may repair your phone.For more detailed safety information, see "Health and safety information" on page 77. • The phone could explode if the battery is replaced with an incorrect type. • Dispose of used batteries according to the manufacturer’s instructions. 2 About this GuideThis User’s Guide provides you with condensed information about how to use your phone. To quickly learn the basics for your ph one, please refer to “Get started” and “Step outside the phone.”In this guide, the following instruction icons appear: Indicates that you need to pay careful attention to the subsequent information regarding safety or phone features. Indicates that you can get more information on the referenced page. → Indicates that you need to press the Navigation keys to scroll to the specified option and then select it. [ ] Indicates a key on the phone. For example, [] < > Indicates a soft key, whose function is displayed on the phone screen. For example, < Menu > • Camera and camcorder Use the camera module on your phone to take a photo or record a video. Special features of your phone •MP3 player Play MP3 music files using your phone as a MP3 player. •Bluetooth Transfer media files and personal data and connect to other devices using free, wireless Bluetooth technology. 3 Special features of your phone • Voice clarity Use the voice clarity feature to increase the volume and clarity of an incoming call, even in the midst of a crowd. • Get personal with photo caller ID See who’s calling you when their very own photo displays. • Name card Create name cards with your number and profile. Whenever introducing yourself to others, use this convenient electronic name card. • Multimedia Message Service (MMS) Send and receive MMS messages with a combination of text, images, video, and audio. •E-mail Send and receive e-mails with images, video, and audio attachments. •Java Enjoy Java™-based embedded games and download new games. •Calendar Keep track of your daily, weekly, and monthly schedule. • Voice recorder Record memos or sounds. 4 Contents Unpack 6 Make sure you have each itemYour phone 6 Buttons, features, and locationsGet started 7 First steps to operating your phoneInstall and charge the phone ..................................... 7Power on or off........................................................ 9Keys and display ..................................................... 9Access menu functions ............................................ 12Customize your phone............................................. 13Make/Answer calls .................................................. 15Step outside the phone 23 Begin with your camera, music, and other special featuresUse camera............................................................ 23Play MP3s .............................................................. 24Browse the web...................................................... 25 Use Phonebook ...................................................... 25Send messages ...................................................... 26View messages....................................................... 28Use Bluetooth ........................................................ 29 Enter text 31 ABC, T9, Number, and Symbol modeCall functions 33 Menu functions 37 All menu options listedSolve problems 92 Help and personal needsHealth and safety information 94 Index 101 5 Overview of menu functions To access Menu mode, press < Menu > in Idle mode. 1 Voice notes p.33 2 Call records p.33 1 All calls2 Missed calls3 Incoming calls4 Outgoing calls5 Delete all6 Call time p.34 p.34 p.34 p.34 p.34 p.34 3 t-zones p.35 4 Instant messaging p.37 5 Messages p.37 1 Create new2 Inbox3 Sentbox4 Outbox5 Draft6 Templates7 Voice mail8 Delete all9 Settings10 Broadcast message11 Memory status p.37 p.40 p.41 p.42 p.42 p.42 p.43 p.43 p.43 p.49 p.49 6 Fun & Apps p.49 1 File manager2 MP3 player3 Voice recognition4 Games5 Image editor6 Organizer …

Text truncated - open the document above for the full version.

Attestation Statements

18600 Broadwick Street January 1, 2006 !"# $%&' ( &) "* +,- . / (0+1+//2(34 (5 /5 ///5 /4(0+1+// 2( 34(5555,4 .(5(65(5 / (5 1 # )57/(5)8 )94144 *4 1 1: ;&/ 1&19<;3<4 SAMSUNG ELECTRONICS CO.,LTD. 416 Maetan3-Dong Yeongtong-gu, Suwon city, Gyeonggi-Do, Korea 442-742 Date: January 1, 2006 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: A3LS GHT709 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, SAMSUNG ELECTRONICS CO.,LTD. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 45 days after the grant as outlined in Public Notice DA 04-1705. This provision will give SAMSUNG ELECTRONICS CO.,LTD. temporary confidentiality of commercially sensitive information prior to product release. The requested Confidential and Temporary Confidential exhibits are listed as follows: CONFIDENTIAL AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Operational Descriptions 3 Parts Lists and Tune-Up Procedure CONFIDENTIAL 4 Schematics 5 External Photos 6 Internal Photos 7 Test-Setup Photos SHORT-TERM CONFIDENTIAL 8 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, SEOUNG HO PARK SAMSUNG ELECTRONICS CO.,LTD.

Attestation Statements

Declaration of Conformity We, Samsung Electronics Co., Ltd., declare on our sole responsibility that the product SGH-T709 HW version : Rev 1.0 has WIFI chipset made by Philips co. SGH-T709 use this WIFI chipset for UMA voice call & data call. It’ s similar to VOIP. SGH-T709 does not use typical access to AP likes usual PDA. When UMA mode being activation, this terminal can not doing GSM voice call. The reason is below. One of the concept of UMA handset is “ hand over” between GSM & UMA call. So, UMA handset does not going together at the same time. Point of contact D.G Kang R&D Group 5 (H/W Lab.1). Samsung Electronics Co., Ltd. Tel. : +28 31 301 6923 Fax : +82 31 279 4288 e-mail: [email protected] (Signature )

Cover Letter(s)

PCTEST Engineering Laboratory, Inc. 6660 Dobbin Road Suite A-E Columbia, Maryland 21045-4844 Tel.: 410-290-6652 / Fax: 410-290-6654 October 6, 2006 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Richard Tseng SUBJECT: Samsung Electronics Co., Ltd. FCC ID: A3LSGHT709 731 Confirmation No.: TC768168 Correspondence Reference No.: 31731 Request for Tech. Info.: 09/08/2006 Dear Tim: Transmitted herewith, on behalf of Samsung Electronics is an amendment provided in response to the request for technical information dated September 9, 2006. 1. Please find attached SAR report containing the results for the WLNA transmitter. Also included is a statement regarding transmission limitations of the device. We trust this information is sufficient to resolve FCC questions in this application. If you have any further questions, please do not hesitate to contact us. cc: Samsung Electronics Co., Ltd.

External Photos

SAMSUNG FCC ID: A3LSGHT709 EUT Photographs © 2006 PCTEST Lab. Dual-Band GSM Phone w/ WLAN Model: SGH-T709 SAMSUNG FCC ID: A3LSGHT709 EUT Photographs © 2006 PCTEST Lab. Dual-Band GSM Phone w/ WLAN Model: SGH-T709 SAMSUNG FCC ID: A3LSGHT709 EUT Photographs © 2006 PCTEST Lab. Dual-Band GSM Phone w/ WLAN Model: SGH-T709 SAMSUNG FCC ID: A3LSGHT709 EUT Photographs © 2006 PCTEST Lab. Dual-Band GSM Phone w/ WLAN Model: SGH-T709 SAMSUNG FCC ID: A3LSGHT709 EUT Photographs © 2006 PCTEST Lab. Dual-Band GSM Phone w/ WLAN Model: SGH-T709 SAMSUNG FCC ID: A3LSGHT709 EUT Photographs © 2006 PCTEST Lab. Dual-Band GSM Phone w/ WLAN Model: SGH-T709 SAMSUNG FCC ID: A3LSGHT709 EUT Photographs © 2006 PCTEST Lab. Dual-Band GSM Phone w/ WLAN Model: SGH-T709

Internal Photos

RF Exposure Info

Reviewed by: PCTEST SAR REPORT SAR SUMMARY REPORT Quality Manager SAR Filename: Test Dates: EUT Type: Dual-Band FCC ID: 0603010135 03/07/2006 - 03/15/2006 GSM Phone with WLAN A3LSGHT709 Page 1 of 25 © 2006 PCTEST Engineering Laboratory, Inc. Applicant Name: Date of Testing: Samsung Electronics 03/07/2006 - 03/15/2006 3351 Michelson Drive, Suite 290 Test Site/Location: Irvine, CA 92612 PCTEST Lab, Columbia, MD, USA Test Report Serial No.: 0603010135 FCC ID: A3LSGHT709 APPLICANT: SAMSUNG ELECTRONICS Application Type: Certification FCC Rule Part(s): § 2.1093; FCC/OET Bulletin 65 Supplement C (July 2001) FCC Classification: Licensed Transmitter Held to Ear (PCE) EUT Type: Dual-Band GSM Phone with WLAN Model(s): SGH-T709 Tx Frequency: 824.20MHz - 848.8MHz (Cellular GSM) 1850.20MHz - 1909.8MHz (PCS GSM) RF Output Power: 0.697 W ERP Cellular GSM (28.433 dBm) 1.915 W ERP PCS GSM (32.821 dBm) Max. SAR Measurement: Cellular GSM: 0.40 W/kg Head SAR, 0.93 W/kg Body SAR PCS GSM: 0.27 W/kg Head SAR, 0.18 W/kg Body SAR Test Device Serial No.: Pre-Production Sample [S/N: FC-164-J] This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. 1528-2003. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant Conditions: Power output listed is ERP for Part 22 and EIRP for Part 24. SAR compliance for body-worn operating configuration is based on a separation distance of 2.0 cm between the back of the unit and the body of the user. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. Belt clips or holsters may not contain metallic components. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) Reviewed by: PCTEST SAR REPORT SAR SUMMARY REPORT Quality Manager SAR Filename: Test Dates: EUT Type: Dual-Band FCC ID: 0603010135 03/07/2006 - 03/15/2006 GSM Phone with WLAN A3LSGHT709 Page 2 of 25 © 2006 PCTEST Engineering Laboratory, Inc. TABLE OF CONTENTS 1. INTRODUCTION......................................................................................................................3 2. TEST SITE LOCATION................................................................................................................4 3. SAR MEASUREMENT SETUP........................................................................................................5 4. ALIDX-500 E-FIELD PROBE SYSTEM..............................................................................................6 5. PROBE CALIBRATION PROCESS..................................................................................................7 6. PHANTOM AND EQUIVALENT TISSUES.........................................................................................8 7. TEST SYSTEM SPECIFICATIONS..................................................................................................10 8. DOSIMETRIC ASSESSMENT AND PHANTOM SPECS.......................................................................11 9. DEFINITION OF REFERENCE POINTS..........................................................................................12 10. TEST CONFIGURATION POSITION.............................................................................................13 11. ANSI/IEEE C95.1 - 1992 RF EXPOSURE LIMITS..............................................................................14 12. MEASUREMENT UNCERTAINTIES..............................................................................................15 13. SAR TEST EQUIPMENT.............................................................................................................16 14. CONCLUSION........................................................................................................................17 15. REFERENCES..........................................................................................................................18 EXHIBIT A. SYSTEM VERIFICATION........................................................................................................19 EXHIBIT B. SAR SETUP PROCEDURES.....................................................................................................20 EXHIBIT C. SAR DATA SUMMARY..........................................................................................................21 Reviewed by: PCTEST SAR REPORT SAR SUMMARY REPORT Quality Manager SAR Filename: Test Dates: EUT Type: Dual-Band FCC ID: 0603010135 03/07/2006 - 03/15/2006 GSM Phone with WLAN A3LSGHT709 Page 3 of 25 © 2006 PCTEST Engineering Laboratory, Inc. 1. INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radio frequency (RF) radiation in ET Docket 93- 62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. (c) 1992 by the Inst…

Text truncated - open the document above for the full version.

Test Report

© 2006 PCTEST Engineering Laboratory, Inc. PCTEST ENGINEERING LABORATORY, INC. 6660 – B Dobbin Road • Columbia, MD 21045 • USA Telephone 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com (email: [email protected]) CERTIFICATE OF COMPLIANCE MANUFACTURER NAME & ADDRESS: DATE & LOCATION OF TESTING: SAMSUNG ELECTRONICS CO., LTD. Date(s) of Tests: March 7-15, 2006 18600 Broadwick Street Test Report S/N: 0603010136 Rancho Dominguez, CA 90220 Test Site: PCTEST Lab, Columbia, MD FCC ID: A3LSGHT709 APPLICANT: SAMSUNG ELECTRONICS CO., LTD. SUMMARY: Model No.: SGH-T709 Equipment EUT Type: Samsung Dual-Band GSM Phone with WLAN Max. Output Power: 0.0283 W (14.5 dBm) Peak Conducted Frequency Range: 2412 - 2462 MHz (DSSS/OFDM) FCC Classification: Digital Transmission System (DTS) FCC Rule Part(s): Parts 15.247; ANSI C-63.4-2001 Test Device Serial No.: S/N: FC-164-J This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C-63.4-2001. I authorize and attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Digital Transmission System (DTS), 15.247 PCTEST LAB TEST REPORT 15.247 FCC Measurement Report Reviewed by: Quality Manager Filename: 0603010136 Test Dates: March 7-15, 2006 EUT Type: Samsung Dual-Band GSM Phone w/ WLAN FCC ID: A3LSGHT709 Page i of i © 2006 PCTEST Engineering Laboratory, Inc. CONFIDENTIAL PROPERTY OF PCTEST TABLE OF CONTENTS ATTESTATION STATEMENTS.............................................................................................................................1 FCC 15.247 MEASUREMENT REPORT COVER PAGE..................................................................................2 1.0 INTRODUCTION...................................................................................................................3 1.1 EVALUATION PROCEDURE.......................................................................................................................................3 1.2 SCOPE.................................................................................................................................................................3 1.3 PCTEST TEST LOCATION..........................................................................................................................................3 2.0 PRODUCT INFORMATION.......................................................................................................4 2.1 EQUIPMENT DESCRIPTION........................................................................................................................................4 2.2 ENCLOSURE.........................................................................................................................................................4 2.3 EMI SUPPRESSION DEVICE(S)/MODIFICATIONS..............................................................................................................4 3.0 DESCRIPTION OF TEST...........................................................................................................5 3.1 CONDUCTED EMISSIONS..........................................................................................................................................5 3.2 RADIATED EMISSIONS..............................................................................................................................................6 4.0 ANTENNA REQUIREMENTS......................................................................................................7 5.0 TEST EQUIPMENT CALIBRATION DATA.......................................................................................8 EXHIBIT A. SUMMARY OF TEST RESULTS..............................................................................................................................9 EXHIBIT A. 6dB BANDWIDTH MEAUREMENT (802.11B)..........................................................................................................10-12 EXHIBIT A. OUTPUT POWER MEASUREMENT (802.11B)........................................................................................................13 EXHIBIT A. POWER SPECTRAL DENSITY..............................................................................................................................14-16 EXHIBIT A. BANDEDGE........................................................................................................................................................17 EXHIBIT A. RADIATED FUNDAMENTAL & HARMONIC MEASUREMENTS................................................................................18-20 EXHIBIT A. RADIATED RESTRICTED BAND MEASUREMENTS................................................................................................21-22 EXHIBIT A. RECEIVER MODE LINE CONDUCTED & RADIATED SPURIOUS.............................................................................23-24 EXHIBIT B. LABELING REQUIREMENTS................................................................................................................................25-26 EXHIBIT C. BLOCK DIAGRAM/SCHEMATICS........................................................................................................................27 EXHIBIT D. OPERATIONAL DESCRIPTION............................................................................................................................28 EXHIBIT E. TEST SETUP PHOTOGRAPHS...............................................................................…

Text truncated - open the document above for the full version.

Test Setup Photos
